Wir beglückwünschen Sie zum Kauf Ihres CARSON-RC-
Verbrenner Modellautos. Bitte lesen Sie diese Bauanleitung sorg-
fältig durch, bevor Sie irgendwelche Arbeiten beginnen.
Das Funkfernsteuern von RC-Autos ist ein faszinierendes
Hobby, das jedoch mit der nötigen Vorsicht und Rücksichtnahme
betrieben werden muß. Ein ferngesteuertes Modellauto, das ein
beachtliches Gewicht aufweist und eine sehr hohe
Geschwindigkeit erreicht, kann in einem unkontrollierten
Fahrzustand erhebliche Beschädigungen und Verletzungen ver-
ursachen, für die Sie als Betreiber haftbar sind.
Vergewissern sie sich bei Ihrer Versicherung, ob sie beim
Ausüben Ihres Hobbys versichert sind.
Nur ein einwandfrei zusammengebautes Modell wird erwar-
tungsgemäß funktionieren und reagieren. Improvisieren Sie nie-
mals mit untauglichen Hilfsmitteln, sondern verwenden Sie im
Bedarfsfall nur Originalersatzteile. Auch bei einem vormontierten
Modell sollten Sie alle Verbindungen auf exakten Sitz kontrollie-
ren.
Fahren Sie niemals los, ohne daß Sie sich von folgenden
Punkten überzeugt haben:
- Akkus oder Batterien für Sender und Empfänger weisen
noch ein gutes Leistungspotential auf.
- Alle Funktionsteile des Fahrzeugs sind in einwandfreiem
Zustand und Sie haben deren Funktion überprüft.
- Sämtliche Schrauben sind auf festen Sitz kontrolliert.
- Es ist kein RC- oder sonstiger Sender in der Nähe in
Betrieb, welcher Funkstörungen verursachen könnte.
- Das Gelände, auf dem Sie zu fahren beabsichtigen, ist
keine öffentliche Verkehrsfläche und wird nicht von
Personen oder Tieren in Anspruch genommen.
- Sender und Empfänger sind eingeschaltet, Sie haben alle
ausführbaren Steuerbefehle kontrolliert.
Nach jeder Fahrt sollten Sie die wichtigsten Bauteile und
Verbindungen überprüfen. Eine einzige gelockerte Schraube
kann ausreichen, um Ihr Modell in eine gefährliche Situation
geraten zu lassen! Warten Sie Ihr Modell regelmäßig und wech-
seln Sie defekte oder abgenützte Bauteile gegen Original-
Ersatzteile aus.
Wir wünschen Ihnen viel Spaß mit Ihrem CARSON-Modellauto
und jederzeit gute Fahrt!

We congratulate you on purchasing your CARSON RC engine
powered model car. Please read this instruction carefully before
you are starting any work.
Driving a radio controlled car is a fascinating hobby which has to
be practised with the necessary caution and respect. A radio
controlled model car which has a considerable weight and can
reach a very high speed can cause damage and injuries in case
of uncontrolled driving conditions and the user is liable for this.
Make sure that you have sufficient insurance coverage in
practising your hobby.
Only a faultless assembled model will operate and react in the
expected manner. Never improvise with any not suitable aids
but use only the original spare parts if necessary. Even with a
prefabricated model you have to control all connections and
screwing whether they are correctly tightened.
Never start driving before you have made sure the following
points:
- batteries for transmitter and receiver have a good potential
and are not weak.
- All operable parts are in good condition and you have tested
their operation.
- You have made sure that all screws are tightened.
- There is no other RC or similar transmitter nearby which
could cause interference.
- the terrain where you want to drive isn't used for common
traffic and is not claimed by any persons or animals.
- Your transmitter and receiver is switched on and you have
checked all control operations which can be performed.
After each drive all important parts and connectors should be
tested. One simply loosened screw can be sufficient to lead your
model into a dangerous situation! Attend to your car in regular
periods and exchange defective or worn out parts with original
spare parts.
We wish you good luck and a lot of fun driving with your
CARSON model car.
