ESB101
Inrush Current Limiter
,
Inrush Current Protection
For capacitive loads, 115Vac/230Vac 16A, 16 ⅓ Hz – 440Hz, - 40°C ... +60°C
Short Specification
:
•Peak- / R.M.S. inrush current limiter
•90-132Vac / 184-264Vac, 16A continuous
•Power consumption 1,1W @ 230Vac
•DIN TS35mm DIN-Rail
•Wall mount (universal case)
•Spring-type terminals 6mm² / 10AWG
•Integrated bypass relay
•Capacitive load 1.500uF up to 10.000uF
•Integrated thermal protection
•IP20 UL94V-0 case DIN43880
for DIN/VDE0603 cutout box
•EN62368-1, EN55032 class B
The ESB is a budget-priced inrush peak
current limiter for high loads in LED-
applications, complex automation systems
and in the machine building. The ESB101
offers effective and interference free operation
with capacitive loads. It is simple to integrate
into existing equipment. The ESB101 is self-
powering and does not require an external
power supply.
No simple NTC-solution! It allows to
reduce cabling sections and to install
fast circuit breakers. 100% protection
from tripping pre-installed circuit
breakers or burning relay and line
switch contacts.
16 ⅓ Hz – 440Hz

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.2/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
Technical Table
M del
ESB101.05UPS ESB101.16 ESB101.23 ESB101.23S ESB101.33 ESB101.LED.230VAC ESB101.LED.115VAC ESB101.23S.115VAC
Peak Current
Limiting ±6%
5A
16A
23A
23A
33A
48A
43A
23A
R.M.S
Current
Limiting ±6%
3,5A
11,3A
16,3A
16,3A
23,3A
33,9A
30,4A
16,3A
Maximum A
ll wed
Capacitive L ad
1.000uF
1.500µF
2.000uF
2.000uF
4.000µF
6.000uF
10.000uF
4.000µF
Limiting Time
(T
n
P wer On)
900ms
(±50ms)
300ms
(±50ms)
300
ms
(±50ms)
500
ms
(±50ms)
300
ms
(±50ms)
300
ms
(±50ms)
300
ms
(±50ms)
500
ms
(±60ms)
Release Time
(T
ff
L w V ltage)
1400ms
(±50ms)
500ms
(±50ms)
500
ms
(±50ms)
800
ms
(±80ms)
500
ms
(±50ms)
550
ms
(±50ms)
550
ms
(±50ms)
900
ms
(±80ms)
Limiting Interval
[T
interval
f r AC
c nt.
)
≥
900ms
≥ 900ms
≥ 900ms
≥ 1400ms
≥ 900ms
≥ 900ms
≥ 900ms
≥ 1400ms
Quickest advisable
Circuit breaker at
30°C
A2A
A6A
B4A
Z6A
A10A
B6A
Z10A
A10A
B6A
Z10A
A13A
B8A
Z13A
B13A
A16A
B13A
Z16A
A10A
B6A
Z10A
AC
Input Range
184
-
26
4
Vac
90
-
13
2
Vac
AC
C ntinu us
Input Range
230Vac
115Vac
Line Frequency
16
⅓ Hz
–
440Hz
16
⅓ Hz
–
440Hz
Switch
-
On V ltage
144Vac
79Vac
AC L wer Margin
52
Vac
(
AC dump / dr p
ut v ltage
)
28Vac
(AC dump / dr p
ut v ltage
)
AC
Current
16A
c ntin
u
us
l ad current
P wer
Supply
N external p wer supply required,
item is self
-
p wer
ing
P wer
c nsumpti n
2,2W @ 115Vac / 1,1W
@ 230Vac
Limiting
Cycles
B
etween each limiting acti n shall be a break f 20 sec., t let the device c l d wn until the next limiting starts
Intern
al Pr tecti n
Thermal fuse pr tects
fr m
ver
heat
& fire
C ling
Natural c nvecti n
Operati n Temp.
Ambient temperature
-
40°C ... +6
0
°C
c nt
inu us
(see perati ns temperature list f r details in this manual)
St rage Temp.
-
40°C
...
+85°C
f r 2 years
EMI
EN550
3
2
class
B
, EN61000
-
6
-
3
EMS
EN61000
-
6
-
2
Safety N rms
EN61010
-
1, EN61010
-
2
-
201, EN62368
-
1, EN60950
-
1,
several units: ANSI/UL508 & CAN/CSA C22.2 (see pr duct list in this manual), UL-File: E485106
Safety Class
Class II
ROHS c nf rmity
ROHS Directive 2011/65/EU
REACH c nf rmity
REACH Directive 1907/2006
MTBF
Calculati n
30
0
.
000h
(IEC
/EN61709, Siemens
SN29500)
MTTF
Calculati n
384.000h (+30°C)
(IEC/EN61709, Siemens SN29500)
Humidity
95%
(+25
°C)
n t c ndensing
P lluti n Degree
2 (IEC/EN50178)
Envir nmental
T
hermal envir nment
3K3
,
mechanics
3M4 (IEC/EN60721)
Altitude max.
4
000m
(13123 ft.)
ab ve sea level
Dimensi n
s
(WxHxD)
(
Wide=
2TE)
,
36,5
x
110
x
62mm
H
using
Parameters
UL94V
-
0 (E45329), ABS/NH6020, RTI 110°C, h using f r DIN/VDE0603
cut ut b x
and f r wall m unt
DIN
-
Rail
DIN
-
Rail
TS35mm DIN/EN60715 (TS35/7,5 und TS35/15)
Weight
0,12k
g
/ 0,2
6
lb
s
C nnecti ns
Spring
-
type terminal
s lid max.
0,
18
...6mm²
2
6
…10
AWG
acc rding with
IEC/EN60664
-
1, IEC/EN61984
Use c pper c nduct rs nly. Wire stripping length 7mm. Tightening t rque per terminal bl ck is 0.5 - 0.6 Nm / 4.5 - 5.3 lbf-in

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.3/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
General Descripti n
The CAMTEC ESB101-series are the 2nd generati n and c st-effective inrush current limiters. The limiters are made f r
115/230Vac 16A netw rks. The line frequency range is 16⅓Hz – 440Hz. The ESB101-Limiter shall be l cated between
the line-switcher/c ntact r and the l ad (Fig.1). The ESB-m dels are designed f r capacitive l ads (n t f r inductive
l ads like c ils/transf rmers, n t f r AC-m t rs and n t f r DC-v ltage applicati n). In the m ment f switching- n the
system the inrush current f the installed l ad will be limited f r the defined time T
n
(Fig.4). Independent fr m the
previ us inrush level; the current limiting is always strict. After T
n
elapses the current limiting circuit f the ESB101 will
be bypassed. Then the l ad is directly c nnected t the AC. If an AC dump versh ts the defined time T
ff
, it will be
detected by the ESB101 (Fig.5). As s n as the AC rec vers the inrush will be limited, again (Fig.2 & 3). The ESB101-
m dels pr vide an internal temperature c ntr l. In case f a failure the device shuts d wn t safely prevent fr m
verheating r fire.
(Fig.1)
Field Applicati ns
The ESB101 limiter all ws c nnecting much m re capacitive l ads (e.g. LED-p wer supply / LED-driver) t a pre-installed
circuit breaker CB (Fig.1). The ESB av ids that the MCB will be tripped. This ccurs independent t the bjective initial
current. The result is that the number f A.C. branch lines and the pre-installed MCB can be reduced dramatically.
Installati n c st exhibit a sustained decline. Alternatively, the cr ss secti n f the branch lines can be reduced when
using smaller and faster resp nding circuit breakers. The c st saving fr m c pper is essential. Sensitive AC netw rks
can be fused safer (e.g. Traffic C ntr l Systems, Street-Lighting, Parking L ts and Tunnels). When the ESB101 is installed
c rrectly, the neutral wire (N) is l ped tr ugh (Fig.1). The inrush pr tecti n circuit always acts t the line c nduct r.
The l ad relates t the AC in such a way that a circuit breaker r an earth-leakage-trip w rks within the limits f the
legal rules. This fact is als applied while the limiting circuit acts. The ESB101 is designed f r capacitive l ads, nly. The
ESB101 cann t be used t gether with transf rmers, c ils, AC-m t rs & drives, heaters, hmic l ad, r with DC-v ltage
at all.

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.4/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
Special M dels ESB101.LED with 115Vac & 230Vac
C mpared t all ther ESB101-m dels the LED-types are the universal inrush current limiters. The c ncept design is
made t c nstruct ptimized A.C. netw rks in the building aut mati n and in the lighting sect r. Tripping the installed
circuit breaker will be effectively prevented. The inrush limiting time is adjusted t the values f a typical LED switch
m de p wer supply r LED-driver. The c nnectable l ad capacity is such as high, that even in the extremes cases it is
rather imp ssible t exceed it in a 16A netw rk. Installed c ntact rs will be relieved and their lifetimes will c nsiderable
increase. T pr tect the installed relay in a c ntr lled DALI-/DMX-Multiplexer we advise t use the ESB101.23 f r a 16A
relay r the ESB101.16 f r a smaller relay. N te that the ESB101 is n t designed t perate t gether with gas inducti n
lamps r ther c nventi nal lighting device. The ESB101 is designed f r capacitive l ads, nly.
Design-In f the ESB101 int A/C netw rks
The ESB101 m dels are the precise inrush current limiter with an verall t lerance f ±6% f the face value. F r the
dimensi n f an upstream c nnected circuit breaker the R.M.S is the key value f the inrush current, n t the peak
current. The thermal trigger p int will n t be met, even while using an extreme fast CB. All-d minant is the magnetic
trigger current. By using the empirical f rmula I
(peak)
x 0,707
(fact r)
= I
(r.m.s.)
the tripping current can be defined exact. Bear
in mind that all the higher the inrush current is, all the faster the input capacit r f several c nnected switch m de
p wer supplies will be l aded. Deduced by this fact we can say that within a 230V 16A A/C netw rk n t the ESB101.16
limiter is the right selecti n f r a MCB B16A, but the ESB101.LED.230VAC. The technical table n page 2 sh ws the
R.M.S value f all the ESB101 types and m dels.
Fig.5 and Fig.7
Fig.5 and Fig.7 sh w the typical start behavi r
f a NTC pr tected sample switch m de p wer
supply. The used test item is a switch m de
p wer supply n DIN-Rail.
The peak current rec rdings sh w the precise
limiting f the inrush fr m f rmerly 62A
peak
t
16A
peak
. The c rresp nding R.M.S level, that is
resp nsible f r the magnetic tripping f the
circuit breaker (MCB), is mark d wn by fact r
0,707. After the time T
n
elapsed it is identified
that the p wer supply starts neatly int the
c ntinu us perati n m de. N w the current is
abs rbed pulse-shaped fr m the AC supply.
In detail the full l ad R.M.S. current
c nsumpti n level f the sample p wer supply
hits 9,8A @ 230Vac.
62Apeak
230Vac
ton
16Apeak
230V
ac
AC input range AC input range
L
ine
v ltage
line v ltage
(Fig.4 limiting time T
n
) (Fig.5 AC dump detecti n T
ff
)
(Fig.8 inrush with ESB101)
(Fig.6 AC dump detecti n T
ff
) (Fig.7 inrush with ESB101)
(Fig.2 perating range 230Vac) (Fig.3 perating range 115Vac)

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.5/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
Mechanics
IP20 h using, UL94V-0 (E45329), ABS/NH6020 with RTI 110°C, h using f r DIN/VDE0603 cut ut b x and wall m unt.
DIN 43880 with IEC standardized ventilati n sl ts. Save fix n DIN-Rail TS35mm (7.5/15) DIN/EN60715. It is designed
f r building cabinets DIN/VDE0603. Easy t wall m unt by multifuncti nal h using; rem ve the DIN-Rail latch and
access the tw m unting h les t screw the ESB101 t any ld surface.
Connections
Clamping Yoke Connector Specifications
Input / Output connections
Tightening torque min. – max. 0,5 – 0,6Nm (blade 1,0x5,5 DIN5264 )
Touch-safe protection acc. to DIN VDE 0470 IP20 plugged/ IP10 unplugged
Clamping range, min. – max. 0,18 – 6mm² / AWG26 – AWG10
Solid, H05(07) V-U min. – max. 0,18 – 6mm²
Stranded, H05(07) V-U min. – max. 0,22 – 4 mm²
w. plastic collar ferrule, DIN 46228 pt 4 min. – max. 0,5 – 2,5mm²
w. wire end ferrule, DIN 46228 pt 1, min. – max. 0,5 – 4mm²
Plug gauge in accordance with EN 60999 a x b; ø 3,6 x 3,1mm; 2,7mm
Pitch (P) 9,52mm
Wire Stripping Length (fine wired)
Nominal Cross Section Wire End Ferrule Stripping Length
0,5mm² H0,5/6 6mm
0,75mm² H0,75/6 6mm
1,0mm² H1,0/6 6mm
2,5mm² H2,5/7 7mm
4,0mm² H4,0/7 7mm
The length of ferrules is to be chosen depending on the rated voltage. The outside diameter of the plastic collar should not be larger than
the pitch (P)
(Fig.8 mechanical drawing) (Fig.9 m unting restricti n) (Fig.10 m unting distances)

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.6/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
M unting Instructi ns
F ll w the ab ve m unting restricti ns t all w maximum lifetime f the pr duct and t prevent fr m tripping the
internal temperature pr tecti n fuse. The ESB101 is an active device. The distance between an ESB101 and the next
active r temperature sensitive device shall be 17,5mm r larger. The p wer c nsumpti n f the device is c nstant at
c ntinu us perati n (2,2W @ 115Vac / 1,1W @ 230Vac). Make sure that the ventilati n h les bel w and ab ve the
unit are n t bl cked t all w free air c nvecti n.
Operati n
Temperature
Ambient
Temperature
ESB101, 115Vac, AC 16A current
ANSI / UL 508 -40°C … +55°C
CAN / CSA C22.2 -40°C … +55°C
IEC EN62368-1 / IEC EN60950-1 -40°C … +60°C
ESB101, 230Vac, AC 10A current
ANSI / UL 508 -40°C … +55°C
CAN / CSA C22.2 -40°C … +55°C
IEC EN62368-1 / IEC EN60950-1 -40°C … +60°C
ESB101, 230Vac, AC 16A current
ANSI / UL 508 -40°C … +50°C
CAN / CSA C22.2 -40°C … +50°C
IEC EN62368-1 / IEC EN60950-1 -40°C … +55°C
Table f the standards
Pr duct C de
Camtec Article N .
IEC / EN
62368
-
1
IEC / EN 60950-1
ANSI / UL508 listed
UL-File E485106
CAN / CSA 22.2 listed
UL-File E485106
GHOST EAC #0658490
RU C-DE.MO10.B.02970
ESB101.16
(R2)
304108
1
001CA
Yes
Yes
Yes
Yes
ESB101.23S
(R2)
304108
1
002CA
Yes
Yes
Yes
Yes
ESB101.23
(R2)
304108
1
003CA
Yes
Yes
Yes
Yes
ESB101.33
(R2)
304108
1
004CA
Yes
Yes
Yes
Yes
ESB101.LED.230VAC
(R2)
304108
1
005CA
Yes
Yes
Yes
Yes
ESB101.LED.115VAC
(R2)
304108
1
006CA
Yes
Yes
Yes
Yes
ESB101.23S.115VAC
(R2)
304108
1
007CA
Yes
Yes
Yes
Yes
ESB101.05UPS
(R2)
304108
1
009CA
Yes
N t listed
N t listed
Yes
Safety regulations: Please read these instructions completely before using the equipment. Keep these
instructions
on
to hand.
The device
may only be
installed
by
trained
specialist staff
.
Installation:
1) The device is designed for devices and systems
that meet the standard requirements for hazardous
voltages, power, and fire prevention.
2.) Installation and service only by trained persons.
The AC power must be switched off. The work is to be
labelled; accidental reconnection of the system must
be prevented.
3.) Opening the device, its modification, loosening
bolts, or operation outside the specified herein
specification or in an unsuitable environment, has the
immediate loss of warranty to follow. We disclaim any
responsibility for any resulting damage to persons or
things.
4.) Note: The device must not be operated without an
upstream circuit breaker (CB). The CB must not be
larger than 16A.
Warning :
Non-compliance these warnings can result in fire
and serious injury or death.
1. Before connecting the device to the AC
network, make wires free of voltage and assure
accidentally switch on.
2. Allow neat and professional cabling.
3. Never open nor try to repair the unit. Inside
are dangerous voltages that can cause electrical
shock hazard.
4. Avoid metal pieces or other conductive
material to fall into the item
5. Do not operate the device in damp or wet
conditions
6. Do not operate the unit under EX-conditions
7. Do not operate the unit with then capacitive
load

ESB101(R2) MANUAL
Camtec Power Supplies GmbH - Gewerbestrasse 30 - DE-76327 Pfinztal / Germany P.7/7 (06/2016.02.4)
Phone [phone] - Fax [phone] – www.camtec-gmbh.com - [e-mail]
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
English
Installati n
instructi n
Read this first!
Before operating this device, please read this manual thoroughly and retain this manual for future reference! This device may only be installed and put into operation by
qualified personnel. If damage or malfunction should occur during operation, immediately turn power off and send device to the factory for inspection. The device does not
contain serviceable parts. The information presented in this document is believed to be accurate and reliable and may change without notice. For any clarifications, the
English translation will be used.
ARNING Risk f electrical sh ck, fire, pers nal injury, r death:
- Turn power off before working on the device. Protect against inadvertent re-powering.
- Do not open, modify, or repair the device.
- Use caution to prevent any foreign objects from entering the housing.
- Do not use in wet locations or in areas where moisture or condensation can be expected.
- Do not touch during power-on and immediately after power-off. Hot surfaces may cause burns.
Deutsch
Installati ns-
anweisung
V r der Inbetriebnahme lesen!
Bitte lesen Sie diese arnungen und Hinweise sorgfältig durch, bevor Sie das Gerät in Betrieb nehmen. Bewahren Sie die Anleitung zum Nachlesen auf. Das Gerät darf nur
durch fachkundiges und qualifiziertes Personal installiert werden. Bei Funktionsstörungen oder Beschädigungen schalten Sie sofort die Versorgungsspannung ab und senden
das Gerät zur Überprüfung ins erk. Das Gerät beinhaltet keine Servicebauteile. Die angegebenen Daten dienen allein der Produktbeschreibung und sind nicht als
zugesicherte Eigenschaften im Rechtssinne aufzufassen. Im Zweifelsfall gilt der englische Text.
ARNUNG Missachtung nachf lgender Punkte kann einen elektrischen Schlag, Brände, schwere Unfälle der T d zur F lge haben:
- Schalten Sie die Eingangsspannung vor Installations-, artungs- oder Änderungsarbeiten ab und sichern Sie diese gegen unbeabsichtigtes iedereinschalten.
- Führen Sie keine Änderungen oder Reparaturversuche am Gerät durch. Gerät nicht öffnen!
- Verhindern Sie das Eindringen von Fremdkörpern, wie z.B. Büroklammern und Metallteilen.
- Betreiben Sie das Gerät nicht in feuchter Umgebung oder in einer Umgebung, bei der mit Betauung oder Kondensation zu rechnen ist.
- Gehäuse nicht während des Betriebes oder kurz nach dem Abschalten berühren. Heiße Oberflächen können Verletzungen verursachen.
Français
Instructi n
d'installati n
A lire avant mise s us tensi n!
Veuillez lire ces instructions de montage et d'entretien avant de mettre l'alimentation sous tension. Conservez ce manuel qui vous sera toujours utile. Cette alimentation ne
doit être installée que par du personnel qualifié et compétent. En cas de dommage ou dysfonctionnement, coupez immédiatement la tension d’alimentation et retournez
l’appareil à l’usine pour vérification! L’alimentation ne contient pas de pièces échangeables Les données indiquées dans ce document servent uniquement à donner une
description du produit et n'ont aucune valeur juridique. En cas de divergences, le texte anglais fait foi.
AVERTISSEMENT Prendre en c mpte les p ints suivants, afin d'éviter t ute détéri rati n électrique, incendie, d mmage aux pers nnes u m rt:
- Mettre l’alimentation hors tension avant toute intervention sur celle-ci et s'assurer qu'il n'y a pas risque de redémarrage.
- Ne pas ouvrir, modifier ou réparer l'alimentation.
- Veiller à ce qu'aucun objet ne rentre en contact avec l'intérieur de l'alimentation (trombones, pièces métalliques).
- Ne pas faire fonctionner l'appareil dans un environnement humide ou dans un environnement où il peut y avoir de la condensation.
- Ne pas toucher le carter pendant le fonctionnement ou directement après la mise hors tension. Surface chaude risquant d’entraîner des blessures.
Españ l
Instrucci nes
de instalación
Lea primer !
Conserve este manual como referencia para futuras consultas. La fuente de alimentación solo puede ser instalada y puesta en funcionamiento por personal cualificado. Por
favor lea detenidamente este manual antes de conectar la fuente de alimentación. Si se produce un fallo o mal funcionamiento durante la operación, desconecte
inmediatamente la tensión de alimentación. En ambos casos, el equipo debe ser inspeccionado en fábrica. La información presentada en este documento es exacta y fiable en
cuanto a la descripción del producto y puede cambiar sin aviso. En casa de duda, prevalece el texto inglés.
ADVERTENCIA Riesg de descarga eléctrica, incendi , accidente grave muerte:
- Desconectar la tensión de red antes de trabajar en la fuente de alimentación. Evite una posible reconexión involuntaria.
- No realizar ninguna modificación o reparación de la unidad. No abrir la unidad.
- Evitar la introducción en la carcasa de objetos extraños.
- No usar el equipo en ambientes húmedos. No operar el equipo en ambientes donde se espere la formación de rocío o condensación.
- No tocar durante el funcionamiento ni inmediatamente después del apagado. El calor de la superficie puede causar quemaduras graves.
Italian
Istruzi ni di
Installazi ne
Leggere prima questa parte!
Prima di collegare il sistema di alimentazione elettrica si prega di leggere attentamente le seguenti avvertenze. Conservare le istruzioni per la consultazione futura. Il sistema
di alimentazione elettrica deve essere installato solo da personale competente e qualificato. Se durante il funzionamento si verificano anomalie o guasti, scollegare
immediatamente la tensione di alimentazione. In entrambi i casi è necessario far controllare l'apparecchio dal produttore! I dati sono indicati solo a scopo descrittivo del
prodotto e non vanno considerati come caratteristiche garantite dell'apparecchio. In caso di differenze o problemi è valido il testo inglese.
AVVERTENZA Il mancat rispett delle seguenti n rme può pr v care f lg razi ne elettrica, incendi, gravi incidenti e perfin la m rte:
Prima di eseguire interventi di installazione, di manutenzione o di modifica scollegare la
tensione di rete ed adottare tutti i provvedimenti necessari per impedirne il ricollegamento
non intenzionale.
- Non tentare di aprire, di modificare o di riparare da soli l'apparecchio.
- Impedire la penetrazione di corpi estranei nell'apparecchio, ad esempio fermagli o altri oggetti metallici.
- Non far funzionare l'apparecchio in un ambiente umido. Non far funzionare l'apparecchio in un ambiente soggetto alla formazione di condensa o di rugiada.
- Non toccare quando acceso e subito dopo lo spegnimento. La superficie calda può causare scottature.
P rtuguès
Instruções de
instalaçã
Leia primeir !
Recomendamos a leitura cuidadosa das seguintes advertências e observações, antes de colocar em funcionamento a fonte de alimentação. Guarde as Instruções para futura
consulta, em casos de dúvida. A fonte de alimentação deverá ser instalada apenas por profissionais da área, tecnicamente qualificados. Se por acaso, durante a utilização
ocorrer algum defeito de funcionamento ou dano, desligue imediatamente a tensão de alimentação. Em ambos os casos,
será necessária uma verificação na Fábrica! Os dados mencionados têm como finalidade somente a descrição do produto, e não devem ser interpretados como propriedades
garantidas no sentido jurídico. Em caso de duvidas aplica-se o texto em inglês.
ATENÇÃO A nã bservância u incumpriment d s p nt s a seguir menci nad s, p derá causar uma descarga elétrica, incêndi s, acidentes graves u m rte:
Antes de trabalhos de instalação, manutenção ou modificação, desligue a tensão de alimentação, protegendo-a contra uma nova ligação involuntária.
- Não efectue nenhuma modificação ou tentativa de reparação no aparelho. Quando necessário contacte o seu distribuidor. Não abra o aparelho.
- Proteger a fonte de alimentação contra a introdução inadvertida de corpos metálicos, como por ex., clipes ou outras peças de metal.
- Não usar o aparelho em ambientes húmidos. Não usar o aparelho em ambientes propensos a condensações.
- Não tocar enquanto estiver em funcionamento, nem após a desligar. A superficie poderá estar quente e provocar lesões.
