Catler 400 series User manual

1
OPERATING YOUR CONTROL GRIP SB 4010
1
1
O
PERATING YOUR CONTROL GRIP SB
4010
Instruction manual
MINI FOOD PROCESSOR
MINI FOOD PROCESSOR
FP 4010

2OPERATING YOUR CONTROL GRIP SB 4010
MINI FOOD
PROCESSOR

33
CONTENTS
5 Catler recommends safety rst
11 Know your Catler product
12 Assembly & operation of your Catler product
22 Care, cleaning & storage of your Catler product
25 Troubleshooting
26 Food preparation guide
30 Recipes
CONTENTS

4OPERATING YOUR CONTROL GRIP SB 4010 4CONGRATULATIONS
Congratulations
on the purchase of your Catler product.

5
CATLER RECOMMENDS SAFETY FIRST
CATLER RECOMMENDS SAFETY FIRST
We at Catler are very safety conscious. We design and manufacture
consumer products with the safety of you, our valued customer
foremost in mind. In addition we ask that you exercise a degree
of care when using any electrical appliance and adhere to the
following precautions:
IMPORTANT SAFEGUARD FOR YOUR MINI FOOD PROCESSOR FP 4010
 Carefully read all instructions
before operation and save for
future reference.
 Remove and safely discard
any packaging material and
promotional labels before
using the appliance for the rst
time.
 To eliminate a choking
hazard for young children,
remove and safely discard the
protective cover tted to the
power plug of the appliance.
 Use this appliance ONLY for
the purposes that it has been
intended for and how it is
described in this manual. This
appliance has been designed
exclusively for household use
and constructed to process
of normal amount of food in
household.
 Do not place the appliance
near the edge of a bench or
table during operation. Use
the appliance only on level
surface, free of water.
 Ensure that the surface is
clean, level, and free of water.
 Do not place the appliance
on or near a hot gas burner,
electric element or where
it could touch a heated oven.
 Do not operate the appliance
on a sink drain board.
 This appliance is not intended
to be operated by means of
an external timer or separate
remote control system.
 Do not use sprays near the
appliance.
READ INSTRUCTIONS BEFORE USE

6CATLER RECOMMENDS SAFETY FIRST
 Before you connect the
appliance into the power
outlet make sure the
voltage on the rating label
corresponds to the voltage
in your power outlet.
 Always make sure the
appliance is completely and
properly assembled before
operating, mainly the blending
leg. Follow the instructions in
the manual.
 Ensure the appliance is turned
o and the power is switched
o at the power outlet before
attempting to assemble or
disassemble.
 Do not run the appliance
unless it is correctly and
properly assembled. Do not
run an empty appliance.
Incorrect using of the
appliance can negatively
inuence its life.
 Handle the appliance and
the accessories with care –
remember the blades are very
sharp and should be kept out
of reach of children.
 Never use the appliance to
process food on a hot stove or
gas burner. Always remove the
saucepan from the heat source
and ensure the power cord
and the appliance are also kept
away from any heat source.
 Use the appliance as described
in this manual.
 Use the whisk attachment
only for the recipes which
require the whisk attachment
usage. Do not use the whisk
attachment any other
purposes than it is intended
for.
 Do not process hot or boiling
liquids in the chopper / mixing
bowl. Allow liquids to cool
before placing into the bowl.
 Insert only food for mixing into
the chopper / mixing bowl.
 Allow the hot food to cool
down to the temperature
of 60°C at least.
 Do not operate the appliance
continuously for more than
1 minute. After 1 minute, turn
o the appliance and allow the
motor to rest for 1 minute at
least.

7
CATLER RECOMMENDS SAFETY FIRST
 When processing dry, thick or
heavy mixtures, interrupt the
process after 30 seconds. Stir
the ingredients and allow the
motor to rest for 1 minute at
least.
 Recipes in the manual are
considered as common food
amount in household.
 If food becomes lodged
around the processing blade,
turn o the appliance by
releasing the main switch and
disconnect the power cord
from the power outlet. Use
a spatula, or plastic knife, to
dislodge the food. In no cases
use your ngers to dislodge
the food. The blades are very
sharp.
 Do not insert your hand
into the mixing bowl if the
appliance is in process.
 Do not remove the appliance
from the mixing mixture
during operation. Turn o the
appliance at rst, disconnect
the power cord from the
power outlet and wait until the
blades stop turning. Then you
can remove the appliance from
the mixing mixture.
 Do not push food into the
food chute with your ngers
or other utensils. Always use
the food pusher provided.
 Keep ngers, hands, knives
and other utensils away from
moving blade and discs.
 Do not place hands or ngers
in the processing bowl
of the food processor unless
the motor, processing blade,
dough blade or disc has come
to a complete stopped. Ensure
the appliance is switched o
at the power outlet and the
power cord is unplugged
before removing the lid from
the processing bowl.
 Do not leave the appliance
unattended when in use.
 Do not use the appliance with
wet hands.
 Always ensure the appliance
has been turn o before
attempting to move the
appliance, when the appliance
is not in use and before
cleaning and storing. Then you
can unplug the appliance from
the power outlet.

8CATLER RECOMMENDS SAFETY FIRST
 If you do not use the appliance
for a long time or you attempt
to leave it unattended, unplug
the appliance from the power
outlet.
 Do not disconnect the
appliance from the power
point by pulling the electric
cable – it may damage the
electric cable/power point.
Disconnect the cable from the
power point by gently pulling
the plug of the electric cable.
TO PROTECT AGAINST
ELECTRIC SHOCK DO NOT
IMMERSE THE MOTOR BODY,
POWER CORD OR POWER
PLUD IN WATER OR ANY
OTHER LIQUID OR DO NOT
ALLOW MOISTURE TO COME IN
CONTACT WITH THESE PARTS.
DO NOT WASH THE POWER
BASE UNDER RUNNING WATER.
 This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities
or lack of experience and
knowledge if they have
been given supervision
or instruction concerning use
of the appliance in a safe way
and understand the hazards
involved.
 Use only supplied accessories
or recommended accessories
by a manufacturer. Otherwise
it may result in re, electric
shock or injury to persons.
 Keep the appliance clean.
Follow the cleaning
instructions provided in Care
and Cleaning chapter.

9
IMPORTANT SAFEGUARD FOR ALL ELECTRICAL APPLIANCES
 This appliance is for household
use only.
 Unwind the cord fully before
use.
 Do not let the cord hang over
the edge of a table or counter,
touch hot surfaces or become
knotted.
 This appliance is not intended
for use by persons (including
children) with reduces physical,
sensory or mental capabilities
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
 Children should be supervised
to ensure that they do not play
with this appliance.
 It is recommended to inspect
the appliance regularly. Do
not use the appliance if power
supply cord, plug or appliance
becomes damaged in any way.
Return the entire appliance to
the nearest authorised Catler
Service Centre for examination
and/or repair.
 Any maintenance other than
cleaning should be performed
at an authorised Catler Service
Centre.
 Do not use this appliance for
other than its intended use.
Do not use in moving vehicles
or boats. Do not use outdoors.
 The installation of a residual
current device (safety switch)
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
a safety switch with a rated
residual operating current
not exceeding 30mA be
installed in the electrical circuit
supplying the appliance.
See your electrician for
professional advice.
 For the security reasons,
we recommend to plug
the appliance directly to its
own circuit, separate from
other appliances. It is not
recommended using hub
or extension cord.
This symbol points out
that the device has double
insulation between the
dangerous mains voltage
and the parts accessible
to the user. In the case of
servicing use only identical
spare parts.
CATLER RECOMMENDS SAFETY FIRST

10
WARNING:
DO NOT OPERATE THE APPLIANCE ON AN INCLINED
SURFACE. DO NOT MOVE THE APPLIANCE WHILE IT
IS SWITCHED ON.
WARNING:
THE POWER PLUG WHEN PLUGGED MUST REMAIN
ACCESSIBLE FOR EASY REMOVING.
WARNING:
THE BLADES AND DISCS ARE VERY SHARP. PAY YOUR
OWN ATTENTION WHEN THEIR HANDLING.
WARNING:
ENSURE THE PROCESSING BLADES AND DISCS HAVE
COMPLETED STOPPED, THE APPLIANCE IS SWITCHED
OFF, POWER CORD IS UNPLUGGED FROM THE POWER
OUTLET IF YOU NEED TO ASSEMBLE/DISASSEMBLE, YOU
NEED TO STORE OR CLEAN THE APPLIANCE OR BEFORE
ATTEMPTING OTHER MANIPULATION.
WARNING:
DO NOT IMMERSE IN WATER OR OTHER LIQUID.
NOT DISHWASHER PROOF.
WARNING:
BLADES ARE SHARP! DO NOT PUT HANDS OR UTENSILS
DOWN FEED CHUTE.
DO NO OPEN THE COVER UNTILL THE BLADES HAVE
COMPLETELY STOPPED.
WARNING:
ONLY FOR HOUSEHOLD USE.
FULLY UNWIND THE POWER CORD BEFORE USING.
KEEP THE MANUAL IN A SAFE PLACE.
KEEP THE APPLIANCE AND ITS POWER CORD OUT OF
REACH OF CHILDREN.
SAFE THESE INSTRUCTIONS
CATLER RECOMMENDS SAFETY FIRST

11
KNOW YOUR CATLER PRODUCT
A
B
C
D
E
F
GH
IJ
K
L
MNOP
A. Speed Control Dial
B. Easy Grip Trigger Switch
C. Motor Body
D. Processing Gear Box
E. Clear Lid
F. 1.6L Chopping Bowl
G. Feed Chute
H. Whisk
I. Stainless Steel Blending Leg
J. Detachable Mashing Gear Box
K. Detachable Mashing Leg
L. Quad Blade
M. Variable Slicing Disc
N. Reversible Shredding Disc
O. Storage Base
P. Spindle
NOT SHOWN
Quad Blade Cover
KNOW YOUR CATLER PRODUCT

12
ASSEMBLY & OPERATION
TO ATTACH THE BLENDING LEG
Hold the blending leg with the blades down,
and align the top end of the blending leg
with the corresponding end of the motor
body and push until the blending leg clicks
and locks onto the motor body.
Always ensure blending leg is dry, and no
water left inside, before reattaching.
USING AS A STICK MIXER
Ensure the blending leg is assembled to the
motor body as detailed above.
1. Place food to be processed into
a suciently large mixing bowl or
saucepan (do not use the food processor
bowl as this may damage either the stick
mixer or the bowl). The bowl should only
be 1/2full or less when blending liquids
or when making a puree of fruit and/or
vegetables.
2. Insert the plug into a 230/240V power
outlet and turn the power on.
3. Turn the dial at the top of motor body,
select a speed from 1 to 15.
If selecting a higher speed, it is recommended
that you start on a slow speed and then
increase to high speed to avoid splattering
and over-processing.
NOTE
ASSEMBLY & OPERATION
BEFORE FIRST USE
Remove any packaging material and
promotional labels. Remove the blending
leg from the mixer motor body and wash
it in warm soapy water (refer to assembly
instructions in this booklet). Rinse and dry
thoroughly. Ensure no water remains inside
the blending leg to avoid water running into
the motor body when reattached.
Disassemble and wash the chopping blade,
chopper bowl, chopper bowl lid, whisk,
storage lid, and blending jug in warm soapy
water, rinse and dry thoroughly. Ensure no
water remains on the chopper bowl lid or
whisk attachment to avoid water running
into the motor body when reattached.
The detachable blending leg, chopping bowl
(without the gearbox), quad blade, variable
masher, whisk can also be washed in the
dishwasher.
The whisk gear box, processor gear box, masher
gear box and motor body are not dishwasher
safe – see the care and cleaning section of this
booklet for cleaning instructions of these parts.
NOTE
This stick mixer is a versatile appliance
that can be attached to:
• The stainless steel blending leg – for use
as a stick mixer.
• The food processor bowl with quad
blade, variable slicing disc, reversible
shredding disc - for use as a mini food
processor.
• The variable mashing leg – for use as
mashing vegetables.
• The whisk attachment – for use as a hand
whisk.

13
4. Place the blending leg as deeply as
possible into the bowl and press the
trigger switch to turn the stick mixer on.
The button must be held for the required
duration of operation.
5. Work through the ingredients in the
bowl with a gentle raising and lowering
motion.
6. Switch o the motor by releasing the
trigger switch.
7. Ensure the motor has completely
stopped before lifting the blender out of
the bowl.
8. When processing has nished, switch
o at the power outlet and remove the
power plug.
TO DETACH THE BLENDING LEG
Ensure the trigger switch is released, the
power is turned o at power point and the
appliance is unplugged. Hold the motor
body with one hand, and using thumb and
nger of the other hand, press on the two
EJECT buttons on either side of the motor
body. Pull the motor body away from the
blending leg to detach.
RECOMMENDATIONS WHEN USING
AS A STICK MIXER
• The stick mixer blends foods and liquids
rapidly, therefore it is easy to over
process. Remember when using the
blending leg to stop the stick mixer and
check food throughout the operation.
• Use caution when blending hot food as
it can splatter.
• The stainless steel blending leg allows
for hot food to be processed directly in
the saucepan. This makes blending soups
and sauces very easy.
• For safety reasons remove saucepan
away from the heat before processing.
• Ensure the body of the appliance and
power cord are kept away from any heat
source.
• When pureeing and blending, cut food
into uniform sizes. This will ensure
smooth and consistent results.
• Warm all liquids to be added to soups
and purees, this will ensure even
blending.
• Do not operate the appliance
continuously for more than 1 minute.
Allow the motor to rest for 1 minute
between each use.
If food becomes lodged around the
processing blade or in the blade guard,
follow the safety instructions below:
1. Release the trigger switch, the power o
at the power outlet and unplug the cord.
2. Use a spatula to carefully dislodge the
food. Do not use ngers as the blades are
sharp.
3. After the food has been removed and
blades are clear, plug the appliance back
into the power supply, switch the power
on and continue blending.
ASSEMBLY & OPERATION

14
USING THE FOOD PROCESSOR BOWL
ATTACHING GEARBOX TO FOOD
PROCESSING BOWL LID
The gearbox should be placed into the food
processor lid. It should click into place.
To attach the motor, click into place onto the
gearbox.
TO ATTACH THE FOOD PROCESSING
BOWL, FOOD PROCESSOR ATTACHMENTS
AND LID
1. Remove the food processing bowl from
the storage unit and place onto a bench
ensuring that the surface is clean and
level.
2. Choose one of the following food
processor attachments:
a) Quad blade
b) Adjustable slicer
c) Reversible shredder
3. There is a common spindle that is used
across all of the three food processor
attachments.
WHEN USING THE REVERSIBLE SHREDDER
1. Place the spindle, into the centre of the
food processing bowl.
CAUTION:
Caution should be taken when
handling the shredding disc.
ASSEMBLY & OPERATION

15
2. Holding the reversible shredder disc,
notice that there is a large grater and
small grater, place the side you require
up. Place over the centre of the spindle
and ensure that it is pushed down rmly.
3. Place the lid into position and ensure that
it is on correctly.
WHEN USING THE ADJUSTABLE SLICER
1. Place the spindle in the centre of the
food processing bowl.
CAUTION:
Caution should be taken when
handling the adjustable slicing disc
and ensure that blade is in the storage
or 0 position.
2. The adjustable slicing disc has 18 precise
settings. To adjust the settings hold the
adjustable slicing disc by the edge (on
the opposite side to the cutting blade)
with one hand and turn the rotating
collar to the desired setting with the
other hand.
3. Place the adjustable slicing disc onto the
spindle. Ensure that it is pushed down
correctly.
ASSEMBLY & OPERATION

16
4. Place the lid into position and ensure that
it is on correctly.
WHEN USING THE QUAD BLADE
1. Using care, hold the quad blade in one
hand, with the other hand, place the
spindle through the centre of the quad
blade from underneath. The quad should
self-locate at the base of the spindle.
The quad blade will sit loosely on the
spindle but will lock into place during
processing.
CAUTION:
Caution should be taken when
handling the quad blade as the blades
are extremely sharp.
2. Place the quad blade and spindle into the
centre of the food processing bowl.
3. Place the lid into position and ensure that
it is on correctly.
4. Once the blade or disc has been selected
for the food processor you can now
process food. Place the food inside the
processing bowl. If using the quad blade.
Do not exceed the maximum (MAX)
marking.
5. Insert the gear box into the lid of the
food processor.
Always place the quad blade into the food
processor prior to placing the food into the food
processor. When using the disc’s adjustable
slicer and reversible shredder these both can
be placed into the food processor prior to
processing food. Some foods, such as nuts, can
stop the quad blade from engaging the built in
safety mechanism. If you have troubles closing
the lid with ingredients such as this we advise
to load these through the feed chute.
NOTE
ASSEMBLY & OPERATION

17
TO USE THE FOOD PROCESSOR
For food preparation tips and recipes refer to
the recipe section of this booklet.
1. Insert the plug into a 230/240V power
outlet and turn the power on.
2. Select a speed between 1–15 on the
speed control dial.
3. Press the trigger switch to turn the
appliance on and start the processing
action.
4. Feed the food through the feed chute
of the food processor, using the food
pusher to push it down.
CAUTION:
Only use the small pusher with the
large pusher resting inside the feed
chute.
5. When processing has nished switch
o the motor by releasing the trigger
switch, switch o at the power outlet and
remove the power plug.
6. Detach the food processing bowl and
lid (refer to instructions). Remove the lid
from the food processor bowl. Carefully
remove the food processing blades or
quad blade and use a spatula to scrape
o any attached food back into food
processing bowl.
TO DETACH THE FOOD PROCESSING BOWL
AND LID
Ensure the switch is released, power is turned
o at power point and the appliance
is unplugged.
Hold the motor body with one hand and
using thumb and nger of the other hand,
press on the two EJECT buttons on either
side of the motor body. Pull the motor body
away from the chopper bowl lid to detach.
ASSEMBLY & OPERATION

18
TO DETACH THE GEARBOX FROM THE LID
• To remove the gearbox grasp the
gearbox and lift up from the processing
lid.
RECOMMENDATIONS WHEN USING
THE STICK MIXER WITH THE FOOD
PROCESSING BOWL
• Do not operate the stick mixer when the
food processing bowl is empty.
• The bottom of the food processing bowl
features a anti-slip rubber rim. This keeps
the food processing bowl stable, however
it is recommended during processing to
hold the motor body with one hand and
the food processing bowl and lid with the
other.
• When processing, cut food into uniform
sizes to ensure quicker, even and more
consistent results.
• The stick mixer blends foods and
liquids rapidly, therefore it is easy to
over process. Remember to check food
throughout the operation.
When using the shredding or slicing disc do
not allow the processing bowl to ll with food
beyond the MAX level indicated. Processing
food beyond this level could damage parts
of the bowl and lid
NOTE
CAUTION:
DO NOT process hard foods such as
coee, grains or chocolate in lumps,
as damage to the blade may result.
DO NOT process boiling or hot foods
in the food processing bowl.
NEVER remove the blade from the
bowl before food processing
is completed.
Processing hard spices will cause the
chopper bowl to become cloudy over
time. Hard spices are best suited to
a spice grinder with a metal bowl.
ASSEMBLY OF THE POTATO MASHER LEG
Before rst use
Remove any packaging material and
promotional labels. Wash blade and two
parts of the mashing leg before use.
CAUTION:
Never immerse the motor body or
gearbox in water or any other liquid.
If the variable masher leg is already assembled
start from step 3.
NOTE
ASSEMBLY & OPERATION

19
1. Holding the outer leg and insert the
gearbox making sure ALIGN arrows are
aligned.
2. Hold both outer leg and gearbox rmly
with one hand and insert inner leg until
it clicks and locks into place.
3. Rotate gearbox while holding outer leg
to lock into place until it clicks.
4. Align the mashing leg with the motor
body and push the two parts together
until it clicks.
5. Place blade on underside of the mashing
head. To lock the blade rotate in
a anticlockwise direction. Blade will not
attach if the leg is not attached to the
motor body.
ASSEMBLY & OPERATION

20
TO USE THE POTATO MASHER LEG
For food preparation tips and recipes
refer to the recipes section. Ensure the
potato masher is completely and properly
assembled.
1. Place food to be mashed into
a suciently large mixing bowl or
container or in saucepan.
2. Insert the plug into a 230/240V power
outlet and turn the power on.
3. Select the desired setting on the variable
mashing leg: textured, smooth or creamy.
4. Select a high speed on the speed control
dial.
5. Place the potato masher into food
and press the trigger switch to turn the
masher on.
6. Move the masher through the
ingredients with a gentle raising and
lowering action until desired texture
is achieved.
7. Switch o the motor by releasing the
trigger switch before lifting the masher
out of the bowl. Switch o at the power
outlet and remove the power plug.
TO DETACH THE POTATO MASHING LEG
1. Ensure the trigger switch is released, the
power is turned o at power point and
the appliance is unplugged.
2. Before removing motor body, remove
masher blade by holding onto the blade
and turning clockwise to unlock.
3. Once blade is removed, hold the motor
body with one hand, and using thumb
and nger of the other hand, press on the
two EJECT buttons on either side of the
motor body. Pull the motor body away
from the masher to detach.
Mashing blade will not attach/detach if the leg
is not attached to the motor body.
NOTE
RECOMMENDATIONS WHEN USING WITH
THE POTATO MASHING LEG
• Release the trigger switch and ensure the
masher has completely stopped turning
before removing the masher from the
food during operation.
• Place the mixing bowl on a damp cloth
during mashing. This will keep the mixing
bowl stable.
USING AS A WHISK
Remove blending leg from motor body
(follow the instructions‘To detach the
blending leg’).
1. Align the whisk gear box to the hole in
the underside of the motor body and
push the whisk in until it clicks and locks
into place.
ASSEMBLY & OPERATION
