DIGITAL MICROFILM SCANNER

Start with a wide-scree microfilm
sca er capable of ha dli g every-
thi g from checks to bluepri ts to
ewspapers, a d more. But make it
compact e ough to fit o a y desktop.
The raise the bar by pushi g output
resolutio up to 600 dpi. Now add
Hi-Speed USB 2.0 i terface a d you
get a desig made for fast a d simple
operatio , great versatility, easy co -
ectivity, a d rapid throughput. While
you’re at it, make it affordable, too.
Now, what do you call this perfect
solutio to your ever-expa di g work-
group eeds? Ca o calls it the
MS-800II.
THE DESKTOP DIGITAL MICROFILM SCANNER
THAT DRAMATICALLY CHANGES THE IMAGE
OF FILM SCANNING.
Quality right own to the
smallest etail.
With up to 600-dpi resolution, the MS-800II sets high
standards for image quality. Such quality resolution offers
a wide range of enhanced printing and distribution capa-
bilities, including laser printing and electronic image
transmission. Ideal for financial institutions, the MS-800II
brings greater efficiency to item processing. And it’ s an
expert at meeting the demands of engineering
applications which require large-format printing. The MS-
800II further refines image quality with multiple scanning
modes (Fine, Photo, Grayscale), plus Background Erasure
and Automatic Exposure. The result is enhanced image
data for a variety
of applications.
Compatibility with virtually any
film format.
Interchangeable film carriers enable the MS-800II to
handle all types of microfilm applications. Compatible with
16mm/35mm open reels, 16mm cartridges, microfiche,
and aperture cards, the MS-800II provides totally
seamless support for every format.
Pro uctivity soars for even the
busiest workgroups.
Overall performance gets a boost from the high-speed
MS-800II. Requiring only about three seconds per image
to scan letter-sized documents at standard dpi settings,
the MS-800II excels at high-volume processing and media
conversion. Even its built-in features accelerate perfor-
mance—Automatic Size Detection, Automatic Negative/Pos-
itive Detection, and Automatic Skew Correction—all
designed to make short work out of complex jobs. For
high-volume batch processing, the MS-800II shifts into
high gear. When paired with Canon’ s FS Controller III, the
MS-800II delivers super-fast, automated image retrieval.
Microfilm Scanner 800II with
Remote eyboard and Fileprint 470

Connectivity that simplifies every
scanning function.
Included with the MS-800II is Canon’ s Scanning Utility
800, a robust driver compatible with Windows®98SE/
ME/XP/NT®4.0. Offering four file formats—TIFF, BMP,
JPEG, and JBIG—it gives users an intuitive, easy-to-use
interface for controlling scanner settings. With the Scan-
ning Utility 800 and Canon CapturePerfect 1.0 you can
turn your PC into a scanning control center —to imprint
information on image data, or send scanned images
directly to an on-line laser printer, without storing the
images first. You’ ll even be able to send images elec-
tronically via fax, e-mail, the Internet, or intranet.
Versatility means more opportunities to
enhance the way your business works.
Designed to work with the systems you have in place
now, the MS-800II is also engineered to expand with
any future configurations. Combined with the optional
Canon Fileprint 470 laser printer, the MS-800II becomes
a complete Digital Microprinter System, producing laser-
quality prints—up to ledger size—without requiring a PC
connection. Set in the special Overlay Mode, the MS-800II
will scan both sides of items, such as checks, then auto-
matically reposition the images into a single, portrait-
oriented data file.
Convenience is having easy-to-use
controls right at han ...
Complementing the easy-to-read, ledger-sized screen is
a user-friendly control panel with many time-saving,
one-touch features, including Autofocus, Memory Zoom
and Image Rotation. Plus, Border Erasure makes clean
printouts from negative film and an optional Framing it
allows you to designate a portion of a document for
scanning. There are also six one-touch Function eys
for storing frequently used control panel settings.
...or right at your workstation.
The MS-800II even has an optional Remote eyboard,
providing quick access to all primary controls on an
independent keypad. Great for busy operators, it’ s an
easy way to maximize throughput ergonomically. It also
provides the convenience necessary for operators with
disabilities.
FICHE CARRIER 190-RII DEDICATED CARRIER
FOR MICROFICHE AND APERTURE CARDS
AUTOCARRIER 100M HIGH-SPEED CARRIER
WITH AUTO LOADING OF “M”-TYPE CARTRIDGES
AUTOCARRIER 100R RELIABLE SEMI-AUTO
LOADING OF 16/35MM OPEN REELS
FS CONTROLLER I/III FOR HIGH-SPEED,
INTELLIGENT IMAGE-RETRIE AL
ROLL/FICHE CARRIER 200 HANDLES FILM AND
MICROFICHE WITHOUT CHANGING CARRIERS
AUTOCARRIER 100C HIGH-SPEED CARRIER
WITH AUTO LOADING OF ANSI OR “M”-TYPE
CARTRIDGES

Microfilm Scanner 800II
Type: Desktop Digital Microfilm Reader/Scanner
Film Formats: Universal with Interchangeable Carriers
Film Types: Both Negative and Positive Images of Silver or Diazo
16mm/35mm Film, Aperture Cards, and Microfiche
Image Scanning
Resolution: Up to 600 dpi
Scan Modes: B/W, B/W Fine, B/W Photo,
Grayscale Up To 256 Levels*
Scan Sizes (U.S.): 11" x 17", 11" x 14", 8-1/2" x 11", 8-1/2" x 5-1/2"
Scan Positions: Center, Left, Two Consecutive Pages
Scan Speed: 3 Seconds 8-1/2" x 11"**
3.9 Seconds 11" x 17"**
Scan Select: Trimming, Auto Border Erasure, Margin Setting
Interface: SCSI-II and Video Printer I/F, Standard, Hi-Speed USB 2.0
Standard Features: Auto Focus with Manual Override
Automatic Exposure with Manual Override
Motorized Zoom Lens with Programmable Memory eys
Motorized Image Rotation with Auto Skew Correction and
Automatic 90°Rotation
Automatic Bimode Sensing with Manual Override (N-P/P-P)
Automatic Border Erasure
Automatic Centering
Scanner Drivers: ISIS®and Twain
Optics
Lens Magnifications: 7-7.5X, 9-16X, 14-30X, 20-50X, 57X
Screen Size (H x W ): 11-3/4" x 17''
Options: Interchangeable Carriers
Remote Operation eyboard
Framing it for Trimming Function
64MB RAM
Foot Switch (Scan/Print)
Workstation IV
Electrical Requirements: 120V AC, 60Hz, 4.5A
Dimensions (H x W x D): 24" x 30" x 24"
Weight: 104 lb.
Software Options: image.SCAN (for Public Use)
Bundled Software: Scanning Utility 800, CapturePerfect 1.0
**128MB RAM required.
**Examples based on ypical se ings a 200 dpi. Ac ual processing speeds
may vary based on PC performance and applica ion sof ware.
Scanning Utility 800
Scan Modes: B/W, B/W Fine, B/W Photo, Grayscale (4/16/256 Levels)
Resolution: 200 dpi/300 dpi/600 dpi
Settings: Brightness, Fine Brightness, Polarity, Batch Type,
Image Rotation, Detect Image Size, Add-on,
Margin Scanning, AE Adjustment, Sharpness, Erase
Background, Erase Notch, Complement Thin Line,
Gamma Setting, Function ey Setting
File Formats: Binary Images (B/W, Photo): TIFF/BMP/JBIG
Grayscale Images: JPEG/BMP/JBIG
Viewing Functions: Zoom In/Out, 90°Rotation, Best Fit, Fit to Width,
Next/Previous Page
Printing Functions: Print Screen Image, Print Scanned Image,
Digital Reader-Printer Mode
Fileprint 470
Type: Desktop Laser Printer
Item Code: 1514B002
Print Speed (LTR): 15 ppm on MS-800II
Resolution: 600 dpi
Stacker Capacity: 250 Sheets
Paper Size: Letter, Legal, 11 x 17
Dimensions (H x W x D): 10.9 " x 20.4 "x 17.3 "
Weight: 42.5 lb.
Power Consumption: Average 360W or Less
(Energy-Saving Mode:
36W or Less)
SPECIFICATIONS
