Casals CTRL-DPH Manual

www.casals.com
CV072018-1
CTRL-DPH
USER MANUAL AND SET INSTRUCTIONS

2
CV072018-1
INDEX
MAIN WINDOW DISPLAY
MANAGEMENT OF FAN SPEED, FLOW OR CONSTANT PRESSURE
BOOSTER FUNCTION
AIR POST-TREATMENT MANAGEMENT
PREHEATING MANAGEMENT
SELECTION MENÚ
STATUS MENÚ: OPERATING STATUS
PROGRAM MENÚ: MANAGEMENT OF THE WEEKLY SCHEDULE
DEFAULT/ PROG. PREDEF.
TIMETABLE
ADJUSTMENT OF SPEED LEVELS
CLOCK MENÚ: CLOCK SETTINGS
ALARMS MENÚ VISUALIZATION OF THE STATUS OF THE ALARMS
INSTALLER MENÚ: CONFIGURATION OF THE INSTALLATION PARAMETERS
WINTER/ SUMMER TEMPERATURE
MODBUS COMMUNICATION
BOARDS
INSTALLATION
WIRING CONTROL PANEL
CONTROL CHARACTERISTICS
WARRANTY CONDITIONS
DIMENSIONS
MOUNTING
p. 3
p. 4
p. 5
p. 5
p. 6
p. 6
p. 7
p. 9
p. 10
p. 11
p. 12
p. 13
p. 13
p. 16
p. 17
p. 24
p. 26
p. 27
p. 31
p. 31
p. 31
p. 31
p. 32
p. 33

3
CV072018-1
VISUALIZATION MAIN SCREEN
The touch screen control panel has been designed to manage units of Mechanically Controlled Ventilation with Heat Recovery (VMC-RC) in
a simple and intuitive way. The user manages the control by means of the icons of the graphic screen making a slight pressure on them;The
direction buttons, which appear after the pressure in a modifiable parameter, allow the user to interact with the unit by going through menu
items and modifying values.Pressing the OK button confirms the modifications or selections made.The color change (green) of an icon after
a press indicates that the parameter represented by that icon can be changed.When an element of the submenus is highlighted, it appears in
background color on a blue background, pressing OK the title changes to green and modifications can be made with the direction buttons.
The main window is a detailed graphic representation of the state of the machine from which all available functions can be activated.To chan-
ge the window and access the other menus, you have to press the icon to change the menu window. From the other windows you can return
to the previous one by selecting the mentioned icon and pressing OK.To save energy the control is placed in standby mode (paid screen) after
a minute of inactivity, pressing at any point on the screen is automatically reactivated.In the presence of alarms, on the other hand, the screen
lights up for half a second approximately every ten.
Unit without bypass Unit with bypass
*= Modifiable parameter
Exhaust fan
External air temperature
* Fan speed sign Preheating sign (CTRL-DPH)
* Change screen sign
Temperature return air
Temperature air in
Post-heating sign
* Adjustment point temperature
By-pass sign
Expelled air temperature
* Timer
Humidity sign Supply fan

4
CV072018-1
MANAGEMENT OF FAN SPEED, FLOW OR CONSTANT PRESSURE
To modify this parameter, the icon at the top right of the synoptic table must be selected by clicking on it (it will turn green and the direction
buttons will appear).Then press the icon of the address button up to increase or down direction to decrease the value located next to it; Once
the desired one is located, press the OK button to confirm the selection. At first it is possible to turn off the machine directly by pressing the
central button,it disappears automatically by pressing the direction buttons.The variation can be expressed as a percentage for variable spe-
ed machines,with a simple 1-2-3 for machines with 3 speeds,in flow (m³ \ h) for machines with constant flow or pressure (Pa) for machines with
constant expression (equipped with the corresponding supplementary kit,see page 29).For these last two models,once the desired value has
been selected,the speed of the fans will automatically vary to keep the flow or the set pressure constant.For machines with a sensor mounted
different from the cop / cav kit, but always with constant pressure or flow rate,enter the percentage value of the pressure or flow scale of the
unit. The regulation it will be carried out in the same way. This also applies to the settings of the weekly programming menu (Program). In
addition to the scale value, the timer element will appear and, if selected,will start the default weekly time program (see Program menu). If an
air quality, relative humidity sensor is present in the unit or if the analog input (0-10V) is activated, we will also have the automatic selection
that allows the automatic regulation of the fan speed in function of CO2, Humidity measured or by an external signal.
In detail the possible selections are:
- off: with this selection, the fans are stopped. Be careful because in any case the unit is electrically powered; this value is obtained by descen-
ding below the minimum adjustable speed.
-xxx%: if the unit has modulating fans it is possible to adjust a percentage value of the speed, flow rate or full-scale pressure (for units not
equipped with the corresponding kit but always in a cop / cav version with a different sensor), starting from a minimum (factory adjusted) to
100% with steps of 5% (1% on request).
-1, 2or 3: if the unit is equipped with 3-speed fans,it is possible to select one of the available ones: speed 1, speed 2 or speed 3.
-watch: with this selection the speed of the fans is controlled according to what is established by the weekly chronoprogram (see Program
menu), this indication is obtained by selecting a value higher than the maximum speed (100% or 3).
-auto: this mode is available only if a sensor (CO2, CO2-COV, relative humidity HR) or an external signal (0-10V) is present. It is obtained by
selecting a value higher than clock.
-xxx m³ \h: if the unit is a constant flow (CAV) version with a kit, the desired value can be set in m3 \ h of flow.The fans will be regulated au-
tomatically to keep it constant depending on the changes in the load.
Speed fan controller (%) Airflow control
Pressure control
Direction buttons
Direction buttons
on/off

5
CV072018-1
BOOSTER FUNCTION
By selecting the icon on the lower left you access the booster function.Through this you can select a time interval (from a minimum of 1 mi-
nute to a maximum of 4 hours) in which to operate the unit at maximum power.The booster function is a priority with respect to other modes
of fan speed management.
After the selection a digital chronometer (hours.minutos.seconds) predetermined to a value of 10 minutes can be modified with the direction
buttons on the right of the screen:up to increase the booster time and down to decrease this time. Pressing the OK button starts the function:
the remaining time for the end of the process is shown on the screen.
When the value 00.00.00 is reached,the fans are controlled again in the previous way.If it is desired to stop the process,it is sufficient to repeat
the adjustment operations of the booster by selecting a time of 0 minutes and pressing OK.
MANAGEMENT OF AIR POSTGRADING
The control is capable of managing an air after-treatment system with both water coil and electrical resistance.
The first is regulated by the control of a 3-point solenoid valve 230V or 24AC-DC \ 0-10V, while the resistance through the corresponding relay.
If after-treatment management is established, the main screen is modified: an icon - thermometer with a temperature value appears in the
lower right corner. On its side and on the flow of the driving air, a picture of post-heating / cooling appears.
Selecting the icon in the bottom right corner establishes the desired temperature set point (TS) inside: the user can increase the value of TS
with the direction arrow up or, on the contrary, decrease it with the Direction arrow below. Once the desired value has been reached, the se-
lection is confirmed by pressing the OK button.With the central button,which appears at first, the post-treatment can be switched off directly.
TS can assume values between 05.0 ° C and 30.0 ° C with steps of 0.1 ° C; if the user selects a TS value lower than 05.0 ° C, the control considers
the post-heating deactivated and the display appears next to the corresponding icon on the screen. It is possible to combine electric after-
heating for winter and water cooling in summer, or under the same conditions,control two separate cold-hot coil (cold only with 0-10V valve).
TS becomes the reference for heating or cooling depending on whether or not these are enabled in the corresponding station of the installer
menu (exclusive to each other) and depending on the one selected in the parameter menu. The post-heating status is shown in the main
window: It is also possible to manage a dehumidification system made by the two separate coil (hot-cold) or by a cold coils with an electrical
resistance underneath.
Active post-heating Postheating off

6
CV072018-1
PREHEATING MANAGEMENT
In addition to the post-heating, the CTRL-DPH control is able to manage an electric preheating system (operated by a PWM signal or on-off)
to prevent the formation of ice inside the heat exchanger.The control automatically activates the anti-frost procedure when the temperature
measured by the expulsion probe (Tx) drops below the value of 3 °C. Here the heater is powered at the minimum power. If the temperature Tx
continues to decrease and falls below 1 °C, the feed of the preheater is progressively increased until it reaches 100%.When Tx returns above
3 °C the procedure is interrupted.The temperature values 3C° and 1C° are set at the factory and can be modified on request. The preheating
status is shown in the main window.
MENU SELECTION
From the main window you access the menu window by touching the corresponding icon (window change icon).You have to scroll with the
up arrow key and then press OK on the desired item.When selecting,you access the diverse detailed information about the installation.When
the last menu item is reached, the arrow below disappears.
On the other hand, when you go beyond the first one, the window change icon appears with the arrow to the left.To return to the previous
menu,click on the latter.
In the menu window you can access the following functions:
- Status
- Program
- Clock
- Alarms
- Installer
- Factory (protected by password, accessible only by factory).
From the Menu window,you access the main window by pressing the up arrow button until the window change icon appears and pressing OK.
Menu selection window
Active post-heating Postheating off
Central window change icon

7
CV072018-1
STATUS MENU: OPERATING STATUS
If the remote control panel is used to manage several units (master-slave mode),a screen with the list of available machines (max 4) will appear
in the menu:
To view the status of an individual unit, select it (move with the arrows and confirm the selection with OK). If the control is configured to ma-
nage an individual unit, when accessing this menu, the status of the unit is displayed directly, displaying the values taken by the parameters
that characterize it; using the direction buttons (up-down) it is possible to scroll through all of them. The pressure, flow parameters refer to
machines with cop / cav kit (see instructions):
Te (exter.) Renewal air temperature in °C
Tr (return) Return air temperature in °C
Tx (expelled) Expelled air temperature in °C
Ti (input) Air temperature introduced in °C
Tw(water) It is active if the after-heating is present by means of a water coil,it indicates the temperature of the water flowing
out of the coil, it is expressed in ° C
Wat.nofrost It is active when the after-heating is established by a water coil and indicates whether the anti-freeze / no-frost
mode is in progress.
The no-frost function relative to the coil is activated when the temperature measured by the Tw probe falls below
3 ° C and then deactivates when it returns above 5 ° C (3 + 2).When a temperature below 3 ° is detected,the control
valve (hot water) is completely opened in order to prevent the formation of ice inside the elements.IfTw falls below
1C ° the fans stop and at the same time an alarm is signaled (see ALARMS menu).The two temperature values of 3
° C and 1 ° C can be changed (menu FACTORY -factory-).
Anti-frost Antifrost function (antifreeze) exchanger. It is activated when the temperature measured by the Tx probe falls be-
low 1 ° C and then deactivated when it returns above 3 ° C.
The purpose is to avoid the formation of ice inside the exchanger.
It can be managed by a preheating resistor, by unbalancing the air flow rates or by regulating the by-pass.
Fan supply Admission fan speed, this value is expressed in:
- Revolutions per minute (RPM) if fans with tachometer signal are installed.
- Percentage if variable speed fans are installed without tachometer signal (Off with fan off).
- Off,1, 2 or 3 for three-speed fans.
Fans.remote Only Evo-d. If on, it indicates the independent regulation of the drive fan from Modbus.
Flow supply Only for units of constant flow with control over two flows.Value in m³ \ h of flow of the driving fan.
Display menu statusSelection of unit to control configuration menu status

8
CV072018-1
Dp Supply Only for units of constant pressure with control over two flows. Pressure value in pascals below the driving fan.
Fan exhau. Exhaust fan speed,see vent.Entr.
FanE.Remote Only Evo-d. If on, it indicates the independent regulation of the return fan from Modbus.
FlowExhau.Only for units of constant flow with control over two flows or with flow sensors.Value in m³ \ h of the return flow.
DpExhau Only for units of constant pressure with control over the two flows. Pressure value in pascals above the return fan.
Flow Only for units of constant flow with control over a flow.Value in m3 \ h of flow of the fan of impulsion.
Dp Only for units of constant pressure with control over a flow.Pressure value in pascals below the driving fan.
Fan hours Hours of operation of the unit.
Bypass It is active if the bypass is configured:
- On open bypass.
- Off bypass closed.
- Bypass Mod Modulation (if set from the factory menu).
Heating/Cooling/On\
Off It is active if air or water after-treatment is configured:
- Heat On \ Off active afterheating \ inactive.
- Refriger. On \ Off after cooling active inactive.
CO2/VOC ppm It is active if a CO2 or VOC / VOC probe is present: it indicates the concentration of CO2 or CO2 / VOC in parts per
million (ppm) measured by the air quality probe, it can take values between 0 and 2000.
Humidity % It is active if a relative humidity probe is present:it indicates the relative humidity value in percentage measured by
the probe,it can take values between 0 and 100.
Auto est .% It is active if the automatic operation of the fans is configured by an external 0-10V signal. Indicates the percentage
value of the external signal (10V corresponds to 100%).
Remote It is active if a digital input (DI) is configured as remote (parameter adjustable in the factory):
- On if DI closed (the fans operate at the speed set on the remote panel).
- Off if DI open (fans stopped).
Boost It is active if a digital input (DI) is configured as a booster (parameter adjustable in the factory):
- end DI open and a time exceeding Boost min.since the last impulse,therefore inactive booster (fans at the speed
established by the control).
- Max. the time has not yet elapsed Boost min. (1 -> 240 minutes) since the DI has received the impulse, active
booster (fans at maximum speed).
PIR It is active if a digital input (DI) is configured as PIR (parameter adjustable in the factory).
- min Open DI (fans at minimum speed).
- max. DI closed (fans at maximum speed) and the minimum PIR time has not yet elapsed.
(1 -> 240 minutes) fixed in the installer menu.
- off DI closed (fans at the speed set by the user in the control) and has
after the time PIR min. from the moment of closing the DI entry.
Summer It is active if a remote digital input (factory default) is set as summer / summer.
-Yes / yes DI open,the summer station is established.
- No DI closed,the winter season is established.
Humidity It is active if a remote digital input (factory default) is set as humidity / humidity.
-Yes / yes DI open,the humidity threshold of the humidistat has been exceeded.
- No DI closed,the humidity threshold of the humidistat has not been exceeded
Fire It is active if a remote digital input (factory) is configured as fire / fire.
- Yes / yes DI open (exhaust fan at maximum speed and blower fan off).
- No DI closed (fans at the speed set by the control).
PFanSupply It is active if the fan alarm is set to 2Press (factory default).
- off open alarm contact, drive fan stopped or broken
- on closed alarm contact, running fan in operation.
PFanExhau It is active if the fan alarm is set to 2Press (factory default).
- off contact of open alarm, return fan stopped or faulty
- on closed alarm contact, return fan in operation.
Recircul.Req. Off/On It is active if it is set to Recircul.one of the digital inputs (at the factory,when recirculation gates are installed).
- open contact off,standard recirculation management.
- on closed contact,maximum active recirculation.

9
CV072018-1
Dehumidif.On/Off It is active if the control is configured to manage the dehumidification system
- on dehumidification enabled
- off dehumidification disabled.
DWat. NoFrost Off\On It is active if the control is configured to manage the dehumidification system Air temperature after the cold coil
in ° C.
It is active if after treatment is established by water coil. Indicates whether anti-freeze / - nofrost mode measured
by on-off thermostat (directed at 1 ° C and connected to a digital input) is in progress. In this case,the control valve
opens completely and both fans stop. At the same moment an alarm appears in the corresponding menu.
Td(Dehum.) It is active if the control is configured to manage the dehumidification system Air temperature after the cold coil
in ° C.
The digital inputs / outputs can be programmed from the factory menu by asking the manufacturer for passwords and instructions on the
available functions.
PROGRAM MENU: WEEKLY PROGRAMMING MANAGEMENT
This menu allows to manage the speed of the fans (in three levels) that are expressed in percentage for machines of variable speed,in pascals
for machines of constant pressure and in m3 / h for machines of constant flow. It is also possible to enable / inhibit air after-treatment (if pre-
sent) in a different way for each day of the week.
Everything can be adjusted for different time slots (from 1 to 8 definable by the user with a resolution of 30 minutes).To access the program-
ming management functions, select Program with the direction buttons pointing to it and press OK.
Program menu display with fan speed Program menu display with air low Program menu display with pressure

10
CV072018-1
DEFAULT
By selecting this menu item and pressing the OK button, the parameters for the management of the unit are automatically assigned the
preset values:
Program valid from Monday to Friday:
Program valid from Saturday to Sunday:
TIME TABLE
Time table Speed fans/ air flow/ pressure Air after-treatment condition:(ON enabled,OFF inhibited)
C1 00:00 -> 06:29 medium OFF
C2 06:30 -> 07:59 medium ON
C3 08:00 -> 11:29 low ON
C4 11:30 -> 12:59 High ON
C5 13:00 -> 17:59 low ON
C6 18:00 -> 21:59 high ON
C7 22:00 -> 00:00 medium OFF
C8 not used - -
TIME TABLE
Time table Speed fans/ air flow/ pressure Air after-treatment condition:(ON enabled,OFF inhibited)
C1 00:00 -> 07:29 medium OFF
C2 07:30 -> 07:59 medium ON
C3 08:00 -> 11:29 medium ON
C4 11:30 -> 12:59 high ON
C5 13:00 -> 17:59 medium ON
C6 18:00 -> 21:59 high ON
C7 22:00 -> 00:00 medium OFF
C8 not used - -
SPEED LEVELS
Low: Medium sp. OFF
Medium sp.: 030% if the unit is equipped with adjustable speed fans; 1 if the unit is equipped with three-
speed fans; auto if the unit has a CO2 sensor, relative humidity or if it is managed by an external
0-10V signal.
0200m s\h if the unit is of constant flow with cop \ cav kit.This value also depends on the factory
menu settings based on the performance of the unit.
010Pa if the unit is constant pressure with cop \ cav kit.This value also depends on the factory
menu settings based on the performance of the unit.
High speed: 065% if the unit is equipped with adjustable speed fans; 2 if the unit is equipped with three-
speed fans; auto if the unit has a CO2 sensor, relative humidity or if it is managed by an external
0-10V signal.
20000m s\h if the unit is of constant flow with kit cop\ cav.This value also depends on the fac-
tory menu settings based on the performance of the unit.

11
CV072018-1
TIMETABLE
By selecting this menu item and pressing the OK button you access the summary display of each day of the week,divided into 24 hours.
To change the settings of each day, simply select it,in the summary display screen, and press the OK button; At this moment the detail screen
of the selected day will be shown, in which the list of the eight possible time slots (C1-C8) appears, the day of the week in which it is being
operated is shown in the upper left part of the screen.
By selecting a time slot and pressing the OK button you can modify its content, in the time zone modification screen, in addition to the indi-
cation of the day in which you are operating (top left), the graphic summary of the programming valid for the whole day.The parameters that
can be modified are:
- Change / Change X: selecting this line and pressing OK you can change the time zone in which you are operating without returning to the
previous page: using the arrows, you can scroll through the different time zones (1-8),once the desired just press OK.
- Time / Hour hh.mm: selecting this line and pressing OK adjusts the start time of the current time slot: using the arrows increases (arrow up)
or decreases (arrow down) the schedule in 30 minute sections; Once you have located the desired value, press OK.This parameter can take a
value between the beginning of the previous time slot and the start of the next time slot.
- Fan speed / Speed.vent xxx: selecting this line and pressing OK adjusts the fan speed (or pressure / full-scale flow rate for machines without
cop / cav kit).The flow for units with constant flow or pressure for constant pressure units with kit cop / cav required for the current time slot:
using the arrows the three low, medium and high possible values are selected; located the desired value,press OK.These values correspond to
what is established according to the following section (Adjustment of speed levels).
- Post-heating / Poscalent. on / off: the parameter is visible only if the control is configured to manage an air after-treatment device; By se-
lecting this line and pressing OK, it is possible to enable (on) or inhibit (off) the air after-treatment device. Using the arrows, the two possible
values, on and off,are selected.Once the desired value is found,press OK.When the timer mode is selected, it is visible on the screen if the ON
/ OFF timeout is enabled.
summary display detail of one day a week
Modifiable parameters in the selected time slot
Selection of the time slot to be modified

12
CV072018-1
After carrying out the personalization of a day of the week according to your own needs (for example, Monday), you can copy the program-
ming made on another day without having to repeat the whole procedure described above. In the summary display window of time slots,
select the day in which you want to copy the previously made programming (for example,Tuesday) and press OK.At this point the detail win-
dow of the time slots of the selected day is displayed.Using the down arrow,go through all the time slots until you reach the line Copy day (it
will appear after the last time slot C8): point to this line and press the OK button.
After accessing the Copy day page (indication visible in the upper left part of the screen),it is possible to select the day from which you want
to copy the programming.Once the election is selected (Monday in our example), press the OK button to confirm the copy and automatically
go to the simplified display of the slots (in our case we will have copied the programming on Monday in the day of Tuesday).This operation
can be repeated for other days of the week.
ADJUSTING SPEED LEVELS
To modify the default values for the three levels (low, medium and high) used for the weekly programming, it is necessary to access the main
page of the Program menu, with the arrows indicate the level to be modified (for example Low speed) and press the OK button. Using the
arrows you can go through the different possible values and, once you have located the desired value, confirm the selection by pressing the
OK button.The possible values for these three parameters are:
- off: stopped fans,accessed by keeping the down arrow pressed for a few seconds (off is below the minimum adjustable speed value).
- xxx%: for units with variable speed fans (or pressure / flow for machines without cop / cav kit) you can select a percentage value between
the minimum (set at the factory) and 100%.
- 1, 2 or 3: for units with three-speed fans you can choose between speeds 1,2 or 3.
- auto: for units equipped with air quality probe, relative humidity or guided by an external 0-10V signal, the fan speed will be automatically
managed by one of these devices. It is accessed by holding the arrow up for a few seconds (auto is above the maximum adjustable speed
value).
-xxx m³ \ h: if the unit is in the constant flow version with the cav mounted kit, the desired value can be set in m³ / h of flow.
- xxx Pa: if the unit is in constant pressure version with the cop kit mounted,the desired value can be set in pressure pascals.
Disabled heating Post-heating enabled
Copy day function selection Copy day: selection of the day to copy

13
CV072018-1
CLOCK MENU: CLOCK SETUP
This menu allows adjusting the day of the week and the current schedule for a correct management of the weekly schedule
ALARMS MENU: VISUALIZATION OF THE STATE OF ALARMS
If the control detects an anomaly, the latter is indicated in the main screen of the control with the intermittent display of a specific icon and
a red message at the top of the screen (Call service or Dirty Filters). If the alarm is detected when the screen is in standby mode, the screen
flashes intermittently (every 10 seconds approx.). Alarms in the pressure sensors are only available for machines with cav / cop kit.
Configuration of the day
Select the day / day line and press the OK button,the current day set will turn green;Scroll with the direction buttons to locate the desired day.
Press the OK button to confirm the selection, the day will change from green to blue.
Setting the time
Select the hours / hour line and press the OK button,the current time set will turn green;Scroll with the direction buttons to locate the desired
time.Press the OK button to confirm the selection,the time will change from green to blue.
Setting the minutes
Select the minutes line and press the OK button, Minutes will turn green; Scroll with the direction buttons to locate the desired minutes.Press
the OK button to confirm the selection, the word minutes will change from green to blue.
If the twinkle of an alarm is in progress, you can directly access the corresponding menu by touching the screen; otherwise, select Alarms on
the menu selection page and press OK. If the control is subjected to several units (master / slave mode), the unit to be monitored must be
selected (see Status menu); otherwise, the detail page of the alarms is accessed directly.
Alarm menu
twinkle of an alarm: outdoor air temperature probe

14
CV072018-1
ALARM LIST
Parameter Val State
Configuration
ok The configuration is correct.
ko
The configuration of the digital inputs or hardware is incorrect. Check the ext.
Inputs in the factory menu. (eg if the same function is configured for several
inputs) or Hardware (Hw evo-compact-> el.water).
Communication ok The communication between the cards in the machine and the remote control
panel works correctly.
ko Problem in the communication between the cards and the remote panel:
1) check the electrical connections between the electronic board and the re-
mote panel (see electrical diagram).
2) If the problem persists, check electrical connections between the two cards
(see electrical diagram).
3) If the problem persists,check the position of the dip switch on both cards.
For a unit: X540 only 1 = on; X531 only 2 = ON; X541 all off.
4) If the problem persists,replace the electronic card.
5) Check that the parameter Hw (factory menu) is correctly configured for the
unit in use.
Outdoor air temperature sensor works correctly.
Te (external)
ok Problem in the outdoor air temperature sensor:
ko 1) check the electrical connections of the temperature probe (see electrical diagrams).
2) If the problem persists,replace the temperature probe.
3) If the problem persists,replace the electronic card.
Tr (return)
ok Return air temperature sensor works correctly.
ko Problem in the return air temperature sensor:
1) check the electrical connections of the temperature probe (see electrical diagrams).
2) If the problem persists,replace the temperature probe.
3) If the problem persists,replace the electronic card.
Tx (expelled)
ok Expelled air temperature sensor works correctly.
ko Problem in the expelled air temperature sensor:
1) check the electrical connections of the temperature probe (see electrical diagrams).
2) If the problem persists,replace the temperature probe.
3) If the problem persists,replace the electronic card.
Ti (input)
ok Introduced air temperature sensor works correctly.
ko Problem in the air temperature sensor introduced
1) check the electrical connections of the temperature probe (see electrical diagrams).
2) If the problem persists,replace the temperature probe.
3) If the problem persists,replace the electronic card.
It is present only if the air after-treatment management is configured with
water coil (Factory menu).
Tw (water)
ok Temperature sensor in the water coil works correctly.
ko Problem in the air temperature sensor entered:
1) check the electrical connections of the temperature probe (see electrical diagrams).
2) If the problem persists,replace the temperature probe.
3) If the problem persists,replace the electronic card.

15
CV072018-1
Tw (water low)
ok It is present only if the air after-treatment management is configured with wa-
ter coil (Factory menu).
The temperature of the water leaving the coil is higher than a safety threshold;
there is no risk of freezing the water in the coil.
ko Risk of freezing the liquid in the water coil.
It is present only if the filter status alarm is configured with differential pressure
switch or depending on the hours of operation of the machine (Factory menu).
Filters
ok Clean filters.
ko It is only present if the fan status alarm is configured with differential pressure
switches, with tachometer signal from the fans or with DO of the fans (Factory
menu).
Fans/
ok Fans OK.
ko Possible failure in a fan.It is only present if the automatic speed management of
the fans with CO2 or CO2 sensor is configured -VOC2 (Installer menu).
CO 2VOC
ok Probe OK.
ko Possible failure of the probe or the connection.
It is only present if the automatic speed management of the fans with relative
humidity sensor (Installer menu) is configured.
RH senso
ok Probe OK.
ko Possible failure of the probe or the connection.
It is only present if the fan speed management is configured with analog 0-10V
external signal (Installer menu).
Ext.signal
ok External signal source works correctly.
ko External signal not present (voltage at terminals equal to 0V):
1) check the electrical connections of the external source (see electrical diagrams).
2) if the problem persists,check the presence of the external signal (tester) with
values higher than 0V.
3) If the problem persists, replace the electronic card. It is only present if the
machine is in a constant flow version with control over the two flows.
FlowSupply ok The pres sensor of drive works correctly.
ko Possible anomaly in the pres sensor of drive.
FlowExhaust
ok It is only present if the machine is in a constant flow version with control over
the two flows.
ko The pres sensor return function works correctly Possible anomaly in the pres.
sensor return.
Flow
ok It is present only if the machine is in a constant flow version with control over
a flow.
ko The pressure sensor works correctly Possible anomaly in the pressure sensor.
DpSupply
ok It is present only if the machine is in a constant pressure version with control
over the two flows.
ko The pres.sensor of impulsion works correctly Possible anomaly in the pres.sen-
sor of drive.
DpExhaust
ok It is only present if the machine is in a constant flow version with control over
the two flows.
ko The pres. sensor return function works correctly Possible anomaly in the pres.
sensor return.
Dp
ok It is present only if the machine is in a constant pressure version with control
over a flow.
ko The pressure sensor works correctly . Possible anomaly in the pressure sensor.

16
CV072018-1
Autominutes
ok It is only present if the automatic speed management of the fans with CO or
CO-VOC sensor (Installer menu) is configured or there is an excess of CO2 in the
environment.The sensor works correctly.
ko Possible anomaly in the sensor.
Antifrost
ok It is activated if the unit fails to exit the antifreeze mode of the exchanger within
2 minutes.The unit works correctly.
ko Two minutes have elapsed since the entry in antifreeze mode and the ejection
temperature has not risen again above 3C °. For speed management, the con-
trol stops the drive fan and adjusts the return fan to the maximum speed. For
resistance management,it stops both the impulsion fan and the resistance, the
return flow goes to the speed set in the control panel. For by-pass manage-
ment, it stops the flow fan and leaves the by-pass in the current position.
Bypass off:
The bypass will remain closed regardless of the internal and external temperatures.
Bypass on:
The bypass will remain open regardless of the internal and external temperatures.
PARAM MENU: ADJUSTMENT OF USER PARAMETERS
The parameter menu is displayed only when the control detects that the conditions exist for which the current station should be selected. It
may be due to the winter / summer settings in the installer menu (see) or the presence of a cold water coil. If it is not displayed, the control
automatically proceeds to the management based on the outside temperature and return values. Modification of the values of the available
parameters is done by selecting the desired one and pressing the OK key; at this point the current value of the parameter turns green, to go
through the different possible values, use the arrows. If a dehumidification system is installed, the relative humidity threshold value can also
be adjusted in this menu.
Bypass configured in“All Season \ All SeasonM”mode and / or management of an element enabled for air after-treatment (Factory menu).For
the regulation, threshold values of the return temperature present in the installer menu are used (see Winter / Summer temperature) which
are compared with the effective values of outdoor temperature \ ambient. If the conditions for free-heating/ cooling persist, the by-pass is
adjusted accordingly according to the following diagram:
By-pass: summer By-pass: winter
Open ( free heating)+ heating
Open ( free heating)
Open modulated (free cooling)
Openmodulated (freecooling)+cooling
closed
closed

17
CV072018-1
Humidity (%)
This parameter is available only when a dehumidification system is planned. Represents the threshold value above which dehumidification is
enabled.The default value is 50%. Dehumidification can also be forced by a digital input.
INSTALLER MENU: CONFIGURATION OF INSTALLATION PARAMETERS
To access this menu, you need to enter a password (5678) to avoid inadvertent modification by non-expert users of parameters that could
compromise the correct operation of the installation.
To enter the password, press the down arrow so that the corresponding line is indicated, press the OK button and enter the first digit. Select
the desired value using the up / down arrows and press OK when you reach it.
Repeat the operation for the three remaining figures. If the password has been entered correctly, the installer menu is displayed; otherwise,
you return to the introduction page.To modify the parameters of this menu, select the desired one (scrolling with the up/ down arrows) and
press the OK button.The currently established value is shown in green, at this point it is possible to modify it using the arrows and pressing
OK to confirm the selection.The parameters related to the coefficients and flow/ pressure values are available only for machines with kit, the
display or not of such parameters is linked to the settings in the factory menu.
Bypass configured in universal mode (Factory menu), three values can be selected for the bypass parameter:
Automatic bypass:
A temperature range,comprised between TMIN and TMAX,is considered comfortable for the user;If the internal temperature (Tr) is within this
range,the bypass will remain closed.When Tr is out of this range (Tr> TMAX or Tr <TMIN) the control will open the bypass in case the external
temperature (Te) is within the comfort range (TMIN <Te <TMAX); otherwise,the bypass will remain closed.
Not defined or automatic
This parameter is available only when a dehumidification system is planned.
Through this you can enable (Yes) or inhibit (No) the dehumidification
system.It can be used, for example,in the winter season, if you do not want
to dehumidify.
digital input
insert password Installer menu

18
CV072018-1
PARAMETERS AVAILABLE IN THE INSTALLER MENU
Language
With this parameter you can select the language in which all the menus will be displayed (with the exception of the Factory menu, which will
always be displayed in English).
GB English display (default value)
FR Display in French
ES Display in Spanish
IT Display in italian
NL Display in Dutch
DE Display in German
HU Display in Hungarian
DK Display in Danish
PT Display in Portuguese
SI Display in Slovenian
Auto
With this parameter you can configure a device to regulate the fan speed automatically. For the connection of the device see the electrical
diagram.
ex signal The speed of the fans will be regulated by an external 0-10V analog signal (default value); if the external signal assumes a value equal
to 0V; the control will signal a problem of the external signal source.For units equipped with variable speed fans:
AutoMin% corresponds to the percentage of the input signal by which the fans must operate at the minimum speed.
AutoMax% corresponds to the percentage of the input signal by which the fans must operate at maximum speed.
For units equipped with three-speed fans:
SP.1,2% = Automax% - AutoMin%+ AutoMin%
SP.2,3% = 7 x (AutoMax% - AutoMin%) + AutoMin%
∆= Automax% - AutoMin%
12
10
5
The values of SP.1.2% SP.2.3% and A depend on the values of the two parameters AutoMin% and AutoMax% according to the following:

19
CV072018-1
HR Sensor
The speed of the fans will be regulated by a relative humidity (RH) sensor with 0-10V output and linear characteristic between 0 and 100% RH
(0V correspond to 0% RH and 10V correspond to 100% RH); If the external signal from the HR sensor assumes a value equal to 0V, the control
will signal an alarm. See graphs of the signal parameter ext. In this case AutoMin% corresponds to the relative humidity value for which it is
considered optimal air quality, AutoMax% corresponds to the value of relative humidity for which the air quality is considered bad.A possible
dehumidification system can be managed by this sensor or, if for example this input is occupied by CO2, by another supplementary selected
in the factory menu.
CO2VOC
The speed of the fans will be regulated by a CO2 sensor (or CO2-VOC) with 0-10V output and linear characteristic between 0 and 2000 ppm
(0V correspond to 0 ppm and 10V correspond to 2000 ppm);if the external signal of the CO2 sensor takes a value equal to 0V the control will
signal an alarm. For units equipped with variable speed fans:
AutoMin ppm corresponds to the concentration of CO2 (CO2-VOC) for which air quality is considered optimal, AutoMax ppm corresponds to
the concentration of CO2 (CO2-VOC) for which air quality is considered poor.
For units equipped with three-speed fans:
SP. 1,2% = Automax ppm - AutoMin ppm + AutoMin ppm
SP. 2,3% = 7 x (AutoMax ppm - AutoMin ppm) + AutoMin ppm
∆= Automax ppm - AutoMin ppm
12
10
5
The values of SP.1.2% SP.2.3% and A depend on the values of the two parameters AutoMin% and AutoMax% according to the following:
None (default value) is not provided for the use of any device for the automatic management of fan speed.

20
CV072018-1
AutoMax %
This parameter is available only if the auto parameter is set to ext. or HR sensor. It can take values between 1 and 100% (steps 1%) with the
limitation that AutoMin% <AutoMax%. For units equipped with variable speed fans:
If auto signal ext.
corresponds to the percentage value of the input signal by which the fans rotate at the maximum speed, above this value the fans remain
adjusted to the maximum speed. For example, the AutoMax value% 080 corresponds to an 8V input signal (80% of 10V).
If auto sensor HR
corresponds to the relative humidity value (in percentage) by which the fans rotate at the maximum speed, below this value the fans remain
adjusted to the maximum speed. For units equipped with three-speed fans, taking into account the second image of the external auto-signal
parameter, the values of SP.1.2% and SP.2.3% are set (nominal values in which the steps of the speed 1 to 2 and speed 2 to 3) you can obtain
the appropriate value to assign to the parameter:
AutoMin ppm
This parameter is available only if the auto parameter is set to CO2 VOC.It can take values between 0 ppm and 1980 ppm (steps of 20ppm) with
the limitation that AutoMin ppm <AutoMax ppm.
For units equipped with variable speed fans,corresponds to the concentration of CO2 (CO2-VOC), expressed in ppm, by which the fans turn at
the minimum speed; below this value the fans remain adjusted to the minimum speed. For units equipped with three-speed fans, taking into
account the second image of the auto CO2 VOC parameter, the values of SP.1.2% and SP.2.3% are set (nominal values in which the speed steps
are produced) 1 to 2 and speed 2 to 3) you can obtain the appropriate value to assign to the parameter:
AutoMax ppm
This parameter is available only if the auto parameter is set to CO2 VOC. It can take values between 20 ppm and 2000 ppm (steps of 20 ppm)
with the limitation that AutoMin ppm <AutoMax ppm For unit equipped with variable speed fans, corresponds to the concentration of CO
2 (CO2 -VOC), expressed in ppm , by which the fans rotate at maximum speed; above this value the fans remain adjusted to the maximum
speed. For unit equipped with three-speed fans, taking into account the second image of the auto CO2 VOC parameter, the values of SP.1.2%
and SP.2.3% are set (nominal values in which the speed steps occur 1 to 2 and speed 2 to 3) you can obtain the appropriate value to assign to
the parameter:
AutoMin% = 7 x SP.1,2% - 2 x SP.2,3%
5
AutoMax% = 8 x SP.2,3% - 3 x SP.1,2%
5
AutoMin ppm = 7 x SP.1,2% - 2 x SP. 2,3%
5
AutoMax ppm = 8 x SP. 2,3% - 3 x SP.1,2%
5
AutoMin %
This parameter is available only if the auto parameter is set to ext. or HR sensor. It can take values between 0 and 99% (steps 1%) with the
limitation that AutoMin% <AutoMax% For units equipped with variable speed fans:
If auto signal ext.
corresponds to the percentage value of the input signal by which the fans rotate at the minimum speed, below this value the fans remain
adjusted to the minimum speed. For example, the AutoMin% 030 value corresponds to a 3V input signal (30% of 10V).
If auto sensor HR
corresponds to the relative humidity value (in percentage) by which the fans rotate at the minimum speed, below this value the fans remain
adjusted to the minimum speed. For units equipped with three-speed fans, taking into account the second image of the external auto-signal
parameter, the values of SP.1.2% and SP.2.3% are set (nominal values in which they occur).
the steps of speed 1 to 2 and speed 2 to 3) you can obtain the appropriate value to assign to the parameter:
