Casio CDP-200R User manual

GUÍA DEL USUARIO
USER’S GUIDE
ES
CDP200RES1C
Guarde toda la información para futuras consultas.
Please keep all information for future reference.
Precauciones de seguridad
Antes de intentar usar el piano, asegúrese de leer las
“Precauciones de seguridad” separadas.
Safety Precautions
Before trying to use the piano, be sure to read the
separate “Safety Precautions”.
EnglishEspañol

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be
placed on the apparatus.
The power indicator being unlit does not mean the apparatus is completely disconnected from the MAINS.
When you need to have the apparatus completely disconnected from the MAINS, you must unplug the power cord. For that
purpose, locate the apparatus in a way that secures easy access to the power cord.
Declaration of Conformity
Model Number: CDP-200R
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.

English
E-1
Important!
Please note the following important information before using this product.
• Before using the AD-12 Adaptor to power the product, be sure to check the AC Adaptor for any damage first. Carefully check the
power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is seriously
damaged.
• The product is not intended for children under 3 years.
• Use only CASIO AD-12 adaptor.
• The AC adaptor is not a toy.
• Be sure to disconnect the AC adaptor before cleaning the product.
This mark applies in EU countries only.
Manufacturer:
CASIO COMPUTER CO.,LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
CASIO EUROPE GmbH
Bornbarch 10, 22848 Norderstedt, Germany
●Company and product names used in this manual may be registered trademarks of others.
●Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal
use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
●IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION,
DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE
USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
●The contents of this manual are subject to change without notice.

E-2
Contents
General Guide ............................. E-4
Using the 10-key Pad (cl) .................................E-6
FUNCTION Button (7) Functions .....................E-6
Getting Ready to Play ................ E-7
Preparing the Music Stand .................................E-7
Connecting a Pedal Unit.....................................E-7
Power Supply .....................................................E-7
Playing the Digital Piano............ E-8
Turning on Power and Playing ...........................E-8
Using Headphones .............................................E-8
Changing Keyboard Response to
Touch Pressure (Touch Response)....................E-9
Adjusting Display Contrast .................................E-9
Using the Metronome .......................................E-10
Controlling the
Keyboard Sounds..................... E-11
Select from a variety of musical
instrument sounds ............................................E-11
Layering Two Tones.........................................E-12
Splitting the Keyboard between Two
Different Tones.................................................E-12
Using Reverb....................................................E-13
Using Chorus....................................................E-13
Using a Pedal ...................................................E-14
Changing the Pitch
(Transpose, Tuning, Octave Shift)....................E-14
Using the Pitch Bend Wheel to
Shift the Pitch of Notes.....................................E-15
Sampling Sounds and Playing
Them on the Digital Piano ....... E-16
Connection and Preparation.............................E-16
Sampling and Playing a Melody Sound
(Melody Sampling) ...........................................E-17
Incorporating a Sampled Sound into a
Drum Set (Drum Sampling) ..............................E-19
Other Sampling Functions................................E-22
Playing Built-in Songs ............. E-24
Playing the Demo Songs..................................E-24
Playing Back a Particular Song ........................E-25
Increasing the Selection of Songs....................E-27
Using Built-in Songs to
Master Keyboard Play .............. E-28
Phrases............................................................ E-28
Step Up Lesson Flow....................................... E-28
Selecting the Song, Phrase, and
Part You Want to Practice................................ E-29
Lessons 1, 2, and 3.......................................... E-30
Lesson Settings ............................................... E-31
Using Auto Step Up Lesson............................. E-33
Music Challenge
Keyboard Game ........................ E-34
Using Auto Accompaniment.... E-35
Playing the Rhythm Part Only.......................... E-35
Playing All Parts............................................... E-36
Using Auto Accompaniment Effectively ........... E-38
Using One-Touch Preset ................................. E-39
Using Auto Harmonize ..................................... E-40
Editing Auto Accompaniment
Patterns...................................... E-41
Saving Keyboard Setups to
Registration Memory ................ E-44
To save a setup to registration memory........... E-45
To recall a setup from registration memory ..... E-45
Recording Your
Keyboard Play........................... E-46
Recording and Playing Back Keyboard Play ... E-46
Using Tracks to Record and Mix Parts ............ E-47
Recording Two or More Songs, and
Selecting One for Playback.............................. E-48
Recording while Playing Along with a
Built-in Song..................................................... E-49
Saving Recorded Data on an
External Device................................................ E-50
B

English
Contents
E-3
Other Useful Digital Piano
Functions .................................. E-51
Changing the Scale of the Keyboard................E-51
Using Music Preset ..........................................E-53
Using the Arpeggiator.......................................E-54
Deleting User Song Data..................................E-55
Deleting All Data in Digital Piano Memory........E-55
Using a Memory Card............... E-56
SD Memory Card and Card Slot Precautions...E-56
Inserting and Removing an
SD Memory Card..............................................E-57
Formatting an SD Memory Card.......................E-57
Saving Digital Piano Data to an
SD Memory Card..............................................E-58
Loading Data from an SD Memory Card
into Digital Piano Memory.................................E-59
Deleting Data from an SD Memory Card..........E-60
Playing Back Data from an
SD Memory Card..............................................E-61
SD Memory Card Error Messages ...................E-61
Connecting External Devices ..... E-62
Connecting a Computer ...................................E-62
MIDI Settings....................................................E-63
Storing and Loading Piano Memory Data.........E-65
Connecting to Audio Equipment .......................E-66
Reference .................................. E-67
Troubleshooting................................................E-67
Specifications ...................................................E-69
Operating Precautions......................................E-70
Error Messages ................................................E-71
Song List ..........................................................E-72
Chord Chart......................................................E-73
MIDI Implementation Chart
Included Accessories
●Music Stand
●Song Book
●Leaflets
• Safety Precautions
• Appendix
• Other (Warranty, etc.)
Items included as accessories are subject to change without notice.
Separately Available Accessories
• You can get information about accessories that
are separately for this product from the CASIO
catalog available from your retailer, and from the
CASIO website at the following URL.
http://world.casio.com/

E-4
General Guide
• In this manual, buttons and other controllers are identified using the numbers shown below.
12 3 65
bsbr bt ck
4789
cl
bl bm bn bo bp bqbk
cscn
dl dm dl
do dp dqdn
co cpcm cq ct dkcr

English
General Guide
E-5
1POWER button ☞E-8
2MAIN VOLUME knob ☞E-8
3MIC VOLUME knob ☞E-16
4RHYTHM EDITOR button ☞E-41, 42
5SCALE EDITOR button ☞E-51, 52, 53
6SAMPLING button ☞E-17, 18, 19, 21, 57
7FUNCTION button ☞E-6
8RECORDER button ☞E-46, 47, 48, 49
9METRONOME, BEAT button ☞E-10
bk INTRO, REPEAT button ☞E-26, 31, 38, 41
bl NORMAL/FILL-IN, REW button
☞E-25, 29, 35, 38, 41
bm VARIATION/FILL-IN, FF button
☞E-25, 29, 38, 41
bn SYNCHRO/ENDING, PAUSE button
☞E-25, 38, 39, 41
bo START/STOP, PLAY/STOP button
☞E-24, 25, 27, 30, 31, 35, 46, 48, 49, 61
bp ACCOMP ON/OFF, CHORDS, PART SELECT
button ☞E-24, 27, 29, 31, 36, 40, 41, 42, 49, 64
bq TEMPO buttons ☞E-10, 26, 39
br SONG BANK button ☞E-25, 26, 29, 49
bs RHYTHM, ONE TOUCH PRESET button
☞E-11, 19, 21, 35, 39, 42, 45, 46, 48, 51, 53
bt TONE, MUSIC PRESET button
☞E-11, 17, 19, 21, 23, 53
ck CARD, SAVE/LOAD button ☞E-57, 58, 59, 60, 61
cl Number buttons, [–]/[+] buttons ☞E-6
cm BANK, LISTEN, CHORD/TR1 button
☞E-18, 30, 44, 45
cn Area1, WATCH, TR2 button
☞E-18, 30, 44, 45, 48, 53
co Area2, REMEMBER, TR3 button
☞E-18, 31, 44, 45, 48, 53
cp Area3, NEXT, TR4 button ☞E-18, 29, 44, 45, 48, 53
cq Area4, AUTO, TR5 button ☞E-18, 33, 44, 45, 48, 53
cr STORE, MUSIC CHALLENGE, TR6 button
☞E-18, 34, 45, 48, 53
cs SPLIT button ☞E-12, 13
ct LAYER button ☞E-12, 15
dk AUTO HARMONIZE/ARPEGGIATOR, TYPE button
☞E-40, 54
dl Speakers
dm Display
dn PITCH BEND wheel ☞E-15
do CHORD root names ☞E-36
dp Percussion instrument list ☞E-11
dq SD CARD SLOT ☞E-57
ds
dt ek el em
dr
dr PHONES/OUTPUT jack
☞E-8, 66
ds USB port ☞E-62
dt DC 12V terminal ☞E-7
ek AUDIO IN jack ☞E-16, 66
el MIC IN jack ☞E-16
em SUSTAIN/ASSIGNABLE JACK
☞E-7
■Back■Front
C

General Guide
E-6
Use the number buttons and the [–] and [+] buttons to change
the settings of the parameters that appear in the upper left
area of the display.
Use the number buttons to enter numbers and values.
• Enter the same number of digits as the currently displayed
value.
Example: To enter tone number 001, input 0 30 31.
• Negative values cannot be input using the number buttons.
Use [–] (decrease) and [+] (increase) instead.
You can use the [–] (decrease) and [+] (increase) buttons to
change the displayed number or value.
• Holding down either button scrolls the displayed setting.
• Pressing both buttons at the same time will revert to the
initial default setting or the recommended setting.
You can use the FUNCTION button (7) to adjust the reverb
effect, to delete data, and to perform a wide range of other
Digital Piano operations.
1. Press 7to display the function menu.
2. Use the cl (10-key) [4] (u) and [6] (i) keys to
display the function you want.
• You can exit the function menu by pressing 7.
• After selecting functions 8 through 12, press the cl
(10-key) [7] (ENTER) key to display the menu item’s
submenu. Then use [4] (u) and [6] (i) to select an
item. You can exit a submenu by pressing the cl
(10-key) [9] (EXIT) key.
3. Refer to the indicated pages for details about
each function.
• The tone and other parameters revert to their initial
defaults whenever you turn on power (page E-8).
Using the 10-key Pad (cl)
Number Buttons
[–] and [+] Buttons
FUNCTION Button (7) Functions
To select a function
St .GrPno
Setting
Function Display See
Page
1 Transpose Trans. E-14
2 Accompaniment Volume AcompVol E-39
3 Song Volume Song Vol E-26
4 Touch Response Touch E-9
5 Tuning Tune E-14
6 Reverb Reverb E-13
7 Chorus Chorus E-13
8 Sampling SAMPLING
Automatic Sampling Start AutoStrt E-22
Automatic Sampling Stop AutoStop E-22
Sampled Tone Protect (Protect) E-23
9 Step Up Lesson LESSON
Voice Fingering Guide Speak E-31
Note Guide NoteGuid E-32
Performance Evaluation Scoring E-32
Phrase Length PhraseLn E-32
10 Other Settings OTHER
Arpeggiator Hold ArpegHld E-54
Pedal Effect Jack E-14
Pitch Bend Range Bend Rng E-15
Accompaniment Scale AcompScl E-53
LCD Contrast Contrast E-9
11 MIDI Settings MIDI
Keyboard Channel Keybd Ch E-63
Navigate Channels Navi. Ch E-63
Local Control Local E-64
Accomp Out AcompOut E-64
12 Delete DELETE
Sampled Sound Delete (tone name) E-23
User Rhythm Delete (rhythm name) E-43
User Song Delete (song name) E-55
All Data Delete All Data E-55

English
E-7
Getting Ready to Play
Connect an optional pedal unit.
Use only the AC adaptor that is specified for use with this
Digital Piano.
Specified AC Adaptor: AD-12
• Be sure to turn off Digital Piano power before
connecting or disconnecting the AC adaptor.
Preparing the Music Stand
Connecting a Pedal Unit
Power Supply
Using the AC Adaptor
Music stand
SUSTAIN/ASSIGNABLE JACK
Household power outlet
AD-12DC 12V terminal

E-8
Playing the Digital Piano
1. Press 1.
This turns on power.
2. Try playing something on the keyboard. Use 2
to adjust volume.
• Turning off the piano causes most current settings to
be cleared. The piano will revert to initial settings the
next time you turn it on.
• This is true for all settings except for sample sound
protection. Once you turn it on it remains on until you
turn it off again.
Using headphones cuts off output from the built-in speakers,
which means you can practice playing even late at night
without disturbing others.
• Be sure to turn down the volume level before connecting
headphones.
• Headphones do not come with the Digital Piano.
• Use commercially available headphones. See page E-3 for
information about options.
• Do not listen to very high volume output over
headphones for long period. Doing so creates the risk
of hearing damage.
• If you are using headphones that require an adaptor
plug, make sure you do not leave the adaptor plugged
in when removing the headphones.
2211 9977
bqbq
clcl
Turning on Power and Playing
IncreaseDecrease
Using Headphones
PHONES/OUTPUT jack

English
Playing the Digital Piano
E-9
Touch Response alters tone volume in accordance with
keyboard pressure (speed). This provides you some of the
same expressivity you get on an acoustic piano.
■Sound intensity depends on the speed that keys
are pressed.
People normally believe that the stronger the pressure applied
to a piano keyboard, the louder the sound. Actually, however,
the intensity of the notes played depends on the speed at
which keys are pressed. Notes are louder when keys are
pressed quickly, and quieter when keys are pressed slowly.
Keeping this in mind as you play a keyboard musical
instrument lets you control note volume without striving to
apply too much pressure with your fingertips.
■The playability of an acoustic piano
Your Digital Piano provides you with key touch that is the next
best thing to an acoustic piano. Note volume changes
automatically in accordance with key press speed.
Use the procedure below to control how much the volume of
played notes change in accordance with playing speed.
Select the setting that best matches your playing style.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “Touch” (page
E-6).
2. Use cl (10-key) [–] and [+] keys to select one of
the four Touch Response sensitivity settings.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “OTHER” (page
E-6).
2. Press cl (10-key) [7] (ENTER) key.
3. Use the cl (10-key) [4] (u) and [6] (i) keys to
display “Contrast”.
4. Use the cl (10-key) [–] and [+] keys to adjust the
contrast.
• The contrast setting range is 01 to 17.
Changing Keyboard Response to
Touch Pressure
(Touch Response)
Keyboard Instrument Sound Intensity
Pressing fast produces
louder notes.
Pressing slowly produces
softer notes.
Do not try to use too much
pressure.
Changing Touch Response Sensitivity
Off (oFF) Touch Response is turned off. Sound
volume is fixed, regardless of key press
speed.
Type 1 (1) Normal Touch Response
Type 2 (2) More sensitive Touch Response than Type 1
Type 3 (3) Less sensitive Touch Response than Type 1
Adjusting Display Contrast
Touch
Indicator disappears when
Touch Response is turned off.
OTHER
Flashes
C o n t r a s t
B

Playing the Digital Piano
E-10
The metronome lets you play and practice along with a steady
beat to help keep you on tempo.
1. Press 9.
This starts the metronome.
2. Press 9again to stop the metronome.
You can configure the metronome to use a bell sound for the
first beat of each measure of the song you are playing.
• You can specify 0, or a value from 2 to 6 as the number of
beat per measure.
• When playing a built-in song, the beats per measure setting
(which determines when the bell sounds) is configured
automatically for the currently selected song.
1. Hold down 9until the beats per measure
setting screen appears on the display.
• If you do not perform any operation for a few seconds
after the beats per measure setting screen appears, the
display will return to the screen displayed before you
pressed 9.
2. Use cl (10-key) to enter the number of beats
per measure.
• The bell will not sound if you specify 0 for this setting. In
this case, all beats are indicated by a click sound. This
setting lets you practice with a steady beat, without
worrying how many beats there are in each measure.
Use the following procedure to change the tempo of the
metronome.
1. Press bq.
Use w(slower) and q(faster) to change the tempo
setting. Holding down either button changes the setting at
high speed.
• Pressing qand wat the same time will initialize the
tempo setting in accordance with the currently selected
song or rhythm.
• Pressing bq causes the tempo value to flash on the
display. While the tempo value is flashing, you can use
cl (10-key) to change it.
Note that you must input leading zeros, so 89 is input
as 089.
• The tempo value will stop flashing if you do not perform
any operation for a short while.
The metronome volume setting is changed automatically with
the volume level of the currently selected Auto
Accompaniment or song. The metronome volume cannot be
adjusted independently.
• For information about changing the Auto Accompaniment
volume, see page E-39.
• For information about changing the song volume, see page
E-26.
• You cannot adjust the balance between the metronome
and note volume during Auto Accompaniment and built-in
tune play.
Using the Metronome
Start/Stop
Changing the Beats Per Measure
This pattern changes with each beat.
Bea t
Changing the Metronome Tempo
Changing the Metronome Sound Volume
Tempo value (flashes)

English
E-11
Controlling the Keyboard Sounds
Your Digital Piano lets you select tones for a wide variety of
musical instrument sounds, including violin, flute, orchestra,
and more. Even the same song sound takes on a different feel
by changing the instrument type.
1. Press bt.
2. Use cl (10-key) to select the tone number you
want.
The corresponding tone number and tone name will
appear on the screen.
• See the separate “Appendix” for a complete list of available
tones.
• Use the number buttons to enter the tone number. Specify
three digits for the tone number.
Example: To select 001, enter 0 30 31.
• When one of the drum sets is selected (tone numbers 654
through 670), each keyboard key is assigned a different
percussion sound.
3. Try playing something on the keyboard.
The tone of the instrument you selected will sound.
1. Press bs and bt at the same time.
This selects the grand piano tone.
Settings
77 btbtbsbs
cscs ctct
clcl
Select from a variety of musical
instrument sounds
To select an instrument for playing
St .GrPno
Tone nameTone number Playing with a Piano Tone (Piano Setup)
Tone Number : “001”
Reverb : “06”
Transpose : 00
Touch Response : Off: Returns to initial default
On: No change
Pedal Effect : SUS
Rhythm Number : “181”
Accompaniment : Rhythm part only
Local Control : On
Drum Assign : Off
Split : Off
Layer : Off
Chorus : Off
Octave Shift (Upper): 0
Auto Harmonize : Off
Arppegiator : Off
Scale : Equal

Controlling the Keyboard Sounds
E-12
You can use the following procedure to layer two different
tones (such as piano and strings) so they sound
simultaneously when you press a keyboard key.
1. Select the first tone you want to use.
Press bt and then use cl (10-key) to select the tone you
want.
Example: 026 ELEC.PIANO 1
2. Press ct.
3. Use cl (10-key) to select the second tone you
want.
Example: 212 STRINGS
4. Play something on the keyboard.
Both tones sound at the same time.
5. Pressing ct again to unlayer the keyboard (so it
plays only the tone you selected in step 1).
• Each press of ct toggles between layered (two tones)
and unlayered (one tone).
You can use the procedure below to assign different tones to
the right range and left range of the keyboard, so it sounds
like you are playing an ensemble between two instruments.
1. Select the tone for the right side range (page
E-11).
Press bt and then use cl (10-key) to select the tone you
want.
Example: 335 FLUTE 1
2. Press cs.
3. Use cl (10-key) to select the left side range tone
you want.
Example: 056 VIBRAPHONE 1
4. Play something on the keyboard.
This will sound the tones assigned to the left and right
side ranges of the keyboard.
Layering Two Tones
E . P i a n o 1
Lights
St r in
g
s
Disappears
Splitting the Keyboard between
Two Different Tones
To select the two tones for a split keyboard
Flute 1
Lights
V i b e s 1
Split point
F3
VIBRAPHONE 1 FLUTE 1

English
Controlling the Keyboard Sounds
E-13
5. Pressing cs again to unsplit the keyboard (so it
plays only the tone you selected in step 1).
• Each press of cs toggles between split (two tones) and
unsplit (one tone).
• If you turn on both layer and split, layering will be applied to
the right side range of the keyboard only.
1. While holding down cs, press the keyboard key
where you want the split point to be.
The key you press will become the lowest note of the right
side range of the split keyboard.
Example: Setting middle C (C4) as the split point.
Reverb adds reverberation to notes. You can change the
duration of the reverb.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “Reverb” (page
E-6).
2. Use the cl (10-key) [–] and [+] keys to select the
reverb setting you want.
Chorus is a function that adds depth and breadth to notes. It
makes you sound as if you are playing multiple instruments.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “Chorus” (page
E-6).
2. Use the cl (10-key) [–] and [+] keys to select the
chorus type you want.
There are five chorus types, plus an off setting.
• The actual effect produced by chorus depends on the tone
you are using.
To change the split point
Disappears
C4
Key name
Using Reverb
Off (oFF) Turns off reverb.
1 to 10 The larger the number selected, the longer
the reverb duration.
Using Chorus
Reverb
Reverb
Indicator disappears when reverb is turned off.
Cho r us
Cho r us
Indicator disappears when chorus is turned off.

Controlling the Keyboard Sounds
E-14
A pedal can be used to change notes in various ways while
playing.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “OTHER” (page
E-6).
2. Press cl (10-key) [7] (ENTER) key.
3. Use the cl (10-key) [4] (u) and [6] (i) keys to
display “Jack”.
4. Use the cl (10-key) [–] and [+] keys to select the
pedal effect you want.
• The following shows the available pedal effects.
The transpose feature lets you change the pitch, in semitone
steps. A simple operation lets you instantly change the pitch
to match that of a singer.
• The transpose setting range is –12 to +12 semitones.
1. Press 7.
2. Use the cl (10-key) [–] and [+] keys to select the
transpose setting you want.
Use the tuning feature when you need to adjust the pitch
slightly to play along with another musical instrument. Also,
some artists perform their music with slightly altered tuning.
You can use the tuning feature to adjust tuning so it exactly
matches a performance on a CD.
• The tuning setting range is –99 to +99 cents.
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “Tune” (page
E-6).
2. Use the cl (10-key) [–] and [+] keys to adjust the
tuning.
Using a Pedal
Selecting the Pedal Effect
Sustain
(SUS)
Sustains notes played while the pedal is
depressed. Organ and other similar tone
notes are sustained even if the pedal is not
pressed.
Sostenuto
(SoS)
Sustains notes that are playing when the
pedal is depressed before the keyboard
keys are released.
Soft
(SFt)
Slightly softens notes played while the pedal
is depressed.
Rhythm
(rHy)
Pressing the pedal starts and stops Auto
Accompaniment or song playback.
OTHER
Flashes
Jack
Changing the Pitch
(Transpose, Tuning, Octave Shift)
Changing the Pitch in Semitone Steps
(Transpose)
Fine Tuning (Tuning)
Trans.
Tune

English
Controlling the Keyboard Sounds
E-15
Octave Shift lets you raise or lower the pitch of the keyboard
notes in octave units.
• The octave shift setting range is –2 to +2 octaves.
• When using Split (page E-12), you can individually set the
left and right keyboard ranges to the pitches you want.
1. Keep pressing ct until the screen shown below
appears on the display.
If you want to use Split, turn on Split before pressing ct.
• If you do not perform any operation for a few seconds
after this screen appears, the display will return to the
previous screen automatically.
2. Use the cl (10-key) [–] and [+] keys to shift the
octave.
3. Press ct.
4. Press ct again.
You can use the pitch bend wheel to slide the pitch of notes
smoothly upwards and downwards. This technique makes it
possible to produce effects that are similar to sounds
produced when bending notes on a saxophone or electric
guitar.
1. While playing a note on the
keyboard, rotate the pitch bend
wheel on the left of the keyboard
upwards or downwards.
The amount the note bends depends on how
much you rotate the pitch bend wheel.
• Do not have the pitch bend wheel rotated
as you turn on the piano.
Use the following procedure to specify how much the pitch of
the note changes whenever the pitch bend wheel is rotated
upwards or downwards. You can specify a range from 0 to 12
semitones (one octave).
1. Press 7and then use the cl (10-key) [4] (u)
and [6] (i) keys to display “OTHER” (page
E-6).
2. Press cl (10-key) [7] (ENTER) key.
3. Use the cl (10-key) [4] (u) and [6] (i) keys to
display “Bend Rng”.
4. Use the cl (10-key) [–] and [+] keys to change
the range.
Octave Shift
• Split On : This step affects the right side keyboard
range only.
• Split Off : This step affects the entire keyboard range.
• Split On : The screen shown below will appear. Use the
cl (10-key) [–] and [+] keys to shift the
octave for the left side keyboard range.
• Split Off : The screen shown below will appear.
Advance to step 4.
Oc t U
pp
er
Oc t Lowe r
Using the Pitch Bend Wheel to
Shift the Pitch of Notes
To play with the pitch bend wheel
Specifying the Pitch Bend Range
OTHER
Flashes
Bend Rn
g

E-16
Sampling Sounds and Playing Them on the Digital
Piano
You can sample a sound from a microphone, a portable audio
player, or other device, and then play the sound on the Digital
Piano’s keyboard. For example, you could sample the bark of
your dog and then use the sound in a melody. You also can
sample and use passages from a CD. The sampling feature is
a great way to create new sounds that are highly creative.
• Before connecting, make sure that the Digital Piano,
external devices, and/or the microphone all are turned
off.
1. Connect a microphone or external device to the
Digital Piano.
• You also could connect a commercially available
microphone.
• Connection of an external device requires commercially
available connecting cords, supplied by you. Connecting
cords should have a stereo mini plug on one end and a plug
that matches the configuration of the external device on the
other end.
2. Turn down the volume levels of the external
device and the Digital Piano.
3. Turn on the external device or microphone, and
then turn on the Digital Piano.
• When using a microphone, adjust the input volume
level with 3.
• It will take a few seconds after you turn on the Digital Piano
before you will be able to use the microphone.
• Sampled sounds are recorded in monaural.
■Cutting off power clears sampled data!
If you disconnect the AC adaptor, currently stored sampled
data will be deleted.
77 bsbs clcl66 btbt
cmcm cncn coco cpcp cqcq crcr
33
Connection and Preparation
MIC IN jack
Digital Piano AUDIO IN jack
CD player, Cassette player,
etc.
Stereo mini plug

English
Sampling Sounds and Playing Them on the Digital Piano
E-17
Use the procedures in this section to sample a sound and play
it as the melody part on the Digital Piano.
• Up to five sampled sounds can be stored in Digital Piano
memory as tone numbers 671 through 675. Simply select
the tone number where the sound you want is located to
assign the sound to the keyboard.
1. Press bt and then use cl (10-key) to enter the
tone number (671 to 675) where you want to
store the sampled sound.
• In place of the above steps, you could press 6and bt at
the same time and then select a tone number.
2. Press 6.
This enters sampling standby.
The allowable sampling time (in seconds) will appear on
the display momentarily and then the display will change
to the following.
3. Output the sound from the external device. In
the case of a microphone, output the sound in
the direction of the microphone.
Sampling will start automatically.
4. After the sound you want to sample is finished,
press 6.
Sampling will stop when you release 6.
• Even if you do not press 6, sampling will stop
automatically whenever there is no more sound being
input from the external device or microphone. Sampling
also will stop automatically 10 seconds after it is
started.
5. Play something on the Digital Piano.
• You may not be able to get 10 seconds of sampling if
Digital Piano memory is low due to storage of other data. If
this happens, deleting other memory data you no longer
need will free up memory space and you should be able to
sample for 10 seconds. See “Deleting a Sampled Sound”
on page E-23 for more information.
• Sampling sound and storing it will delete any sound
data currently stored under the same tone number. To
help ensure that you do not accidentally delete
important data, be sure to read “Protecting Against
Accidental Deletion of Sampled Sounds” on page E-23.
Sampling and Playing a Melody
Sound (Melody Sampling)
To sample a sound
N o D a t a
No sampled sound stored
Lights
W a i t i n
g
Flashes
S a m
p
lin
g
Lights
S 1 : O r
g
n l
Sampled sound 1
Used memory
(Unit: Kbytes)
Remaining memory
capacity

Sampling Sounds and Playing Them on the Digital Piano
E-18
■How sampled sounds are played
Pressing Middle C (C4) will play back the original sound. The
keys to the left and right of C4 play the sound at different
pitches.
You can use the following procedure to loop a sampled sound
so it continues to repeat, as you play on the Digital Piano.
1. Press bs.
2. While holding down 6, press cr.
This enters repeat standby.
3. Press the button (cm to cq) that corresponds to
the melody sampling tone number you want to
select.
This will start looped playback of the selected sound.
4. Press the same button again to stop playback.
5. Press cr to return to the screen that was
displayed before step 2 of this procedure.
You can use the following procedure to change the volume
level of the looped playback of each sampled sound, if you
want.
1. Press the button of the sampled sound whose
volume you want to change (cm to cq).
• This will cause the sounds loop to sound.
2. While the loop is sounding hold down the same
sampled sound button (cm to cq) as you press
any keyboard key.
• Pressing the keyboard key quickly will increase sample
sound volume, while pressing slowly will decrease
volume.
3. After the sampled sound is at the volume level
you want, release its button (cm to cq).
Looping a Sampled Sound
To select this tone number: Press this button:
671 cm
672 cn
673 co
674 cp
675 cq
C4
Funk 8Bt
Lights
Changing the Volume of Sampled Sound
Looped Playback
B
