Casa Systems Apex Enterprise Femto User manual

Cautions and Warnings
Caution: The eFemto emits radio frequency electromagnetic energy. To
comply with FCC RF exposure compliance requirements, this device must be
installed to provide a separation distance >20 cm from all persons during
normal operation. For operation within the 5GHz frequency range, this device
is restricted to indoor environments.
Warning: Read and understand the installation instructions and all safety
warnings before connecting the eFemto to the power source. Failure to
understand safety precautions
may result in injury.
Warning: Operate the eFemto only with the power adapter supplied
with the product.
Warning: Do not cover the eFemto or block the airflow to the device
with any objects.
California Prop65 Warning: The plastic and cords on this product contain
phth alates, a chemical known to the State of California to cause cancer,birth
defects and other reproductive harm. Wash hands after handling. For more
information, please visit the following site: www.p65warnings.ca.gov
USA: Federal Communications Commission (FCC) statement
This device complies with FCC part 15 FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
FCC Warning:
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Note: This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device meets the FCC and IC requirements for RF exposure in public or
uncontrolled environments.
FCCID: 2AO38LTE2004-04
What’s in the eFemto Box
eFemto
•Mounting Bracket with Hardware
•GPS Antenna and cable
•Ethernet cable –1.5m
•Power cord
•Power supply (not plenum rated)
•Quick Start Guide
Mounting Procedure
The package contains screws and anchors for drywall mounting. Installation
on alternate surfaces will require the purchase of the appropriate anchors
and hardware.
1. Determine the mounting location and verify that no wires, pipes, etc.,
are directly behind or in the wall at the point of mounting.
2. Use the wall mounting bracket to act as a template to mark anchor
holes on the wall.
3. Drill holes into drywall and push in the supplied plastic drywall anchors.
Installation on surfaces other than drywall may require different
anchoring hardware which can be purchased at your local hardwarestore.
4. Align the mounting bracket with the wall anchors and attach using the
supplied screws.
5. Slide the eFemto with mounting bracket into the wall mountingbracket.
6. Fasten retaining screws (Self-tapped screw,1018 harden, PA4*25, Phillips
2#, Color-Zn plating) on the side of the bracket.
7. When power is supplied through the POE port, the POE power source
should meet the requirements of ES1 and PS2
Connections
Prerequisites
Ethernet and Backhaul (B/H) Requirements
For optimum performance regarding backhaul bandwidth requirements and specific
firewall settings, please refer to the User Guide.
GPS Signal
The eFemto requires a strong GPS signal from the provided indoor GPS antenna. For
installation other than with the provided GPS antenna, please refer to the online 4G
LTE Network Extender for Enterprise User Guide.
Placement
The eFemto can be installed: vertically or horizontally on a wall, floor, or ceiling.
Place the unit at least 10 feet away from products that generate electromagnetic
radiation (e.g., microwave oven).
1. Identify a location for the eFemto, central to users, but no more than
21 feet from an exterior window or wall to allow for a strong GPS
signal.
2. Identify a power source for the eFemto.
3. Follow device mounting, installation and power up steps
Copyright 2020 Casa Systems. All rights reserved.

GPS Installation
Connect the GPS antenna cable (indoor use only) to the GPS port of the eFemto.
Note: The GPS antenna must stay connected to the eFemto at all times for
operation. The initial GPS fix can take up to 60 minutes.
Ethernet and Power Connections
Attach the supplied Ethernet cable from your router or modem LAN port to the
eFemto PoE/WAN port for network connectivity.
Plug in the Power Supply and insert the power cable into the eFemto Power port.
Automatic startup and hardware initialization will begin.
POWER ON
At startup, the eFemto will conduct self configuration. This will take between
30 - 60 minutes the first time the eFemto turns on.
Optional Accessories Available
Power over Ethernet (POE) Device
A full list of optional accessories can be viewed and ordered from
www.verizonwireless.com.Text
Automated Startup
The following Status LED sequence will occur. Upon successful setup, the LED will
blink green.
Note: If the LED fails to turn green after one hour or is blinking a series of red
pulses, consult the troubleshooting section (below).
Troubleshooting
No GPS Signal
The Sync LED off and Alarm LED fix red indicates no GPS signal. Check the About
eFemto page in the Advanced Settings web interface, on the tabs for “Status and
Alerts” or “GPS” to see the status of the GPS constellation.
Is my wireless device connected to the eFemto?
Using the Advanced Settings web interface, sign in and the Connected Devices
panel for indication of connected users.
Cannot reach eFemto GUI or locked out of device.
Press the RESET button for 10 seconds to reset the system to factory default
settings.
Version 1.0 Doc-3185 Rev 1.0
Copyright 2020 Casa Systems. All rights reserved.
