ECHNICAL DOCUMEN S
LARGE-FORMA PRODUC ION PRIN ING SOLU IONS
iPF820/810

Introducing the
imagePROGRAF®iPF820
and iPF810 Printers
Large-format solutions for technical
documents production printing
Are your large-format printers keeping
pace with your need for technical
documents in color and monochrome?
If not, then it’s time to take a look at the
new imagePROGRAF iPF820 and iPF810,
Canon’s single-solution, large-format
printing systems developed specifically
to meet the demands of manufacturing,
engineering, construction and reprographic
firms for seamless, uninterrupted production
of razor-sharp monochrome plots and
high-quality color prints.
With world-renown Canon technology at their core,
these printers were built to keep you moving
forward and ahead of the curve by consolidating
printing operations, increasing workgroup productivity,
and minimizing costs while improving the image
quality of every print produced. Choose the one
that’s right for you.
imagePROGRAF iPF820 PRIN ER
A 44"-wide powerhouse printing system that keeps
workgroups productive, with dual media rolls that
support multiple media types and long print runs.
imagePROGRAF iPF810 PRIN ER
A highly versatile large-format printing system
for high-volume production printing on media
up to 44"- wide.
imagePROGRAF iPF820 PRO/iPF810 PRO PRIN ERS
Select either the iPF820 PRO or iPF810 PRO for a
complete technical documents production printing
solution that includes CAD|STATION PS+, a True
Adobe®PostScript®Color RIP that features print
management and job accounting functionality.

CAN YOU IMAGINE HE NEX GENERA ION
IN ECHNICAL DOCUMEN S PRIN ING?
What if you could upgrade your large-format
printing operations from “the way it is” to
the “way you know it needs to be”?
Now you can. With the introduction of the
new 44"- wide imagePRO RAF iPF820/810
large-format printers, Canon has brought
to market the next generation in technical
documents printing. Built for high-speed
production of both full-color and monochrome
output, these single-solution printing systems
effortlessly produce intricately detailed CAD
drawings, color renderings, and IS maps.
Start by choosing either the single- or dual-
media-roll model, then add a large-format
scanner, stacker, and production software with
True Adobe PostScript RIP to configure the
multifunction system solution you need for
high-volume production printing and support
for large workgroups.
Highly efficient, superb print quality, versatile
options, and a remarkably low total cost of
ownership – this is the large-format printing
system you’ve been waiting for.
iPF820/810

Speed and Precision – Two D-Sized Prints Per Minute
Print speed is critical when you need
to keep projects moving forward and
meet tight deadlines. That’s why the
imagePRO RAF iPF820/810 printers
are built for high-speed production of
complex schematics, drawings, maps,
and presentations.
WO D-SIZED PRIN S PER MINU E,
IN COLOR OR MONOCHROME
Canon’s advanced system architecture
achieves print speeds of up to 688 ft.2/hr.
on plain papers. Or print a full-color,
2400 x 1200 dpi high-resolution, A0-sized
image (10.76 ft.2) with full graphic coverage on
heavyweight coated media in only
three minutes.*
SPEC ACULAR ACCURACY
AND EX RAORDINARY DE AIL
A large 1.07", super-high-density print-head
with 15,360 nozzles and a double set of
Matte Black ink channels ejects minuscule
4pl droplets of ink across a wide swath of
media. The result is consistently accurate,
2400 x 1200 dpi output with fine lines
that are accurate to +/- 0.10% and as
thin as 0.02mm.
FIVE-COLOR REAC IVE INK ECHNOLOGY
Print complex schematics with super-clear
small text fonts and crisp lines over color
backgrounds, even on uncoated technical
papers. This unique, wide-color-gamut ink set
features four colorfast dye inks and a pig-
ment Matte Black ink that are chemically
engineered to prevent excessive “bleeding”
so text and lines are always sharp and legible.
* Mechanical print time does not include data transfer time. Print time is measured for 60 consecutive minutes (including head cleaning and cutting time), printing multiple
copies using Canon Printer Driver with Plain Paper setting at Draft (full-density) Mode.

The new imagePRO RAF iPF820/810
printers are single-solution systems built
to satisfy the full range of large-format
technical document printing requirements
professionals encounter every day.
DUAL MEDIA ROLLS
Equipped with dual media rolls, the
iPF820 printer eliminates the cause
of many bottlenecks in busy printing
environments. It can automatically
switch between different size and
types of media or print on the same
media to enable fast, consecutive printing
of jobs submitted by multiple users.
VERSA ILE OU PU UP O 44"- WIDE
Print what you need, when you need
it. With the auto rotation and nesting
functionality on HP- L/2 files, the
iPF820/810 printers not only maximize
throughput, but they also help save on
media consumption and per-print costs.
AU OMA IC BLACK INK SELEC ION
Based on the type of media being
used, the printer will automatically
select the right type of black ink for
best results: pigment Matte Black for
uncoated and technical papers or dye
Black for coated and glossy media.
BORDERLESS PRIN ING
Print from edge-to-edge.* Output can
be ready to use without additional
trimming and finishing when utilizing
the borderless printing option.
SELF-PROPELLED CU ER
The double rotary blade cutter is driven
separately from the print-head carriage
so that cutting can start immediately
after printing is finished. The result is
faster, continuous throughput.
PRIN LONGER WI HOU IN ERRUP ION
Canon’s unique sub-ink tank system
means you can replace ink on-the-fly,
without stopping the printer. Choose
the extra large 700ml ink tanks for
even greater productivity.
MEDIA DE EC ION SYS EM
The automatic media detection and
management system keeps track of
paper usage and warns the user if
there’s not enough media to complete
a print task.
HIGH-CAPACI Y MEDIA BASKE
For long print runs, a high-capacity
media basket comes standard on
both the iPF820 and iPF810 printers.
Productivity – Maximized
*Up to 42" wide

MAXIMUM PRODUCTIVITY
•Print two D-sized prints per minute or
120 D-sized prints per hour, in color or
monochrome
•The iPF820 is equipped to automatically
switch between its dual media rolls to
enable fast, consecutive printing of
different media types and sizes
•Send large sets of files from multiple
workstations to a built-in 80 B hard drive
•Economy Print Mode allows for lower
cost of operation
•High-density print-head with 15,360 nozzles
provides high-speed, accurate results
•Self-propelled cutter can start cutting
immediately after printing is finished
for fast throughput time of multipage
documents
•Sub-ink tank system allows for changing
ink without interrupting a print job
VER ATILITY
•Direct printing support for HP- L/2 and
HP RTL
•The enhanced HDI Driver enables direct
printing from AutoCAD®and AutoCAD LT
•Convenient media feed options for
everyday use
•Intuitive printer driver UI enables easy
selection of automatic roll switching
functionality
HIGH-QUALITY PRINTING
•High-resolution output up to
2400 x 1200 dpi
•Print fine 0.02mm thick lines with
tiny 4-picoliter ink droplets
•Precise +0.1% line accuracy
•Unique five-color dye/pigment Reactive
Ink technology optimizes imaging
imagePROGRAF®
TECHNICAL DOCUMENTS: LARGE-FORMAT PRINTING
iPF810 iPF820

HIGH-CAPACI Y PLAIN PAPER S ACKER
•Optional stacker provides a flat surface
to off-load prints, eliminating the need
for operator handling
•Built for high productivity
•Stacker automatically picks up plain
paper documents of mixed sizes
and stacks them up to 300 sheets
CAD|S A ION PS+ SOF WARE
(PRO Models Only)
•A full-color RIP with true Adobe PostScript
processing, advanced job management
features, and accounting functionality
•Web submission tools drag-and-drop
hot folders, and client/server workflow
features for significant increase
in productivity
LARGE-FORMA SCANNER
•Optional large-format scanner provides
a powerful scan-to-copy/archive/e-mail
integrated workflow solution
•Fast and effective large-format
capture-to-output functionality
General View of Interface
Cost Accounting
Configuration
MULTIFUNCTION SOLUTIONS TO FIT YOUR ORKFLO

Operations – Optimized
Canon designed the large-format
imagePRO RAF iPF820/810 printers
to make producing technical documents
faster, easier, and more efficient. To help
you optimize daily operations, the enhanced
features contribute directly to overall
performance and simplified end-user tasks.
WORKGROUP PRIN ING
Waiting for large files to print can slow down
an entire workgroup. That’s where an 80 B
hard drive makes all the difference. Now
multiple users can organize and manage their
print jobs easily via the system’s remote user
interface with up to 29 password-protected
mail boxes. Once a large data file is sent,
the printer stores it in the queue, freeing
workstations for the next project. The large
hard drive capacity means workgroups can
be extra productive.
ENHANCED REMO E USER IN ERFACE
The enhanced Remote User Interface
includes password-protected mail boxes
to help organize and manage print jobs
from multiple users, so medium- to
large-size workgroups can share the
printer more efficiently.
CANON PRIN ER DRIVER
Intuitive operation with easy and
advanced settings for both Windows
and Macintosh users.
FREE-LAYOU FUNC ION
Assemble charts, tables, text documents,
and graphics of different file formats onto a
single page, and print them together to create
high-impact posters and presentations.
SCAN- O-PRIN ENLARGEMEN S
Making enlargements is as easy as
making copies when an imagePRO RAF
large-format printer is seamlessly integrated
with a Canon imageRUNNER®or
imagePRESS™multifunction system
with Universal Send.
REAL PREVIEW FUNC ION
Avoid unnecessary errors and reprints
with this real-time preview function that
enables users to modify settings, even
after clicking “Print.”
COLOR EMULA ION
The color emulation function helps these
imagePRO RAF printers to approximate
the colors produced by other legacy
large-format ink-jet printers.
ENHANCED HDI DRIVER
Print HP- L/2 and HP RTL files directly
from CAD applications, including AutoCAD
and AutoCAD LT via Canon’s enhanced HDI
Driver. This high-speed HDI driver saves users
time and improves workgroup efficiencies.
HARD DRIVE SECURI Y
The 80 B hard drive supports multiple
methods of data erasure and document
security, ranging from a quick and easy
option that simply removes file system infor-
mation to a triple overwrite of the hard drive
that conforms to the DoD.52220.22-M stan-
dard of the U.S. Department of Defense.

In addition to the low initial acquisition cost
of these printers, a number of important
features minimize ink consumption, media
waste, and maintenance costs to contribute
to a significantly reduced total cost of
operations while still producing technical
documents of the highest quality.
•Economy Print Mode lo ers the cost
per print: Significantly reduce ink
consumption and lower total printing
costs by selecting Economy Print Mode
when printing drafts and check plots.
•Durable print-head reduces maintenance
costs: Canon’s unique high-density
print-head ejects fine droplets of ink with
remarkable efficiency and accuracy.
With 15,360 nozzles, there’s less wear
and tear on each individual nozzle,
increasing the life of the print-head.
•Large-Capacity Ink Tanks: Large 330ml
or 700ml ink tank helps lower total cost
of ownership overtime while increasing
your productivity.
•Minimize media aste: Canon’s auto
rotation and nesting feature with HP- L/2
files helps you take full advantage of the
printer’s 44"- wide media capacity.
•Ink technology improves print durability:
Chemically engineered for improved
durability and adhesion, Canon’s unique
five-color Reactive Ink technology can
actually extend the life of your full-color
maps, schematics, and construction plans.
Even with the stress of constant handling,
writing, and display, ink stays put, so you
won’t need to spend time and money
reprinting large-format documents.
•Energy Savings: Engineered for efficiency
and reliability, these ENER Y STAR®
qualified printers draw only 190 watts
of power during use.
Costs – Minimized

System Solutions – Simplified
imagePROGRAF iPF820 PRO AND
imagePROGRAF iPF810 PRO PRIN ERS
Choose either the iPF820 PRO or iPF810 PRO
printer to further enhance your operations with
a complete production printing solution that
includes CAD|STATION PS+, a True Adobe PS
color RIP with advanced job management and
accounting functionality. CAD|STATION PS+
has a client/server architecture with the ability
to set up an unlimited number of clients, giv-
ing these PRO model printers greater func-
tionality. They also simplify batch printing pro-
cedures, relieve the image processing burden
from end-user workstations for faster job
throughput, and include advanced accounting
and job-cost tracking functions.
•With the PRO model printers, you can
print directly from Windows or AutoCAD
HDI drivers.
•Printing of industry-specific file formats:
HP- L/2, HP RTL, C M, CALS, AutoCAD,
DWF, DXF, and DW as well as PS, EPS,
PDF, TIFF, BMP, and others.
•This tool set provides additional controls
over output options and helps manage
batch printing more efficiently.
•The color RIP includes profiles for a
wide variety of media along with color
calibration tools.
•Accounting functions track output activity
and record details such as project, customer,
or cost center information to simplify
invoicing and project cost accounting.
•Web-based job submission
Submitting Jobs via eb Client Job Configuration

iPF820/810
These highly versatile printers can also
be configured with additional options to
fully optimize your productivity from input
to output.
HIGH-CAPACI Y S ACKER
Add an optional high-capacity plain paper
stacker for even greater efficiency. The stacker
provides a sturdy flat surface to off-load plain
paper prints and eliminates the need for
operator handling. Multiple workstations can
send jobs to the printer unattended and
retrieve them later, without hampering the
stacker’s capacity.
•Automatically picks up documents and
stacks them up to 300 sheets (plain paper)
•User-installable
•Stacker tray holds mixed output sizes
HIGH-SPEED, HIGH-RESOLU ION
LARGE-FORMA SCANNING
Need to archive, reproduce, or distribute
large-format documents and presentations
from hard-copy originals? Add a compatible
high-speed, high-quality large-format scanner
to your imagePRO RAF printer to create a
complete multifunction, scan-to-copy solution.

Print-Head
PF- 03
Technology
FINE (Photolithography Ink-jet Nozzle Engineering)
Print Resolution (Max.)
2400 x 1200 dpi
Line Accuracy*
±0.1% or Less
Minimum Line Weight**
0.02mm
Number of Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet ize
4 Picoliter
Nozzle Pitch (Head Resolution)
1200 dpi x Two Rows
Print-Head wath
1.07 inch
Ink Type
Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K)
Pigment: Matte Black (MBK)
Ink Tank
hipped with Printer: PFI-303 (330ml) MBK, C, M, Y, K
Replacement: PFI-703 (700ml) MBK, C, M, Y, K
PFI-303 (330ml) MBK, C, M, Y, K
Ink upply Method
Tubing System with Sub-Tanks for Continuous Ink Supply
Nozzle Recovery ystem
Non-firing Nozzle Detection and Compensation
Printer Controller
L-COA Controller
Printer Memory
384MB
Hard Drive
80 B
Mail Boxes (User Job torage)
One Common Inbox; 29 User Inboxes
(Password-protected)
Media Feed
Roll Feed: iPF810: One Roll, Front-loading, Front Output
iPF820: Two Rolls, Front-loading, Front Output
Media Width
Roll Feed: 10" – 44" (254mm – 1118mm)
Cut heet: 8" – 44" (203.2mm – 1118mm)
Printable Margins
Roll Feed: All Sides: 0.12" (3mm) or 0" for Borderless
Maximum Print Length ( ingle Page)†
Roll Feed: 59' (18m)
Cut heet: 63" (1.6m)
Borderless Printing Widths (Roll Media Only)
10", 14", 17", 24", 36",42" B2 (20.28"/515mm),
A1 (23.38"/594mm), B0 (40.6", 1030mm),
A0 (33.11"/841mm)
Media Cutter
Durable Dual-Blade Rotary Cutter
Media Thickness
0.07 – 0.8mm (2.8 – 31.4mil)
Media Core izes
2" and 3" Core (Adapter Included)
Maximum Roll Outer Diameter
5.9" (150mm)
Output Media Bin
Portable Media Basket (Standard), 44" Plain Paper
Stacker (Optional), Media Take-Up Reel (Optional,
iPF810 only)
Printing oftware
iPF810/iPF820
imagePRO RAF Printer Driver, HDI Driver
††
, Printer Driver
Extra Kit (Free Layout, imageRUNNER Linking Function),
Print Plug-in for Microsoft®Office
iPF820 PRO/iPF810 PRO
‡
Above plus RATIO®CAD|STATION PS+
(CAD|STATION PS+ Server, PLOTCLIENT|SET,
PLOTCLIENT|HDI, PLOTCLIENT|WEB, WINPRINT)
Operating ystem
Printer Driver
Windows 32-bit 2000/XP/Server 2003/Vista/Server
2008, Windows 64-bit XP/Server 2003/Vista/Server
2008, Macintosh®OS X (10.2.8, 10.3.x, 10.4.x),
Macintosh OS X CUPS (10.4.9, 10.5.x)
CAD| TATION erver
Windows 2000/XP/2003 Server/Vista
Print Language
Printer
ARO, HP- L/2, HP RTL
CAD| TATION P + (PRO Models Only)
Adobe®PostScript®3, PDF 1.4, EPS, HP- L,
HP- L/2, HP RTL, DWF, DW , PLT, CALS,
C M, TIFF, JPE , BMP, CALS, C M
Interface
tandard (Built-in): USB 2.0 Hi-Speed, 10/100Base-T/TX
Optional: IEEE1394 (FireWire)
Acoustic Noise
Operation: 52dB (A) or Less
tandby: 35dB (A) or Less
Acoustic Power: 6.8 Bels or Less
Power upply
AC 100–240V (50-60Hz)
Power Consumption
Maximum: 190W or Less
tandby: 6W or Less (11W or less when IEEE1394 is mounted)
Power Off: 1W or Less (Executive Order Compliant)
Certifications
Electrical afety Regulations
UL (USA), C-UL (Canada), S mark
(Argentina), CE mark (EN60950, EN55022
classB, EN61000-3-2, EN-61000-3-3, EN55024)
(EU), CB certification (Others)
Electromagnetic Interface Regulations
FCC Class B (USA), IC Class B (Canada)
Environmental Certifications
ENER Y STAR®(Worldwide), RoHS
Directive, WEEE, Executive Order (USA)
Operational Environment
Temperature: 59 – 86 F° (15 – 30 C°)
Relative Humidity: 10 – 80% (No Condensation)
Printer Dimensions (H x W x D) and Weight with tand
iPF810/iPF810 PRO
45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm),
Approx. 335 lb. (152kg)
iPF820/iPF820 PRO
45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm),
Approx. 417 lb. (189kg)
Package Dimensions (H x W x D) and Weight
iPF810/iPF810 PRO
49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm),
Approx. 664 lb. (301kg)
iPF820/iPF820 PRO
49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm),
Approx. 768 lb. (348kg)
Options
•
IEEE1394 Expansion Board (EB-05)
•
44" Plain Paper Stacker (STK1-94)
•
Take-Up Unit (TU-06)
•
Roll Holder Set (RH2 - 44)
•
PosterArtist
User-Replaceable Items
•
Ink Tank (PFI -303/PFI-703)
•
Print-Head (PF- 03)
•
Maintenance Cartridge (MC-09)
What’s In The Box
iPF810
Printer, Portable Media Basket, User Software CD
(Printer Driver, HDI Driver, Utilities), 5 Ink Tanks
(MBK, C, M, Y, K), 2/3" Core Media Spool, Print-Head,
Maintenance Cartridge, Quick Setup uide (Poster),
Printer Reference uide (Booklet), Power Cord,
One-Year Onsite Limited Warranty, Registration
Card, Stand, Hardware (For Setting Up the Printer)
iPF820
All items included in iPF810, plus Secondary Roll Unit
iPF820 PRO/iPF810 PRO
All items included in iPF810 or iPF820, plus
CAD|STATION PS+ Package
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has etermine that these pro ucts meet the ENERGY STAR®
gui elines for energy efficiency. ENERGY STAR an the ENERGY STAR mark are registere U.S. marks. Microsoft,
Win ows, an Win ows Vista are registere tra emarks of Microsoft Corporation in the Unite States an /or
other countries. Intel is a tra emark of Intel Corporation in the U.S. an other countries. Macintosh is a tra emark
of Apple Inc. AutoCAD is a tra emark of Auto esk, Inc. in the Unite States. A obe, PostScript, an Illustrator are
registere tra emarks or tra emarks of A obe Systems Incorporate in the Unite States an /or other countries.
QuarkXPress is a tra emark of Quark, Inc. an all applicable affiliate companies, Reg. U.S. Pat. an Tm. Off. an
in many countries. CANON, IMAGEPROGRAF, IMAGERUNNER, an the GENUINE logo are registere tra emarks
an IMAGEPRESS is a tra emark of Canon Inc. in the Unite States an may also be registere tra emarks or
tra emarks in other countries. IMAGEANYWARE is a tra emark of Canon. All other reference pro uct names an
marks are tra emarks of their respective owners an are hereby acknowle ge . All printer output images simulate .
Specifications an availability subject to change without notice.
©2008 Canon U.S.A., Inc. All rights reserve .
0126W149
1008-820/810-25M-LDM
PRINTED ON RECYCLED
PAPER IN THE U
. S . A .
E
SPECIFICA IONS
iPF820/810
*Line accuracy repeatability is guaranteed after a user performs
necessary adjustment and under the same environmental
conditions. Applies to media for line drawing (Plain Paper,
Coated Paper, CAD Translucent Matte Film, and CAD Tracing
Paper) only.
** Theoretical value based on data resolution.
†The maximum printable length varies, depending on the
application, OS, and RIP used.
†† For AutoCAD or AutoCAD LT 2000/2000i/2002/2004/2005/
2006/2007/2008/2009
‡
For high-speed and error-free printing of PostScript files
such as PS, PDF or EPS, using CAD|STATION PS+ software
in iPF810 PRO or iPF820 PRO is strongly recommended.
Alternatively, other PostScript compatible RIP package may
be used to print PostScript files. For a list of Canon
recommended RIP packages, please consult with
Canon Alliance and Industry Market program list
of RIP vendors at .usa.canon.com.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
