CARANDINI SWE User manual

1
ASSEMBLY INSTRUCTIONS FOR SWE LED LIGHTING SYSTEM
1. JOINING THE SWE PROFLES
1. Carefully take out the SWE proles form the box and place them on a stable surface.
2. Prepare the mounng slings for the installaon (min. 2 slings per xture).
3. Unscrew and remove the SWE covering shield from the side where the proles will be joined together [pic. 1]
4. Remove the top cover [pic. 2]
5. Place both SWE proles so the A prole will be aligned to the B ( A opposite B ) [pic. 3]
6. Place the mounng hooks in SWE prole guides [pic. 4]
7. Hang the xture at designated places by means of wires, lines or chains
8. Connect both of the connectors together ( A prole connector to B prole socket) [pic. 5, pic. 6]
pic. 1
PINCLAMP
pic. 2 pic. 3
A
B
pic. 4
PROFILE
GUIDE
pic. 5
AB
pic. 6

2
WARNING !
Connecon of lighng xtures to the electrical installaon must be carried out by qualied personnel
eligible and authorized for such operaons.
Before the installaon, turn o the main power circuit
Aempts of disassembling or altering xtures’ internal components are not allowed
Fully operaonal electrical installaon is necessary for the installaon of lighng xtures
9. Join A and B proles together [pic. 7]
10. Place the buckle ring ( A prole) on the pin ( B prole) [pic. 8]
11. Tighten the clamp by pressing it down; both proles should be joined now and connected with each other [pic. 9]
12. Set the light line horizontally [pic. 10]
13. Check all the connecons and power connectors
14. Connect the light line to the electrical installaon by means of power connector of already installed SWE prole [pic. 11] [pic. 12].
WARNING ! - Prior to starng assembly you must turn of the main power. Leave the main power turned o aer the installaon of SWE
prole.
pic. 12
pic. 11
pic. 7 pic. 8 pic. 9
ABABAB
Pic. 10

2. ASSEMBLING SWD LUMINARIES ON SWE PROFILES
1. Carefully take out the SWD luminaries form the box and place them on a stable surface.
2. Locate the socket and the safety hook on the SWE prole; they will be used to connect SWD luminaries with SWE proles [pic. 1]
3. Fasten the SWD safety wire to the SWE safety hook [pic. 2]
4. Place the SWD luminary on the already installed SWE prole so that the electrical connector could line up with SWE socket [pic. 3]
5. Join SWD xture with SWE prole by connecng the socket and the connector. Press them slightly together [pic. 4]
6. Mount the covering shield by pressing it gently unl it clicks into a place [pic. 5]
SOCKET SAFETY HOOK
pic. 1
pic. 3
pic. 2
pic. 4
pic. 5
