Operation Guide 5347 (OC)
MA1402-EB
Ú
#!3)/#/-054%2#/,4$
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
xNote that the product illustrations in this manual are intended for reference only, and so the actual
product may appear somewhat different than depicted by an illustration.
This watch does not have a city code that corresponds to the UTC offset of –3.5 hours. Because of
this, the radio-controlled atomic timekeeping function will not display the correct time for Newfoundland,
Canada.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss suffered by
you or any third party arising through the use of this product or its malfunction.
E-2
About This Manual
Operations are performed using the watch’s crown, and the two buttons
indicated by the letters Aand Bin this manual.
Hand Functions
1
1 Hour Hand
2
2 Second Hand
3
3 Minute Hand
4
4 Upper Dial Big Hand
5
5 Upper Dial Small Hand
6
6 Lower Dial Big Hand
7
7 Lower Dial Small Hand
8
8 Mode Hand
9
9 Day Indicator
This User’s Guide uses numbers shown above to identify watch hands and indicators.
Hand and Date Indicator Movement
x
9
Day Indicator movement is coordinated with
8
Mode Hand movement. When changing the
9
Day
Indicator setting, the
8
Mode Hand will also rotate.
xThe
9
Day Indicator changes gradually at midnight. It takes anywhere from about 90 seconds to three
minutes for the day to change. The
8
Mode Hand will rotate when the
9
Day Indicator changes.
xThe day may not be displayed correctly while the crown is pulled out.
xThe Home City date is displayed in the Timekeeping Mode and the Stopwatch Mode. The World Time
City date is displayed in the World Time Mode (page E-23).

  
 
Upper dial
Lower dial
E-3
Crown Operations
The crown can be pulled out to one of two (click) positions. Never apply undue force when pulling out the
crown.
Important!
xIn order to ensure full water resistance and to prevent damage due to impact, make sure that the crown
is normally pushed in fully when using the watch.
xWhen pulling out the crown, avoid using undue force, which creates the risk of personal injury to your
fingers and fingernails, and of watch malfunction.
First click Second click
High-speed Movement
When setting a time or when performing home position adjustment (page E-39), you can move the hands
either forward or back at high speed. There are two high-speed levels: HS1 and HS2 (faster than HS1).
E-4
To start HS1 high-speed movement
While the crown is pulled out, rotate it rapidly three turns away from you (for
forward movement) or towards you (for reverse movement). High-speed
movement will continue even if you release the crown.
To start HS2 high-speed movement
While HS1 high-speed movement is progress, again rotate the crown rapidly
three turns in the same direction as the current HS1 movement (away from you
for forward movement or towards you for reverse movement).
To stop high-speed movement
Rotate the crown in the direction that is opposite that of the current high-speed
movement or press any button.
Important!
xLeaving the crown pulled out for more than two minutes (approximately 30 minutes in the case of hand
and day home position adjustment) without performing any operation will automatically cause crown
operations to become disabled. If this happens, press the crown back in, pull it out, and then start the
operation over again.
E-5
Things to check before using the watch
1. Pull the crown out to the first click.
2. Hold down Bfor at least two seconds to enter the Timekeeping Mode.
3. Push the crown back in.
4. Observe the movement of the
2
Second Hand.
Is the
2
Second Hand moving smoothly at one-second intervals?
Is the
2
Second Hand moving at two-second intervals
or is it stopped completely?
Go to step 5.
The watch is charged. For details about
charging, see “Charging the Watch”
(page E-9).
Power is low. Charge the watch by placing it in a
location where it is exposed to light. For details, see
“Charging the Watch” (page E-9).
NO
YES
YES
NEXT
E-6
5. Check the Home City.
Use the procedure under “Selecting a City” (page E-28) to configure your Home City.
Important!
xProper time calibration signal reception depends on correct Home City, time, and date settings in the
Timekeeping Mode. Make sure you configure these settings correctly.
6. Set the current time.
xTo set the time using a time calibration signal
See “To get ready for a receive operation” (page E-16).
xTo set the time manually
See “Configuring Current Time and Date Settings Manually” (page E-32).
The watch is now ready for use.
xFor details about the watch’s radio controlled timekeeping feature, see “Radio Controlled Atomic
Timekeeping” (page E-13).
E-7
Contents
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2
Crown Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3
Things to check before using the watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-5
Charging the Watch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-9
To recover from the sleep state . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-12
Radio Controlled Atomic Timekeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-13
To get ready for a receive operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-16
To perform manual receive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18
To check the result of the latest receive operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-19
To turn auto receive on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-20
Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-22
Selecting a City . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28
To select a city. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-28
To switch between standard time and summer time manually . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31

Operation Guide 5347 (OC)
E-8
Configuring Current Time and Date Settings Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32
To change the current time and date setting manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32
Using the Stopwatch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-36
To measure elapsed time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-38
Adjusting the Hand and Day Home Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-39
To adjust the hand and day home positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-44
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-49
E-9
Charging the Watch
The face of the watch is a solar panel that generates power from light. The generated power charges a
built-in rechargeable battery, which powers watch operations. The watch charges whenever it is exposed
to light.
Charging Guide
Whenever you are not
wearing the watch, be sure
to leave it in a location where
it is exposed to light.
xBest charging
performance is achieved
by exposing the watch to
light that is as strong as
possible.
When wearing the watch, makes
sure that its face is not blocked
from light by the sleeve of your
clothing.
xThe watch may enter a sleep
state (page E-12) if its face is
blocked by your sleeve even
only partially.
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot. Take care when
handling the watch to avoid burn injury. The watch can become particularly hot when exposed to
the following conditions for long periods.
xOn the dashboard of a car parked in direct sunlight
xToo close to an incandescent lamp
xUnder direct sunlight
E-10
Important!
xKeep the watch in an area normally exposed to bright light when storing it for long periods. This helps
to ensure that power does not run down.
xStoring the watch for long periods in an area where there is no light or wearing it in such a way that it is
blocked from exposure to light can cause power to run down. Make sure that the watch is exposed to
bright light whenever possible.
Power Levels
You can get an idea of the watch’s power level by observing the movement of
the
2
Second Hand.
xIf the
2
Second Hand is moving normally at one-second intervals, power is
at Level 1.
xIf the
2
Second Hand is moving at two-second intervals, power is at Level 2,
which is quite low (Low battery alert). Expose the watch to light as soon as
possible so it can charge.
Level Hand Movement Function Status
1 Normal. All functions enabled
22
2
Second Hand moves at
two-second intervals.
Time calibration signal reception and
home position adjustment disabled
3 All hands stopped at 12 o’clock. All functions disabled
xWhen power drops to Level 3, all settings (including timekeeping) will be
cleared. Recharging the battery will reset all settings to their initial factory
defaults, so you will need to configure settings again.


Moves at two-second
intervals.
E-11
xWhen the watch is at Level 3, exposing it to light for a while will cause the
2
Second Hand to move to
the position of second 57. This indicates that charging has started.
Power Recovery Mode
The watch is designed to go into a power recovery mode that stops hand operation temporarily whenever
power suddenly drops below a certain level due to continuous signal reception or other operations over a
short period. Note that all operations are disabled while the watch is in the power recovery mode.
The hands will move to the correct positions and the watch will resume normal operation after power
recovers (in about 15 minutes). Putting the watch in a location where it is exposed to light will help power
to recover sooner.
Charging Times
Exposure Level (Brightness) Daily
Operation *1
Level Change *2
Level 3 Level 2 Level 1
Outdoor sunlight (50,000 lux) 8 minutes 2 hours 18 hours
Window sunlight (10,000 lux) 30 minutes 6 hours 66 hours
Window sunlight on cloudy day (5,000 lux) 48 minutes 8 hours 107 hours
Indoor fluorescent lighting (500 lux) 8 hours 94 hours – – –
*1 Approximate exposure each day to generate power for normal daily operation.
*2 Approximate exposure to take power up one level.
xThe above times are for reference only. Actual times depend on lighting conditions.
xFor details about the operating time and daily operating conditions, see the “Power Supply” section of
the Specifications (page E-49).
E-12
Power Saving
Power Saving enters a sleep state automatically whenever the watch is left for a certain period in an area
where it is dark. The table below shows how watch functions are affected by Power Saving.
xThere actually are two sleep state levels: “second hand sleep” and “function sleep”.
Elapsed Time in Dark Operation
60 to 70 minutes (second hand sleep) Only the 2
2
Second Hand will stop at its current position.
6 or 7 days (function sleep) xAll hands stopped at 12 o’clock.
xOnly day indication operates normally.
xThe watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is already in a sleep
state when 6:00 AM arrives, however, it will remain in the sleep state.
xThe watch will not enter a sleep state while it is in the Stopwatch Mode, or while an elapsed time
operation is in progress in the Timekeeping Mode or the World Time Mode.
To recover from the sleep state
Move the watch to a well-lit area, perform a crown operation, or press any button.
E-13
Radio Controlled Atomic Timekeeping
This watch receives a time calibration signal and updates its time setting accordingly. However, when
using the watch outside of areas covered by time calibration signals, you will have to adjust the settings
manually as required. See “Configuring Current Time and Date Settings Manually” (page E-32) for more
information.
xTime calibration signal reception is enabled while the watch is in the Timekeeping Mode or World Time
Mode. In this manual, all examples show time calibration signal reception in the Timekeeping Mode.
The same procedures apply while the watch is in the World Time Mode.
xTime calibration reception is based on the applicable mode’s city setting. In the Timekeeping Mode,
the city setting is the Home City. In the World Time Mode, it is the World Time City (page E-28).
This section explains how the watch updates its time settings when the city setting is a city in Japan,
North America, Europe, or China, and is one that supports time calibration signal reception.
If the city setting is this: The watch can receive the signal from the transmitter
located here:
LONDON (LON), PARIS (PAR), ATHENS (ATH) Anthorn (England), Mainflingen (Germany)
HONG KONG (HKG) Shangqiu City (China)
TOKYO (TYO) Fukushima (Japan), Fukuoka/Saga (Japan)
NEW YORK (NYC), CHICAGO (CHI),
DENVER (DEN), LOS ANGELES (LAX),
ANCHORAGE (ANC), HONOLULU (HNL)
Fort Collins, Colorado (United States)
Important!
xThe areas covered by HONOLULU (HNL) and ANCHORAGE (ANC) are quite far from the calibration
signal transmitters, so certain conditions may cause reception problems.
E-14
Approximate Reception Ranges
Japanese Signals Chinese Signal
Fukushima
500 kilometers
1,000 kilometers
Fukuoka/Saga
1,500 kilometers
Changchun500 kilometers
Beijing
Shangqiu
Shanghai
Chengdu
Hong Kong
UK and German Signals North American Signal
Anthorn
500 kilometers
1,500 kilometers
Mainflingen
The Anthorn signal is receivable
within this area.
2,000 miles
(3,000 kilometers)
600 miles
(1,000 kilometers)
Fort Collins
E-15
xSignal reception may not be possible at the distances noted below during certain times of the year or
day. Radio interference may also cause problems with reception.
−Mainflingen (Germany) or Anthorn (England) transmitters: 500 kilometers (310 miles)
−Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)
−Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles)
−Shangqiu (China) transmitter: 500 kilometers (310 miles)
xAs of June 2013, China does not use Daylight Saving Time (DST). If China does go to the Daylight
Saving Time system in the future, some functions of this watch may no longer operate correctly for the
China time zones.
xUsing this watch in a country covered by a time calibration signal that is different from the countries it
supports may result in incorrect time indication due to local application of summer time, etc.

Operation Guide 5347 (OC)
E-16
To get ready for a receive operation
1. Enter the Timekeeping Mode (page E-24).
xYou could also enter the World Time Mode to perform this procedure.
Time calibration reception is based on the applicable mode’s city setting. In the Timekeeping Mode,
the city setting is the Home City. In the World Time Mode, it is the World Time City (page E-28).
2. Place the watch in a location where signal reception is good.
12 o’clock
or
xPosition the watch as shown in the nearby illustration,
with 12 o’clock pointed towards a window. Make sure
there are no metal objects nearby.
xSignal reception normally is better at night.
xThe receive operation takes from two to 10 minutes, but
in some cases it can take as long as 20 minutes. Take
care that you do not perform any button operation or
move the watch during this time.
E-17
xSignal reception may be difficult or even impossible under the conditions described below.
Inside or among
buildings
Inside a vehicle Near household
appliances,
office
equipment, or a
mobile phone
Near a
construction
site, airport, or
other sources of
electrical noise
Near high-
tension power
lines
Among
or behind
mountains
3. What you should do next depends on whether you are using Auto Receive or Manual Receive.
xAuto Receive: Leave the watch over night in the location you selected in step 2.
xManual Receive: Perform the operation under “To perform manual receive” on page E-18.
Important!
xWith Auto Receive, the watch performs the receive operation each day automatically up to six times
(up to five times for the Chinese calibration signal) between the hours of midnight and 5 a.m. When any
receive operation is successful, none of the other receive operations for that day are performed.
xCalibration signal reception is disabled in the following cases.
−In the Stopwatch Mode
−While an elapsed time operation is in progress in the Timekeeping Mode or World Time Mode
−While Auto Receive is turned off
−While the crown is pulled out
−While the battery charge is low
−While the watch is in function sleep
E-18
To perform manual receive
1. Enter the Timekeeping Mode (page E-24).
xYou could also enter the World Time Mode to perform this procedure.
Time calibration reception is based on the applicable mode’s city setting (page E-13). In the
Timekeeping Mode, the city setting is the Home City. In the World Time Mode, it is the World Time
City (page E-28).
2. Hold down Bfor at least two seconds.
xThe
2
Second Hand will first indicate A(a.m.) or P(p.m.), then move to
R(READY) to indicate that signal reception has started.
3. The
2
Second Hand indicates the operations the watch is currently
performing.
When the 2
2
Second Hand is
pointed here: It means this:
R (READY) Watch is setting up for reception.
W (WORK) Reception is in progress.
xIf signal reception is unstable, the 2
2
Second Hand may move between
W(WORK) and R(READY).
xThe watch’s time setting is adjusted automatically whenever a receive
operation is successful.


A (a.m.)
P (p.m.)
R (READY)
W (WORK)
E-19
Note
xCorrect indication will resume after the receive operation is complete. If you need to produce a correct
time reading immediately, press any button to stop the receive operation.
xIf reception fails for some reason, check the surrounding area and eliminate possible causes for failure
and then try again. See “To get ready for a receive operation” (page E-16).
To check the result of the latest receive operation
Important!
xPerform the operation below in the same mode (Timekeeping Mode or
World Time Mode) where the latest receive operation was performed.
Changing to another mode will cause the latest receive information to be
cleared.
1. Press B.
xThe
2
Second Hand will first indicate A(a.m.) or P(p.m.), and then move
to Y(YES) if the latest receive operation was successful, or N(NO) if it
was not.
2. After about ten seconds, regular timekeeping will resume. Before that, you
can press Bto return manually to the mode you started from (Timekeeping
or World Time) in step 1.
Note
xThe
2
Second Hand will indicate N(NO) if you have exited the mode
(Timekeeping Mode or World Time Mode) where the receive operation was
performed, or if you have adjusted the time or date setting manually since
the latest receive operation.
Y (YES)
N (NO)


E-20
To turn auto receive on and off
1. Enter the Timekeeping Mode (page E-24).
xYou could also enter the World Time Mode to perform this procedure.
Time calibration reception is based on the applicable mode’s city setting
(page E-13). In the Timekeeping Mode, the city setting is the Home City. In
the World Time Mode, it is the World Time City (page E-28).
2. Press B.
xThe
2
Second Hand will first indicate A(a.m.) or P(p.m.). Then it will
indicate the last reception result (Yor N) for about 10 seconds.
3. During the 10 seconds that the
2
Second Hand is pointing to the latest
receive operation result (see above), pull out the crown to the first click.
xThis will cause the
2
Second Hand to point to either Y(YES) or N(NO),
which indicates the current on/off setting.
xLeaving the crown pulled out for more than two minutes without
performing any operation will automatically cause crown operations to
become disabled. If this happens, press the crown back in, pull it out,
and then start the operation over again.
4. Rotate the crown to move the
2
Second Hand to the setting you want.
xTo turn on auto receive, select Y(YES).
xTo turn off auto receive, select N (NO).
5. Push the crown back in to return to the mode you started from (Timekeeping or World Time) in step 1.
Y (YES)
N (NO)


E-21
Radio-controlled Atomic Timekeeping Precautions
xStrong electrostatic charge can result in the wrong time setting.
xEven if a receive operation is successful, certain conditions can cause the time setting to be off by up
to one second.
xThe watch is designed to update the date and day of the week automatically for the period from
January 1, 2000 to December 31, 2099. Updating of the date by signal reception will no longer be
performed starting from January 1, 2100.
xIf you are in an area where signal reception is not possible, the watch keeps time with the precision
noted in “Specifications” (page E-49).
xThe receive operation is disabled under any of the following conditions.
−While power is at Level 2 or Level 3 (page E-10)
−While the watch is in the power recovery mode (page E-11)
−While the watch is in the sleep state (power saving, page E-12)
E-22
Mode Reference Guide
Your watch has three “modes”. The mode you should select depends on what you want to do.
Pull out the crown to the first click and then rotate it to navigate between modes.
In this mode: You can do this: More info:
Timekeeping
xView the current time in the Home City.
xUse the upper dial and the 2
2
Second Hand to measure elapsed
time (1/20 (0.05)-second timing for up to 60 minutes (five 12-minute
revolutions)).
xView the current time in the World Time City in the lower dial.
xConfigure Home City and summer time settings.
xPerform calibration signal Auto Receive and Manual Receive.
xEnable/disable Auto Receive.
xManually configure time and date settings
E-24
E-37
World Time
xView the current time in the World Time City.
xView the current time in the Home City in the upper dial.
xUse the lower dial and the 2
2
Second Hand to measure elapsed
time (1/20 (0.05)-second timing for up to 60 minutes (five 12-minute
revolutions)).
xConfigure World Time City and summer time settings.
xPerform calibration signal Auto Receive and Manual Receive.
xEnable/disable Auto Receive.
xManually configure time and date settings.
E-25
E-37
Stopwatch
xMeasure elapsed time (1/20 (0.05)-second timing for 60 minutes).
xView the current time in the World Time City in the upper dial.
xView the current time in the Home City in the lower dial.
E-36
E-23
Relationship between the Timekeeping Mode and World Time Mode
This section explains about the watch’s Timekeeping Mode and World Time Mode, and the Home City
and World Time City.
Timekeeping Mode The Timekeeping Mode is mainly used for viewing the current time in the Home
City.
World Time Mode The World Time Mode is mainly used for viewing the current time in the World
Time City.
Home City Specify the city where you normally will be using your watch. In Japan, the Home
City is Tokyo.
World Time City Specify another city anywhere around the globe.
xWhile the watch is in the Timekeeping Mode, time calibration signal reception is performed in
accordance with the Home City setting. When a time calibration signal is received and the time setting
is adjusted automatically while the watch is in the Timekeeping Mode, World Time Mode times are also
adjusted accordingly.
xWhen the watch is in the World Time Mode, time calibration signal reception is performed based on
the World Time City time. When a time calibration signal is received and the time setting is adjusted
automatically while the watch is in the World Time Mode, other World Time Mode times are also
adjusted accordingly.
xAdjusting the time setting manually while the watch is in the Timekeeping Mode will cause World Time
Mode times to be adjusted accordingly.
xAdjusting the time setting manually while the watch is in the World Time Mode will cause Timekeeping
Mode times to be adjusted accordingly.

Operation Guide 5347 (OC)
E-24
General Guide
Pull out the crown to the first click and then rotate it to navigate between modes. Push the crown back in
after entering the mode you want.
xPulling out the crown to the first click and then holding down Bfor at least two seconds will return
directly to the Timekeeping Mode.
Timekeeping Mode

xStart
xStop
xReset
Crown
Day Indicator
World Time Minute Hand
World Time Hour Hand
Minute Hand
Day of the Week
Hour Hand
Stopwatch
Second Hand
Stopwatch Minute Hand
(Up to 60 minutes: five
12-minute revolutions)
Second Hand
Abutton
xPress once to start an
elapsed time operation.
Bbutton
xPressing once while the
2
Second Hand is indicating
normal timekeeping will
cause the
2
Second Hand to
move to A(a.m.) or P(p.m.)
for about one second.
xAfter last signal receive result
is indicated (page E-19), the
2
Second Hand returns to
normal timekeeping.
Pull out the crown to the first click.
E-25
Stopwatch Mode

xStart
xStop
xReset
Crown
Minute HandHour Hand
Stopwatch Second Hand
Points to ST.
World Time Hour Hand
World Time Minute Hand
Stopwatch Minute Hand
(0 to 60 minutes)
Stopwatch 1/20 (0.05) Second Hand
World Time Mode

xStart
xStop
xReset
Crown
World Time Day
Indicator
World Time
Minute Hand
Stopwatch Minute Hand (Up to 60 minutes:
five 12-minute revolutions)
Stopwatch Second Hand
World Time
Second Hand
Points to WT.
World Time
Hour Hand
Hour Hand
Minute Hand Abutton
xPress once to start an elapsed time
operation.
Bbutton
xPressing once while the
2
Second
Hand is indicating normal
timekeeping will cause the
2
Second
Hand to move to A(a.m.) or P(p.m.)
for about one second.
xAfter last signal receive result is
indicated (page E-19), the
2
Second
Hand returns to normal timekeeping.
E-26
Using the Stopwatch
xPerform this operation in any mode.
AA A A B
Start Stop Resume Stop Reset
Note
xAs the
9
Day Indicator changes after you switch between the Timekeeping Mode and World Time
Mode, the
8
Mode Hand also rotates (page E-2).
xThe
9
Day Indicator changes gradually at midnight each day. It take anywhere from about 90 seconds
to three minutes for the day to change.
E-27
Watch Modes
Timekeeping Mode
(Crown pulled out to first click.)
World Time Mode Stopwatch Mode
In upper dial
In lower dial
In upper dial
In lower dial
In upper dial
In lower dial
xThe day of the week is indicated in the Timekeeping Mode. Pulling out the crown to the first click will
cause the Mode Hand to move to TM. The mode indicators to the left and right of the Mode Hand
indicate the upper and lower dial hand functions: ST (Stopwatch) for the upper dial and WT (World
Time) for the lower dial.
xIn the World Time Mode, the Mode Hand points to WT. The mode indicators to the left and right
indicate the upper and lower dial hand functions: TM (Timekeeping) for the upper dial and ST
(Stopwatch) for the lower dial.
xIn the Stopwatch Mode, the Mode Hand points to ST. The mode indicators to the left and right indicate
the upper and lower dial hand functions: WT (World Time) for the upper dial and TM (Timekeeping) for
the lower dial.
E-28
Selecting a City
Your watch lets you select from among city codes for 29 cities around the globe, plus one code for
UTC (Universal Coordinated Time). Selecting a city code causes the watch’s time setting to change
automatically to indicate the current time in that zone.
Important!
xYou can use the same steps to select a city code in the Timekeeping mode and the World Time Mode.
xIn the Timekeeping Mode, the city setting is the Home City, and in the World Time Mode, it is the World
Time City.
To select a city
Note
xThis watch does not have a city code that corresponds to
Newfoundland.
1. Pull out the crown to the second click.
xThis will cause the
2
Second Hand to move to the city code of
the currently selected city.
xThis indicates the city code setting mode.
xLeaving the crown pulled out for more than two minutes without
performing any operation will automatically cause crown
operations to become disabled. If this happens, press the
crown back in, pull it out, and then start the operation over
again.
xFor details about city codes, see the “City Code Table” at the
back of this manual.


Illustration shows Timekeeping Mode.
TYO (TOKYO)
E-29
2. Rotate the crown to move the
2
Second Hand to the city code
you want to select.
xEach time you select a city code, the
1
Hour Hand,
3
Minute
Hand,
8
Mode Hand, and
9
Day Indicator move to the current
time for that city code.
3. After the setting is way you want, push the crown back in.
xThe day of the week and day will also be displayed in
accordance with the selected city code.

 
 
E-30
STD/DST Switching
You can select summer time or standard time independently for each city. The initial default setting for all
cities is AT (AUTO).
Normally you should use the AT (AUTO) setting because it automatically switches between summer time
and standard time. You should change the setting to STD (standard time) or DST (summer time) in the
following cases.
−When using the watch in a city not included in the City Code Table
−When the switching dates in your location are different from those shown in the City Code Table
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from Standard Time.
Remember that not all countries or even local areas use Daylight Saving Time.
xNote that you cannot switch between STD (standard time) and DST (daylight saving time) while UTC*
is selected as the city code.
*Coordinated Universal Time, the world-wide scientific standard of timekeeping. The reference point for
UTC is Greenwich, England.
E-31
To switch between standard time and summer time manually
1. Pull the crown out to the second click.
xThe
2
Second Hand will move to the currently selected city code.
xLeaving the crown pulled out for more than two minutes without performing any operation will
automatically cause crown operations to become disabled. If this happens, press the crown back in,
pull it out, and then start the operation over again.
2. Press A.
xThe
2
Second Hand will move to the currently selected summer time setting (see table below).
xAfter about two seconds, the
2
Second Hand will return to the city code setting.
xBe sure to perform step 3 within two seconds after you press A(while the
2
Second Hand is
indicating the summer time setting).
AT (AUTO) The watch automatically switches between standard time and daylight saving time in
accordance with its calendar.
STD The watch always shows standard time.
DST The watch always shows daylight saving time.
3. Hold down Afor about one second to cycle through the summer time settings as shown below.
AA
AT (AUTO) STD DST
A
4. After the setting is way you want, push the crown back in.

Operation Guide 5347 (OC)
E-32
Configuring Current Time and Date Settings Manually
You can configure current time and date settings manually when the watch is unable to receive a time
calibration signal.
To change the current time and date setting manually
1. In the mode whose time and date setting you want to change
(Timekeeping Mode or World Time Mode), pull out the crown to
the second click.
xThis will cause the
2
Second Hand to move to the city code of
the currently selected city.
xLeaving the crown pulled out for more than approximately
30 minutes without performing any operation will automatically
cause crown operations to become disabled. If this happens,
press the crown back in, pull it out, and then start the operation
over again.


Illustration shows Timekeeping Mode.
TYO (TOKYO)
E-33
2. Change the city setting and summer time setting, if you want.
xTo change the city setting, perform step 2 under “To select a
city” (page E-28).
3. Hold down Bfor about one second. This will enter the time and
date setting mode.
xThe
2
Second Hand will move to A(a.m.) or P(p.m.).
xIn the following steps, each press of Bcycles between
settings as shown below.
(About 1 second)
City Minute Hour
Day
BYear
B
B
B
B
Month
B
4. Rotate the crown to adjust the minute setting.
xA high-speed movement feature (one full cycle maximum) is available when adjusting the hands.
See “Crown Operations” (page E-3).



E-34
5. Press B.
xThe
1
Hour Hand will move slightly left and right to indicate the hour and day setting mode.
6. Rotate the crown to adjust the hour setting.
xThe
2
Second Hand will move to A(a.m.) or P(p.m.).
xA high-speed movement feature (one full cycle maximum) is available when adjusting the hands.
See “Crown Operations” (page E-3).
7. Press B. This will enter the year setting mode.
xAfter the
2
Second Hand moves to the month, the
3
Minute Hand and
1
Hour Hand will move and
point to the year.
x
2
Second Hand: The month setting is configured in step 10, below.
8. Rotate the crown to adjust the year setting.

0
2
3
4
9
8
1
75
6
Setting the year (ones digit)

00
20
30
40
90
80
10
70 50
60
Setting the year (tens digit)
E-35
9. Press Bto enter the month setting mode.
xThe
2
Second Hand will perform one rotation and
stop at the current month setting.
10. Rotate the crown to adjust the month setting.
11. Press the B.
xThe
8
Mode Hand will move slightly, indicating
the day setting mode.
12. Rotate the crown to adjust the day setting.
xThe
8
Mode Hand will rotate along with the crown
rotation.
13. After the settings are the way you want, push the
crown back in to return to the mode you started
from in step 1.
xThis causes timekeeping to resume with the
2
Second Hand starting from 12 o’clock.
xThe day of the week indicated by the
8
Mode
Hand changes automatically in accordance with
the date (year, month, and day).
Note
xThe watch’s built-in full automatic calendar makes allowances for different month lengths and leap
years. Once you set the date, there should be no reason to change it except after you have the
watch’s rechargeable battery replaced or after power drops to Level 3.

Dec
Nov
Feb
Mar
Apr
Oct
Sep
Aug
Jan
Jul May
Jun
Setting the month
E-36
Using the Stopwatch
This watch can be used as a stopwatch.
xMeasurement is possible in the Stopwatch Mode, Timekeeping Mode, and World Time Mode.
xMeasurement is 1/20 (0.05) second units.
xMeasurement can be up to 59 minutes, 59.95 seconds (60 minutes total).
xElapsed time measurement stops when the maximum limit is reached.
xIn the Timekeeping Mode and World Time Mode, measured time display is up to 11 minutes,
59.95 seconds.
If measured time exceeds 11 minutes 59.95 seconds, switch to the Stopwatch Mode.
Stopwatch Mode
Example: When elapsed time is 20 minutes, 45.10 seconds
Hand Functions
1
1 Hour Hand: Indicates the stopwatch minute count
(1 revolution = 60 minutes).
2
2 Second Hand: Indicates the 1/20 (0.05)-second count during stopwatch
operation.
3
3 Minute Hand: Indicates the stopwatch seconds count.
8
8 Mode Hand: Points to ST.
xThe watch face is marked with 0.05-second markers.


 
E-37
Timekeeping Mode
Example: When elapsed time is 3 minutes, 45.10 seconds
Hand Functions
2
2 Second Hand: Indicates the 1/20 (0.05)-second count.
4
4 Upper Dial Big Hand: Indicates the 1-second count.
5
5 Upper Dial Small Hand: Indicates the 1-minute count (up to 60 minutes: five
12-minute revolutions).
8
8 Mode Hand: Points to the day of the week while elapsed time is in progress.
World Time Mode
Example: When elapsed time is 3 minutes, 45.10 seconds
Hand Functions
2
2 Second Hand: Indicates the 1/20 (0.05)-second count.
6
6 Lower Dial Big Hand: Indicates the 1-second count.
7
7 Lower Dial Small Hand: Indicates the 1-minute count (up to 60 minutes: five
12-minute revolutions).
8
8 Mode Hand: Points to WT while elapsed time is in progress.



  
E-38
To measure elapsed time
AA A A B
Start Stop Resume Stop Reset
xPressing Awithout resetting the stopwatch will resume the elapsed time operation from where it was
last stopped.
Note
xThe Stopwatch Mode can indicate elapsed time up to 59 minutes, 59.95 seconds. Elapsed time
measurement will stop automatically when the maximum time is reached.
xPressing Bwill not perform a reset operation while the hands are moving to elapsed timekeeping.
xIn the Stopwatch Mode, the
2
Second Hand indicates the 1/20 (0.05)-second count for the first
30 seconds of a stopwatch elapsed time operation. The
2
Second Hand will jump to the current value
whenever A(Stop) is pressed.
xIn the Timekeeping Mode and World Time Mode, the
2
Second Hand (1/20 (0.05) second) hand
returns to normal 1-second movement approximately 20 seconds after an elapsed time measurement
operation is started.
E-39
Adjusting the Hand and Day Home Positions
If the watch is exposed to strong magnetism or impact, it can cause its hands and/or the date to go out of
alignment. This can result in incorrect date and/or time indication even though a time calibration signal is
being received.
The watch automatically adjusts the
2
Second Hand,
3
Minute Hand, and
1
Hour Hand positions
periodically.
If you notice that the
4
Upper Dial Big Hand,
5
Upper Dial Small Hand,
6
Lower Dial Big Hand,
7
Lower Dial Small Hand,
8
Mode Hand, or
9
Day Indicator are not in the correct position, perform
manual adjustment.
Important!
xPerforming hand position correction in either the Timekeeping Mode or World Time Mode will correct
the hand positions in all modes.
xYou cannot correct the hand and day home positions while in the Stopwatch Mode.

Operation Guide 5347 (OC)
E-40
Hand/Day Adjustment Steps
For full details, see the procedure from page E-41 to E-43.
Pull crown out to second click.
2
Second Hand
3
Minute Hand
1
Hour Hand
4
Upper Dial Big Hand
5
Upper Dial Small Hand
8
Mode Hand
9
Day Indicator
B
B
B
B*
(Wait for at least six seconds until the
2
Second Hand moves to 12 o’clock.)
B
6
Lower Dial Big Hand
7
Lower Dial Small Hand
8
Mode Hand*
9
Day Indicator*
Auto Adjustment
Manual Adjustment
*Perform this operation only if you are unable to align the
8
Mode Hand and
9
Day Indicator using the
operation to the right.
xAfter completing adjustment, push the crown back in. Pushing the crown back in part way through
adjustment will return to the mode you started from, with any adjustments you made in effect.
E-41
To adjust the hand and day home positions
Important!
xYou do not need to perform the procedure in this section if the watch is indicating the time and/or day
correctly.
1. Pull the crown out to the second click.
2. Keep Bdepressed for more than six seconds. This will cause the
2
Second Hand moves to
12 o’clock.
xAfter about one second, the
2
Second Hand moves to A(a.m.) or P(p.m.). After about six seconds,
the
2
Second Hand moves to 12 o’clock.
xRelease Bafter the
2
Second Hand moves to 12 o’clock. At this time the watch will start automatic
adjustment of the
2
Second Hand,
3
Minute Hand, and
1
Hour Hand positions.
xAdjustment is complete when the
2
Second Hand,
3
Minute Hand, and
1
Hour Hand move to
12 o’clock.
3. Press B.
xThe
2
Second Hand,
3
Minute Hand, and
1
Hour Hand will
move to 2 o’clock.
xThe
4
Upper Dial Big Hand and
5
Upper Dial Small Hand will
move to 12 o’clock and stop there.
xIf the
4
Upper Dial Big Hand and
5
Upper Dial Small Hand
do not align with 12 o’clock, rotate the crown to adjust them
so they do.
xYou can use high-speed hand movement to perform this step.

 

E-42
4. Press B.
xThe
6
Lower Dial Big Hand and
7
Lower Dial Small Hand will
move to 12 o’clock and stop there.
xIf the
6
Lower Dial Big Hand and
7
Lower Dial Small Hand
do not align with 12 o’clock, rotate the crown to adjust them
so they do.
xYou can use high-speed hand movement to perform this step.
5. Press B.
xCheck if the
8
Mode Hand is stopped at 12 o’clock and the
9
Day Indicator indicates the day correctly.
xIf the position of the
8
Mode Hand and/or
9
Day Indicator
is not correct, rotate the crown to adjust the
8
Mode Hand to
12 o’clock and the
9
Day Indicator so the day is in the center
of indicator window.
xYou can use high-speed hand movement to perform this step.
xWhen you rotate the crown, there is a limit on the movement of
the
8
Mode Hand and
9
Day Indicator. The maximum range
of movement of the
8
Mode Hand is 180 degrees left and right.
The
9
Day Indicator can move just a little (page E-2).
xIf you successfully align the
8
Mode Hand and
9
Day
Indicator, advance to step 7. If you are unable to align the
8
Mode Hand and
9
Day Indicator, go to step 6.

 


 
Day Indicator during home position
adjustment
E-43
6. Press B.
xWait until the
8
Mode Hand stops at 12 o’clock and the
9
Day
Indicator stops at 1.
xThe
8
Mode Hand may continue to rotate for as long as
30 minutes until the
9
Day Indicator stops at 1 (page E-2).
xIf the
8
Mode Hand and/or
9
Day Indicator is not aligned
properly when they stop moving, rotate the crown to adjust
them so the
8
Mode Hand is at 12 o’clock and so 1 is in the
center of the
9
Day Indicator window.
xYou can use high-speed hand and day movement to perform
this step.
7. Push the crown back in.
This exits the adjustment mode and returns to normal timekeeping.
Important!
xLeaving the crown pulled out for more than approximately 30 minutes without performing any operation
will automatically cause the adjustment operation to become disabled. If this happens, push the crown
back in and then pull it out to restart the above procedure from the beginning.
Pushing the crown in will return to the mode you started from in step 1 with the hands and/or day in
their newly adjusted positions.


 
E-44
Troubleshooting
Hand Movement and Position
■I lost track of what mode the watch is in.
Refer to “Mode Reference Guide” (page E-22). To return directly to the Timekeeping Mode, pull out the crown
to the first click hold down Bfor at least two seconds. To return to the Timekeeping Mode, push the
crown back in.
■The
2
Second Hand is moving at two-second intervals.
Power may be low. Expose the watch to light until the
2
Second Hand starts moving normally, at one-
second intervals (page E-10).
■The hands of the watch suddenly start moving at high speed, even when I do not perform any
operation.
This could be due to any one of the following causes. In all cases, the hand movement does not indicate
malfunction, and should stop shortly.
xThe watch is recovering from a sleep state (page E-12).
xThe time setting is being adjusted following a successful auto time calibration signal receive operation
(page E-13).
■Hands suddenly stop moving. Button operation also is disabled.
The watch may be in the power recovery mode (page E-11). Do not perform any operation until the hands
return to their normal positions (in about 15 minutes). The hands should return to their correct positions when
normal operation returns. To help power recover, leave the watch in a location where it is exposed to light.
■All hands are at 12 o’clock and nothing happens when I press any button.
The rechargeable battery is dead. Expose the watch to light to charge the battery and restore normal
operation.
E-45
■The current time setting is off by hours.
xYour city setting may be wrong. Check your city setting and correct it, if necessary (page E-28).
■The current time setting is off by one hour.
xIf you are using the watch in an area where time calibration signal reception is possible, see “To select
a city” (page E-28).
xThe period when summer time is applied in the location where you are using the watch may be
different from the period set for your currently selected city. Use the procedure under “To switch
between standard time and summer time manually” (page E-31) to switch from AT (AUTO) to STD (for
standard time) or DST (for summer time).
■The hands and/or day indications are off.
This could indicate that the watch has been exposed to magnetism or strong impact, which has caused
problems with proper hand and day alignment. Adjust the watch’s hand and day home position alignment
(page E-39).
■Data indication is correct, but it is not in the middle of the day indicator.
The date is in the process of changing. For information about how the date changes, see page E-2.
Charging
■The watch does not resume operation after I expose it to light.
It can take quite a long time to charge the battery after the power level drops to Level 3 (page E-10). Continue
exposing the watch to light until the
2
Second Hand starts moving normally (at one-second intervals).
E-46
Time Calibration Signal
The information in this section applies only when LONDON (LON), PARIS (PAR), ATHENS (ATH),
HONOLULU (HNL), ANCHORAGE (ANC), LOS ANGELES (LAX), DENVER (DEN), CHICAGO (CHI),
NEW YORK (NYC), HONG KONG (HKG), or TOKYO (TYO) is selected as the city. You need to adjust
the current time manually when any other city is selected.
■The
2
Second Hand indicates N (NO) when I check the result of the latest receive operation.
Possible Cause Remedy Page
xYou are wearing or moving the watch, or
performing a button operation during the signal
receive operation.
xThe watch is in an area with poor reception
conditions.
Keep the watch in an area where reception
conditions are good while the signal receive
operation is being performed.
E-16
You are in an area where signal reception is not
possible for some reason. See “Approximate Reception Ranges”. E-14
The calibration signal is not being transmitted for
some reason.
xCheck the website of the organization that
maintains the time calibration signal in your area
for information about its down times.
xTry again later.
—
■The current time setting changes after I set it manually.
You may have the watch configured for Auto Receive of the time calibration signal (page E-17), which will
cause the time to be adjusted automatically according to your currently selected city. If this results in the
wrong time setting, check your city setting and correct it, if necessary (page E-28).
E-47
■Auto Receive is not performed or I cannot perform Manual Receive.
Possible Cause Remedy Page
Your city setting is wrong. Check your city setting and correct it, if necessary. E-13
E-28
Auto Receive is disabled because there is an
ongoing elapsed time operation. Stop the ongoing stopwatch operation. E-36
The watch is in the Stopwatch Mode.
Change to the Timekeeping Mode. If you want to
perform signal reception in the World Time Mode,
enter the World Time Mode.
E-24
The Auto Receive function is turned off. Turn on Auto Receive. E-20
The crown is pulled out. Push the crown back in. E-3
There is not enough power for signal reception. Expose the watch to light to charge it. E-9
■Signal reception is being performed successfully, but the time and/or day is wrong.
Possible Cause Remedy Page
Your city setting is wrong. Check your city setting and correct it, if necessary. E-13
E-28
The watch may have been exposed to magnetism
or strong impact, which has caused problems with
proper hand and day alignment.
Adjust the watch’s hand and day home positions. E-39

Operation Guide 5347 (OC)
L-2
City Code Table
City Code City
UTC Offset/
GMT Differential
Summer Time Period
Summer Time Start Summer Time End
PAGO PAGO (PPG) Pago Pago –11 None None
HONOLULU (HNL) Honolulu –10
ANCHORAGE (ANC) Anchorage –9
02:00, second Sunday
in March
02:00, first Sunday in
November
LOS ANGELES (LAX) Los Angeles –8
DENVER (DEN) Denver –7
CHICAGO (CHI) Chicago –6
NEW YORK (NYC) New York –5
SANTIAGO (SCL) Santiago –4 24:00, second Saturday in
October
24:00, second Saturday
in March
RIO Rio De Janeiro –3 0:00, third Sunday in
October
0:00, third Sunday in
February or 0:00, fourth
Sunday in February
F. DE NORONHA (FEN) Fernando de Noronha –2
None NonePRAIA (RAI) Praia –1
UTC
0
LONDON (LON) London 01:00, last Sunday in
March
02:00, last Sunday in
October
PARIS (PAR) Paris +1 02:00, last Sunday in
March
03:00, last Sunday in
October
ATHENS (ATH) Athens +2 03:00, last Sunday in
March
04:00, last Sunday in
October
JEDDAH (JED) Jeddah +3 None None
TEHRAN (THR) Tehran +3.5 0:00, March 22 or
0:00, March 21
0:00, September 22 or
0:00, September 21
E-48
Crown Operation
■Nothing happens when I rotate the crown.
Possible Cause Remedy Page
The crown has been left pulled out for more than
two minutes (30 minutes in the case of hand home
position adjustment) without any operation being
performed.
Push the crown back in and then pull it out again to
restore normal operation. E-3
E-49
Specifications
Accuracy at normal temperature: ±15 seconds a month (with no signal calibration)
Timekeeping : Hour, minutes, seconds, a.m./p.m. indication, day, day of the week
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Other: Home City and World Time City can be assigned one of 29 city codes (29 time zones) and
Coordinated Universal Time; Daylight Saving Time (summer time)/Standard Time auto switching
Time Calibration Signal Reception: Auto receive up to six times a day (5 times a day for the Chinese
calibration signal; Remaining auto receives cancelled as soon as one is successful);
Manual receive
Receivable Time Calibration Signals:
Mainflingen, Germany (Call Sign: DCF77, Frequency: 77.5 kHz); Anthorn, England (Call
Sign: MSF, Frequency: 60.0 kHz); Fukushima, Japan (Call Sign: JJY, Frequency: 40.0
kHz); Fukuoka/Saga, Japan (Call Sign: JJY, Frequency: 60.0 kHz); Fort Collins, Colorado,
the United States (Call Sign: WWVB, Frequency: 60.0 kHz); Shangqiu City, Henan
Province, China (Call Sign: BPC, Frequency: 68.5 kHz)
Stopwatch: Measuring capacity: 59'59.95"
Measuring unit: 1/20 (0.05) seconds
Measuring modes: Elapsed time
Other: Power Saving; Low battery alert; Auto Correction of Hand Home Positions
Power Supply: Solar panel and one rechargeable battery
Approximate battery operating time: 5 months (no exposure to light after a full charge; one signal
reception of approximately 4 minutes per day)
L-1
City Code Table
L-3
City Code City
UTC Offset/
GMT Differential
Summer Time Period
Summer Time Start Summer Time End
DUBAI (DXB) Dubai +4
None None
KABUL (KBL) Kabul +4.5
KARACHI (KHI) Karachi +5
DELHI (DEL) Delhi +5.5
DHAKA (DAC) Dhaka +6
YANGON (RGN) Yangon +6.5
BANGKOK (BKK) Bangkok +7
HONG KONG (HKG) Hong Kong +8
TOKYO (TYO) Tokyo +9
ADELAIDE (ADL) Adelaide +9.5 02:00, first Sunday in
October 03:00, first Sunday in April
SYDNEY (SYD) Sydney +10
NOUMEA (NOU) Noumea +11 None None
WELLINGTON (WLG) Wellington +12 02:00, last Sunday in
September 03:00, first Sunday in April
xBased on data as of June 2013.
xThe rules governing global times (UTC offset and GMT differential) and summer time are determined
by each individual country.
xThe summer time periods in this table are applicable to specific cities. For cities not included in the
list, select the list city that is in the same time zone as the desired city and perform STD/DST settings
manually.
