Canon ZR 40 User manual

Record Your Precious Memories
the Simple Way
www.canondv.com
Record Your Precious Memories
the Simple Way

22x 88x Digital
22x Optical Zoom Lens
plus 440x Digital Zoom (ZR50MC )
18x Optical Zoom Lens
plus 360x Digital Zoom (ZR45MC /ZR40)
This Canon optical zoom lens perfectly transforms distant
subjects into dramatic close-ups with absolutely no loss in
image quality. The digital zoom extends the magnification to an
amazing 440x (ZR45 MC /ZR40: 360x)* revealing details too
distant to be seen with just the eye alone. The scope from wide
panorama to super telephoto is
outstanding.
*ZR50MC: 88x when using a memory card
ZR45MC/ZR40: 72x when using a memory card
Image Stabilizer
A high quality image stabilization system
corrects camera shake instantly, giving
you smooth, stable pictures. It enables
you to record shake-free images, even
on long telephoto shots
without a tripod.
Stabilizer
OFF
Stabilizer
ON
DV Format
Enter the world of DV and realize truly amazing picture and sound quality. Images
reaching up to 500 line horizontal resolution reveal stunning detail and clarity. Clearly
superior quality than even the best analog camcorders, by 20% at least, and free from
annoying color noise. DV is the right format, right now!
440x Digital
A New Era in Personal Digital Video
A New Era in Personal Digital Video
The ZR50 MC , ZR45 MC , and ZR40 take
advantage of the latest digital video
technology, yet are small enough to fit in the
palm of your hand. Sporting a sleek body
design, and an extensive list of features, these
camcorders provide exceptional results, and
are remarkably easy to use. Canon's attention
to detail guarantees a flawless shooting
experience, seamless connectivity, and endless
creativity.

IEEE 1394 DV Terminal
The ZR50 MC , ZR45 MC and ZR40 are
equipped with a DV IN/OUT terminal that
conforms to IEEE 1394. It takes just a
single digital cable to transfer or copy
your videos in pure digital form to your
DV compatible computer or another
Canon DV camcorder. Once you’ve
transferred video images to your
computer, you can edit your movies or
send your movies over the Internet, or
post them on your Web site. Also, print
them out on a Canon color printer,
transfer them back to your Canon
camcorder and archive them
on a Mini DV cassette, or
create a dubbing master.
MultiMediaCard and SD Memory Card
(ZR50MC and ZR45MC only)*
The ZR50 MC and ZR45 MC expand video possibilities by using a
MultiMediaCard or an SD (Secure Digital) Memory Card in addition to
a Mini DV cassette. These ultra-small and ultra-light media record,
store and manage still images, as well as allow easy transfer of still
images to a PC with the camcorder. Use an SD
Memory Card for high-capacity recording. Copy
still images from a videocassette to a memory
card, and vice versa. Produce effects not possible
with just a cassette using one of the three types of
Card Mix Effects. Choose one of the sample
images provided on the supplied MultiMediaCard
such as a picture frame or crashing waves and
combine it with the currently recording image.
*An 8MB MultiMediaCard is supplied with the camcorders.
USB Terminal (ZR50MC and ZR45MC only)*
Allows high speed transfer of memory card data to computers through the USB
terminal. By using the USB cable and software provided, you can process and
organize still images on your PC. The camcorder functions as
a memory card reader/writer. Bundled software: ZoomBrowser
EX (Windows) / ImageBrowser (Macintosh). You can easily
download, browse, archive and retouch still images.
Automatically resize images and attach them to e-mail,
arrange them for printing, and add text anywhere on the page.
*System requirements:
Interface: USB: only preinstalled Windows 98/Windows Me/Windows 2000/Windows XP
systems with built-in USB ports, or only systems equipped with genuine Apple-brand built-in
USB interfaces.
Effortless Multimedia Connectivity
Effortless Multimedia Connectivity
Operating System Free hard disk space
Windows ZoomBrowser EX 120MB or more
PhotoStitch 40MB or more
Macintosh ImageBrowser 20MB or more
PhotoStitch 30MB or more
Operating System CPU RAM
Windows 98 150MHz or better 32MB or more
Windows Windows Me/ 150MHz or better 64MB or more
Windows 2000
Windows XP 300MHz or better 128MB or more
Macintosh 8.6–9.2 PowerPC 20MB or more

Flexible LCD View Screen
and Color Viewfinder
The 2.5” view screen makes it easier to compose
sensational shots from any angle. It
swivels and flips for
maximum handling
comfort and flexibility. It
also tucks neatly away
when bright shooting
conditions make the
eyecup viewfinder the
preferred way to shoot.
AV Insert and Audio Dubbing
Use this feature to insert new scenes of video from your VCR or
other camcorder onto a tape recorded in the SP mode. Using a
recording made in the 12 bit audio mode you can also add
stereo sound from another audio source or through the internal
microphone or an external microphone.
Advanced Accessory Shoe
(ZR50MC only)
Simply slide on an accessory, and the shoe transmits power
directly from the ZR50 MC
. Choose to attach
Canon’s DM-50 Directional Stereo Microphone*,
the world’s first stereo shotgun mic with high
sensitivity and super-directional pick up.
Use when recording or dubbing audio. Or,
attach the VL-3 Video Light*, which can
either stay on continuously or turn on/off
automatically in response to changes in
the brightness of the shooting situation.
*Optional
Lithium Ion Power
Lithium ion battery packs can be recharged at any time, so you
will always be prepared for peak shooting performance, and
never caught without power unexpectedly. Cut
down on charging time with the high-capacity
BP-522 and BP-535 battery packs’* quick
charging feature. When charged with the
CR-560 charger kit*, the BP-522 and BP-535
give 70 minutes of recording** after only 15
minutes of charging.
* Optional
**Using the viewfinder
Analog Line-In
For instant editing, simply connect your TV, VCR, or
analog camcorder to the ZR50 MC, ZR45 MC or ZR40
and send the analog signal directly to your computer's
IEEE1394 terminal*, without recording to tape. If you
choose, you may first record the analog signal to DV
tape, allowing you to create a high-quality master of your original.
*The Analog-Digital Converter may not function depending on the software used.
Progressive Photo
(ZR50MC and ZR45MC only)
The ZR50 MC and ZR45 MC employ the Progressive
Photo function to record sharp, clear still images,
even of moving subjects, onto a memory card. When you take a
still image, the camcorder's iris works as a mechanical shutter
immediately closing after the picture is taken. Every 1/30 of a
second, the camcorder reads two fields of image data
simultaneously, resulting in full-frame images virtually free of
annoying time-lag blur.
Digital Photo Mode
The camcorders function as a digital still
camera; they’re like two cameras in one.
Just press the photo button to capture
more than 700 stunning still pictures on
a single videocassette (in SP mode) or
combine video and still
pictures together with the
added benefit of audio. The
ZR50 MC and ZR45 MC can
also capture approximately
60 fine resolution still
pictures onto an 8MB
MultiMediaCard.
Movie Making Fun Fo
Movie Making Fun Fo

Digital Effects
The camcorders include a selection
of digital effects for a more
appealing look and greater
imaging variety.
Faders
Use the various faders to start or end scenes
with a fade to or from black. Choose between
Fade Trigger, Vertical Wipe, Horizontal
Wipe and Mosaic fades*.
*During playback only.
Effects
Give variety to your images during
recording by adding Art, Black and White,
Sepia or Mosaic* effects.
*During recording to a tape and playback only.
Multi-image Screen
(ZR50 MC and ZR45 MC only)
Divides your display screen into four,
nine or sixteen pictures with the Image
Capture feature. You can choose the speed
at which the images are captured: Manual,
Slow, Moderate, or Fast.
PCM Digital Sound
The camcorders offer two digital audio modes to enhance the
playback experience. The 16 bit mode produces the higher, CD
equivalent, two-channel sound quality while the 12 bit mode
records on two of four channels
leaving two other channels free to
dub extra sound at a later date.
Spotlight
Program Auto Exposure
Ensures great video results even in challenging
shooting conditions. Select the program that
matches your scene and the camcorder adjusts
internal controls for perfect video
every time. Choose from Easy
Recording, Auto, Sports, Portrait,
Spotlight, Sand & Snow,
Low Light and Night.
Sand & Snow
Low Light
Portrait
Sports
Sepia
Art
MULTI
SCREEN
• Microphone Terminal
• Headphone Terminal
• S-Video Input/Output
• World Clock
• Built-in Speaker
• 16:9 Wide Screen Mode
• Remote Control
• Photo Search/Date Search
• Time Code/Data Code
• Self-Timer
• Confirming/Warning Beeps
• Zero Set Memory
• Record Search & Review
• LANC Terminal*
*Connect only equipment bearing the
LANC symbol.
AE Shift
Gives you control over how dark or
light the camcorder sets the auto
exposure level.
Manual Controls
In addition to being fully automatic, the camcorders offer manual
control over focus, white balance and shutter speed.
Selectable Color Light-up Buttons
(ZR50MC only)
The clear buttons above the LCD panel light up, adding a touch
of fun while also making it possible to play back cassettes when
in dark surroundings. Choose the color in which they light up:
green, orange, blue, yellow, turquoise or purple. Press one of the
buttons and they simultaneously change color. You can also
select to turn them off, or set them to power save mode, where
they only light up when one of them is pressed.
Extended Recording Function
(ZR50MC only)
In addition to the SP mode, the ZR50 MC ’s Extended Recording
Function lets you choose from three more recording modes: Long
Play (LP), giving 1.5 times the standard recording time; and two
more modes giving two and three times SP*. When image data is
recorded to a tape in the 2x and 3x SP modes, it is compressed
twice as much as in SP and LP modes. In the 3x SP mode,
record for up to 4 hours on an 80 minute cassette tape.
The ZR45 MC and ZR40 can record in the SP and LP modes.
*When recording in double or triple length recording mode, image quality will not be as high as
SP or LP mode.
Night Mode
In situations too dark for conventional recording, the camcorder
selects the optimal shutter speed, based on the
subject's brightness, allowing improved
brightness and color. Now you can capture your
baby sleeping without even turning on the light.
Green
Orange
Blue
Yellow
Turquoise
Purple
or Everyone
or Everyone

This mark identifies genuine Canon video accessories.
When you use Canon video equipment,
we recommend Canon-brand accessories
or products bearing the same mark.
Availability differs from area to area.
Power Sources
Creative Shooting
Accessories
Canon Digital
Videocassettes
Carrying Accessories
DVM-CL Digital Video
Head Cleaning Cassette
DVM-E60/DVM-E80
Digital Video Cassette
www.canondv.com
Printed on
40% reused paper.
Pictures simulated
Errors and omissions excepted. Weight and dimensions are approximate.
Subject to change without notice.
•Macintosh is trademark of Apple Computer Inc., registered in the United States and
other countries. •Microsoft and Windows are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries. •Other names and
products not mentioned above may be registered trademarks or trademarks of their
respective companies. •SD Logo is a trademark. •Canon is a trademark of Canon Inc.
U.S.A. CANON U.S.A., INC.
Consumer Information Center toll-free at 1-800-828-4040 (in U.S.A.)
One Canon Plaza, Lake Success, NY 11042 USA
CANADA CANON CANADA INC.
Consumer Information Center toll-free at 1-800-828-4040 (in Canada)
6390 Dixie Road, Mississauga, Ontario L5T 1P7
MEXICO CANON MEXICANA, S. DE R. L. DE C. V.
Periferico Sur No.4124 Col.
CENTROY Ex-Rancho de Anzaldo C.P. 01900 Mexico, D.F.
SURAMÉRICA CANON LATIN AMERICA, INC.
703 Waterford Way Suite 400 Miami FL 33126 USA
ASIA CANON HONGKONG COMPANY LTD.
9/F, The Hong Kong Club Building, 3A Chater Road, Central, Hong Kong
©CANON INC. 2002 PRINTED IN USA
IMPRIME AU USA
0027W388
PUB. DCE-133
0102S100
Specifications
Power supply (rated): 7.4 V DC (Battery)
9.5 V DC (DC IN)
Power consumption:
Using viewfinder: ZR50 MC 3.3 W,
ZR45 MC 3.3 W, ZR40 3.1 W
Using LCD screen: ZR50 MC 4.1 W,
ZR45 MC 4 W, ZR40 3.9 W
Television system: EIA standard (525 lines,
60 fields) NTSC color signal
Video recording system: 2 rotary heads,
helical scanning system DV system
(Consumer digital VCR SD system) Digital
component recording. ZR50 MC only: 3
rotary heads, SD/SDL system.
Audio recording system: PCM digital
sound: 16 bit (48kHz/2ch), 12 bit (32kHz/
4ch). ZR50 MC only: 2x SP and 3x SP 12 bit
only (32kHz/2ch)
Image sensor: 1/6" CCD (charge coupled
device) approx. 460,000 pixels (approx.
290,000 effective pixels)
Tape format: Videocassettes bearing the
(Mini DV) mark.
Tape speed: SP: 3/4ips (18.81 mm/s); LP: 1/2
ips (12.56 mm/s). ZR50 MC only: 2x SP 3/8
ips (9.41 mm/s); 3x SP 1/4ips (6.28 mm/s)
Maximum recording time (with an 80 min.
cassette): SP: 80 min.; LP: 120 min.
ZR50 MC only: 2x SP: 160 min.; 3x SP: 240
min.
Fast forward/rewind time: 2 min. 20 sec.
(with a 60 min. cassette)
Lens: ZR50 MC F/1.6-3.6, 22x power zoom,
f=2.8-61.6 (equivalent to 48~1056 mm in
35 mm format), ZR45 MC /ZR40 F/1.6-2.9,
18x power zoom, f=2.8-50.4 (equivalent to
48~864 mm in 35 mm format)
Focusing system: TTL autofocus, manual
focusing possible
Minimum focusing distance: 3 ft 33/8in. (1
m), 3/8in. on maximum wide angle
Maximum shutter speed: 1/8,000 (ZR50 MC
and ZR45 MC only: 1/250 when using a
memory card)
Minimum illumination: 0.5 lx using the
Night program during tape recording
Recommended illumination: More than
100 lx
Filter diameter: 30.5 mm
Viewfinder: 0.44 inch, color LCD (approx.
113,000 pixels)
LCD screen: 2.5 in. measured diagonally
(approx. 112,000 pixels)
Microphone: Stereo electret condenser
microphone
USB terminal: mini-B
DV terminal: DV 4 pin connector (based on
IEEE1394)
Video terminal: 1 Vp-p/75 ohms unbalanced
S-video terminal: 1 Vp-p (Y signal), 0.286
Vp-p (C signal)
Audio terminal: Input level: -10 dBV/40
kohms, unbalanced; Output level: -10 dBV,
less than 3 kohms, unbalanced
Operating temperature range: 32 - 104°F
(0 - 40°C)
•ZR50 MC , ZR45 MC or ZR40
•BP-512 Battery Pack (ZR50 MC ),
BP-508 Battery Pack (ZR45 MC /ZR40)
•CA-560 Compact Power Adapter
•SS-800 Shoulder Strap
•WL-D77 (ZR50 MC /ZR45 MC ),
WL-D74 (ZR40) Wireless Controller
•STV-250N Stereo Video Cable
•MMC-8M MultiMediaCard (ZR50 MC /ZR45 MC )
•Software/USB Cable (ZR50 MC /ZR45 MC )
SC-A50
Soft Carrying Case
SC-1000
Soft Carrying Case
Genuine
Leather
VL-10Li
Battery
Video Light
Powerful 10 W
illumination. A BP-900
series battery attaches
directly, so operation is
cable-free.
Lithium Ion Battery Packs
Extra batteries for use with the camcorders.
ZR-1000 Zoom Remote
Controller
Plugs into the camcorder’s
LANC terminal and allows you
to control functions such as
record start/stop, zoom and
focus while the camcorder is
mounted on a tripod, without
touching the camcorder body
itself.
ZR50 MC and ZR45 MC only
Recording media: MultiMediaCard, SD
Memory Card
Number of recording pixels: 640 x 480
pixels
Image format: Design rule for Camera
Format system (DCF), Digital Print Order
Format (DPOF) compliant (only images
marked for printing)
File format: JPEG (compression mode:
Fine/Standard)
Estimated MultiMediaCard MMC-8M
capacities (approx.)*: Fine 60 images,
Standard 105 images
*The actual number you can record varies
depending on the image. Remember that the
sample images recorded on the supplied
MultiMediaCard are included in the total number.
CR-560 Charge
Adapter/Car Battery Cable Kit
Connects to your car's cigarette lighter to power the
camcorder or recharge BP-500 Series battery
packs on the move. Can also draw power from
an AC outlet when connected to the
camcorder's CA-560 Compact Power Adapter.
FS-30.5U Filter Set
Includes neutral density
(ND 8) filter and MC
protector.
WD-30.5
Wide-converter
Gives wide-angle coverage
at 0.7x.
TL-30.5
Tele-converter
Increases focal length by
1.9x. Image resolution may be lower
when the zoom is at the tele-angle
position with TL-30.5.
Advanced
Accessory Shoe
(ZR50 MC only)
WS-20
Wrist Strap
DM-50
Directional Stereo
Microphone
Attaches to the shoe for cable-free
operation. Picks up shotgun or
shotgun + surrounding sound.
Powered by the camcorder’s
power source. Wind shields
included.
VL-3 Video Light
This 3W light attaches to
the shoe for cable-free operation.
Continuous on and auto on/off
settings. Powered by the
camcorder’s power source.
THE CANON
ZR50 MC /ZR45 MC /ZR40 KIT
Dimensions: 21/4x 37/8 x 55/8in.
(58 x 99 x 144 mm)
Weight: ZR50 MC /ZR45 MC : 1 lb 23/4oz 530g)
ZR40: 1 lb 21/2oz (525 g)
Warning: Unauthorized recording of copyrighted materials may infringe on the rights of
copyright owners and be contrary to copyright laws.
Battery pack Maximum recording time
using viewfinder using LCD screen
BP-508 (single-capacity) ZR45 MC : 1 hr. 30 min. 1 hr. 15 min.
(ZR45 MC /ZR40: supplied) ZR40 : 1 hr. 35 min. 1 hr. 15 min.
BP-512 (single-capacity) ZR50 MC : 2 hr. 45 min. 2 hr. 15 min.
(ZR50 MC : supplied, ZR45 MC : 2 hr. 45 min. 2 hr. 15 min.
ZR45 MC /ZR40: optional) ZR40 : 2 hr. 55 min. 2 hr. 20 min.
BP-511 (single-capacity) ZR50 MC : 2 hr. 45 min. 2 hr. 15 min.
(optional) ZR45 MC : 2 hr. 45 min. 2 hr. 15 min.
ZR40 : 2 hr. 55 min. 2 hr. 20 min.
BP-522 (double-capacity) ZR50 MC : 5 hr. 50 min. 4 hr. 40 min.
(optional) ZR45 MC : 5 hr. 50 min. 4 hr. 45 min.
ZR40 : 6 hr. 10 min. 4 hr. 55 min.
BP-535 (triple-capacity) ZR50 MC : 9 hr. 15 min. 7 hr. 25 min.
(optional) ZR45 MC : 9 hr. 15 min. 7 hr. 40 min.
ZR40 : 9 hr. 50 min. 7 hr. 50 min.
