Cartechno NA-VL2DVD900 User manual

Version 02.10.2015
Product features
Video-inserter for factory -infotainment monitors
2 video-inputs for after -market devices (e.g. DVD-Player, DVB -T tuner, …)
Built-in audio-switch (no audio-insertion)
Rear-view camera CVBS video-input
Automatic switching to rear-view camera input on engagement of reverse gear
RGB-input for after -market navigation
Video-in-motion (ONLY for connected video-sources)
Compatible with factory rear-view camera
AV-inputs PAL/NTSC compatible
Video-inserter
NA-VL2DVD900
Video-inserter with 2 video + RGB + rear-view camera input
for Opel, Chevrolet and Buick
with CD500, DVD600, DVD800, DVD900,
CD600 intelliLink and DVD950 intelliLink
navigation systems/radios

Version 02.10.2015 NA-VL2DVD900
Page2
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Checking the compability of vehicle and accessories
1.3. Boxes and connectors
1.3.1. Video-interface
1.3.2. GM-LAN box
1.4. Dip-switch sengs
1.4.1. Enabling the interface’s video inputs (dip 1-3)
1.4.2 RGB-video input signal selecon for aer-market navigaon (Dip 4)
1.4.3 Rear-view camera seng (dip 5)
1.4.4. Monitor selecon (dip 7-8)
2. Installation
2.1. Place of installaon
2.2. Connecon schema
2.3. Connecng video-interface and GM-LAN box
2.4. Connecon to the factory monitor
2.5. Connecng peripheral devices
2.5.1. Aer-market RGB navigaon
2.5.2. Video-sources to AV1 and AV2
2.5.3. Audio-switch and audio-inseron
2.5.4. Aer-market rear-view camera
2.5.4.1. Case 1: GM-LAN box detects reverse gear
2.5.4.2. Case 2: GM-LAN box does not detect reverse gear
2.5.4.3. Video signal connecon
2.6. Connecng video-interface and keypad
2.7. Picture sengs
3. Interface operation
3.1. By “hang up”-key
3.2. By keypad
4. Specications
5. Frequently asked questions
6. Technical support

Version 02.10.2015 NA-VL2DVD900
Page3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulng,
directly or indirectly, from installaon or operaon of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s soware can cause malfuncons of the interface. We
offer free soware-updates for our interfaces for one year aer purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the soware-updates will not be refunded.
1. Prior to install ation
Read the manual prior to installaon.
Technical knowledge is necessary for installaon. The place of installaon must be free of
moisture and away from heat sources.
1.1. Delivery contents
Take down the serial numberof the interface and store this manual for support
purposes: ____________________

Version 02.10.2015 NA-VL2DVD900
Page4
Requirements
Vehicle Buick Lacrosse , Regal
Opel Insignia A, Astra J, Meriva B, Mokka
Chevrolet Cruze, Orlando
Head-unit/monitor CD500, DVD600, DVD800, DVD900, CD600intelliLink and
DVD950intelliLink
Limitations
Video only The interface inserts ONLY video signals into the infotainment.
For sound use the possibly exisng factory-audio-AUX-input or a
FM-modulator.
Factory rear-view camera Automac switch-back from inserted video to factory rear-view
camera only while reverse gear is engaged. To delay the switch-
back me, addional electronics is required.
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors
1.3.1. Video-interface
The video-interface converts the connected aer-market sources video signals to an GVIF
signal which is the inserted into the factory monitor on certain trigger opons.

Version 02.10.2015 NA-VL2DVD900
Page5
1.3.2. GM-LAN box
The GM-LAN box reads digital signals from the GM-LAN-bus and converts them for the
video-interface.
1.4. Dip-switch settings
Some sengs must be selected by the dip-switches on the
video interface. Dip posion down is ON and posion up is OFF.
See following chapters for detailed informaon.
1.4.1. Enabling the interface’s video inputs (dip 1-3)
Only the enabled video inputs can be accessed when switching through the interface’s video
sources. It is recommended to enable only the required inputs for the disabled will be
skipped when switching through the video interfaces inputs.
1.4.2. RGB-video input signal selection for after-market navigation (Dip 4)
If an aer-market RGB navigaon or other RGB video source is connected, the source’s RGB
output signal must match the interface’s RGB video input seng.
Dip
Function
ON (down)
OFF (up)
1
RGB-input
enabled
disabled
2
CVBS AV1-input
enabled
disabled
3
CVBS AV2-input
enabled
disabled
4
RGB-input resoluon
800x480
1080p H+V sync
5
Rear-view cam type
aer-market
factory or none
6
No funcon
-
set OFF
7
Monitor
selecon
Try all 4 possible combinaons of dip 7 and 8 to find the
best picture (quality and size)
8

Version 02.10.2015 NA-VL2DVD900
Page6
1.4.3. Rear-view camera setting (dip 5)
If set to OFF, the interface switches to factory GVIF picture while the reverse gear is engaged
to display factory rear-view camera or factory opcal park system picture.
If set to ON, the interface witches to its rear-view camera input CAM while the reverse gear
is engaged.
1.4.4. Monitor selection (dip 7-8)
Dip 7 and 8 are for monitor-specific video sengs which cannot be predicted as even within
the same head-unit version, the monitor specificaons may vary. It is necessary to try all
possible combinaons (both OFF, both ON, 7 OFF and 8 ON, 7 ON and 8 OFF) - while a
working video source is connected to the chosen input of the interface - to see which
combinaon gives the best picture quality and size (some may give no picture). It is possible
to first hot plug through the dip combinaons, but if you do not experience any change of
picture aer trying all 4 opons, retry and disconnected the 6pin power plug of the video-
box between every change of the dip seng.
2. Installation
Switch o ignition and disconnect the vehicle’s battery! The interface needs a permanent
12V source. If according to factory rules disconnecting the battery is to be avoided, it is
usually sucient to put the vehicle is sleep-mode. In case the sleep-mode does not show
success, disconnect the battery with a resistor lead.
If power source is not taken directly from the battery, the connection has to be checked
for being start-up proven and permanent.
2.1. Place of installation
The interface is installed on the backside of the factory monitor.

Version 02.10.2015 NA-VL2DVD900
Page7
2.2. Connectionschema

Version 02.10.2015 NA-VL2DVD900
Page8
2.3. Connectingvideo-interface and GM-LAN box
The GM-LAN box reads digital signals from the GM-LAN and converts them for the video-
interface. ACC +12V max. 0.5A (red of 6pin) and reverse gear +12V max. 0.5A (green of 6pin)
constant signal. Video-source switching (white of 6pin) as +12V impulse.
Connect black female 4pin Micro-Fit connector of the 4pin cable to the male 4pin
Micro-Fit connector of the GM-LAN-box.
Note: Check LEDs on CAN-box aer reconnecng the baery, one must be on.
1) GM-LAN
2) +12V Battery
3) Ground
Note: GM-LAN posion can be different on certain vehicles
Connect white female 6pin Molex connector of the 6pin to 8pin cable to the male
6pin Molex connector of the video-interface.
Connect black female 8pin Micro-Fit connector of the 6pin to 8pin cable to male 8pin
Micro-Fit connector of the GM-LAN-box.
Note: Check LEDs on video-interface aer reconnecng the baery, one must be on.
Vehicle female Quadlock connector

Version 02.10.2015 NA-VL2DVD900
Page9
2.4. Connection to the factory monitor
Remove factory monitor.
Connect female 8pin connector of the GVIF cable to the male 8pin connector of the
interface.
Remove female GVIF connector from the rear of the factory monitor and connect it
to the GVIF connector of the GVIF cable.
Connect female GVIF connector of the GVIF cable to the male GVIF connector of the
factory monitor.
2.5. Connecting peripheral devices
It is possible to connect 2 aer-market AV-sources, an aer-market rear-view camera and an
aer-market navigaon to the video-interface.
Before nal installation of the per ipheral devices, we recommend a test-run to detect
incompatibility of vehicle and interface. Due to changes in the production of the vehicle
manufacturer is always the possibility of incompatibility.

Version 02.10.2015 NA-VL2DVD900
Page10
2.5.1. After-Market RGB navigation
Connect female 8pin connector of the RGB cable to the male 8pin connector of the
video-interface. The loose grey wires have no funcon and have to be isolated.
Connect male 6pin connector of the RGB cable to the aer-Market navigaon.

Version 02.10.2015 NA-VL2DVD900
Page11
2.5.2. Video-sources to AV1 and AV2
Connect female 6pin connector of the video cable to male 6pin connector of the
video-interface.
Connect video RCA of the AV-source 1 to the female RCA connector Video IN 1 of the
video cable.
Connect video RCA of the AV-source 2 to the female RCA connector Video IN 2 of the
video cable.

Version 02.10.2015 NA-VL2DVD900
Page12
2.5.3. Audio-switch and audio insertion
This interface can only insert video signals into the factory infotainment and switch audio
signals. If an AV-source is connected to AV1 or AV2, audio inseron must be done by factory
audio AUX input or FM-modulator to which the interface’s sound-switch output is
connected. When the interface is switched from AV1 to AV2, the audio signal is switched
parallel to the corresponding video signal by the interface’s built-in audio-switch.
The inserted video-signal can be acvated simoultaneously to each audio-mode of the
factory infotainment.
Audio pins
Denition
½
Audio input signal R/L of source AV2
¾
Audio input signal R/L of source AV1
5/6
Audio output signal R/L of factory audio AUX
or FM-modulator
7
Ground
Note: If only one AV-source shall be connected, it is possible to connect the video output of
the AV-source to the video input AV1 of the video-interface and the audio output of the AV-
source directly to the point of audio-inseron (e.g. audio AUX input).
Connect female 7pin connector of the audio cable to male 7pin connector of the
video-interface.
Connect the audio-RCA of the possibly exisng factory AUX-input or the FM-
modulator to the female RCA port AV-Out of the audio cable.
Connect the audio-RCA of the AV-source 1 to the female RCA port AV1 of the audio
cable.
Connect the audio-RCA of the AV-source 2 to the female RCA port AV2 of the audio
cable.

Version 02.10.2015 NA-VL2DVD900
Page13
2.5.4. After-market rear -view camera
Some vehicles have a different reverse gear code on the GM-LAN which the included GM-
LAN box is not compable with. Therefore there is two different ways of installaon. If the
GM-LAN box can detect the reverse gear in the vehicle, the green wire of the 6pin to 8pin
cable should carry +12V while the reverse gear is engaged.
Note: Do not forget to set dip5 of video-interface to ON before tesng.
2.5.4.1. Case 1: GM -LAN box detects reverse gear
If the CAN-bus interface delivers +12V on the green wire of the 6pin to 8pin cable when
reverse gear is engaged, the video interface will automacally be switched to the rear-view
camera input CAM while reverse gear is engaged.
Addionally, the +12V (max. 500mA) power supply for the rear-view camera can be
taken from the green wire of the 6pin to 8pin cable.

Version 02.10.2015 NA-VL2DVD900
Page14
2.5.4.2. Case 2: GM -LAN box does not detect reverse gear
If the GM-LAN box does not deliver +12V on the green wire of the 6pin to 8pin cable when
reverse gear is engaged (not all vehicles are compable) an external switching signal from
the reverse gear light is required. As the reverse gear light signal contains electronic
interference, a normally open relay (e.g AC-RW-1230 with wiring AC-RS5) or filter (e.g. AC-
PNF-RVC) is required. Below schema shows the use of a relay (normally open).
Cut the green cable of the 6pin to 8pin cable close to the at the black 8pin connector.
Isolate the short end of the green wire (GM-LAN box side).
Connect reverse gear light signal/power to coil (85) and ground to coil (86) of relais.
Connect rear-view camera power and green wire (video interface side) of 6pin to
8pin cable to output (87) of relay.
Connect permanent baery power to input (30) of relay.

Version 02.10.2015 NA-VL2DVD900
Page15
2.5.4.3. Video signal connection
Connect the video-RCA of the aer-market rear-view camera to the female RCA port
of the video-interface which is labeled as CAM.
Note: Picture sengs for CAM input must be done in AV2.
2.6. Connecting video-interface and keypad
Connect the female 4pin connector of the keypad to the male 4pin connector of the
video-interface.

Version 02.10.2015 NA-VL2DVD900
Page16
2.7. Picture settings
The picture sengs are adjusted by the 3 buons on the video -interface. Press the MENU
buon to open the OSD sengs menu or to switch to the next menu item. Press UP and
DOWN change the selected value. The buons are embedded in the housing to avoid
accidental changes during or aer installaon. Picture sengs must be done separately for
RGB, AV1 and AV2 while the corresponding input is selected and visible on the monitor. AV2
and CAM share the same sengs which must be adjusted in AV2.
Note: The OSD menu is only shown when a working video source is connected to the
selected video-input of the interface.
The following sengs are available:
Contrast
Brightness
Saturaon
Posion H (horizontal)
Posion V (vercal)
Note: If the GM-LAN box does not support the very vehicle, the guide-lines cannot be used.
If supported and acvated, the guide-line also show the steering wheel posion dependant
driving path.

Version 02.10.2015 VL2-DVD900
Page17
3. Interface operation
3.1. By “hang-up” key
The “hang-up”-button on the steering-wheel can be used to execute interface funcons.
Press “hang-up”-button on the steering-wheel to switch the video-source.
Each repeon will switch to the next enabled input. If all inputs are enabled the order is:
Factory video RGB-in video IN1 video IN2 factory video …
Inputs which are not enabled are skipped. If the audio cable is connected, when switching
from video IN1 to video IN2, also the sound will be switched.
Note: The white wire of the 6pin cable can be used with a +5-12V pulse to switch the video-
sources alternavely.
3.2. By keypad
Alternavely or addionally to the factory infotainment buons the interface’s external
keypad can be used to switch the enabled inputs.
4. Specications
BATT/ACC range 7V ~ 25V
Stand-by power drain <5mA
Power 0.2A @12V
Power consumpon 2.4W
Video input 0.7V~1V
Video input formats PAL/NTSC
RGB-video amplitude 0.7V with 75 Ohm impedance
Temperature range -40°C to +85°C
Weight 195g
Dimensions (box only) B x H x T 182 x 24 x 100 mm

Version 02.10.2015 NA-VL2DVD900
Page18
5. Frequently asked questions
For any troubles which may occur, check the following table for a soluon before requesng
support from your vendor.
Symptom
Reason
Possible solution
No picture/black
picture (factory
picture).
Not all connectors have been
reconnected to factory head-
unit or monitor aer
installaon.
Connect missing connectors.
No power on CAN-bus box (all
LED CAN-bus box are off).
Check power supply of CAN-bus box. Check CAN-bus
connecon of CAN-bus box.
CAN-bus box connected to
CAN-bus in wrong place.
Refer to the manual where to connected to the CAN-
bus. If not menoned, try another place to connect to
the CAN-bus.
No power on video-interface
(all LED video-interface are
off).
Check whether CAN-bus box delivers +12V ACC on red
wire output of 8pin to 6pin cable. If not cut wire and
supply ACC +12V directly to video-interface.
No picture/black
picture/white picture
(inserted picture) but
factory picture is OK.
No picture from video source.
Check on other monitor whether video source is OK.
No video-source connected to
the selected interface input.
Check sengs dips 1 to 3 of video interface which
inputs are acvated and switch to corresponding
input(s).
LVDS cables plugged in wrong
place.
Double-check whether order of LVDS cables is exactly
connected according to manual. Plugging into head-
unit does not work when the manual says to plug into
monitor and vice versa.
Wrong monitor sengs of
video-interface.
Try different combinaons of dips 7 and 8 of video-
interface. Unplug 6pin power aer each change.
Inserted picture totally
wrong size or posion.
Inserted picture double
or 4 mes on monitor.
Inserted picture
distorted, flickering or
running vercally.
Video sources output set to
AUTO or MULTI which causes
a conflict with the interfaces
auto detecon.
Set video source output fixed to PAL or NTSC. It is best
to set all video sources to the same standard.
If error occurs only aer
source switching: Connected
sources are not set to the
same TV standard.
Set all video sources to the same standard.
Some interfaces can only
handle NTSC input.
Check manual whether there is a limitaon to NTSC
menoned. If yes, set source fixed to NTSC output.
Inserted picture b/w.
Inserted picture qual.
bad.
Picture sengs have not been
adjusted.
Use the 3 buons and the interface's OSD to adjust the
picture sengs for the corresponding video input.
Inserted picture size
slightly wrong.
Inserted picture
posion wrong.
Camera input picture
flickers.
Camera is being tested under
fluorescent light which shines
directly into the camera.
Test camera under natural light outside the garage.
Camera input picture is
bluish.
Protecon scker not
removed from camera lens.
Remove protecon scker.

Version 02.10.2015 NA-VL2DVD900
Page19
Symptom
Reason
Possible solution
Camera input picture
black.
Camera power taken directly
from reverse gear lamp.
Use relay or electronics to "clean" reverse gear lamp
power. Alternavely, if CAN-bus box is compable
with the vehicle, camera power can be taken from
green wire of 6pin to 8pin cable.
Camera input picture
has distoron.
Camera input picture
sengs cannot be
adjusted.
Camera input picture sengs
can only be adjusted in AV2
mode.
Set dip 3 of video-interface to ON (if not input AV2 is
not already acvated) and connect the camera to AV2.
Switch to AV2 and adjust sengs. Reconnect camera
to camera input and deacvate AV2 if not used for
other source.
Not possible to switch
video sources by OEM
buon.
CAN-bus interface does not
support this funcon for
vehicle.
Use external keypad or cut white wire of 6pin to 8pin
cable and apply +12V impulses for AV-switching.
Pressed too short.
For video source switching a longer press of about 2.5
seconds is required.
Not possible to switch
video sources by
external keypad.
SW-version of interface does
not support external keypad.
Use OEM-buon or cut white wire of 6pin to 8pin
cable and apply +12V impulses for AV-switching.
Interface does not
switch to camera input
when reverse gear is
engaged.
CAN-bus interface does not
support this funcon for the
vehicles.
Cut the green wire of the 6pin to 8pin cable and apply
+12V constant from reverse gear-lamp signal. Use
relay to "clean" gear lamp power.
Interface switches
video-sources by itself.
CAN-bus interface
compability to vehicle is
limited.
Cut the grey wire of 6pin to 8pin and isolate both
ends. If problem sll occurs, addionally cut the white
wire of 6pin to 8pin cable and isolate both ends.
10R-03 5384
6. Teknisk support
Bjarne Kristensen
Salg og support
Autoelektriker 1977
Selvstændig siden 1990
Mobil: 60 40 68 68
E-mail : bj[email protected]
