Casablanca PANAMA User manual

1
P/N 6643Z HN0210
BEFORE YOU START .....................................................................................................................................................................5
SAFE USE........................................................................................................................................................................................5
MOUNTING RECOMMENDATIONS................................................................................................................................................6
SLOPED CEILING INSTALLATIONS..............................................................................................................................................6
GETTING STARTED........................................................................................................................................................................7
CROSSBAR MOUNTING BRACKET INSTALLATION...................................................................................................................7
LAG SCREW INSTALLATION (OPTIONAL)...................................................................................................................................8
 .......................................................................................................................................................8
FAN PREPARATION........................................................................................................................................................................8
 ....................................................................................................................................................................9
CANOPY INSTALLATION ...............................................................................................................................................................9
 ........................................................................................................................................................................9
CANOPY ELECTRICAL CONNECTIONS.....................................................................................................................................10
 ................................................................................................................................................10
 .................................................................................................................................... 10
4-SPEED OPERATION .................................................................................................................................................................. 11
 ........................................................................................................... 11
 ........................................................................................................................... 11
......................................................................................................................... 11
 ........................................................................................................................ 12
.................................................................................................... 12
...................................................................................................................................15
SINGLE W-85 INSTALLATION......................................................................................................................................................15
DUAL W-85 INSTALLATION .........................................................................................................................................................16
OPERATION SPEED CONTROL ..................................................................................................................................................17
OPERATION REVERSING AIRFLOW...........................................................................................................................................17
 ....................................................................................................................................................................17
OPERATION POWER....................................................................................................................................................................17
AUTOMATIC DEMONSTRATION PROGRAM ..............................................................................................................................18
............................................................................................................................................18
®PROGRAM ..................................................................................................................................... 19
®®PROGRAM .................................................................................................. 19
OPERATION FAN-MINDERPROGRAM .....................................................................................................................................20
..........................................................................................................................................................21
Safety and the proper operation of your Casablanca fan both require a thorough knowledge
of the product and proper installation; therefore, before attempting to install and operate your
Casablanca fan, read this owner’s manual completely and carefully. Retain this manual for
future reference.
CAUTION: To avoid possible electrical shock, make certain that electricity is turned off
at the circuit breaker or fuse box before attempting any installation procedure.
Panama®Owner’s Manual

CONTENTS

2

Plate

Please take a moment to locate the model number and serial number from your fan (see below)
and record this information on the Warranty page inside the front cover of your Owner’s Manual
if it does not appear there already. These numbers are found on the motor identication plate
afxed to the fan motor in the location shown below:

Your Casablanca fan was crafted with pride and care and inspected thoroughly
prior to shipment. Before you begin to assemble and install your Casablanca
fan, remove all parts from the carton and
check them against the Parts Guide in this
manual.
Make sure all parts are included in the box
using the Parts Guide on the following
pages.
If there are missing or broken parts:
Call 1-888-227-2178 Monday through Friday, 7 a.m. to
4 p.m. PST. Your request will be handled immediate-
ly. Replacement parts will be sent to you via Federal
Express.

Do not remove lightbulbs from their packaging until
you are ready to install them.
Before discarding packaging materials, be certain that
all parts have been removed.
Use a clean, dry paintbrush to remove small Styro-
foam pieces that may remain after unpacking.
Do not brush Styrofoam into wiring cavities.
The blades in each pack are matched for equal weight
to assure smooth fan operation. If more than one fan
is being installed, do not mix blades from different
cartons.
When cleaning, painting, or working near your fan, be
cautious of the fan and blades.
Always turn power to the ceiling fan OFF before re-
placing lightbulbs or working on your fan.
Never insert anything into the path of the fan blades
while the fan is in operation.
Never install a fan over a pool or spa.
Never operate a fan that has been damaged in any
way.
Install the fan according to the instruc-
tions in this manual.
If the fan does not work:
Refer to the Troubleshooting Tips in this Owner’s
Manual.
Call Technical Support at 1-888-227-2178.
Contact your local Authorized Service Center.
Our Web site at www.casablancafanco.com
contains additional information on Casablan-
ca products, troubleshooting, and Authorized
Dealer or Service Centers. Please do not
return this product to the store.
Serial Number
®
  
DJ01 1151 MODEL #66xxG/Z or
66DxxG
POMONA, CA
SERIAL No.: DJ06 2237
66xxZ Model Number

3
Panama®
Item # Description Picture (not to scale) Quantity
1. Motor Housing 1
2. Ceiling plate 1
3. Phillips Screwdriver 1
4. 11/2" x 8-32" Roundhead screws and Washers , 2 EA
5. Screw Pack:
Lag Screw and Washer (1) 1 EA
6. Wire Nuts (4), 4
7. Canopy and Canopy Hatch 1
8. Perma•Lock™ Downrod
and Ball Assembly 1
9. Canopy Screws and Lock Washers, 5 EA
10. Allen Wrench 1
PARTS GUIDE

4
Item # Description Picture (not to scale) Quantity
11. Blade Irons 5
12. Blade Iron Screws 11
13. Blade Screws and Washers 16 EA
14. Light Pull Chain Switch (G model only) 1
15. Light Pull Chain Fandangle (G model only) 2 -(66xxG)
3 -(66DxxG)
16. W-41 Single Rotary (optional for G model only) 1
17. W-81 Dual Rotary (optional for G model only) 1
18. W-85 Control and Mounting Hardware (Z model only)
`
1

5
Panama®
Circuit Breaker
(Trip breaker for the
circuit you will be
working on)
Fuse Box
(Remove fuse for the
circuit you will be
working on)
18"
70"
SAFE USE
CAUTION: RISK OF ELECTRICAL SHOCK! Installation is to be in accordance with the National Electrical
Code, ANSI/NFPA 70-1999 and local codes. If you are unfamiliar with the wiring codes, you should use a
qualied electrician. To avoid overheating and possible damage to other equipment, do not install control to a
receptacle, uorescent light xture, motor-operated appliance, or transformer-supplied appliance.
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for
ceiling fan installations. If it is not, a new box must be installed. Casablanca extension poles are available for
sloped or high ceiling installations.
 This ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit. The maximum
current requirement for the fan with light xture is 3.8 amps. The fan uses about 1 amp or 100 watts. Maximum light
current is 2.8 amps or 340 watts of lighting.
Where wire nuts are employed, be sure all bare wires are within the connectors. When installing the canopy
hatch, make sure all wires are within the canopy and that no wires are being pinched.
 WARNING: Do not bend the blade brackets when installing the brackets, balancing the blades, or cleaning
the fan. Do not insert foreign objects in between the rotating fan blades.
Unpacking
Before assembling and installing your ceiling fan, remove all parts from the shipping cartons
and check them against the parts listed in the Parts Guide. Before discarding packaging ma-
terials, be certain that all parts have been removed.
For best performance and for your warranty to be valid,

Introduction
The blades in each pack are matched for equal
weight to assure smooth fan operation. If more
than one fan is being installed, be careful not to mix
blades from different cartons.
Inspect the contents of your carton for possible
shipping or handling damage. If parts are missing
or damaged, call 1-888-227-2178.
It is always a good idea to have an assistant to help
with the installation.
When cleaning, painting, or working near your fan,
be very careful of the fan and blades. Always turn
the power OFF to the ceiling fan before working on
it or replacing lightbulbs.
Never insert anything into the path of the fan
blades while the fan is in operation.
• Never install a fan over a pool or spa.
Never operate a fan that has been damaged in any
way. Contact Casablanca Fan Company by calling
1-888-227-2178, or contact your local authorized
Casablanca dealer for assistance in obtaining
service.
BEFORE YOU START
84"

6
MOUNTING RECOMMENDATIONS
SLOPED CEILING INSTALLATIONS
Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air
circulation, and fan size are all important factors to consider before installation.
Location
Ceiling fans have practical uses in almost every room in your home.
We suggest you follow these mounting recommendations as you
decide where to install your Casablanca fan.
• For safety reasons, the fan blades must be a minimum of 7' above
the oor.
• Do not locate the fan in a doorway or above a swinging door.
• In bedrooms, fans work best when mounted above the foot of the
bed.
• Over pool tables, be sure to provide plenty of clearance to avoid
damage from pool cues.
• In kitchens be sure to allow for open cupboard doors to clear the fan
blades.
• Do not install a fan close to or over a pool or spa. High humidity combined with corrosive gases will destroy
the nish and warp the blades.
Fan Size
Variable fan speed capability permits the use of a full-size 52" fan even in smaller rooms. For very large rooms,
two fans may be needed.
Calculation of Ceiling Angle
Use the tear-off Ceiling Angle Template
card inserted in this manual. It provides
you with a simple “go” or “no-go” for install-
ing your fan on a sloped ceiling.
7' minimum
When to Use Extension Poles
For optimum performance and appearance, an ex-
tension pole should be used with your Casablanca
fan when installing on high (cathedral) ceilings or
sloped ceilings. Casablanca offers standard poles
in increments of 6" up to 5'. Custom poles are
available in lengths up to 9'9". See your Authorized
Casablanca Dealer for details.
Blades must be a
minimum of 7 feet
above the oor
Extension
Pole
Maximum
Hang-Tru®
angle 32º
This slope is less than 32º.
It is OK to install your fan.
This slope is 32º. This is the maximum
slope that will allow the fan to hang
straight down. It is OK to install your fan.
This slope is more than 32º. Your fan will not
hang straight down, an adaptor is necessary.
Contact your local Authorized Casablanca
Dealer in regards to purchasing a “Sloped
Ceiling Adaptor.”
NOTE: Fan may wobble or vibrate if pole length is
not long enough and inside blade is too close to
downslope or side wall. Extending pole length will
usually solve problem.
SUGGESTED EXTENSION POLE LENGTHS
Ceiling Height Pole Length
8' 0" standard
8' 6" standard
9' 0" 6"
9' 6" 12"
10' 0" 12"
11' 0" 18"
12' 0" 24"
13' 0" 36"
14' 0" 48"
EXAMPLE 3
EXAMPLE 2
EXAMPLE 1
ceiling outlet
box
support
brace
standard
mounting
style

7
Panama®
Using Existing Ceiling Fixture Outlet Box
After turning the power OFF at its source (either
the circuit breaker or fuse box), lower the old xture
and disconnect the wiring. Check the ceiling xture
outlet box to be sure it is marked “Approved for
Ceiling Fan Mounting.” If it is not, a new box must
be installed.
GETTING STARTED
Installing a New Ceiling Fixture Outlet Box
If you do not have an existing xture located where
you wish to place your Casablanca fan, an ap-
proved ceiling xture outlet box must be installed
and wired.
Note: The weight of this fan is 24 to 26 pounds,
depending on model.
WARNING!
To reduce the risk of re, electrical shock, or
personal injury, mount to outlet box marked
“Acceptable Fan Support of 22.7 kg (50
lbs.) or less” using the mounting hardware
provided with the outlet box.
CEILING HARDWARE (not to scale)
WARNING!
Support directly to building structure only.
CROSSBAR MOUNTING BRACKET INSTALLATION
Note: After removing the old xture, check the outlet
box to insure that it is supported by a joist or beam
across its upper surface. If not, a 2 x4 stud must be
installed.
Step 1a. Remove the knockout plug in the center
of the outlet box or drill a 1/2-inch hole for the lag
screw to pass through. Then drill a 1/4-inch guide
hole into the joist or beam to a depth of 3 inches.
Step 1b. Route the outlet box wires through the
keyhole slot of the crossbar mounting bracket as
shown. Attach the crossbar mounting bracket to the
outlet box with the screws provided, making sure
the outlet box wires are not pinched by the washer.
CAUTION:
To reduce the risk of personal injury, use only
the mounting hardware provided with the
approved outlet box to install the crossbar
mounting bracket.
Crossbar Mounting Bracket
Lag Screw and Washer (1)
1" x 8-32 Roundhead Screw and Washer (2)
21/4" x 8-32 Roundhead Screw (2)
Wire Nut (4)
Joist
Ceiling-Fan-
Approved
Wiring Box
Ceiling Wiring
Crossbar
Mounting Bracket
Green Ground Wire
Ridge side down
1" x 8-32
Roundhead Screw
Washer
FAN INSTALLATION
CAUTION:
Damp Location rated fans required a Ground
Fault Interrupter(GFI). use a weather-proof
outlet box, properly connect ground wires,
and use only under a weather-proof structure

8
Prepare for fan installation as follows:
3a. Route the wires from the motor through the PermaLock™
downrod and ball assembly.
3b. Using the provided allen wrench, loosen the set screw
several turns to allow installation of the downrod. Thread
the downrod into the motor coupling until it stops turning,
this will take at least four and a half full turns.
3c. Securely tighten the set screw with the provided allen
wrench to ensure safe operation of your fan.
Tip: The downrod has a tapered thread
that is designed to lock completely when
correctly installed.
CAUTION: Failure to fully lock in the down-
rod before securely tightening the set screw
may cause the fan to separate from the
downrod during normal operation!
MOTOR
COUPLING
TAPERED
THREAD
MOTOR
WIRES
GROUND
WIRE
ALLEN
SET SCREW
DOWNROD
& BALL
ASSEMBLY
FAN PREPARATION
IMPORTANT SAFETY INFORMATION!
BEFORE STARTING THE INSTALLATION OF YOUR CEILING FAN, INSTALL THE
THREADED DOWNROD INTOTHE MOTOR COUPLING AND LOCK THE ASSEMBLY
DOWNROD & BALL
ASSEMBLY

ALLEN SET SCREW
1⁄420 x 1⁄4”
PREINSTALLED
LAG SCREW INSTALLATION OPTIONAL
NOTE: This step is required only under two condi-
tions: If the fan weighs 36 lbs. or more (which does
not pertain to this fan) or if the existing ceiling
xture outlet box needs to be modied for a ceiling
fan application (for example, if the house is not new
construction and you are replacing an existing light
xture). We recommend that the ceiling box be of
sufcient capacity to support the weight of the fan
and light xture under any conditions. If in doubt
whether you need to install the lag screw, consult a
qualied electrician.
Step 2 (optional). With the large washer attached,
pass the lag screw (Pack A) through the center hole
of the crossbar mounting bracket and screw into the
guidehole. Tighten until the outlet box is mounted
rmly to the beam. This box must be secured to the
ceiling rmly.
LAG
SCREW
LARGE
WASHER
1/8"
ALLEN WRENCH

9
Panama®
Step 5. To hang the fan body in the
canopy, hold the fan body rmly and
insert the ball into the canopy open-
ing. Check that no wires were pinched.
Rotate the fan body until the slot in the
nylon ball ts into the pin opposite the
canopy opening.
NOTE: Independent control of the
light xture using a W-81 accessory
control requires an additional pow-
er wire run from the wall switch to
the fan. See Page 12 for wiring.
CAPPED
BLUE
D1OPTION
WIRE ON
3SPEED ONLY
FOR LIGHT
CONTROL PINSLOT
BALL
CANOPY
HATCH
CANOPY LOCK WASHER 5
CANOPY SCREW 5
Step 4. Attach the canopy to the crossbar mounting bracket with three of
the 8-32 x 21/2” long canopy screws and lock washers provided with your
Casablanca fan. Hand tighten until snug against the ceiling.
CANOPY
SCREW
CANOPY
LOCK
WASHER
FEED OUTLET BOX
WIRES THROUGH
CANOPY OPENING
Note: On sloped ceilings, align the
canopy opening toward the top or
peak of the room.
CANOPY HARDWARE
HANGING THE FAN
CANOPY INSTALLATION
CANOPY

10
Step 6a. Attach the fan wires to the ceiling xture outlet
box wiring by twisting the bare ends of the wires together
and then securing with a wire nut. Test that the connection
is secure by pulling on the wire nut. Connect in this order:
Step 6b. W-85 Wiring Connections
 
conductor of power source. Secure with wire nut.
 
xture outlet box. Secure with wire nut.
 -
ing outlet box. Secure with wire nut.
Step 6c. Pull Chain Connections
 
conductor of power source. Secure with wire nut.
 
xture outlet box. Secure with wire nut.
 
ceiling outlet box and the BLUE wire form light kit. Secure
with wire nut.
 
outlet box. Secure with wire nut.
2 WHITE WIRES
2 BLACK
WIRE NUT
PULL CHAIN
CONNECTIONS
3 GREEN WIRES
3 GREEN WIRES
2 WHITE WIRES
2 BLACK + 1 BLUE
W85 CONNECTIONS
Step 7. Tuck the wires into the canopy
with the wire nuts pointed upwards, so
that the WHITE and BLACK wires are on
oppositesides ofthecanopy andallwires
are clear of the canopy opening.
Step 8. Install canopy hatch with the
last canopy screw and lock washer. To
do this, tilt the fan body away from the
hatch opening.
Tighten the screws rmly by hand only,
TILT THE
FAN TO
INSTALL
LAST
CANOPY
SCREW
CANOPY
HATCH
CANOPY
SCREW
LOCK
WASHER
Step 9. Straighten the fan, then check
to ensure that there is no movement be-
tweenthecanopyandceilingorHang-Tru
ball and top support shaft.
CANOPY HATCH INSTALLATION
CANOPY ELECTRICAL CONNECTIONS
If you will be installing an accessory light kit, also connect
the BLUE light power wire from fan to the BLACK wires).

11
Panama®
PROCEED TO YOUR FAN’S CONTROL FEATURE SECTION FOR INSTALLATION/OPERATING INSTRUCTIONS:

BLADE/BLADE HOLDER INSTALLATION
Step 10. Attach the blades to the blade
holders with the three blade screws and
at washers provided for each blade.
Hand tighten securely.
Install the assembled blade and blade
holder to the fan motor.
Hand tighten securely.
Repete for each blade assembly. BLADE SCREW
3 PER BLADE
FLAT WASHER
3 PER BLADE
BLADE HOLDER SCREW
2 PER BLADE HOLDER
Your fan is equipped with a ywheel
that allows for both 4 and 5 blade
installation. The screw holes sur-
rounded by squares are for 4 blade
installation, while the screw holes in
circles are for 5 blade installation as
shown above.
WARNING: To reduce the risk of personal injury, do not bend blade holders
when installing, balancing, or cleaning. Do not insert foreign objects between
rotating fan blades.

12
Pull-chain switches on the fan control the fan and lights.
Using the fan control pull-chain switch: Fan o at start.
First pull: fan ON, High speed
Second pull: Medium speed
Third pull: Medium Low speed
Fourth pull: Low speed
Fifth pull: Fan OFF
Using the optional light pull-chain switch: Light o at
start.
First pull: light ON
Second pull: light OFF
Direction of blade rotation is controlled by the reverse slide
switch on the side of the switch housing.
No changes in household wiring are required.
COLLAR
SWITCH
HOUSING
1. Refer to light kit instructions to assemble and attach your light
kit correctly.
2. Remove the two 8-32 screws from the switch housing cap.
3. Remove the plug from switch housing.
4. Install pull-chain switch and nger tighten collar on switch.
5. Connect one wire from pull-chain switch to the BLUE D1-Option
wire. Secure splice with a wire nut.
6. Connectotherwire frompull-chainswitchtoBLACK wirefromlight
kit. Secure splice with a wire nut.
7. ConnectWHITE wire from switch housing toWHITE wire from light
kit. Secure splice with a wire nut.
8. At the canopy, connect the BLACK and BLUE wires.
The W-41 wall control provides four-speed control of fan from a convenient wall location.
The W-41 is designed to replace a standard wall switch and will t wall boxes with a depth
of 2” or greater. Not for use with single pull-chain fan/light option wiring.
To install a W-41 wall control in place of an existing wall switch, follow the instructions
on the W-41 package.
Note: No rewiring is required if the fan is replacing an existing light xture.
Operation of the fan from the wall switch is simple:
1. Turn knob to obtain desired speed setting.
R
The W-81 wall control provides separate control of fan and light with two separate knobs
from a convenient wall location. The W-81 is designed to replace a standard wall switch
and wall boxes with a depth of 2” or greater. Requires two hot leads from wall box to ceil-
ing wiring box.
To install a W-81 wall control in place of an existing
wall switch, follow the instructions on the W-81 package.
Operation of the fan from the wall switch is simple:
1. Turn the upper knob to the desired fan speed.
2. Turn the lower knob to the desired light setting.
OFF
LO
MED
MED
HI
HI
OFF MAX
CAUTION! Failure to set the pull-chain speed to HIGH can result in faulty operation of
the fan and damage to the W-41 wall control. To conrm fan is set to HIGH: Turn W-41
fan speed switch to‘HI’- set fastest fan speed with pull chain.
CAUTION! Failure to set the pull-chain
speed to HIGH can result in faulty operation
of the fan and damage to the W-81 wall
control. To conrm fan is set to HIGH: Turn
W-81 fan speed switch to ‘HI’ - set fastest
fan speed with pull chain.
NOTE: If a separate circuit is used to control the lights from a wall
control, the BLUE D1-Option wire in the canopy should be con-
nected to that switch leg.
OPTIONAL LIGHT
PULL CHAIN
SWITCH
REVERSE
SWITCH
FAN & SPEED CON
TROL
PULL CHAIN SWITCH
4SPEED OPERATION



BLUE D1
LIGHT FIXTURE
WHITE
BLACK

13
Panama®
R
 
by the W-81 wall control.
 
OFF bytheW-81and the intensity
adjusted from low to high.
 
twoindependent120VACsupply
wires.
 
the HIGH speed setting.
 
 
(4) dierent speed settings.
 
dierent speed settings.
 
 
HIGH speed setting.
 
are required.
 
the W-41 wall control.
CAUTION! Failure to set the pull-chain
speed to HIGH can result in faulty
operation of the fan and damage to
the W-41 wall control. To conrm fan
is set to HIGH: Turn W-41 fan speed
switch to ‘HI’ - set fastest fan speed
with pull chain.
CAUTION! Failure to set the pull-
chain speed to HIGH can result in
faulty operation of the fan and
damage to the W-81 wall control.
To confirm fan is set to HIGH:
Turn W-81 fan speed switch to
‘HI’ - set fastest fan speed with
pull chain.
4SPEED



14
®3
WALL CONTROL AND HARDWARE (not to scale)
Switch Mounting
Screws (2)
Wall Plate
Screws
(2) White
(2) Almond
White Wall
Plate(1)
W-85
Wall Control
Switch Bezels
(1) White
(1) Almond
Almond Wall
Plate(1)
(4) Wire Cap
Before installing the W-85 wall control you will need
to check and see if you will need to change the
bezel on the front of the wall control from WHITE to
ALMOND. If you are going to use white, skip these
steps and go to wall control installation starting on
page 15. The bezel can be changed at any time
before or after installation. The wall control does
not need to be uninstalled to replace the bezel.
W-85 Wall Control Bezel Replacement installation
as follows
Step 17a. Locate the four (4) tabs holding the bezel to
the front of the switch, then press in on each tab one
at a time, removing the bezel as shown in Figure #1.
Step 17b. Locate the rubber key pad attached to
the four (4) locating pins as shown in Figure #2 and
remove rubber key pad from the WHITE bezel, also
as shown in Figure #2.

To avoid possible electrical shock, make cer-
tain that electricity is turned off at the circuit
breaker or fuse box before attempting any in-
stallation or repair procedure
CAUTION! NOT turning the power OFF at the
circuit breaker or fuse box may cause damage to
the electronics within the wall control and or the PC
board on the fan.
Figure #2
WHITE
BEZEL
RUBBER KEY
PAD
LOCATING
PINS (4)
LOCATING
PINS
HOLES(4)
W-85 CONTROL INSTALLATION
Figure #1
BEZEL
BEZEL
TABS

15
®3
LOCATING
PINS (4)
Figure #5
ALMOND
BEZEL
BEZEL
TABS
BEZEL
ALIGNMENT
PIN AND HOLE
Figure #3
ALMOND
BEZEL
RUBBER KEY
PAD
W-85 Wall Control Bezel replacement: -
CONTINUED
Step 17c. Reinstall the rubber key pad on to the
four (4) locating pins located on the almond bezel
as shown in Figure #3 and #4.
Step 17d. To attach the bezel back on to the front
of the switch you will need to align the four (4) tabs
on the bezel with the front of the wall control and
by gently pressing on both top and button of the
bezel at the same time, snap the bezel back on to
the front of the switch as shown in gure #5.
Step 17e. Check your work by pressing on the
light, fan, reverse and power buttons, making sure
that the buttons do not stick and that each switch
functions properly.
RUBBER KEY
PAD
ALMOND
BEZEL
Figure #4
LOCATING
PINS
(4)

16
®3

W-85 CONTROL INSTALLATION
1.Use only the Casablanca W-85 wall control.
2.Do not use any additional control with your Inteli-
Touch 3 fan (for example, dimmer, or fan speed
control).
3.Do not use more than one fan per wall control.
4. No other light xtures or electrical appliances
may be connected on the circuit controlled by the
W-85 wall control.
W-85 is used to describe either white (-11) or almond nish.
If you have multiple Inteli-Touch 3 fans, refer to the section
"Changing Frequency Setting" on page 18.
1. Remove the screws and switch plate from the existing
switch box.
2.Remove the screws holding the switch in the switch
box.
3. Pull the existing switch from the switch box to expose
the wire connections.
4.Remove the two wires from the switch.
5. Connect the BLACK wire from the POWER SOURCE
that you just removed from the switch to the BLACK/
The wall control installs in the same manner as an ordinary light switch, using an existing wall box and wiring. This
controller is designed to signal the fan microcomputer as well as perform normal switching operations. For this
reason the following precautions must be observed:

Ensure power is turned OFF at the breaker or fuse panel before starting installation.
NOTE: The RED wire is not used in this ap-
plication, DO NOT remove the crimped cap
from the wire..

STRIPED WIRE
W-85
Wall Control
2 BLACK
WIRES
RED WIRE
NOT USED
(FIGURE #2)
(FIGURE #1)
NOTE: W-85 Wall Control should only be installed on Casablanca's Inteli-Touch®3 fans with DOWNLIGHTS
ONLY.
WHITE STRIP wire on the W-85 wall con-
trol. Secure this connection with a wire nut.
6. Connect the second BLACK wire that you
just removed from the switch to the second
BLACK wire on the located on the back of
the W-85 wall control. Secure this connec-
tion with a wire nut.
7.Connect the green ground wire coming
from the back of the W-85 control to the
ground wire in the switch box. Secure the
splice with a wire nut.
8.Check your work by using the wiring dia-
grams as shown in Figures # 1 and #2.
9. Install the W-85 in the wall box with the
two long screws provided.
10. Install the wall plate with the two color-
matched screws.
SINGLE W85 INSTALLATION
W-85

17
®3
DUAL W85 INSTALLATION
To control the fan and lights from two locations (a three-way circuit), use two W-85
wall controls as shown in the wiring diagram in Figure #5. Before installing the
two switches into the wall, place both switches side by side, then locate the 4 dip
switches on the side of the two switches. Then make sure that the dip switches
are set to the same address on both switches as shown in Figure #4. When setting
these dip switches you are setting the channel number that is required to control
both your fan and lights from both sides of the room. If you are installing other
Inteli-Touch®3 fans within your home you may need to reset the dip switches on
these other fans to a different channel before installing your W-85 wall control into
the wall. Please review the section on channel changing on this instruction sheet.

(FIGURE #4)

Ensure power is turned OFF at the breaker or fuse panel before
starting installation.
To control thefanand lights fromtwo locations(a three-waycircuit), usetwo
W-85 wall controls.
1. Remove the screws and switch plate from the existing switch box
and the screws holding the switch in the switch box.
2. Pull the existing switch from the switch box to expose the wire con-
nections.
3. Determine which wire is connected to the common terminal from
the power source (120V AC) of the three-way switch. (The terminal
will be marked on switch).
4. Remove the wire from the common terminal of the three-way switch.
Connect this wire to the remaining black/white striped wire on the W-85
control. Secure this splice with a wire nut.
5.Remove the two remaining wires from the three-way switch. Con-
nect the black wire of these wires to a black wire on the W-85 control.
Secure the splice with a wire nut. The remaining red wire is to be con-
nected to the other red wire on the
W-85. Secure the splice with a wire nut.
6.Connect the green ground wire coming from the back of the W-85 con-
trol to the ground wire in the switch box. Secure the splice with a wire
nut.
7.Check your work by using the wiring diagrams as shown in Figure #5
on this page.
8. Install the W-85 in the wall box with the two long screws provided.
9.Install the wall plate with the two short color-matched screws provided.
10.Installation of the second W-85 control is identical. Repeat steps 1 through 9.
W-85
Wall Control

STRIPED WIRE
2 RED WIRES
2 BLACK
WIRES
(FIGURE #5)
W-84
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
RED
GREEN
120V AC
BLACK
BLACK WITH
WHITE STRIPE
W-84
RED RED
RED
BLACK WITH
WHITE STRIPE
GREEN
NEUTRAL
WHITE
GREEN
W-85 W-85

18
®3 OPERATION POWER
The button is normally left in the on position. Always turn the power off
during cleaning or servicing the fan and during thunderstorms. It is also used to
exit or enter additional programs.
The button must be left on to retain a previously set fan speed or light level.
OPERATION SPEED CONTROL
FAN CONTROL
ON - OFF:
A momentary
press of the FAN
button
CHANGE SPEED:
Press and hold
FAN button longer
than one second
There are six individual speed settings for the fan; each speed is indicated
by an audible tone of increasing pitch.
To select the desired fan speed:
1. With fan off, press and hold the button labeled . The fan blades
will start rotating at the slowest speed, and will increase in steps.
2. Release the button when the desired speed is reached.
The fan speed is now in memory and will automatically come on at the
same speed each time the button is used. To maintain this level
of speed, turn the fan on by pressing less than one second. To
lower speed, turn fan off, then on by pressing and holding the
button until the desired speed is reached. When the fan is on, you may
increase the speed by pressing and holding the button until the
desired speed is reached, then release it.
OPERATION REVERSING AIRFLOW
The direction of airow can be changed from down-
ward to upward or from upward to downward.
To reverse the airow:
1. Make sure the is on and blades are Turn-
ing.
2. Press the button.
Note: A four-toned signal
indicates the command was
accepted by the fan. A few
seconds later the fan will slow
to a stop and then reverse
direction.
LIGHT CONTROL
ON - OFF:
A momentary press of
the  button
-
NESS:



SECOND
To turn the lights off and on, press and release the button for less than
one second.
1) First press/release of the button- The light will turn ON.
2) Second press/release of the button- The light will turn OFF.
To vary the light brightness at each touch level:
To vary the light brightness:
1. With lights off, press and hold the button. After one second the lights will
come on at their lowest level and gradually become brighter.
OPERATION LIGHTS
NOTE: Light Operation - the light varies from “bright” to “dim” over
approximately 8 seconds. This sequence will reverse the light when it
reaches the brightest or dimmest level if you continue to hold the LIGHT
button. Release the button when the desired level is reached.
2. Release the button when the desired brightness level is reached.
The brightness level is now in the fan memory and will automatically come on at
the same brightness the next time the button is used.

19
®3 CHANGING FREQUENCY SETTING
NOTE: All fans leave the factory set to
“1111”
You will only have to change the dip switch settings in the remote if you
are using more than one fan in the same area and want to control them
separately.
DIP


SET TO ‘1111’
(Factory Setting)

SET TO ‘1001’
AUTOMATIC DEMONSTRATION PROGRAM
A multi-tone signal will verify the start of the test pro-
gram which proceeds as follows:
• Lights slowly increase to full intensity.
• Fan accelerates to speed three with audio tones.
• Light dims to half intensity.
• Fan accelerates to full speed with audio tones.
• Fan reverses at full speed with audio tones.
• Fan operates at full speed.
• Fan turns off with audio tones (blades coast for a
short time).
• Lights turn off.
The complete cycle lasts slightly over one minute. It
will continue to repeat until the is turned off
for more than ve seconds, cancelling the program.
Programmed into every Inteli-Touch®3 Series fan is
an Automatic Demonstration Program. It can be used
to fully demonstrate and test the operation of the fan.
To enter the demonstration program:
1. Turn off for at least 5 seconds. This will
clear the fan memory ready for programming.
2. Turn on.
3. Immediately operate the buttons in the following
sequence:
+++ +
NOTE: DO NOT set dip switch setting in the remote
to ‘0000’, this may cause frequency interference
from other Casablanca Products.
Step 1. Turn power OFF at the circuit breaker or fuse box and at the toggle
switch, for the fan you want to change.
Step 2. Remove the screws and switch plate from the existing switch box.
Step 3. Remove the screws holding the switch in the switch box.
Step 4. Pull the existing W-85 switch from the switch box to expose the dip
switches located on the side of the control as shown in Figure #1.
Step 5. Change the dip switch settings, assuring that they are different from
the previously installed Inteli-Touch®3 fan.
Step 6. Mount the W-85 Wall Control unit back into the wall electrical box.
Step 7. At the circuit breaker or fuse box and at the toggle switch, turn the
power off for the fan whose frequency you are changing.
Step 8. Within 20 seconds of restoring power to the ceiling fan and the
W-85 Wall Control press and hold both the “FAN” and “REVERSE” buttons
as shown in Figure #2 for 3 seconds, you will hear one tone from the Piezo
Buzzer indicating the command has been accepted.

20
®3
OPERATION HOMESAFE®PROGRAM
The  makes an unoccupied home appear occupied by turning
the lights on and off at random times.
To enter the Home-Safe Program:
1) To operate the lights and fan for Home Safe Program – Press the But-
ton off for a least 5 seconds.
2) Turn the on. Immediately press the buttons in the following sequence:
+ + + . A series of tones will be heard through the
piezo-buzzer and ashing lights indicating the command has been accepted will
follow. This program overrides all manual control of lights and fan. Once the lights
turn on, they will automatically turn off after 2 hours.
3) The lights will automatically cycle on and off in a controlled sequence as follows:
ON 1 hour, OFF ½ hour, ON 2 hours, OFF 1 hour, ON ½ hour then OFF 2 hours.
This seven hour pattern will repeat continuously so that a different pattern of lighting
is seen each day of the week.
4) To cancel the Home-Safe Program, press the Button OFF for ve
seconds.
OPERATION SAFEEXIT®AND LIGHTMINDER®PROGRAM
NOTE: Both Light-Minder and Safe-Exit programs will always run at the same
time.
The Light-Minder Program automatically turns OFF the fan mounted lights after two
hours.
To enter the Light-Minder Program:
1) To operate the lights for Light Minder Program – Press the button off for at
least 5 seconds.
2) Turn the on. Immediately press the buttons in the following sequence:
+ + + . A series of tones will be heard through the piezo-
buzzer indicating the command has been accepted. Once the lights turn on, they will
automatically turn off after 2 hours.
3) Light operation still remains normal, if you leave the room and turn OFF the lights
will blink to indicate this Safe-Exit command has been accepted. The lights will stay
on for 30 seconds and then begin to dim. After thirty seconds have elapsed, the lights
will turn completely off.
4) To cancel the Light-Minder and Safe-Exit Programs, press the button.
The Safe-Exit Program gives you about thirty seconds of light when you turn the
lights off, enabling you to exit your home before the lights go out. To enter the Safe-
Exit Program:
1) To operate the lights for Safe-Exit Program – Press the button off for at
least ve seconds.
2) Turn the Power on. Immediately press the buttons in the following sequence:
+ + + . Immediately press the Button after an audio tone
is heard from the fan controller. The lights will blink to indicate this command has been
accepted. The lights will stay on for 30 seconds and then begin to dim. After thirty
seconds have elapsed, the lights will turn completely off.
3) To cancel the Safe-Exit Program, press the button off for ve seconds.
NOTE: If the lights are left on in the room, the lights will automatically turn
OFF after 2 hours. ( this is Light-Minder)
Light-Minder
Safe-Exit
