MAKE FLEXIBILITY YOUR MIDDLE NAME
1.5X
THE ZOOM LEADER AMONG
ULTRA-PORTABLES
www.canonprojectors.com
The bigger the zoom, the more room you
have to work with. Canon’s exclusive
1.5X zoom lens gives you an extensive
range of flexibility, making placement
easy in any size room. At the wide
setting, you can project a large 100-
inch image from as little as 10.4 feet
away.
Wide Projection Range
The LV-5200 features a DVI-I interface
for either digital or analog RGB input,
allowing you to hook up two laptop
computers at the same time. It also
offers component, S-Video, and RCA
terminals, giving you the freedom to
connect to virtually any electronic
device.
Bright, Crisp Projection
Keep your audience focused on the
picture, not the projector. The LV-5200
features a special Silent Mode that
reduces fan noise to a quiet 34 decibels.
Perfect for showing movies at home or
delivering a presentation in a small
conference room.
Project data or video at a bright 1,700
ANSI lumens. Crisp Native SVGA resolu-
tion (800 x 600 pixels) is supplemented
by XGA resolution (1,024 x 768) by using
advanced, high-quality compression.
Quiet OperationSuperior Connectivity
Serious about features? So is Canon's compact LV-5200 projector. Featuring 1.5X motorized zoom, the most powerful in its class,
exceptional brightness, and expert connectivity, it delivers unbeatable results wherever you plug it in.
And thanks to its ultra-quiet operation, your audience will be treated to a one-of-a-kind projection experience.

KNOW HOW
TM
1-800-OK-CANON www.canonprojectors.com
© 2002 Canon USA, Inc.YT2-1306 1202SZ10 PRINTED IN JAPAN
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042, U.S.A.
Canon Canada Inc.
6390 Dixie Road
Mississauga,
Ontario L5T 1P7, Canada
Canon Mexicana, S. DE R.L. DE C.V.
Periférico Sur No. 4124, 5º y 6º pisos,
Col. Ex-Rancho de Anzaldo,
01900 México, D.F.
Canon Latin America
703 Waterford Way Suite 400
Miami, FL 33126, U.S.A.
User-friendly Features
Just plug in your device, and the LV-5200
automatically adjusts itself to the incoming
signal. A handy remote control provides
easy access to functions such as digital
zoom, image freeze, gamma adjustment,
and more.
Flexible Image Adjustment
Get sharper data projection using the Hi-
Contrast Mode, or crisper video with the
Cinema Mode. What's more, Auto
Grayscale creates sharper black & white
images, while Auto Fleshtone makes
portraits look livelier. Customizable settings
are also included.
Superior Optical Technology
In addition to its state-of-the-art zoom
range, the Canon LV-5200's projection lens
has other important strengths. Its short
throw distance is ideal for small rooms—
100-inch projection, for example, starts at
only 10.4 feet. Also, Canon's renowned
lens expertise ensures low image distortion
and enhanced color fidelity.
▼
Unbelievable Versatility
Unlike other projectors in its price range,
the LV-5200 offers more than just wide
device compatibility—it gives you more
options. Digital or analog RGB input can be
fed into the DVI-I terminal, and the RGB
Analog (VGA) terminal can be switched to
handle input or output.
Monitor
Configuration 1
Configuration 2
Desktop PC
Laptop 1
Also connect: DVD players • VCRs • Digital cameras • Digital camcorders
Analog OUT
Analog IN DVI-I
DVI-I
Laptop 2 Visualizer
Great for Classrooms, Living Rooms and Offices!
LV-5200 Kit Contents
Projector • Wireless remote control (AA
alkaline batteries included) • VGA
computer cable • DVI/VGA adapter •
Mouse control cable for PS/2 • Lens
cap • Soft carrying case • Power cable •
Warranty card • User's manual
Distortion-free Images
When the LV-5200 is slightly tilted from the
screen, you can keep your images
perfectly proportioned by applying the
projector's Keystone Correction.
LV-5200
All specifications are subject to change without notice.
Canon is a registered trademark of Canon, Inc.
Top Control
Panel
Audio Output
Jack R
Audio Output
Jack L
Reset Button
Control
Port
Connector
USB Port
Keystone
Button
Warning
Temp
Indicator
Lamp
Indicator
Ready
Indicator
Lamp
Replace
Indicator
Focus
Button
Video Input
Jack Pr/Cr
Video Input
Jack Y
Audio Input
Jack L
Adjustable Feet
and Feet Lock
Latches
Projection Lens
Infrared
Remote
Receiver
Audio Input
Jack R
RGB Input
Digital/Analog
Computer
Audio
Input Jack
S-video Input
Jack
RGB Analog
Input/Output
Menu Button
Input Button
Zoom Button
Image Button
Set Button
Video Input
Jack Pb/Cb
Specifications
Type: Ultra-portable LCD projector
LCD Panel:
0.8" polysilicon active matrix TFT x 3. 4:3 aspect ratio
Number of Pixels: 1,400,000 800(H) x 600(V)
Supported Display Standards: Native SVGA, XGA (Compression),
VGA
Light Source: 180W UHP lamp
Brightness: 1,700 ANSI lumens
Uniformity: 85% (corner to center)
Contrast Ratio: 400:1
Horizontal Resolution: 500 TV lines
Projection Lens: 25.7 to 37.9 mm, F1.7 to 2.44, 1.5X zoom
Lens Shifting: 26:1
Elevation Adjustment: Up by 15.6°(One-touch adjustment)
Projected Image Size (Projection Distance): WIDE mode: 36"
(3.6 ft.), 100" (10.4 ft.), 150" (15.7 ft.), 200" (21.1 ft.), 300"
(31.8 ft.) TELE mode: 24" (3.6 ft.), 36" (5.4 ft.), 100" (15.6 ft.),
150" (23.5 ft.), 200" (31.4 ft.)
Digital Keystone Distortion Compensation Angle: ±20°
Noise: 36 dBA (Normal), 34 dBA (Silent)
Color System: NTSC/PAL/SECAM/NTSC 4.43/PAL-M/PAL-N
Supported Computers: IBM PC compatible, Macintosh, PC98,
workstation (Some workstations are not supported.)
Scanning Frequency: 15 to 80kHz for horizontal sync., 50 to
100Hz for vertical sync., 100MHz for dot clock
Audio Output: 1W monaural
Built-in Speaker: 1.6 x 1.2 in., x 1
Rated Supply Voltage: 100 to 120/200 to 240V AC, 50/60Hz
Power Consumption: 260W
Ambient Operation Temperature: 41 to 95˚F (5 to 35°C)
Storage Temperature: 14 to 140˚F (-10 to 60°C)
Dimensions (W x H x D):
13.1 x 3.5 x 9.6 in./331.5 x 89.5 x 244.1
mm excluding legs. (Legs: 0.5 in./11.5 mm)
Weight of Main Unit: Approx. 9.46 lbs. (4.3 kg)
Nomenclature
Power On-Off
Button
