CC&T 1924 User manual

C C
& T CAROLINA CHAIR & TABLE COMPANY
Thank you for purchasing a Carolina Chair & Table Company product. This product has been designed for easy assembly and is
constructed for durability. Please take this time to read and follow the assembly instruction carefully. If a part or hardware is
missing or you have any difficulties in assembling this product, please contact us Toll-Free at 18002283876.
PARTS CHECK LIST
CODE COMPONENTS Q'TY
FITTINGS CHECK LIST
CODE DESCRIPTION Q'TY
ASSEMBLY INSTRUCTION
A SEAT x01
C FOOT RING x01
Dx08
E
F
x04
G
x12
JCBC M6 x 35mm
JCBC M6 x 40mm
SPRING WASHER M6
x08
FLAT WASHER M6
1.
ITEM#1924 /1930
Hx01
ALLEN KEY M4
B LEGS x04
A
B
C
D x6
F x6
G x6
H
Assemble legs (B) to the seat (A) with JCBC (D) , spring washer (F) and flat washer (G).
Do not tighten all the way until step 2 is completed.
B
B
B
A

3.
2.
ASSEMBLY
COMPLETED!!!
C
Tighten the foot ring (C) to leg (B) with JCBC (E) and spring washer (F).
Assemble legs (B) to the seat (A) with JCBC (D) , spring washer (F) and flat washer (G).
B
B
B
B
A
F x2
G x2
D x2
H
F x4
E x4 H
STEP 2
STEP 2.1
STEP 2 -
STEP 2.1 -
Please make sure all screws are tightened 100%.
