CARNEO TIK&TOK User manual

TIK&TOK

Please read the manual before use.
◆The information in this document won't be modified or
extended in accordance with any notice.
◆The watch should be charging 2 hours at least before use.
1. Caution:
1.1 Waterproof and dustproof
The watch supports waterproof and dustproof. Please follow below
guidelines to maintain the waterproof and dustproof function.
Otherwise your device might be damaged.
·Do not use watch under the strong pressure water.
·Do not use watch when diving, snorkeling or other sports in
turbulent water.
·Please dry your hands or watch fully before operating.
·If the watch is exposed to water, please dry it fully with soft cloth. If
it is exposed to other liquids (such as salt water, pool water, soapy
water, oil, perfume, sunscreen, hand sanitizer) or chemicals (such as
cosmetics), please wash it with clean water and dry it fully with soft
cloth. Do not follow these instructions may damage its performance
and appearance.

·If the watch is dropped or hit, the waterproof and dustproof
function may be damaged.
·Do not disassemble your watch. The waterproof and dustproof
function may be damaged.
·Do not use watch in extremely high or low temperature
environments.
·Do not use blowers and other heated equipment to dry the watch.
·In sauna room, the waterproof function may be damaged.
1.2 Cleaning and management of 019lite2
Follow the below points to ensure that 019lite2 is operating normally
and looks good. Otherwise, maybe damage 019lite2 and cause skin
irritation.
·Protect watch from dust, sweat, ink, oil and chemical products (such
as cosmetics, antibacterial sprays, hand sanitizers, detergents, and
insecticides). Otherwise, the internal and external parts may be
damaged or causes performance degradation. If 019lite2 is stained
with above substances, please clean it with lint-free soft cloth.
·When cleaning 019lite2, do not use soap, detergent, abrasive
materials, compressed air, ultrasonic waves or external heat sources.
Otherwise, 019lite2 may be damaged. Soap, detergent, hand sanitizer,
or detergent residue may cause skin irritation.

·After exercising or sweating, please clean your wrist and strap. Use
water to clean 019lite2 and dip a small amount of alcohol to wipe,
then dry it thoroughly.
·If 019lite2 is stained or infiltrated with other objects, please use wet
soft toothbrush to clean it.
1.3 If you are allergic to material on 019lite2, please
pay attention when using
·Manufacturer conducted testing about hazardous materials on
019lite2 by internal and external certification agency, including
testing of all materials contact skin, skin toxicity testing, and wearing
testing.
·019lite2 contains nickel. If your skin is very sensitive or you are
allergic to the materials on 019lite2, please take necessary
precautions.
–Nickel: 019lite2 contains a small amount of nickel. The content is
lower than the reference value of European REACH regulations. You
will not be exposed to the nickel in 019lite2 and our device has
passed the international certification test. However, if you are allergic
to nickel, please use 019lite2 with caution.
·All materials used on 019lite2 comply with relevant inspection
standards such as REACH and RoHS.

2. Product specification
◆Model:DW-019lite2
◆CPU RTL8762C ARM Cortex-M0 53MHz
◆Memory:RAM 128KB+ ROM 64Mb
◆Capacitive touch screen 1.4” 240*240 pixel IPS
◆Bluetooth version 5.0
◆Function:Games , Heart Rate, Push Dial, Do not disturb, Daily
activity, Sleep, Notification (G-mail, Facebook, Skype, WhatsApp
and so on)
◆Battery Lithium-ion 3.7V/160mAh
3.Product details
3.1 Product details
(1) Power on: When the watch is in the off state, press and hold the
power key for five seconds to turn it on. The home screen of the
watch will be displayed after booting.

(2) Touch screen operation: From the home screen, swipe to the right
to the games list menu, then choose one to play.
(3) Wake up screen: When the watch screen is in the off state , you
can press the power key to wake up the screen. If the Gesture control
button is turned on in the APP, you can also wake up the screen by
turning the wrist.
(4) Shutdown: Click the Setting icon, click System - Shut down, click
to shut down.
4. Products quick into
4.1 Products quick into
(1) Long press the main interface to enter the home page thumbnail.
You can view it left and right, click touch to switch the home page.
(2) Swipe to the right: Display games list -> Jigsaw puzzle, Puzzle game,
Basketball.
(3) Swipe down: Display Battery, Bluetooth, Date, Timer, Brightness,
Setting, Do Not Disturb mode.
(4) Swipe up: Storage information, Heart rate monitoring, Daily
activity.
(5) Swipe to the left: Display the static icon list, click to enter the
corresponding function, right stroke to return to the previous level.

4.2 Clock Display
Setting method:
Power on. When the watch in clock mode, please long press on the
middle screen and set different clock interfaces if you like.
5.Product quick use
5.1 Download and install
You have to download and install the " HitFit Pro " App from APP
Store or Google Play Store:
5.2 Connection and Synchronize data
5.2.1 Bluetooth connection
5.2.1.1 For Android:
Open HitFit Pro App -- Click “Device”in bottom -- “Device Connection”
--Searching Device.

Click OK and Click Pair to bind watch as below.
Open“HitFit Pro”- left swipe menu bar swipe to left - Device - select
the corresponding device icon - search for the corresponding
Bluetooth address pairing
5.2.1.2 For IOS:
Connect step 1: Open“HitFit Pro”app, “Add device ”on “Me”
screen to search Bluetooth devices nearby, find watch name
DW-019lite2 and paired it in app. Once DW-019lite2 connected will
show in the phone's Bluetooth menu screen as below pictures.
Open“HitFit Pro”- left swipe menu bar - Device - select the
-corresponding device icon - search for the corresponding Bluetooth
address pairing.

Connect step 2: Now the Bluetooth menu interface displays
DW-019lite2 connected successfully as below picture shows.
After connected successfully, as shown by the icon on the left.
5.2.2 Synchronizing data
Pair your watch with " Hitfit Pro " App, press " " to sync data.
Your data will be shown on App accordingly.

Notice:
Please don’t shut the Bluetooth notify service when you are clearing
software by background or close background application software. It
will affect the sync function between watch and phone if shut it.
5.3 Basic functions
5.3.1 Daily activity
(1) Function introduction: The watch will display the user's total
number of steps on the day, walking distance, calories burned on the
same day, and the data will be cleared at 0 o'clock (midnight) every
day.
(2) Operation instructions: The main interface swipes left and right
and clicks the motion data to switch to the step counter interface.
After no operation for 5 seconds, the screen is automatically turned
off.

5.3.2 Sports
In sports mode: the single-point function icon allows you to enter
sports modes such as Walking, Running, Climbing, Riding and
Basketball.
5.3.3 Heart rate
(1) Function introduction: The watch will measure the user's heart
rate under the heart rate measurement interface. After the test is
completed, the vibration will display the result. After no operation,
the screen will automatically go out.
(2) Operating instructions: Swipe to the left on the main interface and
click the heart rate static icon to switch to the heart rate
measurement interface. Once the interface is entered, the
measurement will start. During the measurement, the interface value
will be zero. After the measurement is completed, the value will be
displayed. If the result cannot be detected, it will always be displayed.
The display value is zero until standby.
5.3.4 Sleep
(1) Function introduction: The watch will display the user's sleep time

the night before. (Sleep measurement time 21:30 - 12:00 next day)
(2) Operation instructions: Swipe the main interface left and right,
click sleep to switch to the sleep interface, you can view the sleep
time of the previous day.
5.3.5 Weather
After connected with HitFit Pro, the watch will show local weather.
5.3.6 Message
When connected to Bluetooth, notifications from your phone will be
sent to your watch. (You need to open the push switch in the app in
advance)
5.3.7 Music
After connected with the Bluetooth, you can manipulate Mobile to
play music and adjust the volume, voice will come out from mobile
phone.
5.3.8 Timer
Swipe left on the main page and click the stop icon static icon to
switch to the stopwatch interface. Click to start timing. During the
timing, you can pause/start switching with a single touch. Swipe the

stopwatch function to the right of the stopwatch interface and return
to the static function page.
5.3.9 Find phone
When you connect your phone, the phone vibrates and rings when
you click the Find Phone icon.
5.3.10 Relax
Adjust your breathing and relax.
5.3.1 Setting
⚫Language: Including different languages you can choose.
⚫Screen display: Including Change dial, Brightness, Screen
time, Turn wrist wake setting.
⚫Do not disturb: Set enter or exit do not disturb mode.
⚫Vibration: Set vibration intensity.
⚫System: Including System version, Shut down, Reset
settings.
6. Caveat
Please follow the doctor's instructions and measure the results of
self-diagnosis and treatment. Users with blood circulation disorders
and blood diseases should be treated under the guidance of a doctor.
The measurement results of this product are for reference only and
are not intended for any medical use or basis.
