Carrier KC Series User manual

KC_
SERIES
OWNER’S GUIDE
Have a question? Need help?
Call 1-800 CARRIER in the U.S.A. only.
For future reference, fill in the information below and
keep this guide in a safe place. Please keep a copy of
your receipt for warranty purposes. This book is for
73KC_101P and 73KC_121P room air conditioners.
DEALER NAME ___________________________________________________
ADDRESS ________________________________________________________
TELEPHONE _____________________________________________________
MODEL/CATALOG NUMBER _______________________________________
SERVICE DISCRETE NUMBER _____________________________________
SERIAL NUMBER _________________________________________________
PLEASE KEEP A COPY OF YOUR RECEIPT FOR WARRANTY PURPOSES.
CONTENTS
Page
A FEW WORDS ABOUT YOUR NEW AIR
CONDITIONING UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
REQUIRED TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
UNPACK THE AIR CONDITIONER. . . . . . . . . . . . . . 3
WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
POWER SUPPLY CORD . . . . . . . . . . . . . . . . . . . . . . . . 3
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WINDOW INSTALLATION . . . . . . . . . . . . . . . . . . . . . 4
STORM WINDOW APPLICATIONS . . . . . . . . . . . . . 8
WALL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . 9
MASONRY CONSTRUCTION . . . . . . . . . . . . . . . . . . 11
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
REMOTE CONTROL AND PANEL CONTROLS . . 11
ENERGY SAVING TIPS . . . . . . . . . . . . . . . . . . . . . . . 13
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CLEAN FILTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CLEAN FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . 13
CLEAN BASEPAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CARE OF THE REMOTE CONTROL . . . . . . . . . . . . 13
REMOTE CONTROL BATTERY REPLACEMENT . 13
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,15

KC_
SERIES
2
A FEW WORDS
ABOUT YOUR NEW
AIR CONDITIONING UNIT
Thank you for choosing a Carrier room air conditioner
to cool your home or office. In addition to providing
economical cooling comfort, Carrier room air condi-
tioners filter and dehumidify the air in the room.
This owner’s guide will supply all the information you
need to install, operate, and maintain your new air
conditioning unit. Please read the entire manual
before installing the unit. See Fig. 1 for a part identifi-
cation and description of the unit.
REQUIRED TOOLS
•Phillips and flathead screwdrivers
•pencil
•level
•measuring tape
•drill
•1/8-in. drill bit
•scissors
FIGURE 1 — AIR CONDITIONER
SWING
OFF
ON/
MODE
TIMER
FAN
SPEED
F
HR
HR
REMOTE
CONTROLLER
INTERIOR
AIR INLET
GRILLE
CONTROL PANEL EXHAUST AIR
VENT LEVER POWER CORD
EXTERIO
R
AIR INLET
AIR OUTLET
AIR FILTER
CABINET
FRONT PANEL
Power Timer
ModeSwing
Power Saver
Auto
High Low
Mid
Fan Speed
Temp/Time

3
INSTALLATION
Your Carrier room air conditioner was designed to be
installed in a single or double hung window. This air
conditioner is not designed for use with vertical (slider
type) windows.
UNPACK THE AIR CONDITIONER
Handle with air conditioner with care.
Remove and properly dispose of packaging materials.
Remove tape and glue residue from surfaces before
turning on the air conditioner. Rub a small amount of
liquid dish soap over the adhesive with your fingers.
Wipe with warm water and dry thoroughly.
Do not use sharp instruments, rubbing alcohol, flam-
mable fluids or abrasive cleaners to remove tape or
glue. These products can damage the surface of your
air conditioner.
WIRING
The air conditioner is powered by plugging it into a
compatible wall outlet. The electrical outlet MUST
match the plug on the unit power cord. See Table 1 for
receptacle types and fuses. The unit nameplate con-
tains unit electrical data, unit ratings, and identifica-
tion numbers. The unit nameplate is located on the
right side of the unit. Do not use a plug adapter or an
extension cord. The use of a time-delay fuse or time-
delay circuit breaker is recommended.
Check available power supply and resolve any wiring
problems before installing and operating the air condi-
tioner. If wiring is required, all wiring must comply
with all local and national electrical codes. All wiring
must be installed by a qualified electrician. If you have
any questions regarding the unit electrical data or wir-
ing, consult a qualified electrician before installation.
For your safety, this air conditioner is grounded
through the power cord plug when plugged into a
matching wall outlet. The power cord is 60-in. long.
TABLE 1 — RECEPTACLE TYPE AND FUSES
POWER SUPPLY CORD
This room air conditioner is equipped with a protective
power supply cord that senses current leakage. Unit
power is automatically disconnected when unsafe con-
ditions are detected. See Fig. 2.
To test the power supply cord:
1. Plug power supply cord into a grounded 3-prong
outlet.
2. Press RESET.
3. Press TEST (listen for click; RESET button will
trip and pop out).
4. Press and release RESET (listen for click; RESET
button will latch and remain in). The power sup-
ply cord is ready for operation.
The Reset button must be pushed in for proper
operation.
The power supply cord must be replaced if the RESET
button fails to trip when the test button is pressed or
fails to reset. A damaged power supply cord must be
replaced with a new power supply cord obtained from
the product manufacturer. The damaged cord MUST
NOT be repaired.
Do not use the power supply cord as an off/on switch.
The power supply cord is designed as a protective
device.
The power supply cord contains no serviceable parts.
Opening the tamper-resistant case voids all warranty
and performance claims.
EXCESSIVE WEIGHT HAZARD
Use two or more people to move and install air condi-
tioner.
Failure to do so can result in back or other injury.
Electrical shock can cause injury or death. Do not
install unit or remove front grille with the power
cord plugged in. Be sure unit is unplugged before
performing any installation or maintenance.
Plug power supply cord into a grounded 3-prong
outlet. Do not remove ground prong. Do not use an
adapter. Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock.
RECEPTACLE TYPE AND FUSES
VOLTS INDICATED/Hz 125/60
AMPS 15
WALL OUTLET
FUSE SIZE 15
TIME DELAY FUSE
(Circuit Breaker) Plug Type
FIGURE 2 — POWER SUPPLY CORD
TEST
RESET

KC_
SERIES
4
LOCATION
The room air conditioner is designed to fit easily into a
single or double hung window. However, since window
designs vary, it may be necessary to make some modi-
fications for safe and proper installation.
Make sure the window and frame are structurally
sound and free from dry or rotted wood. Replace wood
if necessary or relocate the air conditioner.
For maximum efficiency, install the air conditioner on
the side of the house or building that has more shade
than sunlight.
Provide sufficient clearance for the air conditioner to
allow proper air circulation through and around the
unit. The rear of the unit must be outdoors (not in a
garage or inside of the building). Provide 20-in. of
clearance on each side of the unit. Provide 20-in. of
clearance from the rear of the unit to any obstruction.
Provide 12-in. of clearance from the top of the unit. See
Fig. 3.
Unit should be at least 30-in. above the floor and out-
side ground.
Curtains and other objects should be moved if they
block indoor airflow.
Unit must be within reach of a proper electrical wall
outlet. Do not use an extension cord.
The unit was designed to evaporate condensation
under normal conditions. Under extreme humidity
conditions, excess condensation may cause the
basepan to overflow to the outside of the unit. The unit
should be installed where condensation drip cannot
cause damage.
WINDOW INSTALLATION
To install the room air conditioner in a window, per-
form the following procedure.
1. Check contents of installation hardware package
provided with air conditioner. See Table 2. Make
sure all the items are included.
2. Determine which window will be used for installa-
tion. See Location section on page 3.
3. Check that the window opening dimensions are
suitable for installation. For KC_101P units, the
window must be between 24 and 38-in. wide and
the window must open at least 15-in. high. For
KC_121P units, the window must be between 27
and 41-in. wide and the window must open at
least 16-in. high. It is recommended that the win-
dow sill be at least 5/8-in. thick to support the
weight of the air conditioner. See Table 3 for unit
dimensions.
AWNING
SIDE
OBSTRUCTION
GROUND
FENCE,
WALL, OR
OTHER
OBSTACLE.
12" MIN.
30" MIN.
20"
MIN.
20"
MIN.
FIGURE 3 — AIR CONDITIONER CLEARANCES

5
TABLE 2 —INSTALLATION HARDWARE PACKAGE TABLE 3 —AIR CONDITIONER
CABINET DIMENSIONS
4. For storm windows, open or remove the outer win-
dow before installing the air conditioner. Remove
any screens that are in the window.
5. Remove the front panel of the air conditioner by
removing the side panel screws (one on each side)
and pulling the front panel off the air conditioner
chassis. Save the screws for reinstallation. See
Fig. 4.
6. Remove the chassis security screws from the sides
of the cabinet. Save screws. See Fig. 4. A pull han-
dle is provided for chassis removal. Gently slide
the chassis from the cabinet by pulling on the han-
dle. The chassis is heavy and assistance may be
required. Take care not to bend or damage the coil
fins on the chassis. See Fig. 5.
7. Cut sealing strip (provided) to match length of top
channel. Save remaining seal strip for use in
Steps 14 and 22. Peel and stick one side of the
sealing strip on to the top channel (provided) as
shown in Fig. 6. Use 1/4-in. screws (provided) to
attach top channel to cabinet. Top channel may
require 4 or 5 screws depending on model. See
Fig. 7.
8. Attached the bottom channel (provided) to the bot-
tom of the cabinet. Use four 1/4-in. screws (pro-
vided). Screws are installed from the inside of the
cabinet to the outside to attach the bottom chan-
nel. See Fig. 7.
9. Install the side shutters (provided). The side shut-
ters are identified as right and left on each frame.
Slide the top and bottom shutter frames into the
top and bottom channels on the cabinet. Attach
the shutters to the cabinet using four 1/4-in.
screws (provided). See Fig. 8.
10. Attach the mounting brackets (provided) to the
angle brackets (provided) using two 11/2-in. bolts,
lock washers, and nuts (provided). Two bolts are
used on each bracket assembly. See Fig. 9. Do not
tighten the bolts immediately. It may be neces-
sary to adjust the depth of the bracket assembly,
depending on the window sill. Install the 2 level-
ing screws (provided) onto the bracket assemblies.
See Fig. 9.
11. Test the bracket assembly in the window. See
Fig. 10. Adjust the location of the angle brackets if
necessary. If location of angle brackets is correct
for installation, tighten bolts on assembly. Level-
ing screws should touch the outside wall. If level-
ing screws are too far away from wall, it may be
necessary to shim the area with a solid piece of
wood. See Fig. 11.
12. Measure the width of the inside sill of the window
and mark the center of the sill. The V-slot on the
brackets should be placed 9 5/8-in. from center on
ITEM QTY
3/4-in. Screws 10
1/4-in. Screws 23
Top Channel 1
Bottom
Channel 1
Lock Washers 4
11/2-in. X 1/4-in.
Bolts 4
1/4-in. Nuts 4
Mounting
Brackets 2
Angle
Brackets 2
Shutter
Clamps 2
Left and Right
Side Shutters 1
Sealing Strip 1
Foam 1
End Cap and
Leveling
Screw 2
UNIT WIDTH (in.) LENGTH (in.) HEIGHT (in.)
73KC_101P 20.5 23.1 14.8
73KC_121P 22.8 28.0 15.7

KC_
SERIES
6
both sides for 73KC_101P units. The V-slot on the
brackets should be placed 10 5/16-in. from center
on both sides for 73KC_121P units. See Fig. 12.
Mount the 2 bracket assemblies on the window
sill with a 3/4-in. screw (provided). The holes on
the bracket assemblies must line up with holes in
the bottom of the cabinet for installation.
13. Place a carpenter’s level on the bracket assembly.
Turn the leveling screw on the bracket assembly
until the bracket is slightly tilted down. A slight
pitch will be needed for condensate run off. The
maximum pitch angle should not exceed 3/16 inch.
See Fig. 10.
14. Cut remaining sealing strip (provided) piece to fit
across the bottom of the window sash. See Fig. 13.
After the sealing strip has been cut, remove the
peel-off backing and stick to bottom of window.
Remaining seal strip material is used in Step 22.
15. Center the cabinet in the window. Lower the win-
dow sash until it rests firmly in the upper channel
installed in Step 7. Make sure the top and bottom
of the cabinet fits snugly to the window opening.
Make sure the bottom channel fits into the groove
in the bracket assemblies. See Fig. 14.
16. Secure the cabinet to the brackets using three
1/4-in. screws (provided) for each bracket. Check to
make sure cabinet is angled slightly downward.
Adjust leveling screws if necessary. See Fig. 15.
17. Pull out the expanding side shutters from the
sides of the cabinet. The panels should expand to
cover the entire width of the window. There is a
hole provided in the top end of each side shutter
which is used to secure the panels to the window.
A shutter clamp is also provided to secure the bot-
tom of the shutter to the window sill. With the
wing panels expanded, mark the drilling locations
on the sides of the window frame and sill (through
the holes in the panels).
18. Drill the holes marked in Step 16 with 1/8-in. drill
bit. With the wing panels expanded, secure the
wing panels with two 3/4-in. screws and shutter
clamp provided (each side). See Fig. 16.
19. Slide chassis into cabinet. Be careful not to pinch
or cut your fingers when you are reinstalling the
chassis. Get assistance if necessary. Secure cabi-
net to chassis by installing chassis screws
removed in Step 6.
20. Reinstall the front panel. Make sure all lock tabs
are engaged. Secure front panel to cabinet with
the screws saved from Step 5. Make sure that the
power cord comes out of the unit.
21. Cut foam (provided) to fit the length of the win-
dow. Insert the foam between the top of the lower
window sash and the window panes of the upper
window. See Fig. 17. Make sure there is a firm fit
SIDE PANEL SCREW (EACH SIDE)
CHASSIS SECURITY
SCREW HIDDEN
CHASSIS SECURITY
SCREW (EACH SIDE)
SIDE PANEL
SCREW (HIDDEN)
COIL
PULL HANDLE
CHASSIS
Fig. 2
SEALING
STRIP
" L" SHAPED
TOP CHANNEL
FIGURE 4 — FRONT PANEL REMOVAL
FIGURE 5 — CHASSIS REMOVAL
FIGURE 6 — TOP CHANNEL LOCATION
Cabinet is not secure and may fall out of window.
Be careful with air conditioner until it is secured to
the window.

7
1/4" SCREW
CHANNEL
"U" SHAPED CHANNEL
POSITION
SHUTTER FRAME
RIGHT
SHUTTER
1/4" SCREW
V-SLOT
BRACKET ASSEMBLY
BRACKET BOLTS
LEVELING SCREW
(TOP VIEW)
(SIDE VIEW)
90 ANGLE
SUPPORT
BRACKETS
(2) 3/4" SCREWS PER BRACKET
OUTER WALL CONSTRUCTION
LEVELING SCREW
BRACKET ASSEMBLY
3/16" MAXIMUM
SOLID PIECE WOOD
(IF REQUIRED)
9 5/8"
CENTER
WINDOW SILL
V-SLOT
101P = 9 5/8"
121P = 10 5/16"
9 5/8"
10 5/16"
10 5/16"
WINDOW
SASH
WINDOW SASH
SEALING STRIP
FOAM STRIP
WINDOW SASH
"L"SHAPED
MOUNTING
CHANNEL
FIGURE 7 — TOP AND BOTTOM
CHANNEL INSTALLATION
FIGURE 8 — SIDE SHUTTER INSTALLATION
FIGURE 9 — BRACKET ASSEMBLY
FIGURE 10 — BRACKET LOCATION
AND INSTALLATION
FIGURE 11 — FIELD-SUPPLIED WOOD SHIM
FIGURE 12 — BRACKET LOCATION
ON WINDOW SILL
FIGURE 13 — SEALING STRIP ON
BOTTOM OF WINDOW SASH
FIGURE 14 — CABINET LOCATION

KC_
SERIES
8
to prevent air leakage between the windows. This
also prevents insects from entering through the
window.
22. Some installations may require additional sealing
around the window or air conditioner. Additional
sealing strip material is provided if needed.
23. The unit was designed to evaporate condensation
under normal conditions. Under extreme humid-
ity conditions, excess condensation may cause the
basepan to overflow to the outside of the unit. A
field-supplied drain hose may be installed at the
drain plug if required to route condensate away
from the unit. See Fig. 18.
24. Plug in the unit.
STORM WINDOW APPLICATIONS
If the window is blocked by a storm window and the
storm window cannot be removed, a mounting board
(field provided) will need to be added to the window
sash. The air conditioner needs to be pitched down-
ward to the back in order for condensate to drain prop-
erly. The frame of the storm window (or any other
obstruction) must be at least 1/2-in. lower than the
window sill. If the storm window frame is not at least
1/2-in. below the window sill, then a mounting board
will need to be added to raise the height of the window
sill. See Fig. 19. The board will need to be provided
and cut by the installer.
1. The wood mounting board should be a minimum
of 11/2-in. wide and should run the length of the
window. The thickness of the mounting board is
dependent on the height of the storm window
frame. The mounting board should raise the front
of the air conditioner high enough so that the unit
will be pitched downward at least 5/8-in. when the
back of the unit is resting on the storm window
frame. See Fig. 19.
2. Cut the wood mounting board to fit the window.
3. Install the wood mounting board on the window
using 2 field-provided nails or screws.
4. Drain holes or slots in storm window frame must
not be caulked or painted shut. Holes are needed
to drain rain water and condensate. Ensure that
trapped water can drain out.
FOAM
SEAL
DRAIN HOSE
(NOT INCLUDED)
FIGURE 17 — SASH FOAM LOCATION
FIGURE 18 — FIELD-SUPPLIED DRAIN HOSE
1/4"
SCREWS
COIL
3/4" SCREWS
SECURITY SCREW
SHUTTER
CLAMP SHUTTER CLAMP
FIGURE 15 — CABINET INSTALLATION
FIGURE 16 — SIDE SHUTTER INSTALLATION

9
WALL INSTALLATION
To install the room air conditioner in the wall, perform
the following procedure:
1. Remove air conditioner from shipping box. Do not
install window installation parts (noted in
Table 2).
2. Determine the location for air conditioner. Make
sure there is adequate clearance on the inside and
outside of the wall. Ensure that the power cord
will reach the available socket without an exten-
sion cord. Air conditioner can be installed in walls
up to 7 in. thick. Side louvers must never be
blocked. Select a wall surface that:
•does not support major structural loads such as
the frame construction at ends of windows and
under truss-bearing points
•does not have plumbing or wiring routed inside
•is near existing electrical outlets or near where a
new outlet can be installed
•faces the area to be cooled and is not blocked by
obstructions
•allows unblocked airflow from rear (outside) of
installed air conditioner
3. The following parts will need to be provided by the
installer:
•wood frame
•wood shims
•wood screws (no. 10, 1-in. long)
4. Working from the inside of the room, find a wall
stud nearest the center of the area where the air
conditioner will be installed. This can be deter-
mined by sounding walls or using a stud finder.
5. Cut or knock out a hole on each side of the center
stud. See Fig. 20.
6. Measure between the inside edges of every other
stud as shown in Fig. 20.
7. Follow all local building codes when building and
installing frame. Build a wooden frame that will
be placed around the unit in the wall. The frame
will reinforce the hole in the wall where the air
conditioner is installed and is used to secure the
air conditioner to the wall. The frame should have
an inner dimension of 20.5-in. width by 14.8-in.
height for 73KC_101P air conditioners or 22.8-in.
width by 15.7-in. height for 73KC_121P air condi-
tioners to ensure that the air conditioner will fit
inside the frame. See Fig. 21. The depth of the
frame should approximately match the depth of
the wall. The thickness of the frame will need to
be added to the dimensions to determine the size
of the hole in the wall.
For example, if using 3/4-in. thick wood for the
frame, the hole would need to be:
201/2+ 3/4+ 3/4= 22-in. wide.
8. After the frame has been constructed, check to
make sure that the air conditioner fits correctly
inside it. If the frame is too tight or too loose,
adjust the size or re-construct.
9. Measure the outer dimensions of the frame and
use those dimensions to cut the hole in the wall.
Make sure the hole is level or condensate will not
drain properly.
10. Install wooden frame into hole in wall. Make sure
frame is properly secured. Fill in the space
between the frame and the studs with wood shims
(spacers). Nails spacers to studs. If required, pro-
vide studs around entire frame to reinforce stabil-
ity of wall. See Fig. 22.
IMPORTANT: Read entire instructions before cut-
ting hole in wall.
IMPORTANT: Be sure to measure air conditioner
to check size before constructing frame.
IMPORTANT: If thickness of the wall covers top
and side vents of the air conditioner when it is
installed, the outer portion of the wall opening
must be widened. The top and side vents must be
clear and uncovered.
FIGURE 20 — WALL INSTALLATION
LOCATION
FIGURE 19 — STORM WINDOW APPLICATIONS

KC_
SERIES
10
11. Caulk joints in wood frame as required. If wall
thickness is 7-in. or more, add aluminum flashing
over bottom of frame opening to ensure no water
can enter area between inner and outer wall.
12. Remove the chassis from the unit cabinet.
13. Slide the empty cabinet into the wall opening and
into wooden frame. Approximately 21/2in. of the
cabinet should be in the room. The rest of the cab-
inet should be positioned through and outside the
wall. See Fig. 23. Maintain proper slope for con-
densate drain operation. Bottom rail should be
resting firmly on bottom board of wooden frame.
14. Secure bottom rail to wood frame with two large
wood screws (1-in. long) using the two holes in the
bottom of the channel. See Fig. 24.
15. There are screw holes in the cabinet (4 each side,
4 top) which are used to secure the cabinet to the
wooden frame. With the cabinet in its final posi-
tion, drill holes in the wooden frame using the
screw holes in the cabinet as a guide. After the
holes have been drilled, secure the cabinet to the
wooden frame using field-supplied screws. See
Fig. 25.
16. Caulk around wood frame and wall opening on
outside wall for a water-tight seal.
17. Optional caulking between the cabinet and the
wooden frame may be done on inside wall. Caulk-
ing provides an air seal around the cabinet. Deco-
rative wood trim may be added to provide a more
pleasing appearance.
18. Lift chassis and carefully slide it into the cabinet.
Be sure that it is firmly seated towards the rear of
the cabinet.
19. Install the front panel.
20. Plug in the unit.
Be careful when handling chassis. Sharp edges on
coil fins can cause personal injury.
Do not push on the controls or the coil when
installing chassis. Damage to unit or personal
injury could result.
FIGURE 21 — FRAME CONSTRUCTION
UNIT
73KC_
DIMENSIONS (in.)
AB
101P 14.8 20.5
121P 15.7 22.8
FIGURE 22 — FRAME INSTALLATION
FIGURE 23 — CABINET LOCATION
IN WALL

11
MASONRY CONSTRUCTION
The air conditioner is installed the same way as the
Wall Installation section with a few exceptions. Follow
all local and national building codes.
The cabinet can be secured to the masonry by using
masonry nail or masonry anchor screws.
Another installation technique would be to construct a
frame of 2 x 4s and install the frame between the wall
opening and the cabinet. The frame must be securely
anchored to the masonry wall opening.
Use a lintel to support masonry above wall opening.
Install exterior cabinet support brackets.
OPERATION
An electronic-type control is used on your Carrier air
conditioner. The electronic control consists of a control
panel and a remote control. Both the control panel or
the remote control can be used to set cooling and fan
modes and adjust the desired temperature. See
Fig. 26. Other additional features are provided.
REMOTE CONTROL AND
PANEL CONTROLS
Either the remote control or the control panel on the
air conditioner can be used. The battery of the remote
control will need to be installed before it can be used.
To operate the room air conditioner with the remote
control, aim the remote control to the signal receptor.
(See Fig. 25.) The remote control will operate the air
conditioner at a distance of up to 23 feet when pointing
at signal receptor of the unit.
■TURN UNIT OFF/ON — Press the POWER button
on the remote control or the ON/OFF button on the
control panel.
NOTE: To switch from Celsius to Fahrenheit, press the
UP ARROW and DOWN ARROW buttons on the con-
trol panel (not the remote control) at the same time.
■COOLING MODES — Each time the MODE button
is pressed, three different operation modes are
changed in sequence - Cooling, Fan Only, or Energy
Saving. Press the MODE button to select the cooling
mode.
In Cooling mode, the air conditioner will run and
provide cooling. The amount of cooling can be adjusted
with the FAN SPEED button on the control panel. The
fan speed will be indicated by the lighted symbol on
the control panel. See Fig. 26. To change the fan speed
on the remote control, press the HIGH, MID or LOW
buttons. If the fan speed is set to Auto mode, the fan
speed adjusts automatically from low to high based on
the setting of the thermostat and the actual room
temperature.
In Fan Only mode, the fan operates to circulate the air
in the room, but there is no cooling operation. This
mode is used to circulate the air in the room when
cooling is not required. The amount of circulation can
be adjusted with the FAN SPEED button on the con-
trol panel. Auto cannot be selected in Fan Only mode.
NOTE: When changing modes during operation, the
unit may not respond immediately. Wait 3 minutes
before attempting to switch modes or restarting the
unit.
■ENERGY SAVING MODE — When the air condition-
ing unit is Energy Saving mode and the Auto fan
speed is selected, the air conditioner will automati-
cally switch from Cooling to Fan Only mode when cool-
ing is not required. When the air conditioning unit is
Energy Saving mode and the low, medium or high fan
speed is selected, the air conditioner will run in Cool-
ing mode if the room temperature is 2 degrees higher
than the thermostat setting. When the room tempera-
ture is lower than 66 F (19 C), the unit will turn off (no
cooling or fan).
The Energy Saving mode can be selected from the
remote control by pressing the POWER SAVER
button.
■FAN SPEED — The air conditioner Fan mode can be
set to High, Medium, Low, or Auto. Press the FAN
SPEED button on the control panel to select the fan
speed. The fan speed will be indicated by the lighted
FIGURE 24 — SECURING BOTTOM RAIL OF
CABINET
FIGURE 25 — SECURING CABINET
TO FRAME

KC_
SERIES
12
symbol on the control panel. See Fig. 26. To change the
fan speed on the remote control, press the HIGH, MID
or LOW buttons.
High fan mode is recommended for very warm days or
when a fast initial cooling of the room is desired.
Medium fan mode is recommended on moderately warm
days or when the unit has been operating for some time
and the temperature is about to reach its desired set-
ting. Low fan mode is recommended on slightly warm
days or after the room temperature has reached its
desired setting. Auto mode adjusts the fan speed auto-
matically from low to high based on the setting of the
thermostat and the actual room temperature.
NOTE: When changing modes during operation, the
unit may not respond immediately. Wait 3 minutes
before attempting to switch modes or restarting the
unit.
■THERMOSTAT — The temperature setting on the
thermostat can be adjusted from a range of 66 to 88 F
(19 to 31 C). The air conditioner will start and stop
cooling operation in order to maintain the temperature
setting of the thermostat.
Press the DOWN ARROW button on the control panel
to lower the temperature setting; press the UP
ARROW button to raise the temperature setting.
When using the remote control, press the “-” button to
lower the temperature; press the “+” button to raise
the temperature setting.
■TIMER MODE — Your Carrier air conditioner unit
can be programmed so that the unit will shut off after
a certain number of hours (if operating) or turn on
after a certain number of hours (if off).
Press the TIMER button to start the Timer mode. The
number of hours will start at 0. The range is 0 to
24 hours.
If the unit is operating, the number of hours until the
unit will turn off will be displayed. If the unit is off,
the number of hours until the unit will turn on will be
displayed. Use the UP and DOWN ARROW buttons on
the control panel to change the number of hours. When
using the remote control, press the “-” and “+” buttons
to change the number of hours.
Press the TIMER button again to cancel Timer mode.
■SWING BUTTON — The SWING button is used to
start or stop the vertical air vanes from swinging back
and forth.
■EXHAUST AIR VENT LEVER — When the lever is
pushed down, the unit will circulate room air. When
the lever is pushed up, some of the room air is
exhausted to the outside.
FIGURE 26 — CONTROL PANEL AND REMOTE CONTROL
CONTROL PANEL REMOTE CONTROL
SWING
FAN
SPEED
TIMER MODE
ON/OFF
HR
F
SIGNAL RECEPTOR
Auto fan speed
Low fan speed
Medium fan speed
High fan speed
Cooling
Fan only
Timer
Energy-saving
HR
F
Display set temp
Display set time
r
Power Timer
Mode Swing
Power Saver
Auto
High Low
Mid
Fan Speed
Temp/Time

13
ENERGY SAVING TIPS
Your Carrier air conditioner is designed to operate
efficiently and save on energy costs. Follow these
recommendations for even greater energy savings:
•Select the warmest thermostat setting that will suit
your comfort needs and leave the thermostat at that
setting.
•Keep the air filter clean (clean approximately every
30 days).
•Use drapes, curtains, or shades to keep direct sun-
light from heating the room.
•Do not obstruct the front panel air intake. Do not
obstruct the top air discharge. Allow air to circulate
freely around the air conditioner.
•Start your air conditioner before outdoor tempera-
ture, cooking heat, or groups of people make the
room hot and uncomfortable. This avoids an initial
period of discomfort while the air conditioner is cool-
ing the room.
•When outdoor temperature is cool enough, use the
FAN ONLY setting. This circulates indoor air, pro-
vides comfort, and utilizes less electricity than when
operating in cooling modes.
MAINTENANCE
When servicing the air conditioner, make sure the
mode is set to OFF and the unit is unplugged from the
electrical outlet.
CLEAN FILTER
Normally, the air filter should be cleaned every
30 days. The filter is highly efficient in removing air-
borne particles. More frequent cleaning may be
required in areas with low outdoor and indoor air
quality.
To remove the filter, grasp the filter handle tabs on
the right center of the front inlet grille and slide the
filter out to the right. The filter may be vacuumed or
washed by hand in warm water. Use of a mild deter-
gent is recommended. Dry the filter thoroughly after
washing. Replace the air filter by sliding it back into
the filter slot. Do not operate unit without filter in
place.
CLEAN FRONT PANEL
The front panel may be cleaned after it is removed
from the air conditioner. Wash the panel by hand with
warm water and a mild soap. Be sure to thoroughly
dry the panel before reinstalling. Never pour water
directly on the unit. Do not use gasoline, thinner, or
other chemicals to clean unit.
CLEAN BASEPAN
The basepan may need to be cleaned if there is a build-
up of mold, mildew, or algae that could cause unpleas-
ant odors. When outdoor humidity is high, condensate
may not fully evaporate from basepan during normal
operation. To clean the basepan, run the air condi-
tioner in Fan Only mode for 4 to 6 hours to remove
condensate. Remove the front panel. Use bleach or
other cleaner to remove mold, mildew, or algae from
basepan. Replace front panel.
CARE OF THE REMOTE CONTROL
The remote control should last indefinitely with proper
care. Do not expose the remote control to direct heat.
Do not spill liquids or place heavy objects on the
remote control. Make sure the signal from the remote
control to the air conditioner is unobstructed.
REMOTE CONTROL BATTERY
REPLACEMENT
If the remote control stops working or if the display
becomes dim, the batteries should be replaced. Use 2
AAA (1.5 volt) batteries. Do not use rechargeable bat-
teries. Do not mix old batteries with new ones.
To replace the battery, find the small tab on the back
of the remote control. See Fig. 27. With a fingernail or
screwdriver, slide out the battery cover using the tab.
Remove and recycle the old batteries. Insert the new
batteries, ensuring that the (+) and (-) of the batteries
are matched correctly. Gently slide the battery cover
back into the remote control.
NOTE: If battery replacement is done within 1
minute, the remote control will keep its original pre-
settings.
FIGURE 27 — BATTERY REPLACEMENT

KC_
SERIES
14
TROUBLESHOOTING
NOTE: If circuit breaker is tripped repeatedly or fuse is blown more than once, contact a qualified electrician.
See Fig. 28 for wiring diagram.
PROBLEM CAUSE SOLUTION
UNIT DOES NOT START Unit may have become unplugged. Check that unit is securely plugged into the wall
socket.
Fuse may have blown. Replace fuse. See Note.
Circuit breaker may have tripped. Reset circuit breaker. See Note.
Unit mode may be set to OFF. Check to make sure Cooling mode is selected.
UNIT NOT PROVIDING ENOUGH
COOLING Unit airflow is blocked. Remove any curtains, blinds, or furniture that may be blocking indoor airflow. Check outdoor airflow and
remove any blockage to outdoor airflow.
Thermostat temperature setting is too high. Reset thermostat to a lower (cooler) temperature.
Unit air filter is dirty. Remove and clean air filter.
Room was excessively hot when cooling oper-
ation started. Allow sufficient time for unit to cool room.
Compressor Overload tripped. Let fan run for approximately 10 minutes to reset
compressor overload and restart compressor.
UNIT MAKING NOISES Normal operation. Low clicking, bubbling, or whooshing noises are nor-
mal during operation of the unit.
Loose parts. Tighten loose parts.
Inadequate support. Provide additional support to unit.
UNIT ODORS Formation of mold, mildew, or algae on wet
surfaces. Remove drain plug and drain condensate from unit. Clean base pan.
WATER DRIPPING OUTSIDE Normal operation. Condensation runoff during hot and humid weather
is normal. A field-supplied drain hose can be
installed if required.
WATER DRIPPING INSIDE Unit is not installed at proper angle. Unit must be tilted slightly outside for proper runoff of
condensation. Check that installation is correct and
make necessary adjustments.
ICE OR FROST BUILD-UP ON COIL Unit air filter is dirty. Remove and clean air filter.
Low outside temperature. When outdoor air is approximately 65 F (18 C) or
below, frost may form when unit is in Cooling mode.
Switch unit to Fan Only mode until ice or frost melts.

15
LEGEND
FIGURE 28 — SCHEMATIC DIAGRAM; MODELS KC_101P AND KC_121P
CN — Connection RY — Relay

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
02-73KC0002-OM Printed in USA Form OM73KC-2 Pg 16 12-05 Replaces: OM73KCA-2
Book 1 4
Tab 8a 10a
Copyright 2005 Carrier Corporation
Carrier Room Air Conditioner Full Warranty
ONE YEAR WARRANTY — CARRIER warrants to the user that this product will be free from defects of workmanship under normal
use and maintenance for a period of one year from the date of original purchase. CARRIER, through its authorized independent servic-
ing dealers or service stations, will either repair or replace a defective product (as decided solely by CARRIER) free of charge to the
user.* CARRIER may replace any defective part with either a new or remanufactured part, at CARRIER’s sole option.
EXTENDED FOUR YEAR WARRANTY ON SEALED REFRIGERATION SYSTEM ONLY — During the second through fifth years
after date of original purchase, CARRIER further warrants to the user that the compressor, condenser, evaporator, and connecting
tubing will be free from defects in material or workmanship under normal use and maintenance. CARRIER will either repair or replace
(as decided solely by CARRIER) any defective compressor, condenser, evaporator or connecting tubing free of charge to the user,
including a recharge of refrigerant for the system if necessary. However, THIS LIMITED WARRANTY DOES NOT INCLUDE costs
incurred for diagnosing, removing, installing, shipping or transporting the product or any parts. User is responsible for these costs;
however, SUCH COSTS MAY BE COVERED by a separate warranty or service agreement provided by the seller or another third
party, such agreement being separate and distinct from this factory warranty.
LIMITATION OF WARRANTIES — ALL IMPLIED WARRANTIES (INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY LIMITED IN DURATION TO THE PERIOD FOR WHICH THE
APPLICABLE PRODUCT COMPONENT IS EXPRESSLY WARRANTED HEREIN. Some states or provinces do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you. THE EXPRESS WARRANTIES MADE IN THIS
WARRANTY ARE EXCLUSIVE AND MAY NOT BE ALTERED, ENLARGED OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR
OTHER PERSON WHATSOEVER. CARRIER WILL NOT BE RESPONSIBLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUEN-
TIAL PROPERTY OR COMMERCIAL DAMAGES OF ANY NATURE WHATSOEVER. Some states or provinces do not allow the
exclusion of incidental or consequential damages, so the above limitation may not apply to you. All work provided for by this warranty
shall be performed during normal working hours. All replacement parts, whether new or remanufactured, assume as their warranty
period only the remaining time period for which the applicable component is expressly warranted herein.
*Authorized independent dealers or service stations are registered with CARRIER through its distributor organization.
CARRIER WILL NOT BE RESPONSIBLE FOR:
1. Damage due to failure to perform normal maintenance outlined in the Owner’s Guide.
2. Instruction on methods of control and use of air conditioning unit after initial installation.
3. Damage or repairs needed as a consequence of faulty installation or application. This is the responsibility of the installer.
4. Failure to start due to voltage conditions, blown fuses, open circuit breakers, or any other damages due to the inadequacy or inter-
ruption of electrical service.
5. Damage or repairs needed as a consequence of any misapplication, abuse, unauthorized alteration, improper servicing or
operation.
6. Damage as a result of floods, winds, fires, lightning, accidents, corrosive environments, or other conditions beyond the control of
CARRIER.
7. Any parts not supplied or designated by CARRIER.
8. CARRIER products installed outside the continental U.S.A., Alaska, Hawaii, and Canada.
9. Shipping damage or damage as a result of storing or transporting the unit.
This warranty gives you specific rights, and you may also have other rights which vary from state to state or province to province.
IF YOUR UNIT DOES NOT WORK, FOLLOW THESE STEPS IN ORDER:
1. Check the things you can do yourself. These include being sure the air conditioner is plugged in an appropriate receptacle, check-
ing the fuse or circuit breaker and ensuring its replacement or resetting, if necessary, and rereading the instruction book to ensure
all controls are set properly. By doing this you can save money. Many unnecessary calls result in the serviceman doing what the
owner can do for himself.
2. CONTACT YOUR DEALER ON THE CARRIER AUTHORIZED SERVICE CENTER. You may find this name printed on the prod-
uct, on your invoice, or in your Homeowner’s Packet.
3. CONTACT THE NEAREST CARRIER DISTRIBUTOR SERVING YOUR AREA. (See Telephone Yellow Pages.)
4. CONTACT CARRIER IF A SATISFACTORY SOLUTION IS NOT REACHED IN STEPS 2 AND 3.
Carrier Air Conditioning Consumer Relations Department, P.O. Box 4808, Carrier Parkway, Syracuse, New York 13221
Telephone: 1-800-CARRIER From Canada: [phone]
FOR FUTURE REFERENCE, FILL IN DETAILS OF YOUR PURCHASE. KEEP YOUR SALES RECEIPT.
Model/Catalog No. ________________________________ Installed By: _________________________________
Service/Discrete No. _______________________________ Name of Owner ______________________________
Unit Serial No. ____________________________________ Address of Installation _________________________
Date of Installation ________________________________
KC_
SERIES

KC_
SÉRIE
GUIDE DU PROPRIÉTAIRE
Vous avez une question ? Vous avez besoin d’aide ?
Aux États-Unis seulement, composez le 1 800 CARRIER.
Remplissez les informations ci-dessous et conservez ce
guide dans un endroit sûr pour consultation ultérieure.
Veuillez conserver une copie de votre facture pour
bénéficier de la garantie. Ce guide concerne les
climatiseurs individuels 73KC_101P et 73KC_121P.
NOM DU DISTRIBUTEUR___________________________________________
ADRESSE _________________________________________________________
TÉLÉPHONE ______________________________________________________
NUMÉRO DE MODÈLE/CATALOGUE_________________________________
NUMÉRO DE SERVICE UNIQUE _____________________________________
NUMÉRO DE SÉRIE ________________________________________________
VEUILLEZ CONSERVER UNE COPIE DE VOTRE FACTURE POUR BÉNÉFICIER DE
LA GARANTIE.
TABLE DES MATIÈRES
Page
À PROPOS DE VOTRE NOUVEL APPAREIL DE
CLIMATISATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
OUTILS NÉCESSAIRES . . . . . . . . . . . . . . . . . . . . . . . . . 18
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-27
DÉBALLAGE DU CLIMATISEUR . . . . . . . . . . . . . . . 19
CÂBLAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
CORDON D’ALIMENTATION . . . . . . . . . . . . . . . . . 19
EMPLACEMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
IINSTALLATION À LA FENÊTRE . . . . . . . . . . . . . . 20
APPLICATIONS AVEC UNE CONTRE-FENÊTRE. 24
INSTALLATION MURALE. . . . . . . . . . . . . . . . . . . . . 25
OUVRAGE DE MAÇONNERIE . . . . . . . . . . . . . . . . . 27
FONCTIONNEMENT . . . . . . . . . . . . . . . . . . . . . . . . .27-29
TÉLÉCOMMANDE ET PANNEAU DE COMMANDE 27
CONSEILS D’ÉCONOMIE D’ÉNERGIE . . . . . . . . . . 29
Page
ENTRETIEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29,30
NETTOYAGE DU FILTRE . . . . . . . . . . . . . . . . . . . . . . 29
NETTOYAGE DU PANNEAU AVANT. . . . . . . . . . . 29
NETTOYAGE DU BAC DE CONDENSATION . . . . 29
ENTRETIEN DE LA TÉLÉCOMMANDE. . . . . . . . . . 29
REMPLACEMENT DE LA PILE DE LA
TÉLÉCOMMANDE . . . . . . . . . . . . . . . . . . . . . . . . . . 30
DÉPANNAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31,32

KC_
SÉRIE
18
À PROPOS DE VOTRE
NOUVEL APPAREIL DE
CLIMATISATION
Merci d’avoir choisi un climatiseur individuel Carrier
pour rafraîchir votre maison ou votre bureau. En plus de
fournir le confort de la climatisation à un prix abordable,
les climatiseurs individuels Carrier filtrent et
déshumidifient l’air ambiant.
Ceguidedupropriétairecontienttouteslesinformations
dont vous avez besoin pour installer, faire fonctionner et
entretenir votre appareil de climatisation. Veuillez lire
le manuel en entier avant d’installer l’appareil.
Consultez la Figure 1 pour l’identification des pièces et
la description de l’appareil.
OUTILS NÉCESSAIRES
• tournevis Phillips et à tête plate
• crayon
• niveau à bulle d’air
• ruban de mesure
• perceuse
•foret
1/8 po (0,3125 cm)
•ciseaux
FIGURE 1 — CLIMATISEUR
SWING
OFF
ON/
MODE
TIMER
FAN
SPEED
F
HR
HR
TÉLÉCOMMANDE
GRILLE
D’ENTRÉE
D’AIR INTÉRIEUR
PANNEAU DE COMMANDE LEVIER
D’EVACUATION
D’AIR
CORD D’ALIMENTATION
ENTRÉE D’AIR
EXTÉRIEUR
SORTIE D’AIR
FILTRE D’AIR
CAISSON
PANNEAU AVANT
Power Timer
ModeSwing
Power Saver
Auto
HighLow
Mid
FanSpeed
Temp/Time

19
INSTALLATION
VotreclimatiseurindividuelCarrieraétéconçupourêtre
installé dans une fenêtre à guillotine simple ou double.
Cet appareil de climatisation n’est pas conçu pour être
utilisé avec des fenêtres coulissantes.
DÉBALLAGE DU CLIMATISEUR
Manipulez le climatiseur avec précaution.
Retirezetjetezlesmatériauxd'emballagedanslerespect
des réglementations en vigueur. Enlevez les résidus de
ruban adhésif et de colle des surfaces externes du cli-
matiseur avant la mise en marche. Placez une petite
quantité de liquide vaisselle sur les résidus d'adhésifs et
frottezavec vosdoigts.Rincezavec un tissu imbibé d'eau
chaude et séchez les surfaces.
N'utilisez pas d'instruments pointus, d'alcool dénaturé,
deliquidesinflammablesoudesnettoyantsabrasifspour
enlever le ruban adhésif ou les traces de colle. Ces
produits peuvent endommager les surfaces de votre
climatiseur.
CÂBLAGE
Le climatiseur est mis sous tension lorsque vous le
branchez à une prise de courant murale compatible. La
prise de courant DOIT correspondre à la fiche du cordon
d’alimentationdel’appareil.ConsultezleTableau1pour
les types de prises et de fusibles. La plaque signalétique
de l’appareil comprend ses données électriques, son
calibre et ses numéros d’identification. La plaque
signalétique se trouve sur le côté droit de l’appareil.
N’utilisez pas une prise de courant à fiches ou une
rallonge électrique. L'utilisation d'un fusible temporisé
ou d'un disjoncteur temporisé est recommandée.
Vérifiez l’alimentation disponible et résolvez tous les
problèmes de câblage avant d’installer et de faire
fonctionner l’appareil de climatisation. Si le câblage est
nécessaire, il doit respecter les codes de l’électricité
locauxet nationaux.Toutlecâblagedoitêtreinstallépar
un électricien qualifié. Si vous avez des questions à
propos des données électriques ou du câblage de
l’appareil, consultez un électricien qualifié avant
l’installation.
Pour votre sécurité, cet appareil de climatisation est mis
à la terre par l’entremise de la fiche du cordon
d’alimentation lorsque cette dernière est insérée dans
une prise de courant murale correspondante. Le cordon
d’alimentation mesure 1,5 mètres.
TABLEAU 1 — TYPES DE PRISES ET DE FUSIBLES
CORDON D'ALIMENTATION
Ce climatiseur individuel est équipé d'un cordon d'ali-
mentationprotégéquidétectelesfuitesde courant.L'ali-
mentationélectriquede l'appareilest automatiquement
interrompue lorsque des conditions dangereuses sont
détectées. Consultez la Figure 2.
Pour réinitialiser le cordon d'alimentation :
1. Branchez le cordon d'alimentation dans une prise
murale à trois broches.
2. Appuyez sur le bouton RESET (réinitialisation).
3. Appuyez sur le bouton TEST (vous devez entendre
un clic, le bouton RESET se déclenche et est
éjecté).
4. Appuyez sur le bouton RESET puis relâchez (vous
devez entendre un clic, le bouton RESET
s'enclenche et reste enfoncé). Le cordon d'alimen-
tation est maintenant prêt pour le fonctionne-
ment.
LeboutonRESET(réinitialisation)doitêtreenfoncépour
que le cordon fonctionne normalement.
Le cordon d'alimentation doit être remplacé si le bouton
RESET n'est pas éjecté lorsque vous appuyez sur le bou-
ton de test ou s'il ne se réinitialise pas. Si le cordon d'ali-
mentation est endommagé il doit être remplacé par un
cordon neuf identique que vous devez vous procurer
auprès du fabricant. Le cordon d'alimentation endom-
magé NE DOIT PAS être réparé.
N'utilisez pas le cordon d'alimentation comme un inter-
rupteur marche/arrêt. Le cordon d'alimentation est
conçu pour jouer le rôle d'un dispositif de protection.
Le cordon d'alimentation ne contient aucune pièce répa-
rable. L'ouverture du boitier du cordon d'alimentation
RISQUE LIÉ AU POIDS DE L'APPAREIL
La coopération d'au moins deux personnes est
nécessaire pour le déplacement et l'installation du
climatiseur.
Le non respect de cette recommandation peut
entrainer des blessures au dos, entre autres.
Unchocélectriquerisquedeprovoquerdesblessures,
voire la mort. N’installez pas l’appareil et ne retirez
pas la grille avant lorsque le cordon d’alimentation
est branché. Assurez-vous de bien débrancher
l’appareil avant de l’installer ou de procéder à
l’entretien.
Branchez la fiche du cordon d'alimentation dans une
prisemurale àtrois broches avecprisede terre.N'uti-
lisez pas de convertisseur. N'utilisez pas de rallonge
électrique.Lenonrespectdecesinstructionspourrait
entrainer la mort, un incendie, ou un choc électrique.
TYPES DE PRISES ET DE FUSIBLES
VOLTS INDIQUÉS/Hz 125/60
AMPÈRES 15
PRISE MURALE
CAPACITÉ DU FUSIBLE 15
FUSIBLE TEMPORISÉ
(Disjoncteur) Type de fiche

KC_
SÉRIE
20
annule la garantie et peut entrainer une réduction des
performances de protection du cordon.
EMPLACEMENT
Le climatiseur individuel est conçu pour être installé
dansunefenêtreàguillotinesimpleoudouble.Toutefois,
en raison des différents types de fenêtres, il peut être
nécessaire d’apporter certaines modifications pour
s’assurer d’une installation sûre et adéquate.
Assurez-vous que les structures de la fenêtre et du cadre
sont solides et exemptes de bois sec ou pourri. Au besoin,
remplacez le bois ou déplacez le climatiseur.
Pour une efficacité maximale, installez l’appareil de
climatisation sur le côté de la maison ou du bâtiment le
plus ombragé.
Prévoyezundégagementsuffisantautourduclimatiseur
pour permettre une circulation d’air adéquate tant à
l’intérieur qu’à l’extérieur de l’appareil. La face arrière
de l’appareil doit se trouver à l’extérieur (et non dans un
garage ou à l’intérieur du bâtiment). Prévoyez un
dégagementde50cm(20po)dechaquecôtéde l’appareil.
Prévoyez un dégagement de 50 cm (20 po) entre la face
arrière de l’appareil et tout obstacle. Prévoyez un
dégagement de 30 cm (12 po) au-dessus de l’appareil.
Consultez la Figure 3.
L’appareildoitsetrouveràun minimumde 75cm(30 po)
du sol, à l’intérieur comme à l’extérieur.
Les rideaux et autres objets doivent être déplacés s’ils
entravent la circulation d’air à l’intérieur.
L’appareil doit se trouver à proximité d’une prise de
courant murale adéquate. N’utilisez pas de rallonges
électriques.
L’appareil a été conçu pour permettre l’évaporation de
la condensation dans des conditions normales. Dans des
conditionsd’humiditéextrême,unexcèsdecondensation
risque de faire déborder le bac de condensation.
L’appareil doit être installé dans un endroit où
l’égouttement de la condensation ne peut causer de
dommages.
INSTALLATION À LA FENÊTRE
Pourinstallerleclimatiseurindividueldansunefenêtre,
procédez comme suit :
1. Vérifiez le contenu pour trouver le matériel
d’installation compris avec l’appareil de
climatisation. Consultez le Tableau 2. Assurez-
vous que tous les articles sont inclus.
2. Choisissez la fenêtre à utiliser pour l’installation.
Consultez la section « Emplacement » ci-dessus.
3. Vérifiez que les dimensions de l’ouverture de la
fenêtre permettent l’installation. Pour les
appareils KC_101P, la fenêtre doit mesurer entre
60 et 95 cm (24 et 38 po) de largeur, et la fenêtre
doit ouvrir à une hauteur d’au moins 37, 5 cm
(15 po). Pour les appareils KC_121P, la fenêtre
doit mesurer entre 67,5 et 102,5 cm (27 à 41 po) de
largeur, et la fenêtre doit ouvrir à une hauteur
d’au moins 40 cm (16 po). Nous recommandons un
appui de fenêtre d’une épaisseur d’au moins 5/8po
(1,56 cm) pour supporter le poids du climatiseur.
Consultez le Tableau 3 pour obtenir les
dimensions de l’appareil.
4. Pour les contre-fenêtres, ouvrez ou enlevez la
contre-fenêtre extérieure avant d’installer le
climatiseur. Enlevez les moustiquaires de la fenêtre.
5. Enlevez le panneau avant du climatiseur en
retirant les vis du panneau latéral (une de chaque
côté). Tirez ensuite sur le panneau avant pour le
dégager du bâti du climatiseur. Gardez les vis
pour la réinstallation. Consultez la Figure 4.
6. Enlevez les vis de sécurité du bâti situés sur les
côtés du caisson. Conservez les vis. Consultez la
Figure 4. Une poignée vous permet de retirer le
bâti. Faites glisser délicatement le bâti du caisson
en tirant sur la poignée. Le bâti est lourd; il se peut
que vous ayez besoin d’aide. Prenez garde de ne pas
plier ni endommager les ouvertures de ventilation
situées sur le bâti. Consultez la Figure 5.
7. Coupez la lisière à calfeutrer (comprise) pour
qu’elle corresponde à la longueur du guide
supérieur. Conservez ce qui reste de la lisière à
calfeutrer pour l’utiliser aux étapes 14 et 22.
Enlevez l’endos et collez un côté de la lisière sur le
guide supérieur (compris), tel qu’illustré à la Fig. 6.
Utilisez les vis de
1
/
4
po (0,625 cm) (comprises) pour
FIGURE 2 — CORDON D'ALIMENTATION
TEST
RESET
AUVENT
OBSTRUCTION
LATÉRALE
SOL
CLÔTURE,
MUR OU
AUTRE
OBSTACLE
30 CM (12 PO) MIN.
75 CM (30 PO) MIN.
50 CM
(20 PO)
MIN.
50 CM
(20 PO)
MIN.
FIGURE 3 — DÉGAGEMENT DU CLIMATISEUR
