imagePROGRAF

Introducing the
imagePROGRAF iPF
MFP M40 System
Large-format scan-to-copy/
file/share solutions
The Canon imagePROGRAF iPF MFP M40
systems are multicomponent, multifunction
solutions for architects, engineers,
construction, GIS, and other professionals
who need to scan, edit, save, share,
and print large-format documents easily
and efficiently.
FEATURES
• M40 Scanner with SingleSensor assembly
technology*delivers incredibly fast and accurate
scan speeds.
• SmartWorks MFP scan to copy/file/share
software includes new custom presets, image
enhancements, and all new cloud integration.
• Direct Print & Share is Canon’s Cloud Portal
software for file sharing.
• A customizable system–choose between 36”
or 44” printers for maximum versatility.
• Computer, Touch-Screen Monitor, and Stand
are all included in the system.
* SingleSensor assembly technology means that multiple sensors are contained in one
assembly device.
2

VERSATILITY
Choose the printer that best fits your workflow—and budget. With five imagePROGRAF models
in the MFP M40 system line-up, it’s easy to customize your system.
CANON
TECHNOLOGY
Unique 5-Color Reactive Ink System
• High resolution: up to
2400 x 1200 dpi output
• Double set of Matte Black
ink channels maximizes
monochrome print speed
• Economy print mode helps
cut down on ink cost for
draft prints
• 15,360-nozzle print-head with
FINE technology
MORE THAN
JUST DRAWINGS
Canon’s imagePROGRAF
5-color line of printers has
what you need to simplify,
strengthen, and complete
your workflow. For poster
creation made simple, Canon’s
PosterArtist Lite software
gives you the tools you
need to help you produce an
eye-popping banner or display
in just a few easy steps. Also
included are a Print Plug-in for
Microsoft® O f fi c e and Accounting
Manager*software to help you
keep track of ink, media, and
total job costs.
*PC only
imagePROGRAF MFP
iPF765/iPF760
• 36” 5-color large-format printers
• Flat stacker/basket neatly stacks up to 20
plain paper prints, 24” x 36” in size
• Interface lock system allows you to
password-protect all user interfaces
• Built-in 250GB hard drive (iPF765 only)
iPF765
iPF760
iPF825/iPF815
• 44” 5-color large-format printers
• Dual-roll capability with automatic
switching for enhanced production
(iPF825 only)
• Large-capacity ink tanks
(330ml and 700ml tanks available)
• Built-in 160GB hard drive
• Sub ink tank system
iPF815
iPF750
• 36” 5-color large-format printer
• Borderless printing
• Bundled with a variety of software
solutions to help enhance your workflow
• Entry-level, low-cost solution
3
iPF825

M40 SCANNER
The M40 scanner with SingleSensor assembly
technology brings the MFP solution to a whole
new level. You have the ability to scan documents
at incredible speeds and, with the included USB 3
connection, experience data transfer speeds of up
to 10 times faster than on previous MFP models!
The intuitive control panel embedded on the scanner
helps make operation of the device incredibly easy,
and its compact design helps space become a non-
issue when using and storing the device.
• Optical resolution of 1200 dpi
• Scan speeds of 13 inches per second
monochrome and 3 inches per second color
• Capability to accept media of different
thickness (up to 2mm)
SMARTWORKS
The included SmartWorks MFP scan-to-copy/file/
share software has been enhanced and now helps
you to be more efficient than ever before.
• New user interface for easy navigation
• Ability to add custom presets with one-touch
retrieval for those often-used settings
• New image enhancements for white point
adjust, black point adjust, sharpen, mirror,
and invert
• Full integration with Direct Print & Share
Cloud Portal software
SYSTEM
Experience the vast customization options that come
with your MFP system. The Canon imagePROGRAF
iPF MFP M40 large-format imaging system is
designed to be a complete scan-to-copy, file, and
share solution. The system includes an imagePROGRAF
iPF large-format printer, M40 large-format scanner,
MFP stand, computer, SmartWorks MFP software,
and a large touch-screen monitor. This solution
provides a fast and effective system for printing,
copying, archiving, and distributing maps, drawings,
renderings, site and facilities management plans,
design and layout proofs, posters, and more.
With the iPF765 or iPF760 printer, the integrated
stand allows the user to position the monitor
in a variety of configurations to provide optimal
functionality and comfort, as well as allowing the
user to mount the stand onto the printer for a true
all-in-one structure, or keep them separate for easy
maneuverability. The MFP solution includes a
touch-screen monitor, and users now have the option
of selecting to have their scanned documents come
straight out the back of the scanner, or rewind to the
front for easy retrieval. Customization is truly brought
to a whole new level with the iPF MFP M40 system.
• Fully operational PC for vast customization
and creativity
• Integrated stand for structural customization
(iPF765 and iPF760 printers only)
MARKETS
The iPF MFP M40 system is designed to help bring a
fully operational work solution to you out in the field
and provide you with all the tools to help enhance
your technical document productivity. Whether
you have a low-volume architecture firm or a high
production enterprise environment, you can choose
the right printing solution to meet your workflow
requirements. See how the MFP solution can bring
your business to the next level. This solution’s
capability to help you produce high image quality
at impressive speeds—and achieve remarkable
productivity—help make it a welcome addition for
anyone looking to advance in the AEC, GIS, and
other technical industries.
imagePROGRAF iPF MFP M40 SYSTEM
4

SmartWorks MFP Software
Featuring one-touch “green button”
Copy, Scan, and Print functions
M40 Large-Format Scanner
• SingleSensor assembly technology
• Scans images up to 40”wide
Large-Format Ink-Jet Printer
Five models to choose from
Touch-Screen Monitor
MFP Stand
On-Board PC Software
and Workflow Solutions
• Direct Print and Share
Cloud Portal Solution
• PosterArtist Lite
• Canon Printer Driver
• Print Plug-in for
Microsoft Office
• Accounting Manager
Feature
imagePROGRAF iPF MFP M40 SYSTEM
5

Canon’s Direct Print & Share*is a cloud-based portal
service that allows users to expand their workflow.
Through a Google** account, users are given the
ability to scan and upload documents to their own
cloud storage space and have those documents
printed from almost anywhere!
Easily print PDFs, TIFFs, and JPEGs through the
user-friendly interface, and even have the ability to
do batch printing. To help further integrate with your
Canon printer and software, Direct Print & Share
comes with a print plug-in for SmartWorks MFP V3
(also included) and AutoCAD®(sold separately) to
make cloud use through this software incredibly easy.
Scan, upload, download, and print directly from these
software solutions to help streamline your workflow.
FEATURES
• Accessible from almost anywhere in the world
• 5GB of free storage
• Batch printing of multiple files
• Integration with software solutions, such as
SmartWorks MFP V3 and AutoCAD
• Drag-and-drop TIFF, JPEG, and PDF files to
shortcut icon
DIRECT PRINT & SHARE SOFTWARE
*Direct Print & Share comes embedded with the imagePROGRAF iPF MFP M40 System, and is also available as a free download at http://usa.canon.com/downloads.
**You must open a Google Cloud account to take advantage of the cloud functionality. Storage capacity and any pricing thereof is based on Google’s current offering and is at
Google’s discretion. Your Google Cloud account is subject to Google’s terms and conditions, which is subject to change at Google’s discretion. Neither Canon Inc., nor Canon U.S.A.,
Inc. represents or warrants any third-party product, service or feature referenced hereunder.
Cloud Storage
Cloud Service Integration
Folder options
for saved files
Upload and
download files
to the cloud
File preview
Password
protected
Files stored
on Cloud
Files to be
uploaded
iPF Direct Print & Share
1. Select a file
2. Right-click to send Print job
management
Real-time preview
Print settings
6

Output Width
44” Wide
Number of Ink Tanks
6
Color Set
Dye: Cyan, Magenta, Yellow, Black
Pigment: Matte Black
Ink Type
Dye/Pigment Reactive Ink
Ink Tank Size
330ml and 700ml
Maximum Print Resolution (dpi)
2400 x 1200
Total Number of Nozzles
15,360
Ink Droplet
Consistent 4pl
Maximum Print Speed
(1200 x 1200 dpi on Plain Paper)
688 sq.ft. per hr.*
Print Speed Best Quality Mode
(2400 x 1200 dpi on Photo Gloss Paper)
89 sq.ft. per hr.*
Software/Utilities/Applications
• Canon Printer Driver
• HDI Driver
• Print Plug-in for Microsoft Office
• Digital Photo Front-Access
• Remote User Interface
• Media Configuration Tool
• Supports HP-GL/2, HP RTL Files
• PosterArtist Lite
• PosterArtist (optional) (PC only)
• Third-Party RIPs (optional)
Special Features
• Dual Media Rolls (iPF825 only)
• Accounting Manager (PC only)
• Economy Color Mode
• Sub Ink Tank System
• Independent Rotary Cutter
Printer Dimensions ( H x W x D)
iPF825: 45” x 74.5” x 50.9” (with basket)
iPF815: 45” x 74.5” x 38.4
Printer Weight
iPF825: Approx. 417 lb.
iPF815: Approx. 305 lb.
Printer Memory
384MB RAM
32GB Dedicated File Processing Memory
Hard Drive
160GB
Connectivity
USB 2.0: 10/100Base-T/TX
Operating System
Windows
®
,** Macintosh
®
**

*OS: Windows XP SP2, CPU: Pentium®4 3.2GHz, RAM:
1GB, Application: Adobe®Photoshop®7.0, Interface: USB
2.0 Hi-Speed, Data used: ISO/JIS-SCID No.5, Output
image size: A1 (580mm x 724.9mm) for iPF655/ 650/ 610,
A2 (410mm x 512.5mm) for iPF510 using optional Roll Feed.
Measured by Canon Inc. Each print time does not include
data transfer time. The print speed may vary depending on
the data volume and size, PC, application, software, media
type, and interface.
** Please visit www.usa.canon.com/download for availability.
imagePROGRAF
PRINTER SPECIFICATIONS
Output Width
36” Wide
Number of Ink Tanks
6
Color Set
Dye: Cyan, Magenta, Yellow, Black
Pigment: Matte Black, Matte Black
Ink Type
Dye/Pigment Reactive Ink
Ink Tank Size
130ml
†
Maximum Print Resolution (dpi)
2400 x 1200
Total Number of Nozzles
15,360
Ink Droplet
Consistent 4pl
Maximum Print Speed
(1200 x 1200 dpi on Plain Paper)
733 sq.ft. per hr.*
Print Speed Best Quality Mode
(2400 x 1200 dpi on Photo Gloss Paper)
79 sq.ft. per hr.*
Software/Utilities/Applications
iPF765/760
• Canon Printer Driver
• Optimization Module for AutoCAD
(PC only)
• Print Plug-in for Microsoft Office
• Remote User Interface
• Media Configuration Tool
• PosterArtist Lite
• PosterArtist (optional) (PC only)
• Third-Party RIPs (optional)
iPF750
• Canon Printer Driver
• HDI Driver
• Digital Photo Front-Access
• Print Plug-in for Microsoft Office
• Remote User Interface
• Media Configuration Tool
• Supports HP-GL/2, HP RTL
• PosterArtist Lite
• PosterArtist (optional) (PC only)
• Third-Party RIPs (optional)
Printer Dimensions (H x W x D)
41.8” x 51.3” x 34.5”
41.8” x 51.3” x 43.3 (when Basket is in the extended
position for flatbed stacking, iPF765/760 only)
Printer Weight
Approx. 141.3 lb.
Special Features
iPF765/760
• Flat Stacker/Basket
• Interface Lock
• Accounting Manager (PC only)
• Sub Ink Tank System
• Top-loading Roll Feed
iPF750
• Accounting Manager (PC only)
• Sub Ink Tank System
• Top-loading Roll Feed
• Gigabit Ethernet Support
• Intuitive Operation Panel
Printer Memory
256MB (32GB iPF765 only)
Hard Drive
250GB (iPF765 only)
Connectivity
USB 2.0: 10/100/1000Base-T/TX
Operating System
Windows,** Macintosh**
†
The starter ink tanks in the package with the printer are not the same
capacity as the replacement ink tanks specified here.
* OS: Windows XP SP2, CPU: Pentium 4 3.2GHz, RAM: 1GB, Applica-
tion: Adobe Photoshop 7.0, Interface: USB 2.0 Hi-Speed, Data used:
ISO/JIS-SCID No.5, Output image size: A0(827mm x 1033.8mm).
Measured by Canon Inc. Each print time does not include data trans-
fer time.The print speed may vary depending on the data volume and
size, PC, application, software, media type, and interface.
** Please visit www.usa.canon.com/download for availability.
PRINTER SPECIFICATIONS
7

1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Park
Melville, NY 11747
The imagePROGRAF iPF MFP M40 systems contain multiple components, some of which
are manufactured by third parties. To the extent that such third party offerings come with
limited warranties, such limited warranties are hereby passed to the purchaser, and Canon
shall have no obligation or any liability with respect to such third party offerings.
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that this product meets
the ENERGY STAR guidelines for energy efficiency. ENERGY STAR and the ENERGY STAR
mark are registered U.S. marks. CANON, IMAGEPROGRAF, and the GENUINE logo are
registered trademarks of Canon Inc. in the United States and may also be registered
trademarks or trademarks in other countries. IMAGEANYWARE is a trademark of Canon.
All other referenced product names and marks are trademarks of their respective owners
and are hereby acknowledged. Some items may not be available at this time; please check
for availability. Specifications and availability subject to change without notice. All printer
output images and effects are simulated. MFP shown with iPF825 and iPF765 printer.
©2013 Canon U.S.A., Inc. All rights reserved.
0175W110
0313-iPFM40-5M-LCR
Scan Speed*
• 48-bit Full Color @ 200 dpi: 3” (per second)
• 8-bit Grayscale and Monochrome @ 200 dpi:
13” (per second)
Scan Modes
• 16.7-million Color RGB (24-bit)
• 256 color RGB Adaptive Indexed Color Palette (8-bit)
• 256-level Grayscale (8-bit)
• Black and White (1-bit)
Color Space
Normalized RGB
Resolution
• 9600 dpi (maximum interpolated)
• 1200 dpi (optical)
Scan Accuracy**
+/- 0.1% ; +/ - 1 pixel
Maximum Image Width
40”
Maximum Media Width
42”
Maximum Scan Length
96”
Maximum Media Thickness
0.079” (2mm)
Media Feed System
Single large diameter precision ground drive roller;
adaptive CIS media focus management and media
guide mechanism; intuitive face-up, front-loading,
and front/rear-exit media path with side justification;
automatic media size detection with reliable optical
media sensors
Digital Imaging Technology
Contact Image Sensor (CIS) Technology (SingleSensor
Assembly)
• 5x close-spaced “deep focus” CIS (25,000 pixels)
• 48-bit RGB digital color image capture (50,400 pixels)
• 16-bit grayscale image capture
• Panchromatic monochrome and black and white
• Bi-directional extra long-life LED light system for
optimum object illumination and instant-on
scanning capability
Digital Image Processing
• 2D Intelligent Adaptive Thresholding (IAT) (1-bit mode)
• Fixed Threshold Black and White (1-bit mode)
• Dynamic Normalization Application (DNA) with
16-bit Super Sampling
User Status and One-Touch Operation
Center mounted LCD scanner control panel;
walk-up operation and user selection of scanner mode
with stop, forward, rewind, scan, and copy buttons;
local language options, panel overlay, and Magnetic
Media Guide
Included Software
• SmartWorks MFP Scan-to-file, Copy, E-mail with
Real-time Image Viewer. Supports TIFF, JPEG, TIFF
G4, and PDF.
• Direct Print & Share Cloud Portal Solution
Operating System
Windows 7 Professional (64-bit)
User Maintenance
Installable Plug-and-Play Scanner; Simple Cleaning
Scanner Interface Kit
Superspeed USB 3.0 ( PC Connector Compatible with
USB 2.0 and USB 3.0 sockets )
Operating Environments
10 – 35°C, 35-80% RH, Non-condensing
External Power Supply
100-250 VAC Autosensing +/- 10%, 50- 60Hz
Scanner Power Consumption
• 53Wh (scanning)
• 5Wh (stand-by)
Compliances
VCCL, CB, CE, FCC, UL, RoHS, ENERGY STAR
®
Stand and Scanner Dimensions
Height: Swing Arm: 57.5”
Straight Arm (max): 66”
Width: Swing Arm (max): 69.9”
Straight Arm: 53.6
Depth: 31.5”
Stand and Scanner Weight
Approx. 120.4 lb.
What’s In The Box?
• M40 Scanner with Power Cord and USB 3.0 and USB
2.0 Cables (scanner to server)
• 2 Meter USB Cable (server to printer)
• M40 MFP Stand
• M40 MFP Stand Assembly Instructions
• SmartWorks MFP Software
• Computer
• Flat Panel Touch-screen Display
• Installation and Operation Manual
• Operator Manual on CD-ROM
• Document Return Guide
• Magnetic Paper Guide
* The scan rate is proportional across the full range of
resolutions supported by the scanner. Actual scan
times will depend on the host system performance.
Quoted top speeds may be limited by the effective
bandwidth of the USB 2 and is not guaranteed for all
media types.
** The quoted scan accuracy may vary depending on the
operating environment and the thickness of the media.
imagePROGRAF
M40 SCANNER SPECIFICATIONS
