Canon MultiPASS MP700 Manual

Unpack the machine and its components.
Check that you have the following:
NOTE
•Aprinter cable is not included.You must purchase a USB cable (less than 16 #/8 ft./5 m) to
connect your machine to a computer.
l
Machine
l
Multi-purpose tray
l
Tray cover
l
Printhead
l
Ink tanks
(Black, cyan, magenta, yellow)
l
Paper output tray
l
Power cord
l
Documentation
(Set-Up Sheet, Quick Reference Guide)
l
MultiPASS MP730/700 Setup CD-ROM
Set-Up Sheet
Set-Up Sheet
Thank you for purchasing the Canon MultiPASS MP700.
To get your machine ready for use, please follow the instructions in this Set-Up Sheet
before referring to any other documentation.
READ THIS SHEET FIRSTREAD THIS SHEET FIRST
•DO NOT assemble the machine or connect the USB cable
before installing the software.You will be instructed when
to assemble and connect the cable.
IMPORTANT

NOTE
•When installing the software in Windows 2000/XP, you must log on as Administrator or
have Administrator privileges.
•If you have previously installed an earlier version of the MultiPASS Suite software (version
4.4 or earlier), you must uninstall it before installing this version. For details on uninstalling
the software, refer to the documentation of the previous version.
Install the software.
1Turn on your computer.
2On your computer, quit any open applications, including virus checkers.
3Insert the MultiPASS MP730/700 Setup CD-ROM into your disk drive.
4In the [MP Setup] screen, click [Install MP Drivers].
• If Set-up screen is not displayed, on the Windows
desktop, double-click [My Computer] (Windows XP: Click
[Start], then click [My Computer]). Open the CD-ROM
icon, then double-click [setup (setup.exe)].
5Follow the on-screen instructions.
Make sure [Yes, I want to restart my computer
now.] is selected and then click [Finish] to
restart your computer. (Do not remove the
CD-ROM at this stage.)
6Click [Finish].
If you do not need to restart your computer,
the following screen is displayed.
If you need to restart your computer,
the following screen is displayed.

7In the [MP Setup] screen, click [Install MP Toolbox].
• If you had to restart your computer and Set-up screen is
not displayed or you have closed it, on the Windows
desktop, double-click [My Computer] (Windows XP: Click
[Start], then click [My Computer]). Open the CD-ROM
icon, then double-click [setup (setup.exe)].
8Follow the on-screen instructions.
9Click [Finish].
IMPORTANT
• Proceed to step below to assemble the machine.
Please keep your computer powered on.
Remove the shipping material from the machine.
1Place the machine on a flat surface.
2Remove all shipping tapes from the exterior of the machine.
Assemble the machine.
1Attach the multi-purpose tray.
2Attach the paper output tray
listen for audible click.

Connect the power cord.
IMPORTANT
• Before turning on the power, make sure the document cover Ais closed.
Load paper.
Place a stack of paper (print-side up) in the multi-purpose tray q.Pinch the paper
guide Aand adjust to the width of the stack w.Then place the tray cover Dover
the multi-purpose tray e.
NOTE
•Make sure the stack does not exceed the paper limit mark Bor tab C.Otherwise a paper
jam may occur.
C
q
e
w
D
A
B
PLEASE WAIT
PUT IN CARTRIDGE
Approx. 30 seconds
1Plug the power
cord into a socket.
2When you connect
the machine, the
Alarm light blinks,
and the messages
above should
appear in the LCD.
3If nothing appears in the
LCD, press [ON/OFF (1 sec.)]
to turn on the machine.
•If you need to turn off the
machine, press [ON/OFF (1 sec.)]
for one second.
ON/OFF(1sec.)
A
Turn over to
continue
Turn over to
continue

Install the printhead.
1Press [Open] qand lift up the scanning unit w.
IMPORTANT
•Do not touch the metal rod or any parts inside the
machine.
•The machine must be turned on when opening the
scanning unit.
2Remove the printhead from its packaging, then remove the orange protective
cap A.
IMPORTANT
•Do not touch the electrical contacts B.
3Raise the lock lever C,then gently slide the printhead into the
holder. Lower the lock lever.
IMPORTANT
• Do not lift the lock lever once the printhead has been installed.
C
B
A
q
w

Install the ink tanks.
1Start with the yellow ink tank. Pull the orange tape in the direction of the arrow
and remove the plastic wrapper so you can see the air hole A.Turn the ink tank
over so that the protective cap Bis facing up. Then hold the ink tank as shown
below and remove the protective cap B.
NOTE
•To avoid spilling ink, never
press on the long sides of
the ink tank C.
•Once you remove the
protective cap B,donot
touch the ink port D.
2Insert the ink tank (label-side up) into the correct slot (refer to the color guide on
the printhead). Press down gently on the ink tank until an audible click is heard.
3Repeat steps 1 and 2 to install the remaining magenta, cyan, and black ink tanks.
IMPORTANT
•Make sure the ink tanks are inserted all
the way into their slots.
4Close the scanning unit until it locks into place.
Align the printhead as explained in step 9.
Align the printhead.
NOTE
• You can also align the printhead from the software.
For details, refer to the Software Guide.
1When the LCD Adisplays the following, press [Set].
NOTE
•If a display other than <ALIGN
PRINT HEAD> appears, refer to
p. 9-5 of the Quick Reference
Guide to align the printhead.
ALIGN PRINT HEAD
PRESS SET KEY A
Black
Yellow
Magenta
Cian
Black
BCI-3eC
BCI-3eBK BCI-3eM BCI-3eY
Yellow
Magenta
Cian
PUSHPUSHPUSH
PUSH
Black
Black
BCI-3eC
BCI-3eBKBCI-3eM
BCI-3eY
Yellow
Magenta
Cian
PUSHPUSH
PUSH
Black
PUSH
Yellow
Magenta
Cian
Black
Correct position Incorrect position
Black Yellow
Magenta
Cian
Black
BCI-3eY
Yellow
PUSH
Black Yellow
Magenta
Cian
Black
BCI-3eY
Yellow
PUSH
PUSU
Yellow
MadeinJapan
Ink Tank
BCI-3eY
PULL
PULL
BCI-3eY
Ink Tank
A
BB
DC

The machine will print a horizontal pattern, and the LCD will display:
2In column A on the printout, note the value of the box with the most solid image.
Then use [2] or [3] on the operation panel to select that value.
Then press [Set].
3Repeat step 2 for columns B to K.
4When values for all columns have been entered and the LCD displays the
following, press [#] to return to standby mode.
NOTE
•If streaks appear on the printed
surface when you use the machine,
perform the vertical printhead
alignment. For details, refer to p. 9-5
of the Quick Reference Guide.
Connect the USB cable to complete the computer settings.
1Make sure the machine is turned on.
2Connect the USB cable Ato the machine and computer USB ports.
Depending on your computer, a message may display asking you to restart your
computer. If this is the case, restart your computer.
A
PRINT VERT. PATTERN?
YES=(A) NO=(#)
Most solid
box
Least solid
box
BAD
SAMPLE
GOOD
SAMPLE
Value for column A
CHANGE H VALUE
A 0
Column A

●Install Utility Software
To install the Utility Software, in the [MP Setup] screen,
click [Install Utility Software].
You can choose not to install the Utility Software at this
stage and install it later. For details, refer to p. IV of the
Quick Reference Guide.
●View User’s Manual
To read the manual on the CD-ROM, click [View User’s
Manual] on the [MP Setup] screen.
CAUTION
• For Windows 2000, the machine may not be able to be set as the default printer.
If that happens, refer to “Setting the default printer” in the Software Guide.
Congratulations! You have now completed your machine
setup.
Where to go from here...
Once you have completed all steps in this Set-Up Sheet, refer to the Quick Reference
Guide for basic operation instructions of all functions of your machine.
If after reading the Quick Reference Guide you require more detailed information,
refer to the User’s Guide or Software Guide (included in the CD-ROM).
NOTE
•Remember to register your machine to ensure product support. The serial number is
located on the back of the machine. Refer to the Quick Reference Guide for information on
the software included on the CD-ROM.
