Canon Smart Dedicated Design BLM300C Installation instructions

Canon
SERVICE SUPPORT GUIDE
Smart Dedicated Design
BLM300C Professional
Booklet Maker

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page i
Published by
Canon U.S.A., Inc.
One Canon Park
Melville, NY 11747-3336
1-800-OK-CANON
E-Mail: [e-mail]
Canon U.S.A. Homepage: http://www.usa.canon.com
Canon U.S.A. Internet e-Support Center Web Site : http://www.support.cusa.canon.com
Canon U.S.A. ISG Central Web Site : http://isgcentral.cusa.canon.com
Canon Network Access (CNA) Web Site : http://www.cna.cusa.canon.com
Smart Dedicated Design Netherlands BV Web Site : www.sdd.nl
Distributed in the United States by Canon U.S.A., Inc.
IMPORTANT
THIS SERVICE SUPPORT GUIDE INCLUDES THE INFORMATION RELATING TO THE BLM300C
PROFESSIONAL BOOKLET-MAKER.
SPECIFICATIONS AND OTHER INFORMATION CONTAINED HEREIN MAY VARY SLIGHTLY FROM
ACTUAL DEVICE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER PRINTED MATTER.
USE OF THIS SERVICE SUPPORT GUIDE SHOULD BE STRICTLY SUPERVISED TO AVOID
DISCLOSURE OF CONFIDENTIAL INFORMATION.
ALL PRICES LISTED ARE SUBJECT TO CHANGE WITHOUT NOTICE.
PART NUMBERS LISTED MAY BE CHANGED WITHOUT NOTICE TO REFLECT ENGINEERING
REVISIONS.
REVISION HISTORY
Revision
Date
Section(s)
Details
September 2013 All Release of the BLM300C Professional Booklet Maker
Service Support Guide
1 January 2014 VI Servicing
Notes
Added Installation times for the BLM300C Professional
Booklet Maker and optional modules
2 July 2014 I, V, X Added the varioPRINT 135/120/110 as supported devices

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page ii
COPYRIGHTS AND TRADEMARKS
This Service Guide is the property of Canon U.S.A., Inc.
© Canon U.S.A., Inc. 2014. All rights reserved.
Canon and Always Ask for Canon Genuine Toner, Parts & Supplies are registered trademarks of Canon
Inc. imagePRESS is a registered trademark of Canon U.S.A., Inc.
All other company names and product names may be trademarks or registered trademarks of their
respective owners, and are hereby acknowledged.
LEGAL NOTICES
The information contained in this Service Support Guide constitutes confidential information of Canon
U.S.A., Inc.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., this Service Support Guide is
solely for reference purposes and may be used only by an authorized Service Provider of Canon U.S.A.,
Inc. No part of this Service Support Guide may be reproduced or transmitted in any form by any means,
electronic or mechanical, for any purpose without the prior written consent of Canon U.S.A., Inc., except
as expressly permitted herein.
Pursuant to the authorized Service Agreement with Canon U.S.A., Inc., Service Provider agrees to
indemnify Canon U.S.A., Inc. and to hold it harmless from and against any and all claims arising out of
Service Provider’s possession, use, or misuse of this Service Support Guide.
Canon U.S.A., Inc. from time to time updates this online Service Support Guide and may modify the
information and/or specifications contained in it at any time without notice. Additionally, all prices and
availability dates listed herein are subject to change without notice. The latest version is available online
at the ISG Central and e-Support Web Sites noted above. Please make certain that you are using the
latest version. Specimens of Web pages included herein are for illustration purposes only.
DISCLAIMER
NEITHER CANON NOR ITS SUPPLIERS NOR ANY AUTHORIZED SERVICE PROVIDER SHALL BE
LIABLE FOR PERSONAL INJURY OR PROPERTY DAMAGE (UNLESS CAUSED SOLELY AND
DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED SERVICE PROVIDER), LOSS
OF REVENUE OR PROFIT, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS,
EXPENDITURES FOR SUBSTITUTE EQUIPMENT OR SERVICES, LOSS OR CORRUPTION OF
DATA, INCLUDING, WITHOUT LIMITATION, DATA STORED ON THE PRODUCT’S HARD DISK
DRIVE, STORAGE CHARGES OR OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT, REGARDLESS OF THE
LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF CANON OR ITS SUPPLIERS OR
ANY AUTHORIZED SERVICE PROVIDER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST CANON OR ITS SUPPLIERS OR
ANY AUTHORIZED SERVICE PROVIDER BE GREATER IN AMOUNT THAN THE PURCHASE PRICE
OF THE PRODUCT CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING,
THE PURCHASER ASSUMES ALL RISKS AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO
PERSONS AND THE PROPERTY OF THE PURCHASER OR OTHERS ARISING OUT OF THE
POSSESSION, USE, MISUSE, OR INABILITY TO USE THE PRODUCT NOT CAUSED SOLELY AND
DIRECTLY BY THE NEGLIGENCE OF CANON OR ANY AUTHORIZED SERVICE PROVIDER.

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page iii
Contents
I. Overview and Purpose................................................................................................. 1
A. Overview ...................................................................................................................1
B. Purpose.....................................................................................................................1
II. Features........................................................................................................................ 2
A. The BLM300C Professional Booklet Maker ...............................................................2
B. Optional Modules.......................................................................................................2
1. The Front Trimmer...............................................................................................2
2. The 2-Knife Trimmer............................................................................................2
3. Square Fold.........................................................................................................2
4. Rotator Transport.................................................................................................2
5. Long Belt Stacker.................................................................................................3
6. Short Belt Stacker................................................................................................3
III. Configuration................................................................................................................ 4
IV. Dealer Sales/Service Authorization............................................................................. 5
V. Educational Training.................................................................................................... 6
A. Training Program Overview.......................................................................................6
1. Learning Path for Technicians Certified on the BLM200/6300 Booklet Maker......7
2. Learning Path for Non-Certified Technicians........................................................7
B. Prerequisites..............................................................................................................7
C. Certification................................................................................................................8
D. Who Should Attend....................................................................................................8
E. Training Facilities.......................................................................................................8
1. Online Course Training Facilities .........................................................................8
2. Classroom Training Facilities...............................................................................8
F. Course Equipment.....................................................................................................8
G. Service Materials.......................................................................................................9
VI. Servicing Notes...........................................................................................................10
A. Power and Plug Requirements ................................................................................10
B. Installation Weight and Dimensions.........................................................................11
C. Installation Space Requirements .............................................................................13
D. Estimated Installation Times....................................................................................14
E. Firmware Update.....................................................................................................15
1. Computer Requirements for Upgrading..............................................................15
2. Update Process.................................................................................................15
F. Suggested Spare Parts............................................................................................16
G. Periodic Maintenance..............................................................................................18
VII. Suggested End-User Customer Service Offerings....................................................19
A. End-User Limited Warranty Conditions....................................................................19
B. Parts Support Program............................................................................................19
C. Service Parts Availability..........................................................................................20
VIII. Product Technical Support Offerings........................................................................21
A. Dealer Support Requirements .................................................................................21
B. Canon USA Support Offerings.................................................................................22
1. Canon USA Technical Support Center...............................................................22
2. On-site Support..................................................................................................24
3. Internet Support.................................................................................................24

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page iv
IX. Appendix......................................................................................................................27
A. Supported Devices ..................................................................................................27
B. Specifications ..........................................................................................................27
Up to 1.57” (40 mm).................................................................................................29
C. List of Tables...........................................................................................................31
D. List of Figures..........................................................................................................31

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 1
I. Overview and Purpose
A. Overview
The BLM300C Professional Booklet Maker is a non Canon finishing solution
developed by Smart Dedicated Design (SDD) Production B.V. This accessory
offers an in-line finishing solution for the Canon imagePRESS
C7011VP/C7010VP Series devices, imagePRESS C7011VPS/C7010VPS
Series devices and varioPRINT 135/120/110 Series devices with the High
Capacity Stacker-F1 attached.
The solution allows the Canon imagePRESS and varioPRINT production
printers to create a full bleed printing and booklet making solution for a wide
range of on-demand applications.
The BLM300C Professional Booklet Maker is the core device of a modular
online finishing system. Available options that enhance the BLM 300
Professional Booklet Maker system include the:
SDD Front Trimmer BLT6989
SDD 2-Knife Trimmer STR6702
SDD Square Fold SFM6904
SDD Rotator RTM6940
SDD Long Belt Stacker BST6800
SDD Short Belt Stacker BST6900
SDD Front Trimmer BLT6989
B. Purpose
The purpose of this document is to provide the servicing dealer with the tools
necessary to enable a successful integration of Canon imagePRESS and
varioPRINT digital print devices with the SDD BLM300C Professional Booklet
Maker and available options. This integration expands the market potential for
the Canon imagePRESS devices. This document has been created to assist
servicing dealers to realize that potential.
Training and support for the SDD BLM300C Professional Booklet Maker and
available options described in this guide are available from Canon U.S.A., Inc.’s
(hereinafter referred to as (“Canon USA”)).

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 2
II. Features
A. The BLM300C Professional Booklet Maker
Connects to the High Capacity Stacker-F1
Supports sheet sizes ranging from 5.5” x 9.76” (140 mm x 248 mm) to 12.6”
x 18.5” (320 mm x 470 mm)
Operation adjustment settings are achieved via the Booklet Maker User
Interface (UI)
Includes a two position stapler that can staple up to 30 sheets (80 g/m2, 120
pages booklet) (or 6 mm thickness whichever is less). Stapling can be
adjusted relative to the fold for a neat look
B. Optional Modules
1. The Front Trimmer
Prevents an effect called creeping during the paper fold process
Provide a neat finish to booklets up to 25 sheets (80 g/m2, 100 pages
booklet) (or 5 mm thickness whichever is less)
2. The 2-Knife Trimmer
This module is used in conjunction with the Front Trimmer to achieve 3-
side trimming
Cuts the top and bottom edges of a booklet to provide a neat finish to
booklets up to 25 sheets (80 g/m2, 100 pages booklet) (or 5 mm
thickness whichever is less)
Trim up to 1.38” (35 mm) from the top and bottom of the booklet (up to
2.76” (70 mm) total)
Trim the top and bottom individually (set at different heights) or
asymmetrically based on the desired height of the booklet
3. Square Fold
Provides a professional square back finishing look to booklets similar to
a bound book
Adds a square back to booklets up to 30 sheets (80 g/m2, 120 pages
booklet) (or 6 mm thickness whichever is less)
The square-fold finish allows for printing on the spine, further increasing
the booklet’s value to the customer
4. Rotator Transport
Required when producing smaller booklet sizes of A5 paper or 5.5" x
8.5"
This module rotates A4, Letter or SRA4 paper 90º from the Long Edge
Feed to the Short Edge Feed ensuring that the printer runs at maximum
productivity

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 3
5. Long Belt Stacker
The output device for the Booklet Maker System
Stacks booklets with a stacking capacity of 59” (1.5 m)
6. Short Belt Stacker
The output device for the Booklet Maker System
Stacks booklets where space is limited

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 4
III. Configuration
Note: All configurations shown are for reference purposes only and are subject to
change without notice. Please refer to the Dealer Price List on the ISG Central
Web Site (http://isgcentral.cusa.canon.com) for the most up-to-date Item Numbers.
Table 1 – Configuration
Item Item Number
1
BLM300C Professional Booklet Maker shown
SDD BLM300C Professional Booklet Maker 7134B005AA
Table 2 – Hardware Accessories
Item Item Number1
SDD Front Trimmer BLT6989 8338B001AA
SDD 2-Knife Trimmer STR6702 8338B006AA
SDD Square Fold SFM6904 8338B002AA
SDD Rotator RTM6940 8338B003AA
SDD Long Beltstacker BST6800 8338B004AA
SDD Short Beltstacker BST6900 8338B005AA
SDD Front Trimmer BLT6989 8338B001AA
1 Item Numbers and Part Numbers are subject to change without notice.

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 5
IV. Dealer Sales/Service Authorization
To become authorized and maintain authorization to sell and service the BLM300C
Booklet Maker, each authorized imagePRESS dealer location must have at least
two (2) technicians who have successfully completed and received certification on
the following:
Hardware Training either or both
imagePRESS C7010VP Hardware Update Course
varioPRINT DP Line Field Technician Blended Training Course
High Capacity Stacker-F1 eLearning Course
BLM300C Booklet Maker
For technicians with prior certification on the BLM200/6300 Booklet Maker:
The BLM300C Professional Booklet Maker Update course (elearning)
For technicians without prior certification on the BLM300C Booklet Maker or
BLM200/6300 Booklet Maker:
The BLM300C & Square Fold Booklet Solutions Blended training Course
(not available at this time)
By meeting this combination of requirements, a dealer can be confident that their
service department will have the skills and knowledge needed to be successful in
servicing and supporting this production product.

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 6
V. Educational Training
A. Training Program Overview
The BLM300C & Square Fold Booklet Solutions (SDD Square Fold Booklet-
Maker and SDD Square Fold Booklet-Maker with Two-Knife Trimmer) training
program consists of two learning paths, based on current training level of the
service technicians (see Figures 1 and 2 below).
The “Update” learning path is specifically for service technicians who are
already certified on the BLM200/6300 Booklet Maker System, and enables
technicians to identify the new features of the BLM300C Booklet Maker system.
The “Blended” training courses provide technicians with the knowledge
required for installing, configuring, servicing, and maintaining the BLM300C
Booklet Maker System and optional modules in the field.
The blended training program will certify the technicians on the BLM300C as
well as the SDD Square Fold Booklet-Maker and the SDD Square Fold
Booklet-Maker with Two-Knife Trimmer.
The training for the BLM300C & Square Fold Booklet Solutions is a fee based
course. To order from Canon Network Access (CNA) use item code 2115V542.
The course fee is $990.00.
Figure 1 – Learning Path for Technicians with BLM200/6300 Certification
Figure 2 – Learning Path for Technicians without BLM300C or BLM200/6300
Certification
BLM200/6300
Booklet Maker
Certified
Service
Technicians
High Capacity
Stacker-F1
High Capacity Stacker-F1
Online Course
(19IPCOHCSF100O)
BLM300C
Professional
Booklet Maker Update
Online Course
(19IPCBLM300UO)
Non-Certified
Service
Technicians
Hardware Training
Course
The imagePRESS C7010VP
Update Course
(09IPCC7010U00E)
BLM300C
& Square
Fold Booklet Solutions
Blended Training
Online Course
(19IPCBLM301E) and
4-Day Classroom Course
(
19IPCBLM301C
)
High Capacity
Stacker-F1
High Capacity Stacker-F1
Online Course
(19IPCOHCSF100O)
varioPRINT DP Line
Field Technician
Blended Training
Online Course
(19VPTRI00O)
and
5-Day Classroom Course
(19VPTRI01C)
Either

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 7
1. Learning Path for Technicians Certified on the BLM200/6300 Booklet
Maker
Technicians who are already certified on the BLM200/6300 Booklet Maker
can take the updated BLM300C Professional Booklet Maker update course
online
Table 3 – Online Course Module for BLM200/6300 Certified Technicians
Course Name Course Code1Required
BLM300C Professional Booklet Maker Update 19IPCBLM300UO Yes
1Item Numbers and Part Numbers are subject to change without notice.
2. Learning Path for Non-Certified Technicians
Technicians can be certified on the BLM300C Booklet Maker by taking the
blended training course.
a. Online Course Modules
The online course module is available on Canon USA’s e-Support
Center Web Site (http://www.support.cusa.canon.com). The online
course provides technicians with the theoretical concepts to install,
configure, and support the BLM300C Booklet Maker.
Table 4 – Online Course Modules
Course Name Course Code1Required
BLM300C & Square Fold Booklet Solutions Online
Course 19IPCBLM301E Yes
1Item Numbers and Part Numbers are subject to change without notice.
b. Classroom Courses
The 4-day Hardware classroom courses blends the information taught
online with hands-on, practical training in the classroom and lab. Each
student is provided the opportunity to assemble, disassemble, and install
key machine components, as well as troubleshoot many areas of the
machine and accessories.
Table 5 – Classroom Courses
Course Name Course Code1Required
BLM300C & Square Fold Booklet Solutions
Classroom Course 19IPCBLM301C Yes
1Item Numbers and Part Numbers are subject to change without notice.
B. Prerequisites
Prior to taking the BLM300C & Square Fold Booklet Solutions Training program,
technicians must successfully complete any of the following
High Capacity Stacker-F1 eLearning Course
The imagePRESS C7010VP Hardware Update Course

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 8
C. Certification
The successful completion of the BLM300C & Square Fold Booklet Solutions
Training program and passing of the final assessment exam are required to sell
this product.
SDD BLM300C Professional Booklet Maker
SDD Square Fold Booklet Maker with Two-Knife Trimmer
SDD Square Fold Booklet Maker
Technician certification is required for authorization to sell these products and
to receive support.
D. Who Should Attend
It is highly recommended that any technician responsible for installing,
servicing, or supporting the BLM300C Booklet-Maker and/or Optional Modules.
Note: Our current support policy dictates that only those technicians who have
completed the training program and pass the final assessment exam are
entitled to live, phone-based support through our TSC (Technical Support
Center). However, self-service support (software downloads, knowledgebase
articles, support forums, technical publications) is available through our
e-Support Center Web Site for all technicians. (Refer to the Technical Support
section on the e-Support Center Web Site for entitlement details.)
E. Training Facilities
1. Online Course Training Facilities
The online courses are located within the eLearning center on Canon USA’s
e-Support Center Web Site. The eLearning center includes Certification
maps that provide easy access to the training. The online courses can be
conducted at any dealer facility that is suitable for online student learning.
2. Classroom Training Facilities
Classroom training is available in the Itasca, Illinois Canon Regional
Training Centers
F. Course Equipment
Windows workstation (Vista, XP, 2007, or higher)
Microsoft Internet Explorer v7.0 or higher

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 9
G. Service Materials
The materials required for the BLM300C & Square Fold Booklet Solutions
Training Program are listed in the table below.
Table 6 – Service Materials
Model Item Location
BLM300C Professional Booklet
Maker
eLearning Training
Program Conducted online
Service Manual Downloadable from within the
eLearning course and the
e-Support Center Web Site

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 10
VI. Servicing Notes
A. Power and Plug Requirements
Canon USA strongly suggests dedicated and properly grounded outlets be
provided for the BLM300C Booklet Maker
The BLM300C Booklet Maker and Rotator module each require a dedicated
NEMA 5-15 receptacle for proper operation
Table 7 – Power Receptacle
Power Receptacle
NEMA 5-15 Receptacle
IMPORTANT
We recommend an additional standard 120 V/15 A outlet for service tools,
such as a laptop computer or vacuum that may be used when servicing or
configuring the machine.
Use only dedicated and properly grounded outlets for the BLM300C Booklet
Maker and optional modules. It is also strongly suggested to use dedicated
and properly grounded outlets for each optional accessory. Do not use
extension cords. The ground connection serves to provide the internal
electronics with a reference voltage. Faulty or poor ground sources will
cause this reference voltage to fall into a range that no longer serves as a
reliable reference voltage. A qualified electrician can measure and provide
the ground source that the BLM300C Booklet Maker and optional modules
or any computer controlled office equipment requires.
Before installation, confirm that all necessary receptacles are available.

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 11
Table 8 – Power and Plug Requirements for Main Unit and Accessories
Description Power Supply Power Supply
Specifications
BLM300C Professional Booklet Maker
2
120V/15A NEMA 5-15
SDD Rotator RTM6940
2
SDD Front Trimmer BLT6989
From the BLM300C
Professional Booklet
Maker N/A
SDD 2-Knife Trimmer STR6702
SDD Square Fold SFM6904
SDD Long Beltstacker BST6800
SDD Short Beltstacker BST6900
B. Installation Weight and Dimensions
Table 9 – Approximate Weight
Component Approximate Weight
BLM300C Professional Booklet Maker 363.8 lb 165 kg
SDD Front Trimmer BLT6989 187.4 lb 85 kg
SDD 2-Knife Trimmer STR6702 451.9 lb 205 kg
SDD Square Fold SFM6904 143.3 lb 65 kg
SDD Rotator RTM6940 286.6 130 kg
SDD Long Belt Stacker BST6800 55 lb 25 kg
SDD Short Belt Stacker BST6900 44 lb 20 kg
Table 10 – Dimensions
Unit Height Width Depth
BLM300C Professional
Booklet Maker 45.3” 1,150 mm 35.8” 910 mm 27.6” 700 mm
SDD Front Trimmer
BLT6989 43.3” 1,100 mm 14.2” 360 mm 23.6” 600 mm
SDD 2-Knife Trimmer
STR6702 43.3” 1,100 mm 23.6” 600 mm 27.6” 700 mm
SDD Square Fold
SFM6904 43.3” 1,100 mm 14.2” 360 mm 23.6” 600 mm
SDD Rotator
RTM6940 43.3” 1,100 mm 26.8” 680 mm 26.4” 670 mm
SDD Long Belt Stacker
BST6800 29.9” 760 mm 61.8” 1,570 mm 17.7” 450 mm
SDD Short Belt Stacker
BST6900 29.9” 760 mm 32.3” 820 mm 17.7” 450 mm
2Canon USA strongly suggests that the power receptacle for the BLM300C Professional Booklet-Maker is connected to a
separate breaker from the power receptacle for the SDD Rotator Module. This is necessary to maintain adequate current for
the Professional Booklet-Maker and each of the modules.

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 12
Table 11 – Dimensions Diagram

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 13
C. Installation Space Requirements
The BLM300C Booklet Maker approximate installation space requirements may
differ, depending on how the machine is configured and the optional modules
attached. Always ensure that there is enough space for service and operation
of the device. The Installation space for the BLM300C Booklet Maker adds to
the imagePRESS digital press and device installation space when configured
with the High Capacity Stacker-F1.
IMPORTANT
Installation Space includes 0.2” (5 mm) space between the components
Provide at least 19 3/4” (500 mm) on the side of the machine for
unrestricted operation, including the opening of accessory doors.
The space behind the machine to the wall and in front of the machine must
be the same as the main unit for unrestricted operation, including the
opening of the main unit and accessory doors.
The machine should not be moved once it is in place.
The floor must be level (with no bows) and flat for the stabilization and
support of the machine.
Do not place anything around the machine. Especially, do not place
anything around the breaker, as doing so may prevent access to the
breaker in an emergency, possibly resulting in personal injury.
Figure 3 – Installation Space – Square Fold Booklet-Maker

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 14
D. Estimated Installation Times
The estimated Installation times below are the estimated times required for
installation of the Square Fold Booklet-Maker with Two-Knife Trimmer starting
from an unpacked condition. The estimated installation times can be achieved
only with a minimum of two (2) experienced technicians on the Square Fold
Booklet-Maker with Two-Knife Trimmer.
Actual work times may differ from the estimated times shown in the table.
Refer to the Square Fold Booklet-Maker with Two-Knife Trimmer Service
Manual for further details.
Table 12 – Estimated Installation Times
Description Estimated Time
BLM300C Professional Booklet Maker (without the RTM6940) 60 minutes
BLM300C Professional Booklet Maker (with the RTM6940) 50 minutes
DFD Kit install into HCS-F1 60 minutes
SDD Front Trimmer BLT6989 40 minutes
SDD 2-Knife Trimmer STR6702 40 minutes
SDD Square Fold SFM6904 30 minutes
SDD Rotator RTM6940 60 minutes
SDD Long Belt Stacker BST6800 15 minutes
SDD Short Belt Stacker BST6900 15 minutes

Canon BLM300C Professional Booklet Maker Service Support Guide
BLM300C Professional Booklet Maker Service Support Guide July 2014
Revision 2 Page 15
E. Firmware Update
1. Computer Requirements for Upgrading
The same recommended Desktop PC or laptop specifications3to download
firmware to the imagePRESS digital Press with the addition of the following
components:
RS-232C (serial crossover cable)
USB to Serial Converter
2. Update Process
The Firmware update process requires that a Software Download Cable is
connected from a PC to specific Printed Circuit Boards (PCBs) located on
the Booklet Maker, Trimmer and Square Fold . Each PCB has a specific
executable file that would need to be run to update the firmware.
The firmware update process for the Rotator requires that a Programming
Logic Cable is connected from a PC to the Programmable Logic Controller
of the Rotator. a specific executable file would need to be run to update the
Rotator firmware.
Table 13 – Software Download Cable
Component PCB
Required
Software
Download Cable Equipment
BLM300
MD6DC B
OPKO007700101
MD6DC C
MD6DC H
CPU
UI
Face Trimmer MD6DC
Square Fold MD6DC
Rotator Programmable Logic Controller
Interface 1060054255
3 Specifications are subject to change without notice.
