Count on Carson
... to bring you and your customers truly innovative,
high-quality optics at extraordinary value. We’ve become a leading supplier in
consumer optics for people of all ages and interests.
Whether you’re a hunter, birder, sports fan, or concert goer, Carson has the
perfect optical product to enhance your viewing experience. Our new state-
of-the-art design center enables us to offer innovative products and attractive
packaging at a reasonable cost. Carson’s dedicated sales team provides the
personalized support necessary to meet your every need.
No-Fault, No-Hassle Warranty* At Carson, we manufacture only
the highest quality binoculars. We’re so condent in our products that
we back them with America’s best binocular warranty! See our website
for details. In the event that your binoculars get damaged, regardless
ofcause,Carson willrepair or replacethem fora total cost of $15, which
includes all return shipping and handling fees, NO HIDDEN CHARGES!
If your binoculars are found to have manufacturing defects in materi-
als or workmanship, Carson will repair or replace your binoculars and
return them FREE-OF-CHARGE. Please Call for details.
*Battery operated items are protected by our Standard One-Year Limited Warranty.
Carson Optical
35 Gilpin Avenue
Hauppauge, New York 11788-4723
Phone [phone] | Fax [phone]
For information, call toll-free: 1-800-967-8427
[email protected]
[email protected]
www.carsonoptical.com
Lens Coating Legend
C = Coated
FC = Fully-Coated
MC = Multi-Coated
FMC = Fully Multi-Coated

XM-050HD 10 x 50mm High Definition
XM-842HD
8 x 42mm
XM-042HD
10 x 42mm
XM-832HD
8 x 32mm
Fully Multi-Coated | O-Ring Sealed | Phase Coated | Waterproof | Fog Proof
Fully Multi-Coated
O-Ring Sealed
Phase Coated
Waterproof
Fog Proof
High Definition
Binocular Series
Features an
astonishing 84.7%
light transmission that
outperforms most of
our competitor’s more
expensive models.
See test results at www.carsonoptical.com
ULTRA BRIGHT IMAGE
3
Model XM-842HD XM-042HD XM-050HD XM-832HD
Magnification 8 x 42mm 10 x 42mm 10 x 50mm 8 x 32mm
Prism BAK-4 BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC FMC FMC
Field of View 330 ft 314 ft 262 ft 420 ft
Eye Relief 22mm 17mm 19mm 15.5mm
Close Focus 13.1 ft 16 ft 19 ft 9.8 ft
Weight 24.3 oz. 24.3 oz. 34 oz. 20.6 oz.
HD OPTICAL COATING TO ENHANCE BRIGHTNESS
XM-HD SERIES
BINOCULARS XM
SERIES
XM-025
10 x 25mm
XM-825
8 x 25mm
Model XM-825 XM-025
Magnification 8 x 25mm 10 x 25mm
Prism BAK-4 BAK-4
Lens Coating FMC FMC
Field of View 272 ft 262 ft
Eye Relief 18.5mm 17mm
Close Focus 6.6 ft 6.6 ft
Weight 12.2 oz. 12.4 oz.
4

56
SERIES
3D stands for Design,
Depth and Dimension...
The 3D Series has been "Designed" for
exceptional user comfort, featuring precisely
placed thumb grooves, "just right" texturing
and all-over body ergonomics.
The advanced optical technology
produces enhanced "Depth"
and "Dimension".
TD-832
8 x 32mm
TD-842
8 x 42mm
TD-050
10 x 50mm
TD-042
10 x 42mm
Fully Multi-Coated • O-Ring Sealed
Phase Coated • Waterproof • Fog Proof
NEW!
Model TD-832 TD-842 TD-042 TD-050
Magnification 8 x 32mm 8 x 42mm 10 x 42mm 10 x 50mm
Prism BAK-4 BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC FMC FMC
Field of View 392 ft. 330 ft. 314 ft. 262 ft.
Eye Relief 19.5mm 19.5mm 16mm 20mm
Close Focus 6.6 ft. 9.8 ft. 9.8 ft. 13.1 ft.
Weight 19 oz. 23 oz. 23.2 oz. 26.9 oz.
NEW!
NEW!
NEW!
BINOCULARS

7
8
GreyhawkTM
CZ-021 | 10-30 x 21mm
Model CZ-021 MZ-517 Z-80
Magnification 10-30 x 21mm 5-15 x 17mm 18-100 x 28mm
Prism BK-7 BAK-4 BK-7
Lens Coating MC FC MC
Field of View 167/84 ft 315/183 ft 78/33 ft
Eye Relief 12-7.5mm 13-10mm 12.5-6mm
Close Focus 7.55 ft 10 ft 11 ft
Weight 7.4 oz. 7.0 oz. 13.5 oz.
SuperZoomTM
Z-80 | 18-100 x 28mm
MiniZoomTM
MZ-517 | 5-15 x 17mm
Model JK-842 JK-042 MO-042
Magnification 8 x 42mm 10 x 42mm 10 x 42mm
Prism BAK-4 BAK-4 BAK-4
Lens Coating FMC FMC MC
Field of View 320 ft 306 ft 315 ft
Eye Relief 22mm 16mm 16mm
Close Focus 5 ft 6 ft 16 ft
Weight 21.5 oz. 22 oz. 24 oz.
NEW!
EXTREME
CLOSE
FOCUS
CLOSE FOCUS
OF 5-6 FEET
- GREAT FOR
BIRD WATCHING 98
JK-SeriesTM
JK-042 | 10 x 42mm
CaribouTM
MO-042 | 10 x 42mm
Also Available
JK-842 | 8 x 42mm
FULL SIZE
ZOOM
BINOCULARS
BINOCULARS
NEW!
NEW!

BUILT-IN
DIGITAL
COMPASS
11
TrailFinderTM
TF-025 | 10 x 25mm
MiniScoutTM
JD-718 | 7 x 18mm
ScoutTM
JD-822 | 8 x 22mm
ScoutPlusTM
JD-025 | 10 x 25mm
OutlawTM
MO-025 | 10 x 25mm
Model JD-718 JD-822 JD-025 MO-025 TF-025
Magnification 7 x 18mm 8 x 22mm 10 x 25mm 10 x 25mm 10 x 25mm
Prism BK-7 BK-7 BK-7 BK-7 BK-7
Field of View 489 ft 393 ft 342 ft 302 ft 343 ft
Weight 4.5 oz. 6.0 oz. 9.9 oz. 6.2 oz. 12.0 oz.
OutdoorPakTM
TZ-401
Pack Includes:
8 x 21mm Binocular, Compass, Flashlight, Multi-Tool
TrackerTM
TZ-821 | 8 x 21mm
TrekTM
TK-821 | 8 x 21mm
Model RV-826 TK-821 TZ-821
Magnification 8 x 26 mm 8 x 21mm 8 x 21mm
Prism BAK-4 BK-7 BK-7
Field of View 330 ft 371 ft 371 ft
Weight 9.8 oz. 5.1 oz. 6.8 oz.
10
OPEN HINGE
NEW!
COMPACT
BINOCULARS
RATED KILLER VALUE IN
OUTSIDE BUYER'S GUIDE
NEW!
NEW!
RavenTM
RV-826 | 8 x 26mm

X-ViewTM
XV-732
7 x 32mm
Close-Focusing Scope
straight
observation
or twist to view
at 450
EXPANDABLE
DIGITAL
NIGHT VISION FOCUS ON
OBJECTS AS
CLOSE AS
18 INCHES!
AuraTM
NV-100
2x/3x Digital Night Vision Scope
Model NV-100 SS-550 XV-732
Magnification 2x / 3x 15-40 x 50mm 7 x 32mm
Prism N/A BK-7 BAK-4
Field of View N/A 141/72 ft 381 ft
Weight 10.3 oz. 23.5 oz. 7.5 oz.
13
BackCountryTM
SS-550 | 15-40 x 50mm
Dual Angle Spotting Scope
12
NEW!
SCOPES

15
14
FPO
RS-650MD
6-18 x 50mm w/ Mildot Reticle
RS-444MD
4.5-14 x 44mm w/ Mildot Reticle
RS-650MP
6-18 x 50mm w/ Multiplex Reticle
RS-444MP
4.5-14 x 44mm w/ Multiplex Reticle
RIFLE
SERIES
SCOPES
NEW!
NEW!
NEW!
NEW!
NEW!
Waterproof • Fog Proof • Shock Proof
One Piece 1" Main Tube Construction
Fully Multi-Coated Lenses
Long Eye Relief
1/4" MOA
RS-344MP
3.5-10 x 44mm w/ Multiplex Reticle

TELESCOPES
CloseUpTM
CF-718
7 x 18mm
Close-Focusing
Monocular
16
MonoZoomTM
ZM-825
8-16 x 25mm
Zoom Monocular
EXTREME CLOSE FOCUS
FOCUS AS CLOSE AS 10 INCHES
FROM YOUR SUBJECT
ONE TOUCH
FOCUS LEVER!
Model BA-825 CF-718 GS-718 ZM-825
Magnification 8 x 25mm 7 x 18mm 7 x 18mm 8-16 x 25mm
Prism BK-7 K-9 BK-7 K-9
Field of View 393 ft. 472 ft 378 ft 241/157 ft.
Weight 3.2 oz. 1.8 oz. 2.0 oz. 4.0 oz.
HawkEyeTM
GolfScope
GS-718 7 x 18mm
MONOCULARS
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.
SkySeekerTM
JC-1000
40-100 x 60mm
Includes:
H-8, H-20 Eyepieces
5 x 24mm Finder
AimTM
MTEL-50
20-80 x 50mm
Includes:
K-9, K-17.5 Eyepieces
2x Barlow Lens
SkyTM
SV-350
14-116.6 x 70mm
Includes:
K-6, K-25 Eyepieces
2x Barlow Lens
8 x 21mm Finder
Model MTEL-50 SV-350 JC-1000
Product 20-80 x 50mm 14-116.6 x 70mm 40-100 x 60mm
Description 2 Eyepieces, 2x Barlow Lens, Tripod 2 Eyepieces, 2x Barlow Lens, Tripod 2 Eyepieces, 5x Finder Scope, Aluminum Tripod
Weight 1.8 lbs 6.8 lbs 7.0 lbs
17
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.
BanditTM
BA-825
8 x 25mm

Vista
Also Available
zPix 200TM
MM-740 | Cobalt | 1.3 Megapixel
26x - 130x Zoom Digital Microscope
zPix | Microscope
Accessory KitTM
MM-01
Kit Includes:
3 prepared slides including:
Honeybee mouth
Fruit fly
Grasshopper leg
7 blank slides
10 slide covers
1 tweezer
1 storage case
Zoom Digital Microscope
Specimen Base
Forceps
Eyedropper
USB cable
MM-640 | 26x - 130x
Zoom Digital Microscope
Integrated Camera and Video Capture!
3 Blank Slides
1 Prepared Specimen Slide
CD Rom Software
640 x 480 Resolution
USB 2.0 or later required
Mac OS 10.4 or later Mac OS 10.4 or later
zPix
18 19
Digital Microscope
Attached USB cable
CD Rom Software
Two Base Adapters
Instruction Manual
640 x 480 Resolution
USB 2.0 or later required
35 times on 14 inch Monitor
43 times on 17 inch Monitor
53 times on 21 inch Monitor
MM-480 zOrbTM
35x Digital Microscope
Available in: Surf Blue - Safari Green - Lava Orange
Integrated Camera and
Video Capture!
Vista
7
Vista
7
Vista
7
DIGITAL
MICROSCOPES
zOrb
NEW!
Please note that any pictoral representations shown on this page do not in any way constitute a representation by the manufacturer that such objects can be seen with these products.

Small Lenses
LCD Screens
Digital & SLR Sensors
Computer Screens
LensPenTM
LP-99
Cleaning System
for Standard Lenses
LensPen MiniProTM
LP-50
Cleaning System
for Small Lenses
LapTop ProTM
VM-50
Cleaning System for Laptop
Computer Screens & Keyboards
VidiMaxTM
VM-99
Cleaning System
for Computer Screens
SensorKlearTM
LP-60
Cleaning System
for Digital Camera Sensors and SLR Sensors
21
CLEANING
SYSTEMS
Model Description
OD-10 1.5x Power (+2.25 Diopters) Clip-On,Flip-Up Magnifying Lenses for Eyeglasses
OD-12 1.75x Power (+3.00 Diopters) Clip-On,Flip-Up Magnifying Lenses for Eyeglasses
OD-14 2x Power (+4.00 Diopters) Clip-On,Flip-Up Magnifying Lenses for Eyeglasses
OD-25 5x Power Lighted Retractable Pop-Out Magnifier
OD-36 2.5x Power Hand Held Magnifier with 5x Power Spot Lens
OD-55 4x Power Magnifier with Attached Precision Tweezers
OD-65 2x Power Flexible,LED Lighted Magnifier w/4x Spot Lens and Clamp-on Base
OD-75 1.5x Power Clip-On,Magnifying Lenses for Hats,with Batteries and Built-In Case
OD-99 4x Power Magnifier with Attached Precision Tweezers, Hook Cleaner and Line Cutter
VM-10 1.75x Power (+3.00 Diopters) Clip-On,Flip-Up Magnifying Glasses w/ Carry Pouch
VM-12 2x Power (+4.00 Diopters) Clip-On,Flip-Up Magnifying Glasses w/ Carry Pouch
VM-14 2.25x Power (+5.00 Diopters) Clip-On,Flip-Up Magnifying Glasses w/ Carry Pouch
VisorMagTM
VM-10 | VM-12 | VM-14
TyMateTM
OD-75
Clip & FlipTM
OD-10 | OD-12 | OD-14
Fish 'n GripTM
OD-99
MagniFlyTM
OD-65
20
MagniViewTM
OD-36
LumiClickTM
OD-25
MagniGripTM
OD-55
Use with Batteries or with
Included 4.5V DC Adaptor
OUTDOOR
MAGNIFIERS
20
Standard Lenses

BinoArmorTM
BA-03 | Easy-Access
Protective Binocular Wrap
16
Stuff-It TM
SN-50MO | Retractable
Microfiber Lens Cloth
with Neoprene Pouch
PholsterTM
PH-25 | Game Bird Carrier 2-Pack
Clips To Your Belt!
also available:
SN-50RE - Red
SN-50BU - Blue
SN-50BK - Black
NEW!
NEW! 23
RETRACTS
WITH EASE!
ACCESSORIES
NEW!
NEW!
Scope Armor Deluxe TM
BA-15 | Easy Access
Neoprene Rifle Scope Cover
Scope Armor TM
BA-10 | Neoprene Rifle Scope Cover
ROCK
SERIES
TRIPODS The Rock JuniorTM
TP-100 3-Way Panhead Tripod
The Rock OriginalTM
TP-200 3-Way Panhead Tripod
The Rock DeluxeTM
TP-300 3-Way Panhead Tripod
The Rock ProfessionalTM
TP-400 3-Way Panhead Tripod
Binocular Not Included
Level Quick
Release
Geared
Elevator
Hook /
Handle
65 " max ht./ 26" min ht. 61" / 25" 54" / 21" 18.5" / 11"
22
TRIPODS
HandiPodTM
TA-2 | Compact Folding Tripod

BugLoupeTM
HU-55
BugViewTM
HU-10
BigEyeTM
HU-20
OVERSIZED
5 INCH LENS
HawkTM
HU-530
MagniRamaM
JD-3
Model Description
HU-10 One-Hand Bug Catcher with 5x Power Magnifier
HU-20 2.5x Power (5-inch) Acrylic Hand Magnifier
HU-55 5x Power Stand Magnifier
HU-401 5 x 30mm Binocular, Lensatic Compass,Flashlight,Whistle/Thermometer
HU-530 5 x 30mm Ultra Lightweight Kid's Binoculars
JD-3 Assorted 3x Mini-Magnifiers
AdventurePakTM
HU-401
Includes:
5 x 30mm Binocular
Lensatic Compass
Flashlight
Whistle/Thermometer
25
OUTDOOR
TOYS
24
MagniScopeTM
MA-30
3x, 8x, 30x
8 x 20mm Monocular
3x Stand Magnifier
Precision 30x Portable Microscope
30x Microscope,
8x Telescope,
9x Fold-out Magnifier,
Directional Compass,
LED Flashlight,
Signal Whistle,
Digital Clock
Model CP-11 MM-24 MM-100 MM-200 MA-30
Magnification 8x, 9x, 30x Power 20-40x Power 60-100x Power 60-100x Power 3x, 8x, 30x Power
Weight 3.4 oz. 2.7 oz. 1.28 oz. 1.12 oz. 4.0 oz.
POCKETMICROSCOPES
MicroBriteTM
MM-24 | 20-40x Power
LED Microscope with Batteries
MicroMaxTM
MM-100
60-100x Power Microscope
MicroMax LEDTM
MM-200 | 60-100x Power
LED Microscope with Batteries
X ScopeTM
CP-11
8x / 9x / 30x
Pocket Scope

TERMINOLOGY
Coated Optics
Coatings on lens surfaces reduce light loss and glare due to reflection, resulting in a
brighter, higher-contrast image with reduced eyestrain. Lenses are coated with a micro-
scopic film of magnesium flouride. More coating leads to better light transmission.
Types of Coating
A single layer on at least one lens.
A single layer on all air-to-glass surfaces.
Multiple layers on at least one lens and all surfaces are
coated at least once.
Multiple layers on all air-to-glass surfaces.
Eye Relief
The distance an eyepiece can be held away from the the eye and still present the full field
of view. Extended or long eye relief reduces eyestrain and is ideal for eyeglass wearers.
Field of View
Field-of-view is the side-to-side measurement of the circular viewing field or subject area.
It is defined by the width in feet or meters of the area visible at 1,000 yards or meters.
A wide field-of-view is better for following fast-moving action or scanning for wildlife.
Generally, the higher the magnification, the narrower the field-of-view.
XM-050 10 x 50mm BAK-4 262 ft at 1,000 yds
34.0 oz.
Magnification (Power)
Binoculars and scopes are often referred to by two numbers separated by an
"X". For example: 12 x 50mm. The first number is the power or magnification of
the lens.With a 12 x 50mm power binocular,the object being viewed appears to
be 12 times closer than you would see it with the unaided eye.
Objective Lens Size
The second number in the formula:(12 x 50mm) is the diameter of the objective
or front lens in millimeters. The larger the objective lens, the more light enters
the binocular, and the brighter the image.
Prism Glass
Most optical prisms are made from borosilicate (BK-7) glass or barium crown
(BAK-4) glass. BAK-4 is higher quality glass yielding brighter images and high
edge-sharpness.
Prism Systems
The prism system turns what would be an upside-down image right-side up.
Roof Prism System – The prisms overlap closely, allowing the objective lens-
es to line up directly with the eyepiece. The result is a slim, streamlined shape
in which the lenses and prisms that magnify and correct the image, are in a
straight line.
Porro Prism System – The objective or front lens is offset from the eye
-piece. Porro prisms provide greater depth perception and generally offer a
wider field-of-view.
Waterproof / Fog Proof
Some binoculars and scopes are sealed with o-rings and are nitrogen purged
for waterproof and fog proof protection. These models are able to withstand
complete immersion and remain dry inside.
Coated:
Fully-Coated:
Multi-Coated:
Fully Multi-Coated:
Exit Pupil
The exit pupil refers to the size of the column of light that exits an
eyepiece.The larger the exit pupil, the brighter the image.
To determine the size, divide the objective lens diameter by the
magnification. (A 12 x 36mm model has an exit pupil, or usable
light, of 3mm.)
50mm 80mm
Porro Roof
Custom imprints and innovative "high-tech" packaging are available
for many of our binoculars, magnifiers and accessories. Great for private
store brands, customer thank-you gifts, or employee incentive rewards.
Call for details. (Minimum purchase may apply.)
26 27
CUSTOM
PACKAGING

Carson Optical
35 Gilpin Avenue
Hauppauge, New York 11788-4723
Phone [phone] | Fax [phone]
For information, call toll-free: 1-800-967-8427
[email protected]
[email protected]
www.carsonoptical.com
