Casio QW-3329 User manual

Operation Guide 3329
1
MA0406-EA
Each press of the CC
CC
Cbutton sounds a confirmation tone and cycles through available modes in the sequence shown below.
•The display will automatically revert to the Timekeeping screen if you leave the Battery Level, Alarm, or Hand Setting screen displayed
without performing any operation for about two or three minutes.
Timekeeping Mode
Seconds ScreenCurrent Time Screen
Hand Setting Mode
(Light)(Screen Switching)
(Mode switching)
Month.
Day Day of
the Week
Seconds
Hour
PM indicator
(no indicator for AM)
Minutes
Calendar Screen
2-second
interval
Mode
Indicator
Changing Display Screen Contents
Each press of the button cycles digital display contents in
the following sequence: Calendar Screen \Seconds Screen
\Current Time Screen.
Days of the Week
SUN: Sunday MON: Monday TUE: Tuesday
WED: Wednesday THU: Thursday FR I : Friday
SAT: Saturday
Button Button
Button Button
Battery Level Screen World Time Mode
Stopwatch Mode Alarm Mode
Level Indicator Current Time
in Selected
City
City Code
Alarm
• Alarm off
Hourly Time Signal
• Hourly Time Signal off
Elapsed Time
Mode Indicator
Modes and Display Screens
The power supply of this watch uses a solar cell to generate
electrical power, which is stored by a rechargeable battery. Using
or storing the watch where it is not regularly exposed to light, or
allowing it to be blocked from light by your sleeve for long periods
as you are wearing it can cause the power of the rechargeable
battery to run down. To ensure stable operation, be sure to allow
the watch to be exposed to light as much as possible when you
are wearing or storing it.
Important!
Note that all data in memory and all settings are cleared whenever
you allow the level of the rechargeable battery to drop to Level 4.
❚ Checking the Battery Level
Use the Battery Level Screen to check the current level of the
watch’s rechargeable battery.
•In the Timekeeping Mode, press the Cbutton once to change to
the Battery Level Screen.
Level Indicator
Battery Level Screen
Timekeeping Mode
Normal operation enabled.
Normal operation enabled.
Level 1
Level 2
Level 3
Level 4 All functions, including timekeeping,
disabled.
Signal reception, tones (alarms, hourly time
signal), face illumination, digital display, and
analog timekeeping disabled.
•Exposing the watch to direct sunlight or other strong light may
cause the battery level indicator to momentarily indicate a level
that is higher than the actual battery level. Because of this, you
should wait for a short while after charging to check the battery
level indicator.
•When the battery level approaches Level 3, the digital display will
start to flash and the analog hands will move to the 12 o’clock
position.
•Even after the battery drops to Level 4, you will be able to resume
normal operation by charging the battery.
•When charging from Level 4, the digital display will start operating
when the battery reaches Level 3. At this time, you will be able to
configure digital time and date settings only. The analog hands will
start to operate when the battery reaches Level 2. At that time,
adjust the analog hand setting so it matches the digital time.
•When charging the battery, keep the watch exposed to light until
the battery reaches Level 2 or Level 1.
❚ Start charging at Level 3!
Battery Level 3 indicates that remaining battery power is very low.
Be sure to expose the watch to light for recharging as soon as
possible after the Level 3 indicator starts to flash.
❚ Flashing Recover Indicator
If you use the light or alarms a number of times during a short
period, a recover (R) indicator flashes on the display and the
following operations become disabled as battery power recovers.
•Face illumination,
•Alarm and hourly time signal
•Analog timekeeping
•Time calibration signal reception
Normal operation will return after the
battery recovers.
•If the battery drops to Level 3 while the recover indicator is flashing
on the display, the Battery Level Screen will show “ ”.
❚ Charging Precautions
Avoid charging the watch in the following locations, and anywhere
else where the watch may become very hot.
•On the dashboard of an automobile parked in the sun
•Very close to an incandescent light source or other sources of
heat
•In a location exposed to direct sunlight for long periods
Note that the display panel may become black under very high
temperatures. This is temporary, and the display will appear
normal again at lower temperatures.
Depending on the light source you are using, the case
of the watch may become quite hot during charging.
Take care to guard against burn injury after charging.
❚ To charge the battery
Point the solar panel (face) of the watch at a light source.
•Remember that even a partial blockage of the solar cell reduces
charging efficiency.
Example: Positioning the watch
Solar Cell
•The illustration shows the resin band model.
Recover (R) Indicator
Power Supply

Operation Guide 3329
2
❚ Charging Guide
Starting from a full charge, the watch
should be able to continue operating
for about nine months without further
charging under the conditions
described below.
Daily Use (All time values are
approximate.)
•Face Illumination:
1.5 seconds
•Alarms: 10 seconds
•Signal reception: 4 times
Making sure the watch is regularly
exposed to light ensures stable
operation.
•Charge Times Required to Advance to a Higher Level
Exposure Level
(Brightness)
Outdoor Sunlight
(50,000 lux)
Sunlight Through a
Window (10,000 lux)
Daylight Through a
Window on an Overcast
Day (5,000 lux)
Indoor Fluorescent
Lighting (500 lux)
Approximate Exposure Time
Level 4 \ Level 3 \ Level 2 \ Level 1
– – – – – –
3 hours 12 hours42 hours
7 hours
11 hours
124 hours
44 hours159 hours
71 hours257 hours
•Note that the above charging times are for reference only. Actual
charging time depends on a variety of environmental factors.
Exposure Level
(Brightness)
Outdoor Sunlight
(50,000 lux)
Sunlight Through a
Window (10,000 lux)
Daylight Through a
Window on an Overcast
Day (5,000 lux)
Indoor Fluorescent
Lighting (500 lux)
Approximate
Exposure
Time
8 minutes
30 minutes
48 minutes
8 hours
Required Daily Charging Time
• The following is the daily amount of
charging required each day to support
the operations under “Daily Use”.
Power Saving causes the watch to automatically enter a sleep state and save power whenever the watch is left in the dark. The Power
Saving feature of the watch is turned on at the factory.
•Note that the watch may also enter the sleep state if the watch is blocked from light by your sleeve.
❚ How the sleep state works
Display sleep state
The display sleep state is triggered whenever the watch is left in the
dark for about one hour between the times of 10:00 p.m. and 6:00 a.m.
•The display sleep state causes the display to go blank, except for
a flashing Power Saving indicator. Alarms and the hourly time
signal continue to operate normally while the watch is in the
display sleep state. Even when the watch is in the display sleep
state, digital-analog time coordination and auto signal receive are
both performed.
• The watch will not enter the sleep state if it is in the Stopwatch Mode.
Function sleep state
The function sleep state is triggered whenever the watch is left in
the dark for six or seven days.
•Alarms and the hourly time signal are disabled while the watch is
in the function sleep state. In the function sleep state, the analog
hands remain stopped at the 12 o’clock position, and auto signal
receive is not performed.
•Digital timekeeping functions continue to operate normally in the
function sleep state.
Power Saving
Indicator
❚ To recover from the sleep state
Move the watch to a brightly lit location or press any button. The
watch will also recover from the sleep state if you angle it towards
your eyes for reading (see “To illuminate the face with the auto
light switch”).
•It can take up to two seconds before display figures re-appear
after you place the watch in a well-lit area.
❚ To turn Power Saving on and off
Use the procedure under “To configure home time settings” to turn
Power Saving on or off.
Leaving the watch in a drawer or anywhere else it is dark can
cause Power Saving to trigger in order to conserve battery
power.
Power Saving
An LED light is used to illuminate the face of the watch for easy
reading in the dark. An auto light switch automatically illuminates
the face when you angle the watch towards your eyes for reading.
❚ To illuminate the face manually
Press the BB
BB
Bbutton in any
mode to illuminate the face of
the watch.
•You can use the procedure under
“Specifying the Illumination
Duration” to configure the
illumination duration as
approximately 1.5 seconds or 3
seconds.
•Pressing the Bbutton illuminates the face regardless of whether
the auto light switch is on or off.
You may hear a faint rattling sound when you move the watch
around. This sound is caused by the movement of a metal
bulb that controls operation of the auto light switch, and does
not indicate malfunction.
❚ To illuminate the face with the auto light
switch
The auto light switch automatically illuminates the face
whenever you angle the watch towards your eyes for reading,
but only when it is dark.
•The auto light switch does not illuminate the face when
surrounding light is bright.
You can use the procedure under “Specifying the Illumination
Duration” to configure the illumination duration as
approximately 1.5 seconds or 3 seconds.
❚ To turn the auto light switch on and off
While a setting screen (one on which a setting is flashing) is on the
digital display, hold down the Bbutton for about two seconds to
toggle the auto light switch on (auto light switch on indicator
displayed) and off (no indicator displayed).
Auto Light Switch
On Indicator
❚ Positioning Your Arm Correctly
•You should be wearing the watch on the outside of your wrist
when using the auto light switch.
•Make sure that the left (9 o’clock) and
right (3 o’clock) sides of the watch are
within ±15 degrees of being parallel
with the ground. The auto light switch
may not operate properly if the angle is
greater.
Important!
•The light may be difficult to see if you turn it on under bright
sunlight.
•If you press the Bbutton or if an alarm operation starts while the
face is illuminated, illumination will turn off.
Auto Light Precautions
•Frequent use of the auto light can run down the battery.
•The auto light switch may cause the face to illuminate when your
sleeve covers the display of the watch.
•The face may not illuminate immediately when you angle the
watch towards your face. This does not indicate malfunction.
•The face remains illuminated for the currently set duration (1.5 or
3 seconds) only, even if you leave the watch angled towards your
face.
•The auto light switch is automatically disabled whenever battery
power is at Level 3 or lower.
•The face may illuminate unintentionally when you wear the watch
on the inside of your wrist, when you shake your arm, or when
you raise your arm. Be sure to turn off the auto light switch
whenever you do not need illumination.
•Keep the auto light switch turned off whenever you are wearing
the watch on the inside of your wrist.
•Electro-static charge and magnetism can interfere with auto light
operation and even make operation impossible. If this happens
lower your arm to the starting position and then raise it again. If
you still have trouble with illumination, try lowering your arm down
to your side and then raise it to your face for reading.
•The auto light switch is automatically disabled when the watch is
in the Hand Setting Mode.
Rotate your arm so the watch
is angled at about 40 degrees,
so you can read its face.
With the watch on
your wrist, position it
level with the ground.
11
11
122
22
2
At least
40
degrees
Face Illumination

Operation Guide 3329
3
Location
Reception is difficult and may even be impossible in the locations
described below. Avoid such locations when performing signal
reception.
•You should think of your watch operating like a radio or TV when it
is receiving the calibration signal.
If you are experiencing problems with reception, move away
from the types of locations described above to a location with
better reception, and try again.
Specifying the Illumination Duration
1. In the Timekeeping Mode,
hold down AA
AA
Afor about
two seconds.
•This will cause your city code
to flash in digital display.
2. Press the CC
CC
Cbutton three
times to display the
flashing seconds count.
3. Press the BB
BB
Bbutton to
toggle the illumination
duration between about
1.5 seconds ( indicator)
and 3 seconds
( indicator).
4. After the setting is the way you want, press the AA
AA
A
button to exit the setting screen.
•The watch will also exit the setting screen automatically if you
do not perform any operation for about two or three minutes.
City Code
(3 times) Seconds
What is a radio-controlled watch?
Your radio-controlled watch is designed to receive a time
calibration signal that contains standard time data, and adjust its
current time setting accordingly.
Signal data
Cesium
atomic clock
Transmitter
Internally
Decode
Watch
Time data
Signal is received
using built-in antenna.
Long-
wave time
calibration
signal
Watch decodes
received data and
converts it to time
data.
Time is adjusted
according to time
data.
After the watch receives the Standard Time signal, it performs
internal calculations to determine the current time. Because of
this, there may be an error of up to one second in the
displayed time.
Calibration Signal
•The Japanese calibration signal (Call Sign: JJY) is maintained by
the National Institute of Information and Communications
Technology (NICT). It is a long wave signal transmitted 24 hours a
day from the Mt. Otakadoya transmitter (40kHz) located in
Tamura-gun, Fukushima Prefecture, and from the Mt. Hagane
transmitter (60kHz) located on the border between Saga
Prefecture and Fukuoka Prefecture.
•The U.S. calibration signal (Call Sign: WWVB) is transmitted by
the National Institute of Standards and technology from Fort
Collins, Colorado.
Note that transmission of the standard wave may be
interrupted occasionally due to maintenance, lightening, etc.
How a Radio-controlled Watch Works
Reception Range
This watch is designed to receive the standard time calibration signal of Japan (JJY) or of the United States (WWVB). The signal that is
received depends on the current Home City setting.
•For information about selecting a Home City, see “Configuring Home TIme Settings”. For information about city codes, see the “World Time
City Code List”.
Home City
TYO
LAX, DEN, CHI, NYC
Transmitter
Either the Mt. Otakadoya signal (40kHz) or the Mt. Hagane signal (60kHz)
Fort Collins, Colorado signal
1000km
Mt. Hagane
(60kHz)
Mt. Otakadoya
(40kHz)
500km
1000km
500km
Japan Transmitter
Locations
•Under optimum conditions, the calibration signal should be
receivable up to 1,000 kilometers from the transmitter. Note
that the wave is relatively weak at distances greater than
500km, so reception may be poor at long distances.
U.S. Transmitter
Location
3000km
1000km
Fort Collins
•Under optimum conditions, the calibration signal should be
receivable up to 3,000 kilometers from the transmitter. Note
that the wave is relatively weak at distances greater than
1,000km, so reception may be poor at long distances.
•Geographic contours, nearby buildings, seasonal conditions, the time of day, can even make reception impossible even when you are within
range of the transmitter.
•Best reception is possible late at night.
Near high-voltage lines
Among or near buildings
Receiving the Calibration Signal
There are two methods you can use to receive the time calibration signal.
•Auto receive (Reception is performed automatically at
midnight, 1:00, 2:00, 3:00 and 4:00 each morning.)
•Manual receive (You initiate reception using a button
operation.)
•If reception is not successful for any of the normal auto receive
operations shown above, auto receive is performed one more
time at 5:00 a.m.
•The watch is set up for auto receive at the factory, so all you need to
do is to place it in a location that allows good reception each night.
❚ To position the watch for optimum reception
Remove the watch from your wrist and place it somewhere so its
top (12 o’clock side, where the antenna is located) is facing
approximately in the direction of the signal transmitter. Keep the
watch away from metal objects.
Resin band
Metal band
•Orienting the watch so it is sideways to the transmitter makes it
more difficult to receive the signal.
•Do not move the watch while it is receiving the calibration signal.
Near mountains
Inside a vehicle (automobile,
train, plane, etc.)
In a location where there is
radio interference
(construction site, airport, etc.)
Next to a household appliance or
office equipment (TV, speaker,
fax, computer, cell phone, etc.)

Operation Guide 3329
4
❚ Time Required for Reception
A calibration signal receive operation takes anywhere from about
two to six minutes.
•Note that when “AUTO” (Auto Select) is specified as the
transmitter selection mode, signal reception can take up to 12
minutes.
•See “Configuring Auto Receive Settings” for more information.
❚ To perform manual receive
In the Timekeeping Mode, hold
down the DD
DD
Dbutton for about
two seconds.
•The watch will beep and reception
will start. An indicator will appear
on the display to indicate reception
conditions.
❚ To interrupt reception
Press the DD
DD
Dbutton.
•All other buttons besides Dare disabled during signal reception.
When reception is successful
The watch terminates reception and adjusts the current time. Next
it beeps and then displays the date and time that the adjustment
was performed.
Reception Error (ERR Indicator)
The watch does not adjust its current time setting, and displays
“ERR” when signal reception is unsuccessful for some reason.
•The watch will return to the Timekeeping Mode automatically if
you do not perform any operation for about one or two minutes.
❚ Receive Indicator
The receive indicator cycles from
“Unstable” through “Stable” as
shown below while reception is in
progress. How far it cycles depends
on the signal strength. Keep the
watch in a location where reception
is stable while reception is in
progress.
Unstable Stable
•Even under optimum reception conditions, it can take about 10
seconds for reception to stabilize.
•Use the receive indicator to check reception status and to
determine the best location for signal reception.
•Note that weather, the time of day, surroundings, and other
factors can all affect reception.
Receive Indicator
Configuring Auto Receive Settings
Use the procedure below to turn auto receive of the time
calibration signal on or off. When TYO (Tokyo) is selected as your
Home City, you can also specify the transmitter selection mode,
which controls which Japanese transmitter signal should be used
for time calibration.
•For information about selecting your Home City, see “Configuring
Home Time Settings”.
•The initial factory default settings for auto receive are Home City =
TYO (Tokyo); Auto Receive = On; Transmitter = AUTO.
•The following procedure can be performed only when TYO, LAX,
DEN, CHI, or NYC is selected as the Home City.
❚ To configure auto receive settings
1. In the Timekeeping Mode,
press the DD
DD
Dbutton.
•This causes the display to
start cycling through the last
reception date and time
screens.
•The watch will return to the Timekeeping Mode automatically if
you do not perform any operation for about one or two
minutes.
2. Hold down the AA
AA
Abutton
for about two seconds.
•This will cause the currently
auto receive setting to flash
on the display.
❚ To view the last reception date and time
In the Timekeeping Mode, press the DD
DD
Dbutton.
•This causes the display to start cycling through the “ ” screen,
date screen, and time screen at two-second intervals.
•To return to the Timekeeping Mode, press the Dbutton again.
•The watch will return to the Timekeeping Mode automatically if you
do not perform any operation for about one or two minutes.
Last Reception Date
Last Reception Time
Auto Receive Settings when the Home City is TYO
• AUTO
Auto receive turned on with automatic selection of either the
Mt. Otakadoya signal (40kHz) or the Mt. Hagane signal
(60kHz), whichever is strongest.
• 40
Auto receive turned on for the Mt. Otakadoya signal (40kHz).
• 60
Auto receive turned on for the Mt. Hagane signal (60kHz).
• OFF
Auto receive turned off.
Auto Receive Settings when the Home City is NYC,
CHI, DEN, or LAX
• ON
Auto receive turned on for the Ft. Collins, Colorado signal.
• OFF
Auto receive turned off.
3. Press the DD
DD
Dbutton to
cycle through the
available auto receive
settings.
4. When the setting is the
way you want, press the
AA
AA
Abutton.
•This will exit the setting
screen and return to the last
reception date and time
screens.
•To return to the Timekeeping
Mode, press the Dbutton
again.
•The watch will return to the
Timekeeping Mode
automatically if you do not
perform any operation for
about one or two minutes.
Calibration Signal Reception
Precautions
•Auto reception can be performed while the watch is in the
Timekeeping Mode or World Time Mode only.
•When a time calibration signal is received, the watch corrects its
digital time setting first, and then adjusts the analog time setting
accordingly. In order to ensure that the analog time matches the
digital time, make sure you adjust the analog time to match the
digital time before signal reception is performed.
•Pressing any button while auto reception is in progress will cause
the watch to beep and then exit the receive operation.
•Make sure you are within the range of the calibration signal
transmitter before performing the reception operation. Remember
that geographic contours, nearby buildings, seasonal conditions,
the time of day, can even make reception impossible even when
you are within range of the transmitter.
•Proper reception may be impossible if there is something blocking
the signal. If reception is unsuccessful, try again.
•This watch is designed to adjust its current time setting in
accordance with the calibration signal transmitted in Japan and
the United States only. It operates like a standard (non-radio
controlled) watch outside of the range of the receivable time
calibration signal transmitters.
•When the watch is unable to adjust its time signal using the
calibration signal for some reason, timekeeping accuracy is within
±15 seconds per month.
•Strong electrostatic charge can cause timekeeping error.
•Signal reception is cancelled if an alarm starts to sound while it is
being performed.
•The watch’s calendar shows dates up to the year 2099.
Attempting a receive operation after that causes an error.

Operation Guide 3329
5
Troubleshooting
The watch cannot receive the time calibration signal.
•Is the signal being transmitted?
Though the Japanese calibration signal (Call Sign: JJY) is
continually transmitted by the National Institute of Information and
Communications Technology (NICT) in theory, it may sometimes
be interrupted for periodic maintenance work, or because of
lightening or other problems.
•Are you within the reception range of a transmitter?
See “Reception Range” for information about areas where the
watch can receive the signal.
•Is there something in the immediate area that may be interfering
with reception?
Even if you are within the reception range of a transmitter, objects
between you and the transmitter or electrical noise can interfere
with reception. Avoid such areas during signal reception. See
“Location” for more information.
•Do you have the correct Home City code selected?
Remember that auto receive is not performed unless TYO
(Japan), NYC (New York), CHI (Chicago), DEN (Denver), or LAX
(Los Angeles) is selected as the Home City. Select the correct
Home City code using the procedure under “To configure home
time settings”.
•Is auto receive turned off (OFF)?
Use the procedure under “Configuring Auto Receive Settings” to
turn on auto receive.
•Is the watch in any mode other than the Timekeeping Mode or
World Time Mode during the auto receive times (midnight, 1:00
a.m., 2:00 a.m., 3:00 a.m., 4:00 a.m., and 5:00 a.m.)?
Auto receive is performed only when the watch is in the
Timekeeping Mode or World Time Mode. It is not performed if the
watch is in any other mode.
Time calibration signal reception is successful, but the hourly
time signal and current time are slightly off.
•After the watch receives the time calibration signal, it performs an
internal decoding process before updating its time setting.
Because of this, the time setting may be slightly off (within one
second).
Time calibration signal reception is successful, but the current
time is one hour fast.
•Do you have summer time (DST) turned on (ON)?
Use the procedure under “To configure home time settings” to turn
off summer time.
Time calibration signal reception is successful, but the current
time setting is wrong.
•Is the correct city code selected for your Home City?
If you are in Japan, you should have TYO selected for your Home
City. For other areas, select the correct Home City code using the
procedure under “To configure home time settings”.
World time lets you display the current time in any one of 30 cities
(29 time zones) around the world.
•When you enter the World Time Mode, the screen for the city that
was displayed when you last exited the mode appears first.
•The seconds count in the World Time Mode is linked with the
Timekeeping Mode seconds count.
•The same 12-hour/24-hour format you select for the Timekeeping
Mode time is also applied in the World Time Mode.
Important!
If the World Time Mode time is incorrect, correct the setting of the
current time in the Timekeeping Mode.
•For information about selecting a Home City, see “To configure
home time settings”.
❚ To search for a city code
In the World Time Mode, press the DD
DD
Dbutton.
•This scrolls westward through the available city codes. A short
while after a city code appears, the display will change to show
the current time in that city.
•Holding down the Dbutton scrolls at high speed.
(Scrolls Forward)
City Code
Current Time in Selected City
•Pressing the Abutton in the World Time Mode displays the city
code of the currently selected city for about two seconds.
•If a time zone does not have a city code assigned to it, the GMT
differential appears instead.
World Time Mode Using Summer Time (DST)
Summer time, or Daylight Saving Time (DST) as is it is known in
some countries, calls for setting clocks ahead one hour during the
summer season. Note that the use of summer time depends on
the country and even the local area.
❚ To turn summer time on or off
1. In the World Time Mode,
use the DD
DD
Dbutton to
display the screen for the
city code whose summer
time setting you want to
change.
2. Hold down the AA
AA
Abutton
for about two seconds.
•This toggles summer time on
and off.
•The “DST” indicator appears
on the display and
timekeeping is advanced by
one hour when summer time
is turned on.
•You can turn summer time on
or off independently for each
World Time Mode city. Note,
however, that you cannot turn
on summer time for the “GMT”
city code.
World Time City Code List
City
Code City Name
– – –
HNL
ANC
LAX
DEN
CHI
NYC
CCS
RIO
– – –
– – –
GMT
LON
PAR
BER
ATH
CAI
Honolulu
Anchorage
Los Angeles
Denver
Chicago
New York
Caracas
Rio de Janeiro
Greenwich Mean Time
London
Paris
Berlin
Athens
Cairo
–11
–10
–9
–8
–7
–6
–5
–4
–3
–2
–1
+0
+0
+1
+1
+2
+2
GMT
Differential
City
Code City Name
GMT
Differential
JRS
JED
THR
DXB
KBL
KHI
DEL
DAC
RGN
BKK
HKG
SEL
TYO
ADL
SYD
NOU
WLG
Jerusalem
Jeddah
Teheran
Dubai
Kabul
Karachi
Delhi
Dakar
Yangon
Bangkok
Hong Kong
Seoul
Tokyo
Adelaide
Sydney
Noumea
Wellington
+2
+3
+3.5
+4
+4.5
+5
+5.5
+6
+6.5
+7
+8
+9
+9
+9.5
+10
+11
+12
•The contents of the above table are current as of December 2003.
•Time differentials in the above table are in accordance with
Universal Time Coordinated (UTC).
DST Indicator
(Changes
Setting)
(Scrolls City Codes)
The auto receive ON/OFF settings don’t appear when
configuring auto receive settings.
•Auto receive ON/OFF settings do not appear on the display
unless TYO (Japan), NYC (New York), CHI (Chicago), DEN
(Denver), or LAX (Los Angeles) is selected as the Home City.
Use the procedure under “To configure home time settings” to
select your correct Home City.
The auto receive AUTO, 40, and 60 settings do not appear when
configuring auto receive settings.
•The AT, JP40, and JP60 transmitter selection mode options are
available only when TYO (Tokyo) is selected as the Home City
code.
Use the procedure under “To configure home time settings” to
select your correct Home City.
What time is auto receive performed?
•Auto receive is performed in the middle of the night, when
reception conditions are best.
Before going to bed at night, place the watch near a window, with
its 12 o’clock position facing in the general direction of the
transmitter.
How can I perform manual receive?
•Hold down the lower right Dbutton for about two seconds.
The watch will beep to indicate that manual receive has started.
Place it near a window, with its 12 o’clock position facing in the
general direction of the transmitter.
How can I view the last reception date and time?
•In the Timekeeping Mode, press the lower right Dbutton.
This will display the date and time that the time calibration signal
was last received successfully. To return to the Timekeeping
Mode, press the Dbutton again. See “To view the last reception
date and time” for more information.
•Check the auto signal reception setting whenever you have
problems with signal reception or when the time setting produced
by signal reception is incorrect.
•The initial factory default configuration of the reception settings
are shown below. You do not need to change these settings if you
use the watch in Japan.
Auto Receive
Home City
Summer Time
Auto Japan transmitter select
(40kHz/ 60kHz)
Tokyo
Auto switching in accordance
with signal data

Operation Guide 3329
6
You can set the daily alarms in 1-minute increments. The watch
beeps for 10 seconds when the current time in the Timekeeping
Mode reaches the alarm time you set.
The Hourly Time signal causes the watch to beep every hour on
the hour.
❚ To display the alarm screen
In the Alarm Mode, press the DD
DD
Dbutton to toggle the display
between the alarm screen and the Hourly Time Signal
screen.
When you enter the Alarm Mode, the screen that was displayed
when you last exited the mode appears first.
Alarm Screen
• Alarm off
Hourly Time Signal Screen
• Hourly Time Signal off
❚ To set the alarm time
1. In the Alarm Mode, press
the DD
DD
Dbutton to display
the alarm screen.
2. Hold down the AA
AA
Abutton
for about two seconds.
•This will cause the hour digits
of the displayed alarm time to
flash.
•Displaying the setting screen
automatically turns on the
alarm.
Hour
(Setting Screen)
3. Use the DD
DD
D(+) and BB
BB
B(–)
buttons to change the
hour setting.
•Holding down either button
changes the setting at high
speed.
•When setting the hour, make
sure you specify AM (no
indicator) or PM (P) correctly
when using 12-hour
timekeeping, or that you
specify the correct 24-hour
time.
•The same 12-hour/24-hour
format you select for the
Timekeeping Mode home time
is also applied in the Alarm
Mode.
4. Press the CC
CC
Cbutton to
select the minute setting.
•This causes the minute digits
to flash.
5. Use the DD
DD
D(+) and BB
BB
B(–)
buttons to change the
minute setting.
•Holding down either button
changes the setting at high
speed.
6. When the setting is the way you want, press the AA
AA
A
button.
•This exits the setting screen.
•The display also will exit the setting screen automatically if
you do not perform any operation for about two or three
minutes.
(Forward)
(Back)
Minutes
(Forward)
(Back)
❚ To turn the alarm on or off
1. In the Alarm Mode, use the DD
DD
Dbutton to display the
alarm screen.
2. Press the AA
AA
Abutton to toggle the alarm on (“ ”
displayed) or off (“ ” displayed).
Alarm Off
Alarm Time
Alarm On
❚ To stop the alarm beeper
Press any button.
❚ To test the alarm
In the Alarm Mode, hold down the Dbutton to sound the alarm.
❚ To turn the hourly time signal on or off
1. In the Alarm Mode, use the DD
DD
Dbutton to display the
Hourly Time Signal screen.
2. Press the AA
AA
Abutton to toggle the Hourly Time Signal on
(“ ”) or off (“ ”).
Hourly Time Signal Off Hourly Time Signal On
The stopwatch measures elapsed time in units of 1/100 second up to 59 minutes, 59.99 seconds (60 minutes total). When the maximum
limit is reached, the elapsed time automatically returns to zero and timing continues from there.
❚ To perform elapsed time measurement
In the Stopwatch Mode, press the DD
DD
Dbutton to start and stop
elapsed time measurement.
(Split/Reset)
(Start/Stop)
❚ Stopwatch Mode Display Screens
•Elapsed Time Screen
The display shows the minutes and seconds.
Minutes Seconds
•Paused Elapsed Time Measurement Screen
When elapsed time measurement is paused, the display alternates
between a minute/second screen and a 1/100 second screen at
2-second intervals.
Minutes Seconds
2-second
interval
1/100 Second
Stopwatch Mode
Using the Alarms and Hourly Time Signal

Operation Guide 3329
7
❚ Elapsed Time Measurement
Start Stop Reset
Pressing the Abutton while timing is stopped resets the stopwatch to all zeros.
Cumulative Time Measurement
Pressing the Dbutton to restart the stopwatch without resetting it to all zeros causes the elapsed time measurement to resume from
where it was last stopped.
❚ Split Time Measurement
Start Record Split Clear Split Stop Reset
Pressing the Abutton while timing is being performed displays the split time screen, but timing continues internally.
•Changing to another mode while a split time is displayed clears the split time operation.
❚ 1st and 2nd Place Finishers
Start 1st Finish
(Displays time of 1st finisher.) 2nd finish Displays time of 2nd finisher. Reset
Pressing the Dbutton while the split time screen is on the display stops elapsed time measurement, and leaves the split time screen on
the display. Press the Abutton to exit the split time screen and display the elapsed time when the measurement was stopped.
Split Time Screen
The split time screen cycles alternately cycle through the split indicator, a
minute/second screen, and a 1/100 second screen.
Split Indicator Minutes Seconds 1/100 Second
Home time settings include your Home City (the city where you will
normally use the watch), the current time and date in your Home
City, and other settings.
•Use the Timekeeping Mode to configure home time settings.
•Also use the following procedure when you want to turn Power
Saving on or off.
If you are planning to manually adjust both the digital and
analog settings, be sure to adjust the digital setting first.
❚ To configure home time settings
1. In the Timekeeping Mode,
hold down the AA
AA
Abutton
for about two seconds.
•This will cause the city code
currently selected as the
Home City to flash on the
display.
2. Press the DD
DD
Dbutton to
scroll through the city
codes until the one you
want to select is
displayed.
•See the “World Time City
Code List” for information
about city codes.
•Holding down either button
scrolls at high speed.
3. When the city code you
want is displayed, press
the CC
CC
Cbutton.
•This will display the summer
time (DST) setting screen.
City Code
TYO=Tokyo
(Foward)
Configuring Home Time Settings
4. Press the DD
DD
Dbutton to
cycle through the
available summer time
(DST) settings until the
one you want to select is
displayed.
•AUTO
This setting enables the auto summer time setting, which
turns summer time on or off in accordance with the received
time calibration signal.
•This setting uses Japan summer time data when TYO is
selected as the Home City, and U.S. summer time data
when NYC, CHI, DEN, or LAX is selected as the Home
City.
•Note that “AUTO” can be selected only when TYO, LAX,
DEN, CHI, or NYC is selected as the Home City.
•OFF
This setting turns off summer time and returns to normal
timekeeping.
•ON
This setting turns on summer time and advances the current
time by one hour.
5. When the summer time
setting is the way you
want, use the CC
CC
Cbutton to
cycle the digital display
through the settings
shown below.
Summer Time
Home City
Code
Power Saving
12/24-hour
Timekeeping
Hour MinuteMonth Year
Day
Seconds
6. While the 12/24-hour
timekeeping setting is
flashing, press the DD
DD
D
button to toggle between
12-hour (“12H”) and
24-hour (“24H”)
timekeeping.
7. While the seconds are
selected, press the DD
DD
D
button to reset them to 00
in accordance with the
time signal on the radio,
TV, etc.
•Pressing the Dbutton while
the seconds count is in the
range of 30 to 59 resets it to
00 and also adds 1 to the
minutes. Pressing the D
button in the range of 00 to 29
resets the seconds count
without changing the minutes.
•Pressing the Bbutton while
the seconds count is flashing
changes the face illumination
duration. See “Specifying the
Illumination Duration” for more
information.
8. While the hour, minutes,
year, month, or day setting
is flashing, use the DD
DD
D(+)
button to change the
setting.
• Holding down the D button
changes the setting at high speed.
•When setting the hour, make sure you specify AM (no indicator)
or PM (P) correctly, or that you specify the correct 24-hour time.
•You can set a year in the range of 2000 to 2099. The day of the
week is set automatically in accordance with the date you set.
•The watch automatically makes adjustments for leap years
and month lengths.
9. While the Power Saving
setting is flashing, press
the DD
DD
Dbutton to toggle it
on (ON) or off (OF).
•The Power Saving indicator
will be on the display when
you exit the setting screen
after turning on Power Saving.
Use the CC
CC
Cbutton to select each of the settings and the
DD
DD
Dbutton to change them.
Indicates 12-hour or
24-hour timekeepin
g
.
Seconds reset to 00.
Minutes
Hour
(Forward)

Operation Guide 3329
8
10 . When all of the settings are the way you want, press the
AA
AA
Abutton.
•This exits the setting screen.
•The display also will exit the setting screen automatically if
you do not perform any operation for about two or three
minutes.
Digital-Analog Synchronization
After adjustment of the digital time, the watch automatically
adjusts its analog setting to match.
•When adjusting the analog time, the hands move clockwise.
•Depending on how many hours different the digital and analog
time settings are, it may take some time for the analog hand
setting procedure to be finished.
Adjusting the Analog Time Setting
You can use the Hand Setting Mode to manually adjust the analog
time when it does not match the digital time.
1. In the Hand Setting Mode,
hold down the AA
AA
Abutton
for about two seconds.
•This will cause the hour and
minute setting of the digital
time to flash on the display.
2. Use the DD
DD
D(+) button to
adjust the hour and
minute hands so they
match the digital time.
•Each press of the Dbutton
moves the hands 20 seconds
clockwise.
•Holding down the Dbutton
moves the hands at high
speed.
(Forward)
High-speed Lock
•While holding down the Dbutton to start high-speed clockwise
movement of the hands, press the Bbutton to lock
the high-speed hand movement. You can then release the
buttons.
•High-speed hand movement will continue until it completes a
12-hour cycle, or until you press any button to stop it.
•High-speed hand movement will also stop momentarily if an alarm
starts to sound. High-speed movement will resume after the alarm
stops.
3. When the setting is the way you want, press the AA
AA
A
button.
•This exits the setting screen and automatically synchronizes
the minute hand with the current seconds count.
•The display also will exit the setting screen automatically if
you do not perform any operation for about two or three
minutes.
