Carestream CS 7200 Manual

User and Installation Guide
CS 7200

Notice
The CS 7200 User Guide describes and illustrates the workflow for digital dental radiography using an
imaging plate (storage phosphor screen) for radiographic diagnostic intraoral images. We recommend that
you thoroughly familiarize yourself with this Guide in order to make the most effective use of your system.
No part of this Guide may be reproduced without the express permission of Carestream Health, Inc.
U.S. Federal law restricts this device to sale by or on the order of a dentist or physician.
This document is originally written in English.
Manual Name: CS 7200 User and Installation Guide
Part Number: 6M0940
Revision Number: 04
Print Date: 2017-05
Important:
Read and follow the operating instructions in this guide carefully and always
keep it within easy reach.
The room in which this unit is to be installed must comply with all official
applicable regulations.
Improper use and handling can create hazards and cause damage to the unit.
To prevent personal injury or material damage, you must observe all safety
information.
Consult the CS 7200 Safety, Regulatory and the Technical Specifications User
Guide before using the CS 7200.
0086

CS 7200 User and Installation Guide (6M0940)_Ed04 i
Contents
Chapter 1
Conventions in this
Guide
Conventions in this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 2
CS 7200 Overview
Indications for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CS 7200 Components Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Scanner Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Indication LEDs Statuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Imaging Plates Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Hygienic Sheaths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3
Setting Up CS 7200
Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unit dimensions and Space Requirements . . . . . . . . . . . . . . . . . . . 9
Electrical Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting Up CS 7200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CS Imaging Software Installation . . . . . . . . . . . . . . . . . . . . .13
CS 7200 Drivers Installation . . . . . . . . . . . . . . . . . . . . . . . . . 18
License Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CS 7200 Post Installation Test. . . . . . . . . . . . . . . . . . . . . . . . 28
Adapt Filtering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Access Adapt Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Create Customized Look. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Modify the Exisiting Customized Look . . . . . . . . . . . . . . . . 31
Delete Existing Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Chapter 4
CS Imaging
Software Overview
General Software Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Single Image Acquisition Overview. . . . . . . . . . . . . . . . . . . . 35
Full Mouth Series (FMS) Image Acquisition Overview . . . 35
Patient Browser Window Overview . . . . . . . . . . . . . . . . . . . . 40
Chapter 5
Acquiring Images
Image Acquisition Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Acquiring Single Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Starting the Imaging Software . . . . . . . . . . . . . . . . . . . . . . . . 42
Preparing the Imaging Plates . . . . . . . . . . . . . . . . . . . . . . . . . 43
Performing the X-rays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Scanning Imaging Plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

ii
Acquiring Multiple Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Preparing the Acquisition of FMS Images . . . . . . . . . . . . . .50
Acquiring FMS Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Retaking Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Manually Erasing the Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Changing Scanner User Preferences . . . . . . . . . . . . . . . . . . . . . . .57
Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Tools Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
About Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Changing Scan Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Chapter 6
Maintenance
Chapter 7
Troubleshooting
Quick Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Indication LEDs Statuses . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
8
Appendix
Offline License Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Create a New Patient Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Chapter 9
Contact Information
Manufacturer’s Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Authorized Representatives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Chapter 10
List of Consumables
List of Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Chapter 11
Publications History

CS 7200 User and Installation Guide (6M0940)_Ed04 1
1 Conventions in this Guide
Conventions in this Guide
The following special messages emphasize information or indicate potential risk to personnel or equipment:
WARNING: Warns you to avoid injury to yourself or others by following
the safety instructions precisely.
CAUTION: Alerts you to a condition that might cause serious damage.
Important: Alerts you to a condition that might cause problems.
Note: Emphasizes important information.
Tip: Provides extra information and hints.

2 Chapter 1 Conventions in this Guide

CS 7200 User and Installation Guide (6M0940)_Ed04 3
2 CS 7200 Overview
Indications for Use
The CS 7200 is intended for digital dental radiography using an imaging plates ( phosphor storage screens)
for dental intra-oral X-ray imaging.
Introduction
The CS 7200 system is used to scan and review intraoral dental X-ray images. When scanning the X-ray
exposed imaging plate a digital image is displayed on the workstation screen. After scanning, the scanner
erases the imaging plate and ejects it. The imaging plate is ready for re-use.
The exam acquisition’s scanned image is sent to the Dental Imaging Software on the workstation. Using the
Dental Imaging Software, the image is processed and reviewed.
The system is composed of the following elements:
CS 7200 scanning device (page 4)
Imaging plates (page 7)
Note: The CS 7200 is intended for dental professionals. You are required to
have training to use the CS 7200.
Note: The scanner is supplied with a separate viewing and archiving software
package: Dental Imaging Software, approved by Carestream Health.
Note: The CS 7200 User Guide is provided on the supplied CD/DVD-ROM.

4 Chapter 2 CS 7200 Overview
CS 7200 Components Overview
Scanner Overview
The CS 7200 scanner includes the functions necessary for scanning and acquiring images from the imaging
plates.
Figure 1 CS 7200 Front View
1
On/Off switch
Turn scanner On: press for 1 second
Shut down the scanner:
press for 2 seconds to reset the scanner, run BIT.
The scanner remains turned on.
press for 5 seconds to turn off the scanner.
2Indication LEDs
3Cover
4Base
5Intraoral imaging plates tray
6Plate insertion entry
7Plate size selection knob
8Insertion panel.

CS 7200 User and Installation Guide (6M0940)_Ed04 5
Figure 2 CS 7200 Back View
Figure 3 Cables Compartment in detail
1Base
2Cables compartment
3Cover
1Power supply inlet
2USB port
3Cable Compartment cove

6 Chapter 2 CS 7200 Overview
Indication LEDs Statuses
The scanner LEDs status indicator shows the following scanner states:
LED Color Scanner State Remark
Off Off
Blinking Yellow Power up Blinking yellow
Yellow Stand by (door closed) Yellow
Yellow Disconnected
Type 1: Blinking yellow 1 - cable is disconnected
Type 2: Fast Blinking yellow - no driver
Type 3: Constant yellow: no UltraLite or scanner is
not ready
Blinking Cyan Plate is fully loaded. Take out
envelope. Beeps twice, sync with light,
Green Insert plate (Door opened) Green
Green Load & recovery Green
Green Recovery
If plate is not fully loaded for a number of times (three
consecutive attempts), the scanner performs a reset
and returns to loading position.
Green Ready for scan Green
Blinking Green Scanning
Fast Blinking Green Erasing/Eject
Blinking Red Error

CS 7200 User and Installation Guide (6M0940)_Ed04 7
Imaging Plates Overview
The CS 7200 works with three imaging plate sizes: 0, 1 and 2. The scanned image file size depends on the
imaging plate size and the scanning resolution set by the user.
The imaging plate has two sides: the active side for capturing the X-ray image and the inactive side. The
active side of the imaging plate includes an orientation ‘c’ mark with a dot inside to facilitate positioning
protocols within the patients’ mouth. The inactive side has a printed dot that corresponds to the location of
the orientation mark on the active side. This dot is visible through the transparent side of the hygienic sheath.
Table 2-1 Intraoral imaging plates sizes
Size Illustration Application
0Periapical exam (Pediatric
dentistry)
1Bitewing exam (Pediatric
dentistry)
2 Periapical exam (Adult)
Active side
Inactive side

8 Chapter 2 CS 7200 Overview
Hygienic Sheaths
For each imaging plate size, a one-time use, disposable, hygienic sheath is used for preventing cross
contamination. The transparent side allows you to see the dot, while the opaque side protects the active side
of the inserted imaging plate from image degradation.
Figure 4 Hygienic Sheath (front view)
1 Adhesive strip (for sealing the hygienic sheath)
2 Sheath transparent side to see the plate refernce
3 Tear line to be opened when inserting the plate into the scanner

CS 7200 User & Installation Guide (6M0940)_Ed04 9
3 Setting Up CS 7200
Environmental Requirements
Check the following ambient operating condition requirements of the room, before installing the unit:
Temperature: 15–35 °C
Relative humidity: 30–85 % Non-condensing
Atmospheric pressure: 700–1060 hPa
For optimal results it is recommended that the light level in the room is approximately 500 lux (normal light
conditions) to minimize the imaging plates exposure to light.
Unit dimensions and Space Requirements
The scanner should be placed on a flat stable surface.
Important: The scanner should be positioned so that there is always easy access
to the mains power supply socket.
Important: It is recommended not to install the scanner close to the opened
window to prevent the exposure to the direct sunlight.

10 Chapter 3 Setting Up CS 7200
The unit dimensions illustrated in the above figure are as follows:
Height of the unit 270 mm. (10.6 in.)
Width 130 mm. (5.1 in.)
Depth 300 mm. (11.8 in.)
Electrical Requirements
Table 2 Electrical installation specifications
Minimum System Requirements
For installation of the CS 7200 intraoral imaging software, the computer must meet the minimum computer
system requirements, specified in the CS 7200 Safety, Regulatory & Technical Specification Guide. .
Electrical Installation Specifications
Power Supply 100 V AC – 240 V AC, 0.8 - 0.4 A
Frequency 50/60 Hz
UPS (online, recommended) 700 VA (UPS is connected to the
scanner, computer and monitor)
Minimum clearance between the
table and the mains wall outlet 10 cm / 3.5 in.
Important:
It is MANDATORY to check that the computer system configuration is
compatible with the computer minimum system requirements specified in the
Safety, Regulatory & Technical Specifications Guide. If necessary you must
update your computer system configuration.

CS 7200 User & Installation Guide (6M0940)_Ed04 11
Setting Up CS 7200
Connecting Cables
This chapter describes how to connect the Power Supply and USB cables to CS 7200:
1. Install the power supply adaptor on power supply as shown below:
2. Remove the cable compartment cover.
Note: CS 7200 must be powered by the dedicates AC/DC adapter model
TR30RAM240, manufactured by Cincon Electronics Co., Ltd.

12 Chapter 3 Setting Up CS 7200
3. Connect the Power supply cable to the power supply inlet in the cable compartment and route the cable
as shown on the below image to secure the cable in its place:
4. Connect the USB cable to the dedicated connector in the cable compartment, and route the cable as
shown on the below image to secure the cable in its place:
5. Close the cable compartment cover.
6. Connect the free end of the USB cable to the main USB port in the back of the computer.
7. Connect the Power Supply cable plug to the Mains wall socket.

CS 7200 User & Installation Guide (6M0940)_Ed04 13
CS Imaging Software Installation
This chapter describes the installation procedure of the Carestream Imaging Software (CSI).
To install the CSI software, follow these steps:
1Insert the Carestream Imaging software DVD-ROM in the DVD-ROM drive of the PC.
The installation wizard is automatically loaded.
2The Installer Language dialog box is displayed. Select the required language and click OK to
continue.
NOTE:
Before installing CS Imaging Software check that:
The computer meets the minimum computer system
requirements. See CS 7200 Safety, Regulatory &
Technical Specifications Guide.
You have the two software DVD-ROMs: one for CS
Imaging Software and the other one for Scanner Driver
Software.
The sleep mode in the computer is disabled.
Note: If the installation wizard is not loaded, run the CSISuiteSetup 1.17 file
located on the installation DVD-ROM.

14 Chapter 3 Setting Up CS 7200
3The Welcome screen is displayed. Click Next to continue.
4The License Agreement screen is displayed. Click I Agree to continue the installation.

CS 7200 User & Installation Guide (6M0940)_Ed04 15
5Click Browse to choose the location for the installation folder or leave the default location and click
Next.
6. Select the components to install and then click Install.
Patient file: is selected by default. You can deselect it, if you do not want the patient database.
7The Practice Management Software Configuration screen is displayed. Click No.

16 Chapter 3 Setting Up CS 7200
Click Ye s only if you use Practice Management Software.
8The Installing wizard screen is displayed. Let the installation process run automatically.
