Canon imageCLASS MF6595 Safety guide

Starter Guide
Please read this guide before operating this product.
After you nish reading this guide, store it in a safe place for future
reference.

Contents
What You Can Do with the Machine..................................................................................................................... 1
Find Your Purpose on the Machine ...................................................................................................................... 2
Set Up the Machine................................................................................................................................................. 3
Do You Have Everything?.................................................................................................................................................3
Manuals for the machine...................................................................................................................................... 3
Install Toner Cartridge.......................................................................................................................................................4
Set Up the Paper Cassette and Load Paper ...............................................................................................................7
Connect the Power Cord and Turn On the Machine ..............................................................................................8
Set the Date and Time.......................................................................................................................................................9
Before FAX Setting (MF6595cx/MF6595/MF6590 Only) ................................................................................ 10
Connect Telephone Cables............................................................................................................................................10
If Necessary to Use Pulse Dialing .....................................................................................................................11
Set the Machine for Sending Faxes (MF6595cx/MF6595/MF6590 Only).................................................... 12
Entering Information............................................................................................................................................12
Registering Sender Information..................................................................................................................................13
Guidelines for Entering Information...............................................................................................................13
Set the Machine for Receiving Faxes (MF6595cx/MF6595/MF6590 Only) ................................................. 14
Select the Receive Mode that Suits Your Needs ....................................................................................................14
Set the Receive Mode......................................................................................................................................................14
About the Receiving Modes ..............................................................................................................................15
Software Settings with Computer...................................................................................................................... 16
Types of Connection Between Computer and the Machine.............................................................................16
Network Connection (MF6595cx/MF6595/MF6590 Only)......................................................................16
USB Connection.....................................................................................................................................................16
About User Software CD ................................................................................................................................................17
MF Drivers & Toolbox ...........................................................................................................................................17
Bundled Programs.................................................................................................................................................18
Manuals.....................................................................................................................................................................18
Network Connection (MF6595cx/MF6595/MF6590 Only).................................................................................19
Connect the Machine to a Network................................................................................................................19
Automatic Setting .................................................................................................................................................19
Manual Setting .......................................................................................................................................................20
Installation Procedure..........................................................................................................................................21
Checking the Installation....................................................................................................................................24
USB Connection.................................................................................................................................................................25
Installation Procedure..........................................................................................................................................25
Checking the Installation....................................................................................................................................28
Appendix................................................................................................................................................................. 29
Uninstallation Procedure ...............................................................................................................................................29
Uninstalling the MF Toolbox (USB Connection Only)...............................................................................29
Uninstalling the MF Drivers ...............................................................................................................................29
Using Online Help.............................................................................................................................................................30

1
What You Can Do with the Machine
You can use the following functions with imageCLASS MF6500 Series.

2
Find Your Purpose on the Machine
For using each function (COPY, FAX, PRINTER, SCANNER, PC FAXING, REMOTE UI), follow the settings in the
owchart below.
For example, when you use copy function only, follow“Necessary Settings”. When you use both copy and fax
functions, follow“Necessary Settings”and “Fax Settings”.

3
Do You Have Everything?
Machine●Paper Cassette*●Toner Cartridge●
Power Cord●Telephone Cable**●Destination Labels**●Ferrite Core for USB Cable**●
Limited Warranty Notice
Registration Card
Starter Guide (This Document)
●
●
●
Basic Operation Guide
User Software CD
Unpacking Instruction Sheet
●
●
●
* MF6595cx/MF6595 only (Optional for MF6595)
**MF6595cx/MF6595/MF6590 only
Manuals for the machine
Starter Guide:
Machine set-up and software
installation
(This Document)
●
Use the handles (on the left side) and the hand grips (on the right
side) to lift the machine. Be sure at least two people lift the
machine.
Basic Operation Guide:
Basic operation features
●
(User software CD)
Reference Guide:
Total operation features
(Also includes the basic operation
guide contents.)
Scanner Driver Guide:
Scanner settings
●
●
Set Up the Machine
Unless otherwise mentioned, illustrations used in this manual are those taken when no optional equipment is
attached to the imageCLASS MF6595, and also the menus described in this manual are based on the model
MF6595.
Depending on the model of your machine, some settings may not be available and the number on the top of each
menu may vary.

4
Install Toner Cartridge
1 Remove the toner cartridge from the bag. Keep
the bag for future use.
Do not open the drum protective shutter (A).
2 Gently rock the toner cartridge several times to
evenly distribute the toner inside.
3 Remove the seals (2 places).
4 Bend back the blue plastic pull tab as in the
illustration above.
Do not remove the pull tab as it is used to pull out the toner
when the cartridge needs replaced.
Set Up the Machine

5
5 Place the toner cartridge on a at surface and
pull the seal completely out.
Do not pull the seal out at an angle.
If toner is adhered on the removed seal, be careful that
your hands or clothes do not get dirty from touching the
toner.
If your hands or clothes get dirty from touching the toner,
wash them immediately in cold water. Do not use hot
water. If you do, the toner may be set permanently.
6 Open the left cover.
–
–
7 Hold the toner cartridge by its handle. Insert the
toner cartridge into the machine with the
arrows (A) on the toner cartridge pointing
toward the machine.
8 Insert the toner cartridge so that the left edge
of the toner cartridge (A) and the protrusions on
the right side of the toner cartridge (B, C) t into
the guides inside the machine. The blue plastic
pull tab should be pulled up as illustrated in
step 4.
Set Up the Machine

6
9 Push the toner cartridge to make sure it is
properly set in the machine.
Do not touch the xing assembly (A) as it becomes very hot
during use.
10 Close the left cover.
Be careful not to get your ngers caught.
If you cannot close the left cover, do not force it to close.
Open the cover and make sure the toner cartridge is
properly set in the machine.
–
–
Set Up the Machine

7
1 Pull out the paper cassette until it stops. If you
use LTR size, go to step 4. If you use other sizes,
go to step 2.
2 Incline the rear paper end guide until it is
unlocked, then remove it from the paper
cassette.
By default, the guide is set to LTR.
3 Attach the guide to the slots of the desired
paper size.
4 Even the edges of the paper stack.
5 Load the paper stack print side up.
Make sure the back edge of the paper stack touches the rear
paper end guide (A), the paper stack does not exceed the
load limit mark (B), and the load is under the small ns (C)
on the paper guides.
6 Gently insert the paper cassette as far as it will
go.
Be careful not to get your ngers caught.
You can load the paper into the additional paper cassette
(standard for MF6595cx and optional for MF6595). For
attaching the additional paper cassette, see the
instruction sheet that comes with the machine.
For loading paper in the multi-purpose tray, see
Chapter 2, “Document and Paper,” in the Basic Guide.
–
–
Set Up the Paper Cassette and Load Paper
Set Up the Machine

Connect the Power Cord and Turn On the Machine
1 Connect the power cord into the rear socket on the back side of the machine and the wall outlet, and press
the [I] side of the main power switch (A) to ON.
2 The machine enters the standby mode.
MF6595/MF6590/MF6540/MF6520
A T E X T
1 0 0 % L T R
0 1
MF6595cx or MF6595 with the optional cassette
A T E X T
1 0 0 % A U T O
0 1
The LCD display turned o:
The machine may enter the sleep mode while you are setting up the machine. Press [POWER] to turn the machine back on and
continue the setup.
<CLOSE COVER LEFT COVER> is displayed:
Make sure that the left cover is closed properly. (See“Install Toner Cartridge,” on p. 4.)
<TONER IS NOT SET INSERT TONER> is displayed:
Make sure that the toner cartridge is installed properly. (See “Install Toner Cartridge,” on p. 4 and“Set Up the Paper Cassette and Load
Paper” on p. 7.)
Any data stored in the memory, including received fax documents, will be deleted about 60 minutes after you turn o the main power
switch or unplug the power cord.
●
●
●
Set Up the Machine
8

Set the Date and Time
Before using the machine, you MUST set the current date and time. The current date and time settings are used as
standard timer settings for functions that require them.
Entering Information
Numeric keys: Enters numbers.
[ ] or [ ]: Moves the cursor position.
[OK]: Conrms the entry.
●
‒
‒
‒
Set Up the Machine
9
Set Up the Machine
1 Press [Additional Functions].
2 Press [ ] or [ ] to select <6. TIMER
SETTINGS>, then press [OK].
3 Press [ ] or [ ] to select <1. DATE&TIME
SETTING>, then press [OK].
4 Use the numeric keys to enter the date (month/
day/year) and time (in 24-hour/military time
format), then press [OK].
1 2 / 3 1 /
´ 0 7 1 1 : 1 9
D A T E & T I M E S E T T I N G
Ex.
If you accidently enter an incorrect number, press [ ] or
[ ] to move the cursor to the number that needs
correcting and overwrite it.
5 Press [Stop] to return to the standby mode.
You can select one of the following three date formats in
<2. DATE TYPE SELECT>.
<MM/DD/YYYY>
<DD/MM YYYY>
<YYYY MM/DD>
By default, <5. DAYLIGHT SV. TIME> in the <6. TIMER
SETTINGS> menu is set to <OFF>.
If you want to set <5. DAYLIGHT SV. TIME> in the <6.
TIMER SETTINGS> menu to <ON>, see Chapter 1, “Before
Using the Machine,” in the Basic Operation Guide.
The LCD display turned o:
The machine may enter the sleep mode while you are
setting up the machine. Press [POWER] to turn the
machine back on and continue the setup.
–
–
–
–
–
●

Connect Telephone Cables
Connect the supplied telephone cable to the telephone line jack (A) on the back side of the machine and the wall jack.
If you want to connect your own external telephone or telephone with built-in answering machine, connect it to external
device jack (B) on the back side of machine.
●
●
Before FAX Setting
(MF6595cx/MF6595/MF6590 Only)
10

11
Before FAX Setting (MF6595cx/MF6595/MF6590 Only)
By default, telephone line type on the machine is set to tone dialing. When you use tone dialing, skip the
following procedure.
When you use pulse dialing, follow the procedure below and change the telephone line type setting to
<ROTARY PULSE> on the machine.
If you do not know the type of telephone line you use, contact your local telephone company.
1 Press [Additional Functions].
2 Press [ ] or [ ] to select <3. FAX SETTINGS>, then press [OK].
3 Press [ ] or [ ] to select <2. USER SETTINGS>, then press [OK].
4 Press [ ] or [ ] to select <5. TEL LINE TYPE>, then press [OK].
5 Press [ ] or [ ] to select the telephone type, then press [OK].
<TOUCH TONE>: Tone dialing (Default)
<ROTARY PULSE>: Pulse dialing
6 Press [Stop] to return to the standby mode.
If Necessary to Use Pulse Dialing

12
Set the Machine for Sending Faxes
(MF6595cx/MF6595/MF6590 Only)
Use the following keys to enter information in the machine.
You can enter the following characters in each input mode:
Use the numeric keys to enter
characters.
Press the numeric key repeatedly
until the required character
appears.
Press [#] to enter symbols.
Press [ ] to switch among input
modes:
[:A]: Letter (uppercase) mode
[:a]: Letter (lowercase) mode
[:1]: Number mode
Press [ ] or [ ] to move the
cursor position.
Press [Clear] to delete the
character at the cursor position.
Hold [Clear] to delete the entire
entry.
Press [OK] to conrm the entry.
●
●
●
‒
‒
‒
●
●
●
Entering Information

13
Set the Machine for Sending Faxes (MF6595cx/MF6595/MF6590 Only)
Registering Sender Information
1 Press [Additional Functions].
2 Press [ ] or [ ] to select <3. FAX
SETTINGS>, then press [OK].
3 Press [ ] or [ ] to select <2. USER
SETTINGS>, then press [OK].
4 Press [ ] or [ ] to select <1. UNIT
TELEPHONE #>, then press [OK].
5 Use the numeric keys to enter your fax number
(up to 20 digits including spaces), then press
[OK]. (For information on how to enter
characters, see p. 12.)
1 2 3 X X X X X X X
U N I T T E L E P H O N E #
Ex.
You can enter the numbers (0-9), space, and + in <1. UNIT
TELEPHONE #>. Press [ ] to enter the space and press [#]
to enter +.
6 Press [ ] or [ ] to select <2. UNIT NAME>,
then press [OK].
7 Use the numeric keys to enter the unit name (up
to 24 characters) (your name, company name,
etc.), then press [OK]. (For information on how
to enter characters, see p. 12.)
C a n o n
U N I T N A M E : A
Ex.
8 Press [Stop] to return to the standby mode.
The LCD display turned o:
The machine may enter the sleep mode while you are
setting up the machine. Press [POWER] to turn the
machine back on and continue the setup.
●
The sender information you register in the machine appears in the header of each page received by your
recipient.
Guidelines for Entering Information
Before sending documents, you MUST register your fax number, unit name, and the current date and time in the
machine.

14
Select the Receive Mode that Suits Your Needs
The receive mode determines how the machine responds to incoming faxes and voice calls. Select the mode
which is most suitable for you from the chart below. For details, see “About the Receiving Modes,” on p. 15.
The remote reception function is useful when the receive mode is set to <Manual> and connected to an external telephone. You can
receive faxes by picking up the external telephone and pressing a two-digit remote reception ID (the default setting is 25). For details,
see Chapter 4, ”Sending and Receiving (MF6595cx/MF6595/MF6590 Only),” in the Reference Guide.
Your telephone with built-in answering machine or answering machine must be connected directly to the machine for <AnsMode>
to work. (See “Connect Telephone Cables,” on p. 10.)
The external telephone must be connected to the machine for <FaxTel> or <Manual> to work. (See “Connect Telephone Cables,” on
p. 10.)
By default, <FaxOnly> is selected in <1. RX MODE>. If external telephone is connected to the machine and receives a fax or voice call,
the external telephone rings if incoming ring is enabled. You can answer the voice call while the external telephone is ringing.
For incoming ring to be enabled, press [Additional Functions] →<3. FAX SETTINGS> →<4. RX SETTINGS> →<4. INCOMING RING> then
select <ON>.
Voice mail is not supported with <AnsMode>.
DRPD (Distinctive Ring Pattern Detection) service assigns two or more telephone numbers with distinctive ring patterns to a single
telephone line, allowing you to have both a fax number(s) and a telephone number(s) using only one telephone line. Your fax will
automatically monitor incoming calls and based on the ring pattern, will let you know if the call is a fax or voice call. Set the fax ring
pattern that matches the pattern assigned by your telephone company. Contact your telephone company for availability.
–
–
–
–
–
–
1 Press [Additional Functions].
2 Press [ ] or [ ] to select <3. FAX
SETTINGS>, then press [OK].
3 Press [ ] or [ ] to select <1. RX MODE>,
then press [OK].
4 Press [ ] or [ ] to select the receive mode,
then press [OK].
5 Press [Stop] to return to the standby mode.
The LCD display turned o:
The machine may enter the sleep mode while you are
setting up the machine. Press [POWER] to turn the
machine back on and continue the setup.
●
Set the Receive Mode
Set the Machine for Receiving Faxes
(MF6595cx/MF6595/MF6590 Only)

15
Set the Machine for Receiving Faxes (MF6595cx/MF6595/MF6590 Only)
<FaxOnly> <AnsMode>
Receives faxes automatically. When you will be using only the fax
function, select this mode without connecting to the external telephone.
Receives faxes automatically and routes voice calls to the answering
machine.
Upon Receiving FAX●Upon Receiving FAX●
The machine
receives faxes
automatically.
The telephone with
built-in answering
machine rings and
the machine
receives fax
automatically.
Upon Receiving VOICE CALL●Upon Receiving VOICE CALL●
The machine does
not respond.
The telephone with
built-in answering
machine rings and
records voice
messages.
<Manual> <FaxTel>
Rings for every call, whether it is a fax call or a voice call. For a fax call,
you have to manually activate reception of the fax.
Automatically switches between fax calls and voice calls. Receives
faxes automatically and the machine rings for voice calls.
Upon Receiving FAX●Upon Receiving FAX●
The external phone
rings. You can
receive incoming
faxes using the
remote reception
function by picking
up the receiver or
pressing the hook
button.
The machine
receives fax
automatically.
Upon Receiving VOICE CALL●Upon Receiving VOICE CALL●
The external
telephone rings.
Answer the call.
The machine rings.
Answer the call.
About the Receiving Modes

16
Software Settings with Computer
Types of Connection Between Computer and the Machine
There are two ways to connect the machine and computer: USB connection and Network connection.
Network Connection (MF6595cx/MF6595/MF6590 Only) (For details on how to set up, see p. 19.)
You can print and fax the documents, and change the machine settings from a computer through a network.
For details of each function with Network Connection, see following guides.
Print Documents →Chapter 5,“Printing and Scanning,” in the Reference Guide
Remote UI →Chapter 7, “Remote UI (MF6595cx/MF6595/MF6590/MF6540 Only),” in the
Reference Guide
PC Faxing →Chapter 4, “Sending and receiving (MF6595cx/MF6595/MF6590 Only),” in
the Reference Guide
USB Connection (For details on how to set up, see p. 25.)
You can print and fax the documents sent from a computer and scan documents into computer.
For details of each function with USB Connection, see following guides.
Print Documents →Chapter 5,“Printing and Scanning,” in the Reference Guide
PC Faxing →Chapter 4, “Sending and receiving (MF6595cx/MF6595/MF6590 Only),” in
the Reference Guide
Scan Documents →Chapter 5, “Printing and Scanning,” in the Reference Guide
The scanner driver is available only through a USB connection.
You can use functions for USB connection and network connection together.
–
–

17
About User Software CD
MF Drivers & Toolbox
UFRII LT Driver
The Canon UFRII LT printer driver enables you to
print from any application software to the
machine. Taking full advantage of your PC’s
processing power to compress the print data,
this driver executes the high-speed data
processing.
PCL Driver (MF6595cx/MF6595 only)
Hewlett-Packard’s PCL printer driver includes
the PCL5c, PCL5e, and PCL6 drivers. The PCL5c
printer driver is for color printers, while the
PCL5e and PCL6 printer drivers are for black-
and-white printers. PCL6 is an advanced version
of PCL5e and oers superior printing quality
and speed. This machine supports the PCL5e
and PCL6 printer drivers.
FAX Driver (MF6595cx/MF6595/MF6590
Only)
The FAX Driver is similar to the printer driver.
Instead of the document being printed when
the user selects [Print] from any application
software, it is formatted and then sent as a fax
to a fax number that the user species.
Scanner Driver (Only available using a USB
connection)
Scanner Driver enables computer to use the
machine as scanner.
MF Toolbox
MF Toolbox is a program that allows you to
easily import images scanned with a scanner
into an application, attach them to e-mail
messages, save them to the computer, etc.
Software Settings with Computer
System Requirements
Microsoft Windows 2000
CPU: Intel Pentium/133 MHz or faster
Memory: 128 MB or more
Microsoft Windows XP
CPU: Intel Pentium/Celeron series
300 MHz or faster
Memory: 128 MB or more
Microsoft Windows Server 2003*
CPU: Intel Pentium/Celeron series
133 MHz or faster
Memory: 128 MB or more
*Only for network connection.
Microsoft Windows Vista
CPU: Intel Pentium 800 MHz or faster
Memory: 512 MB or more

18
Bundled Programs
To install the following programs, load the User
Software CD into a computer, click on the [Easy
Installation] or [Custom Installation] button on the
CD-ROM Setup (Software Programs) screen, then
follow the instructions that appear on the screen. If
the CD-ROM Setup (Software Programs) screen is
not displayed, click [Start] on the Windows task bar
→ [My Computer]. (Windows Vista: click [start] on the
Windows task bar → [Computer].
Windows 2000: double-click [My Computer] on the
Windows desktop.) Open the CD-ROM icon, then
double-click [MInst] ([MInst.exe]).
ScanSoft OmniPage
ScanSoft OmniPage makes it easy to convert
scanned paper documents and images from
image les into editable text for use in your
favorite computer applications. For details, see
the online help for this program.
Presto! PageManager
Presto! PageManager makes it easy to scan,
share and organize photos and documents. For
details, see the online manual and online help
for this program.
NetSpot Device Installer (NSDI)
NetSpot Device Installer enables you to set up
the machine for network operations.
When you start this program, click on the
[Additional Software Programs] button in step
2 of “Network Connection - Installation
Procedure” or in step 2 of “USB Connection -
Installation Procedure,” then follow the
instructions that appear on the screen. For
details, see the Readme le and online help for
this program.
Canon Font Manager (MF6595cx/MF6595
only)
Canon Font Manager is utility software that
allows you to install and uninstall fonts, etc..
For details, see the Readme le for this
program.
PCL Barcode (MF6595cx/MF6595 only)
30 barcode scalable fonts are included.
ScanSoft OmniPage and Presto! PageManager are
not supported on Windows XP 64-bit version and
Windows Server 2003.
NetSpot Device Installer is not supported on
Windows 64-bit version.
–
–
Manuals
Reference Guide
Reference Guide consists of total operation
features, network and remote user interface,
system manager settings, reports and lists, and
trouble shooting. Also includes the basic
operation guide contents.
Scanner Driver Guide
Scanner Driver Guide consists of scanner
settings from a computer.
Software Settings with Computer
