Califone Portable Hands-free Wireless Audio Package... User manual

Distributed by:
Portable Hands-free W reless
Aud o Package
Model PA300UHF-PL
1. The 30W R S Wireless PresentationPro is powerful enough
for groups up to 500 people with (un)balanced XLR / 1/4”
mic and phone jack aux inputs, volume and tone controls
2. Omnidirectional bracket includes hardware for
tripod mounting and for permanent installation
3. Portable tripod with carry case for mobility and storage
4. atching 16-channel UHF belt pack transmitter with
lavalier mic with 150’ range
5. Foam-lined carry case for safe storage
• Ideal for mobile presenters, classroom and athletic uses
• Warranty for school use - unlike some other audio products
whose warranties would be voided if used in schools
Perfect for classroom & AV cart uses,
church meet ngs, small theaters,
assembl es and ndoor/outdoor funct ons,
the portable PA300UHF-PL s as s mple
to use as t s powerful for vo ce ampl -
f cat on and mult med a presentat ons.
It del vers hands-free operat on w th ts
laval er m c and belt-pack transm tter.
And w th ts w reless connect v ty,
add t onal speakers can be eas ly and
qu ckly added for even greater aud ence
coverage.
“Project Intercept"
Please contact us immediately if you experience any
difficulties with your Wireless PresentationPro System. Our
“Project Intercept" customer service program will quickly
repair or replace items under warranty. Simply contact us
via phone or email [email protected].
Visit our website at www.califone.com to learn more about
the complete line of wired and wireless Califone®head-
phones and other audio products including: Public address
systems, wireless microphone systems, group listening
centers,multimedia players and computer peripheral products.
We are proud of helping teachers enhance student
understanding and achievements since 1947, with
your satisfaction as our first priority.
This Wireless PresentationPro System carries a one-year
warranty (limited six year speaker warranty), with service
support available through authorized dealers nationwide.
Rated Power Output: 30 watts R S
UHF Receiver Specs 16 selectable channels, 740 - 801.80 mHz
Speakers: Woofer: 5-1/4” High efficiency; Tweeter: 13mm mylar dome
Inputs: Line inputs (2): Hi-Z, RCA (summing L+R)
Balanced mic: Hi or lo-Z, w/ phantom power (+15 volts D.C.)
Unbalanced mic: Lo –Z, 1/4”-phone
Auxiliary: Hi-Z ono 1/4”-phone
Line Output: 250mv constant
AC Power Requirements: 110-125VAC,50/60 Hzor 208-240 VAC, 50/60 Hz
Dimensions (HWD): 6-1/4” x 10” x 8-1/2”
B-350
Weight capacity Rated to 66 pounds, 30 kg
Bracket composition 1018 Carbon Steel, black powder-coat finish
Knobs 4-finger shaped, high-impact ABS polymer
Inserts Permanently affixed brass with sunburst teeth
TP-30
Weight Capacity aximum rating to 55 pounds
Tubing 1-1/8” aluminum
Knob Triangle shaped, high-impact ABS plastic
Cordura Carry Bag Two Nylon handles, top flap zipper access
Dimensions; Folded 36”L x 3.5”W x 3.5”H
Unfolded in/ ax height 34”-68”
Footprint 30” triangle (from tripod leg tip to tripod leg tip)
( -316) Belt Pack Transmitter / (L -316) Adjustable UHF Lapel mic
4.5oz. transmitter, 16 channels, 160’ range
2005 Case 22”L x 22”H x 10”D, with protective foam lining
For more information on any of the Wireless PresentationPro system
components, consult their individual spec sheets.
Weight 36 pounds total shipping weight of system
Safety Ratings CE/C-UL approved safe for use in school,
business, church and government facilities
Warranty 1 year from date of purchase
Spec f cat ons
PA300UHF-PL , arch 2007
Califone®International Inc. 800-722-0500
www.califone.com
1
23
5
4
