Casio WSD-F20X User manual

.
WSD-F10/
WSD-F20/
WSD-F20S/
WSD-F20X/
WSD-F20SC/
WSD-F20A
User’s Guide
Thank you for purchasing this watch.
Before trying to use this watch, be sure to read the Safety Precautions in
the Quick Start Guide that comes with it. Make sure you use the watch
correctly.
EN
© 2017 CASIO COMPUTER CO., LTD.

Contents
Introduction ....................................................................................... EN-2
Watch Features ............................................................................ EN-2
Measurement Functions ............................................................... EN-4
Overview ...................................................................................... EN-6
About This Manual ....................................................................... EN-7
Getting Ready ................................................................................... EN-8
Basic Operations You Should Remember ................................... EN-13
Using Outdoor Watch Functions - Using CASIO Watch Faces and Apps
........................................................................................................... EN-18
Using CASIO Watch Faces ........................................................ EN-19
Using the Location Memory App (WSD-F20 series only) ........... EN-21
Using the TOOL App .................................................................. EN-27
Using the Activity App ................................................................ EN-38
Using the MOMENT SETTER App ............................................. EN-41
Using the Timepiece App ........................................................... EN-44
Common Outdoor Function Settings .......................................... EN-46
Monochrome Display ..................................................................... EN-60
Troubleshooting ............................................................................. EN-62
Important! ........................................................................................ EN-64
Precautions During Use .............................................................. EN-64
User Maintenance ...................................................................... EN-73
Chargeable Battery Handling (Please recycle!) .......................... EN-74
Personal Information Protection Precautions .............................. EN-74
Main Specifications ........................................................................ EN-75
Supplementary Information ........................................................... EN-81
EN-1

Introduction
Attention WSD-F10 Owners!
●This manual describes operations for a WSD-F10 watch that has been
updated to Wear OS by GoogleTM. For information about updating to Wear
OS by Google, visit the website below.
https://support.google.com/wearos/
●The functions below, which are described in this manual, are not supported
by the WSD-F10.
ーBuilt-in GPS
ーSome Activity app functions (Paddle, Snow)
ーSome watch faces (Location, Traveler)
ーLocation Memory app
●The WSD-F10 acquires location information from a phone. Be sure to use
it while connected with a paired phone.
Attention iPhone Owners!
●When using this watch while it is paired with an iPhone, be sure to have the
Wear OS by Google app running on the iPhone. If the Wear OS by Google
app is not running, functions that require communication with the iPhone
will not operate.
●Some watch functions are restricted when it is paired with an iPhone. For
details, visit the website below.
http://support.casio.com/wsd/
Watch Features
Powered with Wear OS by Google
This watch is designed primarily to be paired with a smartphone running
AndroidTM 4.4+ (excluding Go edition) or iOS 9.3+*1. Pairing with a
smartphone enables use of variety of different functions, both in conjunction
with the smartphone and when the watch is being used by itself.
*1 Recommended. However, a WSD-F10, F20, F20S, or F20X watch that is
already paired with a smartphone running Android 4.3+ or iOS 9+ can also
be used.
EN-2

Five-atmosphere Water Resistance + MIL-STD*2
Even though this watch has a built-in voice recognition microphone, it still is
water resistant up to five atmospheres. This means you can wear your watch
while swimming, fishing, etc. MIL-STD-810G standard environment
resistance allows you to wear your watch while engaged in a variety of
vigorous outdoor activities, including: mountain climbing, cycle sports,
fishing, and more.
*2 United States Department of Defense Military Standard
Built-in GPS (WSD-F20 series only)
This watch has GPS*3 built in, and you can acquire location information
without connecting with a phone. The watch itself can display a map*4 of your
current location, measure and record data for a variety of activities, and more.
*3 In addition to GPS (U.S.), your watch also supports GLONASS (Russia)
and QZSS (Japan) positioning. This manual uses “GPS” to refer to all of
the above positioning systems.
*4 To display the map when you do not have a smartphone, you need to have
the map data downloaded beforehand.
Dual-layer LCD for Improved Readability
CASIO app operations are designed to use either the color or the
monochrome LCD. The monochrome LCD makes display contents easier to
read when outdoors under sunlight.
Three Side Buttons Designed for Sure Operation
The three side buttons are designed for sure operation even when outdoors.
Apps can be freely assigned to the TOOL button and the APP button.
EN-3

CASIO MOMENT SETTER+ App for Smartphone Control of
the Watch
A CASIO MOMENT SETTER+ smartphone app (available from the Google
Play store for Android smartphones only) can be used to customize the watch
setup (MOMENT SETTER notifications, TOOL app functions, etc.) from your
smartphone.
CASIO Camera Linking
Use this app to control supported CASIO camera models from the watch. For
details, visit the CASIO website below.
http://support.casio.com/wsd/
Measurement Functions
Your watch can take barometric pressure, altitude, bearing, and other
readings. Its built-in watch faces and applications can use readings for display
and other useful functions. Note that this watch is not a special purpose
measuring instrument. Readings produced by measurement functions are
intended as general reference information only.
Compass (Bearing Measurement)
For serious mountain climbing and other activities that require accurate
bearing readings, take along a highly reliable compass to use in combination
with the watch’s compass.
Important!
●Note that accurate compass readings and/or correction will not be possible
in the areas described below.
ーIn the vicinity of a permanent magnet (magnetic accessory, etc.), metal
objects, high-voltage wires, aerial wires, or electrical household
appliances (TV, computer, cellphone, etc.)
ーIn motor vehicles, on boats, on aircraft, etc.
ーIndoors, especially inside of reinforced concrete structures.
EN-4

Altimeter, Barometer
The watch’s Altimeter uses a pressure sensor to measure barometric
pressure, and then calculates and displays relative altitude based on the
measured value. Because of this, readings taken at different times at the
same location may produce different altitude values due to changes in
temperature, humidity, barometric pressure, and other factors. Also note that
values displayed by the watch may be different from elevations indicated for
areas where you are located. When using the watch’s altimeter while
mountain climbing, it is recommended that you perform regular correction in
accordance with the local altitude (elevation) indications.
Tide Graph (Graphic Display of Tide Information)
The Tide Graph feature of your watch is intended to provide a rough image
of current tide conditions. Do not use its tide information for navigation
purposes. For navigation purposes, be sure to use official tide charts issued
by a reliable agency or authority for the area you are navigating.
EN-5

Overview
Package Contents
Watch, AC adaptor, charger cable, Quick Start Guide, warranty, cloth band/
band replacement tool (WSD-F20X only)
General Guide
①
②
③
④
⑤
⑥
⑦
⑧
ACharge LED
BCharger terminal
CPressure sensor
DMicrophone
ETOOL button
FPower button
GAPP button
HTouch screen
EN-6

About This Manual
●The contents of this manual are subject to change without notice.
●Copying of this manual, either in part or its entirety, is forbidden. You are
allowed to use this manual for your own personal use. Any other use is
forbidden without the permission of CASIO COMPUTER CO., LTD.
●CASIO COMPUTER CO., LTD. shall not be held liable for any lost profits
or claims from third parties arising out of the use of this product or this
manual.
●CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost
profits due to loss of data caused by malfunction or maintenance of this
product, or any other reason.
●The watch and sample screens depicted in the illustrations in this manual
may be different from the actual appearance of the watch.
EN-7

Getting Ready
Be sure to read the precautions in the “Quick Start Guide”, and also perform
all of the steps under “Preparing the Watch for First Use” and “Preparing the
Watch for Outdoor Use”.
Preparing the Watch for First Use
You must perform the steps below before using the watch for the first time.
1. Charge the watch
Plug the provided AC adaptor into a power outlet, and then connect the
provided charger cable and AC adaptor as shown in the illustration.
●The charge LED lights red during charging, and green when a full
charge is achieved.
●The watch will turn on automatically when the charge reaches a certain
level.
AC adaptor*
Charge LED
* The shape of the AC adaptor supplied in your geographic area may be
different from the one shown in the illustration.
Important!
●To help promote longer battery life, regular charging of the watch (about
once a month) is recommended even if you do not use it for a long time.
2. Install the Wear OS by Google App on a Smartphone
Android smartphone: Download the Wear OS by Google app from the
Google Play store.
iPhone: Download the Wear OS by Google app from the iTunes App
Store.
EN-8

3. Pair the Watch with Your Smartphone
When pairing, it is recommended that you have the smartphone and
watch within one meter of each other. Refer to the websites below for
information about how to pair the watch with a smartphone.
Wear OS by Google Help
https://support.google.com/wearos/
CASIO website
http://support.casio.com/wsd/
4. Install the CASIO MOMENT SETTER+ App on the
Smartphone (Android Only)
If you are using an Android smartphone, download the “CASIO MOMENT
SETTER+” app from the Google Play store and install it. You can use the
CASIO MOMENT SETTER+ app to configure the following watch
settings from your smartphone: TOOL App, MOMENT SETTER App.
Important!
●There are two versions of the CASIO MOMENT SETTER+ app. Make sure
you have the latest version installed on your phone. Icons shown in the
Google Play store indicate whether the app is the old version or new version.
Old version icon New version icon
●In order to use all of the functionality provided by this watch, be sure to
update all of your related CASIO apps to their latest versions before using
your watch. For information about the update procedure, visit the website
below.
http://support.casio.com/wsd/
EN-9
