CARVIN SC212C User manual

SPEAKER CABLES
The PH8 is our standard cable when purchasing a complete guitar amp stack.
These cables feature 1/4” plugs and heavy 16 gauge copper wire. You can DAISY-
CHAIN up to one additional speaker per cable by using the unused 1/4” OUTPUT”
jack (right side) on your speaker jack plate. Be sure to note the total impedance to
the amp so it is not lower than it’s recommended impedance. See Typical
Loudspeaker Impedance Configurations.
PRECAUTIONS
1) DO NOT EXCEED THE POWER RATING marked on the rear connect plate.
Excessive power will destroy drivers. 2) DISTORTION from power amps will destroy
drivers much faster than clean power. 3) WATER, MOISTURE, and DUST are
harmful to drivers causing failure which is not covered under warranty.
WARRANTY
CARVIN loudspeakers are covered by a ONE year limited warranty unless
otherwise stated. Warranty coverage is limited to original manufactures defects
only. WARRANTY DOES NOT COVER: 1) Opened or burned voice coils. 2) Torn
cones caused by improper packing or abuse. 3) Damage from rain, moisture, ETC.
SERVICE
In the USA, please call 800-854-2235 for a RMA # (return authorization number).
Write this number on the box and enclose a description of the problem. Prepay to
Carvin 12340 World Trade Drive, SD, CA 92128.
Outside the USA, contact your dealer or go to http://www.carvinworld.com for your
nearest service center. Include a written description of the problem with serial
number and date of purchase.
MODEL SC412T/SC412B SYSTEM SPECS:
Speakers: 4 Celestion SEVENTY 80 Speakers
Frequency Response: 72 to 7.5k Hz
Power Handling: 400 watts
Mode Switch: Mono/Stereo
Nominal Impedance: Mono 8ΩStereo 4Ω
Input Connector: One 1/4" Phone Connector
Output Connector: One 1/4" Phone Connector
Woofer Enclosure Type: Closed Box
Enclosure Covering: Black Vinyl
Dimensions: 30"W x 14.5"D x 30"H
Warranty: One Year
Weight: 75 lbs.
Optional Cable: PH8
Optional Covers: Top; CVS412T, Bottom; CVS412B
Optional Casters: CTS4
CARVIN ENGINEERING DATA SC412T/SC412B/SC212E GUITAR SYSTEM INSTRUCTIONS
SC412T
Carvin’s SC speaker cabinets are constructed of the finest materials and are built to
the toughest standards in the industry. Moreover, they are loaded with the best all-
around sounding 12” drivers available. The Celestion SEVENTY 80 speakers are
capable of crystal clear “Clean” tones and yet can be driven hard to achieve that
familar “British” over-drive sound, with plenty of midrange and bass response. The
enclosure is built from light weight, yet incredibly strong, poplar plywood and is
covered in rich black protective vinyl. Built-in recessed handles, steel corners and a
steel mesh grill further protect your investment.
Caster inserts are already in place if you choose to add the optional CTS4 casters.
RECEIVING INSPECTION
INSPECT YOUR SPEAKER FOR ANY DAMAGE which may have occurred during
shipping. If any damage is found, please notify the shipping company & CARVIN.
SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to re-ship
your unit, always use the original carton and packing material. This will provide the best
possible protection during shipment. CARVIN and the shipping company are not liable
for any damage caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty service if needed in the future.
SHIPMENT SHORTAGE. If you find items missing, they may have been shipped
separately. Please allow several days for the rest of your order to arrive before inquiring.
RECORD THE SERIAL NUMBER on the enclosed warranty card or below on this
manual for your records. Keep your portion of the card and return the portion with your
name and comments to us.
TYPICAL LOUDSPEAKER IMPEDANCE CONFIGURATIONS
Individual speaker or speaker cabinet wiring examples for total impedance.
For your records, you may wish to record the following information.
Serial No._____________________ Invoice Date_______________
STEREO/MONO SWITCH
The stereo/mono switch allows you to
run your stereo pre-amps, effects, and
power amps with only a single cabinet.
Perfect for portable rack systems.
REAR CONNECT PLATE
Two standard 1/4” phone jacks are
featured. One for connecting to the
power amp and the other for connecting
to an additional speaker system.
76-00412C 0705
SC412B
SC212E
MODEL SC212E SYSTEM SPECS:
Speakers: 2Celestion SEVENTY 80 Speakers
Frequency Response: 72 to 7.5k Hz
Nominal Impedance: Mono 8ΩΩ
Input Connector: One 1/4" Phone Connector
Woofer Enclosure Type: Open back
Enclosure Covering: Black Vinyl
Dimensions: 26"W x 10.25"D x 17.5"H
Warranty: One Year
Weight: 33 lbs.
Optional Cable: PH8
Optional Covers: CV212,
FEATURES
CELESTION
SPEAKERS
