Calivita AQUARION User manual

AQUARION
Warning: Incorrect installation and/or operation could void your valuable warranty.
Please protect your investment! READ THIS MANUAL CAREFULLY
Owner’s Manual
for your new

1
2
A L K A L I N E I O N I C W A T E R S Y S T E M
TABLE OF CONTENTS
Description
Dear Customers ...............................................................................................................................................
What is alkaline electrolyzed-reduced water? ........................................................................................
Why the Orion is the world’s most advanced ionizer ..........................................................................
Safety Precautions
Power Related ...................................................................................................................................................
Installation Precautions .................................................................................................................................
During Usage ....................................................................................................................................................
pH Reagent Liquid Precautions ..................................................................................................................
Some helpful tips ..............................................................................................................................................
How to Use
Names and functions of Parts I ...................................................................................................................
Names and functions of Parts II ..................................................................................................................
How to Install ....................................................................................................................................................
How to Use ........................................................................................................................................................
How to Measure pH .......................................................................................................................................
How to set your individual pH levels ........................................................................................................
How to Add Calcium ......................................................................................................................................
Regularly check and clean your Pre-Filter ..............................................................................................
How to Replace the Filter .............................................................................................................................
About your Biostone Filter ...........................................................................................................................
Customer Service
Trouble shooting guide ..................................................................................................................................
Specifications ....................................................................................................................................................
CONGRATULATIONS ON YOUR NEW PURCHASE!
You have just purchased the finest, most advanced water system in the world! Your new ionizer
is designed to provide you with many years of the cleanest, healthiest and most “functional” water
available. There are many specific uses and benefits of this amazing water, so read this manual
carefully to learn how to get both optimum performance out of your ionizer and to protect your
investment.
Your new Aquarion produces filtered alkaline, ionized water.
Just exactly what is that? The Aquarion employs computer accurate and selectable magnetic energy
to perform electrolysis through patented platinum bonded titanium electrodes inside a water cell.
Inside this advanced cell, the magnetic energy separates the water into an alkaline (high pH) and
acid (low pH) stream without using any chemicals.
Ionizing the water in this way re-structures the molecules and reduces their cluster size, binds
extra oxygen molecules, and concentrates ionized, absorbable and beneficial minerals like Calcium,
Magnesium and Potassium.
Your new Aquarion also produces Acidic water. This type water is low in pH, less than
pH6 and has many excellent uses. You will now have the convenience and benefits of water that
“functions” in many ways that ordinary tap, filtered or bottled water cannot.

3
4
A L K A L I N E I O N I C W A T E R S Y S T E M
What is alkaline electrolyzed – reduced water?
You can get alkaline/acidic electrolyzed-reduced water by electrolyzing the water after filtering impurities. Alkaline
reduced water is the optimal water for health because it is rich in minerals including calcium. Acidic water is good for
skin.
Some uses for the different levels of Alkaline water
What would I use the Purified water for?
For initial consumption period (4-7 days).
Let your body adjust slowly to the increase in pH.
Many people find that this lower level is actually perfect for them.
After the adjustment period you can drink the water at this next level.
This level is also great for cooking rice and other grains – fluffier and great tasting!
Some people like this for drinking though it can start to taste strong
It is superb for making tea or coffee as it enhances the taste and reduces bitterness!
Generally most people find this very strong tasting and with powerful detoxifying effects.
Great for boiling vegetables! Alkaline water will eliminate the bitter taste and brings out more of their natural
color.
The pH of Purified water is neither raised nor lowered and would be
the same as your tap water.
This water is simply cleaned of impurities by the advanced filtration system.
You can use it both as drinking water and to take medications with.
1
2
3
4
Some uses for the different levels of Acidic water
The Acid water has both antiseptic and antibacterial properties.
It also has an astringent effect and can be used for cosmetic purposes.
Use it while brushing your teeth,
gargle with it and use it as
a natural mouth wash!
It is an excellent astringent;
use it for washing your face or
as a natural after shave.
This setting has sterilizing
properties - use it to sterilize
cutting boards, dish towels etc…
In the kitchen use it to help
clean kitchen utensils.
12
3 4
Precautions for use of Alkaline water – don’t develop a “drinking” problem!
• If you have never consumed alkaline water - do not use a setting higher than 1 to begin with.
• Let your body adjust slowly and naturally for 4-7 days. After this initial adjustment period, you can gradually increase
the alkalinity of the water.
• Do not take medications with alkaline water. Take medications only with purified water.
• Consult with a physician before drinking alkaline water if you have:
– Chronic disease
– A dysfunctional liver or intestines
– Are currently under medical treatment
• Do not drink alkaline water if you have achlorhydria.
• Consult a physician before using acidic water if you have:
– Sensitive skin
– Allergies
• Only use potable drinking water in your ionizer.
• Poor water quality may have negative effects on your health and your ionizer! Most municipal water sources will be
fine in your ionizer.
• Well water and water from smaller systems should be checked, and may require pre-filtering. Your ionizer is not
under warranty for any damage or required cleaning caused by hard water deposits.
Safety Precautions
Please read these pages carefully. They contain very important information to keep YOU and your new ionizer safe!
Do’s and Dont’s
Warning Property damage, serious injury or death may result if these instructions and precautions are not observed.
Physical injuries or material damage may be caused if the instructions are not observed.
Caution
Disconnect the power cord from
the wall outlet.
Ground product for protection from
electric shock.
Do not touch it.DO
DO NOT Do not disassemble it.

5
6
A L K A L I N E I O N I C W A T E R S Y S T E M
Why the Aquarion is the world’s most
advanced ionizer
Water selection and mode indicators
A revolutionary new automatic dynamic flow system employing
patented SOL valves.
5-layered platinum-titanium electrodes
Triple diaphragms
Mountain range-like specialized electrodes
Top quality 9 step single-body nano-silver multi-stage filter
One-touch ON/OFF water supply Flux control
MICOM control system
Enhanced convenience in filter replacement
Digital Filter Life Indicator
9 settings for pH
Voice Indicator
Your ionizer has an attractive colored FND display that easily identifies your selections.
With the SOL valve system, your ionizer produces top quality alkaline water without the separate cleaning cycle
of every other ionizer. The SOL valve system keeps desirable flow levels and pressure which prevents scale build
up and protects from overloading the electrolysis cell.
This feature also reduces the amount of flow from the Acidic drain line.
We use the most advanced platinum-titanium electrode plating process that consistently produces water with
optimum ORP (Oxidation Reduction Potential) at the selected pH level.
Unique diaphragms made of natural pulp coated with PE and processed with surfactants keep pH, ORP and ion
exchanges between acid and alkaline uniform despite changes in pressure, flow amount or velocity.
They prevent scale buildup by employing a new material called fremion.
When a cross section of an electrode is examined at 700 times magnification, you can see that the electrodes
have very sharp points and form valleys.
Your ionizer employs special electrodes that generate reduced water with optimal ORP and stable pH level.
Premium filter materials ensure production of healthier and cleaner water, trapping a wide variety of
contaminants while allowing beneficial minerals to pass through.
Unlike the ionizers with a manually controlled water supply, where users must constantly check the flow rate,
your ionizer has patented SOL valves which automatically control the flow rate. This ensures you ease of use and
optimal operation - no guess work involved!
Fully automated flux control through an advanced new patented valve system greatly enhances the
optimization of pH and ORP in your water.
MICOM control system optimizes the pH and ORP of your water and helps keeps your ionizer in top working
condition.
A new indicator light alerts you if service is needed on your ionizer.
You remove the filter cover and the spring-loaded filter housing makes it a snap to replace your filter. MAKE
SURE NOT TO THROW AWAY THE GRAY FILTER CUP AT BOTTOM OF FILTER!!!
The easy to read digital indicator gives you an approximate indication of remaining water filter life. Optimum
performance is ensured by always changing your filter on time. In addition to the digital counter, a new indicator
light will flicker when your current filter life is up, reminding you to change your filter.
Wide choice range of pH. Enhanced convenience with One-Touch operation
A voice alerts you to your selection of alkaline, acidic or purified water.
You can adjust the volume level or simply switch the sound ON/OFF as you desire.
Easy to understand symbols and colors identify the type and level of water you have selected on the machine.

7
8
A L K A L I N E I O N I C W A T E R S Y S T E M
Safety Precautions
If a break down occurs, do not make a repair by yourself. Contact the place of purchase or A/S center.
Electrical power precautions
If your ionizer becomes submerged in water, unplug the power cord
from the wall BEFORE removing the ionizer from the water.
Failure to do so may cause electric shock!
NEVER attempt to repair or service the unit yourself.
Contact your dealer.
Attempting to do so will void your valuable warranty!
Do not use your ionizer at voltages other than specified (AC 110V FOR USA).
Use a GFI outlet. Do not plug in your ionizer where it will exceed
the rating of outlet or electric wiring.
Failure to do so can result in fire, injury and/or damage to yourself,
wiring or ionizer!
NEVER touch the power cord or plug with wet hands
– this may result in electric shock!
Ensure the power plug is firmly and properly inserted into the outlet
– failure to do so may result in electric shock or fire!
Do not wash your ionizer by immersion or by pouring water over the main body;
always unplug your ionizer while cleaning the casing.
Clean with damp sponge or cloth.
Protect your ionizer from freezing temperatures.
Installation Precautions
Protect your ionizer from direct sunlight.
Do not put anything heavy on top of your ionizer.
Do not install your ionizer on an unstable or soft surface.
Install only on a hard and level surface.
Maintenance Precautions
Common Sense Precautions
Always unplug your ionizer when changing the fuse or cleaning
your ionizer – failure to do so may result in electric shock.
Do not attempt to repair or service the unit yourself. Contact your dealer.
Attempting to do so will void your valuable warranty!
Make sure to use your ionizer only with potable water which is suitable for
human consumption.
DO NOT use your ionizer with well water, water with extreme hardness, high
sediment or TDS levels without first consulting your dealer.

9
10
A L K A L I N E I O N I C W A T E R S Y S T E M
Safety Precautions
During Use
pH Reagent Liquid Precautions
Some helpful tips
Do not run hot water through your ionizer.
Unplug your ionizer if you plan not to use it for an extended period
or turn off the main power switch on the back of the unit.
Filter replacement may be necessary.
Do not expose the pH measuring reagent to extreme heat, flames
or fire. It is combustible.
Do not drink the pH reagent liquid, put it in the eyes or apply to the body.
– If the liquid is ingested, induce vomiting immediately and call
a doctor.
– If the liquid gets in the eyes, flush immediately and thoroughly
with cool water; call a doctor.
– If spilled or dropped on your body, wash if off immediately.
Make sure to keep the pH reagent liquid tightly closed and out of the reach of
For storing your alkaline water, glass or ceramic is best. Always try and keep your
stored water cool and away from direct sunlight.
You can use plastic, but only use lexan (number7) or poly bottles (Nalge type).
It is always best fresh out of the machine and ideal if consumed on a day-today
basis.
Do not store alkaline water in stainless steel, bronze or aluminum containers.
Save the box and Styrofoam your ionizer came packed in.
This will help if your ionizer needs to be transported at a later date.
Do not use an ionizer downstream of a sodium-based ion exchange softening
Do not clean by pouring water over or spraying the ionizer.
Do not close, bend, pinch, press or otherwise obstruct output ports
or hoses.
If the appliance makes strange or unusual noises or burning
smells are detected, unplug the power cord immediately and
contact your dealer to arrange service.
Unplug your ionizer if you plan not to use it for an extended
period or turn off the main power switch on the back of the unit.
Filter replacement may be necessary.

11
12
A L K A L I N E I O N I C W A T E R S Y S T E M
Names and functions of Parts I
Front
Back
Body
Function display panel
Flexible stainless steel
alkaline water outlet.
Filter cover
Main switch
AC
Power cord
Tap water inlet
Acidic water outlet port
Huse holder
Volume
controller
Calcium cap
Rear cover

13
14
A L K A L I N E I O N I C W A T E R S Y S T E M
Names and functions of Parts I
Indicators
Alkaline water display indicator
Acidic water display indicator
Purified water display indicator
Alkalinity pH indicator
pH level indicator
Acidic level indicator
Flux indicator
Filter life indicator
Filter replacement indicator
Caution light
“POWER” button
“ALKALINE” water button
“ACIDIC” water button
“PURIFIED” water button
“MELODY” button
Turns the sounds On or Off. Additionally, the volume can be adjusted
on the back.
Used to select purified water.
Used to select acidic water and the desired level (1-4)
Used to select alkaline water and the desired level (1-4)
Starts and stops water flow into your ionizer.
When this light is lit the appliance needs to be serviced.
Flickers when the filter needs replacing.
Counts filter usage in a digital display.
Indicates the water flow in your ionizer.
An orange symbol shows which level of alkaline water is selected.
A blue symbol shows which level of alkaline water is selected.
The green indicator will light when purified water is selected.
The orange indicator will light when acidic water is selected.
The blue indicator will light when alkaline water is selected.
When alkaline water is selected a blue number (1-4) will indicate which level.
When acid water is selected an orange number (1-4) will indicate which level.

15
16
A L K A L I N E I O N I C W A T E R S Y S T E M
1. ATTACH DIVERTER TO YOUR TAP – Remove the aerator from tap (pliers may be required), and attach
diverter valve in its place. There are adapters supplied in case the diverter does not fit your tap.
If you have leaks at the diverter, use plumber’s Teflon tape (available at any hardware store for a couple of dollars).
2. CUT A FOUR INCH LENGTH OF WHITE HOSE - Using a very sharp utility knife, cleanly cut a four inch
length of the white hose. The cleaner you make your cut, the less likely you will experience a leak.
3. ATTACH THE IN-LINE PRE-FILTER –
There is a small black arrow on the pre-filter indicating water flow direction.
The arrow on the pre-filter will POINT AT YOU IONIZER indicating water
flowing toward the ionizer. Insert the four inch length you cut into the end
of the pre-filter making by pushing firmly ensuring the arrow is pointing
at the end of the four inch hose. The four inch length will be between
your ionizer and the pre-filter.
4. ATTACH THE TAP WATER INLET HOSE TO YOUR IONIZER –
Attach the free end of the four inch length of white hose with the pre-filter
attached to the gray port on the bottom of the ionizer. To attach the white inlet
hose, by pushing it firmly into the grey tap water inlet port.
(To remove it, press on the end of the fitting and pull it out at the same time).
5. POSITION YOUR IONIZER – This can be beside the sink, to the rear of the sink, or on the wall above the
sink (there are keyhole slots on the back for this). Make sure it is on a hard and level surface
Connect the external valve between the hoses.
If the water pressure is excessively high, adjust the water flow by turning
the external valve.
To get the proper pH and ORP value of ionized water, set the external valve
to allow 1.5 liters of water per minute to flow through the ionizer.
How to install the external valve
Installation method
How to Install
To have the pe of ionized water, adjust the volume of water flow to
the level 2 controlling the external valve.
How To Install
Accessories
Inlet Acidic water
outlet
pH test kit Spare adaptor Hose Color chart Manual
1/4” hose
DUST PRE- FILTER
Your new Orion gives you the option of three installation methods:
1) at your sink attached to your faucet with a diverter,
2) at your sink but plumbed directly to your cold water line (no diverter) and,
3) undersink - completely out of sight with a small dedicated faucet.
It is recommended that methods 2) & 3) be done by a plumber.
Installation Method 1. At the sink with a diverter (easiest)

17
18
A L K A L I N E I O N I C W A T E R S Y S T E M
3. CUT A FOUR INCH LENGTH OF WHITE HOSE
Using a very sharp utility knife, cleanly cut a four inch length
of the white hose. The cleaner you make your cut,
the less likely you will experience a leak.
You will use this piece in the next step.
4. ATTACH THE IN-LINE PRE-FILTER
There is a small black arrow on the pre-filter indicating
water flow direction.
The arrow on the pre-filter will POINT AT YOU IONIZER
indicating water flowing toward the ionizer. Insert the four inch
length you cut into the end of the pre-filter making by pushing
firmly ensuring the arrow is pointing at the end of the four inch hose.
The four inch length will be between your ionizer and the pre-filter.
5. ATTACH THE FOUR INCH WHITE HOSE TO YOUR IONIZER
Attach free end of the four inch length of the hose into the gray port
on the bottom of the ionizer by pushing it firmly into the grey tap water inlet port.
(To remove it, press on the end of the fitting and pull it out at the same time).
6. POSITION YOUR IONIZER
This can be beside the sink, to the rear of the sink.
Make sure it is on a hard and level surface.
7. ATTACH THE GRAY ACIDIC OUTLET HOSE
The ACIDIC OUTLET port is on the lower right corner of the back of the ionizer, and is labeled with a red sticker.
First slide, one of the small squeeze clamps over the end of the hose.
To make it easier to attach, soak the hose in a cup of warm water for 20-30 seconds.
Firmly push the hose all the way onto the gray outlet port. Squeeze the clamp and slide it over the port.
Ensure the opposite end runs down into the sink.
Cut the hose to a convenient length.
8. CONNECT THE POWER CORD to an appropriate GFI outlet.
9. INSTALL FLEXIBLE STAINLESS STEEL SPOUT
Screw this into the port on the top of the ionizer. Do not over tighten.
How to Install
6. ATTACH THE TAP WATER INLET HOSE TO THE DIVERTER –
a. Insert the long length of white hose into the free end of the pre-filter
(see photo).
b. Remove the small compression nut on the back side of the diverter
opposite of the diverter lever.
c. Slide this nut over the end of the white hose with the threads positioned so
you can screw it back onto the diverter.
d. Push the white hose firmly onto the nipple, and then screw the compression
nut back onto the nipple. Make sure the nut is screwed firmly in place, but
do not over tighten. If you are having trouble getting hose on to the nipple,
try soaking it in hot water for a minute.
7. ATTACH THE GRAY ACIDIC OUTLET HOSE .
The ACIDIC OUTLET port is on the lower right corner of the back of the ionizer,
and is labeled with a red sticker. First slide, one of the small squeeze
clamps over the end of the hose.
To make it easier to attach, soak the hose in a cup of warm water for 20-30
seconds. Firmly push the hose all the way onto the gray outlet port.
Squeeze the clamp and slide it over the port.
Ensure the opposite end runs down into the sink. Cut the hose to a convenient length.
8. CONNECT THE POWER CORD to an appropriate GFI outlet.
9. INSTALL FLEXIBLE STAINLESS STEEL SPOUT –
Screw this into the port on the top of the ionizer.
Do not over tighten.
1. SPLIT YOUR COLD WATER SUPPLY LINE –
This can be accomplished in a variety of ways depending on how your plumbing is configured.
Most commonly, you would install a “T” junction in the cold water line.
“T” junctions are available at any good hardware store and are inexpensive.
Take the white hose when you purchase the “T” to ensure the proper size fitting.
2. ATTACH THE TAP WATER INLET HOSE TO THE “T” JUNCTION –
You will need a hole through which you can route the white hose from the “T” to your ionizer.
Most newer sinks have cutouts that will work for this.
Pull the hose up to the counter.
Installation Method 2. At the sink under direct main pressure (more difficult)
Undersink Installation (most difficult)
Undersink installations can only be accomplished with an Undersink Conversion kit.
Your ionizer will require a very specialized faucet and a variety of other parts.
The conversion kit comes complete with everything needed to complete this type of installation.
It is recommended that a plumber perform this type of installation.
Please contact your dealer.

19
20
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Use
Initial operation
To select Alkaline water
To select Acidic water
Note: Acidic water is for external use only. DO NOT DRINK
POWER UP YOUR IONIZER.
Turn the power button on.
The appliance goes into the standby mode after all the indicators go on and off
with a sound.
TURN ON THE WATER
Turn on your water supply opening you valve of faucet.
If you have your ionizer connected to your faucet with a civerter,
Turn thd lever to “divert the water to your ionizer.
Repeat steps 1-3 above, or with water is already running through the ionizer then:
Repeat steps 1-3 from Initial Operation; or with water
already running through the ionizer then:
Depress the “ACIDIC” button to select the desired setting from
1 – 4. You will hear a voice confirmation that “Acidic water” has
been selected, and the display panel will show an orange symbol
and an orange number corresponding to the level selected.
Note: Your ionizer will always “remember” the last setting used.
If the previous selection was Acidic Level 2, when you start
flow through the ionizer next time you use the ionizer it will
automatically process at Acidic Level 2.
To select a different level, depress the “ACIDIC” button to move to
next level until the desired setting level is achieved. The orange
symbol and number will change accordingly.
Depress the “ALKALINE” button to select the desired setting from 1–4.
You will hear voice confirmation that “Alkaline water” has been selected, and the display panel will show
a blue symbol and blue number corresponding to the level selected.
Note: Your ionizer will always “remember” the last setting used.
If the previous selection was Alkaline Level 2, when you start flow through the ionizer next time you use
the ionizer it will automatically process at Alkaline Level 2.
To select a different level, depress the “ALKALINE” button to move to next level until the desired setting
level is achieved. The blue symbol and number will change accordingly.
START WATER FLOW THROUGH YOUR IONIZER
– Depress the “POWER” button which opens the internal valve in your ionizer.
– The Digital Filter Life Indicator will begin to register numbers and you will hear your ionizer’s “voice”
announcing the selected mode of operation. For instance: “Purified water selected”.
– NOTE: The water may initially come out discolored (light to charcoal gray) due to carbon particulates
in the new filter. This is not harmful and is typical of all carbon filters. Allow the water to flow
for 2-3 minutes in the “Purified” mode and this will flush all the carbon dust.
POWER
POWER
ALKALINE
ACIDIC
Alkaline water levels Note: pH levels will always vary with different source water.
Descriptions of Acidic water levels Note: pH levels will vary with different source water.
Weak Alkaline water (pH7.5 – pH8.5).
This level is used for initial consumption
period (4-7 days). Let your body adjust
slowly to this increase in pH.
Weak Acidic water (pH6.5 – pH5.5). Used
for oral hygiene, mouth wash etc.
Medium to Strong Acidic water
(pH5.5 – pH5). For cleaning in
the kitchen.
Weak to Medium Alkaline water (pH8
– pH9). Move up to this level after the
initial adjustment period. Adjust to
this level for 3-4 days. Most people
will drink at level 2 or 3.
Weak to Medium Acidic water
(pH6 – pH5.5). For skin care,
as an astringent.
Strong Acidic water (pH5 and lower).
For sterilization purposes.
Strong Alkaline water (pH9.5
– pH10+). Generally, most people
find this very strong tasting and with
powerful detoxifying effects.
Medium to Strong Alkaline water (pH8.5
– pH9.5). This is the most common level
of alkalinity for drinking purposes. Some
people may start to detect a strong
change in taste.

21
22
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Use
To select “Purified” waterr How to Measure pH
How to Shut off the water flow from your ionizer
With water flowing through the machine, press the “PURIFIED” button.
You will hear a voice confirmation that “Purified water”
has been selected, and the display panel will show a green symbol.
The purified water comes out of the stainless steel spout.
Nothing comes out of the acidic outlet.
Fill one of the test tubes provided about 1/4 full
with alkaline, acidic or purified water.
Drop 2 or 3 drops of the pH reagent into the container
and shake it.
The pH value is determined by matching the color the pH
color chart provided.
• DO NOT consume water containing reagent
• Keep the pH reagent liquid, color chart, and test tubes away from direct sunlight
• KEEP pH reagent liquid AWAY FROM CHILDREN and OPEN FLAMES!
• For contact with eyes, flush liberally with fresh water, seek medical help
• If ingested, induce vomiting, seek medical help
With water running through the ionizer, depress the
power button. The water will stop and the display panel
will go dark indicating the ionizer is in standby or “asleep”.
With water running through the ionizer, depress the “MELODY” button.
All sounds except for the chime sounds will be muted.
All sound volume including the voice, the chime sound
(with or without voice muted) can be adjusted by manipulating the Speaker Volume with a small
Phillips screwdriver on the back of your ionizer.
POWER
POWER
MELODY
PURIFIED
If the reagent and water are not mixed well, the correct result may not be
displayed.
Important Note: Water quality and mineral content vary greatly in different localities and will directly impact performance
of your ionizer with respect to pH.

23
24
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Use
How to set your individual pH levels
* User can regulate the electrical current of the water ionizer based on the water source.
Turn on the main switch on the rear case
while pressing the Power button on the front.
Depress the “ALKALINE” button to raise to the desired setting, and depress the “ACIDIC”
button to lower to the desired setting.
To fix the setting you selected, depress the power button on the front.
With the beep sound, the default setting level 3 appears on the pH level indicator
of the display panel.
(You can select the desired setting from 0–6)
POWER
POWER
Standby Mode
ALKALINE ACIDIC

25
26
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Add Calcium
REGULARLY CHECK AND CLEAN YOUR PRE-FILTER
Stop the water flow prior to calcium replacement.
– Water will overflow if you open the calcium cap while
Unscrew the cap to the left and remove.
– The first time you remove it the cap
may be tight. Use a butter knife to
work it free.
Take the basket apart from the cap and dispose of the
remaining beads. The beads never completely disappear
– it’s the calcium coating on the beads that slowly releases
into the water. Beads will release calcium for about 1–2
months depending on amount of use and pH of water.
Wash the basket and remove all water.
Add the new calcium beads and close the cap.
Insert the basket into the calcium port and twist the cap
closed.
– Water will overflow if you do not close
the cap tightly.
– Keeping the pre-filter clean is critical to the proper operation of your ionizer.
– First ensure your water supply is turned off.
– Then remove the pre-filter by pressing on the end of the fitting and pulling out the hose
at the same time. Rinse out the filter thoroughly to remove any built up particulate.
– Rinse from both sides.
– Reinstall it.
– Clean the filter in this way any time you notice a decreased flow from your ionizer.
Close
Calcium
Open

27
28
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Replace the Filter
IMPORTANT! Stop water flow prior to filter replacement.
When the digital filter life indicator reaches full or you see the
flickering filter symbol, it is time to replace your filter.
Flush out the GAC carbon dust.
– The water will initially come out discolored (light to charcoal gray)
due to carbon particulates in the new filter.
This is not harmful and is typical of all GAC filters.
Allow the water to flow for 2–3 minutes in the “Purified” mode
and this will flush all the carbon dust.
Reset the filter life indicator.
– Press the “Reset” button located at the top of the filter housing compartment for 2–3
seconds while in standby mode (water not running through the ionizer).
Replace the filter housing cover.
Please replace filter when any one of the flowing occur:
– When severely polluted water has been run through the ionizer and
filter
– Excessive odor in output water and/or severely decreased flow rate
– After prolonged period of inactivity of over 30 days
Immediately after filter replacement, the water will come out black and
unclear due to the activated carbon particulates in the new filter but will
become clear momentarily. (It is not harmful.)
Open the filter housing cover.
– First, slide the cover upwards (figure 1) Then,
slide the cover to the left (figure 2) and remove it.
Remove the expired filter.
– Taking hold of the filter securely with your right hand,
press the filter firmly down against the spring loaded
mechanism (figure1) to disengage the top of the filter
and then pull it toward you (figure2) and up to remove it.
– The upper part of the filter is separated from housing by
pressing firmly down. Once you have engaged the spring
loaded mechanism, you can then easily remove the filter
from the main body by pulling it toward you.
– There will be a gray filter cup at the bottom of the filter.
Remove this piece from the expired filter and reinsert the cup into the base
of the housing.
Insert the new filter into the compartment.
– Ensure the gray filter cup has been reinserted properly into the base.
– Remove the plastic caps covering both ends of the new filter.
– Seat the large opening on the bottom of the filter cartridge onto the base
(with the black o-ring) in the center of the gray filter cup.
– Push the filter down and into the housing compartment ensuring the
opening at the top of the filter is seated properly into the fitting at the top
of the housing.
Check for leakage by running water through your ionizer before replacing
the housing cover.
Filter cover
Reset
Reset
Button Filter
cover
FILTER
EXCHANGE
How to Replace the Filter

29
30
A L K A L I N E I O N I C W A T E R S Y S T E M
How to Replace the Filter
Fiber Filter
Tap water
Solenoid valve
Filter
Water flow sensor
Water cell
Acidic water
Ultra Fine Filter
Fiber Filter
Calcium
Filber Filter
Silver Activated Carbon
Fiber Filter
Tourmaline
Fiber Filter
Calcium:
It slightly increases the alkaline mineral content in your water. It improves water taste and odors,
You get coral calcium on tap!
Tourmaline:
Tourmaline emits Far Infra Red (FIR) energy naturally. FIR produces well documented health benefits
and it also has an amazing effect on water.
The Biostone contains the semi – precious gemstone tourmaline in ceramic form, so you get FIR on
tap!
Non – woven fabric filter
Filters out sediment and particulate.
Granular Activated Carbon (GAC) :
The workhorse of the filtration media. GAC is especially effective at removing chlorine, its odor and
taste, agricultural chemicals, phenol, trihalomethane and other chemical contaminants.
Silver is impregnated into the granular activated carbon to inhibit bacterial growth in between use.
Non woven fabric filter :
Filters out sediment and particulate.
Composition of filter Flow Diagram

31
32
A L K A L I N E I O N I C W A T E R S Y S T E M
Trouble Shooting Guide
Abnormal condition Cause(s) Resolution
The Function Display
Panel does not come on.
A power plug is not property
inserted, or it is inserted into a faulty
outlet.
Properly insert power plug into a
correctly functioning power outlet
The fuse is blown.
The fuse is not inserted properly.
Replace the fuse. A spare fuse is
included in your reagent kit.
(3A / 250V fuse)
The Function Display Panel /
display indicators do not
come on even after turning
the tap on.
Faulty PCB
(Printed Circuit Board)
Immediately unplug the unit and
contact your dealer to arrange
service.
pH test shows alkaline water
color as neutral (7) while
acidic water color gets
yellow (6). This is normal
if initial pH is 6.5
Faulty or evaporated reagent: alkaline
/ acidity are always produced in
inverse proportion. Therefore,
showing an acidic color means
inversely that alkaline water has to
be generated from the unit. Lack
of alkaline color can result from a
chemical reaction where carbonic
acid in water evaporates some test
reagent elements.
Test pH value on level 3 or 4 water;
replace reagent.
Power supply is suddenly
cut off while operating the
unit.
Elevated level of salt in the water or
high TDS; extended operation at high
pH; sudden flux in electrical current.
In these cases your machine will shut
down automatically to protect the
electrodes and circuitry.
Wait - the unit will become
operational again after about one
hour. Your ionizer has a safety
mechanism built-in to protect
the electrodes and circuitry. This
mechanism will shut the ionizer
down automatically. This mechanism
protects the unit from overuse
excessive electric current.
Filter is clogged. Premature clogging
may be caused by sudden drop
in water quality and an influx of
sediment or other contaminants,
which stress the filter.
Replace your filter.
Clean Pre-filter
Low pressure in your household
plumbing.
Ensure water supply valves are fully
open. The water pressure in house
may be too low.
The input hose is bent, kinked or
therwise restricted. Straighten the bent hose.
Low output of alkaline water
from the unit.
Abnormal condition Cause(s) Resolution
Strange smell from
Alkaline water.
Expired filter from ordinary use or
premature clogging due to flux in
water quality.
Replace your filter.
Sudden flux in water quality with
elevated level of Choline
(not Chlorine). Elevated Choline
levels are observed in some areas
during summer months. These
levels fall within safe drinking water
standards, yet will cause a reaction
with ionized water causing a unique
Select lower pH level (1-2). If still
present, filter replacement may be
necessary.
You have high hardness (calcium
primarily) in your water. The white
is extracted CaCO3 (Calcium
carbonate). After Co2 in water is
bonded with Ca where elevated
levels of CO3 exist in your water. In
water where elevated levels of CO3
exist, what you see after ionization is
Co2 in the water bonded with Ca.
This is calcium! It is not only harmless,
but actually good for you. Remember
the ionizer separates and condenses
the alkaline minerals and this is what
you are seeing. You can lower the
setting (1-2) and reduce this effect.
Typically this only occurs in hard
water areas.
Your water bottle or receptacle is foul
and needs cleaning. Contamination
mixes with alkaline water when filling
your bottle. Expired filter.
Clean your bottle or receptacle.
Try selecting lower pH level (1~2).
Replace your filter.
Filter not installed correctly into filter
housing.
Remove your filter and reinstall
it properly following the filter
replacement instructions. Increase
the quantity of source water inflow.
Acidic output hose is bent, kinked or
otherwise restricted.
Straighten the bent hose; increase
water flow from supply.
Water appears milkish;
white snow like particles
in the bottom of your glass.
At first no smell, but then
smell from the alkaline
water about one hour after.
Water leakage from the
filter cartridge housing.
No acid water flow from the
acidic output port.

33
34
A L K A L I N E I O N I C W A T E R S Y S T E M
MEMO
AQUARION
