Casio AP-710 User manual

AP-710
MIDI Implementation
CASIO COMPUTER CO., LTD.
Contents
I Overview 4
1 Product Configuration as a MIDI Device 4
1.1 SystemSection.......................................... 4
1.2 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 SoundGeneratorSection .................................... 4
2 Conditions that Disable Message Send and Receive 6
II Channel Message 7
3 Note Off 7
4 Note On 8
5 Control Change 8
5.1 Bank Select (00H,20H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.2 Modulation(01H) ........................................ 9
5.3 PortamentoTime(05H) ..................................... 9
5.4 Data Entry (06H,26H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.5 Volume(07H) .......................................... 9
5.6 Pan(0AH) ............................................ 9
5.7 Expression(0BH) ........................................ 10
5.8 Hold1(40H) ........................................... 10
5.9 Portamento On/Off(41H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.10 Sostenuto(42H) ......................................... 10
5.11 Soft(43H) ............................................ 11
5.12 Release Time (48H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.13 AttackTime(49H)........................................ 11
5.14 VibratoRate(4CH)....................................... 11
5.15 Vibrato Depth (4DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.16 VibratoDelay(4EH) ...................................... 12
5.17 PortamentoControl(54H).................................... 12
5.18 High Resolution Velocity Prefix (58H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.19 ReverbSend(5BH) ....................................... 13
5.20 ChorusSend(5DH) ....................................... 13
5.21 NRPN(62H,63H) ........................................ 13
5.22 RPN(64H,65H) ......................................... 13
1

5.23 AllSoundOff(78H)....................................... 15
5.24 ResetAllControllers(79H)................................... 15
5.25 AllNotesOff(7BH)....................................... 15
5.26 OmniOff(7CH) ......................................... 15
5.27 OmniOn(7DH) ......................................... 15
5.28 Mono(7EH) ........................................... 15
5.29 Poly(7FH)............................................ 16
6 Program Change 16
6.1 DSP Assignments during Tone Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7 Channel After Touch 16
8 Pitch Bend 17
III System Message 18
9 Active Sensing 18
10 System Exclusive Message 18
10.1 Universal Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 18
10.2 Universal Non Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . 21
10.3 Instrument-Specific System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 21
IV Instrument-Specific System Exclusive Messages 22
11 Format 22
11.1 MessageClassifications ..................................... 22
11.2 BasicMessageStructure..................................... 22
11.3 FormatofEachField ...................................... 22
12 Parameter Operations 26
V Parameter List 27
13 Using the Parameter List 27
14 System Parameter 27
14.1 System Information Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
15 Patch Parameter 28
15.1 MasterTuneParameter..................................... 28
15.2 SystemChorusParameter.................................... 28
15.3 SystemReverbParameter.................................... 28
15.4 PortamentoParameter ..................................... 28
16 Spec Parameter 29
VI DSP Parameter List 31
17 Tone with DSP List 31
2

VII Setting Values and Send/ Receive Values 32
18 Setting Value Tables 32
18.1 Off/OnSettingValueTable................................... 32
18.2 Sustain Pedal Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.3 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.4 PanSettingValueTable..................................... 32
18.5 Fine Tuning Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
18.6 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
18.7 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
VIII MIDI Implementation Notation 34
19 Value Notation 34
19.1 HexadecimalNotation...................................... 34
19.2 BinaryNotation ......................................... 35
3

Part I
Overview
1 Product Configuration as a MIDI Device
As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Per-
formance Controller Section described below. Each of these sections can send and receive specific MIDI
Messages in accordance with its function.
1.1 System Section
The System Section manages the Instrument status.
1.2 Performance Controller Section
The Performance Controller Section generates performance messages in accordance with keyboard play
and pedal operations, etc. Basically, generated performance messages are sent to external destinations
while also being transmitted to the Sound Generator Section. The channel number of the sent channel
message is in accordance with the Instrument’s part number.
1.3 Sound Generator Section
The Sound Generator Section mainly performs receive of performance information and sound source
setting information. It consists of a common part that does not depend on the channel and a musical
instrument part that is independent of each channel.
1.3.1 Sound Generator Common Block
The common block consists of system effects, master control, etc. These can be controlled by general
universal system exclusive messages, or the Instrument’s system exclusive messages or all.
1.3.2 Instrument Part Block
The instrument part section consists of a total of 32 instrument parts. The settings of each part can be
changed using channel messages or Instrument’s system exclusive messages or all. The functions assigned
to each part are shown below. The MIDI send channel and MIDI receive channel can be changed using
the Instrument’s MIDI settings.
4

Part Number Part Name MIDI Receive Ch MIDI Send Ch Assigned
Function
Description
00 A01 - 01(Note1) Keyboard Upper1(Main)/
(Right-side
keyboard in the
Duet Mode)
01 A02 - 02 Keyboard Upper2(Layer)
02 A03 - 03 Keyboard Lower1(Split)/
(Left-side
keyboard in the
Duet Mode)
03 A04 - - -
04 A05 - 05 Recorder Play Track1 main
05 A06 - 06 Recorder Play Track1 layer
06 A07 - 07 Recorder Play Track1 split
07 A08 - - Metronome/
Count
08 A09 - -
09 A10 - -
10 A11 - -
11 A12 - -
12 A13 - -
13 A14 - -
14 A15 - 04 Recorder Play Track2
15 A16 - – - -
16 B01 01 - MIDI/Song Play Ch.01
17 B02 02 - MIDI/Song Play Ch.02
18 B03 03 - MIDI/Song Play Ch.03 (Left hand
track)
19 B04 04 - MIDI/Song Play Ch.04 (Right
hand track)
20 B05 05 - MIDI/Song Play Ch.05
21 B06 06 - MIDI/Song Play Ch.06
22 B07 07 - MIDI/Song Play Ch.07
23 B08 08 - MIDI/Song Play Ch.08
24 B09 09 - MIDI/Song Play Ch.09
25 B10 10 - MIDI/Song Play Ch.10
26 B11 11 - MIDI/Song Play Ch.11
27 B12 12 - MIDI/Song Play Ch.12
28 B13 13 - MIDI/Song Play Ch.13
29 B14 14 - MIDI/Song Play Ch.14
30 B15 15 - MIDI/Song Play Ch.15
31 B16 16 - MIDI/Song Play Ch.16
Note1: Can be changed by Keyboard Channel setting.
5

2 Conditions that Disable Message Send and Receive
No MIDI messages at all can be sent or received while “Please Wait ...” is on the display.
6

Part II
Channel Message
Instrument Velocity Resolution The upper seven bits of the 14-bit resolution correspond to the
Note On/Off message, while the lower seven bits correspond to the High Resolution Velocity Prefix
message.
Note On/Off High Resolution Velocity Prefix
Upper 7 bits Lower 7 bits
14bits
The initial default value for the lower 7 bits is 00H. Receipt of a High Resolution Prefix message
causes the lower seven bits to be set, but note on/off is not performed.
Receipt of a Note On/Off message causes the upper seven bits to be set with note on/off performed
with 14-bit resolution Velocity.
The High Resolution Velocity Prefix message corresponds the message immediately following the Note
On/Off message, and the lower seven bits are cleared to 00H immediately following note on/off by the
Note On/Off message. 7-bit resolution note on/off using only the Note On/Off message also continues
to be supported.
For details about each message, see ” 3 Note Off”, ”4 Note On”, and ”5.18 High Resolution Velocity
Prefix”.
3 Note Off
Format
Message Format: 8nH kkH vvH
9nH kkH 00H(receive only)
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance
with on the Transpose function and Octave Shift function.
Receive Receipt stops a note being sounded by a note on message.
When a High Resolution Velocity Prefix message is received immediately prior to the Note Off message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note off of the note being
sounded is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
Note off by making the Note On Velocity 00H is identical to note off by the combination of High
Resolution Velocity prefix message 40H and Note Off Message 40H.
7

Note: This Instrument has a function that assumes connection of an external device that sends Note Off Velocity as a fixed
value. Note Off Velocity 00H is replaced with 40H until a Note Off message with a Velocity value other than 00H is received. This
function is enabled when the Instrument is turned on, and disabled by receipt of a Note Off message with a Velocity value other
than 00H.
4 Note On
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when something is played on the keyboard. The key number changes in accordance
with on the Transpose function and Octave Shift function.
Receive Receipt sounds a note of the corresponding instrument part.
When a High Resolution Velocity Prefix message is received immediately prior to the Note On message
and the lower seven bits of the 14-bit Velocity are set, the 14-bit resolution note on is performed.
For information about the relationship between the Note On/Off message and High Resolution Ve-
locity Prefix message, see ”Instrument Velocity Resolution” at the beginning of part II.
5 Control Change
Message Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
For details about messages, see each section of this manual that covers them.
5.1 Bank Select (00H,20H)
Message Format: BnH 00H mmH (MSB)
BnH 20H llH (LSB)
n: MIDI Channel Number
mm: MSB Value(Note1)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Note1: For details about the relationship between the MSB value and the tone, see the Tone List that comes with the
Instrument.
Transmit Sent when a tone number is selected. For information about numbers, see the Tone List in
the User’s Guide.
Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the
tone is not actually changed until a Program Change message is received. For details, see “6 Program
Change”.
8

5.2 Modulation (01H)
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
5.3 Portamento Time(05H)
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the portamento application time.
5.4 Data Entry (06H,26H)
Message Format: BnH 06H mmH (MSB)
BnH 26H llH (LSB)
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when there is a change to the parameter assigned to RPN. For details about information
assigned to parameters that correspond to RPN, see ”5.22 RPN”. This Instrument does not have a
parameter that corresponds to NRPN.
Receive Receipt changes the parameter assigned to RPN.
5.5 Volume (07H)
Message Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when layer balance or lower volume is adjusted.
Receive Receipt changes the part volume.
5.6 Pan (0AH)
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value(Note1)
9

Note1: For information about the relationship between setting values and send/receive values, see “18.4 Pan Setting Value
Table” in “VII Setting Values and Send/Receive Values”.
Transmit Sent when Music Library play is stopped.
Receive Receipt changes the pan of the corresponding part.
5.7 Expression (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the Expression value.
5.8 Hold1 (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when a pedal that has a sustain (damper) function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
5.9 Portamento On/Off(41H)
Message Format: BnH 41H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the portamento on/off setting.
5.10 Sostenuto (42H)
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
10

Transmit Sent when a pedal that has a sostenuto function is operated.
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
5.11 Soft (43H)
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.1 Off/On Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Transmit Sent when a pedal that has a soft function is operated.
Receive Receipt performs an operation equivalent to a soft pedal operation.
5.12 Release Time (48H)
Message Format: BnH 48H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63
Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to decay to zero after a key is
released.
5.13 Attack Time (49H)
Message Format: BnH 49H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63
Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to rise to its maximum level.
5.14 Vibrato Rate (4CH)
Message Format: BnH 4CH vvH
n: MIDI Channel Number
vv: Value (Note1)
11

Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63
Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the note vibrato rate.
5.15 Vibrato Depth (4DH)
Message Format: BnH 4DH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63
Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the degree of pitch modulation.
5.16 Vibrato Delay (4EH)
Message Format: BnH 4EH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1: For information about the relationship between setting values and send/receive values, see the “18.3 –64 - 0 - +63
Setting Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the time it takes until note vibrato starts.
5.17 Portamento Control(54H)
Message Format: BnH 54H vvH
n: MIDI Channel Number
vv: Source Key Number
Receive Receipt of this message first stores the Source Note Number for the next note. When the next
Note On is received, the portamento effect is applied to the note using this Source Note Number as the
pitch start point and the Note On event key number as the end point. If there already is a note being
sounded by Source Note Number at this time, the new note on is not performed and the portamento
effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
5.18 High Resolution Velocity Prefix (58H)
Message Format: BnH 58H vvH
n: MIDI Channel Number
vv: Value
Transmit Sends the lower seven bits of 14-bit Velocity when a key is pressed or released.
12

Receive Receipt is handled, in combination with the following Note On/Off message, as the lower
seven bits of 14-bit Velocity. For information about the relationship between the Note On/Off message
and High Resolution Velocity Prefix message, see ”Instrument Velocity Resolution” at the beginning of
part II.
5.19 Reverb Send (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the reverb send of the corresponding part.
5.20 Chorus Send (5DH)
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the chorus send of the corresponding part.
5.21 NRPN (62H,63H)
Message Format: BnH 62H llH (LSB)
BnH 63H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
5.21.1 Assignable Functions to NRPN
This Instrument does not assign any parameters to NRPN.
5.22 RPN (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
13

5.22.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 18H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Receive Receipt changes Pitch Bend Sensitivity.
5.22.2 Fine Tune
Message Format: BnH 64H 01H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Receive Receipt changes Channel Fine Tune.
5.22.3 Coarse Tune
Message Format: BnH 64H 02H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(28H - 58H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Receive Receipt changes Channel Coarse Tune.
5.22.4 Null
Message Format: BnH 64H 7FH
BnH 65H 7FH
n: MIDI Channel Number
Transmit Sent when an RPN message send operation is performed.
Receive Receipt de-selects RPN.
14

5.23 All Sound Off (78H)
Message Format: BnH 78H 00H
n: MIDI Channel Number
Receive Receipt stops all voices that are sounding.
5.24 Reset All Controllers (79H)
Message Format: BnH 79H 00H
n: MIDI Channel Number
Transmit Sent when MIDI send related settings are changed.
Receive Receipt initializes each performance controller.
5.25 All Notes Off (7BH)
Message Format: BnH 7BH 00H
n: MIDI Channel Number
Transmit Sent when MIDI send related settings are changed.
Receive Receipt releases (key release) all voices that are sounding.
5.26 Omni Off (7CH)
Message Format: BnH 7CH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the
reception of this message, the instrument always operates as Omni Off mode.
5.27 Omni On (7DH)
Message Format: BnH 7DH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the
reception of this message, the instrument always operates as Omni Off mode.
5.28 Mono (7EH)
Message Format: BnH 7EH 00H
n: MIDI Channel Number
15

Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the
reception of this message, the instrument always operates as Poly mode.
5.29 Poly (7FH)
Message Format: BnH 7FH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received. Regardless of the
reception of this message, the instrument always operates as Poly mode.
6 Program Change
Message Format: CnH ppH
n: MIDI Channel Number
pp: Program Number (Note1)
Note1: For details about the relationship between the program number and the tone, see the Tone List that comes with the
Instrument.
Transmit Sent when a tone number is selected.
Receive Receipt changes the tone of the corresponding part. The selected tone is determined by the
program value of this message and the Bank Select message value received prior to this message.
6.1 DSP Assignments during Tone Selection
6.1.1 DSP Line Structure
Though the Instrument has four DSP lines that can be used simultaneously, selecting a tone that uses
DSP causes the required number of DSP lines to become reserved so the tone is configured with the
requisite DSP. For information about tones that use DSP, see “17 Tone with DSP List”.
6.1.2 DSP Line Assignment
Selecting multiple tones with DSP at the same time creates the possibility that there will not be enough
DSP lines. In this case, the last selected tone with DSP is given priority. Some DSP line(s) already
being used will be released so they can be assigned to the newly selected tone.
7 Channel After Touch
Message Format: DnH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
16

8 Pitch Bend
Message Format: EnH llH mmH
n: MIDI Channel Number
ll: Value LSB
mm: Value MSB
Receive Receipt changes the pitch of the currently sounding note. Pitch bend change sensitivity
depends on the pitch bend sensitivity configured with RPN.
17

Part III
System Message
9 Active Sensing
Message Format: FEH
Transmit This message is never sent.
Receive Once this message is received, the Active Sensing mode is entered. If no MIDI message is
received for a specified amount of time, voices being sounded by this Instrument’s sound source are
released, the controller is reset, and the Active Sensing mode is exited.
10 System Exclusive Message
Message Format: F0H iiH ddH....F7H
ii: ID Number
dd: Device ID
The Instrument sends and receives standard universal system exclusive messages, and system exclusive
messages that have Instrument-specific formats.
ID Number The ID numbers handed by this Instrument are shown below.
ID Number ID Name
44H Casio Computer Co. Ltd
7EH Non Real Time System Exclusive Message
7FH Real Time System Exclusive Message
Device ID The device ID is used mainly for individual control of multiple devices. When a System
Exclusive message is sent, the sending device sends messages that include a value that matches the
device ID of the sending device. When a System Exclusive message is received, the receiving device
receives only messages that include a value that matches the receiving device ID. The device ID 7FH is
a special value, and receipt is always performed whenever the device ID of either the receiving device
or the message is 7FH. MIDI Device ID is one of Spec Parameter and can be changed by the System
Exclusive Message. Device ID of MIDI System Exclusive Message in this case should be sent is set to
7FH.(Initial Value:7FH)
10.1 Universal Real Time System Exclusive Message
Message Format: F0H 7FH ddH....F7H
dd: Device ID
18

10.1.1 Master Volume
Message Format: F0H 7FH ddH 04H 01H llH mmH F7H
dd: Device ID
ll: LSB Value(Receive:Ignored)
mm: MSB Value
Receive Receipt changes the Master Volume.
10.1.2 Master Fine Tuning
Message Format: F0H 7FH ddH 04H 03H llH mmH F7H
dd: Device ID
ll: LSB Value(Note1)
mm: MSB Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “18.5 Fine Tuning Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the tuning setting is changed.
Receive Receipt changes the tuning setting.
10.1.3 Master Coarse Tuning
Message Format: F0H 7FH ddH 04H 04H llH mmH F7H
dd: Device ID
ll: LSB Value(Transmit:00H,Receive:Ignored)
mm: MSB Value(28H - 58H)
Receive Receipt changes the Patch Master Coarse Tune parameter.
10.1.4 Reverb Type
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H
dd: Device ID
vv: Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “18.6 Reverb Type Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the reverb type is changed.This Instrument treats a hall simulator
as a reverb.
Receive Receipt changes the reverb type.
19

10.1.5 Reverb Time
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 01H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Reverb duration.
10.1.6 Chorus Type
Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 00H vvH F7H
dd: Device ID
vv: Value(Note1)
Note1: For information about the relationship between setting values and send/receive values, see “18.7 Chorus Type Setting
Value Table” in “VII Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the chorus type is changed.
Receive Receipt changes the chorus type.
10.1.7 Modulation Rate
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Chorus Rate.
10.1.8 Modulation Depth
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 02H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the chorus level setting.
10.1.9 Send To Reverb
Message Format: F0H 7FH ddH 04H 05H 01H 01H 01H 01H 02H 04H vvH F7H
dd: Device ID
vv: Value
Receive Receipt changes the Chorus Sent To Reverb setting.
20
