Operation Guide 5333
1
MA1301-EA
#!3)/#/-054%2#/,4$
To change the day indicator setting
To adjust the time setting
Pull the Crown out to Click 1.
Push the Crown back in.
Push the Crown back in.
Rotate the Crown to change the
time setting.
When the second hand is at
12 o’clock, pull the Crown out to
Click 2.
Rotate the Crown away from you
to set the day.
Note
xTake care that you set the correct AM
or PM time.
xWhen changing the time, move the
minute hand four or five minutes past
your final setting, and then back it up
to the setting you want.
Note
xThe day indicator setting uses a
31-day month. Make adjustments for
months of shorter lengths.
xAvoid changing the day indicator
setting between the hours of 9p.m.
and 1a.m. Otherwise, the day
indicator may not change correctly
at midnight.
Stopwatch functions
Specifications
Accuracy: ±20 seconds average per month
Stopwatch: Measuring Capacity: 39'59.99" (40 minutes)
Measuring Unit: 1/100 second
Measurements: Elapsed time; split time; two finishes
Battery: One silver oxide battery (Type: SR927W)
Battery Life: Approximately 3 years (2 hours stopwatch operation per day)
Low Battery Indicator: Second hand moves in 2-second increments when power is
low.
xYour watch may differ somewhat from the one shown in the illustration.
Using the Stopwatch
Elapsed time
AAA A B
Start Stop Re-start Stop Reset
Split time
ABBAB
Start Split Split release Stop Reset
Two finishes
ABABB
Start Split
First runner
finishes.
Display time of
first runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
Important!
xDo not operate the stopwatch with the crown pulled out.
Note
xThe stopwatch 1/100-second hand and stopwatch 1/10-second hand move for
the first three minutes of an elapsed time measurement operation only. After that,
both hands stop at the 0 position.
Stopping the elapsed time operation will cause the two hands to move to
the 1/100-second and 1/10-second positions of the stopped elapsed time
measurement operation. Note, however, that the hands will not move when the
stopwatch is stopped if the cumulative elapsed time exceeds 120 minutes.
xThe stopwatch minute hand is a 40-minute retrograde dial. Every 40 minutes (at
the 41st or 81st minute), it reverts back to the 1 position.
xThe stopwatch second hand and stopwatch minute hand move for the first 120
minutes of an elapsed time measurement operation. After that, the second hand
stops at the 0 position while the retrograde minute hand stops at the 40-minute
position.
The stopwatch measures elapsed time in 1/100-second increments up to
39 minutes, 59.99 seconds.
Perform the following procedure if the stopwatch hands do not return to their
0(zero) positions when you reset the stopwatch.
Use the Abutton to select the hand whose zero position you want to correct.
Each time you hold down Afor about two seconds in the following procedure, it
cycles to the next hand to be corrected.
Use the Bbutton in the following procedure to correct the 0 position of the
currently selected hand. Holding down Bmoves the current hand at high speed.
Correcting the 0 Positions of the Hands
Operational Flow
Pull the Crown out to Click 2.
Hold down Afor about two seconds. The Stopwatch 1/100-second Hand
and Stopwatch 1/10-second Hand will rotate to indicate the 1/100-second
hand and 1/10-second hand setting mode.
xIf the hands do not align with the 0 position, use the Bbutton to adjust them.
Hold down Afor about two seconds, the Stopwatch Second Hand will
rotate to indicate the second hand setting mode.
xIf the hand does not align with the 0 position, use the Bbutton to adjust it.
Hold down Afor about two seconds, the Stopwatch Minute Hand will rotate
to indicate the minute hand setting mode.
xIf the hand does not align with the 0 position, use the Bbutton to adjust it.
After all of the hands are the way you want, push the Crown back in.
Important!
xTimekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
Perform the operation below after having the watch’s battery replaced or whenever
hand movement seems to be abnormal.
Required Operation after Battery Replacement or Whenever the
Hand Movement is Not Normal
Important!
xTimekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
Pull the Crown out to Click 2.
Push the Crown back in.
xThe second hand should be moving normally at one-second intervals.
Hold down the Aand Bbutton at the same time for at least two seconds.
Second Hand
Click 2
Click 1
Hour Hand Minute Hand
A
B
Stopwatch Second Hand
Stopwatch Minute Hand
Stopwatch 1/10-second Hand
Day Indicator
Crown
Stopwatch 1/100-second Hand
xIn the above sample illustration, the stopwatch shows an elapsed time of
20minutes and 41.19 seconds.
Demo Mode
The stopwatch is equipped with a Demo Mode that you can activate by resetting
the stopwatch to all zeros, and then holding down the Bbutton for at least two
seconds.
xThis will cause the stopwatch 1/100-second hand, stopwatch 1/10-second hand,
and stopwatch second hand to start moving at high speed. The stopwatch minute
hand will move back and forth between 0 and 40 minutes. Hand movement will
stop and the watch will exit the Demo Mode after about three seconds.
xTo stop hand movement and exit the Demo Mode manually, press the Aor B
button.
Crown Operations
Some water-resistant models (100 meters, 200 meters)
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull the
crown out. Avoid applying undue force when pulling. The watch
loses its water resistance while the crown is unscrewed. After
performing a crown operation, fully screw the crown back in.
Crown
Loosen
If your watch has a rotary bezel...
You can rotate the bezel to align its ▼mark with the
minute hand. Then you will be able to tell how much
time has elapsed since aligning the ▼mark.
Start
Elapsed time
Current
