Safety and the proper operation of your Casablanca fan both require a thorough knowledge of the product and proper
installation; therefore, before attempting to install and operate your Casablanca fan, read this owner’s manual completely
and carefully. Retain this manual for future reference.
Caution: To avoid possible electrical shock, make certain that electricity is turned off at the circuit breaker or fuse box
before attempting any installation procedure.
Silhouette II ™Owner’s Manual
READ AND SAVE THESE INSTRUCTIONS!
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
MOUNTING RECOMMENDATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CEILING MEDALLION PREPARATION AND INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ceiling Medallion Bracket Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
MOTOR INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Motor Housing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Medallion Plate Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
BLADE PREPARATION AND INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
LIGHT FIXTURE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
VERSA•TOUCH2™ CONTROL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Control Bracket Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Changing Transmitter Frequency Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Remote Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TROUBLESHOOTING TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CARE RECOMMENDATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AUTHORIZED SERVICE CENTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
PRODUCT SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
C2M72M AA1205

2
Circuit Breaker
(Trip breaker for the
circuit you will be
working on)
Fuse Box
(Remove fuse for the
circuit you will be
working on)
18" ↑↑
↑↑
↑
84" ↑↑
↑↑
↑
70"↑↑
↑↑
↑
SAFE USE
•CAUTION: RISK OF ELECTRICAL SHOCK! All wiring must be performed in accordance with national and local
electrical codes. If you are unfamiliar with the wiring codes, you should use a qualified electrician. To avoid overheating
and possible damage to other equipment, do not install control to a receptacle, fluorescent light fixture, motor operated
appliance, or transformer-supplied appliance.
• This fan is designed to be installed on an existing electrical outlet box. The outlet box must be UL Listed for ceiling fan
installations, if it is not, a new box must be installed. Casablanca extension poles are available for sloped or high ceiling
installations.
•This ceiling fan requires a grounded electrical supply of 120 VAC, 60 Hz and a minimum 15 amp circuit. The maximum
current requirement for the fan with light fixture is 3.8 amps. The fan uses about 1 amp or 100 watts. Maximum light
current is about 1 amp or 100 watts of lighting.
•Where wire nuts are employed, be sure all bare wires are within the connectors. When installing the canopy hatch, make
sure all wires are within the canopy and that no wires are being pinched.
For best performance and for your warranty to be valid,
use only genuine Casablanca blades, light fixtures, and accessories.
INTRODUCTION
•The blades in each pack are matched for equal weight to
assure smooth fan operation.If more than one fan is being
installed, be careful not to mix blades from different
cartons.
•Inspect the contents of your carton for possible shipping
or handling damage and report any such damage directly
to your authorized Casablanca dealer.
•It is always a good idea to have an assistant to help with
the installation.
•When cleaning, painting, or working near your fan, be
very careful of the fan and blades. Always turn the power
OFF to the ceiling fan before servicing it, working on it,
or replacing lightbulbs.
•Never insert anything into the path of the fan blades while
the fan is in operation.
• Never install a fan over a pool or spa.
•Never operate a fan that has been damaged in any way.
Contact Casablanca Fan Company by calling
1-888-227-2178, or contact your local authorized
Casablanca dealer for assistance in obtaining service.
BEFORE YOU START

3
SILHOUETTE II™
MOUNTING RECOMMENDATIONS
Before mounting your Casablanca fan, read the following helpful recommendations.The location of the fan, air circulation,
and fan size are all important factors to consider before installation.
Location
Ceiling fans have practical uses in almost every room in your home. We suggest you follow
these mounting recommendations as you decide where to install your Casablanca fan.
• This fan is not suitable for installation on a sloped ceiling.
• For safety reasons, the fan blades must be a minimum of 7' above the floor.
• Do not locate the fan in a doorway or above a swinging door.
• In any installation, the tips of the blades must be at least 18" from the wall in order
to provide sufficient clearance for the blades.
• In bedrooms, fans work best when mounted above the foot of the bed.
• In low ceiling locations, our optional Low Ceiling Adaptor (LCA—available at extra cost) can be used to gain 31/2" on
certain fan models.
• Over pool tables, be sure to provide plenty of clearance to avoid damage from pool cues.
• In kitchens be sure to allow for open cupboard doors to clear the fan blades.
• Do not install a fan close to,or over, a pool or spa. High humidity combined with corrosive gases will destroy the finish and
warp the blades.
Fan Size
Variable fan speed capability permits the use of a full-size 52" fan even in smaller rooms. For very large rooms, two fans may
be needed.
GENERAL GUIDELINES
WARNING!
To reduce the risk of fire, electrical shock, or
personal injury, mount to outlet box marked
“Acceptable for Ceiling Fan Support” using the
mounting hardware provided with the outlet box.
Using Existing Ceiling Fixture Outlet Box
After turning the power OFF at its source (either circuit breaker or fuse box), lower the old fixture and disconnect the wiring.
Check the ceiling fixture outlet box to be sure that it is marked “Approved for Ceiling Fan Mounting.”If it is not, a new box
must be installed.
Installing a New Ceiling Fixture Outlet Box
If you do not have an existing fixture located where you wish to place your Casablanca fan, an approved ceiling fixture outlet
box must be installed and wired.
GETTING STARTED

4
CEILING MEDALLION BRACKET INSTALLATION
Step 1a: Lay ceiling medallion bracket on flat surface, flat
side down. Insert four adjuster screws (Pack A) in outer
screwholes as shown and hand-twist two full full turns.
Step 1b. Insert motor housing screws (Pack B) into three
screwholes as shown in picture and hand-twist two full turns.
Step 1c. Turn ceiling medallion bracket over and raise flat
side to ceiling.
Step 2a. Remove the knockout plug in the center of the out-
let box.
Step 2b. Route the outlet box wires through the center hole
of the ceiling medallion bracket. Attach the ceiling medal-
lion bracket to the outlet box with the screws provided (Pack
C), ensuring that the outlet box wires are not pinched by the
washer.
Ceiling Medallion Bracket Motor Assembly Motor Housing Medallion Plate
CEILING MEDALLION PREPARATION AND INSTALLATION
Screw Pack A:
Adjuster Screws (4)
Screw Pack B:
Motor Housing Screws (3)
Screw Pack C:
3" x 10-32"
roundhead screws (2)
11/2" x 8-32"
roundhead screws (2),
washers (4),
nuts (4)
CEILING MEDALLION HARDWARE (not to scale)
A
B
WARNING!
Support directly to building structure only.
CAUTION:
To reduce the risk of personal injury, use only the
mounting hardware provided with the approved
outlet box to install the ceiling medallion bracket.
A
B
B
A
A

5
SILHOUETTE II™
MOTOR INSTALLATION
NOTE: You will need an assistant to help hold up the
ceiling medallion bracket and motor in steps 3 and 4.
Step 3a. Remove the paper shield from the motor.
Step 3b. Attach one of the hooks on the outside of the
motor onto one of the loops hanging from the ceiling
medallion bracket.
Step 3c. Attach the fan wires to the ceiling medallion
bracket wiring by placing the bare end of the wires side by
side and then securing with a wire nut (Pack C).Test that
the connection is secure by pulling on the wire nut.
Connect in this order:
• GREEN leads from ceiling medallion bracket
to GROUND conductor of power source. Secure with
wire nut.
• WHITE wire from fan to white NEUTRAL wire in
ceiling medallion bracket. Secure with wire nut.
• BLACK power wire from fan to BLACK power wire in
ceiling medallion bracket. Secure with wire nut.
NOTE: If the color of your ceiling wires differs from that
described, consult an electrician.
Step 3d. Trim excess motor wires to six inches and tuck
inside.
Step 3e. Attach other two hooks.
Motor
Hooks
Ceiling
Medallion
Loops
MOTOR HOUSING INSTALLATION
Step 4. Align the three motor housing (B) screws into the
keyholes on the motor housing and twist until secure.
Tighten screws using the Phillips-head screwdriver.
NOTE: When aligning the screws, center the motor
housing so that there is an even amount of space all around
the motor.
1 Blue to 1 Black wire
2 White Wires
3 Green Wires

6
Step 5. Raise the medallion plate to the ceiling medallion
bracket and fit the four keyholes into the adjuster (A) screws.
To align, insert an alignment tab onto each of the four
adjustment screws with the printed side facing up. Align
the raised dots with the alignment tabs.Twist the medallion
plate clockwise until locked into place. Pull out the four tabs.
MEDALLION PLATE INSTALLATION
BLADE PREPARATION AND INSTALLATION
Medallion Plate
Ceiling Medallion
Bracket
Blade Irons (5)
Blade Medallions (5)
Blades (5)
Screw Pack D
Blade Screws (21)
Screw Pack E
Blade Iron Screws (11)
Step 6a. Sandwich a blade between a blade medallion and
blade iron. Thread four blade screws (Pack D) through the
screwholes and tighten using the provided screwdriver.
Repeat for each blade.
Step 6b. Attach each blade/blade iron assembly to the motor
by threading two blade iron screws (Pack E) through the
matching holes in the blade iron and the motor. Using the
Phillips screwdriver, tighten the screws loosely. After all five
blade assemblies have been installed, tighten the screws
securing with the screwdriver. Blade Iron Screws
Blade Screws
BLADE HARDWARE (not to scale)
Alignment
Tabs
Raised
Dots

7
SILHOUETTE II™
LIGHT FIXTURE INSTALLATION
Step 7a. Insert three switch housing screws (Pack F) into
the screwholes in the center of the motor.
Step 7b. Hold the switch housing up to the motor. Feed
the wires through the center hole and align the switch
housing screws (F) with the keyholes. Twist the switch
housing clockwise.
Step 7c. Tighten all three screws using the screwdriver.
Step 7d. Remove the ceramic wire nuts from the wires on
the socket plate and set aside for use in the next two steps.
Step 7e. Attach the WHITE wire on the socket plate to
the WHITE wire on the switch housing. Secure with a
ceramic wire nut.
Step 7f. Attach the BLACK wire on the socket plate to
the BLUE wire on the switch housing. Secure with a
ceramic wire nut.
Step 7g. Align the three holes on the socket plate with the
screwholes on the switch housing.Insert three socket plate
screws (Pack G) and tighten until secure using the
screwdriver.
Step 7h. Remove the lightbulb shield from the socket plate.
Insert one end of the halogen bulb into the socket. Push
the end of the socket, then insert the other side of the
halogen bulb into the socket. Re-insert lightbulb shield.
Step 7i. Position the indentations in the outer rim of the
glass shade so that they line up with the tabs on the inside
surface of the fan light fixture rim.
Step 7j. Carefully lift the glass shade up inside the light
fixture as far as it will go. Rotate the shade in a clockwise
direction until it is held tightly in place by the three tabs.
Switch Housing
Socket Plate &
Bulb Shield Glass Shade
Pack F
Switch Housing
Screws (3)
Pack G
Socket Plate
Screws (3)
Halogen Lightbulb
LIGHT FIXTURE HARDWARE (not to scale)
Switch Housing
Screws
Socket Plate Screws
Glass Shade
Halogen
Lightbulb
CAUTION:
The halogen bulb is very delicate and should not be
handled with bare hands. After removing it from
the box, grasp it gently by the plastic covering or a
soft cloth.
Ceramic
Wire Nuts
Lightbulb
Shield

8
Screw
6-32 X 1"
(2)
Screw
6-32 X 3/8"
(2)
Wood
Screw
1" (2)
Drywall Anchor
6-32 (2)12v Battery
W-72
Control
W-72
Control Holder
VERSA•TOUCH2™ CONTROL INSTALLATION
CONTROL BRACKET INSTALLATION
Standard Light Switch
Step A. Remove the two screws holding the switch cover
plate. Do not remove the cover plate.
Step B. Orient the control bracket as shown and line up
the two inner mounting holes with those on the switch.
Step C. Insert and tighten the screws using the provided
screwdriver.
Inner
Mounting
holes
Control
Bracket
Standard
Toggle
Switch
Switch
Cover
Plate
Rocker Light Switch
Step A. Break off the two tabs by pushing outward.
Step B. Remove the two screws holding the switch cover
plate. Do not remove the cover plate.
Step C. Orient the control bracket as shown and line up
the two inner mounting holes with those on the switch.
Step D. Insert and tighten the screws using the provided
screwdriver.
Outer
Mounting
Holes
Control
Bracket
Rocker
Light
Switch
Switch
Cover
Plate
Wall Installation
Step A. Locate a 2x4 wall
stud in a convenient
location.
Step B. Orient the control
bracket as shown over the
2x4 stud.
Step C. Insert the 1" wood
screws in either the inner
or outer mounting holes
and tighten using the
provided screwdriver.
Decor Ovalhead Screw
6-32 X 1"
Anchor
Panhead
Screw Drywall Anchor
NOTE: The wall anchors and 6-32 x 1" screws may
be used in situations where mounting to a stud is not
possible.Use the inner mounting holes. After securing
the anchor, discard the anchor’s pointed screws and
use the 6-32 decor ovalhead screws supplied.
SAFETY FIRST: To reduce the risk of electrical shock, this fan must be installed with
an isolating wall control/switch. CAUTION! Do not use with wall dimmer.
Wood
Screw 1"
VERSA•TOUCH2™ HARDWARE (not to scale)
Step 8. Follow instructions for the type of transmitter control bracket you will be using.

9
SILHOUETTE II™
Send Signal
LED
Fan Control
To start the fan. Press the selected speed button to run the fan at the desired speed.
LOW=Low speed MED=Medium speed HIGH=High speed
To turn off the fan, press the FAN OFF button.
Airflow Direction
To reverse the airflow, press the REVERSE button. REVERSE operates at any speed
whether the fan is on or off.The fan returns to its set speed after reversing.
Light Control
Turn the light on or off independently from the fan by pressing the LIGHT button. If you
press the button for more than 0.7 seconds, it becomes a dimmer. The light varies from
“bright" to “dim”over approximately 8 seconds. If you continue to hold the LIGHT button,
this sequence will reverse when the light reaches its brightest or dimmest level. Release the
button when the desired level is reached.
Auto Resume
Quick (pressing less than 0.7 seconds) on/off operation of the LIGHT button maintains
the desired brightness level set previously.
If the fan is not functioning after installation:
Step 1. Check to make sure that batteries are installed correctly
in the control.
Step 2. Turn the power off to the fan (from the circuit breaker)
for at least 5 seconds.
Step 3. Turn the power back on (at the circuit breaker) and push
the HIGH, MED, and LOW buttons–in that order–within 20
seconds.
Step 4. The fan should now function properly.
CHANGING TRANSMITTER FREQUENCY SETTING
You will only have to change the dip switch settings in the re-
mote if you are using more than one fan in the same area and
want to control them separately.
Step 1. At the circuit breaker or fuse box, turn the power off for
the fan you want to change.
Step 2. Open the battery door of the Versa•Touch control and
remove the batteries.
Step 3. Change the dip switch settings, assuring that they are
different from the previously installed Versa•Touch fan.
Step 4. Re-install the batteries and the battery door on the control.
Step 5. At the circuit breaker or fuse box,turn the power back on
for the fan whose frequency you are changing.
Step 6. Within 20 seconds of restoring power, push the HIGH,
MED, and LOW buttons (in that order).
Circuit Breaker
or Fuse Box
Press in this order to set new
frequency:
1. HIGH 2. MED 3. LOW
Dip Switch
Set to “01001”
Dip Switch
Set to “10000”
Versa•Touch 2
Control
(back)
LOW
MED
HIGH
LIGHT
FAN
OFF
REVERSE
1
2
3
Note: You may want to label your controls to assure you
do not mix them up.
REMOTE OPERATION
WARNING!
Do not turn the power off at the circuit breaker,
then back on, for the previously installed
Versa•Touch2 fan(s), as you may inadvertently
change the frequency settings for it as well.
Note: All fans leave the factory set to “00000.”

10
Please refer to this troubleshooting guide before requesting service or contacting your dealer for assistance.
TROUBLESHOOTING TIPS
PROBLEM POSSIBLE REMEDIES
Fan will not start • Check the main circuit fuses, circuit breakers, and wall switch position. Check all wire
connections. Make sure the power is turned off during this inspection.
• The 9-pin connector is not making good contact. Check the 9-pin connector in the
receiver mounted in the switch housing (see receiver diagram on page 11).
• The battery is weak. Install a fresh battery.
• The fan receiver is defective. Replace fan receiver.
• Check the frequency setting: Turn the power off at the circuit breaker, only for the fan
that is not functioning. Check that the jumper switches match in both the receiver and
the transmitter.
Fan wobbles or shakes excessively • Be sure the canopy pin is set properly into the slot on the ball.
• Check that the bladeholders have not been bent during installation and the blades are
balanced.
• The hanger bracket and/or ceiling outlet are attached too loosely. Make sure the hanger
bracket is attached tightly to the ceiling outlet box and the downrod assembly is secured
firmly.
• The downrod is attached to downrod base too loosely. Make sure all the screws are
securely tightened.
Fan is noisy during operation • Check and tighten the light fixture retaining screws, glass shade screws, and/or
lightbulb(s).
• Tighten the canopy screws and mounting plate assembly.Make sure the wire nuts inside
the canopy and switch housing are not touching the metal parts and that they have not
fallen off the wire splices. Tighten as necessary.
• Tighten the blade holders to the flywheel (or direct drive motor) and the blades to the
bladeholder screws.
• Make sure all screws in the motor housing are snug but not overly tight.
Fan does not run on low speed • If fan is new, it may need to be “broken in.” Run at high speed for several days.
Battery life is short • Replace with alkaline batteries.
Light works, but fan does not work • The fan wires are not connected properly. Follow the instructions in Step 3c.
Fan and light run only on full speed • The fan receiver is defective. Replace fan receiver.
Fan is missing one speed • The fan receiver is defective. Replace fan receiver.
Fan does not change speed, but light works • The fan receiver is defective. Replace fan receiver.
Reverse does not work • The fan receiver is defective. Replace fan receiver.
Fan starts working by itself • There is frequency interference. Change frequency as described on Page 9.
Fan operates only when transmitter is close • Check that antenna wire is not touching metal plate.
Fan works, but light does not dim • The fan receiver is defective. Replace fan receiver.
Fan works, but light does not work • The fan receiver is defective. Replace fan receiver.
• The light socket is broken. Replace socket.
• A lightbulb is defective. Replace lightbulb.
