CareCo DL08130 User manual

DL08130 - Zest Infrared Foot Massager
Safety Attention
a) Important Safety Instructions
• ●Be sure to read the user manual thoroughly prior
to use and follow instructions for usage.
• After using or before cleaning the product, ensure
the power is disconnected.
• Use the heating function with caution to avoid serious burns.
• Do not apply the product to insensitive or over-sensitive skin or to body parts with poor circulation.
• Always ensure children or people with disabilities are supervised when using the product.
• Do not use undercover eg. under a pillow or blanket as this could cause fire, electric shock or
malfunction from overheating.
• Please stop using immediately if you feel uncomfortable.
• Do not use if the power cord or plugs are damaged - contact the service center for inspection and
repair.
• Do not use spare parts that have not been recommended by the manufacturers.
• Do not insert or drop objects into any opening on the product.
• Always switch the massager off before disconnecting the power.
• This product cannot be used for self-diagnosis or treatment - please visit a healthcare professional
for this.
b) Use Environment
• Do not use the product in a wet or dusty environment in order to avoid product failure.
• Do not use this product at temperatures over 40.
• Do not use the product outdoors.
• Do not use the product next to an electric heater or stove or in direct sunlight.
c) Please consult your doctor before using this product if you have the following situations:
• Receiving medical treatment or experiencing physical discomfort
• Suffering from hypertension, heart disease, cerebral arteriosclerosis, and cerebral thrombosis
• Suffering from cancer
• Pregnant or menstruating
• Suffering from osteoporosis
• Using a pacemaker or implantable medical devices
• Suffering from acute diseases
• Minors
d) Buttons
• Do not operate the button with wet hands and keep the buttons away from water or other liquid.
• Do not fall asleep when using the product.
• Do not use this product when you are drunk or feeling uncomfortable.
• Do not directly contact the massager pad with your hands, foot joints, knees, chest and abdomen.
• Do not use this product for longer than 30 minutes.
• Do not use if the product’s cloth cover has been damaged.
• Do not use the product one hour before and after eating so as to avoid adverse effects.
Product Specifications (DL08130)
Rated Voltage
Standards
Timer
220V
GB 4 706.1-2005
GB 4 706.1-2008
15 minutes
Rated Power 45W

• Do not enable the heating function when the product is being used in a low room temperature. It is
recommended that you should gradually adjust the temperature to a normal range before enabling
heating.
• If the product is used immediately after being transferred from a cold environment to a warm
environment, the accumulation of water vapor inside the product may affect the normal operation
of the product or even cause mechanical failure. You are suggested to put the product in a normal
room temperature for 1 hour before use.
Maintenance
Product Components
a) Storage
• The product should be stored in its box in dry, well-ventilated and cool conditions when it is not in
use.
• Do not hang the product with the cord.
• Avoid scratching by sharp objects on the surface of the product.
• Do not put the product in direct sunlight or under condition of high temperature.
b) Cleaning
• Make sure the power button is off and unplug the power cord before cleaning.
• Use a dry cloth to clean the surface of the product.
• Do not use corrosive detergents, such as benzene or thinner, to clean the product.
Product Features
• The modern egg-shaped design makes the product
lightweight and portable;
• A variety of functions including scratching, roller kneading
and push kneading acupressure, air pressure and heating;
• Massager pad that provides all-round massage and deep
acupressure to relax and relieve tension in the feet;
• Removable and washable cover for keeping clean;
• Cord wrap for added convenience.
1. Central Surface: four independent buttons—controlling the product’s settings and functions
2. Central Massager Pad: Scratching—Acupressure on the arches with heating.
3. Front Massager Pad: Roller Kneading—Acupressure on the front soles
4. Rear Massager Pad: Push Kneading—Acupressure on the heels
5. Interior airbag—Air pressure on the insteps
6. Removable and washable fabric cover—cleaning
7. Bottom: Cord Wrap—keeps things tidy
c) Maintenance
• Keep the product clean and away from high humidity conditions.
• Please use a dust cover (not included in the box) to cover the product to prevent dust from coming
into it if it is not used for a long period of time.
Features and use of Diagram

a) Before use
• Check the product for any damage.
• Ensure a stable and comfortable use environment.
b) Use
• Untie the power cord and connect to power of 220V/50Hz
Default Settings:
• Press the Power Button ONCE, and the heating function is ON in a red indicator; the Intensity is low
in a blue indicator, and the product is on Mode 1 in a blue indicator.
• Press the Power Button ONCE, then press the Heating Button ONCE, and the heating function will
be OFF as the red indicator goes off.
• When the product is in operation, press the Intensity Button to switch between the two types of
intensity. Blue light indicates low Intensity and red light indicates high Intensity.
• When the product is in operation, press the Mode Button to switch between two Modes. Blue light
indicates Mode 1 and red light indicates Mode 2.
Display
Timer Button: To set massage duration on timer.
Mode Button: To switch between massage modes. This product provides two modes of
massage with red and blue light indicators for each.
Intensity Button: To controls the massage intensity, where the red light indicates a high
intensity and blue light indicates a low intensity.
Heating Button: When the product is turned on, push this button to control the heating
independently with a red light indicator (The heating is on in default).
Power Button: To turn on/off the product.
Settings

Warranty:
Your CareCo branded product is under warranty to be free from defects in material and workmanship
for one year from date of purchase. This warranty expresses our confidence in the workmanship and
materials used for our products.
In the event of a defect covered by this warranty, CareCo will, at our discretion, replace the product
or supply parts to remedy. This warranty does not cover device failure due to owner misuse or
negligence, or due to normal wear and tear. The warranty does not extend to non-durable parts, such
as rubber accessories, which are subject to normal wear and tear and require periodic replacement.
If you have any queries please contact CareCo.
Please refer to the following several tips and possible solutions if problems occur during usage of
this product. The product may be returned to the service center or undergo inspection and repair by
authorized technicians.
CareCo, Hubert Road, Brentwood,
Essex CM14 4JE
www.careco.co.uk
Troubleshooting:
Problems Possible Causes Remedies
Not working
• Unplugged
• Power button not pushed
• Connect the product to
power or check whether
or not the product is
well-connected.
• Push the power button
Suddenly stops running
• Power disconnection
• Operation duration over
15 minutes
• Product overrun and overheat
• Too much operating pressure
that the massage balls stop
rotation
• Check whether or not the
product is well-connected
• Restart the product
• Restart the product after
cooling
• Restart the product
