Caple CM130 User manual

Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Microwave & Grill
Instruction Manual
CM130

19
Please keep this instruction manual for future reference Instruction manual CM130
OPERATION INSTRUCTIONS
SETTING THE CLOCK:
When the microwave is first turned on, the screen will display “0:00”, a buzzer will ring once.
»Press “Kitchen Timer/Clock” twice to select clock function, the hour figures will flash.
»Turn “ “ to adjust the hour figures, the input item should be within 0-24hr.
»Press “Kitchen Timer/Clock” the minute figures will flash.
»Turn “ ” to adjust the minute figures, the input time should be within 0-59.
»Press “Kitchen Timer/Clock” to finish setting the clock. “:” will flash, and the time
will illuminate.
NOTE:
If the clock is not set, the oven will not function when powered.
During the process of setting the clock, if you press “Stop/Clear” the oven will go back to the
previous status automatically.
MICROWAVE COOKING:
Press “Micro/Grill/Combi” the LED will display “P100”. Press “Micro/Grill/Combi” repeatedly or
turn “ “ to choose the power you want, and “P100”, “P80” “P50”, “P30” or “P10” will
display for each added press. Then press ”Start/+30Sec/Confirm” to confirm, and turn “ “ to
set the cooking time from 0:05 to 95:00. Press ”Start/+30Sec/Confirm” again to start cooking.
Example:
If you want to use 80% microwave power to cook for 20 minutes, you can operate the oven using
the following steps.
»Press “Micro/Grill/Combi” once, the screen display “P100”.
»Press “Micro/Grill/Combi” once again or turn” “ to choose 80% microwave power.
»Press “Micro/Grill/Combi” to confirm, and the screen displays “P80”.
»Turn “ “ to adjust the cooking time until the oven displays “20:00”.
»Press “Start/+30Sec/Confirm” to start cooking.
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14

Instruction manual CM130
20 Please keep this instruction manual for future reference
NOTE:
When selecting a cooking duration, the timer will increase in the following quantities:
0 - 1 minute 5 seconds
1 - 5 minutes 10 seconds
5 - 10 minutes 30 seconds
10 - 30 minutes 1 minute
30 - 95 minutes 5 minutes
For example:
When selecting a cooking duration between 1- 5 minutes the timer will go up in 10
second increments.
“MICRO/GRILL/COMBI”
ORDER
PAD INSTRUCTIONS
DISPLAY
M I C R O WAV E
POWER
GRILL
POWER
1P100 100%
2P80 80%
3P50 50%
4P30 30%
5P10 10%
6 G 0% 100%
7C - 1 55% 45%
8C - 2 36% 64%

21
Please keep this instruction manual for future reference Instruction manual CM130
COMBINATION COOKING:
Press “Micro/Grill/Combi” the LED will display”P100” and press “Micro/Grill/Combi” a few times
or turn the “ “ to choose the power you want, and “P100, “P80” “P50” “P30”, “P10”
“G”,”C-1” or “C-2” will display for each added press. Press “Start/+30Sec/Confirm” to confirm
and turn “ “ to set cooking time from 0:05 to 95:00.
Press “Start/+30Sec/Confirm” again to start cooking.
Example:
If you want to use 55% microwave power and 45% grill power(C-1) to cook for 10 minutes, you
can operate the oven as the following steps.
»Press “Micro/Grill/Combi” once, the screen display “P100”.
»Press “Micro/Grill/Combi” a few times or turn “ “ to choose combi 1 mode.
»Press “Start/+30Sec/Confirm” to confirm, and the screen displays “C-1”.
»Turn “ “ to adjust the cooking time until the oven displays “10:00”.
»Press “Start/+30Sec/Confirm” to start cooking .
NOTE:
If half the grilling time passes and the oven sounds twice, this is normal. In order to have a better
effect when grilling food, you should turn the food over, close the door, and then press
”Start/ +30Sec./ Confirm” to continue cooking.
If there is no operation, the oven will continue cooking.
QUICK START:
»In standby mode, press “Start/+30Sec/Confirm” to start cooking with 100% power, each
added press will increase 30 seconds cooking time up to 95 minutes.
»In microwave, grill cooking or time defrost state, each press of “Start/+30Sec/Confirm” can
increase 30 seconds of cooking time.
»In standby mode, turn “ “ left to set cooking time with 100% microwave power, then
press “Start/+30Sec/Confirm” to start cooking.
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14

Instruction manual CM130
22 Please keep this instruction manual for future reference
DEFROST BY WEIGHT:
»Press “Weigh/Time/Defrost” once, and the oven will display “dEF1”.
»Turn “ “ to select the weight of food from 100 to 2000g.
»Press “Start/+30Sec/Confirm” to start defrosting.
DEFROST BY TIME:
»Press “Weigh/Time/Defrost” twice, and the oven will display “dEF2”.
»Turn “ “ to select the defrost time. The MAX time is 95 minutes.
»Press “Start/+30Sec/Confirm” to start defrosting. The defrost power is P30, this
cannot be changed.
KITCHEN TIMER:
»Press “Kitchen/Timer/Clock” once, LED will display 00:00.
»Turn “ “ to enter the correct timer. (The maximum cooking time is 95 minutes).
»Press “Start/+30Sec/Confirm” to confirm setting.
»When the kitchen time is reached, the clock indicator will go out and the buzzer will ring
5 times.
If the clock is set (24-hour system), the LED will display the current time.
NOTE:
The kitchen timer is different from the 24-hour system, the kitchen timer is a timer only.
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14

23
Please keep this instruction manual for future reference Instruction manual CM130
AUTO MENU:
»Turn “ “ right to choose the menu, and “A-1” to “A-8” will display, which means pizza,
meat, vegetable, pasta, potato, fish, beverage and popcorn.
»Press “Start/+30Sec/Confirm” to confirm.
»Turn “ “ to choose the default weight as the menu chart.
»Press “Start/+30Sec/Confirm” to start cooking.
Example:
If you want to use “Auto Menu” to cook 350g of fish.
»Turn “ “ clockwise till “A-6” display.\
»Press “Start/+30Sec/Confirm” to confirm.
»Turn “ “ to select the weight of fish till “350” display.
»Press “Start/+30Sec/Confirm” to start cooking.
The automatic Menu Chart:
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
MENU WEIGHT DISPLAY
A - 1
PIZZA
200g 200
400g 400
A-2
MEAT
250g 250
350g 350
450g 450
A - 3
VEGETABLES
200g 200
300g 300
400g 40-0
A-4
PASTA
50g (with 450ml cold water) 50
100g (with 800ml cold water) 100
A-5
POTATO
200g 200
400g 400
600g 600

Instruction manual CM130
24 Please keep this instruction manual for future reference
MENU WEIGHT DISPLAY
A - 6
FISH
250g 250
350g 350
450g 450
A - 7
BEVERAGE
1 cup (120ml) 1
2 cups (240ml) 2
3 cups (360ml) 3
A-8
POPCORN
50g 50
100g 100
MULTI STAGE COOKING:
Two cooking stages can be set. If one stage is defrosting, it should be put in the first stage. The
buzzer will ring once after each stage and the next stage will begin.
NOTE: Auto menu and preheating cannot be set as one of the multi stage options.
EXAMPLE:
If you want to defrost food for 5 minutes and then cook with 80% microwave power for 7
minutes, operate it as the following:
»Press “Weigh/Time/Defrost” twice, and the oven will display “dEF2”.
»Turn “ “ to select the defrost time till “5:00” display.
»Press “Micro/Grill/Combi” once, the screen display “P100”.
»Press “Micro/Grill/Combi” once again or turn “ “ to choose 80% microwave power.
»Press “Start/+30Sec/Confirm” to confirm, and the screen displays “P 80”.
»Turn “ “ to adjust the cooking time till the oven displays “7:00”.
»Press “Start/+30Sec/Confirm” to start cooking, the buzzer will sound once for the first section
and the defrosting time starts to count down. The buzzer will sound once again entering the
second section of cooking. When cooking finishes the buzzer sounds five times.
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1.
When the microwave oven is , the LED will display "0:00", buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting. ":" will flash, and the time will .
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, not function when powered.
2) ", the oven
During the process of setting, if you press "
will go back to the previous status automatically.
2.
Press " " the LED will display "P100".Press " "
times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14

25
Please keep this instruction manual for future reference Instruction manual CM130
INQUIRING FUNCTION:
»In microwave, grill and combination cooking state, press “Micro /Grill/Combi” the current
power will be displayed for 3 seconds. After 3 seconds, the oven will revert back to the
former state.
»In cooking state, press “Kitchen/Timer/Clock” to inquire the time and the time will display for
3 seconds.
CHILD SAFETY LOCK:
Lock: In standby state, press “Stop/Clear” for 3 seconds, there will be a “beep” denoting entering
the child lock sate. Will light and current time will display if the time has been set.
Otherwise the screen will display .
Unlock: In locked state, press “Stop/Clear” for 3 seconds, there will be a “beep” denoting that the
lock is released.
21
7) Press " " to start cooking, and buzzer will sound once for the
first section, defrosting time counts down. Buzzer will sound once again entering
the second cooking. hen cooking finish , buzzer sounds five times.
1) Press " " twice, and the oven will display "dEF2".
2) Turn " " to select the defrost time till "5:00" displays.
3) Press " " once, the screen displays "P100".
5) Press " " to confirm, and the screen displays "P 80".
6) Turn " " to adjust the cooking time till the oven displays "7:00".
4) Press " " once again or turn " " to choose 80%
10. Inquiring Function
(1) In states of microwave, grill and combination cooking, press " ",
the current power will be displayed for 3 seconds. After 3 seconds, the oven will turn
back to the former state.
(2) In cooking state, press " " to inquire the time and the time will
display for 3 seconds.
Lock: In waiting state, press " " for 3 seconds, there will be a long beep
denoting entering the childlock state. will light and current time will diplay
if the time has been set Otherwise,
: In locked state, press " " for 3 seconds, there will be a long
"beep" denoting that the lock is released.
9. Multi-section cooking
At most 2 sections can be set for cooking. In multi-section cooking, if one section is
defrosting, then defrosting shall be placed in the first section.
Example: If you want to defrost food for 5 minutes and then cook with 80% microwave
power for 7 minutes, operate it as the following:
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Stop/Clear
Weight/Time Defrost
microwave power.
Wes
.
Kitchen Timer/Clock
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
the screen will display .
21
7) Press " " to start cooking, and buzzer will sound once for the
first section, defrosting time counts down. Buzzer will sound once again entering
the second cooking. hen cooking finish , buzzer sounds five times.
1) Press " " twice, and the oven will display "dEF2".
2) Turn " " to select the defrost time till "5:00" displays.
3) Press " " once, the screen displays "P100".
5) Press " " to confirm, and the screen displays "P 80".
6) Turn " " to adjust the cooking time till the oven displays "7:00".
4) Press " " once again or turn " " to choose 80%
10. Inquiring Function
(1) In states of microwave, grill and combination cooking, press " ",
the current power will be displayed for 3 seconds. After 3 seconds, the oven will turn
back to the former state.
(2) In cooking state, press " " to inquire the time and the time will
display for 3 seconds.
Lock: In waiting state, press " " for 3 seconds, there will be a long beep
denoting entering the childlock state. will light and current time will diplay
if the time has been set Otherwise,
: In locked state, press " " for 3 seconds, there will be a long
"beep" denoting that the lock is released.
9. Multi-section cooking
At most 2 sections can be set for cooking. In multi-section cooking, if one section is
defrosting, then defrosting shall be placed in the first section.
Example: If you want to defrost food for 5 minutes and then cook with 80% microwave
power for 7 minutes, operate it as the following:
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Stop/Clear
Weight/Time Defrost
microwave power.
Wes
.
Kitchen Timer/Clock
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
the screen will display .

Instruction manual CM130
26 Please keep this instruction manual for future reference
NORMAL
Microwave oven interring with
TV reception.
Radio and TV reception may be interfered when microwave oven operating. It is
similar to the interference of small electrical appliances like, mixer, vacuum, cleaner
and electric fan. It is normal.
Dim oven light. In low power microwave cooking, oven light may become dim. It is normal .
Steam accumulating on door,
hot air out of vents.
In cooking, steam may come out of food, most will get out form vents but some
may accumulate on a cool place such as the oven door. It is normal.
Oven started accidentally with
no food in.
You must not run the unit without any food inside. It is very dangerous.
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE REMEDY
Oven can not be started.
1. Power cord not
plugged in tightly.
Unplug. Then plug again after
10 seconds.
2. Fuse blowing or
circuit breaker works.
Replace fuse of reset
circuit breaker (repaired by
professional personnel of
our company).
3. Trouble with outlet. Test outlet with other
electrical appliances.
Oven does not heat. 1. Door not closed well. Close door well.
Glass turntable makes a
noise when microwave
oven operates.
Dirty roller rest
oven bottom.
Refer to “Maintenance of
Microwave” to clean
dirty parts.

3
Please keep this instruction manual for future reference Instruction manual CM130
SAFETY INSTRUCTIONS
Read carefully all the instructions contained in this
manual. It provides you with important information
regarding the safe installation, use and maintenance of
the appliance as well as useful advice for getting the best
out of your microwave oven. Keep this booklet in a safe
place for future reference. After removing the packing,
check that the appliance is not damaged in any way.
Be careful not to leave the packing materials (plastic
sheeting, expanded polystyrene etc.) where children can
get at them, as they can be dangerous.
ATTENTION:
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
-Children shall not play with the appliance.
-Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Children less than 8 years of age shall be kept away
unless continuously supervised.
-Keep the appliance and its cord out of reach of children
less than 8 years.
-If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.

Instruction manual CM130
4Please keep this instruction manual for future reference
IMPORTANT:
-Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock.
-It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to microwave energy.
WARNING:
-Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
-When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
-Only use utensils that are suitable for use in
microwave ovens.
-If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
-Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
-The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
-Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
-The oven should be cleaned regularly and any food
deposits removed.

5
Please keep this instruction manual for future reference Instruction manual CM130
-Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
-The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
-This product is not designed for commercial use, it is a
household appliance only. It is not intended to be used in:
• Staff kitchen areas in shops, offices and other working
environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential
type environments.
-The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
-Metallic containers for food and beverages are not
allowed during microwave cooking.
-The appliance shall not be cleaned with a steam cleaner.
-Care should be taken not to displace the turntable
when removing containers from the appliance. (For fixed
appliances and built-in appliances being used equal
or higher than 900mm above the floor and having
detachable turntables. But this is not applicable for
appliances with a horizontal bottom hinged door.)
-The microwave oven is intended to be used built-in.
-Steam cleaner is not to be used.
-Surface of a storage drawer can get hot.

Instruction manual CM130
6Please keep this instruction manual for future reference
WARNING:
-The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept
away unless continuously supervised.
-During use, the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
-Accessible parts may become hot during use. Young
children should be kept away.
-The appliance must not be installed behind a decorative
door in order to avoid overheating.
-When the appliance is operated in the combination mode,
children should only use the oven under adult supervision
due to the temperatures generated.
-Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the over door glass since they can
scratch the surface, which may result in shattering of
the glass.
WARNING:
Electric shock hazard: Touching some of the internal
components ccan cause serious personal injury or death. Do
not disassemble this appliance.
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is properly
installed and grounded.

7
Please keep this instruction manual for future reference Instruction manual CM130
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. This appliance is equipped with a cord having
a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and
grounded.
Consult a qualified electrician or appliance engineer if
the grounding instructions are not completely understood
or in doubt as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use
only a 3-wire extension cord.
A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
If a long cord set or extension cord is used:
The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
The extension cord must be a grounding-type 3-wire cord.
The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.

Instruction manual CM130
8Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.

9
Please keep this instruction manual for future reference Instruction manual CM130
ATTENTION:
»Before use, remove all plastic films protecting some parts of the appliance (fascia - panel,
parts in stainless steel, etc.)
»Do not use the appliance to heat a room.
»When the appliance is not in use, we recommend you turn it off, isolate it from the
electrical supply.

Instruction manual CM130
10 Please keep this instruction manual for future reference
CLEANING
Be sure to unplug the appliance from the power supply before any cleaning.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth
when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in shattering of the glass.
CLEANING TIP:
For easier cleaning of the cavity walls: Place half a lemon in a bowl, add 300ml (1/2 pint) water
and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
WARNING:
Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the procedure below.
UTENSIL TEST:
»Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
»Cook on maximum power for 1 minute.
»Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
»Do not exceed 1 minute cooking time.
UTENSILS

11
Please keep this instruction manual for future reference Instruction manual CM130
UTENSILS REMARKS
ALUMINIUM FOIL
Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to
prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be
at least 1 inch (2.5cm) away from oven walls.
BROWNING DISH Follow manufacturer’s instructions. The bottom of the browning dish must be at least 5mm
above the turntable. Incorrect usage may cause the turntable to break.
DINNERWARE Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or
chipped dishes.
G L A S S J A R Always remove lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
GLASSWARE Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
O V E N
COOKING BAGS
Follow manufacturer’s instructions. Do not close with a metal tie. Make slits to allow
steam to escape.
PA P E R P L AT E S
AND CUPS Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
PAPER TOWELS Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
PARCHMENT PAPER Use as a cover to prevent splattering or a wrap for steaming.
PLASTIC
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling
bags” and tightly closed plastic bags should be slit, pierced or vented as directed
by package.
PLASTIC WRAP Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow
plastic wrap to touch food.
THERMOMETERS Microwave-safe only (meat and candy thermometers).
WAX PAPER Use as a cover to prevent splattering and retain moisture.
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
F O O D C A RTO N
WITH METAL
HANDLE
May cause arcing. Transfer food into microwave-safe dish.
MATERIALS YOU CAN USE IN A MICROWAVE OVEN:

Instruction manual CM130
12 Please keep this instruction manual for future reference
M E TA L O R
METAL-TRIMMED
UTENSILS
Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
WOOD Wood will dry out when used in the microwave oven and may split or crack.
MATERIALS TO BE AVOIDED IN A MICROWAVE OVEN:
UTENSILS REMARKS
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
FOOD CARTON WITH
METAL HANDLE May cause arcing. Transfer food into microwave-safe dish.
METAL OR METAL-
TRIMMED UTENSILS Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature..
WOOD Wood will dry out when used in the microwave oven and may split or crack.

13
Please keep this instruction manual for future reference Instruction manual CM130
UTENSILS REMARKS
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
FOOD CARTON WITH
METAL HANDLE May cause arcing. Transfer food into microwave-safe dish.
METAL OR METAL-
TRIMMED UTENSILS Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature..
WOOD Wood will dry out when used in the microwave oven and may split or crack.
SETTING UP YOUR MICROWAVE
PARTS AND ACCESSORIES:
Remove the oven and all materials from the carton and oven cavity. Your oven comes supplied
with the following accessories:
CONTENTS QUANTITY
Glass Turntable 1
Turntable Ring Assembly 1
Instruction Mw anual 1
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Materials to be avoided in icrowave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
SETTING UP YOUR OVEN
arts and ccessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
1
1
Glass tray
Turntable ring assembly
Instruction Manual 1
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Grill Rack( Only be used in grill function
and be placed on the glass tray )
9
G
E D CB
F
A
A. Control panel
B. Turntable shaft
C. Turntable ring assembly
D. Glass turntable
E. Observation window
F. Door assembly
G. Safety interlock system
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Materials to be avoided in icrowave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
SETTING UP YOUR OVEN
arts and ccessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
1
1
Glass tray
Turntable ring assembly
Instruction Manual 1
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Grill Rack( Only be used in grill function
and be placed on the glass tray )
9
Grill Rack
(Only to be used in the grill function and to be
placed on the glass turntable)
Other manuals for CM130
2
Table of contents
Other Caple Microwave Oven manuals
