Casio DM-100 User manual

DM-100
Operation Manual
Tablebeast Modification 23

CASIO.
DM-100
ELECTRONIC MUSICAL INSTRUMENT
Introduction
Your new DM-100 keyboard is a state-of-the-art musical in-
strument which incorporates the latest electronics tech-
nology to make its operation as easy as possible.
Exceptional sound quality backed up by a host of sophisti-
cated features and functions makes this keyboard a joy to
play for everyone.
In order to enjoy the features and functions of this unit
to their fullest, be sure to carefully read this manual and
follow the instructions contained herein.
. General Guide .
. Power Supply
. General Operation...
.
Preset
Tones
......
. Tone Bank Sounds .
. Auto-rhythms......
.
Upper
keyboard
Sampling
Function
.
. Troubleshooting
.
Care
of
Your
Keyboard
.
2DO5w9uecunR9N ——
Contents
Auto-accompaniment .
Specifications .....

1. General Guide
0000000 OO © 9 ®® DEO 000
ETEEN] Sedes
= CELLE E M-i TE EEEE
eeo e DDO 0200
Q Built-in speakers
@ Power switch
© Main volume slider
@ Lower volume slider
© Upper volume slider
Q Accomp volume slider
@ Casio Chord selector
Q Tempo control buttons
© Demo button
@ Rhythm selectors
@ Rhythm select button
@ Upper tone selectors
@ Lower tone selectors
@ Sample buttons
@ Tone select button
@ Tone Bank button
@ Sample tune buttons
@ Effect select button
@ Built-in microphone
€» Sampling long button
@ Sampling button
@ Clear key
® Loop key
6D Reverse key
® Envelope keys
® Intro/ending button
@ Start/stop button
® Synchro/fill-in button

1. General Guide
se NAS
[Rear panel]
UNE our
Demonstration Tune
This unit features a preset demonstra-
tion tune which has been carefully pro-
grammed to showcase all the features and
benefits of this unit. Simply press the
Demo button @, and listen to the DM-100
® Headphone jack
@® Line in/Sampling jack
@ Tuning controls
$ : 2 dps lays itself!
Adjust the pitch of the entire keyboard within +30 pay
cents
and
provide
easy
tuning
with
other
instruments.
*
The
demonstration
tune
is
played
in
an
endless
loop.
Press
@
Output
jack
(L/R)
the
Demo
button
again
to
stop
the
tune.
* The lower keyboard is inoperable while playing the demon-
As many preset tones are in stereo, be sure to use both output jacks stration- turie.
when connecting to an external amplifier.
@® AC adaptor jack

2. Power Supply
* Dry batteries
This
unit
can
be
powered
by
six
D
size
(SUM-I/R20P)
manganese
dry
cell
batteries.
Weakened
batteries
will
result
in
lower
volume
or
poor
tonal
quality.
The
power
indicator
lamp
will
gradually
lose
its
brightness
when
battery
power
weakens.
At
this
time,
change
batteries
or
shift
to
one
of
the
alternate
power
sources
men-
tioned below.
Battery replacement:
@ Open the battery compartment cover on the bottom
of the unit and take out used batteries.
(2)
Load
new
batteries
taking
care
that
polarity
is
correct.
*
It
is
advisable
to
replace
all
six
batteries
at
the
same
time
for
longer
battery life.
* Standard battery life is approximately 7 hours.
* Car battery
With
the
car
battery
adaptor
(CA-5,
optional),
DC
power
is
supplied
from
a
car
battery
through
the
cigarette
lighter socket.
An AC adaptor (AD-5, optional) is required when using
household current. Use only a genuine CASIO adaptor
with the same voltage rating (100, 117, 220, or 240) as the
power supply in your area to prevent component damage.
Plug the AC adaptor into the AC outlet and the cord into
the unit. This will automatically cut off the battery power
supply.

2. Power Supply
x Auto power off function
Power
is
automatically
cut
off
approximately
6
minutes
after
the
last
operation
of
the
unit.
Power
supply
can
be
restored
by
switching
power
OFF
and
then
ON
again.
CAUTIO:
*
Use
only
genuine
CASIO
adaptors
to
avoid
risk
of
damage.
* Remove batteries from the battery compartment when
the
unit
is
not
used
for
extended
periods.
(Battery
leak-
age can damage electrical parts.)
*
The
adaptor
may
become
warm
when
left
connected
to
an
outlet.
This
is
normal,
but the
adaptor
should
be
disconnected
when
not in use.
*
THE
FOLLOWING
CONDITION
CAN
CAUSE
BATTERIES
TO BURST:
1. Use of adaptors other than genuine CASIO adaptors.
2. loading batteries with polarities reversed.
3. General Operation
@ Turn the power switch ON.
(2)
Adjust
the
volume
levels
(Main,
Lower,
Upper)
with
respective
volume
controls.
(8)
Select
one
of
20
preset
tones
for
the
lower
keyboard
(see
“Preset
Tones",
page
7)
or
one
of
the
210
Tone
Bank
sounds
(see
"Tone
Bank
Sound",
page
9).
Lower volume slider
Main
volume
slider
Upper
volume
slider
-
m
m"
Power
switch
lon
=
[^
z
=
——
Accomp
—
volume
F,
- "
^
slider
POWER Wam = owen UPPER ACCOMP
volte YOUU voume — VOLUME

3. General Operation |
(4) Select one of the 8 preset tones for the upper keyboard
(see “Preset Tones,’ page 8).
(8 Go ahead and play on both the upper and lower
keyboards.
4. Preset Tones
* To select a preset tone for the lower keyboard
@ Press the tone select button to choose the upper row
or
lower
row
of
the
preset
tones
for
the
lower
keyboard.
The upper or lower select indicator lights to show the
active row.
(2) Press one of the tone selectors to choose a preset tone.
*
“PIANO”
tone
is
automatically
selected
when
power
is
turned
ON.
* Dual bass sounds on the lower keyboard
When BASS sound is selected for the lower keyboard
by
pressing
the
"BASS"
tone
selector,
two
different
bass
tones can be played on the keyboard at the same time.
The WOOD BASS tone sounds on the lower half of the
keyboard (C2—B3), while the SLAP BASS tone sounds
on the upper half (C4—C6).
LL
[e
—
Wood
bass
(C2—B3)
—ele—
siap
bass
(C4—C6)
——À4

He
4. Preset Tones
* Percussion sounds on the lower keyboard
When PERCUSSION sound is selected for the lower
keyboard by pressing the "PERCUSSION" button, the
lower keyboard keys can be used to play a total of 49
different built-in percussion sounds. These sounds are
assigned to respective keys as shown below;
tom 1/2/3/4/mixed
synth. tom 1/2/3
cow bell 1/2
triangle open/mute
timbales; high mute/
high/low/mixed
computer game sound
12/3
agogo high/low
bass drum 1/2
snare drum 1/2
gated snare drum
rim shot
closed hihat 1/2
open hihat 1/2
crash cymbal 1/2/3/mixed
synth. cymbal 1/2/3
ride cymbal 1/2
gong 1/2
©000000000
© © 00000
* To select a preset tone for the upper keyboard
Press one of the upper tone selectors.
“PIANO” tone is automatically selected when power is turned ON.
* Sample buttons 1~4 can be used to select sounds which you have
assigned to them through sampling. When sampling is not carried
out, the sample memory banks contain the following sounds;
Sample 1: Piano
Sample 2: Vibraphone
Sample 3: Guitar
Sample 4: Pipe Organ

5. Tone
Bank
Sounds
à The lower keyboard features Casio's innovative "Tone
*
Bank"
feature,
which
lets
you
choose
from
an
amaz-
ing total of 210 different sound combinations. To create
these layered sounds, the Tone Bank function actually inte-
grates the characteristics of the 20 preset sounds which
are produced by the new PCM sound source to create
entirely new and distinct sounds which can be selected
through the following procedure.
* To select Tone Bank sounds on the lower keyboard
(D Select any of the 20 preset tone. When selecting Tone
Bank sounds, the tone initially selected is used as a
base, or "Primary" sound.
* When the Primary sound is selected, the keyboard features 10-note
polyphony.
(2) Press the Tone Bank button.
This activates the Tone Bank function, allowing you to
choose a Secondary sound to integrate with the
Primary sound you just selected.
* After the Tone Bank button is pressed, the keyboard changes to 5-note
polyphony.
(8)
Select
any
other
of
the
20
preset
tones.
The
characteris-
tics
of
this
"Secondary"
sound
is
automatically
integrat-
ed
with
those
of
the
"Primary"
sound
already
selected.
To select a different secondary sound
The
secondary
sound
can
be
changed
at
any
time,
as
long
as
the
Tone
Bank
function
is
selected.
Simply
select
a
different
preset
tone—the
primary
sound
re-
mains
the same.
To select a different primary sound
The
primary
sound
can
be
changed
by
first
turning
the
Tone
Bank
function
OFF
(press
Tone
Bank
button
so
that indicator
goes out), selecting
any other preset
tone,
and
finally
turning
the
Tone
Bank
function
back
ON.
The
secondary
tone
remains
the
same
in
this
case.

5. Tone Bank Sounds |
< Example of Tone Bank Operation
@) Select the preset ORGAN tone by JAZZ
pressing the corresponding tone selec-
tor. (This is the “Primary” sound.)
Initially, the ORGAN tone can’ be
played with 10-note polyphony.
@ Press the Tone Bank button.
The ORGAN tone can now be played
with 5-note polyphony.
* Indicator lights
Tone bank button
NOTE:
When power is turned ON, the PIANO tone is auto-
matically selected in Tone Bank memory. Because of this,
procedure (2) above causes the ORGAN tone to be inte-
grated with the PIANO tone.
@ Select the preset CHORUS tone by CHORUS
pressing the corresponding tone selec- E
tor. (This is the "Secondary" sound.) MERC
Now, the "ORGAN + CHORUS” inte-
grated Tone Bank sound can be played
with 5-note polyphony.
®
®
Next, try changing the Secondary
sound by selecting the preset FLUTE
tone. The “ORGAN + FLUTE” integrat-
ed Tone Bank sound can be played
with 5-note polyphony.
Next, try changing the Primary sound
by first pressing the Tone Bank button
once again to turn the Tone Bank func-
tion OFF temporarily. The preset
ORGAN tone can once again be played
with 10-note polyphony.
Select a new Primary sound—the
STRINGS tone for example, and turn
the Tone Bank function back ON. As
the secondary sound (FLUTE) does not
change in this case, you can now play
the “STRINGS + FLUTE” integrated
Tone Bank sound with 5-note poly-
phony.
210 SOUND
TONE BANK
210 SOUND
TONE BANK

6. Auto-rhythms
* Playing an auto-rhythm
@ Press the rhythm select button to choose the upper row
or the lower row of auto-rhythms. The upper or lower
select indicator lights to show the active row.
(2) Press one of the rhythm selectors.
(3) Press start/stop button to start the rhythm.
(&) Adjust the tempo of the rhythm by using the tempo
control buttons. Pressing the <A> button will.increase
tempo, while pressing the <¥> button will decrease
tempo.
* Tempo of the auto-rhythm can be adjusted between 40 and 256 beats
per minute. Pressing both tempo keys at the same time resets the
tempo to 132 beats per minute.
® You can adjust the relative volume of the rhythm by
using the accomp and lower volume sliders.
© Press start/stop button once again to stop auto-rhythm
play.
* Using Synchro/fill-in button
Press to enter synchro start standby. Rhythm starts
when an accompaniment keyboard key (lower 15
octave, C through F) is pressed. (See page 13-14 to use
synchro start in the auto-accompaniment perfor-
mance.) When pressed during auto-rhythm and accom-
paniment performance, an appropriate fill-in is inserted
in the rhythm pattern. If the button is held down, the
fill-in pattern is repeated until the end of the measure
during which the button is released.
Using Intro/ending button
If you press the intro/ending button instead of press-
ing the start/stop button to start an auto-rhythm, the
selected auto-rhythm begins after a one-measure intro
pattern. This can be an effective way to lead into auto-
rhythm performance. If pressed during auto-rhythm
and accompaniment performance, the rhythm stops af-
ter an appropriate ending pattern.
* Using synchro start with an intro pattern
Press the synchro/fill-in button to enter synchro start
standby, and subsequently press the Intro/ending but-
ton. Rhythm starts when an accompaniment keyboard
key is pressed, after a one-measure intro pattern.

7.
Auto-accompaniment
E Eum o a
* Casio Chord selector Casio Chord selector
Slide to select one of the Casio Chord
functions.
putes
m.
[0| ns site estes
For normal
play without
auto-
accompaniment.
FINGERED 1 & 2 ...For auto-accompaniment pressing
chords as usual on the lower key-
board.
ON seen For auto-accompaniment using the
Casio
Chord
system
on
the
lower
keyboard.
Accomp volume
* Accompaniment volume control slider
Adjust the volume of the auto-
accompaniment.
HUTTE
axe
ur
NOTES:
* If the Casio Chord selector is set to “FINGERED (1 or
2)" or “ON”, the lower 1.5 octave of the lower keyboard
become accompaniment keyboard keys, and the upper
part of the lower keyboard becomes 4-note polyphonic.
I—
Accompaniment
—+}+—
Melody
keyboard
(4-note
polyphonic)
—*|
keyboard
* During auto-accompaniment performance, chord
played on the accompaniment keyboard will continue
to sound after releasing the keys.
* Auto-accompaniment starts with rhythm, the moment
the accompaniment keyboard key is pressed if synchro
start is in standby status.

Casio Chord system
The Casio Chord system has been developed so you
can play the four main types of chords more easily.
Playing of the chords is simplified as shown below:
* Pressing one of the accompaniment keyboard keys
produces a major chord corresponding to that
note.
* Simultaneously pressing any key to the right (two
keys at the same time) results in a minor chord.
* Similarly, pressing one more key to the right (three
keys in all) produces a seventh chord, and press-
ing the fourth key to the right (four keys in all)
creates a minor seventh chord. `
< Examples >
C (C major chord)—Press @.
Cm (C minor chord)—Press @, @ together.
C7 (C seventh chord)—Press @, , © together.
Cn; (C minor seventh chord)—Press @, ©, ©, O
together. cok FGAB F
* Not only @ @, and @, but |
any black or white keys can be
|
used as long as they are to the
d 7 0000
right
of
@.
Accompaniment
keyboard
J
7. Auto-accompaniment
[1] Auto-accompaniment using the Casio Chord system
(One-finger method)
(1) Set the Casio Chord selector to “ON”. m
p
E
(2)
Select
one
of
the
auto-rhythms
and
[c
press the synchro/fill-in button. Eg
* Tempo indicator lights, meaning that the accom- E97
paniment keyboard keys are ready for play.
Play on the accompaniment keyboard keys according
to the Casio Chord system.
* Adjust the tempo and accompaniment volume using the respective
controls.

7. Auto-accompaniment
[2] Auto-accompaniment play using standard chord
fingering
(1) Set the Casio Chord selector to “FIN-
GERED 1” or “FINGERED 2".
@ Select one of the auto-rhythms and
press the synchro/fill-in button.
* Tempo indicator lights, meaning that the accom-
paniment keyboard keys are ready for play.
EA 3
VCI
(8) Play a chord on the accompaniment keyboard keys.
* Adjust the tempo and accompaniment volume using the respective
controls.
*
This
unit
is
capable
of
recognizing
the
following
chords;
<M,
m,
—5,
+5, dim, sus4, 7, MZ, mz, mM7, m75, Aus4, 9, m9»
«About “Fingered 1" and “Fingered 2"
This keyboard features two different types of fingered
accompaniment patterns. You can select which type you
want by selecting either the Fingered 1 mode, or the
Fingered 2 mode. Respective accompaniment patterns and
characteristics are as listed below.
(Fingered 1 Accompaniment)
Accompaniment consists of a single bass line and two
different backing chord patterns. The pattern does not
change until you play a chord consisting of at least 3 notes.
(Fingered 2 Accompaniment)
Accompaniment consists of a single bass line and a single
backing chord pattern. In addition, you can add notes
manually in two-note polyphony on the “accompaniment
keyboard" without affecting the accompaniment pattern.
The pattern does not change until you play a chord con-
sisting of at least 3 notes.
* Auto-accompaniment tones are preset in correspondence to each
auto-rhythm type. A list of auto-rhythms and corresponding accom-
paniment tenes is previded on: pape 15.

7. Auto-accompaniment
<About
the
tones
used
in
the
auto-accompaniment
>
Each
auto-accompaniment
pattern
consists
of
one
bass
line
and two types of chord
lines (chord
1 and chord
2). The
tones
of
these
elements
are
preset
corresponding
to
each
auto-rhythms
as shown
below;
RHYTHMS CHORD 1 TONES CHORD 2 TONES BASS TONES
ROCK 1 BRASS ENS. METALLIC SOUND SLAP BASS
ROCK 2 BRASS SYNTH. CLAVI SLAP BASS
8 BEAT 1 JAZZ ORGAN PIANO SLAP BASS
8 BEAT 2 METALLIC SOUND BRASS ENS. SLAP BASS
16 BEAT 1 MARIMBA ELEC. PIANO SLAP BASS
16 BEAT 2 SYNTH. CLAVI BRASS ENS. SLAP BASS
DISCO 1 SYNTH. CELESTA BRASS ENS. SLAP BASS
DISCO 2 HARP STRINGS BRASS ENS.
POPS 1 JAZZ ORGAN PIANO WOOD BASS
POPS 2 FLUTE BRASS ENS. SLAP BASS
SLOW ROCK 1 PIANO. VIBRAPHONE WOOD BASS
SLOW ROCK 2 PIANO HARP WOOD BASS
SWING PIANO BRASS ENS. WOOD BASS
SAMBA SYNTHE. CLAVI JAZZ ORGAN SLAP BASS
BOSSA NOVA ELEC. PIANO STRINGS WOOD BASS
WALTZ
STRINGS
ORGAN
WOOD
BASS
REGGAE JAZZ ORGAN FUNKY CLAVI SLAP BASS
TANGO ACCORDION PIANO WOOD BASS
BEGUINE PIANO JAZZ GUITAR WOOD BASS
MARCH BRASS ENS. FLUTE BRASS ENS.

8. Upper Keyboard Sampling Functi
6 With the DM-100's upper-keyboard sampling func-
*
tion,
sounds
up
to
1.4
seconds
in
length
can
be
"sampled'—or
digitally
recorded—and
then played
back on
the upper
keyboard.
There
are two different
sampling
times
— 1.4 seconds
and 0.7 seconds.
With 0.7second
sam-
pling,
you can store up to 4 different
sounds
in memory,
while with "long"
1.4-second
sampling,
you can store up
to 2 different
sounds.
[Input
from built-in
microphone
or line input]
With the DM-100,
two different
methods
can be used to
record
sounds.
You can use the built-in
microphone
for
direct
PCM sampling,
or connect
an external
device
such
às a cassette
tape recorder
or CD player
to the line input.
* Sampling procedure
(D Select one of the 4 sample buttons.
* Press sample button 1 or 3 for long sampling.
* Sample 1 is automatically selected when sam-
pling is performed without specifying a sample
button.
(2) Press the sampling button.
SAMPLING
* Press the sampling long button for 14-second
sampling.
ETT
(8) Enter the sound using the built-in microphone, an
external microphone or line in.
* Any sampled sound previously present in the selected memory is
deleted.
* If no sound is entered for approximately 12 seconds, sampling standby
is cancelled.
(&) Now the sampled sound can be played on the 32
keyboard keys.
* Loop, reverse, envelope
Loop and/or reverse effects can
be added to the sampled
sound. Also, an envelope can be
applied to the sampled sound.
Envelope keys
Reverse key
Loop key
Clear key

8. Upper keyboard Sampling Function
T) Select one of the 4 sample buttons.
(2) Press the effect select button followed
by any desired effect key (loop, reverse, Select
6 envelopes).
* The reverse effect takes 3-6 seconds to apply.
* Loop and reverse effects can be performed and cancelled by turns
each time the effect key is pressed.
* Three effects (loop, reverse, one of 6 envelopes) can be simultane-
ously applied to a sample sound.
* All effects can be cancelled by pressing the effect select button
followed by the clear key.
<6 envelopes >
seine Piano/guitar damped tone, slow decay.
ae Long release (damped tone), slower decay
than @.
Eve Reverb, some sustain after decay begins.
vads Slow attack, slow increase of volume at
beginning.
... Tremolo |, fade out with slight vibrato.
Tremolo II, slight vibrato.
* Sample tune
The pitch of sampled sounds can be easily tuned to
A4 of the upper keyboard with the sample tune
function.
@ Press one of 4 sample buttons to be maa
tuned, followed by either of the sam- ° ° ° '
ple tune buttons (A) (V).
* A continuous sound in the standard pitch (A4 of
the upper keyboard) will be heard together with
the sampled sound for comparison.
(2) Hold down the tune up button (A) to
raise the pitch, or the tune down but-
ton ( V) to lower the pitch. Release the
button at the point where the standard
pitch sound and the sampled sound
are tuned.
* The pitch of the sampled sound can be changed in the range of one
octave, with the original pitch being at the mid-point of the octave.
* Simultaneously pressing the tune up (&) and down (Y) buttons allows
comparison between the sampled sound and standard pitch (A4 of
the upper keyboard) without raising or lowering the original pitch
of the sampled sound.
Y SAMPLE TUNE à

9. Troubleshooting
*For any malfunction, always check battery condition first. (see page 5)
1. Main volume turned down.
2. Headphones connected.
3. Auto power off has activated.
4. Sampling function is activated.
n . Turn up main volume.
. Disconnect headphones.
3. Turn the power switch off and then
on again.
4. Upper keyboard is inoperative after
sampling button is pressed. Press
one of the sample buttons (1—4) to
return to normal operation.
S
Main, accompaniment and lower
volume turned down.
Turn up main, accompaniment and
lower volume.
Main, accompaniment and lower
volume turned down.
Turn up main, accompaniment and
lower volume.
Another sound has been sampled.
The sound previously sampled is auto-
matically erased if you sample another
sound.
Refrigerators, washing machines and
similar electric appliances.
Use outlet as far away as possible from
appliance thought to be the cause.
1. Main volume turned down.
2. Defective connection cord.
1. Turn up main volume.
2. Replace connection cord.

. Avoid heat, humidity, and direct sunlight.
Do not overexpose the unit to direct sunlight, place it
near a heater, or in any area subject to high tem-
perature.
. Avoid severe impacts and do not drop.
Severe impacts can result in malfunction. When carry-
ing or transportion the unit, protect the keyboard and
keys by packing with soft cloth.
Keep the unit free of liquids, dust, particles, etc.
Do not allow foreign matter to enter between the keys.
Be especially careful of metallic objects such as hair-
pins, sewing needles or coins. Also, do not allow the
unit to get wet.
Never attempt to modify any part of the unit.
Your keyboard is a precision musical instrument made
up of sophisticated electronic parts. Any modification
of, or tampering with internal components can cause
trouble or malfunction.
Do not use lacquer thinner or similar chemicals for
cleaning.
Clean the keyboard with a soft cloth dampened with
a mild detergent solution and squeeze it until almost
dry.
Remove batteries before extended storage.
Batteries left in the unit for long periods can leak and
cause damage to electronic circuitry.
In case of malfunction. . .
Check whether buttons and connections are set cor-
rectly as indicated in the troubleshootiong chart. If the
unit still does not work properly, contact the original
retailer or a nearby dealer. Never attempt to repair the
unit yourself. This can result in serious damage of the
components.

Model:
DM-100
Number of keys:
Upper; 32 mini keys Lower; 49 mini keys
Polyphonic:
Upper; 4-note polyphonic Lower; 10-note polyphonic
Preset tones:
Upper; 8
Piano, Vibraphone, Pipe organ, Violin, Trumpet, Flute, Clarinet, Guitar
Lower; 20
Piano, Harpsichord, Vibraphone, Jazz organ, Pipe organ, Brass-ens, Flute, Chorus, Bells, Per-
cussion, Elec piano, Funky clavi, Jazz guitar, Organ, Accordion, Strings, Synth-reed, Metallic
sound, Synth-ens, Bass (Wood bass/Slap bass)
Sampling Tones: Upper; 4
Tone bank sounds: Lower; 210
Auto-rhythms: 20;
Rock 12, 8 beat 1-2, 16 beat 1-2, Disco 1-2, Pops 1-2, Slow rock 1-2, Swing, Samba, Bossa
nova, Waltz, Reggae, Tango, Beguine, March
Rhythm source:
49 PCM rhythm sources
Auto-accompaniment
function:
Lower; Casio Chord on/fingered 1/fingered 2
Sampling time: Upper; 0.7-second sampling (x4) 1.4-second sampling (x2)
Sampling rate:
Upper; 9.38 kHz 8-bit
Sampling tune:
Upper; +1 octave
Effects:
Upper; Reverse, Loop, Envelope x 6
