Cardinal Gates XpandaGate User manual

1TWO (2)
MOUNTING
BRACKETS
2
3
2X
4
ASSEMBLY INSTRUCTIONS
1. Attach mounting
brackets to top sides
of gate. (You will hear a
click when it is seated.)
2. Expand gate to fit opening and mark for mounting all four (4)
mounting brackets (A). Bottom mounting brackets can slide up to
mount above baseboard if needed (B), but mount as close to floor
as possible for maximum stability.
3. Drill holes (C) for plastic anchor (into
drywall) or pilot hole (for wood
mounting). Insert plastic anchors into
drywall, if applicable (D).
4. Install gate with 1” screws (E). Position gate
into final desired angles. Screw tight all six (6)
joints (F) counterclockwise to tighten.
GATE IS RECOMMENDED FOR CHILDREN BETWEEEN 6 AND 24 MONTHS.
XPANDAGATE - MODEL EX100
FOR OPENINGS 30” (78cm) - 100” (254cm)
Max span in 100”
A
B
8X
C
D
8X 8X
E
F
INCLUDED:
EIGHT (8)
DRYWALL
ANCHORS
EIGHT (8)
1” SCREWS
NOTE: For maximum stability, install in a zig zag pattern. ( )
6X
GATE OPERATION
TO OPEN
Slide button back
with thumb
and lift gate
to open.
TO CLOSE
Push gate shut.
Listen for “CLICK”
to ensure gate is
locked.
TIP FOR
ASSEMBLY,
DISASSEMBLY
AND ADDING
EXTENSIONS
1. Depress button
lock with blunt
ended tool like a
screwdriver.
2. Pull mounting
bracket off gate.
NEVER USE TO KEEP CHILD AWAY FROM POOL.

GATE MAINTENANCE
GATE CARE & REMINDERS
GATE WARRANTY
To clean, rinse with lukewarm water, wash gently with mild soap or detergent and lukewarm water,
using a soft cloth or sponge. Rinse again. Dry with a soft cloth or sponge to prevent water spotting.
DO NOT SCRUB or use brushes or squeegees.
Our gates are built to last many years with proper use and care. Here are a few suggestions...
• Close gates gently - do not slam - to prevent damage to latch mechanism.
• When closing, be sure latch on gate frame engages as depicted in instructions.
• For safety, always close gate when not in use. Children should not be allowed to swing on an
open gate.
• Periodically check all screws, bolts, etc. for security and proper adjustment.
CARDINAL GATES, INC., offers many accessories such as extensions, stair kits, and other
safety products. Check with your dealer or call CARDINAL GATES, INC. at 1-800-318-3380.
We sincerely hope that you thoroughly enjoy many years of service from your CARDINAL GATE.
Your Cardinal Gate is warranted to be free of manufacturing defects for a period of one year
from the date of purchase when used in homes, and according to manufacturers instructions.
When used commercially, such as day care centers, the warranty is 90 days.
Cardinal Gates, lnc. will either repair or replace, at our option, any parts necessary to correct
defects in material or workmanship during the warranty period. The warranty disclaims liabilty
for incidental, special and consequential damages of any nature.
TO EXERCISE WARRANTY:
Ship your gate in a protective carton, freight prepaid to:
CARDINAL GATES, INC.
79 Amlajack Way
Newnan, GA 30265
You must include the following:
1. Proof of purchase (store receipt, etc.).
2. Brief note describing problem with gate.
3. Full return address along with phone number.
FOR FURTHER ASSISTANCE
Call 1-800-318-3380
79 Amlajack Way
Newnan, GA 30265
770-252-4200
www.cardinalgates.com
