Canon LBP-2000 User manual

REVISION 0
FY8-13HQ-000
COPYRIGHT


 2001 CONON INC. CANON LBP-2000 REV.0 AUG.2001
AUG. 2001
SERVICE
MANUAL

Use of this manual should
be strictly supervised to
avoid disclosure of confi-
dentialinformation.
COPYRIGHT ©2001 CANON INC

P - 1
PREFACE
INTRODUCTION
This Service Manual provides basic facts and figures needed to service the laser beam printer LBP-
2000 (hereafter, the Printer), performed to ensure initial product quality and performance.
The following options may be used in combination with the Printer:
• Universal Cassette UC-65
• Paper Feeder Unit PF-65
• Hard Disk HD-65
• Ether Board EB-65
This Service Manual also covers these options. For others, see their respective Service Manuals.
This Service Manual consists of the following chapters:
Chapter 1, ‘Product Outline,’ introduces features and specifications as well as how to install and
use the Printer.
Chapter 2, ‘Operation,’ explains the principles of operation used in the mechanical/electrical
systems of the Printer according to function as well as timing at which associated
mechanisms operate.
Chapter 3, ‘Mechanical System,’ shows the mechanical construction of the Printer and how to
disassemble/assemble and adjust its components.
Chapter 4, ‘Troubleshooting,’ indicates how to correct various faults and make checks/adjust-
ments, and provides standards to follow.
APPENDIX contains a general timing chart, general circuit diagrams, and list of signals.
Changes made to the descriptions because of product improvement or the like will be commu-
nicated in the form of Service Information bulletins as they occur.
All service persons are expected to go through this Service Manual and Service Information
bulletins for a full understanding of the Printer while equipping themselves with skills and knowl-
edge used to identify and correct faults in the Printer.

PREFACE
P - 2
CONTENTS
CHAPTER 1 PRODUCT OUTLINE
CHAPTER 2 OUTLINE OF OPERATION
I. FEATURES .............................. 1-1
II. SPECIFICATIONS ..................... 1-2
A. Printer ............................. 1-2
B. Options ............................ 1-4
III. SAFETY ................................... 1-5
A. Safety of the Laser Unit .... 1-5
B. Safety of Toner ................. 1-5
C. Safety of Ozone ................ 1-5
IV. NAMES OF PARTS ................... 1-6
A. External View ................... 1-6
B. Cross Section ................... 1-8
V. INSTALLATION ........................ 1-9
A. Points to Note About
Installation....................... 1-9
B. Selecting the Site ............. 1-9
C. Unpacking and Installing .. 1-11
D. When Storing or Handling
the EP-65 Cartridge .......... 1-18
VI. RELOCATING THE PRINTER .... 1-21
VII. ROUTINE MAINTENANCE/
INSPECTION BY THE USER ...... 1-22
VIII. USING THE PRINTER ............... 1-25
A. The Operation Panel ......... 1-25
B. Operation Panel Menus ..... 1-27
C. Service Menu.................... 1-28
I. BASIC OPERATION .................. 2-1
A. Functional Construction ... 2-1
B. Sequence of Basic
Operation ......................... 2-2
C. Power-On Sequence .......... 2-6
II. ENGINE CONTROL SYSTEM ..... 2-7
A. Outline of the Electrical
Circuitry .......................... 2-7
B. Inputs to and Outputs from
the DC Controller ............. 2-9
C. Controlling the Fixing
Mechanisms ..................... 2-12
D. High-Voltage Power Supply
Circuit ............................. 2-18
E. Low-Voltage Power Supply
Circuit ............................. 2-23
F. Video Interface Control .... 2-25
G. Other Control ................... 2-27
III. LASER/SCANNER SYSTEM ...... 2-30
A. Outline ............................. 2-30
B. Laser Control Circuit ........ 2-31
C. Scanner System................ 2-34
IV. IMAGE FORMATION SYSTEM ... 2-37
A. Outline ............................. 2-37
B. Printing Process ............... 2-38
V. PICKUP/FEEDING SYSTEM ...... 2-46
A. Outline ............................. 2-46
B. Detecting the Paper Size .. 2-49
C. Using the Cassette ............ 2-50
D. Using the Multifeeder ....... 2-51
E. Fixing/Delivery
Assembly .......................... 2-53
F. Detecting Jams ................ 2-54
VI. VIDEO CONTROL SYSTEM ....... 2-59
A. Outline of the Electrical
Circuitry .......................... 2-59
B. Operation Panel ................ 2-62
C. Self Test ........................... 2-63
VII. PAPER FEEDER ....................... 2-65
A. Outline ............................. 2-65
B. Inputs to and Outputs from
the Paper Feeder
Controller ......................... 2-66
C. Pickup/Feeding
Operation ......................... 2-67
D. Detecting Jams ................ 2-70

P - 3
PREFACE
CHAPTER 4 TROUBLESHOOTING
APPENDIX
CHAPTER 3 MECHANICAL SYSTEM
I. EXTERNALS AND CONTROLS... 3-1
A. External Covers ................ 3-1
B. Heat Discharging Fan ....... 3-4
C. Door Switch Assembly ...... 3-5
II. PCBS ....................................... 3-8
A. Arrangement of the PCBs .. 3-8
B. Video Controller PCB ........ 3-8
C. DC Controller PCB ............ 3-12
D. Power Supply PCB
Assembly .......................... 3-14
III. DRIVE MECHANISMS ............... 3-15
A. Main Motor ....................... 3-15
B. Drive Assembly ................. 3-16
IV. FEEDING MECHANISMS........... 3-17
A. Cassette Pickup
Assembly .......................... 3-17
B. Multifeeder Tray Pickup
Assembly .......................... 3-20
C. Registration Roller
Assembly .......................... 3-23
V. EXPOSURE MECHANISMS ....... 3-25
A. Laser/Scanner Assembly ... 3-25
VI. CHARGING/DEVELOPING/
CLEANING MECHANISMS ......... 3-26
A. EP-65 Cartridge ................ 3-26
B. Transfer Charging Roller ... 3-26
VII. FIXING SYSTEM ...................... 3-27
A. Fixing Assembly ............... 3-27
VIII. PAPER FEEDER ....................... 3-34
A. External Covers ................ 3-34
B. Pickup Assembly .............. 3-34
C. Drive Mechanism .............. 3-38
D. PCBs ................................ 3-39
I. INTRODUCTION ....................... 4-1
A. Troubleshooting Flow
Chart ................................ 4-1
B. Making Initial Checks ....... 4-4
C. Test Print ......................... 4-5
II. TROUBLESHOOTING IMAGE
FAULTS ................................... 4-10
III. MEASURES AGAINST JAMS ..... 4-17
IV. FEEDING FAULTS .................... 4-21
V. MALFUNCTIONS ...................... 4-23
VI. CORRECTING A FAULT STATUS
CONDITION ............................. 4-25
VII. STANDARDS AND
ADJUSTMENTS ........................ 4-31
A. Making Mechanical
Adjustments ..................... 4-31
B. Making Electrical
Adjustments ..................... 4-32
C. Copying the Counter
Readings .......................... 4-33
D. Variable Resistors (VR), Light-
Emitting Diodes (LED), Check
Pins, Jumpers, and Switches by
PCB .................................. 4-34
VIII. MAINTENANCE AND
INSPECTION ............................ 4-38
A. Periodically Replaced
Parts ................................ 4-38
B. Durables ........................... 4-38
C. Scheduled Servicing ......... 4-39
D. Points to Note for
Cleaning ........................... 4-40
E. Standard Tools ................. 4-41
F. Special Tools .................... 4-42
G. Solvents and Oils .............. 4-42
IX. ARRANGEMENT OF ELECTRICAL
PARTS ..................................... 4-43
A. Switches and Sensors ....... 4-43
B. Clutches, Solenoids, and
Motors ............................. 4-45
C. Others .............................. 4-47
D. PCBs ................................ 4-48
E. Connectors ....................... 4-50
I. GENERAL TIMING CHART ........ A-1
II. GENERAL CIRCUIT DIAGRAM .. A-3
III. LIST OF SIGNALS .................... A-5
A. Inputs to and Outputs from
the DC Controller PCB ...... A-5
B. Inputs to and Outputs from
the Paper Feeder
Controller PCB ................. A-9
IV. MESSAGES TABLE ................... A-10

CHAPTER 1
PRODUCT OUTLINE
I. FEATURES .............................. 1-1
II. SPECIFICATIONS ..................... 1-2
III. SAFETY ................................... 1-5
IV. NAMES OF PARTS ................... 1-6
V. INSTALLATION ........................ 1-9
VI. RELOCATING THE PRINTER .... 1-21
VII. ROUTINE MAINTENANCE/
INSPECTION BY THE USER ...... 1-22
VIII. USING THE PRINTER ............... 1-25

1 - 1
CHAPTER 1
I. FEATURES
1. High-speed printing
Although compact in design, the Printer is a high-speed printer capable of generating 20 pages per
minute.
2. Various sources of paper with the addition of options
In addition to the cassette and the multifeeder that come as standard, the Printer may be com-
bined with three 250-sheet paper feeders (PF-65; hereafter, paper feeder) to enable 5-way pickup,
each source with different types of paper.
3. Continuous printing of large volumes of work
As many as three option paper feeders may be installed to the Printer. Combined with the stand-
ard cassette and multifeeder, a maximum of about 1,100 sheets of paper (64 g/m2) may be accom-
modated for continuous, large-volume printing work.
4. Power saving, toner saving design
The printer is designed to enter sleep mode (power saving mode) after remaining in standby mode
for a specific period of time, thereupon automatically cutting the power to the fixing heater and
ultimately limiting the total consumption of power.
The printer is also able to print in toner save mode, in which it prints using less toner (lighter
output) to save on toner.
5. Auto interface switching mechanism
In addition to the parallel interface (Centronics compatible) and USB (V1.0 slave only) that come
as standard, the printer allows the connection of a build-in print server (option; 10Base-T/100Base-
TX). Depending on which interface board to use, the Printer will automatically switch among
parallel, USB, and Ethernet (option) interfaces.
6. Auto emulation switching
This printer supports the Hewlett-Packard’fs PCL5e and PCL-XL printer language. Also, Adobe
PostScript 3 can be provided by installing the optional Canon Adobe PostScript 3 Module A-65.
This enables auto emulation switching for PCL and PostScript based on the received data.

CHAPTER 1
1 - 2
II. SPECIFICATIONS
A. Printer
1. Printer engine
1) Type Desktop page printer
2) Printing method Electrophotostatic
3) Printing speed (Note 1) 20 pages/min (A4, horizontal), 11 pages/ min (A3)
4) First print time (Note 2) 11.0 sec (approx.; A4, horizontal)
5) Wait time (Note 3) 30 sec or less
6) Resolution
Main scanning direction 600 dpi
Sub scanning direction 600 dpi
7) Image formation system
Laser Semiconductor laser
Scanning method 6-face mirror
Photosensitive drum OPC (30-mm dia.)
Charging Roller charging
Exposure Laser scanning
Toner Magnetic, 1-component, dry
Development 1-component toner projection
Toner supply Cartridge replacement
(EP-65; good for about 10,000 A4 pages, dot ratio at 4% and print
ratio at 5%)
Transfer Roller transfer
Separation Curvature separation
Cleaning Rubber blade
Fixing Heat roller fixing
8) Pickup Multifeeder tray
Cassette
Paper feeder (option)
Paper type Plain paper, thick paper, colored paper, label sheet, recycled paper,
transparency film, envelopes
Paper size
Multifeeder tray Plain paper (64 g/m2to 90 g/m2, recommended) or thick paper (91
g/m2to 157 g/m2, recommended) or label sheets of following dimen-
sions: 76.2 (W) x 98 (L) to 297 (W) x 431.8 (L) mm
Cassette Plain paper (64 g/m2to 90 g/m2, recommended) of following sizes:
B3, B4, A4, A4R (vertical), B5, A5, 11 x 17, LGL, LTR, Executive;
label sheets
Stack multifeeder 10 mm high (about 100 sheets of 64 g/m2paper)
Cassette 25 mm deep (about 250 sheets of 64 g/m2paper)
Cassette type Universal cassette designed for following: A3, B4, A4, A4R (vertical),
B5, A5, 11 x 17, LGL, LTR, Executive
9) Delivery Face-down (250 sheets max. of 64 g/m2paper)
10) Operating environment
Temperature 7.5 to 32.5ºC (45.5 to 90.5ºF)
Humidity 5% to 90% RH
Atmospheric pressure 746 to 1013 hPa (560 to 760 mmHg)
11) Power consumption Sleep mode: 16 W (avr)
(at 20ºC room temp, In standby: 118 W (avr)
at rated supply voltage) In printing: 448 W (avr)
Maximum: 850 W or less

1 - 3
CHAPTER 1
12) Noise (published noise Sound power level 67 dB or less (printing)
by ISO9296) 57 dB or less (standby)
Sound pressure level 53 dB or less (printing)
(bystander position) 38 dB or less (standby)
13) Dimensions 488 (W) x 455 (D) x 311 (H) mm/18.9 (W) x 17.7 (D) x 12.2 (H) in. (w/
o options)
14) Weight 15 kg/33 lb (approx.; including 250-sheet cassette), 2 kg/4 lb
(approx.; cartridge)
15) Power supply 120 to 127 V, 220 to 240 V 50/60 Hz
16) Options Paper Feeder Unit PF-65 (3 units max.)
Universal Cassette UC-65
Hard Disk HD-65
Ether Board EB-65
Notes: 1. Based on test prints made at 20ºC room temperature with the rated supply voltage.
May be longer depending on the type of paper and the fixing mode selected.
2. Time required (room temperature at 20ºC and printer in standby) from when the print
signal arrives form the video controller to when a single A4 sheet is received and deliv-
ered to the delivery tray. May be longer depending on the type of paper and the fixing
mode selected.
3. At 20ºC room temperature, without an expansion RAM.
The above specifications are subject to change for product improvements.
2. Video Controller
1) CPU Power PC 405 (200 MHz)
2) Memory (RAM) 8 MB (built-in; may be expanded to 72 MB max. with option)
3) Memory (ROM) 8 MB (build-in; may be expanded to 16 MB max. with option)
4) RAM slot 1
5) ROM slot 3
6) Host interface
Standard • Centronics (IEEE1284 compatible)
• USB (V1.0 slave only)
Option • 10Base-T/100Base-TX
7) Translator
Standard PCL5e, PCL-XL
Option Adobe PostScript Level 3 Module A-65
8) Resident font 45 scalable fonts (MicroType fonts), 32 TrueType fonts, 9 Bitmap
fonts
9) Optional font 136 fonts for A-65 module
10) Scaler UFST
11) Option Flash ROM Module FR-65 (4MB: for fonts and macros storage)
The above specifications are subject to change for product improvements.

CHAPTER 1
1 - 4
B. Options
1. Built-in print server
a. Hardware
1) Interface 10Base-T, 100Base-TX
2) CPU AXIS: EXTRAX100LX (32-bit RISC CPU 100 MHz)
3) ROM 2 MB
4) RAM 4 MB
5) Dimensions 100 (W) x 85.5 (D) x 24 (H) mm/3.9 (W) x 3.1 (D) x 0.8 (H) in.
6) Weight 100 g/0.2 lb (approx.)
7) Power supply 3.3 VDC (from printer)
b. Software
1) Protocol IPX/SPX, TCP/IP, AppleTalk (EtherTalk), NetBEUI/NetBIOS
2) Frame type IPX/SPX : 802.2, 802.3, Ethernet II, 802.2 Snap
TCP/IP : Ethernet II
AppleTalk : 802.2 SNAP (Phase II)
NetBEUI/NetBIOS : 802.2
5) Print application IPX/SPX : Bindery Server, NDS PServer, NPritner, RPrinter
TCP/IP : LPD, FTP, RAW, IPP
AppleTalk : CAP (Canon AppleTalk PrintServer)
The above specifications are subject to change for product improvements.
2. Paper feeder
1) Pickup paper size A3, B4, A4, A4R (vertical), B5, A5, 11 x 17, LGL, LTR, Executive
(plain paper; 64 g/m2to 90 g/m2, recommended)
2) Cassette size 25 mm deep (about 250 sheets of 64 g/m2paper)
3) Cassette type Universal (may be configured for following: A3, B4, A4, A4R (verti-
cal), B5, A5, 11 x 17, LGL, LTR, Executive
4) Dimensions 488 (W) x 406 (D) x 118 (H) mm/18.9 (W) x 15.7 (D) x 4.7 (H) in.
5) Weight 5 kg/11 lb (approx., including cassette)
6) Power supply 24 VDC, 5 VDC (from printer)
The above specifications are subject to change for product improvement.
3. Hard disk
1) Memory 10 GB
2) Interface ATA-3
3) Dimensions 112 (W) x 136 (D) x 28 (H) mm/4.3 (W) x 5.1 (D) x 1.1 (H) in.
4) Power supply 5 VDC (from printer)
The above specifications are subject to change for product improvements.

1 - 5
CHAPTER 1
III. SAFETY
A. Safety of the Laser Unit
Although invisible, laser light is used inside the laser/scanner unit. Do not disassemble the laser/
scanner unit, as exposure to laser light can damage your eyes.
The Printer’s laser/scanner unit is not designed for adjustment in the filed. The following shows
the label attached to the cover of the laser/scanner unit.
Figure 1-3-1
B. Safety of Toner
Toner is a non-toxic material composed of plastic and small amounts of colorings. If your skin or
clothes came into contact with toner, remove as much of it as possible using dry tissues; then,
rinse with cold water. (Do not use warm water. The toner will turn into jelly, and will not come off.)
Do not bring toner into contact with vinyl material. They tend to react with each other.
C. Safety of Ozone
The Printer’s charging roller generates a minute amount of ozone gas (O3) because of corona
discharge (only when the Printer is in operation).
The Underwriters’ Laboratory (UL) provides standards for amounts of ozone discharge, and the
Printer is verified to satisfy the requirements at time of shipment from the factory.

CHAPTER 1
1 - 6
IV. NAMES OF PARTS
A. External View
1. Printer engine
• Front of the printer
[
8]
[
7]
[
6]
[
5]
[
4]
[
3]
[
2]
[
1]
Figure 1-4-1
• Rear of the printer
[10]
[9]
[8]
[6] [4]
[1]
[2]
[3]
[5]
[7]
Figure 1-4-2
1: Delivery tray
2: Front cover
3: Open/close lever
4: Multifeeder tray
5: Paper guide
6: Cassette
7: Power supply switch
8: Control panel
1: Expansion board slot cover
2: Expansion board slot 1
3: Expansion board slot 2
4: Power receptacle
5: Test Print switch
6: Test Print switch
7: Leading edge margin adjusting volume
(VR101)
8: USB interface connector
9: Parallel interface connector
10: Slot cover

1 - 7
CHAPTER 1
• Behind the front cover
[4]
[3]
[1]
[2]
Figure 1-4-3
1: Static eliminating brush
2: Transfer charging roller
3: Toner cartridge guide
4: Registration roller
2. Paper feeder
[2]
[3]
[1]
Figure 1-4-4
1: Connector
2: Positioning pin
3: Cassette

CHAPTER 1
1 - 8
B. Cross Section
1. Printer engine
[4][3][2][1] [5] [6] [7] [9][8]
[12][13][14] [11] [10][19] [15][17] [16][18]
Figure 1-4-5
1: Registration roller
2: Transfer charging roller
3: Fixing assembly
4: Pressure roller
5: Fixing roller
6: Delivery roller
7: Fixing heater
8: Control panel
9: Laser/scanner unit
10: Cassette
11: Cartridge
12: Primary charging roller
13: Photosensitive drum
14: Developing cylinder
15: Cassette pickup roller
16: Cassette separation pad
17: Manual feed separation pad
18: Manual feed pickup roller
19: Multifeeder tray
2. Paper feeder
[1] [2] [3] [4]
Figure 1-4-6
1: Feeding roller
2: Cassette pickup roller
3: Cassette separation pad
4: Cassette

1 - 9
CHAPTER 1
V. INSTALLATION
A. Points to Note About Installation
The Printer is thoroughly adjusted and inspected at the factory before it is packed and shipped.
Installation work is important in that the Printer must perform in the field as it did when it passed
the factory inspection.
The service engineer must have a full understanding of the machine, and install it in an appro-
priate site using specific steps, following up the work with a thorough inspection.
B. Selecting the Site
The site of installation must meet the following requirements; if possible, visit the site of installa-
tion before the Printer is delivered.
1. Power supply
The power supply must satisfy the following:
• AC: ±10% of ratings
• Frequency: 50/60 ±2 Hz
2. Operating environment
The site must satisfy the following:
• Its floor must be level.
• Its temperature and humidity are as follows:
Ambient temperature: 7.5ºC to 32.5ºC (45.5 to 90.5ºF)
Ambient humidity: 5% to 90% RH (There must not be condensation.)
• It must be well ventilated, without accumulation of heat.
Avoid the following areas:
• subject to direct rays of the sun; as necessary, provide thick curtains to block out the sun.
• subject to magnetism (magnet, magnetic filed).
• subject to vibration.
• subject to dust.
• near a source of fire or water.

CHAPTER 1
1 - 10
3. Spatial requirements
Allow an appropriate distance from all walls, thus ensuring unobstructed work space. (Figure 1-5-
1) If the Printer is to be installed on a table, be sure that the table is wide enough to accommodate
the Printer’s feet (rubber pads) and strong enough to withstand the Printer’s weight.
338
440
325
(mm)
434249
1300
123
(mm)
488
100
106
312
620
720
(mm)
260
27790 67
90 84
436 408 5131
16 36
(mm)
Dimensions Around
the Printer (standard)
Locations of the Feet View form the side
(with 3 paper feeders)
View from the Side (standard)
(Each rubber foot is
5 mm in height, and its tip is
a square of 18 x 18 mm.)
200
Figure 1-5-1

1 - 11
CHAPTER 1
C. Unpacking and Installing
When a piece of metal is brought in from a cold to warm place, droplets of water can develop on its
surface. This phenomenon is known as condensation, and the use of an LBP suffering from con-
densation can cause various printing faults.
If the Printer has been brought in from a cold place, leave it alone for at least one hour before
unpacking it.
1. Unpacking the printer
1) Unpack the Printer.
2) Check to make sure that none of the following is missing:
1. power cord
2. toner cartridge
3. dust cover
4. CD-ROM
5. documentation
3) Remove the plastic bag used to cover the Printer, and check to make sure that the covers and
the like are free of image and deformation from transportation.
4) Slide out the cassette, and move the Printer to the site of installation.
5) Place the Printer at the site of installation. (Take care.)
• If the Printer is to be laid on a paper feeder, be sure that the position pins on the paper feeder
fit into the openings in the Printer’s bottom.
6) Remove the tape used to keep the parts in place.
7) Open the multifeeder tray, and pull the open/close lever to the front to slide out the front
cover.
8) Remove the protective tape used to keep the transfer charging roller in place.
9) Lock the open/close lever, and close the front cover and the multifeeder tray.
10) Slide in the cassette.
2. Unpacking and installing the cartridge
1) Open the bag used to pack the cartridge, and take out the cartridge.
2) Holding the cartridge as shown in Figure 1-5-13, shake it gently up and down about 5 to 6
times so that the toner inside it will be even.
3) Place the cartridge on a level surface. While holding the top of the cartridge with one hand, pull
the tab carefully with the other hand; then, pull straight out the sealing tape.
4) Open the multifeeder tray, and pull the open/close lever to the front to draw out the front
cover.
5) Holding the cartridge with both hands, fit it in the Printer. At this time, be sure to slide in the
cartridge carefully until it butts against the rear of the Printer.

CHAPTER 1
1 - 12
3. Unpacking and installing the hard disk
Note: Before handling the hard disk, be sure to touch a metal area of the Printer to avoid dam-
aging the PCBs by static charges.
1) Turn off the Printer, and disconnect the power cord and the interface cable.
2) Take out the hard disk from its packaging box.
3) Remove the vinyl bag used to cover the hard disk.
4) Remove the screw [1], and detach the expansion board slot cover [2].
[2]
[1]
Figure 1-5-2
5) Remove the screw [3], and detach the expansion board slot 1 cover [4].
[3]
[4]
Figure 1-5-3

1 - 13
CHAPTER 1
6) Holding the metal cover area [5] of the hard disk, slide in the hard disk along the guide rail.
[5]
Figure 1-5-4
7) Secure the top and bottom of the hard disk with the 2 screws [6] that come with the hard disk.
[6]
Figure 1-5-5
8) Attach the expansion board slot cover and the power cord.
9) Connect the Printer’s power cord to the power outlet.

CHAPTER 1
1 - 14
4. Unpacking and installing the built-in print server (Ether Board EB-65)
Caution: If possible, wear a wrist strap designed to prevent damage by static charges. The static
charges in your body can damage the electric mechanisms when you install the built-in
print server to the Printer.
Take particular care not to touch the parts in electric circuits.
1) Unpack the print server.
2) Take out the print sever from its packaging box.
3) Remove the vinyl bag used to cover the print server.
4) Remove the screw [1], and detach the expansion board slot cover [2].
[2]
[1]
Figure 1-5-6
5) Remove the screw [3], and detach the expansion board slot 2 cover [4].
[4]
[3]
Figure 1-5-7
