Configuration help for SENSORswitch
series HWT2
Content: Short description / Technical data (Page 1)
Configuration help (Page 2)
Additional information / Connection diagram (Page 3 - 5)
CAPTRON is the first manufacturer worldwide to develop and produce capacitive
stop request SENSORswitches with touch function for the public and private
transportation. When touching the switch surface, the passenger receives visual
feedback by 12 LEDs and optionally also acoustically by signal tone.
The HWT2 stop request SENSORswitches are specially designed for daily continuous
use in public transport company and convince through extreme longevity, reliability and
robustness. Mechanical wear or regular maintenance are therefore not applicable.
The HWT2 series is suitable both for rod mounting with different diameters (Ø 30 mm,
34/35mm) and for wall mounting. The simple and quick mounting is done by clipping the SENSORswitches into the previously screwed
mounting brackets on the rod or wall. Thus, no screws are visible on the housing and vandalism is prevented.
Please find below the most important features listed:
- 16 cm² switch surface - Extremely long service life - several 100 million switching cycles
- Option 1: rod mounting (Ø 30mm, 34/35mm) - Individualization through symbols
- Option 2: wall mounting - Barrier-free - Braille and raised pictograms on the housing or
- Switches to touch, no pressure necessary switch surface (optional / TSI-PRM compliant)
- Feedback - optical and acoustic signals
by 12 LEDs and beeper (optional)
CAPTRON can provide individual advice to enable you to choose the perfect
product from the HWT2 series for the required specifications and applications.
Please contact us:
Tel. [phone]
E-Mail: [e-mail]
Technical data at 24 V and 20 °C:
Supply voltage: DC 24V DC (10 … 32V) Short-circuit protection:
Short-circuit and overload
protection
Load current: max. 200 mA Voltage drop: max. 2 V at 200 mA
Output: PNP-NO Current consumption: max. 15 mA at 24V DC
Minimum period of
operation:
approx. 180ms Operation temperature: -30 … +80°C
Output signal: approx. 400ms (Dynamic 1) Degree of protection (IP): Housing IP40
LED 1: 8 green LEDs Type of operation: Capacitive
LED 2: 8 red LEDs Operation force: No operation force required
Reverse polarity
protection:
Protection of all lines

Conguration help for SENSORswitch series HWT2
82140 Olching, Germany
Johann-G.-Gutenberg-Str. 7
www.captron.com
CAPTRON Electronic GmbH
CAPTRON Electronic GmbH Johann-G.-
Gutenberg-Str.7
82140 Olching, Germany
www.captron.com
Tel [phone] • Fax [phone] • [e-mail]
Geschäftsführer: Reinhard Bellm, Petra Bellm, Philip Bellm • München HRB 70962 • USt.-ID Nr.: DE 129 310 850
2
Type code –with switching function Dynamic 1:
HWT2 - 6 - / TG - SR // /
Example: HWT2 - C 6 5 D S - V15 / TG - SR / T5 / T23
C1 –Mounting of the stop request button HWT2 2
C2 -Type of connection 5
Code
Description
Code
Description
E
Rod mounting, for Ø 30mm 6 Connector JST
C
Rod mounting, for Ø 34 / 35mm - -
W Wall mounting - -
- - - -
C3 –Colour of the housing
C4 -LED-control 3/ Numbers of pins / Supply voltage
Code
Description
Code
Description
0 Traffic red (RAL 3020) D Automatic / 3-pin / DC 24V
1
Traffic green (RAL 6024)
B
Manual / 3- + 2--pin / DC 24V
5
Traffic yellow (RAL 1023) - -
6
Traffic black (RAL 9017) - -
E Traffic grey B (RAL 7043) - -
H Traffic blue (RAL 5017) - -
-
-
-
-
O1 –Option 1 / Acoustic feedback
C5 -Symbol on switch surface
Code
Description
Code
Description
S Acoustic feedback (Signal tone) V15 „STOP“ (white on red)
-
- V20 „WHEELCHAIR“ (white on blue)
-
-
For further symbols please see our Symbol list (Link) *
* all symbols marked as „Standard“ are already available from
1 pieces / order up without any surcharge.
C6 –LED colours (LED1 –LED2)
O2 –Option 2 / raised pictogram on housing 4
Code
Description
Code
Description
TG-SR Green (LED1) / Red (LED2) - Standard T5 Relief "X" on the housing
O3 –Option 3 / Pictogram / Braille on switch surface 4
Code
Description
T22 Relief “<>” on switch surface *
T23 Braille characters “STOP” on switch surface *
* Option T22 and T23 cannot be combined!
C1
C2
C3
C4
O1
C5
C6
O2
Configuration help HWT2
O3
- - - - - - - -
Please note the additional information and
explanations on the following pages.
Thank you!
- - - - - - - -

Conguration help for SENSORswitch series HWT2
82140 Olching, Germany
Johann-G.-Gutenberg-Str. 7
www.captron.com
CAPTRON Electronic GmbH
CAPTRON Electronic GmbH Johann-G.-
Gutenberg-Str.7
82140 Olching, Germany
www.captron.com
Tel [phone] • Fax [phone] • [e-mail]
Geschäftsführer: Reinhard Bellm, Petra Bellm, Philip Bellm • München HRB 70962 • USt.-ID Nr.: DE 129 310 850
3
Additional information & explanations on the previously described configuration items:
to 1) / Switching function:
Switching function - Dynamic: The output signal is time-limited to 300ms, independent of the duration of actuation.
to 2) / Type of mounting of the stop request SENSORswitch HWT2:
„E“ -Rod mounting
for hand rails with Ø 30mm
Example picture
Product dimensions: Rod distance:
All dimensions in mm
„C“ -Rod mounting
for hand rails with Ø 34mm/35mm
Example picture
Product dimensions: Rod distance:
All dimensions in mm
„W“ -Wall mounting
Example picture
Product dimensions:
All dimensions in mm
- - - Please turn over - - -

Conguration help for SENSORswitch series HWT2
82140 Olching, Germany
Johann-G.-Gutenberg-Str. 7
www.captron.com
CAPTRON Electronic GmbH
CAPTRON Electronic GmbH Johann-G.-
Gutenberg-Str.7
82140 Olching, Germany
www.captron.com
Tel [phone] • Fax [phone] • [e-mail]
Geschäftsführer: Reinhard Bellm, Petra Bellm, Philip Bellm • München HRB 70962 • USt.-ID Nr.: DE 129 310 850
4
Assembly and disassembly (for example rod assembly with Ø 34mm / 35mm):
Removal of the HWT2 cup
Special tool „HWT2-DW"
Required drillings on Mounting of the
handrail mounting flange
to 3) / LED control & Connection diagrams:
LED control - Automatic: LED1 (= green) lights up in operating state.
When the SENSORswitch is touched, LED1 goes out and LED2 (= red) lights up.
- Manual: Both LED1 and LED2 can be controlled separately as required.
.
Connection diagrams:
Connection diagram „D“Connection diagram „B“
PNP-NO // Automatic PNP-NO // Manual
to 4) / Option 1 & 2 –available tactile pictograms & Braille on housing and switch surface:
Option „T5“ Option „T22“ Option „T23“
2x tactile pictogram „X“ on housing 1x tactile pictogram „<>“ on switch surface
(cannot be combined with option T23!)
1x braille „STOP“ on switch surface
(cannot be combined with option T22!)
* optionally with
beeper

Conguration help for SENSORswitch series HWT2
82140 Olching, Germany
Johann-G.-Gutenberg-Str. 7
www.captron.com
CAPTRON Electronic GmbH
CAPTRON Electronic GmbH Johann-G.-
Gutenberg-Str.7
82140 Olching, Germany
www.captron.com
Tel [phone] • Fax [phone] • [e-mail]
Geschäftsführer: Reinhard Bellm, Petra Bellm, Philip Bellm • München HRB 70962 • USt.-ID Nr.: DE 129 310 850
5
to 5) / Types of connection:
Connector JST - 3-pin / Automatic („HWT2-_6_D...“) Connector JST - 3- + 2-pin / Manual („HWT2-_6_B...“)
You need support with the configuration?
Our internal sales team will be happy to advise you on this (Tel.: [phone]; [email protected]om)
You need data sheets and/or 3D data?
Please also contact our internal sales department. Thank you.
Version 1.0 / data status: 12.03.2020
