CONTACT INFORMATION
For customer service, please contact your
authorized dealer immediately. If you need
additional information and/or assistance,
contact:
LMS Customer Service Department
1462 East Ninth Street
Pomona, CA 91766.
Toll Free: 1-800-CAL-SPAS
Fax: [phone]
This guide is intended for owners of Cal Spas portable spas sold in the United States and
Canada.
If you have an in-ground spa, you will need the Cal Spas In-ground Spa Pre-Delivery Guide,
available on the Cal Spas web site.
Locating Your Spa
Pre-Delivery Checklist...............................1
Planning the Best Location ...........................1
Site Preparation....................................2
Placement of Spa for Service Access ...................3
Electrical Service Stub-up ............................5
Getting the Spa Into Your Yard
Electrical Requirements
240 Volt Electrical Installation ........................8
Electrical Installation for 11 kW Heater.................9
GFCI Wiring Diagram ..............................10
Testing the GFCI Breaker ...........................11
High Power Conguration...........................11
120 Volt Electrical Installation .......................12
Spa Technical Specications
Imperial Units ....................................13
Metric Units ......................................15

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
1
Locating Your Spa
Pre-Delivery Checklist
Most cities and counties require permits for exterior construction and electrical circuits. In addition, some
communities have codes requiring residential barriers such as fencing and/or self-closing gates on property to
prevent unsupervised access to the property by children under the age of 5. Your dealer can provide information
on which permits may be required and how to obtain them prior to the delivery of your spa.
For additional operating and installation information, please see your selling dealer.
Before Delivery
Plan your delivery route
Choose a suitable location for the spa
Lay a 3 - 4 concrete slab
Install dedicated electrical supply
After Delivery
Place spa on slab
Connect electrical components
Planning the Best Location
Safety rst
Do not place your spa within 10 feet (3 meters) of
overhead power lines.
Make sure the spa is positioned so that access to the
equipment compartment and all side panels will not be
blocked. Be certain that your installation will meet all
city and local safety codes and requirements.
Consider how you will use your spa
How you intend to use your spa will help you determine
where you should position it. For example, will you use
your spa for recreational or therapeutic purposes? If
your spa is mainly used for family recreation, be sure
to leave plenty of room around it for activity. If you will
use it for relaxation and therapy, you’ll probably want
to create a specic mood around it.
Plan for your environment
If you live in a region where it snows in the winter or
rains frequently, place the spa near a house entry. By
doing this, you will have a place to change clothes and
not be uncomfortable.
Consider your privacy
In a cold-weather climate, bare trees won’t provide
much privacy. Think of your spa’s surroundings during
all seasons to determine your best privacy options.
Consider the view of your neighbors as well when you
plan the location of your spa.
Provide a view with your spa
Think about the direction you will be facing when sitting
in your spa. Do you have a special landscaped area in
your yard that you nd enjoyable? Perhaps there is an
area that catches a soothing breeze during the day or
a lovely sunset in the evening.
Keep your spa clean
Prevent dirt and contaminants from being tracked into
your spa by placing a foot mat at the spa’s entrance
where the bather’s can clean their feet before entering
your spa. You may also consider keeping a small
water-lled basin nearby for bathers to rinse their feet
before entering your spa.
In planning your spa’s location, consider a location
where the path to and from the house can be kept
clean and free of debris.
Allow for service access
Many people choose to install a decorative structure
around their spa. If you are installing your spa with any
type of structure on the outside, such as a gazebo,
remember to allow access for service. It is always best
to design special installations so that the spa can still
be accessed.

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
2
Your spa needs a solid and level foundation. The area
that it sits on must be able to support the weight of the
spa, with water and the occupants who use it. If the
foundation is inadequate, it may shift or settle after the
spa is in place, causing stress that could DAMAGE
YOUR SPA SHELL AND FINISH.
Damage caused by inadequate or improper
foundation support is not covered by the
warranty. It is the responsibility of the spa
owner to provide a proper foundation for
the spa.
Place the spa on an elevated 3 to 4 / 30 cm concrete
slab. Pavers, gravel, brick, sand, timbers or dirt
foundations are not adequate to support the spa.
We strongly recommend that a qualied, licensed
contractor prepare the foundation for your spa.
If you are installing the spa indoors, pay close attention
to the ooring beneath it. Choose ooring that will not
be damaged or stained.
If you are installing your spa on an elevated wood deck
or other structure, it is highly recommended that you
consult a structural engineer or contractor to ensure
the structure will support the weight of 150 pounds per
square foot (732 kg / m2).
To properly identify the weight of your new spa when
full, remember water weighs 8.33 per gallon, or 1 kg
per liter. For example, an average 8’ spa spa holds
approximately 500 gallons, or 1892 liters, of water.
Using this formula, you will nd that the weight of the
water alone is 4,165 lbs, or 1892 kg. Combined with
the dry weight of the spa you will note that this spa will
weigh approximately 5,000 lbs, or 2267 kg, when full
of water.
Your Cal Spas retailer can help you with your foundation
and more. Your retailer has a wealth of information and
experience about how to get the most out of your spa
and can provide you with a full line of accessories that
are designed to complement your spa and increase
your enjoyment.
Site Preparation

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
3
While you are planning where to locate your spa, you
need to determine how much access you will need for
service.
All spa models require access to the front of the spa for
periodic service. For this reason, the spa should never
be placed in a manner where the front is permanently
blocked. Examples include placing the front of the
spa against a building, structural posts or colums, or
a fence.
For some spa models, the sides and the back do not
require service access and can be placed where you
wish, provided the spa is on a 3 - 4 / 30 cm concrete
slab. See the gure below.
Other spa models require access to the sides or rear
should if they ever need service or repair. See the
gure on page 4.
If you are planning to enclose or surround your spa
with a deck, make sure there is access for service or
repair.
These spas require clearance in
the front of the spa only.
Escape series (except ES864B,•
which also requires clearance
on the RIGHT SIDE)
Aqua series•
Zone series•
Xtream series•
Connect series•
Resort series (except R890B•
with three pumps)
Front of Spa
1’ minimum distance from
edge of concrete slab
Not to scale
Top View of Spa Frame
on Concrete Slab
Equipment Pack
Platform
Minimum of 3 feet clearance
to provide access to equipment area
Placement of Spa for Service Access

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
4
Front of Spa
1’ minimum distance from
edge of concrete slab
Not to scale
Top View of Spa Frame
on Concrete Slab
Equipment Pack
Platform
Minimum of 3 feet clearance
to provide access to equipment area
These spas require clearance in
both the front and the rear of the
spa.
Diamond series•
Fitness series•
R890B (with three pumps)•

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
5
The location of the electrical service cable is a
decision each spa owner needs to decide. Running
the electrical cable lay on top of the slab is visually
unappealling and can present a trip hazard.
Most spa owners prefer to bury electrical conduit
before the slab is laid and run the cable into the spa
cabinet. The location of the conduit in the concrete
slab is called the stub-up.
The stub-up location for both 7’ and 8’ spas should be
13 in from the left of the spa and 8 inches in from the
front of the spa. See the drawing on the next page.
We do not recommend the stub-up extending higher
than 4 above the concrete slab.
Spas equipped with a pump in the left corner will need
to have a hole drilled in the spa’s equipment pack
platform to allow the electrical wiring to pass through.
The hole should be no larger than 3 in diameter.
Electrical Service Stub-up
Front of Spa
Equipment Pack
Platform
Location of
electrical stub-up
22”
40”
Not to scale
Top View of Spa Frame
Front of Spa
Equipment Pack
Platform
Location of
electrical stub-up
8”
13”
Not to scale
Top View of Spa Frame
on Concrete Slab
This applies to all portable spas except:
Models Z522L, A621T, and A511R•
For these spas, the stub-up can be located in the left or right front
corner without interference with spa equipment.
F1770•
See the following page for electrical stub-up information for this
model.

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
6
This applies to F1770 spa only.
Front of Spa
Equipment Pack
Platform
Location of
electrical stub-up
1’ minimum
distance from
edge of
concrete slab
8”
13”
Not to scale
Top View of Spa Frame
on Concrete Slab
Front of Spa
Equipment Pack
Platform
Location of
electrical stub-up
22”
40”
Not to scale
Top View of Spa Frame
Front of Spa
Equipment Pack
Platform
Location of
electrical stub-up
8”
13”
Not to scale
Top View of F1770 Swim Spa Frame
on Concrete Slab
Swim Pump Platform
12”
12”
Location of
electrical stub-up
Access door
37½”
37½”
Minimum of 3 feet clearance
to provide access to equipment area
Access door
Minimum of 3 feet clearance
to provide access to equipment area
Swim side
Spa side

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
LocatingYour Spa
www. c a l s p a s . c o m
7
Check the Dimensions of Your New Spa
The specication chart on page 13 lists your spa’s
model and its dimension as it sits on the delivery cart.
During delivery, the spa must remain on the delivery
cart at all times. Compare the dimensions to the width
of the gates, sidewalks, and doorways along the
delivery route. It may be necessary for you to remove a
gate or partially remove a fence in order to provide an
unobstructed passageway to the installation location.
Plan the Delivery Route
Consider the following when planning your delivery
route:
Check the width of gates, doors and sidewalks to•
make sure your spa will pass through unobstructed.
You may have to remove a gate or part of a fence
to allow for adequate width clearance.
Are there low roof eaves, overhanging branches•
or rain gutters that could be an obstruction to
overhead clearance?
8’ spas need at least 42 wide gate and 9’ height•
clearance.
If the delivery route will require a 90º turn, check•
the measurements at the turn to ensure the spa
will t.
Are there protruding gas meters, water meters•
or A/C units on your home which will cause
obstructions along the delivery path to your
yard?
Are there stairs in your delivery route? If so, you•
must consult your Cal Spas dealer prior to delivery
to make adequate preparations.
Special Circumstances
The use of a crane for delivery and installation may
become necessary if you are unable to provide an
adequate delivery route. It is used primarily to avoid
injury to your spa, your property or to delivery personnel.
Your Cal Spas dealer may be able to assist you with
the arrangements. If your spa delivery requires the
use of a crane, the cost of a crane is generally not
included in the standard delivery service.
Getting the Spa Into Your Yard

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
8
All 240V spas must be permanently connected (hard
wired) to the power supply. See the wiring diagram on
page 10.
These instructions describe the only acceptable
electrical wiring procedure. Spas wired in any
other way will void your warranty and may result
in serious injury.
When installed in the United States, the electrical
wiring of this spa must meet the requirements of NEC
70 and any applicable local, state, and federal codes.
The electrical circuit must be installed by an
electrical contractor and approved by a local
building or electrical inspector.
Failure to comply with state and local codes may
result in re or personal injury and will be the sole
responsibility of the spa owner.
The power supplied to the spa must be on a dedicated
GFCI protected circuit as required by NEC 70 with no
other appliances or lights sharing the power.
Use copper wire with THHN insulation. Do not use
aluminum wire.
Use the table on the next page to determine your GFCI
and wiring requirements.
Wire runs over 85 feet must increase wire gauge to
the next lower number. For example: A normal 50
amp GFCI with four #6 AWG Copper wires run over 85
feet would require you to go to four #4 AWG copper
wires.
Electrical Requirements
All 5100DV and 6200DV control systems are set at the factory to run on the low power setting for 40 amp
operation. This is the default setting. Spa owners can have their installer change this setting so the spa will run
on high power for 50 amp operation. See conguration instructions on page 11.
Warning: Never set a spa to run on high power without installing a properly rated GFCI.
All Portable Spas (except Ultimate Fitness -- see below)
Control System Power Setting GFCI Required Wires Required
VS300 Standard One 40 amp GFCI Four #8 AWG copper wires
5100DV
6200DV
Power saver mode
(This is the factory default
setting.)
One 40 amp GFCI Four #8 AWG copper wires
High power setting
See conguration
instructions on page 11.
One 50 amp GFCI Four #6 AWG copper wires
6300DV
Power saver mode One 50 amp GFCI Four #6 AWG copper wires
Default high power setting
See conguration
instructions on page 11.
One 60 amp GFCI Four #6 AWG copper wires
9800 (except
Ultimate Fitness
spas -- see next
page)
Standard One 50 amp GFCI Four #6 AWG copper wires
240 Volt Electrical Installation

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
9
Ultimate Fitness Spas
Spa Model
GFCI
Required
Wires Required GFCI Required Wires Required
Standard conguration
(5.5 kW heater)
Conguration for Option 499 (11 kW
heater) and Option 157 (swim jets with
Speck pump)
F1418
Service 1 One 40 amp
GFCI
Four #8 AWG copper
wires
One 40 amp
GFCI
Four #8 AWG copper
wires
Service 2 N/A N/A One 30 amp
GFCI
Three #8 AWG copper
wires
F1239
F1249
Service 1 One 50 amp
GFCI
Four #8 AWG copper
wires
One 60 amp
GFCI
Four #8 AWG copper
wires
Service 2 N/A N/A One 30 amp
GFCI
Three #8 AWG copper
wires
F1640
Service 1 One 60 amp
GFCI
Four #8 AWG copper
wires
One 60 amp
GFCI
Four #8 AWG copper
wires
Service 2 N/A N/A One 30 amp
GFCI
Three #8 AWG copper
wires
F1770
Service 1
(swim side)
One 60 amp
GFCI
Four #8 AWG copper
wires
One 60 amp
GFCI
Four #8 AWG copper
wires
Service 2
(swim side) N/A N/A One 30 amp GFCI
Three #8 AWG copper
wires
Service 3
(spa side)
One 40 amp
GFCI
Four #8 AWG copper
wires
One 40 amp
GFCI
Four #8 AWG copper
wires
Electrical Installation for 11 kW Heater
This applies to Fitness spas with the 11 kW heater only.
Two electrical services are required to heat the swim side of the Fitness Spa.
R
ED A
C
W
HT A
C
J53
J
2
3
J19
J
4
3
J
48
K1
2
U
4
J
50
J
52
B
LK A
C
J
6
6
J
6
5
J
63
J
64 J4
2
J
54
J
56
J
55
J
2
5
J
5
7
J10
1
J
100
J2
6
T
B
1
CLASS
G
F
US
E 30A
C
LASS G
FUS
E 30
A
F6
F7
F4
K4
W
1
F2
K7
T1
H
TR
2
H
TR
1
F
US
E
0.3A
2
50V
K
6
K
8
G
R
B
W
J
79
J
J
46
J
4
5
J
81
12VAC
A
DC
M
J37
J37
J
4
J7
J7
J
7
4
W
8
1
2
3
FUS
E
3A
250
V
.
HO
T
BLA
C
K
NEUTRAL
WHITE
H
OT
RED
B
alboa
J11
J11
J8
J8
BARCODE
G
R
B
W
W
W
J
1
2
J
14
W1
3
W1
2
K13
W
2
0
W15
K
10
J2
MAIN
PAN
E
L
MAIN
PAN
E
L
MAIN
PAN
EL
A
UX
PAN
E
L
AUX
PAN
EL
J9
J
5
J6
K3
J
3
K
2
W
2
F
5
W
9
W7
REM
O
TE
K11
K9
J
1
K1
G
R
B
W
G
R
B
W
G
R
B
W
J
8
6
J
8
0
J60
J60
J
6
9
J
01J02
F
US
E 10A 250V
J
39
J7
1
J70
J98
J98
J8
9
J9
1
J
17
J1
5
J
13
J
83
J
22
J
24
J
82
J
3
6
TS
T
S
ENS.
A
SENS. B VAC
E
XT. 2
S
P P
U
MP 3E
X
T. R
LY
AUX
. F
J
7
2
C
F
G
S
WITCHBANK
A
S
WIT
C
HBANK
B
J9
0
J
9
7
7
G
R
B
W
J85
J85
J85
HOT
BLACK NC
HOT RED
J1
J3
Service 1:
White - NEUTRAL
Black - HOT
Red - HOT
Green - GROUND
Service 2:
Green - GROUND
Black - HOT
Red - HOT

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
10
GFCI Wiring Diagram

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
11
High Power Conguration
DIP Switch Denitions for 5100DV, 6200DV, and 6300DV systems
OFF Position (Down) ON Position (Up)
Test Mode OFF A1 Test mode (normally OFF)
Standard / Economy /
Sleep Mode changes
allowed
A2
Standard Mode only
Use Digital Duplex or
Light Duplex plane A3 Use Mini Panel
Pump 2 enabled A4 Pump 2 disabled
Single voltage heating
(240VAC only) A5 Dual voltage heating enabled
Safety Suction (must be
OFF) A6
See table at right A7 See table at right
Temperature displayed in
Fahrenheit A8 Temperature displayed in
Celsius
No circ pump; Pump 1 is
two-speed A9
Circ pump acts like Pump
1 low speed (lter cycle,
polling); Pump 1 is one-
speed
See table at right A10 See table at right
Note: Arrow indicates factory default setting.
Testing the GFCI Breaker
Test the GFCI plug prior to rst use and periodically when the spa is powered. To test the GFCI plug version,
follow these instructions. (Spa should already be plugged in and operational.)
Press the TEST button on the GFCI. The GFCI will trip and the spa will stop operating.1.
Press the RESET button on the GFCI. The GFCI will reset and the spa will turn back on.2.
The spa is now safe to use.
Number of high speed pumps
that can be run before heater
is disabled (A5 OFF)
OR
before heater runs at 120VAC
(A5 ON)
No. of
Pumps
A7 A10
0OFF OFF
1ON OFF
2OFF ON
3ON ON

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
12
120 Volt Electrical Installation
Always follow applicable local, state and federal codes and
guidelines.
Use only a dedicated electrical line with a 15-amp breaker.
Cord-and-plug connections may not use a cord longer than 15 ft (4.6
m) and must be plugged into a dedicated 15-amp GFCI connection.
Do not use extension cords!
Always use a weatherproof-covered receptacle.
Receptacle shall be located not less than 5 ft (1.5 m) from and not
exceeding 10 ft (3.0 m) from the inside wall of the spa.
Do not bury the power cord.
If your cord becomes damaged, replace it before next usage.
All 120V spas must have a GFCI. This can be either a 15-amp GFCI
receptacle or a GFCI cord and plug kit as shown below (CKIT110 -
P/N ELE09700086).

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
13
Spa Technical Specications
All sizes on this chart represent outside dimensions. Due to our continuous improvements, specications, size
and pricing are subject to change without prior notice.
Imperial Units
For spa specications in metric units, see page 15.
Aqua Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
A511R 78 Round 36 300 350 2850
A621T 72 72 35 130 600 1685
A730B 84 84 35 425 800 4340
A730L 84 84 35 425 800 4340
A750L 84 84 35 425 800 4340
A750B 84 84 35 425 800 4340
A830L 93 93 35 450 900 4650
A830B 93 93 35 450 900 4650
A850L 93 93 35 450 900 4650
A850B 93 93 35 450 900 4650
Connect Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
C736L 84 84 35 425 800 4340
C736B 84 84 35 425 800 4340
C836L 93 93 35 450 900 4650
C836B 93 93 35 450 900 4650
Diamond Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
DI760B 84 84 39.5 425 850 4390
DI760L 84 84 39.5 425 850 4390
DI780B 84 84 39.5 425 850 4390
DI780L 84 84 39.5 425 850 4390
DI860B 93 93 39.5 450 900 4650
DI860L 93 93 39.5 450 900 4650
DI880B 93 93 39.5 450 900 4650
DI880L 93 93 39.5 450 900 4650
DI970A 93 130 39.5 800 1200 7865
DI970N 93 130 39.5 800 1200 7865

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
14
Escape Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
ES734B 84 84 39.5 425 800 4340
ES734L 84 84 39.5 425 800 4340
ES750B 84 84 39.5 425 800 4340
ES750L 84 84 39.5 425 800 4340
ES850B 93 93 39.5 450 900 4650
ES850L 93 93 39.5 450 900 4650
ES861B 93 93 39.5 450 900 4650
ES861L 93 93 39.5 450 900 4650
ES864B 93 93 39.5 450 900 4650
ES864L 93 93 39.5 450 900 4650
ES938L 93 130 39.5 800 1200 7865
ES947E 93 138 39.5 900 1250 8750
Resort Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
R862 93 93 35 450 900 4650
R890B 90 90 35 450 900 4650
R890L 90 90 35 450 900 4650
Xtream Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
X750B 91 91 35 425 800 4340
X750L 91 91 35 425 800 4340
X770B 91 91 35 425 800 4340
X770L 91 91 35 425 800 4340
Ultimate Fitness Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
F1239 93 167 51 2000 1600 18260
F1418-II 93 141 51 1500 1600 14095
F1439-II 93 171 51 1800 1800 16795
F1640 93 200 51 2500 2000 22825
F1770 93 200 51 2000 (swim side)
285 (spa side)
2950 21985

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
15
Zone Series
Model
Width
(inches)
Length
(inches)
Height
(inches)
Capacity
(gallons)
Dry Weight
(pounds)
Filled Weight
(pounds)
Z522L 54 78 32 125 430 1470
Z536L 64 84 32 226 535 2420
Z628T 72 72 34 130 600 1685
Z630B 76 84 34 325 735 3445
Z630L 78 84 32 340 740 3575
Metric Units
Aqua Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
A511R 198 Round 91 1134 159 1293
A621T 183 183 89 491 272 764
A730B 213 213 89 1607 363 1970
A730L 213 213 89 1607 363 1970
A750L 213 213 89 1607 363 1970
A750B 213 213 89 1607 363 1970
A830L 236 236 89 1701 409 2110
A830B 236 236 89 1701 409 2110
A850L 236 236 89 1701 409 2110
A850B 236 236 89 1701 409 2110
Connect Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
C736L 213 213 89 1607 363 1970
C736B 213 213 89 1607 363 1970
C836L 236 236 89 1701 409 2110
C836B 236 236 89 1701 409 2110

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
16
Diamond Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
DI760B 213 213 100 1607 386 1992
DI760L 213 213 100 1607 386 1992
DI780B 213 213 100 1607 386 1992
DI780L 213 213 100 1607 386 1992
DI860B 236 236 100 1701 409 2110
DI860L 236 236 100 1701 409 2110
DI880B 236 236 100 1701 409 2110
DI880L 236 236 100 1701 409 2110
DI970A 236 330 100 3024 545 3569
DI970N 236 330 100 3024 545 3569
Escape Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
ES734B 213 213 100 1607 363 1970
ES734L 213 213 100 1607 363 1970
ES750B 213 213 100 1607 363 1970
ES750L 213 213 100 1607 363 1970
ES850B 236 236 100 1701 409 2110
ES850L 236 236 100 1701 409 2110
ES861B 236 236 100 1701 409 2110
ES861L 236 236 100 1701 409 2110
ES864B 236 236 100 1701 409 2110
ES864L 236 236 100 1701 409 2110
ES938L 236 330 100 3024 545 3569
ES947E 236 351 100 3402 568 3970
Resort Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
R862 236 236 89 1701 409 2110
R890B 229 229 89 1701 409 2110
R890L 229 229 89 1701 409 2110

Portable Spa Pre-Delivery Guide
LTR50001024, Rev. J
Electrical Installation
www. c a l s p a s . c o m
17
Xtream Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
X750B 231 231 89 1607 363 1970
X750L 231 231 89 1607 363 1970
X770B 231 231 89 1607 363 1970
X770L 231 231 89 1607 363 1970
Ultimate Fitness Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
F1239 236 424 130 7560 726 8286
F1418-II 236 358 130 5670 726 6396
F1439-II 236 434 130 6804 817 7621
F1640 236 508 130 9450 908 10358
F1770 236 508 130 7560 (swim side)
1077 (spa side)
1339 8899
Zone Series
Model
Width
(cm)
Length
(cm)
Height
(cm) Capacity (liters)
Dry Weight
(kg)
Filled Weight
(kg)
Z522L 137 198 81 473 195 668
Z536L 163 213 81 854 243 1097
Z628T 183 183 86 491 272 764
Z630B 193 213 86 1229 334 1562
Z630L 198 213 81 1285 336 1621

LTR50001024, Rev. J
1/2/13
LMS Customer Service Department
1462 East Ninth Street
Pomona, CA 91766
Toll Free: 1-800-CAL-SPAS
Fax: [phone]
www.calspas.com
