Calspas Platinum Series User manual

1
Platinum, Escape X,
& Deck Spas
2
0
2
4
Calspas Home Resorts™Owners Manual
2
All rights reserved. Duplication without written consent is
strictly prohibited.
LTR.2023.1010, REV. B-3
1/20/2023
Lloyd’s Material Supply Company, Inc.
Copyright 2023 Lloyd’s Material Supply Company, Inc.

2
2
LTR.2023.1010
1/1/2024
Lloyd’s Material Supply Company, Inc.
Copyright 2024 Lloyd’s Material Supply Company, Inc. All
rights reserved. Duplication without written consent is
strictly prohibited.
LTR.2024.1010-NC
1/1/2024

3
Important Safety Information........................
Preparing for Your New Portable Spa.....................
Location Planning.................................................
Foundation Requirements.....................................
240 Volt Electrical Installation...............................
GFCI Wiring Diagram for USA and Canada.....
Filling and Powering Up the Spa............................
Priming the Pump................................................
Gecko in.k1000+ Control System...................
Key Pad Functions................................................
Start or Stop Accessories......................................
Reading the Temperature.....................................
Sleep Mode & Settings.........................................
Water Care & Filter Cycles....................................
Energy Modes.....................................................
Reminders & Set Date and Time...........................
Set Temperature Units..........................................
Panel Lock & Unlock.............................................
in.touch Wi Set Up.........................................
Warm Weather (Thermal Creep) Control................
Error Messages & Trouble Codes...........................
Electrical Power Eciency Tips..............................
Jets & LED Lighting.............................................
Water & Air Controls............................................
ATS Therapy Seat System.....................................
Water Clarity...................................................
The Key to Clear Water.........................................
Testing and Adjusting Spa Water...........................
Sanitization & Maintenance...........................
Filter Cleaning Instructions & Bather Load.............
Troubleshooting Water Clarity...............................
Replacing Pillows & Jets.......................................
Spa Cover Installation..........................................
Draining Your Spa................................................
Winterization (Cold Climate Draining)....................
Vacation Care......................................................
Cleaning Your Spa & Freedom Sound System.........
Replacement Parts................................................
Basic Troubleshooting..........................................
How to Control Thermal Creep.............................
Warranty Information...........................................
6
8
8
9
9
10
11
13
14
14
15
16
17
18
19
20
22
23
24
29
30
31
31
32
33
34
34
35
36
37
38
40
41
43
44
44
45
47
53
55
57
Table of Contents

4
This Page is Intentionally Blank

5
This Page is Intentionally Blank

6
4

7
5

8
6
Preparing for Your New Portable SpaPreparing for Your New Portable Spa
Planning the Best LocationPlanning the Best Location

9
7
Preparing a Good FoundationPreparing a Good Foundation
240 Volt Electrical Installation240 Volt Electrical Installation

10
8
House Breaker Box
GREEN (Ground)
WHITE
(Neutral)
RED (Hot)
BLACK (Hot)
GFCI Breaker Box
Spa Control Box
E
T
I
HW
FrontView of GFCI
)dnuorG(NEER
G
RED
(Hot)
WHITE (Neutral)
WHITE (Load Neutral)
BLACK
(Hot)
BLACK (Load Hot)
RED (Load Hot)
Bottom View of GFCI
WHITE
BLACK (HOT)
RED (H
OT)
WHITE
(LOAD NEUTR AL)
One 220V circuit breaker
One GFCI
Four wires:
Red (hot)
Black (hot)
White (neutral)
Green (ground)
CIRCUIT BOARD
WHITE
(NEUTRAL)
BLACK (HOT)
RED (H OT)
GREEN
(GROUND)
GROUND TERMINAL B LOCK (ATTACHED
TO OUTSIDE OF S Y
STEM BOX)
GROUND TE
RMINAL BLOCK(ATTACHED
TO OUTSIDEOF S YSTEM BOX)
BP501G1and BP501X control boxes
WHITE
(NEUTRAL)
BLACK(H OT)
RED (HOT)
GREEN
(GROUND)
CIRCUIT BOARD
GROUND TERMINA
LB LOCK (
ATTACHED
TO OUTSIDE OF S YSTEMB OX)
BP20X control box
Control
Box
GFCI Wiring Diagram for USA & CanadaGFCI Wiring Diagram for USA & Canada
GFCI Breaker TestingGFCI Breaker Testing
IN.YE3 (2 Pump System)
IN.YE5 (3 Pump System
40 Amp
50 Amp
Four #6 AWG Copper Wires
Four #6 AWG Copper Wires
IN.YE5 (4 Pump system) 60 Amp Four #6 AWG Copper Wires
Refer to this diagram
for both:
IN.YE-5-AMP-V3
&
IN.YE-3-AMP-V3

11
10
71
Filling and Powering Up the SpaFilling and Powering Up the Spa

12
11
69

13
12
Priming the PumpPriming the Pump

14
11
+
Keypad functions
Sleep mode
Touch the screen to exit sleep mode� 3 minutes after the
last pump is turned off, the screen will shut off if there is
no touch activity�
Then Follow the instructions on the screen to access the
main screen�
Main screen
The main screen gives you access to your accessories and
water temperature� At the bottom of the screen
you will see any error or maintenance messages that are
present�
in.k1000+ keypad layout
all-on or all-off key
(one touch activation)
direct to function
selection wheel
(settings and
additional options)
on-screen
system messages
and reminders
interactive display icons
(main spa functions)
mode selection
wheel (settings and
accessories)

15
12
+
Start or stop accessories
To start or stop an accessory, touch the associated icon�
Icons will become animated when their accessory is
turned on and animation will stop when turned off�
Icons on the screen will reflect the speed or state of
the devices running on your spa� When an accessory has
more than one speed press the button until it reaches
the desired speed�
Notifications
A notification area at the top right-hand side of the screen
shows the state of certain installed accessories�
Keypad functions
Notification icons
in.touch:
• Indicates that the in�touch module is detected
and connected to a Wi-Fi network�
• A red cross indicates that the in�touch module
is detected but is not connected to a Wi-Fi network�
• An animated icon indicates that the in�touch
module is connecting to a Wi-Fi network�
For more information about the in�touch,
refer to the Wi-Fi section�
in.clear:
• The icon is green when the in�clear is
generating bromine�
• The icon is grey when the in�clear is not
generating bromine�
• A red cross indicates that the in�clear is
turned off�
For more information about the in�clear,
refer to the in�clear functions section�
in.stream 2:
• The icon is green when the in�stream 2 is on�
• A red cross indicates that the in�stream 2 is
turned off�
For more information about the in�stream 2,
refer to the in�stream 2 functions section�
in.mix:
• Indicates that an in�mix system is detected�
For more information about the in�mix system, refer
to the in�mix functions section�

16
13
+
Water temperature
The temperature shown at the bottom of the screen
indicates the current water temperature� Use the Up and
Down icons to set the desired temperature� The set point
will appear in blue� After 3 seconds without any change to
the set temperature value the current water temperature
will reappear in white�
When the set value is lower than the current temperature
Cooling to xx.x will appear below� When the set value is
higher than the current temperature, Heating to xx.x will
be indicated under the value�
Spa menu
From the home page you can access the following:
•
swim (if configured)
• in�clear (if installed)
• in�stream 2 (if installed)
• in�mix (if installed)
• Spa menu
• Settings
To select an option, slide the left wheel up or down until
the desired icon menu is highlighted in the middle�
On the right side is a menu for access to the Display and
Contrast pages�
Keypad functions
Display page
Use this page to change the display orientation�

17
14
+
Contrast page
Use this page to change the display contrast�
Settings
In the Settings page you can access the following:
•
Water Care
• Heat Pump (if installed)
• Maintenance
• Date & Time
• Keypad
• Electrical Config
• Wi-Fi
• Miscellaneous
• About
To select an item, slide the right wheel until the desired
icon is highlighted in the middle or press on the menu
name�
Keypad functions
Sleep
Press key to go directly into the sleep mode� In sleep
mode, water splashing on the keypad can't inadvertently
start/stop a pump�

18
15
+
Water Care
The Water Care page will help you set up your ideal
filtration and heating settings� Choose between
Away from Home, Standard, Energy Savings,
Super Energy and Weekender, depending on your need�
Touch the Water Care name to choose your setting�
A green checkmark will appear on the selected icon to
confirm your choice�
When you select another water care setting, a confirmation
window appears to prevent inadvertent selection that
could result in a setup modification for your spa�
In Economy mode, the set point will be reduced by 20°F*,
which means that the heating system will not be engaged
unless the temperature falls to 20°F below the spa's set
temperature�
The filtration schedule shown on the in�k1000+ screen
will apply to the main filtration pump, most likely pump 1�
If your spa uses a circulation pump configured to run
24 hours, the screen will show you the purge setting
instead of filtration�The purges are pre-programmed for
a fixed number of minutes, therefore the duration will
be set to N/A on the screen and only the start time can
be modified�
* Default pack value
Water care modes
Away from home:
In this mode the spa will always be in economy mode;
the set point will be reduced by 20° F�
Standard:
The spa will never be in economy mode and will be
filtering according to the pack's low level configuration�
Energy Savings:
The spa will be in economy mode during the peak hours
of the day and resume normal mode on the weekend�
Super Energy Savings:
The spa will always be in economy mode during peak
hours, every day of the week�
Weekender:
The spa will be in economy mode from Monday to Friday,
and will run normally on the weekend�
Keypad functions

19
15
+
Water Care
The Water Care page will help you set up your ideal
filtration and heating settings� Choose between
Away from Home, Standard, Energy Savings,
Super Energy and Weekender, depending on your need�
Touch the Water Care name to choose your setting�
A green checkmark will appear on the selected icon to
confirm your choice�
When you select another water care setting, a confirmation
window appears to prevent inadvertent selection that
could result in a setup modification for your spa�
In Economy mode, the set point will be reduced by 20°F*,
which means that the heating system will not be engaged
unless the temperature falls to 20°F below the spa's set
temperature�
The filtration schedule shown on the in�k1000+ screen
will apply to the main filtration pump, most likely pump 1�
If your spa uses a circulation pump configured to run
24 hours, the screen will show you the purge setting
instead of filtration�The purges are pre-programmed for
a fixed number of minutes, therefore the duration will
be set to N/A on the screen and only the start time can
be modified�
* Default pack value
Water care modes
Away from home:
In this mode the spa will always be in economy mode;
the set point will be reduced by 20° F�
Standard:
The spa will never be in economy mode and will be
filtering according to the pack's low level configuration�
Energy Savings:
The spa will be in economy mode during the peak hours
of the day and resume normal mode on the weekend�
Super Energy Savings:
The spa will always be in economy mode during peak
hours, every day of the week�
Weekender:
The spa will be in economy mode from Monday to Friday,
and will run normally on the weekend�
Keypad functions
The selection of dierent energy modes
you can set specic ltration cycles for
each energy mode.
Selecting a mode that matches your
usage can help keep electrical costs low.
For most owners, we would
recommend weekender mode as this
will tell the heater to be active only on
weekends, and to maintain within your
selected temperture range during the
week.

20
19
+
Keypad functions
Reminders
The in�k1000+ keypad will provide reminders about
maintenance required on your spa, like rinsing or cleaning
the filter� Every task has its own duration based on
normal use�
The Reminders menu allows you to check the time left
before maintenance is required, as well as to reset the
time once a task has been completed�
To reset a task, select it by pressing the curved arrow,
then confirm when prompted� Once you have confirmed,
the task will be reset�
You can also use the option Reset Reminders to reset all
the reminders�
Date and Time
Use this page to change Date/Time settings�
Standby
The Standby mode allows you to service your spa� Pumps
will stop for 30 minutes and will automatically restart after�
The normal page will return at the end, once the pumps
will be restarted�
Maintenance
From the Maintenance page you can access the following:
• Reminders
• Standby
To acces the desired option simply touch the
corresponding menu item�
