Ricoh SG 7100DN User manual

v20140514
DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER.
DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES.
DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO ALLOW
THE RICOH AUTOMATIC MAINTENANCE UTILITIES TO KEEP THE PRINT HEAD NOZZLES CLEAR.
CAUTION
INsTALLATION GUIDE
PowerDriver V4
Windows 7 & 8
Ricoh SG 7100DN

SECTIONS:
There are two steps required to complete the installation
and conguration process for the SubliJet-R PowerDriver
V4 to work with the Ricoh SG7100DN printer. Complete
both as described below for optimum results.
* Step 1 is included in this document. Steps 2 and 3 are located on the Sublijet-R SG7100DN
PowerDriver V4 Installation and Conguration webpage on sawgrassink.com and can be accessed
by the link provided above.
Steps:
1) Download, install and register the SubliJet-R PowerDriver V4
2) Congure your design software* (i.e. CorelDRAW, PhotoShop, Illustrator, etc.)
3) Using the Sawgrass color palette*
Page 1
*
Notes:
a) PowerDriver V4 is only compatible with Windows versions 7 and 8.
b) The Ricoh OEM printer driver is now automatically installed.
*

Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 1 of 15 >>
1) Locate the Sawgrass Technologies website by entering sawgrassink.com in the address eld of your
web browser. Once there, hold the mouse arrow over Technical Support in the menu bar. From
the drop down list that appears select SubliJet-R, Ricoh SG 7100DN then Windows 7 and 8 (see
FIGURE 1).
FIGURE 1
B
A
CD
2) Click on the Installation & Conguration Instructions button (see FIGURE 2).
FIGURE 2
The following instructions explain how to download, install and register the SubliJet-R SG 7100DN
PowerDriver V4 on a computer running Windows 7. These instructions feature Internet Explorer 10.
Your experience may differ based on the operating system and internet browser being used.

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 2 of 15 >>
3) Once on the appropriate Installation and Conguration Instructions webpage for your setup, click on the
link in Step 3, Download and install the Ricoh Driver and Sawgrass PowerDriver V4 (see FIGURE 3).
FIGURE 3
4) On the webpage that appears, click the link for the Ricoh SG 7100DN in the PowerDriver section
(see FIGURE 4).
FIGURE 4
Note: At anytime during the download and installation process, your rewall or virus protection
software may present warnings. Make the appropriate selections necessary to continue.

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 3 of 15 >>
5) The following window will appear asking if you want to Run, Save or Cancel. Click Save (see FIGURE 5).
FIGURE 5
6) The le will begin downloading into the Downloads folder on your computer. When complete, the
download message at the bottom of the screen will give you the option to Run, Open or View
downloads. Click Run (see FIGURE 6).
FIGURE 6
Placeholder Images
Placeholder Images
Placeholder Images
Placeholder Images
Do you want to run or save SJR_7100_US_v1.0a27.exe (13.7MB) from sawgrassles.bluekeyinc.com?
The SJR_7100_US_v1.0a27.exe download has completed.

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 4 of 15 >>
7) Select the appropriate language and click OK to continue (see FIGURE 7).
FIGURE 7
A
B
8) Verify that the PowerDriver is for the correct printer. If so, click Next (see FIGURE 8).
FIGURE 8

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 5 of 15 >>
9) If you agree with the terms of the License Agreement, click I Agree (see FIGURE 9).
FIGURE 9
10) Click Install to allow PowerDriver to be installed into the correct destination folder (see FIGURE 10).
FIGURE 10

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 6 of 15 >>
11) If the appropriate Ricoh OEM printer driver is not currently installed, it will begin to download. The
following status screen will be displayed during this process (see FIGURE 11).
FIGURE 11
FIGURE 12
12) Once the download has complete the Ricoh OEM driver will be installed.You will need to accept the
Software License Agreement for installation to continue. If you agree with the terms select I accept the
agreement and click Next (see FIGURE 12).
A
B
Note: If the appropriate OEM printer driver is already installed and what is displayed in Figure 11 does
not appear, skip to step 22.

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 7 of 15 >>
13) Select Add a new printer and click Next (see FIGURE 13).
FIGURE 13
A
B
14) Select how the printer is connected to your computer and click Next (see FIGURE 14). For this example
we will select Connect USB cable.
FIGURE 14
A
B

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 8 of 15 >>
15) The following screen will appear asking you to select your printer (see FIGURE 15). Highlight RICOH
AcioSG7100DN RPCS-R and click Next.
FIGURE 15 B
A
16) Ensure your printer is powered OFF and click Next to continue (see FIGURE 16).
FIGURE 16

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 9 of 15 >>
17) Once the les are nished copying, ensure your printer is powered ON and the computer will begin auto-
detecting the port (see FIGURE 17).
FIGURE 17
18) In the following screen you are asked to customize the Status Monitor (see FIGURE 18). Adjust the
settings according to your preferences and click Next to continue.
FIGURE 18

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 10 of 15 >>
19) Click Set Now to continue (see FIGURE 19)
FIGURE 19
20) Click OK to continue (see FIGURE 20).
FIGURE 20

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 11 of 15 >>
21) Select No, restart later. Click Finish to continue PowerDriver installation (see FIGURE 21).
FIGURE 21
22) The following screen may or may not appear. If it does, you will need to accept the software license
terms for the installation to continue. If you agree with the terms select I agree to the license terms
and conditions and click Install. If it does not appear, continue to step #24 (see FIGURE 22).
FIGURE 22
B
A
B
A

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 12 of 15 >>
23) Once this portion of the installation is complete the following screen will appear. Click Close to continue
(see FIGURE 23).
FIGURE 23
24) Click Yes when prompted to Register the PowerDriver. A separate Registration window will appear
(see FIGURE 24).
FIGURE 24

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 13 of 15 >>
25) Take note of the Product ID number, it will be needed to register your software. Click the Obtain
Registration Code button (see FIGURE 25).
FIGURE 25
26) On the Product Registration web page that automatically opens, ll in the required information and click
Submit when complete. A registration code will be sent to the email address entered on that form
(see FIGURE 26).
FIGURE 26
B
A

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 14 of 15 >>
27) When the email with the Registration Code is received, enter it into the Registration Code text box and
click Apply Registration Code (see FIGURE 27).
FIGURE 27
A
B
28) The message pictured below, conrming that registration was successful, will appear. Click OK to
continue (see FIGURE 28).
FIGURE 28
Note: If you have difficulties with registering online, note the Product ID described in step 25 above
and call 843-884-1575, Option 1 or email [e-mail]. Registration codes via phone
or email are provided 8:00 am – 5:00 pm EST, Monday – Friday. Also, separate registration codes are
required for every machine on which the PowerDriver is installed.

SubliJet-R: Ricoh SG 7100DN – Installation Guide
Step 1 of 2: PowerDriver V4 Download & Installation
PAGE 15 of 15 >>
29) The following screen conrming that the driver settings have been initialized will appear. Click OK to
continue (see FIGURE 29).
FIGURE 29
30) You must restart your computer to complete the installation. Save and close any work that may be open
and click Finish (see FIGURE 30).
FIGURE 30
1 of the 2 steps of the installation and conguration process are now complete. It is very important to complete the
last step, Congure your design software on the Installation and Conguration webpage.
For the absolute latest information and updates on all products, materials, processes and/or
procedures relative to all offerings by or through Sawgrass Technologies, Inc., refer to our website:
www.sawgrassink.com
