Caraudio-Systems dvbLOGi User manual

Version 22.07.2014 DT1-CXC-TV1
dvbLOGiC DVB-T Tuner
DT1-CXC-TV1
for BMW Professional navigation systems
CCC and CIC with iDrive
Vehicles with factory TV-tuner port
(Factory TV-tuner must be uninstalled)
Product features
• Full plug and play vehicle-specific dual DVB-T Tuner + USB-AV-Player
•DVB-T-Tuner MPEG4 compatible (HD)
•USB-AV-Player for USB-media (audio, video, photo) up to 2TB (FAT32 and NTFS)
• Support of all common Audio & Video formats (e.g MKV, MOV, MPEG-1/2/4, H.264)
•USB-AV-Player with last position memory for Audio and Video playback
• with two antenna adapters and USB extension with installation socket
• integrated into and controllable by vehicle infotainment
• AV-input with IR-control channel
• control of after-market devices, e.g. DVD-player, DAB+ tuner
• after-market rear-view camera input
• automatic or manual switching to after-market rear-view camera input (only from
dvbLOGiC mode)
• rear-seat-entertainment AV-output for AV-sources connected to the dvbLOGiC
• optional remote control for full DVB-tuner and USB AV-Player functions/rear-seat-
entertainment
• power-on remote-out trigger-signal (+12V max 1A) to switch on connected devices
• video-in-motion

Version 22.07.2014 DT1-CXC-TV1
Page1
Contents
1. Prior to Installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Setting the dip switches of the CAN-box TV-436
1.4. Setting the dip switches of the tuner-box DT1C-M736
1.4.1. Automatic switching to rear-view camera
1.4.2. Deactivating dvbLOGiC AV input
2. Installation
2.1. Removal of navigation computer CCC/CIC
2.2. Installation of CAN-box TV-436
2.3. Installation of tuner-box DT1C-M736
2.4. Antennas and optional IR-remote control set
2.5. USB-AV-Player
2.6. Connecting peripheral devices
2.6.1. AV-source
2.6.2. Installing AV-source’s IR-sensor additionally
2.6.3. After-market rear-view camera
2.6.4. After-market rear-seat-entertainment
3. Operation
3.1. Activation of the video-in-motion function
3.2. Selecting the dvbLOGiC as current AV-source
3.3. Assigning device control for connected AV-source
3.4. Switching to internal DVB-T, AV-source or after-market rear-view camera
3.5. Button assignment table iDrive
4. Specifications
5. Technical support
Appendix A –Device control table
Appendix B –DVB-T function manual

Version 22.07.2014 DT1-CXC-TV1
Page2
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We offer
free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
If remote function for a peripheral device shall be used, additional an IR-remote cable and
Y-adapter are needed, see chapter AV-source .
CAN-box
TV-436
HW_____
SW _____
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.
Tuner-box
DT1C-M736
HW_____ SW_____
Harness
C2C-BMW01
Harness
CAB-AV-6P
2pcs. antenna adapters ANT-FSMB-P
Harness
TV-BMW01
Harness
C3C-AVIR
USB-extension cable
USBC-EXT

Version 22.07.2014 DT1-CXC-TV1
Page3
1.1. Check compatibility of vehicle and accessories
1.2. Setting the dip switches of the CAN-box TV-436
1.3. Setting the dip switches of the tuner-box DT1C-M736
The default dip switch settings of the tuner-box
need to be changed ONLY if a rear-view camera is
or shall be connected or if the AV-input of the
dvbLOGiC shall be deactivated. The dip switches are located
inside the tuner-box. For changes it is necessary
to open the box. Default settings are:
Dip1 = ON, Dip2 = OFF, Dip3 = OFF
Requirements
Vehicle 1series (E87) only CCC, 3series (E90/91/92), 5series (E60/61),
6series (E63/64), 7series (E65/66), X5 (E70), X6 (E71), Z4 (89)
Navigation Navigation system Professional CCC (older 1/2-button iDrive
or CIC (newer 8-button iDrive)
Vehicles with TV-tuner port
Limitations
Factory-TV-tuner Must NOT be installed. If uninstalled, optical ring must be closed.
Teletext Teletext of the dvbLOGiC can only be used with the optionally
available C3-IRSET remote control set.
After-market rear-view cam Automatic switching to camera only from dvbLOGiC mode.
Factory PDC If an after-market rear-view camera should be connected by the
dvbLOGiC the visual PDC display must be deactivated occasionally
or permanently for camera picture.
Vehicles with CIC dip 1 ON, dip 2 OFF, dip 3 OFF
Vehicles with CCC dip 1 OFF, dip 2 OFF, dip 3 OFF

Version 22.07.2014 DT1-CXC-TV1
Page4
1.3.1. Automatic switching to after-market rear-view camera
If an after-market rear-view camera shall be connected or a factory
rear-view camera is connected, in order for the dvbLOGiC to
automatically switch to its camera input when reverse is engaged,
set dip2 = ON (up).
Note: Automatic switching to after-market rear-view camera works
only from dvbLOGiC mode.
1.3.2. Deactivating dvbLOGiC AV input
If no peripheral AV-source shall be connected to the dvbLOGiC, we
recommend to disable the AV-input, to avoid customers switching by
mistake to black/no picture of the AV-input. In order to disable the
AV-input of the dvbLOGiC,
set dip1 = OFF (down).
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in
sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a
resistor lead.
Complete and correct function of the interface is possible only when CAN and MOST®
(tuner) connections are made properly. On vehicles without TV-icon, it will be coded
automatically after installation.
Place of installation is behind the navigation computer CCC or CIC.
Note: The loose white and green cable of harness TV-BMW01 are not required and must be
isolated.
Dip switches
of tuner-box
Dip switches
of tuner-box

Version 22.07.2014 DT1-CXC-TV1
Page5
2.1. Removal of navigation computer CCC/CIC
Example 5series (E60/61).
Remove trim strip step by step using a
plastic wedge. Do not proceed to quickly to
avoid breaking clamps of the trim strip.
Remove screws 1 and 2 (see picture).
Remove climate control panel. Remove
CD/DVD drive trim. The trim is fixed by
2 screws on the upper side and plugged to
the lower trim. Remove the lower trim
(plugged too).
Remove 4 screws and take out
navigation computer.

Version 22.07.2014 DT1-CXC-TV1
Page6
2.2. Installation of CAN-box TV-436
Disconnect female Quadlock connector from the back of the navigation computer.
Remove MOST®-insert from the factory harness female Quadlock connector.
Plug MOST®-insert into male MOST®-connector shell of harness C3C-BMW0x.
Plug female Quadlock connector into male Quadlock socket of harness
C3C-BMW0x.
Plug male MOST®-connector into female MOST®-socket of C3C-BMW0x.
Plug female Quadlock connector of C3C-BMW0x into male Quadlock socket of the
navigation computer.
Connect harness TV-BMW01 to the 8pin Molex connector of CAN-Box TV-436.
Note: Vehicles without MOST®-components, which means without factory CDC, without
factory phone or other MOST®-components have optical leads at the navigation computer,
but it can be possible that the optical ring is not closed at the diagnostic connector in the
glove compartment. In this case a connector bridge for optical wires is necessary.

Version 22.07.2014 DT1-CXC-TV1
Page7
2.3. Installation of tuner-box DT1C-M736
The fibre optical interface installation is
made at the navigation computer, which
is located at the left side in the trunk
behind a cover and has to be removed.
The factory TV-tuner must be uninstalled.
Remove the factory optical leads of the factory
TV-tuner port (blue female connector) and connect
it to the black male MOST®-connector enclosed to
harness C2C-BMW01. Pay attention to the
directional arrow on the optical lead connectors.
Connect the black male MOST®-connector to the
female MOST®-connector on the rear of the
tuner-box DT1C-M736 (OPTICAL).
Connect the blue male connector of harness
C2C-BMW01 to the factory TV-tuner port
(blue female connector).
Picture exemplary

Version 22.07.2014 DT1-CXC-TV1
Page8
2.4. Antennas and optional IR-remote control set
Mount antennas ANT-12 and connect them to the female f-plug connectors on front
of tuner-box DT1C-M736.
We strongly recommend to first test the reception quality of the chosen mounting
position of the antennas before final installation! See “Appendix C – Antenna
positioning” for additional information.
Connect the antenna adapters ANT-FSMB-P to the factory antennas of the vehicle.
The C3-IRSET consists of the external C3C-SENSOR IR-sensor and the C3C-RC
IR-remote control and can be used to control the dvbLOGiC’s internal DVB-T tuner
functions additionally to the control through the navigations buttons. Connect the
C3C-SENSOR to the female black/red/blue 3pin AMP connector of harness
C3C-AVIR and locate the sensor in an accessible place.
Note: To use the teletext function of the dvbLOGiC’s internal DVB-T tuner, the
C3-IRSET is necessary to enter the page numbers.

Version 22.07.2014 DT1-CXC-TV1
Page9
2.5. USB-AV-Player
Connect the USB extension USBC-EXT to the USB-port on the rear of the tuner-box
DT1C-M736.
Connect USB-media (up to 2TB, FAT32 and NTFS) to the USB-port of the USB-
extension USBC-EXT.
2.6. Connecting peripheral devices
It is possible to connect an after-market AV-source, an after-market rear-view camera and
rear-seat-entertainment to the dvbLOGiC Tuner.
Before final installation of the peripheral devices, we recommend to test-run the
dvbLOGiC functions to detect incompatibility of vehicle, navigation, factory accessories or
peripheral devices as soon as possible.

Version 22.07.2014 DT1-CXC-TV1
Page10
2.6.1. AV-source
The dvbLOGiC has the possibility to connect and remotely control by navigation buttons a
pre-programmed device. The device list in the device control table shows the pre-
programmed remote channels and the related IR-remote cables STA-xxx which must be
ordered separately for the control of the device.
Using the respective STA-xxx IR-control cable, interconnect the yellow female 3pin
AMP connector of harness C3C-AVIR and the IR-port of the AV-source.
Using an RCA-cable, interconnect the female RCA-port of harness CAB-AV-6P with the
AV-output of the AV-source.
The pink ACC-output wire (+12V max 1A) of harness C3C-BMW0x can be connected
to the ACC-input wires of the connected device to switch it on. It carries +12V when
the navigation computer is running.
2.6.2. Installing AV-source’s IR-sensor additionally
Additionally to the control via OEM navigation, it is possible to install the original IR-sensor
of a connected device. By using the respective Y-adapter (e.g. STA-Y35MM or STA-RJ12) for
the IR-Port of the connected device, the controls of navigation AND device’s IR-sensor can be
connected and used simultaneously. Installation of the IR-sensor is recommended as the
controls via navigation are limited, and not all functions may be covered.

Version 22.07.2014 DT1-CXC-TV1
Page11
2.6.3. After-market rear-view camera
Connect the video RCA of the after-market rear-view camera to the the female RCA
connector RVC of tuner-box DT1C-M736.
Connect the green wire of C2C-BMW01 to the camera power supply (+12V max. 1A).
The green wire is high (+12V) when reverse gear is engaged.
-
-On some vehicles the reverse light signal doesn’t exist on the CAN-bus. Connect the
white wire of harness C2C-BMW01 to reverse light signal (+12V of reverse light) if the
dvbLOGiC doesn’t switch to the rear-view camera automatically.
-Note: Automatic switching to after-market rear-view camera works only from
dvbLOGiC mode.
With an existing factory PDC the visual PDC display must be deactivated occasionally or
permanently by iDrive while operating in the vehicle settings for camera picture. If needed
the PDC display can be switched on by PDC button.

Version 22.07.2014 DT1-CXC-TV1
Page12
2.6.4. After-market rear-seat-entertainment
Using RCA-cables, connect the rear-seat-entertainment to the female RCA-connector
VIDEO OUT of harness C3C-AVIR.
Note: As the output is a full output, not shared with the video signal for the
navigation system, splitting the video with an RCA Y-cable might give a good enough
picture for two rear-seat-entertainment monitors. If not, or if connecting more than
two monitors, use a video splitter.
3. Operation
3.1. Activation of the video-in-motion function
On vehicles with CIC (8-button iDrive) the video-in-motion function is permanently active
without disturbing the navigation performance.
On vehicles with CCC or E65 navigation (1 or 2 button iDrive) press the menu-button or the
iDrive wheel for about 3 seconds while in main menu. Alternatively it is possible to set dip-
switch 1 of the CAN box TV-436 to ON. But then the navigation performance is disturbed on
the first few kilometres of driving.
3.2. Selecting the dvbLOGiC as current AV-source
In the vehicle’s main menu, select Infotainment and then TV by iDrive to choose the
dvbLOGiC as current AV-source.

Version 22.07.2014 DT1-CXC-TV1
Page13
3.3. Assigning device control for connected AV-source
After selecting the dvbLOGiC as current AV
source, push iDrive knob to open the
dvbLOGiC control menu. Select control
levels setup “AV: RCxx”and assign related
IR-code as described in device control
table.
Note: If the AV-input is deactivated (see chapter 1.4.2.), the menu items “AV” and “AV:
RCxx” will not be available.
3.4. Switching to internal DVB-T, AV-source or after-market rear-view camera
In the dvbLOGiC control menu, choose TV to enter internal DVB-T tuner and USB-AV-Player
mode, AV to enter AV-input mode (not available if AV-input is deactivated, see chapter
1.4.2) or REAR CAM to switch to the dvbLOGiC after-market rear-view camera-input (even if
the automatic switching to the camera input is disabled, see chapter 1.4.1.). After selection
the menu will close automatically and switch to the selected source. The iDrive knob, some
multi-function-steering wheel buttons (MFSW) and some navigation buttons (HU) are now
available for remote functions (see assignment table for iDrive below).
By pressing the iDrive-MENU-button, the system returns to the factory iDrive functions. By
pressing the iDrive knob again, the dvbLOGiC control menu will be re-entered.

Version 22.07.2014 DT1-CXC-TV1
Page14
3.5. Button assignment table iDrive
The button assignment table shows which functions of dvbLOGiC and additionally connected
devices can be executed by iDrive. Once DVB-T or AV-input mode are activated the iDrive
action in the left column will execute the function described in the corresponding device
column. The function description equals the remote control buttons of the optional
dvbLOGiC remote control or the additional device. On the additional device the writing may
vary (e.g. AV instead of Source).
iDrive action
Device
Internal DVB-T
DAB on AV-input
DVD on AV-input
DVC on AV-input
iPod interface on AV-
input
Menu long
MENU
SETUP
Setup
Setup
Setup
Menu short
Return to factory
iDrive functions
Return to factory
iDrive functions
Return to factory
iDrive functions
Return to factory iDrive
functions
Return to factory
iDrive functions
Options long
*2
POWER
-
Audio
Audio
KCE: Light Bulb, Vlink:
Subtitle
Options short
*2
-
-
Subtitle
Subtitle
KCE: lower vol, Vlink:
Display
Back short *2
EXIT
EXIT
STOP
STOP
STOP
Enter long
PLAY / PAUSE
POWER
POWER
POWER
POWER
Enter short
OK
OK
OK
OK
OK
North long
EPG
FAV
Menu / PBC *1
Menu / PBC *1
Shuffle
North short
UP
UP
UP
UP
Previous chapter
West long
EXIT
FAV+/-
Play/Resume
Play/Resume
Play/Resume
West short
LEFT
LEFT
LEFT
LEFT
LEFT
South long
SCAN
SOURCE
Source
Source
Source
South short
DOWN
DOWN
DOWN
DOWN
Next chapter
East long
TV- Next channel
(AFS)
USB - FFWD
SCAN
Zoom
Next DVD or DVD
selection menu
KCE: increase vol,
Vlink: ESC
East short
RIGHT
RIGHT
RIGHT
RIGHT
rechts
Left turn
UP
UP
Next chapter
Next chapter
UP
Right turn
DOWN
DOWN
Previous chapter
Previous chapter
DOWN
UP short on
MFSW *3
Next channel
RUNTER
Next chapter
Next chapter
Next chapter
DOWN short
on MFSW *
Previous channel
HOCH
Previous chapter
Previous chapter
Previous chapter
LEFT short on
HU *3
Next channel
RUNTER
Next chapter
Next chapter
Next chapter
RIGHT short
on HU *3
Previous channel
HOCH
Previous chapter
Previous chapter
Previous chapter
*1 DVD title menu *2 not available on all vehicles *3 multi function steering wheel and head-unit

Version 22.07.2014 DT1-CXC-TV1
Page15
4. Specifications
Operation voltage 10.5 –14.8V DC
Stand-by power drain <1mA
Operation power drain <1200mA
Power consumption <16,5W
Temperature range -30°C to +80°C
Weight 333g
Measurements (box only) B x H x T 140 x 30 x 105 mm
5. Technical Support
Caraudio-Systems Vertriebs GmbH NavLinkz GmbH
manufacturer/distribution corporate sales/tech dealer-support
Rheinhorststr. 22 Eurotec-Ring 45
D-67071 Ludwigshafen am Rhein D-47445 Moers
phone [phone]
email [e-mail]
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
