Cardinal CS Series User manual

1
Digital Counting Scale
CS Series
Operation Manual
Cardinal Scale Manufacturing Co.
8526-M256-01 Rev A PO BOX 151 WEBB CITY, MO 64870 Printed in USA
07/04 PH [phone] - FAX [phone]
www.detectoscale.com
Cardinal CS Series user ManualCardinal CS Series user ManualCardinal CS Series user ManualCardinal CS Series user Manual

2
PRECAUTIONS
Before using this instrument, read this
manual and pay special attention to all
"WARNING" symbols:
IMPORTANT ELECTRICAL
WARNING
INTRODUCTION
Thank you for purchasing our Detecto CS
Series Digital Counting Scale. Your scale is
equipped with a rechargeable battery pack
that is able to provide 100 hours continuous
operation (with backlight on) or 200 hours
continuous operation (with backlight off).
This manual will guide you through setup and
operation of your scale. Please read it
thoroughly before attempting to operate this
scale and keep it handy for future reference.
ÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞ
FCC COMPLIANCE STATEMENT
WARNING! This equipment generates, uses and
can radiate radio frequency and if not installed
and used in accordance with the instruction
manual, may cause interference to radio
communications. It has been tested and found to
comply with the limits for a Class A computing
device pursuant to Subpart J of Part 15 of FCC
rules, which are designed to provide reasonable
protection against such interference when
operated in a commercial environment. Operation
of this equipment in a residential area may cause
interference in which case the user will be
responsible to take whatever measures necessary
to correct the interference.
You may find the booklet "How to Identify and Resolve
Radio TV Interference Problems" prepared by the
Federal Communications Commission helpful. It is
available from the U.S. Government Printing Office,
Washington, D.C. 20402, stock No. 001-000-00315-4.
ÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞÞ
All rights reserved. Reproduction or use, without
expressed written permission, of editorial or pictorial
content, in any manner, is prohibited. No patent
liability is assumed with respect to the use of the
information contained herein. While every precaution
has been taken in the preparation of this manual, the
Seller assumes no responsibility for errors or
omissions. Neither is any liability assumed for
damages resulting from use of the information
contained herein. All instructions and diagrams have
been checked for accuracy and ease of application;
however, success and safety in working with tools
depend to a great extent upon the individual accuracy,
skill and caution. For this reason the Seller is not able
to guarantee the result of any procedure contained
herein. Nor can they assume responsibility for any
damage to property or injury to persons occasioned
from the procedures. Persons engaging the
procedures do so entirely at their own risk.
TABLE OF CONTENTS
INSTALLATION ..………………..……….… 1
PRECAUTIONS ……………………….….… 2
CARE AND CLEANING ……………….…… 2
KEY FUNCTIONS ………………………….. 3
ANNUNCIATORS ………………………….. 5
OPERATION ………………………………... 6
Display Backlight ……………………….. 6
Counting …………..…………………….. 7
Accumulator ………………………..…… 8
Tare Weight Entry ……………………… 9
Quantity/Weight Preset Limits ……..…. 10
CALIBRATION ……………………………… 11
OPERATIONAL SETUP ……………..……. 12
ERROR AND STATUS DISPLAYS …….… 15
BEFORE YOU CALL SERVICE ………….. 15
SPECIFICATIONS
Displays:
(.75” High LCD,
with backlight)
Weight = 5 Digits
Piece Weight = 5 Digits
Count = 6 Digits
Dimensions:
11.75" W x 12.63" D x 4.25" H
(298mm x 321mm x 108mm)
Platform Size 11.38" W x 8.25" D
(289mm x 210mm)
Model
CS-6
CS-15
CS-30
CS-65
Capacity and Division Value
6 lb x .0005 lb (3 kg x .2g)
15 lb x .001 lb (7.5 kg x .5g)
30 lb x .002 lb (15 kg x 1g)
65 lb x .005 lb (30 kg x 2g)
Zero Established on power up
routine and maintained by
auto-zero circuitry
Power Built-in rechargeable battery
pack or 115 VAC 50/60Hz or
230 VAC 50/60Hz
Tare 100% of full scale capacity
Temperature 32 ~ 104°F (0° ~ 40°C)
Humidity 25% ~ 95% RH
Serial Number_______________________
Date of Purchase ____________________
Purchased Form_____________________
___________________________________
___________________________________
RETAIN THIS INFORMATION FOR FUTURE USE
