Canon PIXMA MX860 series User manual

Make sure to read this manual before using the machine. Please keep it in hand for future reference.
Getting Started

Symbols■
The following symbols are used to mark important instructions. Observe these instructions.
Additional explanations.
Instructions that, if ignored, could result in personal injury or material damage.
Instructions that must be observed for safe operation.
Model Number: K10333 (MX860)
Macintosh, Mac and AirPort are trademarks of Apple Inc., registered in the U.S. and other countries.•
Descriptions for operations that take some time to complete.
Microsoft is a registered trademark of Microsoft Corporation.•
Windows is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.•
Windows Vista is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.•
Wi-Fi is a registered trademark of the Wi-Fi Alliance. The Wi-Fi CERTIFIED logo is a certication mark of the Wi-Fi Alliance.•
Caution

1
Contents
After Installing the Machine
Conrming Your Connection Type
Install the Print Head
Turn the Power On
Preparation
Loading Paper
Connect the Telephone Line
Set Up for Fax Reception
Install the Ink Tanks
Setup the Machine and the Computer
Select the Connection Method

2
1
A
Preparation
Manuals•
Before turning on the machine, remove all the orange tapes and the protective sheets.
The Print Head is placed inside
of the Paper Output Tray (A).
Open the Paper Output Tray with
your hands, and take out the Print
Head.
Print Head
ink tanks power cord
Setup CD-ROM (containing the drivers, applications and on-screen manuals)•
Warranty•
Check the Included Items■
Do not install the machine where an object may fall
on it. The object may fall inside the machine, resulting
in malfunction.
•
Do not place any object on top of the machine. It may
fall into the machine when opening covers, resulting
in malfunction.
•
Choosing a Location□
USB cable•
telephone line cable

3
2
B
A
12
Connect the Telephone Line
This section describes the basic method of
telephone line connection.
Connect the machine with a telephone line
using the supplied telephone line cable (A).
Do not connect the machine and a telephone in
parallel to the same telephone line using a distribution
adapter. The machine may not operate properly.
•
Remove the telephone connector cap (B), then
connect a telephone with the telephone line
cable.
To use the machine as a fax, a telephone line
needs to be connected.
If you cannot send faxes after installing the machine, check
the telephone line type. For details, refer to "Conrming
the Telephone Line Connection" in the on-screen manual:
Basic Guide.
•
For other connection methods, refer to the on-screen
manual: Basic Guide.
When using as a fax only:
Go to "3 Turn the Power On" on page 4.
Only when connecting a telephone:
When using as both a
fax and telephone:
When using as a
fax only:
When not using
as a fax:
Go to "3 Turn the
Power On" on
page 4.
only

4
3
1234
1
2
B
A
D
C
Turn the Power On
Plug the power cord into the back
left of the machine, then connect
the other end to the wall outlet.
Turn on the machine
(A).
Do NOT connect the USB cable at
this stage.
•
The machine may
make some operating
noises. This is normal
operation.
•
Make sure that the
Document Cover (B)
is closed.
•
Use the {or }button (C) on the
Operation Panel to select the language
for the LCD, then press the OK button.
If an unintended language is displayed on the LCD, press the Back button (D) to return to the Language
selection screen.
•
The standby screen is displayed.
Use the {or }button (C) on the Operation Panel
to select the country or region of use, then press the
OK button.

5
1
4
A
B
C
ED
Install the Print Head
Open the Paper Output Tray (A), then lift the Scanning Unit (Cover) (B) until it locks into place.
Handle the Print Head carefully. Do not drop or
apply excessive pressure to it.
•
The Print Head Holder makes a noise as it moves. This is normal operation.•
Close the Document Cover (C) and lift it with the Scanning Unit (Cover).
The Scanning Unit Support (D) is xed automatically.
The Print Head Holder (E) comes out. (This is where you install the Print Head.)
If the Print Head Holder does not move, make sure that the machine is turned on.•

6
4
34
F
2
Remove the Print Head from the silver
package.
There may be some transparent or light blue ink on the inside of the bag the Print Head comes in, or
the inside of the protective cap - this has no effect on print quality. Be careful not to get ink on yourself
when handling these items. Be careful not to stain your hands.
•
Remove the orange protective cap.Firmly raise the Print Head Lock Lever (F) until it stops.
The Print Head Lock Lever (F) may feel heavy.•

7
56
F
Tilt the Print Head forward and set it in place. Lower the Print Head Lock Lever (F) completely.
Do not knock the Print Head against the sides of the holder.•
Install in a well-lit environment.•
Pinch the Print Head Lock Lever rmly and lower it
gently.
•
Once you have installed the Print Head, do not remove
it unnecessarily.
•

8
5
A
1
1
2
2
Install the Ink Tanks
Handle the ink tanks carefully. Do not drop or
apply excessive pressure to them.
•
Be sure to use the supplied ink tanks.•
If the Print Head Holder moves to the right, close
and reopen the Scanning Unit (Cover).
•
Pull the orange tape (1) in the direction of the
arrow to peel off the protective lm and remove
the lm (2) completely.
While pressing down with your left thumb, twist off
the orange protective cap (A) located on the bottom
of the ink tank.
Do not hold the sides of the ink tank; ink may splash.•
