CAMDEN WC13PS Series User manual

Page 1 of 11
WC13PS Series Restroom Control
INSTALLATION INSTRUCTIONS
Electrified Locks, Relays and Timers
1. GENERAL DESCRIPTION
The Restroom Control Kit allows access in and out of a Restroom,
with the ability to secure the door to make patrons aware that
the location is either occupied or vacant.
The CX-WC13PS Series of Restroom Control Kits are controlled
by Camden’s advanced relay logic controller model CX-33. The
CX-33 currently has 2 pre-set modes that will accommodate
most Restroom applications. When used to control a Restroom
application, the modes most often used will be Mode 7 (normally
unlocked) or Mode 8 (normally locked). The default Mode for
the CX-WC13PS is Mode 7 (normally unlocked). Each Restroom
Control Kit will have the ability to physically open the door then
allow the patron to lock the door once inside. When locked the
CX-33 will change the coloring of the inside & outside PUSH TO
OPEN buttons from green to red displaying that the Restroom
is in use. When the inside PUSH TO OPEN is pressed it will
unlock the door, then (physically) open the door and change the
coloring of the inside & outside PUSH TO OPEN buttons back to
green, displaying that the Restroom is now vacant. The locked
Restroom can be unlocked by either pressing the inside PUSH TO
OPEN which will reset the system back to unlocked, or by using
the crash bar, paddle or turning the knob set to open the door
contact circuit and resetting the CX-33.
The CX-WC13PS Series of Restroom Control Kits use Camden’s
trademark Aura boards. The Aura circuit board is installed behind
the outside PUSH TO OPEN and inside PUSH TO LOCK push
buttons and can be seen easily seen by patrons at a distance.
2. INSTALLATION
Operation at a Glance
When the exterior PUSH TO OPEN button is pressed it will
trigger the PBTN input on its Aura board causing its N.O. relay
contact to send a momentary closure to the outside PUSH TO
OPEN on the CX-WC13PS allowing the door to swing open.
When the interior PUSH TO LOCK button is pressed it will trigger
the PBTN input on its Aura board causing its N.O. relay contact
to send a momentary closure to inside PUSH TO LOCK causing
the CX-WC13PS to lock the Restroom and switch the Aura colors
from green to red. The inside PUSH TO OPEN button is wired
directly to inside PUSH TO OPEN on the CX-WC13PS.
When pressed the Restroom will unlock and the door will swing
open. The Restroom can also be unlocked by opening the door
from the inside which will break the door contact circuit causing
the CX-WC13PS to reset and unlock the door. The Aura’s will
switch back to green signalling the Restroom is now vacant.
Mounting
IMPORTANT: Do not apply power to the unit until you
have fully read the instructions and have made the
required adjustments.
The CX-WC13PS cabinet should be mounted in a clean dry
location out of direct contact with the elements.
Wiring the CX-WC13PS Series Restroom
Control Kit is as follows:
The CX-WC13PS comes from Camden with the CX-33 pre-wired
to a labeled set of two terminal strips. This will make the wiring
of the push buttons easier since the wiring manual will no
longer need to be directly referenced for termination points. A
complete wiring diagram is adhered to the inside of the door
to provide a layout of the wiring as a reference when wiring the
eld devices to the kit.
There are two terminal strips that mirror the locations on the
CX-33. The left strip is used for power to the CX-33, the PUSH
TO OPEN and PUSH TO LOCK buttons, the door position switch,
and the Wet trigger. The right strip is for the outputs to drive the
strike (Relay 1), door operator (Relay 2), Aura LEDs (Relay3), and
to provide DC power for the door strike.
Once all eld devices are wired to the CX-WC13PS, then AC
power can be wired in.
IMPORTANT: Conrm the electrical panels breaker you are
going to be using is currently off. Do not wire the primary
terminals of the transformer until the secondary terminals
are connected rst.
The supplied CX-TRX-5024 transformer will have its secondary
terminals wired to the terminals on the top of the left terminal
strip marked as “AC”. Next, wire the primary terminals to the AC
feed to be used. Conrm your connections and apply power by
turning on the electrical panel breaker.

Page 2 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
Selecting a Mode
The CX-WC13PS has two Restroom applications built in (Mode
7 & 8). The default mode for the CX-WC13PS is Mode 7
(normally unlocked).
Determining which mode is correct for you will be based on
whether the Restroom will be normally unlocked (Mode 7) or
normally locked (Mode 8).
There are three LED displays that will allow you to see what mode
you have selected when advancing through the modes. To change
the mode of the CX-WC13PS simply press the MENU button once
and use the UP button to advance to the desired mode.
Editing the Settings for a Mode
Camden builds in typical times for lock release and door
operator activation and is ready to use without changing any
parameters. If you need to change the timing or delay for an
output, it can be done by pressing the “MENU” button within the
mode you selected. Once the option is selected you can use the
“UP or DOWN” buttons to select the timing needed.
The rst option (H & 1 ashing) will be how long relay 1 will be
activated for (0-50 seconds). The second option (d & 1 ashing)
will be how long to wait before activating relay 2 (0-15 seconds).
The third option (H & 2 ashing) will be how long relay 2 will be
activated for (0-50 seconds). The fourth option (d & 2 ashing)
will be how long to wait before activating relay 3 (0-15 seconds).
The fth option (H & 3 ashing) will be how long relay 3 will be
activated for (0-50 seconds). See chart below.
Factory Reset (Defaulting the CX-33)
To return the CX-33 back to its factory default settings you will
need to remove power, then hold down the “MENU” button
while powering up the CX-33. Once started you will see the
rmware version listed then a number “1” will be displayed.
Reconnect your power and press the “MENU” button once then
use the “UP” or “DOWN” button to advance to the desired mode.
Fully test the operation of the CX-WC13PS for proper functionality.
Display (M) Description ( Mode you are in) Parameters (1-15 )
H, then 1 Relay 1 Hold Time 0.0 to 50 seconds
d, then 1 Relay 2 Delay Time 0.0 to 15 seconds
H, then 1 Relay 2 Hold Time 0.0 to 50 seconds
d, then 1 Relay 3 Delay Time Depends on Mode
H, then 1 Relay 3 Hold Time 0.0 to 50 seconds
dSets the display ON or OFF during operating mode ON or OFF
AInput delay on Activate. If other than 0.0 is selected, the input must
be held in for the time period chosen before the CX-33 will activate. 0.0 to 10 seconds
1Set Dry Input 1 to activate on normally open or normally closed contact. N/O OR N/C
2Set Dry Input 2 to activate on normally open or normally closed contact. N/O OR N/C
3Set Dry Input 3 to activate on normally open or normally closed contact. N/O OR N/C
4Set Dry Input 4 to activate on normally open or normally closed contact. N/O OR N/C
5Set Dry Input 5 to activate on normally open or normally closed contact. N/O OR N/C

Page 3 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
SURFACE MOUNT RESTROOM INSTALLATION
1. Place the white vinyl sign behind the surface aura enclosure
and place them against the mounting wall.
2. Use the #10 x 1'' pan head screws with the green pvc anchors
provided to hold the white vinyl sign and the aura enclosure
against the wall .
Note: White vinyl sign does not come with the
CM- 45/4 - 4 1/2" 'Push To Open'.
3. Place all the square rubber pads inside the ush aura enclosure.
Insert the aura board inside the ush aura enclosure, making
sure the screw holes on the aura board align with the screw
holes inside the surface aura enclosure. Use the #6 x 3/8"
self-tapping screws to tighten Aura board in place.
4. Place the Aura insert inside the surface aura enclosure, making
sure the mounting screw holes on the aura insert and the
surface aura enclosure align.
FOR CM-45/454SE1, CM-45/854SE1 & CM-45/4 SWITCHES
a. Use the 6-32 hex head screws to tighten the aura
insert slightly.
b. Fit in the assembled CM-45/4 by locating the screws
with the holes on the backplate.
c. Fit the hex key through the hole on the face plate and
completely tighten the 6-32 screws in place.
FOR CM-2520-4854SE1 COMBO SWITCH
a. Fit the plastic spacer inside the aura insert
b. Place the combo switch Inside the aura insert, making sure
the mounting holes on the aura and on the back plate align
c. Use the 6-32 Phillips screws to tighten in place.
5. Apply the label to the black vinyl as required.
Surface Aura
Enclosure
#10 x 1”
Pan Head Screw
(4 pcs)
#6 x 3/8” Phillips
self-tapping screw
(2 pcs)
5/8” x 5/8” Square Rubber Pad (4 pcs)
6-32 Phillips
screw (2 pcs)
Aura Board
Plastic spacer
(For use only on CM-2520/48)
Aura Dip Switch Settings
1REM/LOC
RELAY
SPEAKER
2
3
Enable
ON
1RED
GREEN
BLUE
RED
GREEN
BLUE
2
3
Active Color
ON
1
2
3
Idle Color
ON
= Switch Position
White Vinyl
Label
Aura Insert

Page 4 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
FLUSH MOUNT RESTROOM INSTALLATION
Flush Aura
Enclosure
Black Vinyl
Dry Wall Bracket
8-32 x 1-1/2”
Phillips Screw
(2 pcs)
#6 x 3/8” Phillips
self-tapping screw
(2 pcs)
6-32 Phillips
screw (2 pcs)
Aura Insert
Aura Board
Plastic spacer
(For use only on CM-2520/48)
Label
Aura Dip Switch Settings
1REM/LOC
RELAY
SPEAKER
2
3
Enable
ON
1RED
GREEN
BLUE
RED
GREEN
BLUE
2
3
Active Color
ON
1
2
3
Idle Color
ON
= Switch Position
1. Prepare the cut-out for the unit and t in the dry wall bracket.
2. Slide in the black vinyl behind the ush aura enclosure and t
them inside the dry wall bracket.
Note: Black vinyl does not come with the CM-45/4 - 4 1/2"
'Push To Open'.
3. Ensure the two mounting holes on the bracket and the Flush
aura enclosure align. Use the 8-32 phillips screws to completely
tighten in place.
4. Place the aura board inside the ush aura enclosure, making
sure the screw holes on the aura board align with the screw
holes inside the Flush aura enclosure. Use the #6 x 3/8"
self-tapping screws to tighten Aura board in place.
5. Place the Aura insert inside the Flush aura enclosure, making
sure the mounting screw holes on the aura insert and the ush
aura enclosure align.
FOR CM-45/455SE1, CM-45/855SE1 & CM-45/4 SWITCHES
a. Use the 6-32 hex head screws to tighten the aura
insert slightly.
b. Fit in the assembled Push plate by locating the screws
with the holes on the backplate.
c. Fit the hex key through the hole on the face plate and
completely tighten the 6-32 screws in place.
FOR CM-2520-4855SE1 COMBO SWITCH
a. Fit the plastic spacer inside the aura insert
b. Place the combo switch Inside the aura insert, making sure
the mounting holes on the aura and on the back plate align.
c. Use the 6-32 Phillips screws to tighten in place
7. Apply the label to the black vinyl as required.

Page 5 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
CX-ED2079 'UNIVERSAL' ELECTRIC STRIKE INSTALLATION
CX-ED2079 ‘Universal’ Electric Strike
1. Prepare the door jamb as per the appropriate drawing.
2. Install mounting brackets to jamb using M5x12 screws
and pressed metal nuts. Do not tighten.
3. Spacers are used to assure ush nal assembly of
faceplate into jamb. Add one of more spacers between
jamb and mounting bracket when face plate extends
beyond the jamb. When the faceplate sits inside the
jamb, spacers must be added between the mounting
bracket & the lip bracket. Make sure clearance hole in
spacer aligns with hole in mounting bracket.
4. Connect wires coming from the low voltage side of the
transformer to wires (black) from strike.
5. Install electric strike jamb by attaching with # 10-32
screws and lockwashers.
6. Secure M5x12 screws holding mounting brackets to jamb.
4. Installation
Mounting Bracket
Spacer
Spacer (Option)
Spacer
M5x12 Flat-Head Screw (2pcs)
Jamp
M5x12 Screw
Vertical Centerline
Note: The products are intended to be installed in accordance
with the installation wiring diagram, mechanical assembly
drawings provided with each product, the local authority having
jurisdiction (AHJ) and the National Electric Code, NFPA 70.
When installed in fail secure mode, the local authority shall be
consulted with regard to the use of possible panic hardware to
allow emergency exit from the secure area.
The electric door strike shall be installed in such a way and
in such a location so as to not impair the operation of an
emergency exit device or panic hardware mounted on the door.
(86mm)
3-3/8”
(187mm)
7-3/8”
(36mm)
1-3/8”
(200mm)
7-7/8”
(86mm)
3-3/8”
(86mm)
3-3/8”
(168mm)
6-3/8”
(31mm)
1-7/32”
(31mm)
1-7/32”
(31mm)
1-7/32”
(105mm)
ESP1B + ESP2B
ESP3B
ESP4B
4-1/8”
(124mm)
4-7/8”
(89mm)
3-1/2”
(155mm)
6-1/8”
(173mm)
6-7/8”
(144mm)
5-11/16”

Page 6 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
CONNECTIONS OPERATIONS
CX-ED2079 ‘Universal’ Electric Strike
Red
Black
Blue
Green
Black
Red
Blue
Green
Black
Red
Blue
Green
(+12V)
( - )
(+24V)
( - )
12V
24V
Varistor
Varistor
Power
Power
5. Connections 6. Operation
POWER
12VDC
Red/Black: +12V
Blue/Green: Ground
A varistor is provided to protect/prevent strike from spikes.
Connect varistor between input wires.
Fail Safe Changing
Fail Secure
24VDC
Red: +24V
Black/Blue: -
Green: Ground
How to modify fail-safe to fail-secure or vice versa.
1. Loosen the screw as per the product diagram below.
2. Rotate the set plate 180° and slide the plate until it
is properly seated.
3. Tighten the screw.
Note: For UL 294 / UL 1034 compliance the door strikes
are to be powered via a UL 294/ UL 603 class 2 power
limited output from a control panel and or power supply.
Furthermore, when powered by AC/DC the units shall use a
UL regulated UL 294/ UL 603 power limited class 2 output
rated 12/24V with AC on indicator.

Page 7 of 11
WC13PS SERIES RESTROOM CONTROL INSTALLATION INSTRUCTIONS
RESTROOM SIGNAGE
PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF CAMDEN DOOR CONTROLS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF CAMDEN DOOR CONTROLS IS PROHIBITED.
5502 Timberlea Blvd. Mississauga, ON Canada L4W 2T7
Tel: [phone]
www.camdencontrols.com
A.OLISA 24/01/20
Light ring on switch will turn red when door is locked.
to unlock door and exit.
TO LOCK THIS DOOR
WAIT FOR DOOR TO CLOSE
40-81C021
Place sign
on the door
inside the
restroom at
eye level
INSIDE THE
RESTROOM
POWER SUPPLY 6, 12, 24 VDC
SMP3
24V OPEN CLSD
CLSD OPEN
SW1 SW2
6V
OPEN OPEN 12V
SW1 SW2
AC
DC+
-
BAT+
-
ACAC
DC
CX-33PS
Power Supply Cabinet
to be mounted on
the wall or above
the ceiling tiles
(if applicable)

Page 8 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
Item Part Number Description
160-31A041 Blue/Red/Green Aura PC Board
260-42C012 Square Aura Insert
360-40E033 Advanced Logic Control Relay and 2 Amp Power Supply in pre-wired metal cabinet
4CX-MDA Magnetic Door Contact
560-42C019
Mounting Box, Flush Aura Enclosure.
Flame/Impact Resistant Black Polymer (ABS)
6-1/2"W X 6-1/2"H X 2"D
660-42C010
Mounting Box, Surface Aura Enclosure.
Flame/Impact Resistant Black Polymer (ABS)
5-1/4"W X 5-1/4"H X 2"D
760-81C021 English Self-Adhesive Vinyl Sign
‘’WAIT FOR DOOR TO CLOSE’’
Black Vinyl & Sign for Flush Aura Enclosure
8CM-SFE1
Black Vinyl & English Label
‘’DOOR LOCKED WHEN RED/UNLOCKED WHEN GREEN’’ &
‘’OCCUPIED WHEN RED/VACANT WHEN GREEN’’
9CM-SFF1 Black Vinyl & French Label ‘’OCCUPÉ/LIBRE’’ &
‘’PORTE BARRÉE/PORTE DÉBARRÉE’’
10 CM-SFFE1
Black Vinyl & English Label
‘’DOOR LOCKED WHEN RED/UNLOCKED WHEN GREEN’’ &
‘’OCCUPIED WHEN RED/VACANT WHEN GREEN’’
Black Vinyl & 2-sided French Label ‘’OCCUPÉ/LIBRE’’ & ‘’PORTE BARRÉE/PORTE DÉBARRÉE’’
White Vinyl & Sign for Surface Aura Enclosure Installed
11 CM-SE1
White Vinyl & English Label
‘’DOOR LOCKED WHEN RED/UNLOCKED WHEN GREEN’’ &
‘’OCCUPIED WHEN RED/VACANT WHEN GREEN’’
12 CM-SF1 White Vinyl & French Label ‘’OCCUPÉ/LIBRE’’ &
‘’PORTE BARRÉE/PORTE DÉBARRÉE’’
13 CM-SEFE1
White Vinyl & English Label
‘’DOOR LOCKED WHEN RED/UNLOCKED WHEN GREEN’’ &
‘’OCCUPIED WHEN RED/VACANT WHEN GREEN’’
White Vinyl & 2-sided French Label ‘’OCCUPÉ/LIBRE’’ & ‘’PORTE BARRÉE/PORTE DÉBARRÉE
ORDERING INFORMATION FOR REPLACEMENT PARTS

Call: 1.877.226.3369 / 905.366.3377
Visit: www.camdencontrols.com
Opening New Doors to
Innovation, Quality and Support!
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
Page 9 of 11
File: WC13PS Restroom Controls
Manual.indd
Rev.: February 26, 2020
Part No: 40-82B238
Questions? Call us toll-free at 1-877-226-3369 or technical support 905-366-3377 (ext. 505)
Notes :
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.

Page 10 of 11
WC13PS SERIES RESTROOM CONTROL
INSTALLATION INSTRUCTIONS
120 VAC
Door Position Switch
Transformer
CX-TRX-5024
24 VAC, 50 VA
Door Operator
N.C.
PUSH
TO OPEN
Remote
12/24V Power
N.O. Relay Output
Outside Wall Switch
CM-45/455SE1 (or similar)
AC
AC
Outside
Push To Open
Inside
Push To Open
Push To
Lock
DPS NC
DPS COMM
+ WET
- INPUT
+ Lock
+ Strike
-Strike
*
Door
Operator
*
LED
Control
*
+ VDC
-VDC
Aura
Dip Switch
Settings
1
2
3
4
CM-AF540SO
CM-AF141SO
GRY
BLK
N/O N/C
BLK
GRY
CX-WEC10-K2
Emergency Call System Wiring
Connect directly to DPS if no Emergency Call System is installed
CX-WC13AXFM-PS Wiring Diagram with CX-WEC10-K2 Integration
Model: 60-40E033
CM-2520/4855SE1 (or similar)
PUSH
TO
OPEN
PUSH
TO
LOCK
Inside
‘Push To Open (always unlocks & opens door)
& Push to Lock’ combination Switch
12/24
Power
Remote
N.O.
Relay
Output
Push To Open
IMPORTANT:
Ensure wiring polarity is consistent from Relay 3
to each Aura Remote Input terminals
FILENAME:
DRAWING No:
SCALE: NONE DRAWN BY: REV:DATE:
CAMDEN DOOR CONTROLS
5502 Timberlea Blvd
Mississauga, Ontario
L4W 2T7
JML Jan 20, 2020 1
CX-WC13AXFM/SM-PS & CX-WEC10K2 Wiring Diagram
Electric Strike
CX-ED2079
Notes
1. CX-33 can be set to Mode 7 (Normally Unlocked)
or Mode 8 (Normally Locked).
2. Mode 7 = Set Set Strike to Fail Safe.
3. Mode 8 = Set Strike to Fail Secure.
Wire MOV
directly to
strike or
magnet
MOV
1REM/LOC
RELAY
SPEAKER
2
3
Enable
ON
1RED
GREEN
BLUE
RED
GREEN
BLUE
2
3
Active Color
ON
1
2
3
Idle Color
ON
= Switch Position

Page 11 of 11
WC13PS SERIES RESTROOM CONTROL INSTALLATION INSTRUCTIONS
CABINET BASE
L
C
L
C
7-7/8” (200.2 mm)
Cabinet Base Mounting Template
6” (152.7 mm)
6” (152.7 mm)
9-5/8”
(243.9 mm)
11-1/16”
(281.4 mm)
