Casablanca SIENA User manual

1
SS
SS
SIEIE
IEIE
IENANA
NANA
NA™™
™™
™
Safety and the proper operation of your Casablanca fan both require a thorough knowledge of the product and proper
installation; therefore,before attempting to install and operate your Casablanca fan, read this owner’s manual completely and
carefully. Retain this manual for future reference.
CAUTION: To avoid possible electrical shock, make certain that electricity is turned off at the circuit breaker or fuse box
before attempting any installation procedure.
SIENA®Owner’s Manual
READ AND SAVE THESE INSTRUCTIONS!
CONTENTS
INTRODUCTION
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
MOUNTING RECOMMENDATIONS
General Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Sloped Ceiling Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
FAN INSTALLATION
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Crossbar Mounting Bracket Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Lag Screw Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Canopy Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Fan Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Blade Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
No Light Cap Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Hanging the Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Canopy Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Canopy Hatch Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Light Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
VERSA•TOUCH2™ CONTROL INSTALLATION
Control Bracket Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Changing Transmitter Frequency Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Remote Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TROUBLESHOOTING TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CARE RECOMMENDATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
AUTHORIZED SERVICE CENTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
PRODUCT SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
P5G73M AA1205

2
Circuit Breaker
(Trip breaker for the
circuit you will be
working on)
Fuse Box
(Remove fuse for the
circuit you will be
working on)
18" ↑↑
↑↑
↑
84" ↑↑
↑↑
↑
70"↑↑
↑↑
↑
SAFE USE
•CAUTION: RISK OF ELECTRICAL SHOCK! All wiring must be performed in accordance with national and local
electrical codes. If you are unfamiliar with the wiring codes, you should use a qualified electrician. To avoid overheating
and possible damage to other equipment, do not install control to a receptacle, fluorescent light fixture, motor operated
appliance, or transformer-supplied appliance.
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan
installations. If it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling
installations.
•This ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit.The maximum
current requirement for the fan with light fixture is 3.5 amps. The fan uses about 1 amp or 100 watts. Maximum light
current is about 2.5 amps or 300 watts of total lighting.
•Where wire nuts are employed, be sure all bare wires are within the connectors. When installing the canopy hatch, make
sure all wires are within the canopy and that no wires are being pinched.
Unpacking
Before assembling and installing your ceiling fan, remove all parts from the shipping cartons and check them against the
parts listed in the Parts Guide. Before discarding packaging materials, be certain that all parts have been removed.
For best performance and for your warranty to be valid,
use only genuine Casablanca blades, light fixtures, and accessories.
INTRODUCTION
•The blades in each pack are matched for equal weight to
assure smooth fan operation.If more than one fan is being
installed, be careful not to mix blades from different
cartons.
•Inspect the contents of your carton for possible shipping
or handling damage. If parts are missing or damaged, call
1-888-227-2178.
•It is always a good idea to have an assistant to help with
the installation.
•When cleaning, painting, or working near your fan, be
very careful of the fan and blades. Always turn the power
OFF to the ceiling fan before working on it or replacing
lightbulbs.
•Never insert anything into the path of the fan blades while
the fan is in operation.
• Never install a fan over a pool or spa.
•Never operate a fan that has been damaged in any way.
Contact Casablanca Fan Company by calling
1-888-227-2178, or contact your local authorized
Casablanca dealer for assistance in obtaining service.
BEFORE YOU START

3
SS
SS
SIEIE
IEIE
IENANA
NANA
NA™™
™™
™
MOUNTING RECOMMENDATIONS
Before mounting your Casablanca fan, read the following helpful recommendations. The location of the fan, air circulation,
and fan size are all important factors to consider before installation.
Location
Ceiling fans have practical uses in almost every room in your home.We suggest you follow these mounting recommendations
as you decide where to install your Casablanca fan.
• For safety reasons, the fan blades must be a minimum of 7' above the floor.
• Do not locate the fan in a doorway or above a swinging door.
• In bedrooms, fans work best when mounted above the foot of the bed.
• Over pool tables, be sure to provide plenty of clearance to avoid damage from pool cues.
• In kitchens be sure to allow for open cupboard doors to clear the fan blades.
• Do not install a fan close to or over a pool or spa. High humidity combined with corrosive gases will destroy the finish and
warp the blades.
Fan Size
Variable fan speed capability permits the use of a full-size 52" fan even in smaller rooms. For very large rooms, two fans may
be needed.
GENERAL GUIDELINES
Calculation of Ceiling Angle
Use the tear-off Ceiling Angle Template card inserted in
this manual. It provides you with a simple “go” or “no-go”
for installing your fan on a sloped ceiling.
7' minimum
When to Use Extension Poles
For optimum performance and appearance, an extension
pole should be used with your Casablanca fan when
installing on high (cathedral) ceilings or sloped ceilings.
Casablanca offers standard poles in increments of 6" up
to 5'. Custom poles are available in lengths up to 9'9". See
your Authorized Casablanca Dealer for details.
Blades must be a
minimum of 7 feet
above the floor
Extension
Pole
Maximum
Hang-Tru®
angle 32º
This slope is less than 32º.
It is OK to install your fan.
This slope is 32º. This is the maximum
slope that will allow the fan to hang
straight down. It is OK to install your fan.
This slope is more than 32º. Your fan will not
hang straight down, an adaptor is necessary.
Contact your local Authorized Casablanca
Dealer in regards to purchasing a “Sloped
Ceiling Adaptor.”
NOTE: Fan may wobble or vibrate if pole length is not
long enough and inside blade is too close to downslope or
side wall.Extending pole length will usually solve problem.
SLOPED CEILING INSTALLATIONS
SUGGESTED EXTENSION POLE LENGTHS
Ceiling Height Pole Length
8' 0" standard
8' 6" standard
9' 0" 6"
9' 6" 12"
10' 0" 12"
11' 0" 18"
12' 0" 24"
13' 0" 36"
14' 0" 48"
EXAMPLE 3
EXAMPLE 2
EXAMPLE 1

4
FAN INSTALLATION
CEILING HARDWARE (not to scale)
WARNING!
Support directly to building structure only.
WARNING!
To reduce the risk of fire, electrical shock, or
personal injury, mount to outlet box marked
“Acceptable for Ceiling Fan Support” using the
mounting hardware provided with the outlet box.
Using Existing Ceiling Fixture Outlet Box
After turning the power OFF at its source (either the circuit
breaker or fuse box), lower the old fixture and disconnect
the wiring. Check the ceiling fixture outlet box to be sure
it is marked “Approved for Ceiling Fan Mounting.”If it is
not, a new box must be installed.
GETTING STARTED
Installing a New Ceiling Fixture Outlet Box
If you do not have an existing fixture located where you
wish to place your Casablanca fan, an approved ceiling
fixture outlet box must be installed and wired.
Note: The weight of this fan is 38 pounds.
CROSSBAR MOUNTING BRACKET INSTALLATION
Note: After removing the old fixture, check the outlet
box to insure that it is supported by a joist or beam across
its upper surface. If not, a 2 x4 stud must be installed.
Step 1a. Remove the knockout plug in the center of the
outlet box or drill a 1/2-inch hole for the lag screw to pass
through.Then drill a 1/4-inch guide hole into the joist or
beam to a depth of 3 inches.
Step 1b. Route the outlet box wires through the keyhole
slot of the crossbar mounting bracket as shown. Attach
the crossbar mounting bracket to the outlet box with the
screws provided in Pack A, making sure the outlet box
wires are not pinched by the washer.
CAUTION:
To reduce the risk of personal injury, use only
the mounting hardware provided with the
approved outlet box to install the crossbar
mounting bracket.
Crossbar Mounting Bracket
Screw Pack A:
Lag Screw and Washer (1)
1" x 8-32 Roundhead Screw and Washer (2)
Wire Nut (4)
Joist
Ceiling-Fan-
Approved
Wiring Box
Ceiling Wiring
Crossbar Mounting
Bracket
Green Ground Wire
Ridge side down
1" x 8-32
Roundhead Screw
Washer

5
SS
SS
SIEIE
IEIE
IENANA
NANA
NA™™
™™
™
LAG SCREW INSTALLATION
CANOPY INSTALLATION
NOTE: This step is required only under two conditions:
If the fan weighs 36 lbs. or more or if the existing ceiling
fixture outlet box needs to be modified for a ceiling fan
application (for example, if the house is not new
construction and you are replacing an existing light fixture).
We recommend that the ceiling box be of sufficient
capacity to support the weight of the fan and light fixture
under any conditions. If in doubt whether you need to
install the lag screw, consult a qualified electrician.
Step 2. With the large washer attached, pass the lag screw
(Pack A) through the center hole of the crossbar mounting
bracket and screw into the guidehole. Tighten until the
outlet box is mounted firmly to the beam. This box must
be secured to the ceiling firmly.
Step 3. Attach the canopy to the crossbar mounting bracket
with three of the 8-32 x 21/2" long canopy screws (Screw
Pack B) and lock washers provided with your Casablanca
fan. Tighten using the provided screwdriver until snug
against the ceiling.
NOTE: On sloped ceilings, align the canopy opening
with the top or peak of the room.
CANOPY HARDWARE (not to scale)
Canopy
Canopy Hatch
Feed outlet box
wires through
canopy opening
Canopy
Lock Washer
Canopy Screw
Pack B:
Canopy Screws and Washers (5)

6
FAN PREPARATION
PERMA•LOCK™ HARDWARE (not to scale)
Prepare for fan installation as follows:
Step 4a. Remove the caution shield from the motor.
Step 4b. Using the provided Allen wrench (attached to
the paper motor warning shield),loosen the Allen set screw
attached to the motor coupling.
Step 4c. Slide the 9" Perma•Lock™downrod and ball
assembly through the center of the Decorative Arm
assembly.
Step 4d. Route the wires through the Perma•Lock™
downrod and ball assembly.
Step 4e. Insert the downrod into the motor coupling,
turning clockwise until it stops, ensuring that the pole
has bottomed out.
TIP: The downrod has a tapered thread that is designed
to lock completely when installed correctly.
Step 4f. Tighten the set screw with the Allen wrench to
ensure safe operation of your fan.If it is tight enough, you
should not be able to turn the downrod counterclockwise
with your hands. If in doubt, tighten the set screw with
the Allen wrench until you cannot turn it any further.
Step 4g. Tighten collar screw on Decorative Arm
Assembly to secure.
Motor Wires
(leave at least 6" long)
Ground Wire
(green)
Perma•Lock™ Downrod
and Ball Assembly
Tapered thread
Allen Wrench
Allen
Set Screw
Motor Housing
Assembly
Motor
Coupling
IMPORTANT SAFETY INFORMATION:
Before starting the installation of your ceiling
fan, install the threaded downrod into the motor
coupling and lock the assembly.
CAUTION: Failure to fully lock in the downrod
before securely tightening the Allen set screw may
cause the fan to separate from the downrod and fall
during normal operation.
Uplight Lightbulbs
(4) A-15 40-watt Allen Wrench
Decorative Arm
Assembly
9" Perma•Lock™
Downrod
and Ball Assembly
(for decorative
arm assembly
installations)
3" Perma•Lock™
Downrod
and Ball Assembly
(for non-decora-
tive arm assembly
installations)
NOTE: Installation of the Decorative Arm Assembly is
optional. For installations without the Decorative Arm
Assembly, a 3" downrod is provided.
3" Perma•Lock™ Downrod
and Ball Assembly
(for non-decorative arm
assembly installations)
Caution Shield
Decorative Arm
Assembly

7
SS
SS
SIEIE
IEIE
IENANA
NANA
NA™™
™™
™
Installation/Replacement of Incandescent Lightbulbs
Step 5. Remove the two screws from the cover door as
shown and lift door from motor. Install a 40-watt S-11
type incandescent lightbulb in the socket.Replace the door
and re-insert the screws. Repeat twice more.
NOTE: When replacing lightbulbs, be sure to use only
40-watt maximum.
BLADE INSTALLATION
Blades (5)
Allen Screw Pack C:
Blade Screws and Washers (16)
BLADE HARDWARE (not to scale)
Step 6a. Align the holes in the Siena® exclusive blade with
the holes in the bladeholder.
Step 6b. Using Screw Pack C and the Allen wrench
provided, install the Allen screws in the blade and
bladeholder as shown. Repeat for each additional blade.
CAUTION:
Blade screws must be tightened securely before
operating the fan.
NO LIGHT CAP OPTION
Note: If you are installing the accessory light fixture, skip
to Step 8a now.
Step 7a. Carefully tuck the light wires into the no light
cap, as shown.
Step 7b. Thread the no light cap into the adapter plate, as
shown.
Allen
Wrench
FAN PREPARATION (CONT.)

8
HANGING THE FAN
Step 8a. To hang the fan body in the canopy, hold the fan
body firmly and insert the ball into the canopy opening.
Check that no wires are pinched. Rotate the fan body until
the slot in the ball fits into the pin opposite the canopy
opening.
Step 8b. Trim excess motor wires,leaving at least 6 inches
above the downrod.Strip 1/2-inch insulation from the end
of each wire using a wire stripper (available at your local
hardware store).
Step 9. Attach the fan wires to the ceiling fixture outlet
box wiring by placing the bare ends of the wires side by
side and then securing with a wire nut. Test that the
connection is secure by pulling on the wire nut. Connect
in this order:
•GREEN leads from mounting plate and downrod
assembly of fan to GROUND conductor of power
source. Secure with wire nut.
•WHITE wire from fan to white NEUTRAL wire in
ceiling fixture outlet box. Secure with wire nut.
•BLACK power wire from fan to BLACK power wire
in ceiling outlet box. Secure with wire nut
NOTE: If the color of your ceiling wires differs from
that described, consult an electrician.
CANOPY ELECTRICAL CONNECTIONS
Step 10a. Tuck the wires into the canopy with the wire
nuts pointed upwards, so that the WHITE and BLACK
wires are on opposite sides of the canopy and all wires are
clear of the canopy opening.
Step 10b. Install the canopy hatch with the last canopy
screw and lock washer using the provided screwdriver.To
do this, tilt the fan body away from the hatch opening.
Tighten the screws firmly.
Step 10c. Straighten the fan, then check to ensure there is
no movement between the canopy and the ceiling or the
Perma•Lock™downrod and the ball assembly.
CANOPY HATCH INSTALLATION
Ball
Slot Pin
Wire Nut
2 Black
Wires
2 White
Wires
3 Green
Wires

9
SS
SS
SIEIE
IEIE
IENANA
NANA
NA™™
™™
™
LIGHT KIT INSTALLATION
Light Assembly Installation
Step 11a. Connect the light assembly connector to the
motor connector, as shown.
Step 11b. Carefully tuck the wires and align the light
assembly with the adapter plate.
Step 11c. Screw the finial rod into the adapter plate to
secure.
Install Glass Shades
Step 12a. Remove the three lock rings from the light fixture
and set aside.
Step 12b. Slide the glass shade into the fixture and hold
firmly. Using the glass locking rings removed in Step 14a,
secure each piece of glass firmly to the light fixture.
Assure each piece of glass is firmly installed by rotating
the glass clockwise until it is no longer loose.
Install Incandescent Lightbulbs
Step 13a. Screw the three 60 Watt type A15 bulbs into
each socket.
NOTE: When replacing lightbulbs, be sure to use only
60-watt maximum.
LIGHT KIT HARDWARE (not to scale)
Light Kit
Downlight Lightbulbs (3)
60-watt A-15
Glass Shade
Finial Rod
Finial
Lock Ring

10
Screw
6-32 X 1"
(2)
Screw
6-32 X 3/8"
(2)
Wood
Screw
1" (2)
Drywall Anchor
6-32 (2)12v Battery
W-73
Control
W-73
Control Holder
VERSA•TOUCH2™ CONTROL INSTALLATION
CONTROL BRACKET INSTALLATION
Standard Light Switch
Step A. Remove the two screws holding the switch cover
plate. Do not remove the cover plate.
Step B. Orient the control bracket as shown and line up
the two inner mounting holes with those on the switch.
Step C. Insert and tighten the screws using the provided
screwdriver.
Inner
mounting
holes
Control
Bracket
Standard
Toggle
Switch
Switch
Cover
Plate
Rocker Light Switch
Step A. Break off the two tabs by pushing outward.
Step B. Remove the two screws holding the switch cover
plate. Do not remove the cover plate.
Step C. Orient the control bracket as shown and line up
the two inner mounting holes with those on the switch.
Step D. Insert and tighten the screws using the provided
screwdriver.
Outer
mounting
holes
Control
Bracket
Rocker
Light
Switch
Switch
Cover
Plate
Wall Installation
Step A. Locate a 2x4
wall stud in a convenient
location.
Step B. Orient the
control bracket as shown
over the 2x4 stud.
Step C. Insert the 1"
wood screws in either
the inner or outer
mounting holes and
tighten using the
provided screwdriver. Decor Ovalhead Screw
6-32 X 1"
Anchor
Panhead
Screw Drywall Anchor
NOTE: The wall anchors and 6-32 x 1" screws may be
used in situations where mounting to a stud is not possible.
Use the inner mounting holes. After securing the anchor,
discard the anchor’s pointed screws and use the 6-32 decor
ovalhead screws supplied.
SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with
an isolating wall control/switch. CAUTION! Do not use with wall dimmer.
Wood
Screw 1"
VERSA•TOUCH2™ HARDWARE (not to scale)
Step 14 Follow instructions for the type of transmitter control bracket you will be using.
