Canon EOS 760DW User manual

EOS 760D (W)
INSTRUCTION
MANUAL
ENGLISH

2
The EOS 760D is a digital single-lens reflex camera featuring a fine-
detail CMOS sensor with approx. 24.2 effective megapixels, DIGIC 6,
high-precision and high-speed 19-point AF (cross-type AF point: max.
19 points), approx. 5.0 fps continuous shooting, Live View shooting, Full
High-Definition (Full HD) movie shooting, and Wi-Fi/NFC function.
Before Starting to Shoot, Be Sure to Read the Following
To avoid botched pictures and accidents, first read the “Safety
Precautions” (p.20-22) and “Handling Precautions” (p.23-25).
Refer to This Manual while Using the Camera to Further
Familiarize Yourself with the Camera
While reading this manual, take a few test shots and see how they
come out. You can then better understand the camera.
Testing the Camera Before Use and Liability
After shooting, play images back and check whether they have been
properly recorded. If the camera or memory card is faulty and the
images cannot be recorded or downloaded to a computer, Canon
cannot be held liable for any loss or inconvenience caused.
Copyrights
Copyright laws in your country may prohibit the use of your recorded
images or copyrighted music and images with music in the memory
card for anything other than private enjoyment. Also be aware that
certain public performances, exhibitions, etc., may prohibit photography
even for private enjoyment.
Introduction

3
Before starting, check that all the following items are included with your
camera. If anything is missing, contact your dealer.
* Battery Charger LC-E17 or LC-E17E is provided. (The LC-E17E comes with a
power cord.)
The Instruction Manuals and DVD/CD-ROMs provided are listed on the next
page.
If you purchased a Lens Kit, check that the lenses are included.
Depending on the Lens Kit type, lens instruction manuals may also be
included.
Be careful not to lose any of the above items.
Item Check List
Battery Pack
LP-E17
(with protective cover)
Battery Charger
LC-E17/LC-E17E*
Wide Strap
Camera
(with eyecup and body cap)
Interface Cable

4
The instruction manual consists of a booklet, leaflet, and PDF manuals
in electronic form (provided on the DVD-ROM). The booklet is the
Basic Instruction Manual. For more detailed instructions, see the
Camera Instruction Manual on the DVD-ROM.
EOS Camera Instruction Manuals Disk DVD-ROM
Contains the following PDF manuals:
• Instruction Manual
• Wi-Fi/NFC Function Instruction Manual
• Software Instruction Manuals for the software on the
EOS Solution Disk
* Instructions for viewing the Instruction Manuals on the DVD-ROM are
on pages 414-416.
EOS Solution Disk
Contains various software. For outlines and installation
procedure for the software, see pages 419-421.
Instruction Manual and DVD/CD-ROMs
Camera and Wi-Fi/NFC Function
Basic Instruction Manual
EOS Camera Instruction Manuals Disk XXX
XXXXX
XXXXX
XXXXX
XXXXX
XXXXX
CEL-XXX XXX
©
C
A
N
O
N
I
N
C
.
2
0
X
X
.
M
a
d
e
i
n
t
h
e
E
U
.
EOS Solution Disk XXX
CEL-XXX XXX
©
C
A
N
O
N
I
N
C
.
2
0
X
X
.
M
a
d
e
i
n
t
h
e
E
U
.
Windows XXX XXX
Mac OS X XXX XXX
XXXXX
XXXXX
XXXXX
XXXXX
XXXXX

5
The camera can use the following cards regardless of capacity: If the
card is new or was previously formatted by another camera or
computer, format the card with this camera (p.65).
• SD memory cards
• SDHC memory cards*
• SDXC memory cards*
* UHS-I cards supported.
When shooting movies, use a large-capacity SD card rated SD
Speed Class 6 “ ” or higher.
If you use a slow-writing card when shooting movies, the movie may
not be recorded properly. Also, if you play back a movie on a card
with a slow reading speed, the movie may not play back properly.
If you want to shoot still photos while shooting a movie, you will need
an even faster card.
To check the card’s reading/writing speed, refer to the card
manufacturer’s website.
Compatible Cards
Cards that Can Record Movies
In this manual, “card” refers to SD memory cards, SDHC memory
cards, and SDXC memory cards.
*The camera does not come with a card for recording images/
movies. Please purchase it separately.

6
Quick Start Guide
1Insert the battery (p.38).
To charge the battery, see page 36.
2Insert the card (p.39).
With the card’s label facing
toward the back of the
camera, insert it into the
card slot.
3Attach the lens (p.47).
Align the lens’s white or red mount
index with the camera’s mount
index of the same color.
4Set the lens focus mode switch
to <f> (p.47).
5Set the power switch to <1>,
then set the Mode Dial to <A>
(Scene Intelligent Auto) (p.76).
Turn the Mode Dial while holding down
the lock release button at the center.
All the necessary camera settings
will be set automatically.
White index Red index

7
Quick Start Guide
6Flip out the LCD monitor (p.41).
When the LCD monitor displays the
date/time/zone setting screens, see
page 44.
7Focus on the subject (p.52).
Look through the viewfinder and
aim the viewfinder center over the
subject.
Press the shutter button halfway,
and the camera will focus on the
subject.
If necessary, the built-in flash will be
raised.
8Take the picture (p.52).
Press the shutter button completely
to take the picture.
9Review the picture.
The captured image will be
displayed for 2 sec. on the LCD
monitor.
To display the image again, press
the <x> button (p.107).
To shoot while looking at the LCD monitor, see “Live View
Shooting” (p.201).
To view the images captured so far, see “Image Playback” (p.107).
To delete an image, see “Erasing Images” (p.318).

8
Icons in this Manual
<6> : Indicates the Main Dial.
<5> : Indicates the Quick Control Dial.
<W><X><Y><Z> : Indicates the direction of the shift or move
when the key on the Quick Control Dial is
pressed.
<0> : Indicates the Setting button.
0, 9, 7, 8: Indicates that each function remains active
for 4 sec., 6 sec., 10 sec., or 16 sec. after
you let go of the button.
* In this manual, the icons and markings indicating the camera’s buttons, dials,
and settings correspond to the icons and markings on the camera and on the
LCD monitor.
3: Indicates a function that can be changed by pressing the
<M> button to change its settings.
J: When shown on the upper right of a page, it indicates that the
function is available only in the Creative Zone modes (p.31).
(p.**) : Reference page numbers for more information.
: Warning to prevent shooting problems.
: Supplemental information.
: Tips or advice for better shooting.
: Troubleshooting advice.
Basic Assumptions
All operations explained in this manual assume that the power switch
is set to <1> and the <R> switch is set to the left (Multi
function lock released) (p.55).
It is assumed that all the menu settings, Custom Functions, etc. are
set to their defaults.
The illustrations in this manual show the camera attached with the
EF-S18-135mm f/3.5-5.6 IS STM lens as an example.
Conventions Used in this Manual

9
Chapters
Introduction 2
Getting Started 35
Basic Shooting and Image Playback 75
Setting the AF and Drive Modes 109
Image Settings 125
Advanced Operations 157
Flash Photography 175
Shooting with the LCD Monitor (Live View Shooting)
201
Shooting Movies 233
Handy Features 271
Image Playback 291
Post-Processing Images 325
Printing Images 333
Customizing the Camera 349
Reference 361
Viewing the DVD-ROM Instruction Manuals /
Downloading Images to Your Computer 413
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

10
Contents at a Glance
Shooting
Shoot automatically Îp.75-106 (Basic Zone modes)
Shoot continuously Îp.122 (iContinuous shooting)
Take a picture of yourself in a group Îp.124 (jSelf-timer)
Freeze the action Îp.160 (sShutter-priority AE)
Blur the action
Blur the background Îp.82 (CCreative Auto)
Keep the background in sharp focus Îp.162 (fAperture-priority AE)
Adjust the image brightness (exposure) Îp.169 (Exposure compensation)
Shoot in low light Îp.76, 176 (DFlash photography)
p.132 (ISO speed setting)
Shoot without flash Îp.81 (7Flash Off)
p.99 (bFlash off)
Shoot fireworks at night Îp.166 (Bulb exposure)
Shoot while viewing the LCD monitor Îp.201 (ALive View shooting)
Use Creative filters Îp.210 (Creative filters)
Shoot movies Îp.233 (kMovie shooting)
Image Quality
Shoot with image effects matching the subject Îp.135 (Picture Style)
Make a large-size print of the picture Îp.126 (73, 83, 1)

11
Take many pictures Îp.126 (7a, 8a, b, c)
AF (Focusing)
Change the AF area selection mode Îp.114 ( S AF area selection mode)
Shoot a moving subject Îp.89, 91, 112 (AI Servo AF)
Playback
View the images on the camera Îp.107 (xPlayback)
Search for pictures quickly Îp.292 (HIndex display)
p.293 (IImage browsing)
Rate images Îp.298 (Ratings)
Prevent important images Îp.316 (KImage protect)
from accidental deletion
Delete unnecessary images Îp.318 (LDelete)
Auto play back images and movies Îp.308 (Slide show)
View the photos or movies on a TV set Îp.312 (Video OUT)
Adjust the LCD monitor brightness Îp.274 (LCD monitor brightness)
Apply special effect to images Îp.326 (Creative filters )
Printing
Print pictures easily Îp.333 (Direct printing)

12
Power
Battery
• Charging Îp.36
• Installing/Removing Îp.38
• Battery check Îp.43
• Checking battery
information Îp.364
Household power outlet Îp.365
Auto power off Îp.42
Cards
Installing/Removing Îp.39
Formatting Îp.65
Release shutter without card Îp.272
Lens
Attaching/Detaching Îp.47
Zoom Îp.48
Image Stabilizer Îp.50
Basic Settings
Dioptric adjustment Îp.51
Language Îp.46
Date/Time/Zone Îp.44
Beeper Îp.272
LCD Monitor
Using the LCD Monitor Îp.41
LCD auto off/on Îp.285
Brightness adjustment Îp.274
Touch screen Îp.62
Recording Images
Creating/Selecting a folder Îp.275
File numbering Îp.277
AF
AF operation Îp.110
AF area selection mode Îp.114
AF point selection Îp.116
Manual focusing Îp.121
Drive
Drive mode Îp.122
Continuous shooting Îp.122
Self-timer Îp.124
Maximum burst Îp.128
Image Quality
Image-recording quality Îp.126
Picture Style Îp.135
White balance Îp.142
Auto Lighting Optimizer Îp.146
Noise reduction for long
exposures Îp.148
Noise reduction for high
ISO speeds Îp.147
Lens aberration correction Îp.150
Reducing flicker Îp.154
Highlight tone priority Îp.353
Color space Îp.156
Shooting
Shooting mode Îp.31
Feature guide Îp.73
ISO speed Îp.132
Aspect ratio Îp.130
Bulb Îp.166
Metering mode Îp.167
Mirror lockup Îp.173
Remote control Îp.366
Index to Features

13
Index to Features
Exposure Adjustment
Exposure compensation Îp.169
AEB Îp.170
AE lock Îp.172
Flash
Built-in flash Îp.176
External flash Îp.181
Flash function settings Îp.183
Wireless shooting Îp.189
Live View Shooting
Live View shooting Îp.201
AF operation Îp.216
AF method Îp.218
Continuous AF Îp.214
Touch Shutter Îp.226
Creative filters Îp.210
Movie Shooting
Movie shooting Îp.233
AF method Îp.218
Movie recording size Îp.245
Movie Servo AF Îp.263
Sound recording Îp.266
Manual exposure Îp.237
Still photo shooting Îp.242
Digital zoom Îp.248
HDR movies Îp.249
Miniature Effect Movies Îp.251
Video snapshot Îp.253
Playback
Image review time Îp.273
Single-image display Îp.107
Shooting information
display Îp.320
Index display Îp.292
Image browsing
(Jump display) Îp.293
Magnified view Îp.294
Image rotate Îp.297
Rating Îp.298
Movie playback Îp.304
Slide show Îp.308
Viewing images on a TV set Îp.312
Protect Îp.316
Erase Îp.318
Image Editing
Creative filters Îp.326
Resize Îp.329
Cropping Îp.331
Printing Îp.336
Customization
Custom Functions (C.Fn) Îp.350
My Menu Îp.360
Software Îp.413
Wi-Fi/NFC function
ÎWi-Fi/NFC Function Instruction
Manual

14
1
Introduction 2
Item Check List................................................................................. 3
Instruction Manual and DVD/CD-ROMs........................................... 4
Compatible Cards............................................................................. 5
Quick Start Guide ............................................................................. 6
Conventions Used in this Manual..................................................... 8
Chapters........................................................................................... 9
Contents at a Glance...................................................................... 10
Index to Features ........................................................................... 12
Contents ......................................................................................... 14
Safety Precautions ......................................................................... 20
Handling Precautions ..................................................................... 23
Nomenclature ................................................................................. 26
Getting Started 35
Charging the Battery ...................................................................... 36
Installing and Removing the Battery............................................... 38
Installing and Removing the Card .................................................. 39
Using the LCD Monitor ................................................................... 41
Turning on the Power ..................................................................... 42
Setting the Date, Time, and Zone................................................... 44
Selecting the Interface Language................................................... 46
Attaching and Detaching a Lens..................................................... 47
Lens Image Stabilizer ..................................................................... 50
Basic Operation.............................................................................. 51
QQuick Control for Shooting Functions ....................................... 57
3Menu Operations.................................................................. 59
dUsing the Touch Screen ............................................................. 62
Formatting the Card ....................................................................... 65
Switching the LCD Monitor Display ................................................ 67
lDisplaying the Grid ................................................................... 69
QDisplaying the Electronic Level............................................... 70
Displaying the Flicker Detection ..................................................... 72
Feature Guide ................................................................................ 73
Contents

15
Contents
4
2
3
Basic Shooting and Image Playback 75
AFully Automatic Shooting (Scene Intelligent Auto) ...................76
AFull Auto Techniques (Scene Intelligent Auto)..........................79
7Disabling Flash .........................................................................81
CCreative Auto Shooting.............................................................82
2Shooting Portraits ......................................................................86
3Shooting Landscapes ...............................................................87
4Shooting Close-ups....................................................................88
5Shooting Moving Subjects ........................................................89
8: Special Scene Mode .............................................................90
C Shooting Children ......................................................................91
PShooting Food ............................................................................92
xShooting Candlelight Portraits ...................................................93
6Shooting Night Portraits (With a Tripod) ....................................94
FShooting Night Scenes (Handheld)............................................95
GShooting Backlit Scenes............................................................96
QQuick Control............................................................................. 98
Shoot by Ambience Selection .......................................................100
Shoot by Lighting or Scene Type .................................................. 104
xImage Playback ......................................................................107
Setting the AF and Drive Modes 109
f: Changing the Autofocus Operation (AF operation) ................ 110
SSelecting the AF Area and AF Point ....................................... 114
AF Area Selection Modes ............................................................. 117
Subjects Difficult to Focus on........................................................120
MF: Manual Focus .....................................................................121
iSelecting the Drive Mode ........................................................122
jUsing the Self-timer .................................................................124
Image Settings 125
Setting the Image-Recording Quality ............................................ 126
Changing the Image’s Aspect Ratio..............................................130
g: Changing the ISO Speed to Suit the Light............................132

Contents
16
5
6
7
ASelecting a Picture Style ...................................................... 135
ACustomizing a Picture Style ................................................. 137
ARegistering a Picture Style ................................................... 140
B: Matching the Light Source (White balance)......................... 142
uAdjusting the Color Tone for the Light Source......................... 144
Auto Correction of Brightness and Contrast (Auto Lighting Optimizer) ... 146
Setting Noise Reduction............................................................... 147
Correction of Lens Peripheral Illumination and Aberrations ......... 150
Reducing Flicker........................................................................... 154
Setting the Color Reproduction Range (Color space) .................. 156
Advanced Operations 157
d: Program AE ............................................................................ 158
s: Conveying the Subject’s Movement (Shutter priority AE)..... 160
f: Changing the Depth of Field (Aperture priority AE) ............. 162
Depth-of-Field Preview .............................................................. 164
a: Manual Exposure ................................................................... 165
qChanging the Metering Mode (Metering mode)...................... 167
Setting Exposure Compensation (Exposure comp.) .................... 169
Auto Exposure Bracketing (AEB) ................................................. 170
ALocking the Exposure (AE Lock)............................................. 172
Mirror Lockup to Reduce Camera Shake ..................................... 173
Flash Photography 175
DUsing the Built-in Flash............................................................. 176
DUsing an External Speedlite ..................................................... 181
Setting the Flash .......................................................................... 183
Using Wireless Flash.................................................................... 189
Easy Wireless Flash Shooting...................................................... 192
Custom Wireless Flash Shooting ................................................. 195
Shooting with the LCD Monitor (Live View Shooting) 201
AShooting with the LCD Monitor .............................................. 202
Shooting Function Settings .......................................................... 208

17
Contents
9
8
UApplying Creative Filters .........................................................210
Menu Function Settings ................................................................214
Changing the Autofocus Operation (AF operation).......................216
Using AF to Focus (AF Method) ...................................................218
xShooting with the Touch Shutter .............................................226
MF: Focusing Manually.................................................................228
Shooting Movies 233
kShooting Movies .....................................................................234
Autoexposure Shooting..............................................................234
Manual Exposure Shooting ........................................................237
Shooting Still Photos ..................................................................242
Shooting Function Settings ...........................................................244
Setting the Movie Recording Size.................................................245
Using Movie Digital Zoom .............................................................248
Shooting HDR Movies...................................................................249
Shooting Miniature Effect Movies .................................................251
Shooting Video Snapshots............................................................253
Menu Function Settings ................................................................263
Handy Features 271
Handy Features ............................................................................272
Disabling the Beeper ..................................................................272
Card Reminder...........................................................................272
Setting the Image Review Time .................................................273
Setting the Auto Power-off Time ................................................273
Adjusting the LCD Monitor Brightness .......................................274
Creating and Selecting a Folder.................................................275
File Numbering Methods ............................................................ 277
Setting Copyright Information.....................................................279
Auto Rotation of Vertical Images................................................281
Reverting the Camera to the Default Settings............................282
Preventing the LCD Monitor from Turning Off Automatically......285
Changing the Shooting Settings Screen Color...........................285

Contents
18
10
11
12
fAutomatic Sensor Cleaning ................................................... 286
Appending Dust Delete Data........................................................ 287
Manual Sensor Cleaning .............................................................. 289
Image Playback 291
xSearching for Images Quickly ................................................ 292
u/yMagnified View................................................................... 294
dPlaying Back with the Touch Screen ........................................ 295
bRotating the Image .................................................................. 297
Setting Ratings ............................................................................. 298
QQuick Control for Playback ..................................................... 300
kEnjoying Movies ..................................................................... 302
kPlaying Back Movies .............................................................. 304
XEditing a Movie’s First and Last Scenes ................................. 306
Slide Show (Auto Playback) ......................................................... 308
Viewing Images on a TV Set ........................................................ 312
KProtecting Images................................................................... 316
LErasing Images........................................................................ 318
B: Shooting Information Display ............................................. 320
Post-Processing Images 325
UApplying Creative Filters......................................................... 326
SResizing JPEG Images........................................................... 329
NCropping JPEG Images .......................................................... 331
Printing Images 333
Preparing to Print.......................................................................... 334
wPrinting................................................................................... 336
Cropping the Image ................................................................... 341
WDigital Print Order Format (DPOF) ......................................... 343
WDirect Printing of Print-Ordered Images ................................. 346
pSpecifying Images for a Photobook ......................................... 347

19
Contents
13
15
14
Customizing the Camera 349
Setting Custom Functions.............................................................350
Custom Function Settings.............................................................352
C.Fn I : Exposure .....................................................................352
C.Fn II : Image ..........................................................................353
C.Fn III : Autofocus/Drive ........................................................... 354
C.Fn IV : Operation/Others.........................................................357
Registering My Menu .................................................................... 360
Reference 361
BButton Functions .................................................................. 362
Checking the Battery Information.................................................. 364
Using a Household Power Outlet..................................................365
Remote Control Shooting..............................................................366
HUsing Eye-Fi Cards ................................................................. 368
Function Availability Table by Shooting Mode...............................370
System Map .................................................................................. 376
Menu Settings ............................................................................... 378
Troubleshooting Guide..................................................................385
Error Codes...................................................................................399
Handling Precautions: STM Lenses (Kit Lenses) .........................400
Specifications ................................................................................ 401
Viewing the DVD-ROM Instruction Manuals /
Downloading Images to Your Computer 413
Viewing the EOS Camera Instruction Manuals Disk DVD-ROM...414
Downloading Images to a Computer.............................................417
About the Software .......................................................................419
Installing the Software...................................................................420
Index .............................................................................................423

20
The following precautions are provided to prevent harm or injury to
yourself and others. Make sure to thoroughly understand and follow
these precautions before using the product.
If you experience any malfunctions, problems, or damage to the
product, contact the nearest Canon Service Center or the dealer
from whom you purchased the product.
To prevent fire, excessive heat, chemical leakage, explosions, and electrical shock,
follow the safeguards below:
• Do not use any batteries, power sources, or accessories not specified in the
Instruction Manual. Do not use any home-made or modified batteries.
• Do not short-circuit, disassemble, or modify the battery. Do not apply heat or solder
to the battery. Do not expose the battery to fire or water. Do not subject the battery
to strong physical shock.
• Do not insert the battery’s plus and minus ends incorrectly.
• Do not recharge the battery in temperatures outside the allowable ambient
temperature range. Also, do not exceed the recharging time indicated in the
Instruction Manual.
• Do not insert any foreign metallic objects into the electrical contacts of the camera,
accessories, connecting cables, etc.
When disposing of a battery, insulate the electrical contacts with tape to prevent
contact with other metallic objects or batteries. This is to prevent a fire or an
explosion.
If excessive heat, smoke, or fumes are emitted when recharging the battery,
immediately unplug the battery charger from the power outlet to stop recharging.
Otherwise, it may cause a fire, heat damage, or electrical shock.
If the battery leaks, changes color, deforms, or emits smoke or fumes, remove it
immediately. Be careful not to get burned in the process. It may cause a fire, electrical
shock or skin burn if you keep using it.
Prevent any battery leakage from contacting your eyes, skin, and clothing. It can
cause blindness or skin problems. If the battery leakage contacts your eyes, skin, or
clothing, flush the affected area with lots of clean water without rubbing it. See a
physician immediately.
Do not leave any cords near a heat source. It can deform the cord or melt the
insulation and cause a fire or electrical shock.
Do not hold the camera in the same position for long periods of time. Even if the
camera does not feel too hot, prolonged contact with the same body part may cause
skin redness, blistering or low-temperature contact burns. Using a tripod is
recommended for people with circulation problems or very sensitive skin, or when
using the camera in very hot places.
Do not fire the flash at anyone driving a car or other vehicle. It may cause an
accident.
Safety Precautions
Warnings Follow the warnings below. Otherwise, death or
serious injuries may result.
