Casio 1874 Configuration guide

1874-1
Module No. 1874
PAPA
A
P
24
RECALL AUTO SPL DATA
INTERVAL
C
A
B
D
P
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
•Press Cto change from mode to mode. Each mode is explained in detail on the
following pages.
•After you perform an operation in any mode, pressing Creturns to the Timekeeping
Mode.
•While in any mode hold down Cfor 2 seconds, to enter the Dive Time Measurement
Mode.
Countdown Alarm ModeStopwatch Mode
▲
▲
▲
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
▲
Hold down
Cfor 2
seconds.
Dive Time Measurement Mode Timekeeping Mode Alarm Mode
GENERAL GUIDE
C
A
B
D
PA PA
A
P
24
RECALL AUTO SPL
INTERVAL
Day of week
Month
PM indicator
Hour
Seconds
Day
Minutes
Seconds Hour Minutes
Day Month Year
12/24-Hour
Format
TIMEKEEPING MODE
•In the Timekeeping Mode, press Bto illuminate the
display.
To set the time and date
1. Press AwhileintheTimekeepingMode.The seconds
digits flash on the display because they are
selected .
2.Press Cto change the selection in the following
sequence.
3. While the seconds digits are selected (flashing), press Dto reset them to 00. If you
press Dwhile the seconds count is in the range of 30 to 59, the seconds are reset to
00 and 1 is added to the minutes. If the seconds count is in the range of 00 to 29, the
minutes count is unchanged.
4. While any digits (besides seconds) are selected (flashing), press Dto increase the
selection. Holding down Dchanges the current selection at high speed.
The 12/24-hour setting is selected (flashing), press Dto switch between the 12-hour
(
12H) and 24-hour (24H) formats.
•With the 12-hour format, the P(PM) indicator appears to the left of the hour digits for
times in the range of noon to 11:59 pm and the A(AM) indicator appears to the left of
the hour digits for times in the range of midnight to 11:59 am.
•The 24-hour format is indicated by 24 on the display. Times are shown in the range of
00:00 to 23:59.
5. After you set the time and date, press Ato return to the Timekeeping Mode.
•The day of the week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 1995 to December 31, 2039.
•If you do not operate any button for a few minutes while a selection is flashing, the
flashing stops and the watch goes back to the Timekeeping Mode automatically.
About the backlight
The backlight uses an EL (electro-luminescent) panel that causes the entire display to
glow for easy reading in the dark. In the Timekeeping Mode or Dive Time Measurement
Mode, press Bto illuminate the display for about two seconds.
•The electro-luminescent panel loses illuminating power after very long use.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The backlight automatically turns off whenever an alarm sounds.
C
A
B
D
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
Current time
Mode indicator
DIVE TIME MEASUREMENT MODE
The Dive Time Measurement Mode lets you measure the
totaltime youspend underwater whilediving or snorkeling,
and the amount of time spent on the surface (surface
interval). The watch also stores one set of diving time
data (total dive time and dive start time) into log memory
for later recall.
•In the Dive Time Measurement Mode, press Bto
illuminate the display.
Precautions
For your own safety, never operate the buttons of the
watch while underwater or while on the water’s
surface. Perform button operations in a safe place
after leaving the water.
C
A
B
D
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
Dive start time
Dive time (hours,
minutes, seconds)
Before Diving/Snorkeling
•Be sure to check if the battery power is low (check for low light intensity or a dim
display). If it is, do not use the watch for diving/snorkeling.
•Make sure that the watch is set to the correct time of day.
•Check the glass, case and band for cracks or chips.
•Make sure that the band is fastened securely around your wrist.
While Diving/Snorkeling
•Always use the “buddy system” when diving — never dive alone.
•Check to make sure that timer operation is being performed properly.
•Take care when diving/snorkeling near rocks or coral to avoid scratching the
watch.
After Diving/Snorkeling
•To avoid corrosion, rinse your watch thoroughly with fresh water to remove salt
water, dirt, etc. (When possible, soak the watch in fresh water overnight to make
sure that all salt is removed.)
To use the Dive Time Measurement Mode
1.Before diving/snorkeling, switch to the Dive Time
Measurement Mode by holding down Cfor at least
two seconds.
2. Tostart thedive time measurementoperation, pressD.
3.To stop the measurement, hold down Dfor at least
one second (until the watch emits a long beep).
•At this time, timing of the surface interval starts. This
timing is performed internally, and it is not indicated on
the Dive Time Measurement Mode display. For details
on how to view surface interval data, see “To review log
data”.
Important!
Do not recall log data (to view the surface interval) while this procedure is in progress. If
you do, the dive time to that point will be stored into memory and the data will be cleared
when you re-start the dive time measurement operation.
4. To resume timing from the dive time shown on the display, press D.
•You can repeat steps 3 and 4 as many times as you like.
5. To clear the Dive Time Measurement Mode, stop the measurement operation (step 3,
above) and then press A.
To review log data Log data can be reviewed (recalled) in the Timekeeping
Mode.
1.Hold down Cfor at least two seconds to enter the
Timekeeping Mode from the Dive Time Measurement
Mode.
2.Hold down Dto display the Log Data Display. The
Log Data Display remains visible as long as you hold
down D. When you release D, the normal
Timekeeping Mode display returns.
To clear the log data memory
Log data in memory is automatically replaced by the
newest measurement. Use the following operation if you
want to manually clear the log data memory.
1. While in theTimekeeping Mode,hold downDtodisplay
the Log Data Display.
2.Press Ato clear the log data memory. At this time, the
display clears so that no data is shown.
C
A
B
D
PA
A
24
RECALL AUTO SPL DATA
INTERVAL
Surface interval
Dive time
Dive start time
C
A
B
D
A
24
RECALL AUTO SPL DATA
INTERVAL
[ Cleared Display ]

1874-2
C
A
B
D
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
Minutes
Mode indicator
Hours
Seconds
Current time
D
Start Stop
(a) Elapsed time measurement
➤Re-start Clear
D➤Stop
D➤D➤B
(b) Split time measurement
D
Start Split
➤
Split release
Clear
B➤Stop
B➤D➤B
(c) Split time and 1st-2nd place times
D
Start Split
➤Stop Clear
B➤
Split release
D➤B➤B
First runner
finishes. Second runner
finishes.
Record time of
first runner.
Record time
of second
runner.
C
A
B
D
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
1/100 second
Mode indicator
Minutes
Hours
Seconds
Current time
1/10 second
STOPWATCH MODE
TheStopwatch Mode lets youmeasure elapsed time, split
times, and two finishes. The range of the stopwatch is 23
hours, 59 minutes, 59.99 seconds.
COUNTDOWN ALARM MODE
Thecountdown timercan be setwithin a rangeof 1second
to24 hours. When the countdownreaches zero, an alarm
sounds for 10 seconds or until you press any button.
•You can also select auto repeat, which automatically
restarts the countdown from the original value you set
whenever zero is reached.
To set the countdown time
1. Press Awhileinthe CountdownAlarmMode.Thehours
digit flashes on the display because it is
selected .
2.Press Cto change the selection in the following
sequence.
Hours Minutes Seconds
Auto repeat on indicator
C
A
B
D
P
A
24
SPL
AUTO
3. PressDto increasetheselection. HoldingdownDchanges theselection athighspeed.
•To set the starting value of the countdown time to 24 hours, set to 0:00 00.
4. After you set the countdown time, press Ato return to the Countdown Alarm Mode.
•If you do not operate any button for a few minutes while a selection is flashing, the
flashing stops and the watch goes back to the CountdownAlarm Mode automatically.
To use the countdown timer
Press Dwhile in the Countdown Alarm Mode to start the countdown timer.
•When the countdown reaches zero and auto repeat is turned off, the alarm sounds or
until you stop it by pressing any button. The countdown time is automatically reset to its
starting value after the alarm stops.
•Press Dwhile a countdown operation is in progress to pause it. Press Dagain to
resume the countdown.
•To completely stop a countdown operation, first pause it (by pressing D), and then
press B. This returns the countdown time to its starting value.
To turn auto repeat on and off
1.Press Awhile in the Countdown Alarm Mode. The
hoursdigit flashes on thedisplay because it is
selected .
2.Press Bto turn auto repeat on (AUTO displayed) and
off (AUTO not displayed).
3.Press Ato return to the Countdown Alarm Mode.
•When the end of the countdown is reached while auto
repeatis on, the alarmsounds, but the countdownstarts
again automatically whenever the countdown reaches
zero.You canstop timing by pressing D, and manually
reset to the starting countdown time by pressing B.
•Normally, an alarm tone sounds for about 10 seconds when the end of the countdown
is reached. If you use auto repeat with start time of 10 seconds or less, the alarm tone
sounds for only one second.
C
A
B
D
PAPA
A
24
RECALL AUTO SPL DATA
INTERVAL
PA PA
INTERVAL
Mode indicator
Hour : Minutes
Current time Alarm on indicator
Alarm No.
Alarm 1 Alarm 2 Hourly Time SignalAlarm 3
ALARM MODE
You can set up to three independent alarms with hour,
minutes, month, and day. When an alarm is turned on, an
alarm tone sounds for 20 seconds when the time is
reached. Press any button to stop the alarm after it starts
to sound.
When the Hourly Time Signal is turned on, the watch
beeps every hour on the hour.
Alarm Types
The alarm type is determined by the settings you make,
as described below.
•To set a Daily alarm
Set the hour and minutes for the alarm time. Set xfor
the month and xx for the day (see step 4 under “To set
analarm time”). This type of setting causes thealarm to
sound every day at the time you set.
•To set a Date alarm
Set the month, day, hour and minutes for the alarm time. This type of setting causes
the alarm to sound at the specific time, on the specific date you set.
•To set a 1-Month alarm
Set the month, hour and minutes for the alarm time. Set xx for the day (see step 4
under “To set an alarm time”). This type of setting causes the alarm to sound every day
at the time you set, only during the month you set.
•To set a Monthly alarm
Set the day, hour and minutes for the alarm time. Set xfor the month (see step 4
under “To set an alarm time”). This type of setting causes the alarm to sound every
month at the time you set, on the day you set.
To set an alarm time
1. Press Dwhile in the Alarm Mode to select the alarm whose time you want to set.
Month-Day
Hour Minutes DayMonth
2. After you select an alarm, press A. The hour digits flash on the display because they
are
selected .
•This operation automatically turns on the alarm.
3. Press Cto change the selection in the following sequence.
4. PressDto increasetheselection. HoldingdownDchanges theselection athighspeed.
•To set an alarm that does not include a month (Daily alarm, Monthly alarm), set xfor
the month. Press Duntil the xmark appears (between 12 and 1) while the month
digits are flashing.
•To set an alarm that does not include day (Daily alarm, 1-Month alarm), set xx for the
day. Press Duntil the xx mark appears (between 31 and 1) while the day digits are
flashing.
•The format (12-hour and 24-hour ) of the alarm time matches the format you select for
normal timekeeping.
•Whensetting the alarm timeusing the 12-hour format,take care to setthe time correctly
as morning (Aindicator) or afternoon (Pindicator).
5. After you set the alarm, press Ato return to the Alarm Mode.
•If you do not operate any button for a few minutes while a selection is flashing, the
flashing stops and the watch goes back to the Alarm Mode automatically.
To turn an alarm and Hourly Time Signal on and off
1. In the Alarm Mode, press Dto select an alarm or the Hourly Time Signal.
2. When the alarm or Hourly Time Signal you want to is selected, press Bto turn it on
and off.
Indicates alarm is ON.
Indicates Hourly Time Signal is ON.
•The alarm on indicator ( ) and the Hourly Time Signal on indicator ( ) are shown
on the display in all modes while these functions are turned on.
To test the alarm
Hold down Dwhile in the Alarm Mode to sound the alarm.
