Installing Your Multifunction
to Your Network for the First Time
PIXMA MX882
Windows OS
1

<< Previous Next >>
Installing Your Multifunction
to Your Network for the First Time
PIXMA MX882
Windows OS
Preparing to Connect My Multifunction to My Network 3
Network Requirements 3
Important Information You Need Before Adding Your Multifunction 4
Adding Your Multifunction to the Network 5
2

Network Requirements
Before connecting the machine to the network, make sure that configuration of the computer and access point or router is
complete, and that the computer is connected to the network.
Notes on Network Connection
•The configuration, router functions, setup procedures and security settings of the network device vary depending on your
system environment. For details, refer to your device's instruction manual or contact its manufacturer.
•The machine cannot be used over a wireless and wired connection at the same time.
Wireless Connection
Connect to your network environment over a wireless connection.
Preparing to Connect My Multifunction
To My Network << Previous Next >>
3

Preparing to Connect My Multifunction
To My Network << Previous Next >>
Be sure to prepare an access point.
Important Information You Need Before Adding Your Multifunction
The following information is required to connect to your access point or router.
•Access Point Name/Network Name:
Also referred to as SSID. A name to identify the specific access point.
•Network Key:
Also referred to as encryption key, WEP key or WPA/WPA2 passphrase, Pre-Shared key.
A password required to set to prevent unauthorized access to communication.
Check your access point or router for the following information, and then write it down.
NOTE: For details on how to check the following information, refer to the manual of your access point or router, or contact its manufacturer.
An "Ad-hoc connection," which establishes a direct
connection to the computer over a wireless connection
without using an access point, is not supported.
4

Adding Your Multifunction to Your Network
Adding Your Multifunction to Your Network
5
Step One
Press the Setup button (A)
Step Two
Use the or button (B) to select Wireless LAN setup, then
press the OK button
<< Previous Next >>

Adding Your Multifunction to Your Network
6
Step Four
Select Easy setup, and then press the OK button.
Step Three
Select Yes, then press the OK button.
When wireless connection is enabled, the Wi-Fi lamp (D)
lights blue.
<< Previous Next >>

Step Five
Select the access point name, then press the OK button.
NOTE: If you are living in an apartment, nearby access
points in use may be detected.
Step Six
Make sure that one of the screens, below, is displayed, then press
the OK button..
If the following screen is not displayed, go to step 9
Adding Your Multifunction to Your Network
7
<< Previous Next >>

Step Eight
Make sure that the network key is correct, then press the left
FUNCTION button. (below End setup)
.
Adding Your Multifunction to Your Network
8
Step Seven
Enter the network key you wrote down, then press the
left FUNCTION button (E).
Press the center FUNCTION button (F) to switch
character entry modes.
<< Previous Next >>
Network key entry is case-sensitive. Be sure to enter upper
and lower case
letters correctly.

Adding Your Multifunction to Your Network
9
Step Nine
When the screen below appears, press the OK button.
<< Previous Next >>
If Failed to connect to the access point. appears, press the
OK button, make sure that the network key is correct, then
enter it again. If a connection still cannot be established, refer
to the printed manual: Network Setup Troubleshooting.

Step One
insert the Setup CD-ROM into the CD-ROM drive. If the
program does not start automatically, double-click the
CD-ROM icon in Computer or My Computer, then doubleclick
MSETUP4.EXE.
For Windows 7/Windows Vista: Click Run Msetup4.exe on
the AutoPlay screen, then click Yes or Continue on the User
Account Control dialog box. If the User Account Control
dialog box reappears in following steps, click Yes or
Continue.
10
Installing the Drivers & Application Software
Step Two
Click Easy Install.
The drivers, application software, and on-screen
manuals are installed.
<<Previous Next>>

Step Three
On the next screen click Install
Step Four
Select Use the printer with wireless LAN connection, then click Next.
11
Installing the Drivers and Software <<Previous Next>>

Step Five
Click Yes for the License Agreement
Step Six
Click Yes or No for the License Agreement Adobe RGB
12
Installing the Drivers and Software <<Previous Next>>

Step Seven
Click Next if the Please Allow All Install Wizard Processes appears
Step Eight
Click Next on the Printer Detection screen
13
Installing the Drivers and Software <<Previous Next>>

Step Nine
When the Detected Printers List appears, select Canon MX880 series
Then click Next.
Step Ten
Click Complete or OK on the Setup Completion screen. Your device and software
have now been set up. Please follow any remaining on-screen instructions to
finish and exit.
14
