Carson SC-1022-20 User manual

Carson Manufacturing Co., Inc.
5451 North Rural Street
Indianapolis, IN 46220
hone: [phone] Fax: [phone]
www.carsonsirens.com
SC-1022-20
SIREN AM LIFIER W/ LIGHT CONTROL
INSTALLATION AND O ERATING
INSTRUCTIONS
Carson is a trademark of Carson Manufacturing Company, Inc.
Sound Hazard - Sound level from siren speaker (>12 dBA @ 1 feet) may cause hearing damage.
Do not operate siren without adequate hearing protection for you and anyone in immediate vicinity.
(Ref. OSHA 191 .95 for occupational noise exposure guidelines)

Page 2 of 8 SC-1 22-2 Installation Instructions
1/3/2 CP52 8A
TABLE OF CONTENTS
GENERAL DESCRIPTION .................................................................................. 2
SPECIFICATIONS .............................................................................................. 3
UNPACKING................................................................................................... 3
INSTALLATION ................................................................................................... 3
SAFETY PRECAUTIONS ............................................................................... 3
MOUNTING .................................................................................................... 3
OPTION SWITCHES ...................................................................................... 4
ELECTRICAL CONNECTIONS .................................................................... 4-5
OPERATION ....................................................................................................... 6
POWER ON/OFF ............................................................................................ 6
SIREN CONTROLS ........................................................................................ 6
Mech, Wail, Yelp, and Phaser Pushbutton Switches .................................. 6
Manual Pushbutton Switch ........................................................................ 6
Horn Pushbutton Switch ............................................................................ 6
Auxiliary Input Functions ............................................................................ 6
Horn Ring Cycler 2 (HRC2) ...................................................................... 6
LIGHT CONTROLS ......................................................................................... 6
LT1 and LT2 Pushbutton Switches ............................................................ 6
SERVICE ............................................................................................................ 7
PROBLEMS .................................................................................................... 7
PARTS and ACCESSORIES........................................................................... 7
RETURNS ....................................................................................................... 8
WARRANTY .................................................................................................... 8
GENERAL DESCRI TION
The SC-1 22 Siren Amplifier with Light Control is designed for single 1 W speaker use having a
remote hand held unit with pushbutton controls.
The primary operating modes are Mechanical, Wail, Yelp, Phaser, and Standby selected by four
pushbutton switches. Momentary Horn Override pushbutton and Manual siren pushbutton for
control of Mechanical, Wail, Yelp, Phaser and Power C. Lights are controlled with two pushbut-
tons as well.
A DIP switch provides options to change tones, disable tones, HRC2 operation, and auxiliary input
polarity. The units utilize short circuit, high voltage, and reverse polarity protection systems for
maximum service life.
NOTICE
Due to continuous product improvements, we must reserve the right to change any specifications and information,
contained in this manual at any time without notice.
Carson Manufacturing Co., Inc. makes no warranty of any kind with regard to this manual, including, but not
limited to, the implied warranties of merchantability and fitness for a particular purpose.
Carson Manufacturing Co., Inc. shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this manual.
See www.carsonsirens.com for latest information.
Sound Hazard - Sound level from siren speaker (>12 dBA @ 1 feet) may cause hearing damage.
Do not operate siren without adequate hearing protection for you and anyone in immediate vicinity.
(Ref. OSHA 191 .95 for occupational noise exposure guidelines)

SC-1 22-2 Installation Instructions Page 3 of 8
CP52 8A 1/3/2
S ECIFICATIONS
UN ACKING
Inspect contents for shipping damage. If found
alert carrier immediately.
Contact supplier immediately if any items are
missing.
INSTALLATION
Proper installation of the unit is essential for years of safe, reliable operation. Please read all
instruction before installing the unit. Failure to follow these instructions can cause serious dam-
age to the unit or vehicle and may void warranties.
SAFETY RECAUTIONS
For the safety of the installer, vehicle operator, passengers and the community please observe
the following safety precautions. Failure to follow all safety precautions and instructions may
result in property damage, injury or death.
Qualifications - The installer must have a firm knowledge of basic electricity, vehicle electrical
systems and emergency equipment.
Hand Control Location - Locate the hand control for easy access by the vehicle operator. DO
NOT locate in air bag deployment area.
Amplifier Mounting - Flanges are provided for mounting (hardware not supplied). Assure clear-
ances before drilling in vehicle.
Wiring - Use wiring capable of handling the current required. Make sure all connections are tight.
Route wiring to prevent wear, overheating and interference with air bag deployment. Install and
check all wiring before connection to vehicle battery.
Testing - Test all siren functions after installation to assure proper operation. Test vehicle opera-
tion to assure no damage to vehicle.
Keep These Instructions - Keep these instructions in the vehicle or other safe place for future
reference. Advise the vehicle operator of the location.
Siren Section
Input Voltage 1 - 16 VDC (negative ground)
Input Current 8 AMPS (@14 VDC - single 1 W speaker)
Standby Current Less than 5 mA @ 14 VDC enabled, less than 5mA standby
Output Power 1 5 WATTS RMS MAX. (15 VDC - single 1 W speaker)
Siren Frequency 7 Hz - 15 Hz (Mechanical 7 Hz - 16 Hz; Two-Tone and Horn = 435 & 585Hz)
Tones / Cycle Rates Horn Mechanical Wail Power C Yelp Phaser Two-Tone
1 9 CPS 5 CPM 13 CPM 1 CPM 19 CPM 15 CPS 6 CPM
High Voltage
Protection
16 - 18 VDC will cause siren output to cease, resumes at normal voltage
Short Circuit Current 5 AMPS (supply circuit must be capable of supplying this for 1 second)
Operating Temp. -15° F to +14 °F
Controls Six Pushbutton switches for Mechanical, Wail, Yelp, Phaser, Manual, and Horn.
Auxiliary input programmable for positive or negative activation.
8-position DIP switch option selector.
Connections Removable 1 -Pos Terminal Block: (2) Power, (2) Speaker, Auxiliary and Enable
inputs, (2) light control outputs.
RJ-12 jack for hand control with built-in cable.
Light Control Section
Controls Two pushbuttons.
Current 5 AMPS per switch, 5 AMPS total
Connections Two light control outputs
General
Size Control Head 1-7/8” Wide, 1” Deep, 4” High
Amplifier 6" Wide, 4-1/4" Deep, 1-7/8" High
Weight 2 LBS.
Qty Item
1 CP4688-1 1 -Pin Terminal Block Plug
1 SC-1 22-1 CH Hand Control Assembly
1 VELCRO Strip Fastener
1 CP52 8 Instruction Manual
1 CP5 3 Hand Control Holster

Page 4 of 8 SC-1 22-2 Installation Instructions
1/3/2 CP52 8A
Hand Control: Choose a mounting location convenient to the operator and away from any air
bag deployment areas. Consider cable routing to amplifier. Mount the hand control with supplied
Hook and Loop tape (VELCRO). If the tape method is not preferred, the hand control may be
mounted several ways. A Holster (CP5 3) to hold the Hand Control or a Hanger and Holder to
hold the Hand Control like a microphone (ED1865) are available accessories.
See PARTS and ACCESSORIES Section.
O TION SWITCHES
An 8-position DIP switch on one side of the amplifier may
be changed to select various options.
Adjusting Option Switches - use a small screwdriver to
change switch settings.
The default setting is shown here. All switches are on.
SW-1 Auxiliary Input olarity - The auxiliary input is normally activated with positive. Turn
switch OFF for negative activation.
SW-4 Two-Tone - Turn this switch OFF to replace Phaser with Two-Tone.
SW-5 Horn Enable - Turn this switch OFF to disable Horn tone. Horn replaced with Yelp.
SW-4 & 5 Tone Disable - All siren tones may be disabled except Manual, Wail and Yelp by turn-
ing OFF both switches. Mechanical will be replaced with Wail. Phaser and Horn will be replaced
with Yelp.
SW-6 Short Manual - The Manual siren tone will normally fall and die out when released. Turn
this switch OFF to have Manual stop immediately.
SW-7 Manual Wail - Turn this switch OFF for Manual Wail instead of Manual Mechanical when
pressing the MAN pushbutton.
SW-8 Mechanical Fall - Turn this switch OFF for a quicker mechanical tone fall time.
HORN RING CYCLER 2 (HRC2) - Turn OFF DIP SW-2 and SW-3 to enable this feature. Also
connect the auxiliary input to the horn ring or other switch. While the siren is in standby, tap the
horn ring to bring the unit out of standby into Mechanical tone. Repeatedly tapping the horn ring
will cycle through Mechanical, Wail, Yelp, and Phaser tones. Tapping the horn ring twice quickly
will stop the siren tones and return the unit to standby. Pressing and holding the horn ring will
produce Horn tone until released. Then the siren will return to its previous siren tone or standby.
ELECTRICAL CONNECTIONS
Electrical connections to the unit are made using terminal block plugs and screw terminals located
on the amplifier. Labels on the unit identify each terminal function. Install the plug on the unit
before wiring. If the unit needs service the plug can be easily removed without unwiring. The
power supply of the unit must be capable of delivering peak currents up to 5 amps for adequate
short circuit protection and reliable operation. The preferred source is directly at the vehicle bat-
tery. The amplifier is fused.
Attach leads by stripping 3/8”, inserting into plug and clamp by tightening screw. Make sure the
screw is tight and the wire can’t be pulled out.
Failure to adequately tighten the screw can result in improper operation or burning the
connector and wire.
Wire Size and Termination - The diagram shows the minimum wire size used for each connec-
tion, along with recommended lead color. If the wire is longer than 1 ft. use the next larger wire
size. Use only high quality crimp connectors for installation on the vehicle.
SW-2 SW-3 Auxiliary Tone in Standby
ON ON (Default) Produces Horn tone while activated.
OFF ON Manual control of Mechanical tone.
ON OFF Manual control of Wail tone.
OFF OFF Activates Horn Ring Cycler 2 (HRC2) function.

SC-1 22-2 Installation Instructions Page 5 of 8
CP52 8A 1/3/2
Enable Input Connection (ORG lead on wiring diagram) - This is NOT the same as the main
power connection. The enable input is like a power switch for the unit. When there is positive
power at this connection, the unit is powered up and ready to function. When power is removed,
the unit is not powered up and will not drain current from the battery. Connect to a positive circuit
controlled by the vehicle ignition switch, usually a terminal at the vehicle fuse panel. The required
current is low (15mA typ.).
Auxiliary Input Connection (Optional) - A momentary input typically connected to the horn ring
of the vehicle or other switch. See OPERATION section for auxiliary input functions.
NOTE: ermanent disconnection of the vehicle horn is NOT recommended.
The auxiliary input may be activated with positive or negative voltage. See Auxiliary olarity
under OPTION SWITCHES section for proper activation polarity. Input current is 1 to 2 mA.
Hand Control Connection - Route cable and plug into RJ12 jack on amplifier.
#18G BRN
#18G BRN
BAT
-
+
RED
#16G BLK
RED ( ositive Supply)
Recommended Wire Size
Load 1 + Load 2 +
8A for Amplifier
Amps
Gauge
5 - 1 #16
1 - 15 #14
Use next larger size if
longer than 1 ft.
AUX
#22G WHT
ENA
#22G ORG
Enable Input
(like an ON/OFF switch)
Connect to positive circuit
(fuse panel) controlled by
ignition or other switch
Load
1
Load
2
Gauge -
see table

Page 6 of 8 SC-1 22-2 Installation Instructions
1/3/2 CP52 8A
O ERATION
OWER ON/OFF
The unit is normally turned on with ignition switch on the vehicle. See INSTALLATION section.
The hand control will also be backlit.
SIREN CONTROLS
MECH, WAIL, YEL , AND HSR USHBUTTON SWITCHES
Four pushbutton switches control the primary operating mode of the siren.
The primary operating modes are:
Standby - A silent mode that may be overridden at any time.
Mech - A simulated mechanical siren tone. Tone may be changed or disabled. See OPTION
SWITCHES section.
Wail - A slower changing tone used on highways.
Yelp - A rapidly changing tone used in congested areas.
haser - A very rapid changing tone used at intersections and very highly
congested areas. May be optionally replaced with Two-Tone or disabled.
Two-Tone is two alternating frequencies like a European HI-LO. See OP-
TION SWITCHES section.
Momentarily press button to activate (lit red). Momentarily press button
again to de-activate. Also while a particular mode is activated, switch to a
different mode by pressing one of the other three buttons. The unit is in
Standby when NONE of the four buttons are activated (NOT lit red). For
example starting with all four buttons off, press the Wail button to turn on
Wail. Now press the Yelp button to change to Yelp. Press the Yelp button
again to turn off sound (return to Standby).
When Mechanical or Wail is turned off the tone will die out. Turn on Short
Manual option to stop tone immediately. See OPTION SWITCHES section.
MAN USHBUTTON SWITCH
Provides manual control of siren tone depending on the primary operating
mode selected.
While in Standby, the Manual button controls the Mechanical tone. Rising to peak while pressed
then falling until die out when released. May be optionally replaced with manual Wail tone.
See OPTION SWITCHES section.
While in Mech, Yelp, or Phaser mode, pressing the Manual button causes tone to rise and peak
then resume when released. While in Wail mode pressing this button toggles between Wail and
Power C tone.
HORN USHBUTTON SWITCH
Produces a simulated Air-Horn tone while pressed. Overrides all siren modes. Horn tone may be
disabled. See OPTION SWITCHES section.
AUXILIARY IN UT FUNCTIONS
The switch or horn ring attached is intended to be momentary. While in Mech, Wail, Yelp, or
Phaser mode, activating auxiliary will produce Horn tone. While in Standby, activating auxiliary
will normally produce Horn tone. Different tones are available. See OPTION SWITCHES section.
Horn Ring Cycler 2 (HRC2) - this feature may also be added. See description on Page 4.
LIGHT CONTROLS
LT1 and LT2 USHBUTTON SWITCHES
Momentarily push button to activate (will light red) corresponding light output.
Momentarily push button again to de-activate corresponding light output.
rimary Mode
and Tone
MAN
Button
HORN
Button
Auxiliary Input
(Horn Ring)
Standby (Silent) M. Mech or M. Wail Horn Horn, M. Mech., M. Wail, or HRC2
Mechanical Man. Mech. Rise Horn Horn
Wail, Yelp, or Phaser Man. Wail Rise Horn Horn

SC-1 22-2 Installation Instructions Page 7 of 8
CP52 8A 1/3/2
SERVICE
This unit is designed to provide years of reliable service under even the worst conditions. Many
times there may appear to be a problem with the unit when the true problem is in the speaker,
controlled devices, or improper installation. The following chart shows typical symptoms and
possible causes.
A blown siren fuse doesn't necessarily mean that the unit is bad. If a speaker or speaker lead is
shorted the fuse will blow before the unit is damaged. Disconnect the SPKR leads and replace
the fuse. If the amplifier makes noise with Wail mode selected and Enable Input powered the
amplifier is OK. Check the speaker or leads for possible shorting.
ROBLEMS
ARTS and ACCESSORIES
The following parts and accessories are available from Carson Manufacturing Company, Inc.:
See www.carsonsirens.com for additional information
or contact our Service Department at:
E-mail [e-mail] or Phone [phone]
Symptom ossible Cause Check
No power or siren
output
No power to enable input (org wire)
Bad speaker
Connector(s) loose
Rear panel fuse blown
Loose connection at power source
Does backlighting come on?
Is the amplifier making noise in Wail?
Do you hear a "pop" when turned on?
Is an external fuse or circuit breaker used?
Are the negative leads connected to a good ground?
No siren tones Bad Speaker
High Voltage Protection
Is the amplifier making noise in Wail?
Input voltage must be less than highest rated voltage.
Distorted siren
sound
Speaker assembly loose
Intermittent Aux Input connection
Low vehicle voltage
Is the speaker bell or tip loose?
Is the Aux Input used and wired properly?
Input voltage must be greater than lowest rated voltage.
Intermittent siren
tone
High Voltage Protection
Connector loose
Bad power connection
Circuit breaker in supply connection
Is the vehicle voltage regulator working properly?
Is the connector tight on the back of the unit?
Is there a loose connection on a power lead?
Is a circuit breaker used with at least a 5 A rating?
Horn function
stuck on or
Manual stuck on
Horn or Manual switch stuck
Aux Input improperly connected
Aux Input Polarity Option set wrong
Does the horn or manual switch return when released?
Is the Aux Input used and wired properly?
Is the AUX_P option properly configured?
Wrong siren tone Two-Tone option installed
Tones disabled.
Is the T-T option selected?
Check option switch settings.
Some siren tones
not working
Tone disabled Check option switch settings.
Light switches not
working
Loose output connections
Rear panel fuse blown
Do the Light Control switch indicators light?
Is the corresponding fuse blown?
Accessory Description * - standard accessory supplied with unit
CP4688-1 * Connector, 1 -pin Terminal Block Plug (SC-1 12)
SC-1022-10CH * SC-1 22 Hand Control Assembly
CP5 3 SC-1 22 Hand Control Holster
ED1865 SC-1 22 Hanger and Holder Kit
ED1753 Cable, Hand Control Extension 15FT Kit (includes C 4652 shielded cable & C 4141 modular coupler)
VELCRO * Velcro Strip Fastener
CP52 8 * Instruction Manual
CP5 3 * Hand Control Holster

Page 8 of 8 SC-1 22-2 Installation Instructions
1/3/2 CP52 8A
RETURN
If you have any questions concerning this or any other Carson product,
please contact our Technical Service Department at [phone].
Many issues can be handled over the phone. We can also be reached via e
-mail at [email protected]
If a product must be returned for any reason, please contact our Technical
Service Department to obtain a Returned Merchandise Authorization num-
ber (RMA#) before you ship the product to Carson. Please write the RMA#
clearly on the package near the mailing label. Be sure to provide a return
address, contact and phone number, along with a brief description of the
problem.
