Carimali Bluedot-s User manual

USER MANUAL

Translation of Original Instructions

TABLE OF CONTENTS

1 GENERAL SAFETY WARNINGS............3

2 IDENTIFICATION .................................... 6

3 INTRODUCTION .....................................7

3.1 SYMBOL DESCRIPTION .............. 7

3.2 USER TYPES ................................7

3.3 INTENDED USE ............................ 8

3.3.1 Reasonably foreseeable

misuse ...................................8

4 DESCRIPTION OF THE MACHINE ........9

4.1 MACHINE CONFIGURATIONS ..... 9

4.2 OUTER COMPONENTS ............. 11

4.3 INNER COMPONENTS...............12

4.3.1 Product containers............... 14

4.4 TFT DISPLAY .............................. 15

4.4.1 Power ON ............................ 15

4.4.2 Boiler - Heating

waiting page ........................ 16

4.4.3 Introduction..........................16

4.4.4 Selection of drinks

to be dispensed ...................17

4.4.5 Hot water dispensing ........... 18

4.4.6 Dispensing in process ......... 18

4.4.7 Dispensing completed ......... 19

4.4.8 Setup menu ......................... 20

5 TECHNICAL FEATURES ...................... 25

5.1 TECHNICAL DATA.......................25

5.2 OVERALL DIMENSIONS.............26

6 RESIDUAL RISKS.................................26

7 HANDLING AND STORAGE................. 27

8 INSTALLATION AND STARTUP...........28

8.1 PACKAGING CONTENTS........... 28

8.2 PRIOR CHECKING

AFTER RECEIPT ........................ 28

8.3 POSITIONING .............................29

8.4. INSTALLATION............................30

8.4.1 Power mains

connection ...........................30

8.4.2 Water mains connection ...... 31

8.4.3 Milk circuit connection ......... 31

9 INSTRUCTIONS FOR USE ...................32

9.1 GETTING STARTED ................... 32

9.1.1 Watertanklling .................. 32

9.1.2 Productlling ....................... 33

9.2 SWITCHING ON..........................34

9.3 DRINK DISPENSING .................. 35

9.3.1 Boilerlling .......................... 35

10 ROUTINE MAINTENANCE ................... 36

10.1 EXTERNAL CLEANING...............37

10.1.1 TFT cleaning........................ 37

10.1.2 Cleaning of

chrome-plated surfaces ....... 37

10.1.3 Cleaning of

machine surfaces ................ 37

10.1.4 Cleaning of solid/liquid

grounds container................ 38

10.1.5 Cleaning of instant products/

coffee bean containers ........ 38

10.2 CLEANING

OF FUNCTIONAL UNITS ............39

10.2.1 Espresso unit cleaning ........ 39

10.2.2 Fresh Brew unit cleaning ..... 41

10.2.3 Mixer cleaning ..................... 42

10.2.4 Cleaning of milk/milk

frother system......................42

11 TROUBLESHOOTING ..........................44

11.1 GROUNDS

DRAWER EMPTYING ................. 45

11.2 WATER TANK FILLING ...............45

12 DISPOSAL ............................................46

1 GENERAL SAFETY

WARNINGS

This manual is integral part of the ma-

chine it is supplied with.

Before proceeding with installation,

use and maintenance of the machine,

the operator is held to read and fully

understand the contents of this man-

ual.

The machine is intended for profes-

sional use. Always strictly follow the

instructions contained in this manual

and keep it in a safe, dry place for fu-

ture reference.

The weighted, equivalent sound pres-

sure level is below 70 dB.

After having unpacked the machine,

verify its integrity. In case of damage

or doubts about the packaging, con-

tact the Service Centre.

Handle the machine with care to pre-

vent the risk of impacts or falls that

may cause damage.

Keep packaging parts (box, inner pro-

tections, etc.) out of reach of children

since they are potentially dangerous.

Do not dump those parts into the en-

vironment, but dispose them accord-

ing to applicable regulations.

NOTE

This symbol on the product or on the

packaging indicates that the product

shall not be treated as household

waste, as it shall be delivered to an

authorised waste collection point for

recycling of electric and electronic de-

vices.

For more detailed information about

recycling of this product, contact the

local authority, the local waste dispos-

al service.

Do not position the machine in close

proximity of water jets or heat sourc-

es. Avoid the direct contact with water

or other liquids also during cleaning.

Do not expose the machine to weath-

er conditions (sun, rain, etc.).

Before plugging the machine in, make

sure the power switch is on “0” posi-

tion.

For electric safety of the machine,

it is necessary to provide a ground-

ing system complete with a residual

current circuit breaker (max IDN =

30mA).

Before connecting the device, make

sure the data on the plate correspond

to the power mains.

The Manufacturer declines any liabili-

ty for failure to comply with the above

or for damages caused by the failure

to properly ground.

Unroll the power cord for its entire

length to prevent the risk of danger-

ous overheating.

The electrical system must be

equipped with an omnipolar switch, in

compliance with the applicable safety

regulations, with contact opening gap

and allowing the complete disconnec-

tion in the conditions of the overvolt-

age category III.

Unplug the machine for any interven-

tion of routine maintenance or check-

ing.

WARNING

Do not pull the pow-

er cord to unplug the

machine from the

electric socket.

The machine can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory

or mental capabilities or lack of ex-

perience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children shall not play with

the machine.

Remove the water tank from the ma-

chinewhenitistobelledorforany

other checking operation.

Never touch the hot parts of the ma-

chine.

Never touch the machine when hands

or other body parts are wet.

Never immerse the machine in water.

The machine delivers high-tempera-

ture drinks. Avoid the risk of burns.

The machine is intended only for the

purpose set forth in this manual. Any

other use is considered as improper.

The Manufacturer declines any liabil-

ity for damage to things and/or per-

sons arising from an improper use of

the machine.

In case of fault or malfunctioning of

the machine, switch it off and unplug.

In case of power cord damage, have

it replaced by the Manufacturer, his

authorized technical Service Centre

or skilled personnel to prevent any

risk.

For repairing, contact only a Service

Centre authorised by the Manufac-

turer and require the use of original

spare parts and accessories. Failure

to comply with the above regulations

could jeopardise machine safety.

For any communication regarding

failures or malfunctioning, contact the

nearest Service Centre, indicating the

model, the type and the serial number

of the machine. The data are shown

on the apposite data plate.

In case the machine is not used any

longer, render it inoperative.

NOTE

When required and in

case of operations not

described in this man-

ual, contact the near-

est Service Centre or

the Manufacturer.

The Manufacturer reserves the right

to carry out technical and aesthet-

ic modications to the machine and/

or this manual for manufacturing or

sales reasons without obligation to

update the previous versions.

Owing to the above, some pictures

contained in this manual may slightly

differ from the actual product.

NOTE

You can access the

latest version of the

manual by registering

on the area for cus-

tomers in the ofcial

website CARIMALI.

2 IDENTIFICATION

3 INTRODUCTION

This manual is a basic component for

the use of the machine. It contains

instructions and information about

handling and usage of the machine in

safety.

3.1 SYMBOL DESCRIPTION

DANGER

It indicates a serious

danger for the opera-

tor that may cause se-

vere injury or death.

ATTENTION

It indicates a poten-

tially dangerous situ-

ation for the operator

that may cause se-

vere injury.

WARNING

It indicates a poten-

tially dangerous situ-

ation that may cause

minor injury or ma-

chine damage.

NOTE

It points out notes or

operation procedures

that helps the oper-

ator when using the

machine.

3.2 USER TYPES

ICON DESCRIPTION

USER

User in charge only of the

simple use of the machine.

FILLING AND MAINTE-

NANCE OPERATOR

User in charge of the lling/

emptying of products and

consumables, as well as

routine maintenance.

SKILLED TECHNICIAN

Skilled operator in charge

of installation, adjustment,

advanced use, and routine

maintenance.

CARIMALI TECHNICIAN

Skilled operator authorized

by the Manufacturer, in

charge of complex opera-

tions.

ATTENTION

Only the CARIMALI

TECHNICIAN or a

SKILLED TECHNI-

CIAN have a shut-

off key, which allows

the access to moving

parts or hot parts.

Be very careful during

the maintenance or

repairing procedures.

3.3 INTENDED USE

The “BLUEDOT” machine was de-

signed and manufactured for dis-

pensing hot drinks, such as:

●Coffee

●Instant products

●Tea

●Milk.

The machine is intended for profes-

sional use, such as:

●Refreshment areas in shops

● Refreshment areas in ofces

●Refreshment areas in other envi-

ronments

●Holiday farms

●Hotels

●Motels

●Bed & Breakfast.

ATTENTION

The machine is not

intended for outdoor

use.

3.3.1 Reasonably foreseeable

misuse

WARNING

In order to ensure

safety of the operator

and the machine, it is

strictly forbidden to

use the machine in a

different manner from

that indicated in this

manual.

4 DESCRIPTION OF THE MACHINE

4.1 MACHINE CONFIGURATIONS

Brewer Fresh

Milk

G S X Water supply

ESPRESSO BREWER

BlueDot-S E 0M 1G 2S 2X WT - WM - WJ

BlueDot-S E 0M 2G 2S 2X WT - WM - WJ

BlueDot-S E 1M 2G 0S 0X WT - WM - WJ

BlueDot-S E 1M 1G 2S 2X WT - WM - WJ

BlueDot-S E 1M 2G 2S 2X WT - WM - WJ

FRESH BREWER

BlueDot-S F 0M 2G 0S 0X WT - WM - WJ

BlueDot-S F 0M 1G 2S 2X WT - WM - WJ

BlueDot-S F 0M 2G 2S 2X WT - WM - WJ

BlueDot-S F 1M 2G 0S 0X WT - WM - WJ

BlueDot-S F 1M 2G 2S 2X WT - WM - WJ

ESPRESSO + FRESH BREWER

BlueDot-S EF 0M 2G 0S 0X WM

BlueDot-S EF 1M 2G 0S 0X WM

TEA BREWER

BlueDot-S T 0M 0G 4S 2X WT - WM - WJ

ESPRESSO + TEA BREWER

BlueDot-S ET 0M 2G 2S 0X WM

BlueDot-S ET 1M 2G 2S 0X WM

Legend:

E: Espresso brewer

F: Fresh Brewer

T: Tea Brewer

EF: Espresso brewer + Fresh Brewer

ET: Espresso brewer + Tea Brewer

M: Milk

S: Instant products / Tea container

G: Grinder

X: Mixer

WT: Water tank

WM: Water connection

WJ: jolly water supply

Optional:

●Water connection

●Jolly water supply (tank + water connection)

● CariPure S water lter

●Premium grinder set

●Premium Self

●Sensor of presence and cup size

●Max Save energy saving

●Aroma fan

●Cup positioning

●Direct coffee discharge

●Modem

●RFiD-NFC

●Wi-Fi

●Coin acceptor + box

Additional units:

●Fridge with digital temperature

●Hot and Cold

4.2 OUTER COMPONENTS

05 Product containers

Upper front door

TFT display

Drink dispensing capacitive keypad / menu

Hot water spout

Dispensing nozzles

Cup support grid

Drip tray

Lower front door

Fresh milk inlet

Power switch

Wiring

Water connection pre-set

Door closing lock

4.3 INNER COMPONENTS

NOTE

The machine can be set up (modular) according to customer’s

requirements. The main components are listed below.

Example of machine with tank (WT) or Jolly (WJ).

Coffee bean containers 1

Coffee bean containers 2

Coffee grinder

Infusion chamber

Grounds drawer

Instant product

container 1

Instant product

container 2

Mixer

Water tank

Example of machine with double unit with water connection only.

Coffee bean container 1

Coffee grinder

Espresso unit

Grounds drawer

Fresh Brew unit

Coffee bean container 2

NOTE

Never ll the containers above the max. level indicated.

4.3.1 Product containers

Capacity: 0.7 Kg / 1.1 l

NOTE

When the container

is lled with the prod-

uct, close the lock

protection; open it af-

ter lling.

Capacity: 0.6 Kg / 1.8 l

NOTE

When the container

is lled with the prod-

uct, close the lock

protection; open it af-

ter lling.

08 - Instant product container

09 - Coffee bean container

4.4 TFT DISPLAY

4.4.1 Power ON

NOTE

If the boiler does not reach the working temperature, when

pressing “Power ON” the “Boiler” page is shown.

Power On

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Enjoy Your Drink !45°

Machine

setup

Time and

date

Variable

message

Dose

setting

Boiler tem-

perature

Machine

alarm

Power ON

User presence

detector

Big / small cup

detector

4.4.3 Introduction

4.4.2 Boiler - Heating waiting page

NOTE

The page is visualized when switching the machine on or

anytime the boiler temperature goes below the minimum drink

dispensing temperature.

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Enjoy Your Drink !45°

98 C°

11:25 |19 Febbraio 2015

Enjoy Your Drink !45°

Temperature

display

Introductory

video

4.4.4 Selection of drinks to be dispensed (example of drinks)

Espresso

Coee creme

Cappuccino

2 Espresso

2 Coee creme

Caelatte

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Drink45°

Milk

with coee

Chocolate

Chocoespresso

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Drink45°

: When this symbol appears the drink delivery is disabled.

Select

drink 2

Select

drink 8

Select

drink 4

Select

drink 10

Select

drink 6

Press to

dispense Hot

Water

Press to

dispense

Hot Water

To next page

Select

drink 1

Select

drink 7

Select

drink 3

Select

drink 9

Select

drink 5

page

It is possible to set up to 4 product pages.

4.4.5 Hot water dispensing

4.4.6 Dispensing in process

Short water dose

Medium water dose

One request

Go back to the drinks

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Hot Water45°

Cappuccino

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Preparing Your Drink...45°

Small water

amount

dispensing

Selected drink

memo

Dispensing

progress bar

Medium water

amount

dispensing

Free water

amount

dispensing

(start/stop)

Return to

drinks

page

4.4.7 Dispensing completed

At the end of dispensing, an acoustic alarm signals that the machine complet-

ed its cycle and is ready for a new dispensing.

Enjoy Your Drink!

Cappuccino

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Enjoy Your Drink !45°

4.4.8 Setup menu - recipe setting

From the “Power ON” page, press the “Dose setting” key to enter the product

page with yellow labels showing the possibility of modify the recipes.

: When this symbol appears the drink delivery is disabled.

Espresso

Long Coee

Capuccino

Long espresso

Coee creme

Medium lter

Coee

11:25 |19 Febbraio 2015

Enjoy Your Drink !45° 11:25 |19 Febbraio 2015

Drink setting45°

17 - Drink setting page (drinks example)

18 - Selection page of setting to modify

Press to

set Long

Espresso

Press to set

Coffee

Crème

Press to

set Medium

lter coffee

Press to set

Espresso

Press to set

Long coffee

Press to set

Cappuccino

To next

page

Press for

exit the cur-

rent screen

Press

for return

to home

“Power on”

screen

Press to

access the

selected

Press to

scroll

the list

Table of contents

Other Carimali Coffee Maker manuals

Carimali

Carimali MULTI SMART Instruction manual

Carimali

Carimali Optima Ultra User manual

Carimali

Carimali ARMONIA SOFT Instruction manual

Carimali

Carimali Multi Smart LM Owner's manual

Carimali

Carimali F10 User manual

Carimali

Carimali F11 Series Owner's manual

Carimali

Carimali Armonia Ultra User manual

Carimali

Carimali CHOCO F Owner's manual

Carimali

Carimali BlueDot 26 Plus User manual

Carimali

Carimali PRATICA1 GR. Guide

Carimali

Carimali CENTO50 Guide

Carimali

Carimali DIVA COF Owner's manual

Carimali

Carimali CENTO 50 User manual

Carimali

Carimali ARMONIA PLUS User manual

Carimali

Carimali CENTO 50 User manual

Carimali

Carimali PRATICA User manual

Carimali

Carimali ARMONIA SOFT PLUS User manual

Carimali

Carimali GENIUS User manual

Carimali

Carimali DIVAPro User manual

Carimali

Carimali DIVA User manual

Carimali

Carimali PRATICA1 GR. Guide

Carimali

Carimali ETA BETA Series Specification sheet

Carimali

Carimali BlueDot Series User manual

Carimali

Carimali ECO LUX E Specification sheet

Popular Coffee Maker manuals by other brands

OBH Nordica

OBH Nordica ADAGIO 1L Instructions for use

SEVERIN

SEVERIN KA4813 operating instructions

Saeco

Saeco GranBaristoAvanti HD8967 user manual

Victoria Arduino

Victoria Arduino Mythos 1 User handbook

Bestron

Bestron ACM8007BE instruction manual

Philips

Philips HD8847 Quick instruction guide

Briel

Briel B14 instruction manual

Scarlett

Scarlett SC-037 instruction manual

SEVERIN

SEVERIN KA 5953 Instructions for use

Aurora

Aurora AU 3140 manual

Siemens

Siemens EQ.7 Plus TE706209 operating instructions

Jura

Jura 761 Instructions for use

Azkoyen

Azkoyen VITRO M5 Technical manual

GeekChef

GeekChef GCF20BP user manual

Fakir

Fakir KAAVE MONO manual

969.Coffee

969.Coffee Mono manual

Saeco

Saeco Minuto HD8763/31 operating instructions

Krups

Krups EA819E Quattro Force manual

Carimali BlueDot-S User manual

Popular Coffee Maker manuals by other brands
